产品说明书英文版V HEN system office room 【HEN16H-HENS2AHENS8Q8-HENH1688】X-Link PRODUCT MANUALS FOR MULTIVIEW CONTROLERThis manual applies to the following models:3UA Multiview CONTROLER ( Optional Front Panal,LCD Console )3UB Multiview CONTROLER ( Optional Front Panal,LCD Console )8U Multiview CONTROLER ( Optional Front Panal )8U-S Multiview CONTROLER( Optional Front Panal )12U Multiview CONTROLERLED Very-large Dot Matrix Screen Multiview CONTROLER ( K Series ) Monitoring Multiview CONTROLER ( N Series )3D Multiview CONTROLER ( 3D Series )4K Multiview CONTROLER (4k Series )IMPORTANT NOTICEThe company reserves the right to update the manual according to improvement of products without any prior notice.In the process of using, if any content in this manual is inconsistent with actual products or there is any further question during use,please contact document information department of our company.Please read this manual carefully before using the CONTROLER and properly file it after reading for future reference. Pictures are for reference only, subject to our available products.Please pay close attention to those with the Icon of in the article.Contents112I Safety guidelinesDanger High Voltage. There is a hazard of highpressure inside this product, non-professionalmaintenance personnel are forbidden to open thedevice! Beware of electric shock!Use the power correctly. Working voltage of thisproduct is 220V, please ensure using the powercorrectly.Ground and use the fuse correctly. This productconnects to the ground plane with earth conductorsof power line, please don't connect earth wires tothe high pressure.Keep ventilation. Maintain adequate ventilation forthe device, the gap between front& rear panels andthe side should be at least 20cm.Moisture proof. Please make sure the device isplaced in a dry environment.Handle with care. There are precision componentsinside the product, please handle with care.Waterproof &foreign body proof. Any liquid, metalfragments, or other irrelevant substances areprohibited to enter the device.Put it away from the inflammable and explosivedangerous goods.II Introduction of Multiview CONTROLERThis chapter includes:Introduction of Multiview CONTROLERExclusive Features of Multiview CONTROLRE1. Introduction of Multiview CONTROLERMultiview CONTROLER is also called big screen processor and display wall CONTROLER etc. The main function is to splice multiple displayunits together into a logic displayer of ultrahigh resolution, and to realize multiple screens and scenarios of optional position and size through opening windows on the basis of this ultrahigh-resolution displayer, which can also ensure that image quality in each screen is excellent. It can show the entire electronic map, geographical information system, industrial flow chart and industrial monitoring information and other data of ultrahigh resolution.Base Type(A Series )3U、8U、12U Product Figure,as shown in the following picture:Base Type Product Figure I（3U、8U、12U）High-end type(U Series )3U LCD Controller Product Figure,as shown in the following picture:3U LCD Controller Product Figure IIMid-Range(K Series )3U Front Panal Product Figure,as shown in the following picture:3U LCD Front Panal Figure IIIMid-Range(K Series )8U Front Panal Product Figure,as shown in the following picture:8U LCD Front Panal Figure IV2. Exclusive Features of Multiview CONTROLERThe company's multi-screen processor has the following exclusive features:A. Pure hardware structure of FPGA, steady and reliabilityWith excellent image processing performance, completely avoid troubles caused by the slow starting speed of PC, hardware conflict and computer virus. Mean Time Between Failure（MTBF）>30000. It can work continuously for more than 1 years.B. Support multiple video signals, on-demand distributionIt supports DVI, HDMI, VGA, AV, SDI, H264 and other video signal for accessing, users can find any collocation as required, meetingindividual requirements of different areas.C. Flexible board design, random combinations; support hot plug, convenient maintenanceRemovable board card matches with cases of different sizes, which can fully meet system requirements of different sizes. Cases make space for expanding and reducing capacity at any time. It is designed with exclusive card channel, system modules, such as input card, output card, control card, fan and power supply, are all independent plug-in design, truly achieving the real-time on-line replacement and convenient maintenance.D. Multi-input videos roaming and overlaying, no regional and hierarchical constraintsSupport multi-input videos to open multiple active windows in optional position in full screen, all windows are allowed to roam free, overlap, magnify and narrow down, no regional and hierarchical constraints, and no size and proportion limits.E. Output synchronization and double-buffer technologyRealize seamless switching between scenario plans without limit to the number, truly achieving synchronous display of screens, ensure no tear, no flicker, no blue screen, no stationary state and other abnormal phenomena.F. Arbitrary cutting function of input videos, support for cutting processing of any sizeArbitrary cutting function of any