Parker与伊顿管接头对照表
parker接头、派克接头简介
parker 接头简介Parker 接头，是美国ParkerHannifin 公司德国工厂的德国工程师Ermto（埃米托）发明于上世纪30 年代，为了纪念其用其名字命名为parker接头，parker接头又名parker卡套式管接头。
Parker接头在中国------parker 接头特性：派克卡套式管接头因其特有的装配方便（仅需两把扳手）而广受欢迎。
经过近80多年的发展，EO工厂始派克接头图册(7张)终保持着卡套式管接头技术的领先地位。
今天，parker管接头是世界上使用最为广泛的一种管接头。
EO管接头是为公制管子设计的，历史上曾经依照德国标准DIN3861、DIN3859和DIN2353，现在这些标准已被国际标准ISO8434取代。
Parker管接头以体积小，压力等级高而著称。
分为低压、中压和高压三个系列（LL、L、S系列）这样使得各种不同的应用场合可以实现最经济化和空间最小化的方案。
parker 接头材质及规格Parker 管接头的材料除了最常见的碳钢镀锌以外，还提供铜和不锈钢两种材料，以适应不同的流体或环境条件。
Parker不锈钢接头的螺母螺纹采用镀银并预先润滑（规格15L-42L，12S-38S），较小规格的螺母螺纹采用蜡封，这样不仅有效的消除了不锈钢螺纹的咬合现象，同时减少40%装配拧紧力矩。
Parker管接头具有50多种不同的形式，可供各种不同应用场合的灵活选择，加上许多parker功能管接头，如旋转接头、球阀、单向阀、截止阀、测压接头等与parker 管接头配合使用，可大大方便系统的配套，提高系统密封的可靠性。
PARKER 液压软管具有防腐、耐高温、抗拉强度高，柔韧性好等诸多性能，而被广泛采用在各行业的液压工程中，派克软管有一层至多层钢丝编织增强层（6层以上），有低、中、高、超高三种压力等级，有轻、重两系列，公称通径在3 — 32mm。
有普通型和特殊型两种软管以满足在普通环境及特殊环境下使用，先进的不剥胶软管极大减轻装配劳动强度，广泛应用在各行业液压系统管路中。
PARKER_接头基础
– 例：Ferulok, EO :卡套扣咬住(切入)管外壁，形成 密封。
接头密封 形式
密封形式Leabharlann • 24°扣咬型(切入型) 续
– 例：EO-2: 功能螺母把弹性密封圈、金属 定位环、卡套集合为一体 – 由功能螺母、接头体(可与EO互换)组成 – 弹性密封圈提供密封功能 – 定位环咬住(切入)管外壁。
谢 谢！
UNF 螺纹命名： 3/4-20 UNF 尺寸 螺距 型式 12 20 UNF
常用英制螺纹型式：NPT、NPTF、UN、UNF、BSPT、BSPP
接头解析 接头螺纹-命名
• 公制螺纹：公制-螺纹尺寸-螺距 例: 螺纹尺寸=12，螺距=1.5mm 螺纹命名： M12*1.5 公制 尺寸 螺距 M 12 1.5
螺纹型式 英制螺纹
BSPT/BSPP： 在欧洲、日本等国使用广泛 BSPT螺纹是锥形螺纹，与NPT螺纹型式相似 BSPP螺纹是直螺纹，与NPSM螺纹型式相似
螺纹型式 公制螺纹
ISO 261公制平行螺纹：
符合ISO 6149和ISO 9974标准 ISO 6149使用公制平行螺纹直提供机械支撑力 密封型式同SAE J1926相似
接头基础 知识
接头基础 知识
• • • • 什么是接头? 其功能是什么? 接头解析 螺纹型式 接头密封型式
什么是接头? 其功能是什么?
使用接头的目的：各种流体动力元件间的液 压或气压管路的连接需要各种类型的接头。 把管联接到液压系统上. 接头提供防渗漏密封 和系统的接口
接头解析
油口端&管末端: 接头是一种连接流体动力系统元件的连接件 ，所有的接头除了堵头、堵帽之外，都至少 有两个端口。
接头密封 形式
密封形式
Parker流体连接件
Parker流体连接件Parker流体连接件Parker Fluid connectors productParker流体连接件 :包括 EO，EO2液压卡套接头，DIN⽆缝钢管，PARKER软管,PARKER软管接头，PARKER免剥胶软管，PARKER液压软管，软管接头及各类软管总成，测压管总成， PARKER软管接头外连接形式DKO 24°锥，NPT美制锥螺纹，JIC37°扩⼝，ORFS美制平⾯密封，JIS60°锥，JIS30°扩⼝，SAE法兰等。
快速接头，单向阀，球阀，管夹等各类液压连接件及卡套预装机，软管扣压机，⼿动弯管器，液压测试仪等。
Parker 快速接头Parker CPI&A-LOK卡套接头Parker MPI卡套接头Parker PHASTITE接头Parker EO2不锈钢接头Parker EO黄铜接头Parker EO渐进式卡套接头Parker EO-DUR不锈钢接头Parker EO焊接接头Parker O-LOK Plus断⾯密封接头Parker 硬管接头Parker 黄铜过渡接头Parker ⽓动接头Parker EO单向阀Parker EO截⽌阀及⼆通球阀Parker Prestomatic 2⽓制动接头Parker EO钢管Parker EO管夹Parker Triple-Lok 37° 扩⼝式接头Parker 仪表PIPE接头和ISO转换接头Parker PIPE活接头Parker 液压法兰及组件Parker 快速接头及诊断设备Parker Parflange F37⾼压⼤尺⼨液压管接头Parker O-LOK接头Parker Ermeto接头Parker橡胶液压软管Parker Parflex热塑软管Parker矿⼭机械⽤胶管,SteckO胶管接头和过渡接头Parker碳钢、不锈钢过渡接头Parker fittingsParker Quick Couplings and AccessoriesParker流体连接件PDF资料下载⽂件名称美国Parker流体连接件中国区产品⼿册 3400-CNParker软管，接头及设备Parker硬管接头及设备Parker快速接头Parker诊断设备 , Parker诊断，测试设备Parker技术⼿册Parker过程控制⾏业产品选型指南 Catalog 4204-ProcessParker Parkrimp 扣压系列 Push-Lok 可拆式 26系列软管接头Parker Parkrimp 扣压系列 Push-Lok 可拆式 43系列软管接头Parker Parkrimp 扣压系列 Push-Lok 可拆式 70系列软管接头Parker Parkrimp 扣压系列 Push-Lok 可拆式 73系列软管接头Parker Parkrimp 扣压系列 Push-Lok 可拆式 77系列软管接头Parker Parkrimp 扣压系列 Push-Lok 可拆式 78系列软管接头Parker Parkrimp 扣压系列 Push-Lok 可拆式 79系列软管接头Parker Parkrimp 扣压系列 Push-Lok 可拆式 82系列软管接头Parker 软管 201和206系列交通⾏业软管Parker 软管制冷⾏业软管 285,244系列Parker 软管交通⾏业软管 293,213系列Parker 软管液压软管 302,436系列Parker 软管磷酸酯软管低温软管 304,472LT系列Parker 软管恒压软管 351TC,351ST系列Parker 软管液压软管 372,701系列Parker 软管铁路⾏业软管 441RH,372RH系列Parker 软管恒压软管 451TC, 451ST, 451TC Twin系列Parker 软管液压软管 471TC, 471ST, 471TC Twin系列Parker 软管液压软管 482TC, 482ST, 426系列Parker 软管液压软管 611, 601系列Parker 软管交通⾏业软管, 新能源/船舶⾏业软管 611HT, SS23CG系列Parker 软管铁路⾏业软管, 681DB, 421RH 系列Parker 软管低温软管, 722LT, 792LT 系列Parker 软管恒压软管, 722TC 系列Parker 软管液压软管 731, JK 系列Parker 软管恒压软管, 781, P35 系列Parker 软管恒压软管, 787TC 系列Parker 软管恒压软管, 791TC, 792ST 系列Parker 软管恒压软管, 797TC 系列Parker 软管吸油/回油软管, 811, 811HT 系列Parker 软管 Push-Lok 软管, 821, 821FR 系列Parker 软管 Push-Lok 软管, 836, 804 系列Parker 软管吸油/回油软管, Push-Lok 软管, 881, 801 系列Parker 软管设备及附件台式切割机台式软管切割机 CTH-1Parker 软管液压软管 H561, 422 系列Parker 软管技术信息如何订购软管，接头与设备Parker 软管技术信息 Media 介质Parker 软管接头及设备 PARKER_HOSE_OVERVIEW_CNParker 软管技术信息如何订购软管，接头与设备软管总成⽣产步骤Parker 派克软管、硬管、接头、连接器、阀及相关附件的选型使⽤安全指南Parker 软管设备及附件 KK2扣压机操作指南Parker 软管设备及附件 KK2便携式扣压机Parker 软管技术信息 Parkrimp No-Skive软管总成⽣产步骤Parker 软管设备及附件 PK2扣压机操作指南Parker 软管设备及附件 PK2扣压机Parker 快换接头通⽤型60 系列快换接头Parker 快换接头螺纹连接型6100 系列快换接头Parker 快换接头通⽤型6600 系列快换接头Parker 快换接头技术信息Parker 快换接头⽆溢流型FEM / IF 系列快换接头Parker 快换接头⽆溢流型FF系列快换接头Parker 快换接头技术信息流体兼容性表Parker 快换接头技术信息概览Parker 快换接头螺纹连接型QHPA 系列快换接头Parker 快换接头技术信息针对派克快换接头及相关附件选型及使⽤的安全指南Parker Parkrimp 扣压系列 Push-Lok 可拆式 S6系列软管接头Parker 软管新能源/船舶⾏业软管, SS25UL, 221FR 系列Parker软管设备及附件软管总成测试台TH 5-3Parker软管设备及附件清洗设备 TH 6-6Parker软管设备及附件清洗设备 TH 6-7Parker软管设备及附件软管清洁包 TH6-10-HL-9-2Parker软管设备及附件重载卧式扣压机 TH8E-380-BMParker软管设备及附件卧式扣压机 TH8E-530, TH 8E-535-BM Parker 快换接头⽆溢流型71 系列快换接头Parker 快换接头通⽤型H 系列快换接头Parker 快换接头螺纹连接型75 系快换接头Parker 快换接头⽆溢流型 FF系列系列快换接头Parker 快换接头⾼压型HP 系列快换接头Parker 快换接头通⽤型 TEMA T系列快换接头Parker Industrial Tube FittingsParker 软管接头及设备技术⼿册化学兼容性表Parker Hose Fittings and EquipmentParker 387 HoseParker 487 HoseParker 722 HoseParker 787 HoseParker 797 HoseParker Five Hoses Two Fittings One SolutionParker Transportation Hose 226 运输软管226系列软管Parker Hydraulic Hose 351TC 351STParker 451TC and 451ST Constant Working Pressure Hoses Parker Hydraulic Hose 711Parker Hydraulic Hose 721 721TCParker Hydraulic Hose 772TC 772STParker Hydraulic Hose 781 P35Parker Hydraulic Hose 782TC 782STParker Hydraulic Hose 791TC 792TC 792ST Parker 低压软管软管接头 PUSH-LOK 系列软管Parker 低压软管软管接头 838M – Push-Lok 软管。
伊顿 ADE-1F2 O 型圈非铠装电缆接头 数据表
US: 1-866-764-5454 CAN: 1-800-265-0502 Copyright 2018 Eaton2041GADE-1F2 o-ring non-armored cable glandsIECEx/ATEX IP66/IP68ATEX Certificate No.: INERIS12ATEX0032X • Zones 1 & 2, Groups IIA, IIB, IIC • Zones 21 & 22, Groups IIIA, IIIB, IIICII2GD / Ex db IIC / Ex eb IIC / Ex tb IIIC IECEx Certificate No.: IECEx INE 12.0025X • ADE sizes 3 to 8, ISO 20 to 40 with TC-ER-HL non-armored cable up to 1” diameter 3DJN E310130, Class I, Zone 2A , AEx e II, Ex e II• ADE sizes 3 to 17, ISO 20 to 110 with non-armored cable types ITC, MV, PLTC, TC-ER, TC-ER-HL, TC3LRC E314047, Class I, Zone 2A , AEx e II, Ex e II• ADE sizes 3 to 17, ISO 20 to 110 with non-armored marine cable Provides 25% of cable clamping. As per IEC60079 § A.2.3.2 for Group II or III cable glands, "Without a clamping device, additional clamping of the cable is needed to ensure that pulling andtwisting is not transmitted to the terminations.” We recommend using the certi ed ADE