变频电机说明书
安川变频器说明书
安川变频器说明书安川变频器说明书一、前言安川变频器是一种广泛应用于各种机械设备中的电子控制器。
它能够将交流电源等静止的电力信号转换成交变的电力信号，从而控制电动机的转速、功率和方向等参数。
安川变频器不仅可以提高机械设备的工作效率，还可以降低能耗和噪音等方面的问题。
在实际生产和工业制造中，安川变频器具有无可比拟的优势，是一种先进的控制技术。
本说明书主要介绍安川变频器的使用方法、性能指标和故障处理等方面的要点。
通过对说明书的仔细阅读，用户可以更好地了解安川变频器的原理和操作技巧，从而更好地使用和维护设备，保证设备的正常运行和安全性能。
二、安装和使用1.安装位置：安川变频器应安装在通风良好、干燥、清洁、光亮的室内环境中。
避免在嘈杂、潮湿、多灰尘等環境中使用，这样会影响安川变频器的性能和寿命。
2.组装和安装：安装前，应检查所有的部件是否齐全完好，并且各部件之间应连接正确。
安装时应注意电器设备的绝缘保护和接地保护。
安川变频器的安装高度不应超过2000米，否则需要加装高度补偿器，以保证安川变频器的正常运行。
3.连接电源和电缆：连接电源前，应先通电检查各项参数是否符合规范，确认无误后可以进行使用。
安川变频器对电缆的长度和材质等有一定的要求，不同型号的变频器需要使用不同规格和材质的电缆。
在连接电缆时，应注意接线的正确性和位置，避免发生短路或其他安全隐患。
4.使用和维护：在使用安川变频器时，应根据需要进行参数的调整和设备的监控，保持设备的稳定性和优良性能。
同时，也要做好设备的日常维护工作，包括清洁、检查、润滑等方面的处理。
在出现故障情况时，应及时处理并排除故障根源，避免影响设备的正常运行。
三、性能指标安川变频器的性能指标是用来衡量设备能力的重要参考。
以下是安川变频器的主要性能指标：1.额定电压：安川变频器的额定电压一般为AC220V/380V/415V，不同型号的变频器也有可能存在差异。
2.额定功率：安川变频器的额定功率是指电动机的额定功率，一般范围是0.1kW~800kW。
安川变频器说明书
安川变频器说明书安川变频器说明书1. 引言安川变频器是一种用于控制电机转速的设备，可以实现电机的变频调速功能。
本文档将介绍安川变频器的基本工作原理、操作方法和注意事项。
2. 变频器的工作原理安川变频器通过改变输入电源的频率来调节电机的转速。
具体而言，它将交流电源的电压通过整流、滤波和逆变等电路转换成直流电源，然后再通过逆变器将直流电源转换成可调频率的交流电源，以控制电机的转速。
3. 变频器的使用方法3.1 连接电源在使用安川变频器之前，首先需要将其连接到电源。
请确保输入电源的电压和变频器的额定电压相符，并注意正确接线，以避免电路短路或电机损坏的风险。
3.2 设置参数在连接电源后，需要设置一些参数来适应具体的应用场景。
这些参数包括电机额定功率、额定转速、最大转矩等。
可以通过变频器的控制面板或者通信接口进行参数设置。
3.3 控制方式选择安川变频器支持多种控制方式，如键盘控制、模拟信号控制和通信接口控制等。
根据实际需求选择适合的控制方式。
3.4 转速调节在变频器开始工作之后，可以通过控制器上的转速调节按钮或者通过通信接口发送指令来改变电机的转速。
可以根据需要逐步调整转速，以达到最佳工作效果。
3.5 故障排除如果在使用过程中遇到故障，请首先检查电源和电机连接是否正确，排除外部因素引起的问题。
如果问题仍然存在，可以参考变频器的故障诊断手册，或者联系技术支持人员进行更详细的排查和修复。
4. 使用注意事项4.1 安全操作在使用安川变频器时，务必遵守操作规程，保证自己和他人的安全。
在操作变频器之前，请先熟悉使用手册，了解相关安全知识，并正确佩戴个人防护装备。
4.2 电源要求请确保提供给变频器的电源符合国家标准，并具备足够的质量和稳定性。
不要使用损坏或不符合要求的电源，以避免对变频器和电机造成损害。
4.3 温度和通风在安装变频器时，应确保其周围环境的温度适宜，并保证有足够的通风空间。
避免将变频器安装在高温或密闭的环境中，以免影响其正常工作或导致故障。
TBVF系列矿用隔爆型永磁同步变频电动机使用说明书(力博)
TBVF系列矿用隔爆型永磁同步变频电动机执行标准：GB3836.1~2-2010Q/SDORA001-2016使用说明书欧瑞安电气2016年03月01日目录1.概述 (4)1.1适用围 (4)1.2执行标准 (5)1.3电动机结构 (6)1.4电动机规格型号及基本参数 (6)1.4.1电动机规格型号 (6)1.4.2 基本参数说明 (6)1.4.3电动机主要性能参数 (7)1.4.4电动机外形及安装尺寸 (10)1.5防爆形式 (13)1.6绝缘及防护等级 (13)1.7防护等级 (14)1.8使用环境要求 (16)1.9工作运行条件 (16)1.9.1控制方式 (16)1.9.2电压/频率的变化 (17)1.10接线盒与温控传感器 (17)1.10.1主接线盒 (17)1.10.2温控线接线 (18)1.11轴承 (22)2.安全须知 (23)2.1.安全标识定义 (23)2.2注意事项 (23)3.产品运输、验货、存放 (24)3.1产品运输吊装 (24)3.2产品验货 (24)3.3产品存放 (25)3.3.1 存放位置 (25)3.3.2长期存放 (25)3.3.3 防锈 (25)3.4一般保护 (25)4.电动机安装 (26)4.1安装前要注意事项 (26)4.2安装场所和地基 (27)4.2.1 安装场所 (27)4.2.2 基础 (27)4.3电动机与联轴器连接 (27)4.4电动机与底座的连接 (29)4.5电气连线 (30)4.6完成安装 (31)4.7水冷系统连接 (31)4.8注油润滑 (32)4.9电动机的调试 (33)4.10验收.................................................. 错误!未定义书签。
4.10.1外观检查项目...................................... 错误!未定义书签。
4.10.2空载试验.......................................... 错误!未定义书签。
变频电机使用维护说明书
变频调速专用异步电动机使用维护说明书大连钰霖电机有限公司一、概述YVP、YVP2系列电机是变频调速电动机，采用独立的全封闭外表轴向轴流风机对电机强迫冷却，外壳防护等级为IP44(YVF)、IP54(YVF2)（也可根据用户要求），冷却方式为IC416，也可按需要制成其它冷却方式。
本系列电机机座中心高、功率、安装尺寸和Y、Y2系列完全一致（外形尺寸与Y、Y2系列不同），安装方式有IMB3、IMB35、IMB5、IMV1等。
可以与国内外同类变频电源装置配套，通用性强，互换性强，运行可靠，维护方便。
电机的使用条件：环境空气温度：随季节而变化，但最高不超过40℃，最低不超过-15℃；海拔高度：不超过1000m；调频范围：3Hz或5Hz~50Hz保证恒转矩运行，50Hz~100Hz保证恒功率运行；电压：380V(1±5%)；接法：功率在55kW及以下为Y接，功率在55kW以上为Δ接；工作方式：S1（连续）定子绕组温升限值（电阻法）：不超过80K。
二、安装前的准备1、电机开箱前应检查包装是否完整无损，有无受潮的迹象。
2、电机开箱后应小心清除电机上的尘土。
3、检查电机的铭牌数据是否符合要求。
4、仔细检查电机在运输过程中，有无变形或损坏，紧固件是否松动或脱落，试用手转动电机是否灵活。
5、用500V兆欧表测量电阻，其值不应低于0.5MΩ，否则应对定子绕组进行干燥处理。
干燥处理时的温度不允许超过120℃。
三、电机的安装1、电机允许用联轴器、正齿轮及三角皮带轮传动。
如选用小皮带轮，可扩大三角带的传动范围。
双轴伸电机的风扇端，只允许用联轴器传动。
2、采用三角皮带传动时，电机轴中心线与负载中心线平行且要求皮带中心线与轴中心线垂直；采用联轴器传动时电机轴中心线与负载中心线应重合。
3、对立式安装的电机，轴伸除三角皮带轮（或相当于三角皮带轮负载）外不允许再带有其他任何轴向负载装置。
4、电机的安装应保证其良好的通风冷却条件。
变频电机说明书
YTB-S2系列交流电机变频调速器使用说明书概 述YTB-S2系列变频器是我公司在YTB-S1的基础上改进而来,它保持了原有的优点,改善了运行性能, 增加了直流制动功能,及其它附属功能. 使调速更可靠，应用更广泛.，采用先进的SMD 工艺,严格的出厂质检，能够满足用户的多种使用要求．开 箱 检 查1 确认在运输过程中是否造成损坏。
2 检查变频器的铭牌以确定在您手中的产品就是所订货品。
3 检查包装箱内含变频器本体一台，使用说明书一份，出厂合格证一张及其它选购品。
型 号 说 明输出功率容量(KW)输入电压（V）T:三相输入 S:单相输入YTB-S2-1.5/220产品系列名称二次改型技 术 参 数额定功率（KW ） 额定电流（A ）S2系列 (单相220V)0．4 30．75 41．5 7.5T2系列(三相380V)0.75 2.5 1.5 3.7 2.2 5 3.7 8.5 5.5 13 输入电源要求 1Φ 220VAC 或 3Φ 380VAC ， 50HZ/60HZ 控 制 特 性频率范围0-120HZ 环境 场所 室内无腐蚀气体，无导电尘埃，通风良好 频率设定 按键,外部电位器,0-10mA 输入温度/湿度 -10℃~+40℃ ,相对湿度90%以下,无结露 点动频率0.1-10.0HZ 标高/振动 海拔1000米以下，振动0.5G 以下 制动功能 再生制动, 能耗制动 过载能力 150%，60秒 加减速时间 0.1-120.0秒 显示 四位数码管，显示运行频率、故障代码等 保护功能 过电压,欠电压,过电流 ,过负载、过热保护,失速保护,熔断器保护 冷却方式 自冷/风冷附加功能 定时器/计数器功能安装与结构1. 安装为了提高散热效果，应垂直安装变频器， 安装底板应为铁质或为其它阻燃耐热材料，并留有足够的 通风空间(周围至少留有12CM 以上的空间). 2.接线图1:安装尺寸图铭牌“Mode”--模式键接线盖板图2:操作面板图“▼”--下降键“▲”--上升键“Run”--运行键“Stop”--停止键四位数码管外接型外接操作盒插座普通型正转灯反转灯打开接线盖板，即可看到主接线柱和控制用接线柱。
变频电机使用说明书
钰霖电机YVF变频调速电动机使用维护手册Usage Handbook资料.前言首先感您购买本公司的YVF系列变频调速电动机，请在使用前仔细阅读本手册的各项容，以保证电机的正确使用，不正确的使用将造成不正常的运行，引起故障或降低使用寿命。
