Sofa Control操作手册（中英文）沙发控制手册“目录表∙简介∙保持动作∙菜单按钮∙全局菜单∙多点击∙脚本切换∙文件选择∙虚拟鼠标∙首选项∙脚本简介沙发控制是一种软件，使您可以与苹果远程控制或FrontRow Keyspan产品射频远程控制的其他应用程序。
遥控器提供了6个单独的按钮。
有了这六个按钮，你可以翻阅您的幻灯片，文档，浏览网页或快进看电影时。
为了实现这个沙发控制图对遥控器上的按钮的应用程序的功能。
有个别为每个受支持的的应用程序映射。
沙发控制的自我介绍。
启动后，它会呈现出短期和易于遵循的教程。
所有你需要的是远程控制。
如果你想获得一个快速启动，你应该给本教程的一个尝试。
您可以打开在任何时候从沙发控制的帮助菜单的教程。
保持动作您的远程控制所有的6个按钮的区分单一短按按钮，并按住一个按钮。
当您按住一个按钮，可以触发不同的动作，这样做。
例如VLC播放器，按下按钮上的“前进/右”切换到播放列表中的下一部电影看电影时，同时按住触发快速您正在观看的影片。
持有触发的动作取决于你使用的应用程序。
持有“播放”按钮的情况下，我们尽量保留了各地不同的应用程序的共同行动。
因此，举行演讲（主题演讲，PowerPoint等）正在使用的应用程序的“播放”按钮，将激活演示鼠标。
对于提供全屏视图，如iTunes，Quicktime播放器，VLC等，的应用程序，持有“播放”按钮，切换全屏视图。
菜单按钮CustomMenus thumbThe按钮遥控器上的“菜单”，在沙发控制的特殊含义。
并非所有应用程序的有用的功能，可以在遥控器上的六个按钮映射。
对于这些情况，并提供更先进的功能，提供应用程序特定的菜单。
按下“菜单”按钮，弹出该应用程序特定的菜单。
你可以从菜单触发的行动，取决于当前活动的应用程序。
全局菜单想改变系统音量或通过使用Exposé应用程序切换的行为不属于应用程序。
这些行动是对所有应用程序有用。
这些系统的水平，全球行动。
因此，这些行动是在全局菜单访问。
您激活全局菜单，按住菜单按钮2秒。
您可以定义要在沙发控制的喜好全球菜单操作。
多点击对于某些应用，六个按钮的限制是麻烦。
应用程序特定的菜单提供了更多的行动，但这些都需要至少两个以上的点击访问。
多的点击动作映射到多的点击事件的行动。
就像你双击你的鼠标左按钮，你也可以双击按下遥控器上的按钮。
双按，然后触发一个应用程序的功能。
多的点击次数是一项高级功能。
习惯它，所有的多单击“操作”也能够在应用程序特定的菜单激活。
多点击映射右侧菜单中的条目的可视化，就像你知道它从标准菜单。
见样本视图右侧截图。
脚本切换当您控制沙发控制你的Mac，您可能需要应用程序之间切换。
从全局菜单，可以激活和使用暴露在应用程序之间切换。
但会使您不幸的是，无法启动应用程序。
ScriptSwitcher thumbWith的脚本切换，您可以通过浏览可用的应用程序来激活并启动它们。
脚本切换器的设计类似于Mac OS X的应用程序切换，您访问的命令Tab快捷键。
要打开的脚本切换，打开全局菜单，按“菜单”按钮两秒钟。
选择的项目“选择脚本”打开脚本切换。
长按遥控器上的向左或向右按钮来浏览应用程序列表。
按加号按钮移动到列表的第一项，而负选择列表中的最后一个项目。
文件选择FileChooser thumbSofa控制提供了一个文件选择打开文件，电影，在您最喜爱的的应用程序，通过使用遥控器。
文件选择器可以通过特定的应用程序菜单访问。
每次打开一个文件，使用文件选择，沙发控制会记住你的决定。