clamping module.KOSHA 2015-BO-0249 to 0256•NEPSI GYJ13.1082XShipping application:•ABS 14-HS1274083-PDA •BV 40910/A0 BV •DNV TAE000010X •Lloyds 11/00072•DTS-01:1991 compliantA Can be used in Division 2, provided that the enclosure contains no components that produce arcs or sparks.ABCFeatures:Featu A Integrated o-ring sealing washerSpecifically formulated elastomer of the cable to provide IP66 or IP68 moisture ingress protectionC Optional external clamp – provides additional external strainrelief for rugged applicationssea Spe of t B Operating temperature:•-60°C to +140°C US: 1-866-764-5454 CAN: 1-800-265-0502 Copyright 2018 Eaton2051GCatalog numbers are for nickel-plated brass; refer to part number builder above for other options.Dimensions shown in inches (millimeters).Ordering information:Part number exampleADE1OM253NPNADE1OM25 3 NPNHub size M63Metric thread sizeCat. #Cable sealing rangeABLength (L)EGland sizeSizeOutersheath min.Outersheath max.M20ADE1OM200NPN 00.11 (2.8)0.22 (5.5)0.59 (15.0) 1.10 (28.0) 1.54 (39.0)0.59 (15.0)3ADE-1F2 o-ring non-armored cable glandsIECEx/ATEX IP66/IP68。
伊顿 ADE-5F 电缆铠装接头 数据表
1G1GADE-5F armored cable glandsStandard materials:•Nickel-plated brass for superior corrosion resistance•stainless steel and aluminum versionsIECEx/ATEX IP66/IP68Cable types:•Steel wire armored cable (SWA)•Steel wire braided cable (SWB)•Steel tape armored cable (STA)•Braided marine shipboard cable; Type P cable•Lead sheathed cable (with addition of earthing washer)IM2 / Ex db I / Ex eb I; for mining applications: brass or bronze –ADE sizes 8 to 17, ” to 4” NPT, ISO 25 to 110; stainless steel –ADE sizes 4 to 17; Ex db I / Ex eb I; for mining applications: brass or bronze – ADE ” to 4” NPT, ISO 25 to 110; stainless steel – ADE 3DJN E310130, Class I, Zone 2A , AEx e II, Ex e II” to 4” NPT or ISO 20 to 110 with armored cable types ITC, MV, PLTC, TC-ER, TC-ER-HL, TC 3LRC E314047, Class I, Zone 2A , AEx e II, Ex e II” to 4” NPT or ISO 20 to 110 with armored cable clamping, including braided cables.KOSHA 2015-BO-0483 to 0490ГБ05.B.00858•NEPSI GYJ13.1082XShipping application:•ABS 14-HS1274083-PDA •BV 40910/A0 BV •DNV TAE000010X •Lloyds 11/00072•DTS-01:1991 compliantA Can be used in Division 2, provided that the enclosure contains no components thatproduce arcs or sparks.Features:Featu A Specifically formulated elastomer inner sheath of the cableAnti-rotation feature armor clamping and grounding systemC Specifically formulated elastomer – used on the outer sheathof the cable to provide IP66 or IP68 moisture ingress protection of tD Optional external clamp – provides additional external strain relief for rugged applications relieE Additional deluge seal – available for ADE-5F gland sizes 12through 17thro F Suitable for lead sheath cable with installation of simplewasher (optional)inne Ant arm B Operating temperature:•-60°C to +140°C5ABCDEF1G1ADE-5F armored cable glandsIECEx/ATEX IP66/IP68Catalog numbers are for nickel-plated brass; refer to part number builder above for other options.Dimensions shown in inches (millimeters).Ordering information:Part number exampleADE5M253NPNK1B To specify the deluge ring, add prefix ‘DTS’ before the kit option in catalog number (for example: ADE5N2003NPNDTSK1). Deluge rings are available for sizes 12 through 17 only.C For across corners dimensions, multiply across flats dimensions by 1.1.D Not UL certified.NPT thread sizeCat. # NPTMetric thread sizeCat. #MetricCable sealing range inner sheathCable sealing range outer sheath Armor ABLength (L)E (NPT)E(Metric)Gland sizeMin.Max.Min.Max.Min.Max.1/”D ADE5N0253NPN M12D ADE5M123NPN 0.18 (4.5)0.28 (7.0)0.28 (7.0)0.47 (12.0)0.01 (0.2)0.04 (0.9)0.75 (19.0)0.75 (19.0) 2.17 (55.0)–0.59 (15.0)5ALNCC。
Parker与伊顿管接头对照表 2
买液压接头找李三189********QQ1029242671 Parker与伊顿管接头对照表序号Parker规格型号伊顿规格型号1GE12LM14×1.5EDOMDA3C1CM-18-14WD2AS10LX1CW-16-103AS12LX1CW-18-124AS15LX1CW-22-155AS18LX1CW-26-186AS20SX1DW-30-207AS22LX1CW-30-228AS25SX1DW-36-259AS28LX1CW-36-2810AS30SX1DW-42-3011AS35LX1CW-45-3512AS42LX1CW-52-4213EGE08LMEDA3C2MC-12-14WD14EGE10LMEDA3C2MC-14-16WD15EGE18LMEDA3C2MC-22-26WD16EGE28LMEDA3C2MC-33-36WD17EGE42LMEDA3C2MC-48-52WD18EL10LOMDA3C CC-1619CC-22EL15LOMDA3C20CC-30EL22LOMDA3C21CC-45EL35LOMDA3C22ET22LOMDA3C BC-3023EW10LOMDA3C2C9-1624EW12LOMDA3C2C9-1825EW15LOMDA3C2C9-2226EW18LOMDA3C2C9-2627EW20SOMDA3C2D9-3028EW25SOMDA3C2D9-3629EW30SOMDA3C2D9-4230EW35LOMDA3C2C9-4531G10ZLA3C1C-1632GE08LREDOMDA3C1CG-16-0433GE08LREDOMDA3C1CB-14-04WD34GE10LM12×1.5EDOMDA3C1CM-16-12WD35GE10LM18×1.5EDOMDA31CM-16-18WD序号Parker规格型号伊顿规格型号36GE10LM22×1.5EDA3C1CM-18-22WD37GE10LMEDOMDA3C1CM-16-14WD38GE10LR1/2EDOMDA3C1CB-16-08WD39GE10LR1/4EDOMDA3C1CB-16-04WD40GE12LM18×1.5EDOMDA3C1CM-18WD41GE12LMEDOMDA3C1CM-18-16WD42GE12LR1/2EDOMDA3C1CB-18-08WD43GE12LR1/2EDOMDA3C1CB-18-08WD44GE15LM22×1.5A3CX1CM-22WD45GE15LMEDOMDA3C1CM-22-18WD46GE18LMEDOMDA3C1CM-26-22WD47GE18LR3/4EDOMDA3C1CB-26-12WD48GE18LREDOMDA3C1CB-26-08WD49GE20SMEDOMDA3C1DM-30-27WD50GE22LM22×1.5EDOMA3C1CM-30-22WD51GE22LMEDOMDA3C1CM-30-26WD52GE22LR1/2EDOMDA3C1CB-30-08WD53GE25SMEDOMDA3C1DM-36-33WD54GE25SREDOMDA3C1DB-36-16WD55GE28L15/16UNFOMDA3C1DO-36-1656GE28LMEDOMDA3C1CM-36-33WD57GE30SMEDOMDA3C1DM-42WD58GE35LMEDOMDA3C1CM-45-42WD59GE35LR1EDOMDA3C1CB-45-16WD60GE35LREDOMDA3C1CB-45-20WD61GE42LMEDOMDA3C1CM-52-48WD62GFS64/25SOM1DFS-36-16序号Parker规格型号伊顿规格型号63GZ10LA3C3C-1664WH10LMKDSO31CI-16-1465SKA10×22WC-10X266SKA12×22WC-12×2.067SKA15×2.52WC-15X268SKA18×2.52WC-18X269SKA20×32WD-20X2.570SKA22×2.52WC-22×2.5（22*2）71SKA25×32WD-25X372SKA28×3（22）2WC-28X2.5（23）73SKA30×32WD-30X374SKA35×3.5（22）2WC-35X3（29）75SKA42×4（34）2WC-42X3（36）76T10LA3CX AC-1677T12LA3CX AC-1878T20SA3CX AD-3079T22LA3C AC-3080T25SA3CX AD-3681T35LA3C AC-4582W12LA3CX1C9-1883WEE10LMOR3C1CH9-16-14OG84WEE15LMOR3C1CH9-22-18OG85WEE18LMOR3C1CH9-26-22OG86SMK20-7/16UNF-PE-KK CSH7/16UNF87SMK20-G1/4-PC CSHG1/4/WD88SMK20-M10×1-PC CSHM10×1/WD89SMK20-M12×1.5-PC CSHM12×1.5/WD90SMK20-M14×1.5-PC CSHM14×1.5/WD91SMK20-M16×1.5-PB CSHM16×1.5/WD 92SKK20-10L-PK CSHS10-L93SMK20-12L-PK CSHS12-L94SMK20-8L-PK CSHS8-L95SMK20-9/16UNF-P