产品介绍YVF系列变频调速电动机是在Y2系列电机基础上更新设计的，可广泛使用于各种机械领域，且符合国家和企业的相关技术标准，与国外同类产品水平相当。
到货检查收到您订购的产品后，请开箱检查以下各项，如发现产品有任何问题或不符合您的订购资料.要求，请您与本公司联系。
1.请核对产品的铭牌，确认您订购的规格2.请检查外观有无在运输中受损3.除电机本体及使用说明书外，确认您所订购的附件有无完整4.检查零部件的装配应良好，紧固件应无松动。
搬运和存储4.1本电机产品为精密制造零件，搬运时只允许在其规格的运输吊攀上进行起吊（小规格可以用手搬运），必须轻吊、轻拿、轻放、防止碰撞。
不得在搬运过程中抱持轴承头部。
且在安装调试中对轴承头部要妥善防护，否则将导致运转精度失准。
资料.4.2电机的存储场所应符合以下条件：（1）周围温度：-15度——+40度（2）相对湿度：5%——80%（3）周围环境：不受直晒，周围介质必须无灰尘、腐蚀性气体、可燃气体、油雾、蒸汽、滴水和震动。
并尽量避免含盐较多的场合。
不得放在会发生温度急剧变化而结露和冰冻的地方。
（4）电机不可直接或倒置放在地面上，应放置在合适的台架上，且应放平稳。
（5）如周围环境恶劣则应用塑料薄膜包好进行保管，可在塑料薄膜中加干燥剂防止受潮。
如要长期保存，则应严格封装。
使用环境资料.（1）海拔：1000米以下（2）环境温度：-15度——+40度（3）电动机安装场所必须干燥，清洁。
具有良好的通风不受直晒，周围介质必须、无灰尘、腐蚀性气体、可燃气体、油雾、蒸汽、滴水和震动。
并尽量避免含盐较多的场合。
（4）空气相对湿度：80%以下电机安装（机械安装和电气安装）5.1电机常用机械安装方式：B3底座安装B35底座及法兰安装B5法兰安装下面是安装时的注意事项：（1）电动机的安装应由技术人员来完成安装的基础应有足够强度，电机应放置平稳请勿倒装、斜装或垂直安装（要垂直安装，请在资料.订购时标注）（2）载荷转动部分在安装前要做动平衡校正。
电机变频驱动器数据手册说明书
Brake chopper 7-digital display assembly
FS2
with SmartWire-DT module DX-NET-SWD3
Specification for general requirements: IEC/EN 61800-2 EMC requirements: IEC/EN 61800-3 Safety requirements: IEC/EN 61800-5-1
Variable frequency drives
DC1
Ue
115 V AC, single-phase
U2230 ຫໍສະໝຸດ AC, 3-phaseULN
V
110 (-10%) - 115 (+10%)
Ie
A
5.8
Rated operational current at an operating frequency of 16 kHz and an ambient air temperature of +50 °C
Overload cycle for 60 s every 600 s
at 230 V, 50 Hz
P
kW
1.1
IM
A
4.6
at 220 - 240 V, 60 Hz
P
HP
1.5
IM
A
5.8
IP20/NEMA 0
OP-Bus (RS485)/Modbus RTU, CANopen®
SmartWire-DT
CE, UL, cUL, RCM, UkrSEPRO, EAC
RoHS, ISO 9001
ρw
%
< 95%, average relative humidity (RH), non-condensing, non-corrosive
西门子变频器说明书
西门子变频器说明书西门子变频器说明书1. 引言西门子变频器是一种高性能的电机调速设备，能够根据需要调整电机的运行频率，实现电机的无级调速。
本说明书将介绍西门子变频器的基本原理、安装要求、操作方法和故障排除等内容，以帮助用户更好地使用和维护西门子变频器。
2. 变频器的基本原理变频器通过改变电源的频率，控制电机的转速。
它由输入回路、整流器、滤波器、逆变器和输出回路等组成。
输入回路将电源的交流电转换为直流电，整流器将直流电转换为可控的直流电。
滤波器用于消除电源中的噪声和干扰。
逆变器将可控直流电转换为可控交流电，从而实现电机转速的调节。
输出回路将变频器产生的交流电供应给电机。
3. 安装要求3.1 电源连接- 将变频器与电源连接时，需要注意电源的相序，确保与变频器的要求相符。
- 接线需要牢固可靠，避免接触不良或松动。
- 接线时应注意线缆的选择，保证其额定电压和电流满足要求。
3.2 接地- 变频器需要良好的接地，确保安全可靠。
- 接地线的截面积应符合要求，接地线的长度应尽量短。
- 接地电阻应符合标准要求。
3.3 散热- 安装变频器时，需要考虑散热问题。
应在通风良好的地方安装，确保变频器的散热良好。
- 变频器的周围不应有阻塞物，确保空气流通。
4. 操作方法4.1 启动和停止- 启动变频器前，需要先检查各部件连接是否良好。
- 启动变频器时，应按照正确的步骤进行，避免产生故障。
- 停止变频器时，应先减小负载，然后再停止变频器。
4.2 频率和转速调节- 变频器可以通过调节频率来控制电机的转速。
- 频率和转速的调节方法有多种，可以通过旋钮、按钮或界面来进行设置。
- 调节时需要根据实际需要进行调整，避免过高或过低。
5. 故障排除5.1 常见问题及解决方法- 若变频器无法启动，可以检查电源是否正常，接线是否良好。
- 若变频器工作异常，可以检查各部件是否受损，是否有杂音等异常情况。
- 若变频器频率调节不稳定，可以检查参数设置是否正确，是否存在干扰等问题。
士林电机 SF 系列变频器 说明书
危險：有受 傷、感 電之 虞 安 裝運 轉之 前請 詳讀 說明 書， 並 依指 示操 作
通電 中及 電源 關閉 後10分鐘 內 請 勿打 開上 蓋 請確 實接 地 注意：有發 生火 災之 虞 請安 裝於 金屬 等不 燃物 之上
说明书导读
导读 士林电机 SF 系列变频器，为符合市面上大部分的应用层面需求，设计了许多复杂的参数 功能，对于初次接触变频器的客户，可能会造成使用上的困扰，因此我们希望读者能够仔细阅 读说明书的每一部分，以便充分掌握此变频器的使用方法。在阅读说明书时，有不明之处，欢 迎来电垂询。 说明书的第 2 章详细列出了士林 SF 系列变频器的规格，2-5 节指导客户安装变频器，并 且强调使用变频器时应注意的安全事项。 第 3 章指导客户如何使用变频器，3-1 节列出了变频器的操作模式；3-2 节说明如何使用 操作器；3-3 节列出了简单的操作步骤。第 4 章对参数作了详细的解释说明。
SF-040-11/15K
323
SF-020-15/18.5K 350
SF-040-18.5/22K 350
L1 (mm) 303 303 303 330 330
W (mm) 200 200 200 230 230
W1 (mm) 186 186 186 214 214
H (mm) 186 186 186 195 195
分辩率
模拟设定
DC 0~5V 信号设定时，分辨率为 1/500； DC 0~10V 或 4~20mA 信号设定时，分辨率为 1/1000。
输出频率 数字设定 最大目标频率的 ±0.01%。
变频器说明书
目录一、安全须知 0二、概括 (2)三、技术指标 (3)四、产品参数列表 (4)五、构造特征与安装 (8)腔体内部构造 (16)六、工作原理及主要元器件 (17)七、显示屏显示界面 (19)八、安装注意事项 (21)十、养护与保护 (26)十一、储藏与运输 (26)十二、开箱检查 (26)一、安全须知为了您的人身和设施安全，在使用本变频器以前，请认真阅读本章节内容，并在此后的搬运、安装、调试、运转、维修过程中严格履行。
1、使用警示和表记定义对于对特定条件及其余会致使人员伤害或设备破坏的警示本符号提示假如不按要求操作，可能致使死亡、重伤或严重的财富损失。
本符号提示假如不按要求操作，可能使身体受伤或设施破坏。
本符号说明操作时需注意的事项。
本符号提示一些实用的信息。
2、安全须知2.1 、非专职人员不得私自操作本设施！2.2 、设施外壳一定优秀接地！2.3 、禁止直接对连结到变频器上的电缆进行绝缘摇测！2.4 、接线时请注意输入接线柱标记R、 S、 T( 电源 ) 和输出接线柱标记U、V、W（电机）不得接错！2.5、将变频器从地面运至工作地址第一次上电前或长久寄存以后再上电，应确认内部完满、无积露！2.6 、不得任意改变本说明书规定的配接设施！2.7 、设施应避开有淋水的地方！2.8 、变频器防爆及电气性能，出厂前均已查验合格，禁止用户变动变频器壳体的构造和电气参数，并做好隔爆面的防备，防止磕碰划伤！2.9 、设施在带电状况下，禁止松动隔爆壳紧固件，在检修或办理故障时，请注意“禁止带电开盖”、“断电后15 分钟开盖”！2.10、断电后15分钟，才同意翻开前门！2.11、检修被驱动设施时，务必断开变频器的隔走开关！2.12 、检修变频器前，断开隔走开关，并断开前级电源！二、概括1、合用范围矿用隔爆兼实质安全型沟通变频器（以下简称变频器）合用于沟通50Hz、电压 660V 或 1140V供电系统、 630kW 及以下三相沟通永磁同步电动机的调速控制。
Altera DE1变频电机启动器配置说明说明书