下一次，你要打开该应用程序的一个文件，沙发控制自动带你到最近的地方，你选择了一个文件的地方。
沙发控制每个应用程序，找出哪些文件类型支持交互。
文件选择过滤掉这些文件不是由应用程序使用。
如果应用程序能够处理文件夹，像开放在预览的文件夹中的所有图片，你可以选择目录。
虚拟鼠标带沙发的控制，您可以使用遥控器来控制鼠标指针。
按下“播放”按钮，您可以通过点击鼠标左键，通过使用加/减和左/右按钮移动并甚至像点击鼠标右键或拖放从虚拟鼠标特定的菜单。
虚拟鼠标可以很容易地在任何时间通过全局菜单访问。
通过虚拟鼠标特定的菜单，你也可以立即返回到您以前使用的应用程序。
与演示鼠标，我们提供了一个专门的变种，那些上演。
在每一个就是给演示文稿（PowerPoint中，主题演讲时，Adobe Acrobat，VoodooPad ,...)你可以通过按住“播放”按钮激活演示鼠标中使用的应用程序。
演示鼠标自动突出显示屏幕下方的鼠标指针的一部分。
要退出演示鼠标，只要按下遥控器上的“播放”按钮。
虚拟远程控制沙发控制提供了键盘快捷键来模拟远程控制。
这些键盘快捷键可用于控制和使用的沙发与可编程器件的控制。
虚拟远程控制是默认关闭。
您必须启用激活的选项高级设置窗格中的虚拟远程控制在沙发控制喜好。
沙发控制下开始后，以下键盘快捷键可用于控制沙发控制。
键盘快捷键模拟遥控器按钮控制命令Shift - F1键加号按钮控制命令SHIFT - F2减号按钮控制命令SHIFT - F3播放按钮控制命令SHIFT + F4左键控制命令SHIFT - F5右按钮控制命令Shift键F6菜单按钮控制命令SHIFT - F7播放按住首选项沙发通过控制选项对话框，您可以调整一下，觉得您的个人需要和沙发控制。
一般设置：如果你要隐藏的沙发从Dock控制，您可以启用，使用菜单额外的沙发控制。
承认双击的最大时间，也可以调整。
全局菜单设置沙发大量的全球行动控制船舶。
其中只有少数是默认激活。
您可以激活并重新排列它们，因为你喜欢在全局操作设置。
视觉效果设置如果你有一个以上的显示器连接到Mac，你可以定义应用于显示脚本切换，菜单和文件选择。
以及颜色的视觉效果和视觉效果的大小可调。
Virutal鼠标沙发控制虚拟鼠标来突出显示鼠标光标下的的东西用鼠标轻。
滑鼠的灯的颜色和半径可配置。
如果你有一个从Boinx Mouseposé许可，您可以配置沙发控制使用。
脚本ScriptsWindow thumbSofa控制使用AppleScript来控制其他应用程序。
AppleScript 是苹果提供的语言，做自动化的工作流程和控制应用程序在Mac上。
对于每个沙发控制支持的应用程序，一个专门的脚本已经研制成功。
这些脚本定义映射到应用程序的一个特定功能的遥控器上的行动。
这些脚本非常简单，只需发送到目标应用程序的键盘快捷键，以控制它。
其他的要复杂得多，因为他们使用的目标应用的特定功能，以更好地控制他们。
要查看系统上安装脚本，打开脚本窗口。
要打开“脚本”窗口，选择菜单项“安装的脚本”从沙发上控制菜单“脚本”。
脚本“窗口为您提供了安装脚本，他们是活跃的概述。
您可以禁用脚本称为列的复选框取消选择“使用”。
禁用的脚本不再使用的沙发控制，但仍然是您的系统上安装的脚本。
如果你想从系统中删除脚本，只需按较低的窗口左上角的减号按钮。
本地更改与明星在其名称中标明的脚本有局部变化。
这意味着您已更改脚本，但脚本的版本号并未改变。
有了这个标记，沙发控制能够找出局部的变化，如果你有。
当您下载一个沙发控制更新，将最有可能取代你的变化，这一点很重要。