CSH9/16UNF96G08LA3C1C-1497G10ZLA3C1C-1698G12LA3CX1C-1899G15ZLA3C1C-22100G28LA3CX1C-36序号Parker规格型号伊顿规格型号101W08LA3CX1C9-14102W10ZLA3C1C9-16103W12LA3CX1C9-18104W18LA3CX1C9-26105W22LA3CX1C9-30106W28LA3CX1C9-36107W42LA3CX1C9-52108EGE12LR1/4EDA3C1CB-18-04WD109GE08LREDOMDA3C1CG-16-04110WEE10LMOR3C1CH9-16-14OG111WEE15LMOR3C1CH9-22-18OG112WEE18LMOR3C1CH9-26-22OG113GE08L7/16UNFOMDA3C1CO-14-04114GE10L7/16UNFOMDA3C1CO-16-04115GE12L9/16UNFOMDA3C1CO-18-06116GE12L7/8UNFOMADA3C1CO-18-10117GE15L3/4-16UNFOMDA3C1CO-22-08118GE15L7/8UNFOMDA3C1CO-22-10119GE22L11/16UNFOMDA3C1CO-30-12120GE22L15/16UNFOMDA3C1CO-30-16121GE35L15/16UNOMDA3C1CO-45-16122GE35L15/8UNOMDA3C1CO-45-20123GE42L15/8UNFOMDA3C1CO-52-20124AS10LX1CW-16-10125AS12LX1CW-18-15126AS15LX1CW-22-15127AS18LX1CW-26-18128AS22LX1CW-30-22129AS28LX1CW-36-28130AS35LX1CW-45-35131AS42LX1CW-52-42132G30SA3CX1D-42133W20SA3CX1D9-30134W30SA3CX1D9-42135W38SA3C Parker1D9-52序号Parker规格型号伊顿规格型号136AS14S1DW-22-14137AS16SX1DW-24-16138AS20SX1DW-30-20139AS25SX1DW-36-25140AS30SX1DW-42-30141AS38SX1DW-52-38142RED10/08LOM3C2C-14-16143RED12/08LOM3C2C-14-18144RED15/08LOM3C2C-14-22145RED18/08LOM3C2C-14-26146RED12/10LOM3C2C-16-18147RED15/10LOM3C2C-16-22148RED18/10LOM3C2C-16-26149RED28/10LOM3C2C-16-36150RED15/12LOM3C2C-18-22151RED18/12LOMD2C-18-26152RED22/12LA3C2C-18-30153RED18/15LOMDA3C2C-22-26154RED22/15LOM3C2C-22-30155RED28/15LOM3C2C-22-36156RED22/18LOM3C2C-26-30157RED28/18LOM3C2C-26-36158RED42/18LOM3C2C-26-52159RED28/22LOM3C2C-30-36160RED35/22LOM3C2C-30-45161RED42/22LOM3C2C-30-52162RED35/28LOM3C2C-36-45163EW08LOMDA3C2C9-14164EW10LOMDA3C2C9-16165EW12LOMDA3C2C9-18166EW15LOMDA3C2C9-22167EW18LOMDA3C2C9-26168EW22LOMDA3C2C9-30169EW28LOMDA3C2C9-36序号Parker规格型号伊顿规格型号170EW35LOMDA3C2C9-45171EW42LOMDA3C2C9-52172RED30/16SOM3C2D-24-42173RED30S/22SINDA3C2D-30-42174RED30/25SOMDA3C2D-36-42175EW14SMOMDA3C2D9-22176EW16SOMDA3C2D9-24177EW25SOMDA3C2D9-36178EW30SOMDA3C2D9-42179EW38SOMDA3C2D9-52180EGE08LMEDA3C2MC-12-14WD181EGE10LMEDA3C2MC-14-16WD182EGE12LM-ED2MC-16-18WD183EGE15LMEDA3C2MC-18-22WD184EGE18LMEDA3C2MC-22-26WD185EGE22LMEDA3C2MC-26-30WD186EGE28LMEDA3C2MC-33-36WD187EGE35LMEDA3C2MC-42-45WD188EGE42LMEDA3C2MC-48-52WD189EGE10SMEDA3C2MD-16-18WD190SKA10×22WC-10×2.0191SKA12×22WC-12×2.0192SKA15×2.52WC-15×2.0193SKA18×2.52WC-18×2.0194SKA22×2.52WC-22×2.5195SKA28×32WC-28×2.5196SKA35×3.52WC-35×3.0197SKA42×42WC-42X3.0198SKA20×32WD-20×2.5199SKA25×32WD-25×3.0200SKA30×32WD-30×3.0201GZ08LA3C3C-14202GZ10LA3C3C-16203GZ12LA3C3C-18204GZ15LA3C3C-22205GZ18LA3C3C-26206GZ22LA3C3C-30207GZ28LA3C3C-36序号Parker规格型号伊顿规格型号208GZ35LA3C3C-45209GZ20SA3C3D-30210GZ25SA3C3D-36211SV08LOMDA3C6C-14LN212SV10LOMDA3C6C-16LN213SV12LOMDA3C6C-18LN214SV15LOMDA3C6C-22LN215SV18LOMDA3C6C-26LN216SV22LOMDA3C6C-30LN217SV35LOMDA3C6C-45LN218SV16SOMDA3C6D-24LN219SV25SOMDA3C6D-36LN220SV30SOMDA3C6D-42LN221SV38SOMDA3C6D-52LN222T08LA3CX AC-14223TR08/12/08LA3CX AC-14-14-18224T10LA3CX AC-16225T12LA3CX AC-18226T15LA3CX AC-22227T18LA3CX AC-26228T22LA3C AC-30229T28LA3CX AC-36230T35LA3C AC-45231T16SA3CX AD-24232T25SA3CX AD-36233T30SA3CX AD-42234ET08LOMDA3C BC-14235ET10LOMDA3C BC-16236ET12LOMDA3C BC-18237ET15LOMDA3C BC-22238ET18LOMDA3C BC-26239ET22LOMDA3C BC-30240ET28LOMDA3C BC-36241ET35LOMDA3C BC-45242ET42LOMDA3C BC-52243ET16SOMDA3C BD-24244ET20SOMDA3C BD-30245ET25SOMDA3C BD-36246ET30SOMDA3C BD-42247ET38SOMDA3C BD-52248EL08LOMDA3C CC-14249EL10LOMDA3C CC-16250EL12LOMDA3C CC-18251EL15LOMDA3C CC-22序号Parker规格型号伊顿规格型号252EL18LOMDA3C CC-26253EL22LOMDA3C CC-30254EL28LOMDA3C CC-36255EL35LOMDA3C CC-45256EL42LOMDA3C CC-52257EL16SOMDA3C CD-24258EL20SOMDA3C CD-30259EL25SOMDA3C CD-36260EL30SOMDA3C CD-42261K10LA3CX XC-16262K12LA3CX XC-18263K15LA3CX XC-22264GE35LR1EDOMDA3C1CB-45-16WD265GE15LR1/4EDA3C1CB-22-04WD266SMK20-15L-PK Stauff CSHS15-L267SMK20-18L-PK Stauff CSHS18-L268G08LA3CX Parker1C-14RN269GE08LR1/8EDOMDA3C1CB-14-02WD270GE18LREDOMDA3C1CB-26-08WD271GE18LR3/4EDOMDA3C1CB-26-12WD272GE25SR1/2EDOMDA3C1DB-36-08WD273GE06LREDOMDA3C1CG-12-02274GE06LR1/4EDA3C1CG-12-04275GE08LREDOMDA3C1CG-14-04276GE08LR3/8EDOMDA3C1CG-14-06277GE08LR1/2EDOMDA3C1CG-14-08278GE10LR1/2EDOMDA3C1CG-16-08279GE10LR3/8EDOMDA3C1CG-16-06280GE12LREDOMDA3C1CG-18-06281GE12LR1/2EDOMDA3C1CG-18-08282GE15LR3/8EDOMDA3C1CG-22-06283GE15LREDOMDA3C1CG-22-08284GE15LR3/4EDOMDA3C1CG-22-12序号Parker规格型号伊顿规格型号285GE18LR3/4EDOMDA3C1CG-26-12286GE18LREDOMDA3C1CG-26-08287GE22LREDOMDA3C1CG-30-12288GE22LR1EDOMDA3C1CG-30-16289GE28LREDOMDA3C1CG-36-16290GE35LREDOMDA3C1CG-45-20291GE42LREDOMDA3C1CG-52-24292GE06SREDOMDA3C1DG-14-04293GE08SREDOMDA3C1DG-16-04294GE10SREDOMDA3C1DG-18-06295GE16SREDOMDA3CParker1DG-24-08296GE20SREDOMDA3C1DG-30-12 297GE25SR3/4EDOMDA3C1DG-36-12 298GE25SREDOMDA3C1DG-36-16 299GE30SR1EDOMA3C1DG-42-16 300GE30SREDOMDA3C1DG-42-20301GE38SR11/4EDOMDA3C1DG-52-20302GE38SREDOMDA3C1DG-52-24 303AS08LX1CW-14-08 304AS08LX1DW-14-06 305AS12LX1DW-18-10 306EGE08LREDA3C2GC-04-14307EGE10LREDA3C2GC-04-16308EGE12LREDA3C2GC-06-18309EGE15LREDA3C2GC-08-22310EGE22LREDA3C2GC-12-30311SKA16×22WD-16×2312SKA16×22WD-20×3.0313SKA30×32WD-30×4.0序号Parker规格型号伊顿规格型号314SKA38×62WD-38×5315GZ12LA3C GZ12LA3C316GZ10LA3C GZ10LA3C317TR08/10/08LA3CX AC-14-16-14318TR10/08/10LCX AC-16-14-16319TR12/08/12LA3CX AC-18-14-18320TR12/15/12LA3CXparkerAC-18-22-18322TR22/15/15LCX AC-22-22-30323TR18/15/18LA3CX AC-26-22-26324TR22/18/18LCX AC-26-26-30325TR22/18/22LCX AC-30-26-30326TR28/22/22LCX AC-30-30-36327TR28/15/28LA3C AC-36-22-36328TR25/16/25SA3CX AD-36-24-36329M42×2/M36×2/φ54AD-36-42-36330WEE08LROM3C C1CG9-14-04OG331WEE12LROR3C1CG9-18-06OG332WEE15LROR3C1CG9-22-08OG333WEE18LROR3C1CG9-26-12OG334WEE22LROR3C1CG9-30-12OG335WEE28LROR3C1CG9-36-16OG336WEE35LROR3C1CG9-45-20OG337WEE12SROMDA3C1DG9-20-06OG338WEE30SROMD1DG9-42-20OG339GE18LM18×1.5EDOMDA3C1CM-26-18WD340GE12L3/4UNFOMDA3C1CO-18-08341GE18L7/8UNFOMDA3C1CO-26-10342GE08S7/16UNFOMDA3C1DO-16-04343EGE16SREDOM3C2BD-08-24WD344EGE28LREDA3C2GC-16-36序号Parker规格型号伊顿规格型号345EGE35LREDA3C2GC-20-45346EGE42LREDA3C2GC-24-52347EGE16SREDOM3C2GD-08-24348EGE30SREDA3C2GD-20-42349EL08SOMDA3C Parker CD-16350WA0601400FIRG-F-G1/4351WA0601700FIRG-M-G1/4352WA0603400A13-F-G1/2353WA0603700A13-M-G1/2354WA0604400A15-F-G3/4355WA0604700A15-M-G3/4356WA0605400A17-F-G1357WA0605700A17-M-G1358HA0506500HD0516100/16200(全套)A21-F-G1-1/4A21-M-G1-1/4359WA0602400A9-F-G3/8360WA0602700A9-M-G3/8361HS12-1-L1522A13-F-L15-SCHOTT 362HS12-2-L1522A13-M-L15-SCHOTT 363HS08-1-L1016A7-F-L10-SCHOTT 364HS08-2-L1016A7-M-L10-SCHOTT 365HS10-1-L1218A9-F-L12-SCHOTT 366HS10-2-L1218A9-M-L12-SCHOTT。
PARKER液压快速接头
★ PARKER液压快速接头
PARKER液压快速接头，是一种即不需要工具又能迅速拆装的管接头，这种接头使用轻巧灵便、密封可靠，适用于液压油、润滑油、水乙二醇等介质。