input video has been specially developed for this product according to different scenarios and requirements of users. Users can cut and shape any part of screen imagefreely with convenient operation of the software according to display requirements, all the images are independently displayed.G. Output mapping function makes construction more flexibleRealize the connection between devices and display units withoutone-to-one correspondence between wires, which can be adjusted in the software freely.H. Support special splicing. It can perfectly support variousdisplay units, realize special display effectIn large-scale exhibitions, enterprise propaganda, stages, bars and other places, users can achieve effects shot by using the functions of special effect and special shape. This device support any splicing combination of display units, special-shaped splicing of LCD, DLP, PDP and LED display unit of any resolution.I. Pane processing technologyFor traditional splicing technology, when display units with gap . LCD \ DLP \ PDP, etc.) are used to present pictures, the picture at the gap between two display units will be divided because of imaging failure, resulting in picture’s breaking and deformation. X-LINK’s paneproce ssing technology shields the picture’s part that is covered by gap between display units through precision adjustment for pixels, achieving smooth and intuitive display.J. The unique advanced subtitle function makes the display more perfectIt can update and display dynamic text messages in real timeaccording to customer needs, such as the weather forecast and urgent message etc. The subtitle function helps users to mark video sources properly, which not only displays images but also increases the function of text information display.K. Mask overlapping function supports the overlapping of customized shapes. Users can customize special effects freelyThe use of mask of special effects can create a richer screen effect.L. The preview and video echoed function greatly helps users to monitor the videoVideo content displaying on the wall can be viewed in advance before playing by the software, and can be viewed remotely during playing.M. Local-storage presupposition for unlimited scenarios facilitates to read and call at any timeSupport the uncapped scene storage, with optional digital control panel, which can facilitate the application of "on-duty automaticinspection" on the areas of manual switch, auto rotation and convenient monitoring etc.N. Digital control panel is helpful to the?scene switchingExclusively developed processor with digital control panel, using the experience of the buttons' superior characteristics of matrix equipment, is specially for splicing in LED screen of super large dot matrix, realizing the fast and convenient scene switching.O. Optional embedded PC operating systemDesign the embedded industrial PC motherboard into board card that can be inserted into the device, so as to integrate PC into the processor to reduce users' trouble to connect it to PC. Users caninstall operating system and common software in the card, which can be used for playing video. perfectly combining functions of externalsplicer of pure hardware architecture and splicer of software architecture.P. Multi-screen interactionMulti-screen interaction refers to the interaction of images, videos and all kinds of documentation resources among cellphone, tablet PC and large screen wall. It is a much "cool" function. It can bring users excellent experience, fun, convenience and it is simple, easy to use, playing the fun of touch to the limit.Q. Support coordinated control among devices, such as startup & shutdown of splicing wall, matrix switching and PTZ control etc.R. Support customized development.III Hardware connectionThis chapter includes:Hardware connection diagramBack panel interface signal diagramDevice supports video input,output and control port signals1. Hardware connection diagramThe typical instance diagram of hardware connection is shown below, it can access various signal sources, such as cameras, DVDs, notebook computers, Blue-ray DVDs, PCs, Webcam etc., and then transmit them to the display wall.Figure 1 Typical instance diagram of hardware connection The installation of this device is very simple; please install it according to the following instructions.1. Disconnect main power of the system, and shut down powers of this device, each display unit and auxiliary devices;2. Place the device into the cabinet or a steady worktable, directthe back panel toward the operating personnel, and keep good ventilation.3. According to figure 1, connect the video cable, networkcable(serial line) and power cord to the response interface of the device.4. After checking and ensuring there is no problem, turn on thepower of each screen, each auxiliary device and the device to start running it with the combination of the control software on PC.Note: please make sure that the power of each device isdisconnected and ensure all connections are correct and reliable during cable assembly.2. Back panel interface signal diagram3UA type multi-screen processor supports input card slots 4, output card slots 6.Figure 2 3UA Back panel3UB type multi-screen