Hill-Rom

屹龙公司

标题：First Impression®（注册商标，直译：第一印象）单人病房端墙控制系统(P780D)安装说明

介绍：

此说明用于安装First Impression单人病房端墙控制系统。请在开工前，仔细阅读并了解各个部件的安装说明。

所需工具：安装图纸打线绳

防护眼镜电钻

1英寸钻头水平（仪）

扫帚和簸箕螺丝刀

隔热毯湿海绵或湿布

铅笔卷尺

钳子剥皮钳

填缝枪捻缝

所需部件: (1) P780D First Impression®单人病房

(1) 58594 780D密封组件包

(6) 55690PL 电镀的墙体嵌套面板—暗线箱

(1) 56203 面板, 安全开关和插座之间需要刻槽

以及

(2) P781D01 First Impression®单人病房悬架(标准)

(1) 58585 780D吊架组件包

或者

(1) P781D02 First Impression® 悬架, 抗震单人病房

(1) 58584 吊架组件包, 780D

58594, 780D密封组件包, 包括以下物品：

(6) 29591 #8自钻螺钉

(8) 5314301 #12六角头自钻螺钉

(4) 53899 塑料插头按钮

(6) 55408 2"绝缘线

(6) 55409 3"绝缘线

58585, 780D吊架组件包, 包括以下物品：:

(6) 16114 #6—32 x 1/2"飞利浦平头镀锌螺钉

(4) 21045 套挂螺栓

(4) 21046 兰花夹

(8) 5314301 #12六角自钻螺钉

(4) 29325PL 电镀壁骨

58584, 780D吊架组件包, 包括以下物品：

(6) 16114 #6—32 x 1/2"飞利浦平头镀锌螺钉

(8) 5314301 #12六角头自钻螺钉

Preparing the Wall for Installation

墙安装准备

WARNING:

Determine the wall and construction type prior to the installation of this

headwall system. Failure to do so could cause injury or equipment damage.

警告：

安装端墙控制系统时需确定墙及建筑类型，否则可能造成人员或设备的损伤。

1. Before proceeding, refer to the local or state building codes, and determine the

wall type and construction type:

• Seismic walls are constructed to prevent damage from an earthquake.

• Non-seismic walls are not constructed to prevent damage from an earthquake.

• Fire-rated walls are constructed to prevent the spread of fire.

• Non-fire-rated walls are not constructed to prevent the spread of fire.

2. Do one of the following:

• For non-seismic walls, contact Hill-Rom Technical Support at 800-445-3720.

• For seismic walls (both fire-rated and non-fire-rated), install wall backing

plates according to the Office of Statewide Health, Planning, and Development

(OSHPD)-approved drawings and the as-built drawings.

1.开工前，参考国家或地区家建筑规范，明确墙及建筑类型：

•抗震墙可以防止高强度地震带来的损伤

•非抗震墙不能防止高强度地震带来的损伤

•防火墙可以阻止火势蔓延

•非防火墙不能阻止火势蔓延

2．根据以下情况作出选择

•对于非抗震墙，请拨打屹龙公司电话800-445-3720要求技术支持.

•对于抗震墙（不论防火或者不防火），根据全州健康计划与发展办公室对办公建筑作出的批准图纸和竣工图纸来安装墙衬板

NOTE:

The backing plate (provided by other) must be 6" (15 cm) wide, 14-gauge steel, continuous between steel studs at a maximum of 16" (41 cm) centers.

注意：

由其他厂商提供的衬板须为6英寸（15cm）宽的14号钢材，并可以连接最大中

心间距为16英寸（41cm）的钢钉。

Installing the Private Unit Hanger Assemblies (P781D01/02)

安装单人病房吊架组件(P781D01/02)

图1. 墙尺寸-吊架

1.Refer to the as-built drawings, and make a vertical plumb line on the wall to show

the bed centerline (A) (see figure 1 on page 3).

1. 参照安装图纸，在墙上做一条铅垂线作为病床的中心线（A）（见第3页图1）。

2. From the finished floor line (B), measure 73 5/8" (187.01 cm) vertically, and

make a horizontal plumb line (C) to show the top edges of the hangers (D).

2. 在距离地板线（B）垂直距离73 5/8" (187.01 cm)位置画水平垂线（C）作为吊架（D）的顶边。

3. From the bed centerline (A), measure 22 5/8" (57.47 cm) horizontally along the horizontal plumb line (C), and make a mark on the wall to show the inside edge of the first hanger (D).

3. 沿水平垂线（C），距离床中心线（A）22 5/8" (57.47 cm)位置处，在墙上作

出标记，标识成第一个吊架（D）的内沿。

4. From the mark on the wall, measure 45 1/4" (114.94 cm) horizontally along the

horizontal plumb line (C) and across the bed centerline (A), and make a mark on the wall to show the inside edge of the second hanger (D).

4. 沿水平垂线（C），穿过床中心线，自上一标记45 1/4" (114.94 cm)远处作出

标记，标识为第二个吊架的内沿。

5. On non-fire-rated or non-seismic-rated walls, do the following to install each