2015How to Configure the DE1 Variable Speed Starter for Reversing Motor Starting Applications.ApplicationThe DE1 Variable Speed Starter (VSS) offers the advantages of both a direct online(DOL) starter and a variable frequency drive (VFD) in a single device by providing the ease of use of a DOL starter and the variable motor speed of a variable frequency drive. The DE1 makes it possible to ensure a soft motor start that uses configured time parameters to take a motor to a defined speed with full torque at low motor RPM while avoiding inrush current peaks, enabling users to achieve the energy efficiency and product reliability required for their applications. Additionally, the DE1 can be easily configured for other applications such as basic starting and/or 2 speed applications.OverviewThe DE1 Variable Speed Starter can be quickly configured by using the DXE-EXT-SET configuration module to change default values if required by the application. This module snaps into the face of the DE1 enabling the user to configure Mains Frequency, Ramp Time, Fixed Frequency, Mode Selection and Motor FLA (protection) with only a small screwdriver. While other devices such as DriveConnect software, the DX-KEY-LED keypad, etc. may be used to configure the DE1, examples in this document refer to the use of the DXE-EXT-SET configuration module to provide a straightforward setup procedure when the DE1is to be used for basic motor starting. Additional capabilities and configuration settings for the DE1…may be found in the DE1 User Manual.ContentsDXE-EXT-SET Configuration Module Functionality (2)Transfer parameter values of the DXE-EXT-SET module to the DE1 (3)DE1 Functionality–Mode 0 Terminal Assignment (3)DE1 Functionality–Connection Diagram for a reversing starter application (4)Application Note AP040101EN Variable Speed Starter:Reversing starter application Effective February2015DXE-EXT-SET Configuration Module FunctionalityThe DXE-EXT-SET configuration module is used for configuringthe DE1 during setup operations and is normally removed from theDE1 for RUN operations, as all parameterization informationresides within the DE1.NOTE: The DXE-EXT-SET module can only download thepotentiometer values from the module into the DE1. The DXE-EXT-SET module cannot upload parameters from a DE1 into themodule.The desired parameterization values can be adjusted prior to beingconnected to the DE1. The module is then connected to the DE1that is in the STOP mode and the SET button is pressed to initiate the download. Parameterization values are found in Table 1:Table 1–Parameterization with the DXE-EXT-SET Configuration ModuleDE1 Parameterization DXE-EXT-SETParameter Unit PNU Range Default SettingsRamp sec.P-030.1-30050.1/1/3/5/10/15/30/60/120/180P-040.1-300Mode P-150-900-9Fixed Frequency Hz.P-200-60201-60I motor Amps P-0810%-100% x I e100%10%-100% x I eSupply Frequency Hz.P-0950-606050/60NOTES:∙The DXE-EXT-SET module Ramp parameter sets both Start(P-03)and Stop(P-04)ramp parameters with the same value.∙I e= DE1… Frame Maximum∙I motor= Motor Nameplate FLA, establishes motor protection thresholds.∙I motor potentiometer setting for a 1.9A FLA motor is calculated by the following formula:I motor=Motor Nameplate FLA= 1.9A=0.904=90%DE1-342D1… Rated Current 2.1A∙Supply Voltage parameter P-07is not configurable with DXE-EXT-SET module.External keypad or drivesConnect software is required to change this parameter.Parameter P-07 default values are established by product catalog number when selecting Frame Size and Frequency.Reference Table 2Application Note AP040101EN Variable Speed Starter:Reversing starter application Effective February 2015Table 2–Supply Voltage ParameterizationSupply Voltage Vac P-07200-240 Vac ± 10%23060 Hz DX-KEY,drivesConnect Supply Voltage Vac P-07400-480 Vac ± 10%46060 HzTransfer parameter values of the DXE-EXT-SET module to the DE11.DE1… must be in STOP mode only, with supply voltage applied.2.Press the SET button for 2 seconds. The status LED will flash (green) 3 times for 2seconds.3.Steady green status LED indicates all parameters have been successfully transferredfrom the module to the DE1….4.The operating parameters will be used for Start/Run/Stop profiles in both forward andreverse directions.DE1Functionality–Mode 0Terminal AssignmentThe DE1 has ten (10) terminal assignment profiles. Mode 0 is default and is recommended for basic motor control consisting of a Start ramp, acceleration to motor synchronous speed, and a Stop ramp.Mode 0 terminal assignments are;∙Terminal 1 / digital input 1 FWD (forward)–START/RUN signal-forward∙Terminal 2 / digital input 2 REV (reverse)–START/RUN signal-reverse∙Terminal 3 / digital input 3 FF1 (fixed frequency 1)–not used∙Terminal 4 / digital/analog input 4 f-REF (frequency set point value)–connected to Terminal +10V to provide a reference signal to command the motor to synchronous speed.Application Note AP040101EN Variable Speed Starter:Reversing starter application Effective February2015DE1Functionality–Connection Diagram for a reversing starter applicationFigure 2 illustrates the connections required for operation of the DE1 in a reversing motor start configuration. Terminal 3 is not used in this type of configuration.