processor supports input card slots 6, output card slots 4.Figure 3 3UB Back panel8U type multi-screen processor supports 11-bit input slot, output card slots 9.Figure 4 8U Back panel12U-type multi-screen processor supports 22-bit input slot, output card slots 18.Figure 5 12U Back panel3. Instruction of port(1) Video input signalsThis device supports video signal inputs, as shown in the following table:CVBS-2 inputBNC interface, supported video format: PAL/NTSC/SECAM SDI inputSerial Digital Interface, support 1920*1080@60HZ YPbPr High-definition color componentinterface,support 1920*1080@60HZ(2) Video output signalsThis device supports video signal outputs, as shown in the following table:Output portDescription DVI outputDigital interface, support digital signal 1920*1080@60HZ VGA outputsupport analog signal, able to output VGA signals through the adapter HDMI output Digital interface, support HD signal, able tooutput HDMI signals through the adapter(3) Control port signalsThis device supports the control, as shown in the following table:Control port DescriptionNetwork interface Users can control the PC software via LAN or directly using a computer.S232/ RS485 Users can connect the related equipment device sthrough serial port for joint control.IV Software operationThis chapter includes:Multiview brief and decompression software installation operation Variety of communication connectivity opitionsUser logon operating software,check the device operation viaintelligent detection systemvicePC operating processes,output resolution,mult-window displaylayout and set a specific operation1. Software brief introductionMultiView software is a new generation of visual, WYSIWYG splicer control software, the control software application features integrated splice products, combining the characteristics of the installation works on the development is completed. It adopts the forefront of softwaredesign concepts, instead of the traditional splicing control software debugging complex requirements of the splicing process to achieve automatic operation of the window control process using a WYSIWYG interface, avoid the cumbersome and complex stitching software default process, use of personnel can quickly master the use of the software.Simple software interface, easy to operate, easy to understand and easy to use, just three steps can be done by setting splicing processors. Specific operational procedures, as follows:2. Uncompressed installation(1) Unzip software installation package and weget the following file: .(2) Click it to start the installation. After the installation is completed, the program will create a shortcut icon on the desktop,namely MultiView, and users can also see the installed in the start menu:[ desktop shortcut] [start menu]Figure 6 Software schematic diagramNote: Some security defense software will hinder the process of the installation, please exit the security defense software temporarily for smooth installation.3. Communication connectionThere are two modes of configuration: network and serial mode.(1)Serial mode:Direct-connect method: Directly connect the device to PC via the serial port line. The software will automatically recognize the serial port (Figure 7).Figure 7 Login page I (Serial) Figure 8 Login page 2 (Ethernet)(2)Network mode (two methods): LAN connection method anddirect-connect method.① LAN connection methodConnect via a local area network (automatic assignment of IP). It needs a server to support automatic assignment of IP, the software will automatically recognize the device IP(Figure 8).② Direct-connect methodtware, namely the device IP(Figure 10). If it fails to detect this IP, please restart the computer.Figure 9 the attribute interface Figure 10 Login page 34. User LoginDefault user name is Admin, the password is blank.Figure 11 PC Login pageA. Administrator User LoginMultiView login interface system default initial user name is Admin, password is blank. Click on the "Login" button, the software began to communicate with the device, complete with the device to synchronize information. Admin privileges can be adjusted by user rights management, different permissions, different level of response equipment operation. Notes:(1) Under the Win7 environment, sometimes users need to set the software to "run as administrator", to let the software obtain the highest authority operation.(2) The checked "device info" stands for information of displaying device and then manually enter the main page, the unchecked "device info" stands for information of devices that don't display and then automatically enter the main page.Users can clearly know the operation of entire device by printed device information, including device temperature and cable’s connection state, etc.Figure 12 Select device informationFigure 13 printing equipment information pageB. Operator User LoginThe user selects the "operator" login page, shown in Figure 14. Users can switch keyboard shortcuts for quick scene change with the scene, relatively complex configuration eliminates the need for other operations, very easy to ordinary users.Figure 14 Scene switch interface5. Operation process of MultiviewSoftware operating procedures, including output resolution setting, the display layout setting, multi-window operation process, basic multi-window operation, scene auto player.