超高压快速接头压力:700bar、1000bar、1500bar、2000bar、3000bar
超高压软管压力:700bar、1000bar、1800bar、2620bar、2800bar
超高压压力表压力:0--7000bar
通用接头
无溢流型接头
★FASTER快速接头
FASTER拥有最广泛的快换接头选择范围，能和市场上绝大多数工业用快换接头互换。
产品符合 UNI EN ISO9001和UNI ISO/TS 16949标准要求，其设计和制造完全满足性能和质量要求。
FASTER快换接头能用于多种领域：农业机械，工业控制，建筑和工程机械，液压工具，空调和制冷行业，石油化工，海上平台，冶金，汽车等。
尺寸：1/4” - 2”
压力: 最高可达105MPA
连接螺纹: BSP-NPT-JPT-SAE-METRIC
常用工业标准：ISO 7241-1
ISO 7241-2
ISO 16028
HTMA。
派克接头加工尺寸及标准(英文版)
Technical HandbookAb-28German DIN Hose Fittings (DIN – Deutsches Institut für Normung)Often referred to as metric fittings these fittings seal using the angled sealing surfaces (metal to metal) or the combination of metal to metal with O-rings.They are available in very light (LL), light series (L) or heavy series (S)The sealing face angles are either 24° with or without O-rings, or 24°/60° universal cones.Identification is made by measuring the thread size and also the tube outside diameter.Defined by the outside diameter and the pitch (distance between 2 crests of the thread)example: M22x1.5 - pitch of 1,5mmDIN Very Light Series (LL)The male 60° cone will mate with the female 60° cone only.The male has a 60° sealing angle (seat) and straight metric thread. The female has a 60° seat and straight metric thread.StandardDIN 20078 Part 3 1)Parker end configurations C0DIN Light (L) and Heavy Series (S) without O-ringThe male 60° cone will mate with the female universal 24° or 60° cone only.The male has a 60° sealing angle (seat) and straight metric threads. The female has a 24° and 60° universal seat and straight metric threads.StandardDIN 20078 Part 2 1)(previously known as DIN 20078 A, D & E)Parker end configurations light series: C3, C4, C5, C6(Often also referred to as “Ball nose cones”)without O-ringEuropean Thread T ypes German DIN Hose Fittings1)obsolete standard, no exact replacementCatalogue 4400/UKfittings seal through the thread interface mechanism. Care should be taken not to confuse the BSPT fitting with the NPTF male fitting. BSPT has a 55° thread angle. NPTFThese fittings have BSP parallel threads but the sealing surface is flat. The seal is made when the composite seal is compressedSEE 0ARKER ADAPTERS RANGE3IZE "30 ! " " MM"30 ! " MM MM 4UBE "30 FEMALE SWIVEL mAT SEAT 0ARKER END CONlGURATIONS " " " 4UBETechnical HandbookFrench Metric 24° Cone Gas FittingsTypical to the French market the French Gas fittings have a 24° sealing surfaces seat with metric straight threads. Although similar to German DIN fittings the threads differ in some sizes as the French Gas fittings have fine threads in all sizes whereas the German DIN fittings use standard threads in the larger sizes.The sealing mechanism is metal to metal.European Thread T ypesFrench Gas fittingsTechnical HandbookStandardSAE J516Parker end configuration01North American Thread T ypesNPTF / SAE JIC 37°This type of fitting uses the thread interfaceto seal and as such has a tapered threadthat deforms and forms the seal.They have 30° sealing angle surfaces,forming a 60° inverted (concave) seat.The fittings are most frequently seen onmachines of US origin.The NPTF male will mate with the NPTF,NPSF, or NPSM females.Care should be taken not to confuse theNPTF fitting with the BSPT male fitting.NPTF fittings have a 60° thread angle.BSPT has a 55° thread angle.ØA dimension is measuredon the 4th pitch of the thread SAE JIC 37°TH PITCH OF THE THREADDryseal American Standard Taper Pipe Thread (NPTF)0ARKER END CONlGURATIONS 6Code 61 and Code 620RESSURE R -0A 03)North American Thread T ypes / Japanese Fittings4-Bolt Split Flange / JIS。
EATON软管接头
EATON软管接头EA TON伊顿软管接头，EA TON伊顿软管接头为流体传动和控制系统提供了管路与元件之间的可靠连接和密封，这归因与EA TON伊顿软管接头独特的内部结构。
1、EA TON伊顿软管接头是受控条件下逐渐切入钢管的。
卡套的前刃A和后刃B相继切入钢管，当两个刃口都切入到设计深度时，止动边C限制了刃口过量切入对管子造成损伤的可能性。
2、与传统的单个刃口卡套不同，EA TON伊顿软管接头的刃口部位有A、B、C三个点与钢管接触，使一切作用于卡套的压力在多个接触点均匀分配。
加上卡套尾环D抱紧钢管后对于管路振动的阻尼作用，使得EO渐进式卡套具有特别优良的耐冲击和振动性能。
3、EA TON伊顿软管接头特殊的设计、材料和热处理工艺得EA TON伊顿软管接头具有特别优良的弹性。
接头装配后卡套中部应微微拱起，由此产生的弹性效应避免了金属接触密封的压力松弛现象，从而可确保卡套长期地可靠工作和反复多次的装拆使用。
EA TON伊顿软管接头具有理想的密封性能，可适用于大多数工况条件，包括高真空密度的密封，小分子气体的密封以及高压液压油的密封。
但是，EA TON 伊顿软管接头的理想功能需要靠正确的装配来保证。
不正确的装配会导致钢管拔脱，接头泄露，弹性消失而抗振动性能降低等问题。
派克parker不锈钢接头简介：派克parker不锈钢接头在德国发明卡套式管接头以来，派克parker 不锈钢接头因其特有的装配方便（仅需两把扳手）而广受欢迎。
经过半个多世纪的发展，派克parker不锈钢接头终保持着卡套式管接头技术的领先地位。
派克parker不锈钢接头是为公制管子设计的，历史上曾经依照德国标准DIN3861，DIN3859，和DIN2353，现在这些标准已被国际标准ISO8434所取代。
Parker派克EO管接头以体积小，压力等级高而著称。
分为低压、中压和高压三个系列（LL/L/S系列），这样使得各种不同的应用场合可以实现最经济化和空间最小化的方案。
ParKer接头选择
D r y T e c h no l o g yIntroductionProduct selectionUltimate target is to fi nd the “best solution”. This optimumsolution provides high system reliability, easy assemblycharacteristics, low maintenance effort and avoids the useof exotic components.This “best solution” is not the ultimately achieveable tech-nology, but an adequate solution which fulfi ls the require-ments of the individual application with minimum systemcost.The “best solution” looks different depending on the spe-cifi c criteria of the given application.Dry TechnologyModern TFDE fi ttings are designed for high reliability, easyassembly and lowest toal cost performance.These products are marked Dry Technology and indicated greyin selection charts.Parker recommends to select only Dry Technology products forall new designs.Design criteria for fi tting selectionStep 1First clarify all design criteria for the given application orproject.Step 2Then determine the “best solution” product. Use selectioncharts on following pages.Application● Hydraulic● Pneumatic● central lubrication● process industry● severenessAssembly● Mass production● On-site installation● Industrial assembly● Field repairSpecifi cations● International standards●End user specifi cation● approvals● availabilityEnvironment● weather● humidity● Stationary/mobileSpace● Space limitations●T ube bending capabilitiesFlow rate● Volume flow● medium viscosity● System dynamics● T ube selectionMedium●hydraulic oil type● Compressed air● Water/seawater● other fluidsTemperature● Medium● Environment● Operation/standstillPressure● System pressure● Pressure peaksBest solution● zero leakage● high reliability● easy assembly●low total cost● standard products123Material selection: Fitting materialEnvironment● select fi tting material withsuitable corrosion resistanceMedium● select compatible fi