【科学课件】聚苯并咪唑的合成和表征

合集下载

A-O-34_新型可溶性聚苯并咪唑的合成与性能研究

新型可溶性聚苯并咪唑的合成与性能研究徐静，刘程，蹇锡高（大连理工大学高分子材料系，大连市中山路158号42信箱，116012）关键词: 聚苯并咪唑二氮杂萘酮耐热性溶解性聚苯并咪唑（Polybenzimidazole ）是一类重要的特种工程塑料，具有优异的热稳定性、阻燃性、耐腐蚀性和机械性能等特点[1-2]，广泛应用于航空航天、电子电气等领域。

聚苯并咪唑通常具有刚性的主链结构，导致其具有很高的熔点以及溶解性差的缺点，如商品化的聚苯并咪唑是由间苯二甲酸和3,3’-二氨基联苯二胺缩聚合成的，具有刚性结构，而且加工性差，使其应用范围受到一定的限制。

在分子主链中引入柔性基团（如醚键、砜基、烷基等）[3-5]或体积较大的基团[6]等可以改善聚苯并咪唑的溶解性，但会降低其耐热性能；也有文献报道了将咪唑环上的氢进行芳环取代可以提高聚苯并咪唑的耐热和氧化稳定性[7]；除此之外，在聚合物主链中引入芳杂环结构可以提高聚合物的耐热性能，如吡啶、三唑等[8]。

本文通过在聚苯并咪唑的分子主链中引入扭曲、非公平面二氮杂萘酮联苯结构，以改善其溶解性能，同时赋予其优异的耐热性，报道了一系列新型含二氮杂萘酮联苯结构的聚苯并咪唑均聚物和共聚物的合成、表征和性能。

PPBI NH N NN H O N N O n N H N N H N NN HH NN O N N O coPPBI m n Scheme 1 Structures of polybenzimidazole containing phthalazinone moiety (PPBI and coPPBI ) 本文采用溶液缩聚法合成聚苯并咪唑，以自制的二酸单体4-[4-（4-羧基苯氧基）苯基]-2-（4-羧基苯基）二氮杂萘-1-酮（DHPZ-DA ），为二酸单体，与3,3’-二氨基联苯胺（DAB ）进行缩聚反应，制备了含二氮杂萘酮联苯结构聚苯并咪唑均聚物（PPBI ）；并以DHPZ-DA 和间苯二酸（IPA ）为二酸单体，采用不用摩尔配比，与DAB 进行共缩聚（coPPBI ），制备了一系列具有不同二氮杂萘酮联苯结构含量的聚苯并咪唑共聚物。

聚苯并咪唑的合成及应用研究进展

V ol 36N o 8 36 化工新型材料N EW CH EM ICAL M A T ERIA L S 第36卷第8期2008年8月作者简介:马涛(1978-),男,兰州大学高分子化学与物理专业在读博士,师承李彦锋教授,从事于耐高温高分子材料的研究。

联系人:李彦锋。

聚苯并咪唑的合成及应用研究进展马涛李彦锋* 赵鑫邵瑜宫琛亮杨逢春(兰州大学化学化工学院,兰州大学生物化工及环境技术研究所,兰州730000)摘要介绍了国内外有关聚苯并咪唑高分子材料的研究状况。

论述了聚苯并咪唑的发展,二元酸和四胺单体的合成方法、聚合工艺、种类及国内外应用状况,并对聚苯并咪唑的发展方向和研究热点进行了分析。

关键词聚苯并咪唑,单体合成,聚合,应用Progress on synthesis and application of polybenzimidazolesM a Tao Li Yanfeng Zhao Xin Shao Yu Go ng Chenliang Yang Feng chun (College of Chemistr y and Chemical Eng ineering ,Institute of Biochemical Eng ineering &Environmental Technolog y,Lanzhou U niversity ,Lanzhou 730000)Abstract T he pro g ress of polybenzim idazoles was reviewed.T he char act er o f polybenzimizo les on phylog eny ,monomer,poly merization technolog y,and applicatio ns w ere detailedly descr ibed,meanwhile,the develo pments of po ly benzim izo les w ere obviously presented.Key words po ly benzimidazo le,monomer sy nthesis,polymer ization,applicat ion随着航天技术的发展,特别是航天器飞行速度和有效载荷与结构质量比的提高,耐高温先进复合材料正在成为最主要的航天结构新材料。

