上海罗氏高致敏固体制剂车间（二期）（给排水部分）Shanghai RocheHigh Potent Facility II Project(SHiP II) (Water Supply and Drainage）编制人:Compiled by：审核人:Verified by：批准人:Approved by：版本AVersion A江苏省建设集团有限公司（沪）China Jiangsu Construction Company目录 Contents第一章编制说明及依据 Compile instructions and basis (1)1.1 编制说明Compile instructions (1)1.2 编制依据Compile basis (1)1.3 工程施工目标 Construction goals (1)第二章工程简介及概况 Chapter II project introduction and overview (3)2.1 工程简介 Project Overview (3)2.2 工程概况及系统介绍Project Overview and System Introduction (3)第三章施工部署 Construction Deployment (5)3.1人力资源分析及工具配备Human resources analysis and equipments (5)3.2主要人员职责Major Staff Responsibilities (7)3.3 安装人员部署Installation Person Deploy men (11)3.4施工顺序安排Construction Sequencing (12)3.5施工管理措施Construction Management Measures (12)3.6施工技术准备Construction Technology Preparation (13)3.7施工器具设备Construction machinery equipment (15)3.8工程施工协调Construction Coordination (16)第四章施工方案 Chapter IV construction plan (18)4.1 材料设备进场计划Materials and equipment site entering plan (18)4.2预留孔洞、套管及预埋管道Reserved holes, casing and embedded pipeline (20)4.3管道安装 pipeline installation (21)4.4给水系统water supply system (23)4.5给水系统water supply system (28)4.6主要卫生器具的安装 major sanitary equipments (31)4.7支、吊架安装support and hanger installation (36)4. 8地漏安装Floor drain installation (37)4. 9管道系统调试pipe system debugging (38)4.10主要设备的安装及调试major equipment installation and debugging (42)4.11成品保护：finished protection (45)第五章工程质量保证措施Chapter V Project Quality Assurance Measures (45)第六章安全技术措施 Chapter VI Safety Measures (47)第一章：编制说明及依据 Description of preparation and basis1.1编制说明：compile instructions：本施工组织设计主要反映本专业的基本施工方法，采用经济、合理、安全可靠的施工方案编制而成的。
This construction organization and design reflect our professional construction methods, and adopts a reasonable, economic, safe and reliable construction plan.我们在认真分析了本工程的特点、难点、重点及各种影响施工的因素,充分融入了我们多年来对类似工程的经验和对业主招标文件、图纸的充分理解，对给排水专业安装部分的管理机构设置、施工进度计划、劳动力组织、机械设备配备、物料的采购供应、主要分项工程的施工方法、进度控制措施、工程质量控制措施、安全保证措施、文明施工及环境保护措施等诸多因素进行了综合考虑和研究，以突出本施工组织设计在罗氏制药高志敏车间二期项目给排水专业施工过程中对本专业目标系统控制的科学性、可行性和指导性。
We are careful analysis of the characteristics of the project, key pain points, and a variety of factors influencing the construction, fully integrated into our years of experience on similar projects and full understanding for the owners of the tender documents, drawings, right。
1.2 编制依据： Develop basis建筑专业提供的平、立、剖面； Building professional provided by Dan Tiping,Li,profile；管理公司提供的单体图纸及业主要求；Monomer drawings and owners of the management company to provide the required;工程建设标准强制性条文；The compulsory provisions of engineeringconstruction standards；上海市工程建设地方标准强制性条文； Shanghai City local construction standards mandatory provisions;《建筑给水排水设计规范》；《Code for design of building water supply and drainage》;《建筑设计防火规范》；《Building the code for fire protection design》；相应的国家规范、标准；relevant national norms and standard本专业历史上类似工程的经验；major similar project experience1.3工程施工目标：Construction goals:1.3.1 质量目标 Quality Goals本专业安装工程的质量控制目标：交给业主一个既满足国家规范要求又让业主满意的合格产品。
The professional installation engineering quality control objectives: meet the owner’srequirements as well as national regulatory requirements.1.3.2工期目标Duration targets给排水专业标段工程我们依假定开工日期为2013年6月30日，2013年12月3日结束，共计64个日历天；给排水验收时间：2013.11.1—2013.11.30。
During the period of water supply tenders , we have assumed that the start date is September 30th , 2013, the end December 3rd , 2013, in all 64 calendar days; water supply and drainage time: 2013.11.1—2013.11.301.3.3安全目标 Security Goals施工工程中，本专业将采取切实可行的措施和充足的安全投入，建立完善的安全施工管理机制，确保本项目施工全过程无重大伤亡事故、无火灾事故和无恶性中毒事件目标。
During the construction, this discipline will adopt practical measures and adequate investment into safety, establish and improve the safety of construction management mechanisms to ensure that the whole construction process of this project, guaranteeing that no major casualties, no fire accidents, and no any poisoning incidents occur.1.3.4环境保护和文明施工目标 Environmental Protection and civilized construction target本专业将严格按照上海市有关建筑工程施工的各项管理规定执行，加强施工组织和现场安全、文明施工管理。
成为既满足设计要求又满足建筑物使用功能的绿色建筑，我们将严格按照环保体系的重点来实施本专业项目。
This discipline will perform in strict accordance with the regulations on building construction in Shanghai, and we will strengthen the construction organization and on-site security and civilized construction management so as to meet the design requirements and green building goal. We will be in strict accordance with the focus of environmental protection system to the implementation of the professional project.1.3.5团结合作目标 Unity and cooperation goals积极、主动、高效为业主服务，急业主所急，想业主所想，处理好与业主和综合管理团队、监理、设计、各标段分包及相关政府部门的关系，使工程各方面形成一个团结、高效、和谐、健康的有机整体，努力促进项目综合目标的实现。
