塑料注塑模具并行设计外文翻译、中英文翻译、外文文献翻译
塑料注塑模具并行设计Assist.Prof.Dr. A. YAYLA /Prof.Dr. Paş a YAYLA摘要塑料制品制造业近年迅速成长。
其中最受欢迎的制作过程是注塑塑料零件。
注塑模具的设计对产品质量和效率的产品加工非常重要。
模具公司想保持竞争优势,就必须缩短模具设计和制造的周期。
模具是工业的一个重要支持行业，在产品开发过程中作为一个重要产品设计师和制造商之间的联系。
产品开发经历了从传统的串行开发设计制造到有组织的并行设计和制造过程中,被认为是在非常早期的阶段的设计。
并行工程的概念(CE)不再是新的,但它仍然是适用于当今的相关环境。
团队合作精神、管理参与、总体设计过程和整合IT工具仍然是并行工程的本质。
CE过程的应用设计的注射过程包括同时考虑塑件设计、模具设计和注塑成型机的选择、生产调度和成本中尽快设计阶段。
介绍了注射模具的基本结构设计。
在该系统的基础上,模具设计公司分析注塑模具设计过程。
该注射模设计系统包括模具设计过程及模具知识管理。
最后的原则概述了塑料注射模并行工程过程并对其原理应用到设计。
关键词:塑料注射模设计、并行工程、计算机辅助工程、成型条件、塑料注塑、流动模拟1、简介注塑模具总是昂贵的,不幸的是没有模具就不可能生产模具制品。
每一个模具制造商都有他/她自己的方法来设计模具,有许多不同的设计与建造模具。
当然最关键的参数之一,要考虑到模具设计阶段是大量的计算、注射的方法,浇注的的方法、研究注射成型机容量和特点。
模具的成本、模具的质量和制件质量是分不开的在针对今天的计算机辅助充型模拟软件包能准确地预测任何部分充填模式环境中。
这允许快速模拟实习,帮助找到模具的最佳位置。
工程师可以在电脑上执行成型试验前完成零件设计。
工程师可以预测过程系统设计和加工窗口,并能获得信息累积所带来的影响,如部分过程变量影响性能、成本、外观等。
2、注射成型法注塑成型是最有效的方法之一,将塑料最好的一面呈现。
这是普遍用于制造复杂的制件,优点是简单、经济、准确与少浪费。
注塑成型过程外文文献翻译、中英文翻译
附录 1：外文翻译介绍如今塑料在日常生活中占据着极其重要的地位。
如果我们说，没有哪个领域的塑料没有不经过制造中直接到宇宙飞船的生产中，这一点也不夸张。
在19 世纪中叶，塑料开始在材料和生活中起主导作用。
耐腐蚀性是塑料甚至成为金属和提高制造生产率方面受到了很高的关注。
从塑料的紧缺，因此在塑料产品设计等各个方面发生巨大的变革,在制造加工领域还在测试阶段,现在,由于很多人最后通过体力劳动取得了卓越的成效,另外人工智能的帮助下,开发出了CAD / CAM 软件。
由于高强度的重量比，提高了化学稳定性和耐温性，具有耐热和耐腐蚀的特性，光泽性使其成为材料更好的选择。
塑料在形成过程中消耗的能量更少，并且可以被循环利用。
今天，塑料正在取代黄铜、铜、铸铁、钢铁等金属。
塑料可以根据制造方法分类，在加热时软化，在冷却时凝固。
这些被称为“热塑性塑料”，以及那些由于化学变化而变硬的物质。
这些被称为热固性或混合型塑料材料成为产品选择特殊材料是另一个重要因素。
这对于产品的确定是非常必要的。
它也应该能够承受压力。
每种材料都有自己的属性。
一些材料在高环境和耐磨性方面比较好。
困难的是找到一种合适材料，它将完全满足整个要求。