含有吡啶环的可溶型聚苯并咪唑共聚物的合成及表征

Ｓａｇａ２０４，Ｃｈｎ）ｈｎｈｉ０２０ｉａ
ＡｂｔａｔＣｏｌｍｅｓｃｎｔｉｎｒｄｉｅｒｎｇｓａｅｓｎｔｓｚｄｂｙｔｏｌｉｎｐｏｙｃｎｄｎｓｔｏｆ３，ｓｒｃ：ｐｏｙｒｏａｎｉｇｐｙｉｎｉｒｙｈｅｉｅｈｅｓｕｔｏｌｏｅａｉｎｏ３一
近几十年来，随着机械、电子、航空等尖端行业对耐热高分子材料需求的快速增加，杂环类聚合物材料芳的研究得到了迅猛发展，形成了聚酰亚胺（Ｉ、苯并咪唑（Ｂ）Ｐ）聚ＰＩ以及聚吡咙（Ｐ）含杂环的高分子化合Ｐｙ等物，在实际中得到了广泛的应用Ｌ。一般而言，有Ｎ、并１］含Ｏ等杂原子的芳香环结构具有优异的热稳定性、化学稳定性，的还具有良好的极性和介电性能。同时，有含有杂环和芳环的高分子材料由于分子链刚性很大且
应的基础上，入含有吡啶环的新单体 —— ２３５６四氨基吡啶（Ｐ，成了一种新型可溶性共聚型聚苯加，，，一ＴＡ）合
并咪唑。实验表明，用Ｄ使ＡＢ、Ｐ、，二羧基二苯醚（ＣＥ３种单体可以在较低温度的条件下合成ＴＡ４４＿ｒＤＤＰ）
ＰＩＢ。２年后，ｇｌ阳备了具有优异热性能的ＰＩ聚合物。上述研究中所合成的ＰＩＶｏｅ等口制Ｂ类Ｂ均具有较好的

具有烷基磺酸侧链的凝胶型聚苯并咪唑质子交换膜的制备与表征

化工进展Chemical Industry and Engineering Progress2024 年第 43 卷第 4 期具有烷基磺酸侧链的凝胶型聚苯并咪唑质子交换膜的制备与表征朱泰忠1，张良1，黄泽权1，罗伶萍1，黄菲1，薛立新1，2（1 浙江工业大学化工学院膜分离与水科学技术中心，浙江杭州 310014；2温州大学化学与材料工程学院，浙江温州 325035）摘要：磷酸（PA ）掺杂聚苯并咪唑（PBI ）以其优异的热化学稳定性和高玻璃化转变温度成为高温质子交换膜燃料电池（HT-PEMFCs ）的首选材料。

然而，由于低温下磷酸较弱的解离度和传递速率，导致膜的质子传导性能不佳，电池冷启动困难。

因此，研发可在宽温湿度范围内高效运行的高温质子交换膜成为当前挑战。

特别是拓宽其低温运行窗口、实现冷启动对这类质子交换膜燃料电池在新能源汽车领域的实际应用具有重要意义。

本文通过多聚磷酸溶胶凝胶工艺与内酯开环反应设计并合成了一系列磷酸掺杂的具有柔性烷基磺酸侧链的凝胶型聚苯并咪唑质子交换膜。

重点探究了烷基磺酸的引入以及侧链长度对磷酸掺杂水平、不同温湿度下的质子传导率及稳定性的影响规律。

研究结果表明，所制备的质子交换膜具有凝胶型自组装片层堆叠的多孔结构，有利于吸收大量磷酸并提供质子快速传输通道。

其中，PA/PS-PBI 展现出了在宽温域范围内均优于目前所报道的其他工作的质子传导性能。

特别是常温下，其质子传导率从原膜的0.0286S/cm 提升至0.0694S/cm 。

80℃下，其质子传导率从原膜的0.1117S/cm 提升至0.1619S/cm 。

200℃下，其质子传导率从原膜的0.2609S/cm 提升至0.3578S/cm 。

此外，该膜在80℃和0%相对湿度（RH ）条件下仍可具有与Nafion 膜在100%RH 时相当的质子传导率，为打破质子交换膜经典定义、实现宽温域（25~240℃）运行提供新的方案。

