FM420104质量记录一览表
MM420参数
部分参数：1、复位为工厂的缺省设置值为了把所有的参数都复位为工厂的缺省设置值，应按下列数据对参数进行设置：设定P0010=30。
设定P0970=1。
说明：大约需要10 秒钟才能完成复位的全部过程，将变频器的参数复位为工厂的缺省设置值。
P0003 用户访问级可能的设定值：1 标准级：可以访问最经常使用的一些参数。
2 扩展级：允许扩展访问参数的范围，例如变频器的I/O功能。
3 专家级：只供专家使用。
4 维修级：只供授权的维修人员使用-具有密码保护。
P0004 参数过滤器可能的设定值：0 全部参数2 变频器参数3 电动机参数7 命令，二进制I/O8 ADC（模- 数转换）和DAC（数- 模转换）10 设定值通道/ RFG（斜坡函数发生器）12 驱动装置的特征13 电动机的控制20 通讯21 报警/ 警告/ 监控22 工艺参量控制器（例如PID）P0010 调试参数过滤器可能的设定值：0 准备1 快速调试30 工厂的缺省设定值P0100 使用地区：欧洲/ 北美可能的设定值：0 欧洲－[kW]，频率缺省值50 Hz1 北美－[hp]，频率缺省值60 Hz2 北美－[kW]，频率缺省值60 Hz P0300 选择电动机的类型可能的设定值：1 异步电动机2 同步电动机P0304 电动机的额定电压P0305 电动机额定电流P0307 电动机额定功率P0308 电动机的额定功率因数P0309 电动机的额定效率P0310 电动机的额定频率P0311 电动机的额定速度P0335 电动机的冷却可能的设定值：0 自冷：采用安装在电动机轴上的风机进行冷却1 强制冷却：采用单独供电的冷却风机进行冷却P0700 选择命令源可能的设定值：0 工厂的缺省设置1 BOP（键盘）设置2 由端子排输入4 通过BOP 链路的USS 设置5 通过链路的USS 设置6 通过链路的通讯板（CB）设置P0701 数字输入1 的功能可能的设定值：0 禁止数字输入1 ON/OFF1（接通正转/ 停车命令1）2 ON reverse /OFF1（接通反转/ 停车命令1）3 OFF2（停车命令2）- 按惯性自由停车4 OFF3（停车命令3）- 按斜坡函数曲线快速降速停车9 故障确认10 正向点动11 反向点动12 反转13 MOP（电动电位计）升速（增加频率）14 MOP 降速（减少频率）15 固定频率设定值（直接选择）16 固定频率设定值（直接选择+ ON命令）17 固定频率设定值（二进制编码的十进制数（BCD 码）选择+ ON 命令）21 机旁/远程控制25 直流注入制动29 由外部信号触发跳闸33 禁止附加频率设定值99 使能BICO 参数化P0702 数字输入2 的功能（设定值与P0701相同）P0703 数字输入3 的功能（设定值与P0701相同）P0704 数字输入4 的功能（设定值与P0701相同）P0756 ADC 的类型可能的设定值：0 单极性电压输入（0 至+10 V）1 带监控的单极性电压输入（0 至+10 V）P0970 工厂复位可能的设定值：0 禁止复位1 参数复位P1000 频率设定值的选择可能的设定值：0 无主设定值1 MOP 设定值2 模拟设定值3 固定频率4 通过BOP 链路的USS 设定5 通过链路的USS 设定6 通过链路的CB 设定10 无主设定值+ MOP设定值11 MOP 设定值+ MOP设定值12 模拟设定值+ MOP设定值13 固定频率+ MOP设定值14 通过BOP 链路的USS 设定+ MOP设定值15 通过链路的USS 设定+ MOP设定值16 通过链路的CB 设定+ MOP设定值20 无主设定值+ 模拟设定值21 MOP 设定值+ 模拟设定值22 模拟设定值+ 模拟设定值23 固定频率+ 模拟设定值24 通过BOP 链路的USS 设定+ 模拟设定值25 通过链路的USS 设定+ 模拟设定值26 通过链路的CB 设定+ 模拟设定值30 无主设定值+ 固定频率31 MOP 设定值+ 固定频率32 模拟设定值+ 固定频率33 固定频率+ 固定频率34 通过BOP 链路的USS 设定+ 固定频率35 通过链路的USS 设定+ 固定频率36 通过链路的CB 设定+ 固定频率40 无主设定值+ BOP链路的USS设定值41 MOP 设定值+ BOP链路的USS 设定值42 模拟设定值+ BOP链路的USS 设定值43 固定频率+ BOP链路的USS 设定值44 通过BOP 链路的USS 设定+ BOP链路的USS 设定值45 通过链路的USS 设定+ BOP链路的USS 设定值46 通过链路的CB 设定+ BOP链路的USS 设定值50 无主设定值+ 链路的USS 设定值51 MOP 设定值+ 链路的USS 设定值52 模拟设定值+ 链路的USS 设定值53 固定频率+ 链路的USS 设定值54 通过BOP 链路的USS 设定+ 链路的USS 设定值55 通过链路的USS 设定+ 链路的USS 设定值60 无主设定值+ 链路的CB 设定值61 MOP 设定值+ 链路的CB 设定值62 模拟设定值+ 链路的CB 设定值63 固定频率+ 链路的CB 设定值64 通过BOP 链路的USS 设定+ 链路的CB 设定值66 通过链路的CB 设定+ 链路的CB 设定值P1001 固定频率1定义固定频率1 的设定值。