tting materialTemperature● check suitability123Material selection: Sealing materialMedium●select compatible fi tting materialTemperature● check suitabilityAssembly●Prefer elastomer sealing for easyassembly and economic service123LL/L/S Series selection for EO fi ttingsPressure● select series with adequatepressure performanceSpace● select series according to available spaceSpecifi cation● prefer L or S series for best availability1234Tube end selectionPressure● select connection type with adequate pressure performance● prefer elastomeric seal for most reliable sealing performanceAssembly● select product with adequate assembly processSpace● select most suitable productSpecifi cation● fi tting type according to project specifi cation1234Tube end selectionPressure● select connection type withadequate pressure● prefer elastomeric seal for most reliable sealing performanceAssembly● select product with adequate assembly processSpace● select most suitable productSpecifi cation● fi tting type according to project specifi cation3512Space● select fl ange typeaccording to available spaceSpecifi cation● select fl ange type according to project specifi cationPressure● select fl ange type connection with adequate pressure performanceApplication● select suitable fl ange type for specifi c applicationFlange type selection12Port/Stud selectionPressure●select connection withadequate pressureperformance Temperature●Use elastomeric sealwhen suitable43Application● select standard connection for specifi c applicationPort/Stud selectionAssembly ● prefer O-Ring/ ED-sealfor easy assembly and economic service ● avoid tapered threads5Port/Stud selectionSpecifi cation● select connection type according to projectspecifi cation● prefer international standards ● select ISO 6149 for new designs12Systematic fi tting selectionOrientable Fitting SelectionPressure ● pre-select orientable fi ttingwith suffi cient pressure performance● prefer elastomeric seal for most reliable sealing performanceFlow Rate● select optimum solution for best fl ow rate and available space34Systematic fi tting selectionOrientable Fitting SelectionSpace● select optimum solution foravailable space and best fl owAssembly● check, if assembly process issuitable5Systematic fi tting selection ApprovalsParker tube fi ttings are recognized by various acceptance or-ganizations, among which are:Germanischer Lloyd (GL)Lloyds Register of Shipping (LR)Det Norske Veritas (DNV)American Bureau of Shipping (ABS)Russian Maritime Register of Shipping (RMS)China Classifi cation Society (CCS)Deutscher Verein des Gas- und Wasserfaches (DVGW)For other applications, Parker tube fittings also approved by diverse national authorities.Numerous original equipment manufacturers and end-users of various industries have approved Parker tube fi ttings.Attention:T ype Approvals usually are limited to certain products, appli-cations, working conditions, validity time or other restrictions. We gladly inform you on your individual application and send out the required documentation.StandardisationSpecifi cation● select fi ttings according tointernational standardisation● check specifi cation of end-customer/end user● consider project-specifi cguidelines●avoid non-standard itemsSystematic fi tting selectionTube Specifi cationsubes with metric outside diametersTGood bendability and weldability.2) T olerance on large tube OD’s not as tight as EO tube.3) Precision tubes for very high pressure hydraulic applications. Tight tolerances for easy handling.Good bendability and weldability.4) T olerance on large tube OD’s not as tight as EO tube.5) Recommended EO standard precision tubes for high pressure hydraulic applications. Tight tolerances (same as steel tubes) for easy handling.Good weldability and corrosion resistance. ( ) = on request6) Recommended EO standard precision tubes for high pressure hydraulic applications. Tight tolerances (same as steel tubes) for easy handling.Good weldability. ( ) = on request7) Common tube, OD. tolerance not as tight as EO tube. Good weldability and corrosion resistance. ( ) = T olerance at 42 mm tube OD is too large8) Common tube, OD. tolerance not as tight as EO tube. ( ) = T olerance at 42 mm tube OD is too large9) Common tube, OD. tolerance not as tight as EO tube. ( ) = T olerance at 42 mm tube OD is too large10) Used in Pneumatic (low pressure) applications. ( ) = Only for tube with smooth outer and inner surface.11) Support sleeve “VH” may be required, e.g. for R250-28x1.5.* = For DPR/PSR/EO-2 systems: thin walled tubes which need a support sleeve require tighter tolerance class T4. T ube O.D. tolerance class D3 is not recommended. D3 may reduce function and capability of the tube connection systems.Systematic fi tting selectionTube Specifi cationsubes with imperial (inch) outside diametersT1) Recommended EO tubes for Hydraulic/Pneumatic applications2) Common tubes in North-America3) Recommended tubes for Hydraulic/Pneumatic applications. Good weldability and corrosion resistance4) T ubes in North-AmericaD r yT ec h n o lo g y Systematic fi tting selectionDry technology versus traditional technologyEO-2 versus bite type+ Elastomeric seal + Suffi ciant seal volume to compensate tube tolerance + High degree of fi ne sealing+ Long-term reliability without retightening + No air ingress+ Clear hit-home-feel at assembly + Easy assembly check+ Integrated preassembly tool + No stress of inner cone of fi tting body + No wear of preassembly tools+ Direct assembly of stainless steel tubes possible (EO-2)+ No galling of stainless steel threads+ Existing tools and EOMA T machines can be used for effi cient assembly (EO-2)+ All parts integrated in Functional Nut (EO-2)+ No confusion of individual ferrules + Less handling effort+ Unlimited repeated assembly + Seal can be individually replaced+ ISO-standardised (DIN EN ISO 8434-1)+ Million times proven product since 1993 (EO-2)+ Interchangeable with EO Progressive Ring (EO-2)– Higher component cost than traditional bite-type fi ttings + Low total cost+ Best value for end user + Mandatory specifi ed from various industries, such as:automotive production, injection molding, mobile equipment, shipbuilding and offshore exploration+ Globally gaining popularityBite typeEO-2Fitting