聚苯并咪唑树脂的合成与性能研究

ylmethane；polybenzimidazole；thermal stability
II
聚..............................................1
1.1 聚苯并咪唑树脂的概述.....................................................................................................1 1.2 聚苯并咪唑的发展概况.....................................................................................................1 1.3 合成聚苯并咪唑的主要单体与工艺.................................................................................3
学校代码 10530 分类号 O633.5
学号 200706020975 密级
硕士学位论文
聚苯并咪唑树脂的合成与性能研究
学位申请人指导教师学院名称学科专业研究方向
张海林原斌教授
化学学院有机化学精细有机合成
二零一零年五月二十日
Study on the Preparation and Performance of Polybenzimidazole resin
作者签名：
日期：年月日
学位论文版权使用授权书
本学位论文作者完全了解学校有关保留、使用学位论文的规定，同意学校保留并向国家有关部门或机构送交论文的复印件和电子版，允许论文被查阅和借阅。本人授权湘潭大学可以将本学位论文的全部或部分内容编入有关数据库进行检索，可以采用影印、缩印或扫描等复制手段保存和汇编本学位论文。

聚苯并咪唑纤维

学号姓名
材料性能材料制作方法材料发展历程与应用
2012-7-3
材料全称：聚2,2`-间亚苯基-5,5`-双苯并咪唑纤维抗张强度：39.7～43.2cN／tex
（短纤维为27.4cN/tex）延伸率：23％～24％（短纤维为30％）吸湿率：高达15％，高于棉花突出性能：尺寸稳定性、阻燃性；耐强酸、强碱、有机溶剂；耐高温、耐化学品腐蚀；良好的纺织性能
ห้องสมุดไป่ตู้
湿法纺丝：PBI
拉伸、热定型
乙二醇凝固浴
（高温下）水洗、干燥纤维
发展历程
聚苯并咪唑纤维于20世纪60年代初由美国空军材料实验室研制成功。1983年由美国塞拉尼斯公司正式投产，年生产能力为 460t，因生产成本高，发展缓慢。它是一种典型的杂环高分子耐热纤维，大分子主链上含有苯并咪唑撑，它主要作为宇航密封舱耐热防火材料﹐由于核纤维吸湿率高达15%﹐因此自1983年后﹐又开发了穿著舒适的高温防护服等民用产品。
可作气体、液体的耐腐蚀滤材和烟道气滤袋，可在150～ 200℃范围内使用，在酸的露点温度以下不受腐蚀。
2012-7-3
聚苯并咪唑纤维还可与聚间苯二甲酰间苯二胺纤维混织，经碳化以后的纤维可作复合材料的高强度、高模量增强材料，其中空纤维（见化学纤维）可用作反渗透膜。
聚苯并咪唑纤维
应用
制作宇宙飞船中的绳索、耐烧蚀热屏蔽材料、减速用阻力降落伞及宇航员的加压安全服等。曾经用它制作阿波罗号和空间试验室宇航员的航天服和内衣。
2012-7-3
在一般工业中可作石棉代用品，包括耐高温手套、高温防护服、传送带等，使用温度常为 250～300℃，能在500℃下短时间使用

一种聚苯并咪唑类树脂的制备方法

专利名称：一种聚苯并咪唑类树脂的制备方法专利类型：发明专利
发明人：沈晶茹,李利红
申请号：CN202111185144.5
申请日：20211012
公开号：CN114058013A
公开日：
20220218
专利内容由知识产权出版社提供
摘要：本发明公开了一种聚苯并咪唑类树脂的制备方法，是由具有式2所示化学结构的芳族四胺与具有式3所示化学结构的六氯丙酮在反应溶剂中、于45～55℃下反应得到具有式1所示化学结构的聚苯并咪唑类树脂，其化学反应式如下：其中，R为四价芳基核，化合物2中的四个氨基成对出现在R中相邻碳原子的邻位碳原子上，n选自10至100中的任一整数。

本发明提供的制备方法，芳族四胺与六氯丙酮在45～55℃下反应即可制得聚苯并咪唑类树脂，操作简单，绿色环保、反应条件温和、生产效率高，适用于工业化生产聚苯并咪唑类树脂。

申请人：上海工程技术大学
地址：201620 上海市松江区龙腾路333号
国籍：CN
代理机构：上海海颂知识产权代理事务所(普通合伙)
代理人：马云
更多信息请下载全文后查看。