∙When digital input 1 gets a signal, the DE1 will accelerate the motor in the forward direction with a ramp of 5 seconds (default value) to motor synchronous speed.∙The DE1 will operate at forward synchronous speed as long as digital input 1 remains signaled.∙When the signal is removed from digital input 1, the DE1 will decelerate the motor with a ramp time of 5 seconds (12Hz/second).∙When digital input 2 gets a signal, the DE1 will accelerate the motor in the reverse direction with a ramp of 5 seconds (default value) to motor synchronous speed.∙The DE1 will operate at reverse synchronous speed as long as digital input 2 remains signaled.∙When the signal is removed from digital input 2, the DE1 will decelerate the motor with a ramp time of 5 seconds (12Hz/second).Figure3illustrates the control signal logic.Figure 2: Connection Diagram Figure 3: Signal LogicApplication Note AP040101EN Variable Speed Starter:Reversing starter application Effective February2015Additional HelpIn the US or Canada:please contact the Technical Resource Center at 1-877-ETN-CAREor1-877-326-2273.All other supporting documentation is located on the Eaton web site atEaton1000 Eaton Boulevard Cleveland, OH 44122 USA © 2014EatonAll Rights ReservedPrinted in USAPublication No.AP040101EN April2014Eaton is a registered trademark of Eaton Corporation.All other trademarks are property of their respective owners。
3000变频说明书
前言
尊敬的用户：
前言
非常感谢您选用西驰 CFC 系列高性能高集成通用型变频器。 我们相信做出明智选择的您将与信赖西安西驰的所有用户一起见证精彩的改变，享 受西安西驰带给您的优质产品和服务。 CFC 系列变频器是高性能、多功能、高集成的通用型变频器，它采用模块化的功能设 计理念，可专为行业需求提供解决方案，并根据客户的要求进行二次开发。
最佳的冷却效果。卧式安装时，可能需要加额外的通风 装置。 ◆ 环境温度要求在-10～40°C 的范围内，如温度超过 40°C， 请取下上面面盖，如超过 50°C 需外部强迫散热或者降额 使用。建议用户不要在如此高温的环境中使用本产品， 因为这样将会极大降低产品的使用寿命。 ◆ 环境湿度要求低于 90%，无水珠凝结。 ◆ 安装在振动小于 0.5G 的场所，以防坠落损坏。不允许产 品遭受突然的撞击。
图 1-1 产品型号说明 1.3 设备铭牌说明
在产品箱体的右侧板下方，贴有标示产品型号及额定值的铭牌，铭牌内 容如图 1-2 所示
图 1-2 产品铭牌 1
产品使用手册
1.4 产品各部位名称说明
面盖固定插入孔 功率板连接端口 主控板 注塑机专用 信号接口板 面盖固定孔
输入铜排 主回路入口
下面盖安装孔
第四章 参数功能介绍 4.1 监控参数……………………………………………………… 30
I
产品使用手册
目录
4.2 系统参数 ……………………………………………………… 30 4.3 参数功能详细说明 ……………………………………………… 40 第五章 故障处理和维护 5.1 故障代码及对策………………………………………………… 66 5.2 异常现象及对策 ……………………………………………… 67 5.3 检查与维护注意事项…………………………………………… 68 5.3.1 检查与维护 …………………………………………………… 68 5.3.2 日常检查项目 ………………………………………………… 69 5.3.3 定期检查项目 ………………………………………………… 69 5.3.4 产品易损件的更换 ………………………………………… 70 5.3.5 产品的存贮 ‥……………………………………………… 71 5.3.6 产品的保修 ………………………………………………… 72 第六章 选配件 6.1 制动组件 ………………………………………………………… 73 6.2 远程操作适配器及延长电缆 ‥………………………………… 73 6.3 RS485 接口通讯与通讯协议 ………………………………………… 74 附录 1 RS485 通讯协议 ‥…………………………………………… 75 附录 2 供水附件的应用 ……………………………………………… 82 附录 3 产品保修卡 …………………………………………………… 86
格力特变频说明书
格力特变频说明书篇一：格力特变频说明书上海格立特电力电子有限公司系上海电器科学研究所（集团）有限公司下属子公司，2009年又成为国家中小型电机及系统工程技术研究中心、上海电机系统节能工程技术研究中心控制及系统集成产品制造中心。
篇二：格力特变频说明书安伟，致力成为变频器中的“戴尔”变频器行业专用，特价，维修，方案系统，咨询尽在ｈｔｔｐ；／／ｗｗｗ．ｙａｐｕｄａ．ｃｏｍ格立特变频器VF---10系列高性能高可靠性强功能操作简便第一章检查与安全注意事项第二章安装第三章键盘操作第四章试运行第五章功能参数一览表第六章功能参数说明第七章异常诊断第八章规范第九章外型及安装尺寸第十章检查与维护第十一章品质保证第十二章选配件第十三章ＲＳ－４８５串行通讯协议１３１５２３４９５３５５５７５９６０６１本使用说明书务必送交本公司产品的实际使用者。
使用本产品前，务请熟读本说明书，阅读后请妥善保管，这对以后的维护、保养及其它场合的使用会有益处。
如在使用过程中还存在解决不了的疑难问题，请随时联络本公司的各地经销商，或直接与本公司联系。
第一章检查与安全注意事项ＶＦｌ０系列变频器在出厂之前均已经过测试和品质检验。
在购买后，拆箱之前请检查产品的包装是否因运输不慎而造成损伤，产品的规格、型号是否与订购之机种相符。
如有问题，请联络供货厂商。
１１拆箱之后检查检查内部含ＶＦｌ０本机、使用说明书一本、保修卡一张。
检查变频调速器侧面的铭牌，以确定在您手上的产品就是所订购之产品铭牌说明：以７５ＫＷ３８０Ｖ为例ＴＹＰＥＶＦｌ０－７Ｒ５Ｇ３ＳＯＵＲＣＥ３Φ３８０Ｖ５０／６０ＨｚＯＵＴＰＵＴ７５ＫＷ１６ＡＯ５－４００ＨｚＳＥＲＮＯ变频器型号输入电源规格输出功率规格生产序号型号说明ＶＦ１０７Ｒ５Ｇ３Ｂ产品代码设计序号输入电压等级１：单相１１０Ｖ；２：单相２２０ｖ３：三相３８０Ｖ；６：三相６６０ＶＧ泛用型Ｐ平方转矩型额定输出容量例：７Ｒ５：７５ＫＷ；１１０：１１０ＫＷＢ为带制动功能，作为用户选件Ｃ为带延长线１２安全注意事项绝不可将交流电源接至变频器输出端Ｕ、Ｖ、Ｗ等端子。
WEG CFW300变频电机驱动说明书
CFW300Variable Frequency DriveMotors | Automation | Energy | Transmission & Distribution | CoatingsUS.CFW300(03/2017)The CFW300 variable frequency drive is a high-performance VFD for three-phase induction motors. It is ideal for applications on machines or equipment that require precise control with easy setup and operation.The CFW300 features a compact size with contactor-style electrical connections (top in / bottom out). The VFD’s performance can be scaled to match the application by selecting WEG vector control (VVW) or scalar control (V/F). The CFW300 includes built-in operator interface (HMI) and SoftPL C with free WPS programming software for custom tailored control schemes. A variety of plug-in option modules for additional I/O and communications protocols may be added to provide extended capabilities, making the CFW300 a flexible and cost effective solution for your variable speed requirements.