(1) Output resolution settingOutput resolution settings include increasing, deleting, editing parameters of the resolution and the test and calibration of them, the main operation flow diagram is as follow:Display current resolution parameters, the output resolution can be achieved on testing and verification.Figure 15 Output resolution settingSelect the right resolution, if there is no right one in the list, users can add the needed resolution. In general, users should select the best resolution.Figure 16 current output resolution SettingsIf the resolution of the display device resolution parameters and parameters of the current selection are inconsistent, you can click Edit to modify it.View the current output resolution, check the "test" and color bar of seven colors will exist in the large screen if the setting is successful, as shown below.Figure 17 Striped test(2) Displayer layout settingsThe displayer layout settings include array settings, corresponding relation settings and array test. The main operation flow diagram is as follows:The number and distribution of equipment, the layout of the logical screen to be set according to the physical display.Figure 18 Displayer layout settingsSet the layout of the logical screen according to the actual screen quantity and distribution of display units.Figure 19 corresponding relations settingsThe actual display units of logical screens can be matched based on the connectivity condition of the actual output interface as follows: Select the output channel and drag it to the corresponding display unit. Directly click the output channel in the display unit to cancel it as necessary.Notes:No. 1& 2 board cards of 3UA slot support to open four windows, others support to open two windows.All board cards of 3UB and 8U support to open four windows.(3) Multi-window SettingsMulti-window settings include settings of open windows and parameters and scene saving etc. according to input video sources. The main operating flow diagram is as follows:Open multiple windows to display multiple screens can be realized on the big screen, multiple input sources simultaneously display, picturein picture, the picture of any size, quickly switch the input source,and a series of partial zoom display function. When multiple windows are superimposed, superimposed on top of the window display section information. Multiple windows can be the same input source may also be a different input source.Figure 20 Multi-window SettingsSelect the input sources to be displayed, open a window in thelogical screen, and then adjust the window size and other parameters. Note:please refer to (4) basic operation for details.(4) Basic operationA. Open a window① Choose the input sources in the video source list;② Drag out a rectangular window from the upper left to the lower right corner directly in edit area of logical screen with the mouse.B. Edit the window attributeThere are two methods to edit the basic attributes of the window:Method I: adjust the settings of the size and coordinate of the window by dragging the mouse directly in the edit area of logical screen;Method II: edit the window attribute directly in window attributes column.C. Switch input sources of a windowThere are two methods to switch input sources of a window when it is necessary:Method I: Select the window that needs switch input sources,directly double click the input slot and channel to be switched in " Video Source " for change settings;Method II: Select the window that needs switch input sources, and then complete the switching by clicking the input slot and channel directly in window attribute column.D. Windows shortcutsThere are two methods to delete, cut, resize the window and change levels etc.Method I: Select the target window and complete the operation by context menu;Method II: Select the target window and complete the operation through the shortcut key in " Win Prop ".E. Window lockWhen the window attribute setting is completed, users can lock it to prevent any incorrect operation or unnecessary change by moving the cursor. Windows will be transparent and irremovable when it is locked.: Select the target window and click the button to lock it.: double click the locked window at any position to select it andthen click the button to unlock it.F. The window covers all over the logical screenThere are two methods to extend a window to the range covered by the grids of its four vertices, namely the window covers all over thelogical screen:Method I: double click the mouse to move the cursor to the target window and then double click left mouse button to complete the operation.Method II: get a fast implementation through toolbar shortcuts ofcover all over logical screen button .G. Open PIP(picture in picture) function① Select the target input source in the Video Source;② Drag out a rectangular window from the upper left to the lower right corner directly in edit area of logical screen with the mouse.③ Select the target window and click the button to lock it.