聚苯并咪唑的合成_性能及在燃料电池膜材料中的应用_浦鸿汀

与熔融聚合相比溶液聚合的优点有[12] : (1) 一步法代替二步法 ; (2) 对控温要求不严 ; (3) 溶剂中的极性化基团可以使过渡状态的产物溶剂化 ,从而降低活化能 ,使得反应可以在较低的温度和较短的时间内完成 ,从而降低了交联的可能性 ; (4) 在整个反应过程中都可以保证反应物充分混合 ,从而使活性端基可以很好地接触 ,而在熔融缩聚反应中端基有可能被包埋而不能接触 ; (5) 反应的副产物 ,如水、酚等可以通过沸腾的溶剂被带出反应体系 ,而在熔融缩聚中则被包含在体系中 ,影响聚合物分子量的提高 ; (6) 溶液状态或悬浮状态中的单体比在熔融状态中更容易脱除。 113 母体法
表 2 各种 PBI 的结构 Table 2 Different structures of PBI
R1 为以下结构 :
参考文献 R1 为杂环结构 : [2]
参考文献 R1 含杂原子结构 : [ 15 ]
[ 15 ] [2]
[2] [ 16 ]
[2]
R1 为其他结构 : [ 21 ]
[ 17 ]
1 PBI 的制备方法
PBI 的制备方法按反应种类分 ,大致有 4 种 :熔融缩聚法 (包括二步法和一步法) 、溶液缩聚法、母体
法、亲核取代法 , 其中对熔融缩聚和溶液缩聚的研究较多。PBI 的合成方法按反应单体分大致有 5 种[1 ,2 ,4 ,5] :四胺与二酸、四胺与二酯、四胺与二醛、四胺与二酰胺、四胺与二腈。其中 ,四胺与二酯的反应最
表 1 熔融一步法与二步法聚合的主要区别 Table 1 Differences between one2stage and two2stage polymerizations
一步法聚合

含苯并咪唑分子的合成及表征

含苯并咪唑分子的合成及表征亓昭鹏;程兴;李佩玉【摘要】A novel benzimidazole-containing compound, i.e. 3-（2-benzimidazolylmethyl）-1, 5-diamino- 3-azapentane is synthesized by a four-step reaction of protection, cyclization, substitution and hydrolysis, using chemical materials like diethylenetriamine, 1,2-diaminobenzene, and chloroacetic acid, etc. And then the structure of the compound is characterized by IR and 1H NMR.%以二乙烯三胺、邻苯二胺、氯乙酸等为原材料，经过保护，环化，取代，水解等步骤，得到了一个新颖的苯并咪唑的衍生物3-（2-甲基苯并咪唑）-1，5-二胺-3-氮杂戊烷，并通过红外光谱、核磁共振确定其结构。

【期刊名称】《黄山学院学报》【年(卷),期】2012(040)003【总页数】2页(P48-49)【关键词】3-（2-甲基苯并咪唑）-1;5-二胺-3-氮杂戊烷;合成;二乙烯三胺;邻苯二胺【作者】亓昭鹏;程兴;李佩玉【作者单位】黄山学院化学化工学院,安徽黄山245041;黄山学院化学化工学院,安徽黄山245041;黄山学院化学化工学院,安徽黄山245041【正文语种】中文【中图分类】O614.241苯并咪唑类化合物是一类具有良好生物活性的杂环化合物，广泛用于药物中间体、杀菌剂、驱虫剂等，在抗癌、镇痛、抗风湿、抗病毒等方面都有重要的药用价值。

[1-3]而且，含苯并咪唑类化合物具有较强的配位能力，也是配位化学领域中一个十分活跃的课题，常被用作超氧化物歧化酶活性中心的模拟物等。

聚苯并咪唑胶粘剂的合成

聚苯并咪唑胶粘剂的合成一、聚苯并咪唑的合成及性能聚苯并咪唑是杂环高分子中第一个被考虑作为耐高温结构胶粘剂的，它是从3，3’-二氨基联苯胺（DAB）和间苯二甲酸二苯酯进行熔融缩聚反应制得。

合成聚苯并咪唑的方法除熔融缩聚以外，还可以用溶液缩聚方法合成，而不同方法制备的聚苯并咪唑，其粘度也不相同。

聚苯并咪唑的特点是瞬时耐高温性优良，在538℃不分解，而聚酰亚胺的分解温度比它低。

到目前为止，研究得比较多的是聚[2，2’-间苯基-5，5’-二苯并咪唑]。

它的预聚物能溶于二甲基甲酰胺（DMF）、二甲基乙酰胺（DMAc）、二甲基亚砜（DMSO），N-甲基吡咯酮（NMP）、六次甲基磷酰胺（HMPA）、甲酸、硫酸等强极性溶剂中。