selection summaryT raditional bite-type fi ttings have been originally devel-oped and designed for operating conditions of fl uidpowersystems completely different from todays and future mar-ket requirements.New products and improved assembly technologies have been developed and introduced by Parker to fulfi ll todays and future requirements of the operators of fl uidpower equipment. This new tube fi tting generation and the ac-cording assembly methods are classifi ed as Dry Technology . All qualifying products are explicitly Dry Technology -labelled throughout this catalogue.For all new designs of ● hydraulic systems ● pneumatic systems,● coolant systems,● lubrication systems and ● sprinkler systemsonly Dry Technology -classifi ed components should be se-lected.Dr yT e c h n o lo g y Dr yT e c hn o l o g y Systematic fi tting selectionO-Lok ® versus traditional Triple-Lok ®+ Higher pressure resistance than T riple-Lok ®+ Elastomeric seal + Suffi ciant seal volume to compensate tube tolerance + High degree of fi ne sealing+ Long-term reliability without retightening + No air ingress+ Clear hit-home-feel at assembly + Easy assembly check + Easy installation of fl at-face components + Superior vibration resistance+ Parfl ange ® orbital flanging technology + Unlimited repeated assembly + Seal can be individually replaced+ ISO-standardised (DIN EN ISO 8434-2)+ Million times proven product– Higher component cost than T riple-Lok ®– Parfl ange ® machine required + braze sleeves can be used for fi eld repair + Low total cost+ Best value for end user + Mandatory specifi ed from various industries, such as:agricultural equipment, mobile construction machines, injec-tion molding+ Globally gaining popularityEO2-FORM versus traditional Weld nipple+ Safe, form-fi t connection + Easy assembly process+ trouble-free with zinc-plated tube + Elastomeric seal + Suffi ciant seal volume to compensate tube tolerance + High degree of fi ne sealing+ Long-term reliability without retightening + No air ingress+ Clear hit-home-feel at assembly + Easy assembly check + Easy tube preparation + Easy quality inspection + No rework of welding+ Use of existing EO-2 seals + Unlimited repeated assembly + Seal can be individually replaced+ ISO-standardised (DIN EN ISO 8434-1/-4)+ Basic product EO-2 is million times proven+ Interchangeable with EO Progressive Ring (EO-2)+ No new or additional components required– Higher component cost than traditional bite-type fi ttings – EO2-FORM machine required + EO-2 can be used for fi eld repair + Low total cost+ Best value for end user+ Approved for application in hydraulic presses, injection mold-ing, lifts, waterlocks and shipbuilding + Globally gaining popularityTriple-Lok ®O-Lok ®Weld nippleEO2-FORMDr yT e c h no lo g y r yT e c hn o l o g y Systematic fi tting selectionSwivel adjustable versus traditional standpipe+ Elastomeric seal + High degree of fi ne sealing+ Long-term reliability without retightening + No air ingress+ Superior pressure rating + High mechanical strength+ No blow-out at incomplete assembly + Easy fi tting installation+ No stress of inner cone of fi tting body + No wear of preassembly tools + Unlimited repeated assembly + Seal can be individually replaced+ ISO-standardised (DIN EN ISO 8434-1/-4)+ Milliontimes proven product since 1970+ Interchangeable with EO standpipe fi ttings– Higher component cost than traditional standpipe fi ttings + Low total cost+ Best value for end user + Mandatory specifi ed from various industries, such as:automotive production, injection molding, mobile equipment, shipbuilding and offshore exploration+ Most frequently used and still gaining popularityMale stud with Eolastic or O-ring seal versus traditional Metal sealt apered thread + Elastomeric seal + High degree of fi ne sealing+ Long-term reliability without retightening + No air ingress+ Superior pressure rating+ Clear hit-home-feel at assembly + No damage to port surface+ Assembly and performance almost independant of port material + Low assembly torques+ No metal sealing edge which may be damaged at transport or handling + Unlimited repeated assembly + Seal can be individually replaced+ ISO-standardised (ISO 1179/ISO 6149/DIN ISO 6149)+ Million times proven product since 1964+ Interchangeable with traditional fi ttings + Wider product range and better availability– Higher component cost than traditional bite-type fi ttings + Low total cost+ Best value for end user + Mandatory specifi ed from various industries, such as:automotive production, injection molding, mobile equipment, shipbuilding and offshore exploration+ Most frequently used and still gaining popularityStandpipeswivelMetal sealED-sealtaperO-ringD ry Te c h no lo g y Dr yT e c h n o lo gy Systematic fi tting selectionLocknut Adjustables versus tapered thread + Elastomeric seal + High degree of fi ne sealing+ Long-term reliability without retightening + No air ingress + Good fl ow characteristic + 360° orientable+ More compact than swivel orientable combination + No additional sealant required + Clear hit-home-feel at assembly + No damage to port surface+ Assembly and performance almost independant of port material + Low assembly torques+ Unlimited repeated assembly + Seal can be individually replaced + Interchangeable with traditional fi ttings+ Available in 90°, 45° elbow, T - and Run-T -confi guration – Machined spot surface required + Lower price than Banjo fi ttings + Low total cost+ Best value for end user + Globally gaining popularityHigh pressure banjo versus traditional low pressure elbow+ Elastomeric seal + High degree of fi ne sealing+ Long-term reliability without retightening + No air ingress + 360° orientable + Compact design+ Suitable for high pressure applications + Matching small spot surface + Clear hit-home-feel at assembly + No damage to port surface+ Assembly and performance almost independant of port material + Seal does not fall off+ Only one hollow bolt needs to be tightened + No hidden screw+ Unlimited repeated assembly + Seal can be individually replaced+ Million times proven product since 1980+ Interchangeable with traditional fi ttings + Available in 90°elbow and T -confi guration – Slight fl ow restriction + Low total cost+ Best value for end user + Globally gaining popularitytaperLocknutLow pressureHigh pressureErmetoOriginal Performance dataFormula:(100%–20fitting 200C PN °=×400100bar %%)=320bar 62(100%–t 200CPN ube bar °=×3100%21,5%)=284barPressure ratingPressure reductions and temperaturesRequired pressure reductions (dependant on the material) with reference to the catalogue pressures for higher temperatures. Both metal fitting material and elastomeric sealing compound have to be selected according to the temperature range of the system.Attention: Fluid Compatibility see page C5.Perbunan = registered trademark of Bayer 1) 35% (if not extra shown in PN-Column “MS” for Brass)2) EPDM is not compatible with oil (not nor-mally held in Stock)Calculation example:PN fitting 16S/71 = 400 bar T emperature = 200°C Material = Stainless steelPressure reduction fittings = 20%Pressure reduction tubes = 21,5%PN tube 16 w 2.5/71, DIN 2413 III = 362 barNominal pressure PNThe Nominal pressure PN is a figure relating to the pressure rat-ing of a fluid component for continuous dynamic applications. It is rounded to correspond to internationally standardised ratings. Logical series of fittings are grouped together, with the nominal pressure of the group being that of the “lowest common denomi-nator” within the group.Internationally, these nominal pressures are recognised and serve to match common sizes of components together. Parker tube fittings meet or exceed common standardised pressure rat-ings.T o prove the long term dynamic load resistance, components are tested under pressure impulse conditions of PN × 1.33, at 1Hz for 1 million cycles. Static test burst pressures are at least 4 times the PN value.Exception: for ball valves the static test burst pressures are at least 1.5 times the PN value according to DIN 3230 T5 and ISO5108.Permissible operating temperatureAmbient temperature of hydraulic and pneumatic applications Temperature not permissibleSealings NBR e.g. N552-90, Perbunan (registered trademark of Bayer) FKM e.g. V894-90EPDM e.g. E540-80PTFE e.g. T eflon® (registered trademark of DuPont)POM e.g. Delrin (registered trademark of DuPont)MaterialsFittings Raw materialMaterialFitting typeEO O-Lok®Triple-Lok®Designation2)MaterialNo.Standard USDesignation2)Bodies Nuts Ferrules WeldfittingsBodies Nuts Sleeves Bodies Nuts SleevesSteel Barstock 11SMnPb30 1.0718 DINEN10277-3SAE 12L14X X X X X Free cuttingsteel11SMn30 1.0715 DINEN10277-3SAE 1213X46S20 1.0727DINEN10277-3SAE 1146XForgings15S10 1.0710DIN 1651XFree cuttingsteel11SMn30modified1.0715 DINEN10087SAE 1213modified X X 36SMn14 1.0764 DINEN10087XC45 modified 1.0503 DIN EN10083SAE 1045modified X X X ExtrusionsteelC10C 1.0214 DIN EN SAE C1010X X X X X WeldablesteelC15 1.0401DIN10277-3XOther Steel at the manufacturers discretion special heat treated X XStainless steel Barstock X6CrNiMoTi17-12-21.4571 DINEN10088ANSI 316TIX X XX2CrNiMo17-13-21.4404 DINEN10088ANSI 316LX X X X X X Forgings X6CrNiMoTi17-12-21.4571 DINEN10088ANSI 316TIX X XX5CrNiMo17-12-21.4401 DINEN10088ANSI 316X X X X X X Other Stainless steel at the manufacturers discretion special heat treated XBrass Barstock CuZn35Ni2 2.0540 DIN17660X X XASTMB16/B453CA360/345X X X X X X Forgings CuZn35Ni2 2.0540 DIN17660XASTMB124CA377X X1) Non standard fitting types like e.g. banjo fittings, rotary fittings, adjustable fittings with locknut and flanges might be made from different materials.2) Equivalent materials may be usedForging: 11 SMn 30+Bi (similar to 1.0715/DIN EN 10087)Straight: 11 SMn Pb30 (1.0718/DIN EN 102773)Surface treatmentParker tube fittings from steel are delivered worldwide with a high quality surface protection:Galvanic zinc plated and bright passivated with special sealer (suffix CF).Why zinc plated?The requirements for corrosion resistance of tube fittings have been increasing in the past few years. Increasingly tube systems are not painted. Higher demands are re-quested also for an aesthetic point of view.The traditional black-grey surface “phosphated and oiled” (Znphr5f – DIN 50942) used for tube connections in the past does not longer meet these demands. An galvanized deposit zinc layer offers the following advantages: The cor-rosion resistance increases significantly due to a plating of min. 8 R and additional sealing by chromating process. In case of scratches or nicks – which are unavoidable d uring assembly – zinc develops a cathodical protection of the steel fitting body against localised corrosion and abrasion.The corrosion resistance of the CF surface is 400% above zinc plated surfaces to meet highest requirements. The CF surface is also Cr(VI)-free to avoid any contamination in the manufacturing process and meets current regulations e.g. European “End of Life Vehicles“ directive.The silver bright colour due to the chromating or passiva-tion process offers an attractive appearance.All major TFDE manufacturing locations are equipped with their own modern galvanic plants. The process control is specially orientated to the tube fitting product.The users of Parker fittings benefit from:– homogeneous thickness of plating (average 13 μm), measured on outside contour for good screwable threads– high quality above-average concerning avoidance of nicks– very good corrosion resistanceContinuous corrosion tests like salt spray tests according to ISO 9227/5% NaCI show an average resistance of 500 hr in contrast to white rust and 700 hr in contrast to red rust for CF surfaces.Particular fitting series or fitting components and valves are delivered with other or modified surfaces for functional reasons or for better differentiation.Surface protection/SurfaceMaterial Fittingsystem Fitting type CF/Cr3*Zinc platedbrightpassivatedCF+ GlidecoatingA3KZinc platedbrightpassivatedZnphr5fblackphosphatedPlainno coatingPlain+ GlidecoatingPlain+ InsidesilverSteel EO-2Fitting bodies XFunctional nuts XEO Fitting bodies XNuts XProgressive stop rings XWeld fittings X EO2-FORM Bodies and nuts from EO are usedO-Lok®Fitting bodies XNuts XParflange® sleeves XBrazing sleeves X Triple-Lok®Fitting bodies XNuts XSleeves XStainless steel EO-2Fitting bodies XFunctional nutsup to 12-L/10-SXFunctional nutsfrom 15-L/12-S XA3K according to DIN EN ISO 4042 / Znphr5f according to DIN EN ISO 3892 and DIN 50942O-Lok and Triple-Lok