• Centrifugal pumps • Fans / Blowers • Blenders / Mixers • Centrifuges •Compressors• Conveyors • Roller Tables • Granulators• Commercial Dryers •Rotary FiltersApplications 2 | 1-800-ASK-4WEGData is subject to change without notice.Variable Frequency DrivesCFW300FlexibilitySlot forCommunicationModulesTwo ExpansionSlots for OptionModulesSlot forInput / OutputModulesRemote Keypad (HMI)(CFW300-KHMIR)Flash Memory Module(CFW300-MMF)Download original parameter values tomultiple other CFW300 VFDs without theneed to apply power to the drives.Conformal Coated Circuit BoardsClass 3C2 coating for all circuit boards as standard providesgreater protection against airborne contaminants. Meets IEC60721-3-3 requirements for corrosive environmentsRFI Filter(CFW300-KFA orCFW300-KFB)Category C2 or C3 Reduceselectromagnetic interferenceEasy Cooling FanRemoval andReplacementWEG Automation - Products and Solutions | 3 Data is subject to change without notice.Variable Frequency DrivesCFW300CFW300 Catalog Number Sequence A S 2NB 20S = Single Phase B = 1 or 3 Phase T = Three PhaseSupply Voltage2 = 200-240 VacSupply Phases1 = 110-127 Vac 07P3 = 7.3 Amps 10P0 = 10.0 Amps 15P2 = 15.2 Amps06P0 = 6.0 Amps 04P2 = 4.2 Amps Rated CurrentDB = Dynamic Brake 01P6 = 1.6 Amps 20 = IP20 (Std.)02P6 = 2.6 Amps CFW30002P6FrameOptionsA or BNB = No Brake4 | 1-800-ASK-4WEGData is subject to change without notice.Variable Frequency DrivesCFW300IP20 EnclosureMotor VoltageMotor HP 1Drive Output Amps 2Catalog NumberBraking TransistorFrame SizeDimensions (in.)HxWxDApprox. Weight Lbs. (kG)List PriceMultiplier Symbol230 V a c / 3 P h a s eInput Power Supply: Single-Phase 110-127 Vac 1/4 or 1/3 1.6CFW300A01P6S1NB20No A 6.3 x 2.8 x 5.9 2.0 (0.9) $361 V1 3/4 2.6CFW300A02P6S1NB20No A 6.3 x 2.8 x 5.9 2.0 (0.9) $394 V11 4.2CFW300A04P2S1NB20No A 6.3 x 2.8 x 5.9 2.0 (0.9) $420 V12 6.0CFW300A06P0S1NB20No A 6.3 x 2.8 x 5.9 2.0 (0.9) $507 V1Input Power Supply: Single-Phase 200-240 Vac1/4 or 1/3 1.6CFW300A01P6S2NB20No A 6.3 x 2.8 x 5.9 2.0 (0.9) $323 V1 3/42.6CFW300A02P6S2NB20No A 6.3 x 2.8 x 5.9 2.0 (0.9) $348 V11 4.2CFW300A04P2S2NB20No A 6.3 x 2.8 x 5.9 2.0 (0.9) $371 V12 6.0CFW300A06P0S2NB20No A 6.3 x 2.8 x 5.9 2.0 (0.9) $461 V127.3CFW300A07P3S2NB20No A 6.3 x 2.8 x 5.9 2.0 (0.9) $543 V1310.0CFW300B10P0B2DB20 3Yes B 8.1 x 2.8 x 6.33.0 (1.4) $648 V1Input Power Supply: Three-Phase 200-240 Vac1/4 or 1/3 1.6CFW300A01P6T2NB20No A 6.3 x 2.8 x 5.9 2.0 (0.9) $343 V1 3/4 2.6CFW300A02P6T2NB20No A 6.3 x 2.8 x 5.9 2.0 (0.9) $376 V11 4.2CFW300A04P2T2NB20No A 6.3 x 2.8 x 5.9 2.0 (0.9) $399 V12 6.0CFW300A06P0T2NB20No A 6.3 x 2.8 x 5.9 2.0 (0.9) $484 V127.3CFW300A07P3T2NB20No A 6.3 x 2.8 x 5.9 2.0 (0.9) $571 V1310.0CFW300B10P0B2DB20 3Yes B 8.1 x 2.8 x 6.3 3.0 (1.4) $648 V1515.2CFW300B15P2T2DB20YesB8.1 x 2.8 x 6.33.0 (1.4)$792V1Notes:1) “HP” rating based on “average FLA values”. Use as a guide only.2) Motor FLA may vary with speed and manufacturer. ALWAYS compare motor FLA to Nominal AMPS of drive. 3) CFW300B10P0B2DB20 is capable of Single-Phase input without derating. For other technical data please refer to WEG product manual.Options and AccessoriesTypeCATALOG NUMBER DescriptionApprox. Wt. (lbs.) List Price Multiplier Symbol I/O 1CFW300-IOAR I/O Expansion Module; 1 AI, 1 AO, 3 DOR, +10vdc0.2 $141 V1I/O 1CFW300-IODR I/O Expansion Module; 4 DI, 3 DOR0.2 $108 V1I/O 1CFW300-IOAENC I/O and Encoder Module; 1 AI, 2 AO, +10vdc, 1 Incremental Encoder Input, +5vdc 0.2 $143 V1I/O 1CFW300-IOADR I/O Expansion Module; 1 NTC Sensor Input, 3 DOR0.2 $207 V1RS485 Card CFW300-CRS485RS-485 Module; 1 RS-485 Input (Modbus-RTU), 1 Mini USB for Remote Keypad 0.2 $82 V1USB Card CFW300-CUSB USB Communication Module w/ 2-meter Cable; 1 Mini USB 0.2 $87 V1RS232 Card CFW300-CRS232RS-232 Communication Module (Modbus-RTU); 1 RS2320.2 $82 V1CANopen Card CFW300-CCAN CANopen/DeviceNet Comm. Module; 1 CAN/DeviceNet, External 24vdc Power 0.2 $100 V1Profibus DP Card CFW300-CPDP Profibus DP Communication Module; 1 Profibus DP 9-Pin Connector 0.2 $294 V1Remote Keypad CFW300-KHMIR Remote Keypad; Includes CFW300-CRS485 and 3-meter Cable 0.4 $256 V1Flash Memory Module CFW300-MMF Flash Memory Module for saving program and parameters to/from drive.0.2 $210 V1RFI Filter Kit – Fr. A CFW300-KFA CFW300 RFI Filter Kit – Frame Size A - SINGLE PHASE INPUT MODELS ONLY 0.3 $90 V1RFI Filter Kit – Fr. BCFW300-KFBCFW300 RFI Filter Kit – Frame Size B - SINGLE