在70%硫酸或25%氢氧化钾溶液中不分解，在浓盐酸中加热也不溶解。

但预聚物再400℃处理一段时间待固化完全后，分子量增大，溶解度降低，就成为不溶不熔的树脂而难以加工成型。

因此在应用过程中先制成低分子量的预聚物。

这种低分子量的预聚物，具有比较好的流动性和对基材的浸润性。

作为胶粘剂和复合材料所需的树脂，一般是二聚体和三聚体，不过这就意味着在进一步缩合中会产生挥发分（水与苯酚），致使胶层及界面上出现针孔。

若大面积胶接则必须在高温（399℃）和加压0.686MPa下固化。

研究表明聚苯并咪唑核上NH的H原子是氧化破坏的活性中心，如用苯基C6H5-或甲基CH3-来取代该H原子，则高聚物的性能发生一定的变化。

当R=C6H5-时，热稳定性比未取代的略佳，但高聚物是热塑性的，应力受到了限制。

研究还表明甲基的取代位置对高聚物的性能有很大的影响，此外，在聚苯并咪唑的主链中引入氧、硫、亚甲基或其他基团可以改变聚苯并咪唑的性能。

比如引入醚键可以增加聚苯并咪唑的溶解性和分子链的柔性，改进成膜性能，还有良好的耐热性，但醚键的位置对热稳定性有一定的影响。

间苯二乙酸和间苯二甲酸混合物与DAB起反应制得的高聚物性能较好，溶解性也有改进，所有聚合反应都是在170℃多聚磷酸（PPA）中进行的。

聚苯并咪唑PBI

聚苯并咪唑(polybenzimidazoles)主链含重复苯并咪唑环的一类聚合物。

英文缩写PBI托基纶（Togylen）。

由芳族四胺和脂族或芳族二羧酸酯制备的聚苯并咪唑结构为：式中R为烷基碳链，Ar为芳香环结构。

聚烷基苯并咪唑的密度1.2克/厘米3，玻璃化温度234～275℃；全芳族聚苯并咪唑的密度1.3～1.4克/厘米3，玻璃化温度比前者高100～250℃。

聚苯并咪唑最突出的优点是瞬间耐高温性，烷基PBI在465～475℃才完全分解，芳基PBI 在538℃尚不分解，900℃失重仅30% ，常期使用温度300～370℃。

此外耐酸碱介质、耐焰和有自灭性、良好的机械和电绝缘性，热收缩极小。

制备方法由多胺与二酸或二酯在高温下熔融缩聚，先生成可溶性的聚氨基酰胺，然后通过脱水环化反应生成咪唑环聚合物。

高温（ 400℃）处理到完全固化后，聚合物变为不溶不熔。

典型的聚合物由 3，3′-二氨基联苯和间苯二甲酸二苯酯缩合而成，其纤维称PBI纤维。

工业上可采用熔融本体缩聚工艺制备PBI，即在惰性气体保护下按照一定比例是单体TAB和DPIP熔融本体缩聚反应合成PBI：上述的缩聚反应分两个阶段进行。

第一阶段为预缩聚，反应温度270~300℃，反应时间1~2h，除去副产物苯酚和水得到泡沫状预聚体，将其冷却和粉碎后再在真空下与375~400℃固相聚合2~3h，制成黄棕色粒状PBI树脂。

制备工艺——纺丝成型聚2,2`-间亚苯基-5,5`-双苯并咪唑（PBI）的纺丝溶剂主要有硫酸—水溶液、二甲基甲酰胺（DMF）、二甲基亚砜（DMSO）和二甲基甲酰胺（DMAC）等，其中DMAC较理想，是适宜的纺丝溶剂。

制备纺丝原液时，将粒状PBI加入DMAC 中，边搅拌边加热到250℃左右，聚合物全部溶解，配制成重量浓度约25%、室温下粘度约150Pa·s(1500P)的纺丝原液。

为防止纺丝原液因氧化交联而出现凝胶现象，需要在溶解及纺丝过程中保持非氧化条件。