变了一个脚本被替换时，备份的脚本存储在您的桌面上。
一些脚本可能会禁用系统上没有安装所需的应用程序。
要看到这些脚本以及从脚本“窗口右下角列表中，选择”禁用脚本“。
脚本共享左下方的操作按钮下方的“减”按钮提供了一些选项，导入和导出脚本。
这使您能够共享脚本，或从我们的网站导入的新的和更新的脚本。
创建自己的沙发控制脚本编辑器，可以很容易编写自己的脚本。
我们在下面的教程一步一步如何编写自己的脚本。
我们要控制一个新的脚本的应用程序是通讯簿，船舶与Mac OS X我们想要达到的目标：▪通过您的联系方式，按遥控器上的左/右的开关▪按遥控器上的加/减的名单和联系单视图之间切换▪显示的姓名和电话号码，按下“播放”按钮时，步骤1：创建一个新的空脚本在第一步，我们要创建一个新的脚本。
1。
选择从沙发上控制“文件”菜单的菜单项“新建脚本”。
一个新的脚本窗口将打开。
NewScript的第一步thumbThe脚本编辑器的主要部分是脚本本身。
该脚本的第一部分（作为注释标记（*和*））是只对文件的目的。
您应该使用的那部分文件的映射。
这些信息，我们可以提取和格式的脚本文件。
沙发控制脚本包含多项功能。
在AppleScript函数以关键字“”的函数的名称。
该功能“rcActivate”已经被添加到脚本。
脚本被激活时，这个函数将被调用。
通常情况下，要激活在激活过程中的目标应用。
占位符代码已经添加要做到这一点。
我们唯一需要做的是插入我们想控制的应用程序的名称。
在我们的例子中，这是“通讯录”2。
“应用程序名”文本替换“通讯录”。
确保您不要删除引号。
3。
按下按钮“验证”，让沙发控制验证脚本。
NewScript的第一步完成thumbIn验证失败的错误代码的情况下，正在凸显。
如果验证成功的代码片断将被格式化，脚本的个别部分突出。
在下一步中，我们配置的脚本，所以它是用于控制地址簿应用程序。
下面的脚本编辑器的工具栏，你找到喜欢的名称和版本的脚本信息。
在第二行有一个复选框，说：“自动控制没有应用程序”。
我们必须改变，“自动控制通讯录”，以告诉沙发控制应用程序的地址簿，应当使用这个脚本。
4。
按一下的话：“没有应用程序”，选择“通讯录”。
同时检查“复选框。
沙发控制会自动设置脚本的名称为“通讯录”，并设置图标。
当然你也可以改变为任何你喜欢的名称。
然后再继续下一步，确保你的脚本窗口右侧的截图看起来类似。
第2步：地图按钮，键盘快捷键在第二个步骤，我们遥控器上的加/减和左/右按钮映射到地址簿的功能。
使自己熟悉与正在通过其菜单翻转通讯簿支持键盘快捷键。
我们要创建以下映射：遥控器按钮键盘快捷键左=>命令[右声道=>命令]另外=>命令2减=>命令1创建一个映射是一个简单的过程。
首先，你添加脚本函数将被调用时被按下遥控器上的按钮。
比你添加的代码发送的键盘快捷方式的目标应用。
1。
选择从工具栏操作“菜单上的”左“的行动。
被称为左边的按钮时，按下遥控器上的功能的代码被添加。
rcLeft（上）（*左按钮被按下时执行的代码。
*）年底rcLeft2。
设置光标后评论“*）”，然后按Enter添加一个新行。
现在我们要添加的代码来模拟键盘快捷键命令。
3。
按“记录键”。
切换到地址簿。
按命令并返回到沙发控制。
4。
按“插入代码”添加代码来模拟键盘快捷键的脚本。
在工具栏按确认完成。
重复这些步骤，为其他三个快捷。
您可以下载第2步生成的脚本。
在任何时候，你可以测试你的脚本，按工具栏按钮“运行脚本”。
步骤3：使用沙发控制可视化的显示名称在这一步，我们将得到当前选中的人的姓名和电话号码。