PHASE INPUT MODELS ONLY0.3$105V1Notes:1) Option card I/O is in addition the standard CFW300 I/O which includes: 4 DI, 1 AI, 1 DOR.WEG Automation - Products and Solutions | 5Data is subject to change without notice.Variable Frequency DrivesCFW300Communications and I/OCFW 300 Option Modules Option Card and I/O TableDI AI AODOR NTCUSBCANRS232RS485ProfiBusEncoder10vdc24vdcStandard I/O (incl.)411CFW300-IOAR 1131CFW300-IODR 43CFW300-IOAENC 2211CFW300-IOADR 31CFW300-CRS48511CFW300-CUSB 1CFW300-CRS2321CFW300-CCAN 1Ext.CFW300-CPDP1DimensionsFrame Size IP20Heightin. (mm)Width in. (mm)Depth in. (mm)Weight Lbs. (kG)A (w/o RFI) 6.3 (157.9) 2.8 (70.0) 5.9 (148.4) 2.0 (0.9)A (w/RFI)7.8 (196.0) 2.8 (70.0)7.5 (190.1) 2.9 (1.3)B (w/o RFI)8.1 (198.9) 2.8 (70.0) 6.3 (158.4) 3.0 (1.4)B (w/ RFI)9.4 (237.0)2.8 (70.0)7.9 (200.1)4.0 (1.8)Vista da base de fixação Vista frontal Vista lateralPHLP Rear view Front view Side View HW D 6 | 1-800-ASK-4WEGData is subject to change without notice.Variable Frequency DrivesCFW300Technical DataPower SupplyVoltage Single Phase110-127 Vac (+10%, -15%)Single Phase or Three Phase 200-240 Vac (+10%, -15%)Frequency50 / 60Hz +/- 2Hz Output Voltage 0-230 Vac Three Phase Frequency 0-400 Hz, 0.1Hz Resolution ControlControl ModesVolts per Hertz (Scalar)Sensorless Voltage VectorSinusoidal PWM (Space Vector Modulation)Switching Frequency 2.5, 5, 10 or 15kHz Frequency Range 0-400 HzOverload Capacity150% for 60 seconds, repeatable every 10 min.Control Inputs 4 programmable isolated digital inputs, NPN or 24Vdc logic (PNP)1 programmable differential analog input; programmable for current or voltage Control Outputs 1 programmable relay output: One NO/NC (Form C) 250 Vac / 0.5 A Communication Field Bus Optional modules for RS-485, RS-232, CANopen, DeviceNet, Profibus-DP, USB SafetyProtectionsMotor over current DC link over voltage Motor overloadDC link under voltage Output phase-to-phase short circuit Drive over temperature Output phase-to-ground short circuit External faultProgramming errorEnclosure Degree of Protection IP20Mounting Surface mounting with screws or DIN rail mountingAmbientTemperature 14 - 122°F (50°C), up to 140°F (60°C) with 2% / 1.8°F (1°C) output current derating Humidity 5-95% Non CondensingAltitude0-3300 ft (1000m)Up to 13,200 ft (4000m) with 1% / 330ft (100m) output current deratingRegulatory Con-formanceEMC Directive 89 / 336 / EEC Electromagnetic compatibility – Industrial Environment EMC Emission and Immunity with optional filter ENC61800-2, 3, 5-1 ENC61800-4-2, 3, 4, 5, 6LVD 73/23/EEC Low Voltage Directive UL 508C, UL 840, UL 50Electrical Equipment standardsSpecial FunctionsLinear and “S” ramp accel and decel, local/remote control, FWD/REV selection, DC braking, manual and auto torque boost, motor slip compensation, electronic pot, two skip frequencies, maximum and minimum adjustable frequency limits, adjustable output cur-rentKeypad4 digit LCD display and 4 keysReadouts for: output frequency (Hz), output current (A), output voltage (V), motor torque (%) in vector mode, DC bus voltage (V), val-ue proportional to frequency (Ex.: RPM), fault and status messagesWEG Automation - Products and Solutions | 7Data is subject to change without notice.Variable Frequency DrivesCFW300。
变频电机使用说明书
饪霖电机YVF变频调速电动机使用维护手册Usage Handbook注童事项使用前请务必仔细阅渎手册，理解各项容，以便正确地安装、连接、使用和维护本手册应妥善保管在实际安装及使用者手中刖百首先感您购买本公司的YVF系列变频调速电动机，谓在使用前仔细阅读本手册的各项容，以保证电机的正确使用，不正确的使用将造成不正常的运行，引起故障或降低使用寿命。
产品介绍WF系列变频调速电动机是在Y2系列电机基础上更新设计的，可广泛使用于各种机械领域，且符合国家和企业的相关技术标准，与国外同类产品水平相当。
到货检查收到您订购的产品后，谓开箱检査以下各项，如发现产品有任何问题或不符合您的订购要求，谓您与本公司联系。
1 •请核对产品的铭牌，确认您订购的规格2•请检査外观有无在运输中受损3•除电机本体及使用说明书外，确认您所订购的附件有无完整4.检査零部件的装配应良好，紧固件应无松动。
搬运和存储4.1本电机产品为精密制造零件，搬运时只允许在其规格的运输吊攀上进行起吊（小规格可以用手搬运），必须轻吊、轻拿、轻放、防止碰撞。
不得在搬运过程中抱持轴承头部。
且在安装调试中对轴承头部要妥善防护，否则将导致运转精度失准。
4.2电机的存储场所应符合以下条件:(D周围温度：・15度——+40度(2)相对湿度：5 —80%(3)周围环境：不受直晒，周围介质必须无灰尘、腐蚀性气体、可燃气体、油券、蒸汽、滴水和農动。
并尽■避免含盐较多的场合。
不得放在会发生温度急剧变化而结18和冰冻的地方。
(4)电机不可直接或倒■放在地面上，应放鬣在合适的台架上，且应放平稳。
(5)如周围环境恶劣则应用塑料薄膜包好进行保管，可在塑料薄膜中加干燥剂防止受潮。
如要长期保存，则应严格封装。
使用环境(1)海拔：1000米以下(2)环境温度：・15度——+40度(3)电动机安装场所必须干燥，清洁。
具有良好的通风不受直晒，周围介质必须、无灰尘、腐蚀性气体、可燃气体、油雰、蒸汽、滴水和農动。
变频电机和齿轮电机参数设置指南说明书