④ After the window becomes transparent, drag out a rectangular window from the upper left to the lower right corner on top of it with the mouse.H. Arbitrary cutting function of input video sourcesCut any part of the video source to display independently and get a fast implementation of video clips and window refinement so as to make the focal points stand out. The specific operation is as follows:① Drag out a rectangular window from the upper left to the lower right corner directly in edit area of logical screen with the mouse.② Select the target window and click the button to cut it.I. Delete the window:①Partial delete: select the target window and click the delete button in the upper right corner of the window to delete part of it.② Delete all: complete the operation by using the clear screen button .J. Save the information to the device:By pressing the button , users can save the configured settings into the device or save them as default scenes to directly restore to the latest related settings when users startup the device next time, as shown below.Device saving can be divided into three functions, respectively are:① Scene saving: click "add" to select the added scene in the left list and set the relevant information on the right and then click "save" to complete the operation.②Scene covering: select the target scene to be covered and set the relevant information on the right and then click "save" to complete the operation.③Scene deleting: select the target scene to be deleted and then click "del" to complete the operation.Figure 21 scenes save(5) Scene player (scene auto switching)It is similar to scene management tools of music players, users can customize different scenes as needed, realizing the management to the play order and time among different scenes and can change the information freely. The main operation flow diagram is as follows:Scene player①Tick the "start"②Right click the mouse to choose new list inthe left list③Right click the mouse to insert the scene onthe right playlist④Choose the target scene to be playing in the"scene list"⑤Click the "play" buttonlist".playlistScene player interface is shown below:Figure 22 Scene playerKey features include scene play, pause, increase switching and scene lists, delete, and switching.Figure 23 Scene player–scene settingsRight click and choose the new list in the left list, and then right click to choose the insert scene in the right scene playlist.Figure 24 Scene player–scene showClick the button to play the video.Note: click the button to stop the video if you need to modify or edit it.V Front panel button operationThis chapter includes:Schematic view of the front panel buttonsKey operating instructionThe main operating of keys1.Front panel button diagramControl panel with LCD display, status lights, operating buttons.Figure 25 Control panel with buttons2. Instruction of buttonsThe front panel is provided with 20 keys and a Chinese / English LCD module. 20 keys are divided into 2 functional areas, the clearfunctional partitioning is convenient for users to operate the device, while the LCD module provides rich display information.(1)Control buttonThe main control buttons are used to do some fast operation, features a clear, easy to operate, the specific key functions in the following table:(2)Numeric keysAfter being saved in upper computer, the scene is defined as a number and then is switched by using numeric keys.(3)Key operation1. Easy scene switchingPress any key to lighten LCD screen, select the scene switching by pressing "up" and "down" keys , press "OK" to enter the next page, then select "easy switch" and press "ok" button to switch the scenes by corresponding numeric keys according to the order to saved scenes.Scene switching includes easy switching, list switching and number switching.2. Device detectionPress any key to lighten LCD screen, select the "device detection" by pressing "up" and "down" keys to view the current working condition of the device.3. View the IP address of this devicePress any key to lighten LCD screen, select the "device information" by pressing "up" and "down" keys, press "OK" to enter the next page, then select "view IP address of this device" and press "ok" button to complete the operation.VI. Common failuresIf you fail to eliminate the failure according to the above methods or the failure you found is outside of the range indicated above, please contact our technical assistance.VII Specification parametersVIII Other reference documentsThe following table shows other documents, detailed information, if you need, please contact with the document information department.Thank you again for you choose our products! We are dedicated to provide best service for you!Appendix1. serial port switch control of the scene (the control)Equipment and control the computer connection diagram, shown in Figure 26.Figure 26 device and control computer Wiring Diagram Determine the serial number operations, as shown in Figure 27. Figure 27 a schematic diagram of the operation to determine the serialnumberWatch the CD serial control software debugging information in the C-004 , the specific operation as shown in Figure 28.Figure 28 serial debugging assistant using schematic Instruction SetScene 1Scene 2Scene 3Scene 4Scene 5Scene 6 06。