parts are plated Cr3 and conform to FC-F01 specification, 120 hours to white rust, 240 hours to red rust.Fluid compatibilityBoth metal fitting material and elastomeric seal compound have to be selected according to the fluid used.Standard recommendations for static seals based on experience and sealing compound manufacturers specification. For use of sealing compounds that are used for dynamic seals like rotary fittings or non-return-valves, see note at end of table.Surface protection/SurfaceMaterial Fitting system Fitting typeCF/Cr3* Zinc plated bright passivatedCF + Glide coatingA3KZinc plated bright passivatedZnphr5f blackphosphatedPlainno coatingPlain + Glide coatingPlain + Inside silverStainless steelEOFitting bodiesXNuts up to 12-L/10-S XNuts from 15-L/12-S XProgressive ringsXEO2-FORM Bodies and nuts from EO are used O-Lok ®Fitting bodies X Nuts X SleevesX Triple-Lok ®Fitting bodies X Nuts X SleevesX Brass All systemsFitting bodies X NutsX Sleeves & ferrulesXFitting material Sealing materialFluid Steel Stainless steelBrass NBR FKM EPDM Acetone 211331Acetylene 213332Air (oil free)111111Ammonia liquid 213231Ammonia gas, cold 113131Animal oils (Lard oil)222112Aral, Vitam BAF 11X 113Argon 111111Asphalt313213ASTM-Oil, no. 1111113ASTM-Oil, no. 2111113ASTM-Oil, no. 3111113ASTM-Oil, no. 4111213ATF oil111113Automotive brake fluid 111331Benzene111313Brine (sodium chloride)X 2X 111Butane113113Carbon bisulphide 11331X Carbon dioxide 111121Carbon oxide111111Castrol, Biotec HVX 11X 113Chlorine (dry)31331X Compressed air 111111Crude oil 213213Fitting material Sealing materialFluid Steel Stainless steel Brass NBR FKM EPDM Cutting oil11X131 DEA, Econa E2211X1X3 DEA, Econa E4611X1X3 Diesel fuel111113 ECOOL11X11X ESSO, Univis 1311X113 ESSO, Univis 2611X113 ESSO, Univis 3211X113 ESSO, Univis 4611X113 Ethanol (Ethylacohol)111131 Ether111332 FINA, Biohydran RS 3811X113 Flue gas31332X FRAGOL, Hydrolub 12511X1X3 Freon 11X X1223 Freon 12131213 Freon 22311323 Gasoline211213 Gas, liquid propane (LPG)111113 Glycerine212111 Glycol (Ethylenglykol)112111 Heating fuel oil111113 Helium111111 Houghton Safe 112011X311 Houghton Safe 62011X121 Hydrochlorid acid323312 Hydrogen31X333 Hydrogen peroxide313312 Hydrolube111111 Iodine313212 Kerosene111113 Lubricating oil SAE 10,20,30,40,50111113 Methane111113 Methanol111131 MIL-F-8192 (JP-9)111313 MIL-H-5606111113 MIL-H-6083111113 MIL-H-7083111121 MIL-H-8446 (MLO-8515)112213 MIL-L-2104 & 2104B111113 MIL-L-7808213213 Mineral oil111113 Natural gas112113 Natural gas, untreated321)3333 Natural mineral oil113213 Neon311111 Nitric acid313323 Nitrogen111111 Oil113113 Oxygen (gas, cold)312333 Ozone113311 Petrolatum111113 Petroleum oil111113 Phosphoric acid331312 Plantohyd 32 S11X1X3 Plantohyd 40 N11X113 Propane111113R134A111331Applicability: 1 = satisfactory NBR = e.g. Perbunan (registered trademark of Bayer)2 = fair FKM3 = not recommended X = unsufficiant data1) Untreated natural gas requires stainless steel with reduced material hardness.2) Brass is resistant against crack under normal circumstances. If overloaded (e.g. by overassembly) the resistance especially against ammo-niac and nitric derivatives can be negatively influenced. This might cause the defect of the connection.This fluid compatibility chart is only applicable on so called “static seals”, such as O-rings and profile sealing rings (e.g. ED-seal, DOZ-seal) in tube fitting and flange systems.For fluid compatibility data of valves, rotary fittings or other multi-function components please review the relevant product pages.Fitting material Sealing materialFluidSteel Stainless steelBrass NBR FKM EPDM Sea Water323111SHELL, Naturelle HF-E-4611X 113SHELL, Tellus Oil DO 3211X 113Silicone oil 11X 111Skydrol 500113331Skydrol 7000113321Soap solutions 313111Steam212331Stoddard solvent 112113Sulphur dioxide 313331Sulphuric acid 323313T oluol111323T ransmission fluid 111113T richlorethane 21X 313Turpentine 213113Water 2112)121Xylol 111313Biodegradable oilsDue to environmental concerns and new legislation bio-degradable oils are rapidly gaining importance for both mobile and stationary applications. The usage of non-in-flammable fluids will remain limited to special applications like mining, steel mills and heavy machines.MediaBiodegradable oils can be classified into 3 categories: HEPG (Glycol based fluids)+ Wide temperature range (–45°C … 100°C)+ Very stable against ageing+ NBR and FKM seals are compatible+ Moderate viscosity change with temperature+ Water soluble– Not mixable with mineral oils or HEES, HETG types– Careful flushing recommended when changing from mineral oil– Paints can be dissolved– Care required with material compatibility(e.g. do not use any zinc containing materials)– Density > 1,100 kg/m3 possible design changes– Price?HETG (Vegetable-based fluids)+ Mixable with mineral oils+ Normal sealing material are compatible(e.g. NBR or FKM)+ Good lubricating properties+ Paint resistant to fluid+ Viscosity changes with temperature are moderate– Limited temperature range (–25°C to +70°C)– Max. temperature not to be exceeded– Limited lifetime– UV and ozone sensitive– Beware of water take-up (cracking?)– Price?HEES (Synthetic ester based fluids)+ Wide temperature range(–30°C … +90°C or over 100°C with some variants)+ Good lifetime+ Mixable with mineral oils+ Normal sealing materials compatible(FKM and NBR recommended)+ Machine paints resistant to fluid+ Viscosity changes with temperature are moderate+ Good lubricating properties– Danger of hydrolysis with water take-up(filters, dryer, occlusion)– Price?CompatibilityGenerally, TFDE steel fittings with standard NBR seals aresuitable for most applications.Suitable sealing compoundsExperience shows that media compatibility is not a critical issue for static seals used on tube fittings. In doubt p lease contact TFDE application engineering.Pragmatic approachIf there is doubt about switching over to softseal fitting s ystems (ISO6149/Eolastic/O-Lok®/EO-2), it might be a good idea to have a close look on the existing hydraulic system. If NBR seals perform well on hoses, cylinders, valves or filters there is nothing to worry about standard TFDE fittings. Usually the design engineers know when special seal compounds like FKM have to be used.。