VARMECA 10Variable speed motors and geared motorse nLEROY-SOMER Ref. 3264 - 4.33/b -1.00PARAMETER-SETTING MANUALVARMECA 10Variable speed motors and geared motorsNOTELEROY-SOMER reserves the right to modify the characteristics of its products at any time in order to incorporate the latest technological developments. The information contained in this document may therefore be changed without notice.LEROY-SOMER gives no contractual guarantee whatsoever concerning the information published in this document and cannot be held responsible for any errors it may contain, nor for any damage resulting from its use.CAUTIONIt is imperative that the equipment is supplied via an isolating device and a circuit-breaking device (power contactor) which can be controlled by an external safety system (emergency stop, fault detector).The VARMECA 10 motor is fitted with safety devices which, in the event of a fault, control stopping and thus stop the motor. The motor itself can become jammed for mechanical reasons. Voltage fluctuations, and in particular power cuts, may also cause the motor to stop.The removal of the causes of the shutdown can lead to restarting, which may be dangerous for certain machines or installations. In such cases, it is essential that the user takes appropriate precautions against the motor restarting after an unscheduled stop. VARMECA 10 is a component designed to be integrated in an installation or an electrical machine. It is the responsibility of the user to take all necessary precautions to ensure that the system complies with current standards.For safety reasons, LEROY-SOMER prohibits the use of VARMECA 10 for lifting applications.LEROY-SOMER declines all responsibility in the event of the above recommendations not being observed.PARAMETER-SETTING MANUALVARMECA 10Variable speed motors and geared motorsLEROY-SOMER Ref. 3264 - 4.33/b -1.00to material or physical damage as well as constituting a fire hazard.1 - GeneralDepending on their degree of protection, VARMECA 10 motors may contain moving parts, as well as hot surfaces, during operation.Unjustified removal of protections, incorrect use, faulty installation or inappropriate operation could represent a serious risk to personnel, animals and equipment.For further information, consult the manual.All work relating to transportation, installation, commissioning and maintenance must be performed by experienced, qualified personnel (see IEC 364 or CENELEC HD 384, or DIN VDE 0100 and national specifications for installation and accident prevention).In these basic safety instructions, qualified personnel means persons competent to install, mount, commission and operate the product and possessing the relevant qualifications.2 - UseVARMECA 10 motors are components designed for integration in installations or electrical machines.When integrated in a machine, commissioning must not take place until it has been verified that the machine conforms with directive 89/392/EEC (Machinery Directive).It is also necessary to comply with standard EN 60204, which stipulates in particular that electrical actuators (which include VARMECA 10) cannot be regarded as circuit-breaking devices and certainly not as isolating switches. Commissioning can take place only if the requirements of the Electromagnetic Compatibility Directive (89/336/EEC, modified by 92/31/EEC) are met.VARMECA 10 motors meet the requirements of the Low Voltage Directive 73/23/EEC, modified by 93/68/EEC. The harmonised standards of the DIN VDE 0160 series in connection with standard VDE 0660, part 500 and EN 60146/ VDE 0558 are also applicable.The technical characteristics and instructions concerning the connection conditions specified on the nameplate and in the documentation provided must be observed without fail.3 - Transportation, storageAll instructions concerning transportation, storage and correct handling must be observed.The climatic conditions specified in the technical manual must be observed.4 - InstallationThe installation and cooling of equipment must comply with the specifications in the manual supplied with the product. VARMECA 10 motors must be protected against excessive stress. In particular, there must be no damage to parts and/or modification of the clearance between components during transportation and handling. Avoid touching the electronic components and contact parts.VARMECA 10 motors contain parts which are sensitive to electrostatic stress and may be easily damaged if handled incorrectly. Electrical components must not be exposed to mechanical damage or destruction (risks to health!).5 - Electrical connectionWhen work is performed on VARMECA 10 motors which are powered up, national accident prevention specifications must be respected.The electrical installation must comply with the relevant specifications (for example conductor cross-sections, protection via fused circuit-breaker, connection of protective conductor). More