H3C路由器基本配置命令大全

H3C路由器基本配置命令有哪些?下面跟gkstk小编一起来学习一下吧! [Quidway]displayversion 显示版本信息

[Quidway]displaycurrent-configuration 显示当前配置

[Quidway]displayinterfaces 显示接口信息

[Quidway]displayip route 显示路由信息

[Quidway]sysnameaabbcc 更改主机名

[Quidway]superpasswrod 12345设置口令

[Quidway]interfaceserial0 进入接口

[Quidway-serial0]ipaddress

[Quidway-serial0]undoshutdown 激活端口

[Quidway]link-protocolhdlc 绑定hdlc协议

[Quidway]user-interfacevty 0

[Quidway-ui-vty0-4]authentication-modepassword

[Quidway-ui-vty0-4]setauthentication-mode

password simple22

[Quidway-ui-vty0-4]userprivilege level

[Quidway-ui-vty0-4]quit

[Quidway]debugginghdlc all serial0 显示所有信息

[Quidway]debugginghdlc event serial0 调试事件信

1 / 8

精品文档

息

[Quidway]debugginghdlc packet serial0 显示包的信

息

[Quidway]iproute-static

{interfacenumber|nexthop}[value][reject|blackhole] 例如:

[Quidway]iproute-static 129.1.0.0 110.0.0.2 [Quidway]iproute-static 129.1.0.055.255.0.0 10.0.0.2 [Quidway]iproute-static 129.1.0.0 1Serial [Quidway]iproute-static 0.0.0.0 0.0.0.0 10.0.0.2 [Quidway]rip

[Quidway]rip work

[Quidway]rip input

[Quidway]ripoutput

[Quidway-rip]network1.0.0.0 ;可以all

[Quidway-rip]network2.0.0.0

[Quidway-rip]peerip-address

[Quidway-rip]summary

[Quidway]ripversion 1

[Quidway]ripversion multicast

[Quidway-Ethernet0]ripsplit-horizon ;水平分隔

2 / 8

精品文档

H3C路由器基本配置命令大全H3C路由器基本配置命令

大全

[Quidway]router idA.B.C.D 配置路由器的ID

[Quidway]ospfenable 启动OSPF协议

[Quidway-ospf]import-routedirect 引入直联路由

[Quidway-Serial0]ospfenable area 配置OSPF区域

acl [match-order config|auto] 默认前者顺序匹配。

rule[normal|special]{permit|deny} [source source-addr source-

wildcard|any]

例:

[Quidway]acl 10

[Quidway-acl-10]rulenormal permit source 10.0.0.0 0.0.0.255

[Quidway-acl-10]rulenormal deny source any

扩展访问控制列表配置命令

配置TCP/UDP协议的扩展访问列表:

rule{normal|special}{permit|deny}{tcp|udp}source

{|any}destination|any}

[operate]

rule{normal|special}{permit|deny}icmp source {|any]destination{|any]

3 / 8

精品文档

[icmp-code][logging]

扩展访问控制列表操作符的含义

equalportnumber 等于

greater-thanportnumber 大于

less-thanportnumber 小于

not-equalportnumber 不等

H3C路由器基本配置命令大全文章H3C路由器基本配置

命令大全出自

，转载请保留此链接～

range portnumber1portnumber区间

[Quidway]acl 101

[Quidway-acl-101]ruledeny souce any destination any

[Quidway-acl-101]rulepermit icmp source any destination any icmp-type echo

[Quidway-acl-101]rulepermit icmp source any destination any icmp-type echo-reply

[Quidway]acl 102

[Quidway-acl-102]rulepermit ip source 10.0.0.1 0.0.0.0 destination02.0.0.1 0.0.0.0

[Quidway-acl-102]ruledeny ip source any

4 / 8

精品文档

destination any

[Quidway]acl 103

[Quidway-acl-103]rulepermit tcp source any destination 10.0.0.1 0.0.0.0 destination-port equal ftp