detailed information is given in the manual. Instructions for an installation which meets the requirements for electromagnetic compatibility, such as screening, earthing, presence of filters and correct insertion of cables and conductors, are given in the documentation supplied with the VARMECA 10. These instructions must be followed in all cases, even if the VARMECA 10 carries the CE mark. Adherence to the limits given in the EMC legislation is the responsibility of the manufacturer of the installation or the machine.6 - OperationInstallations incorporating VARMECA 10 motors must be fitted with additional protection and monitoring devices as laid down in the current relevant safety regulations : law on technical equipment, accident prevention regulations, etc. Modification of VARMECA 10 motors using control software is permitted.Active parts of the device and live power connections must not be touched immediately after the VARMECA 10 is powered down, as the capacitors may still be charged. In view of this, the warnings fixed to VARMECA 10 motors must be observed.During operation, all doors and protective devices must remain closed.7 - Servicing and maintenanceRefer to the manufacturer’s documentation.SAFETY AND OPERATING INSTRUCTIONS FOR ELECTRICAL ACTUATORS(In accordance with the low voltage directive 73/23/EEC modified by 93/68/EEC)enLEROY-SOMER Ref. 3264 - 4.33/b -1.00PARAMETER-SETTING MANUALVARMECA 10Variable speed motors and geared motorsCONTENTS1 - GENERAL INFORMATION (30)1.1 - Operating principle (30)1.2 - General characteristics (30)1.3 - Weight and dimensions of the CDC-VMA console (30)1.4 - Wiring diagrams (31)2 - COMMISSIONING THE CDC-VMA CONSOLE (37)2.1 - Installation (37)2.2 - Presentation of the keypad (37)2.3 - Read mode (38)2.4 - Parameter-setting mode (38)2.5 - The VARMECA 10 parameters (39)3 - COMMISSIONING THE PEGASE VMA 10 PC PARAMETER-SETTING SOFTWARE (41)3.1 - Connection (41)3.2 - Installing the software (41)3.3 - Use (42)3.4 - The VARMECA 10 parameters (43)4 - TROUBLESHOOTING (46)5 - SUMMARY OF SETTINGS (47)PARAMETER-SETTING MANUALVARMECA 10Variable speed motors and geared motorsGENERAL INFORMATIONLEROY-SOMER Ref. 3264 - 4.33/b -1.001 - GENERAL INFORMATION1.1 - Operating principleThis manual describes access to the parameter settings of the VARMECA 10 (VMA 11 - 12 - 13 - 14) range, using a CDC-VMA console or PEGASE VMA 10 PC software.Combined with the VARMECA 10, these tools can simplify programming, diagnostics and displaying parameters.1.2 - General characteristics1.2.1 - "CDC-VMA console" OPTION CONTENTS OF THE KIT:- 1 power supply unit to connect to single phase mainssupply 230 V - 50/60 Hz.- 1 connection cable (length = 1.5 m) to connect to theVARMECA 10.- 1 console with digital LCD display - 2 lines of 16 characters. - 1 parameter-setting manual.1.2.2 - "PEGASE VMA 10 programmingsoftware" OPTIONCONTENTS OF THE KIT:- 1 connection cable (length = 3m) to connect to theVARMECA 10,- 3 disks for loading the software onto a PC (or 1 CD-ROM). - 1 parameter-setting manual.MINIMUM PC CONFIGURATION:- Pentium 100 MHz.- 8 Mb of RAM.- WINDOWS 95 or 98.1.3 - Weight and dimensions of the CDC-VMA consoleSee the following diagram.PARAMETER-SETTING MANUALVARMECA 10Variable speed motors and geared motorsGENERAL INFORMATIONLEROY-SOMER Ref. 3264 - 4.33/b -1.001.4 - Wiring diagram1.4.1 - Standard configuration (factory setting)e nLEROY-SOMER Ref. 3264 - 4.33/b -1.00PARAMETER-SETTING MANUALVARMECA 10Variable speed motors and geared motorsGENERAL INFORMATION1.4.2 - Configuration option 1: 2 preset speeds - 2 operating directionsAssociated parameter settingPARAMETER-SETTING MANUALVARMECA 10Variable speed motors and geared motorsGENERAL INFORMATIONLEROY-SOMER Ref. 3264 - 4.33/b -1.001.4.3 - Configuration option 2: analogue reference and 3 preset speeds - 1 operating directionAssociated parameter settinge nLEROY-SOMER Ref. 3264 - 4.33/b -1.00PARAMETER-SETTING MANUALVARMECA 10Variable speed motors and geared motorsGENERAL INFORMATION1.4.4 - Configuration option 3: correction of an external reference with the speed control button - 2operating directions - enabling/disabling the control buttonAssociated parameter settingPARAMETER-SETTING MANUALVARMECA 10Variable speed motors and geared motorsGENERAL INFORMATIONLEROY-SOMER Ref. 3264 - 4.33/b -1.001.4.5 - Configuration option 4: 2 preset speeds fixed or proportional to the reference - 1 operatingdirectione nLEROY-SOMER Ref. 3264 - 4.33/b -1.00PARAMETER-SETTING MANUALVARMECA 10Variable speed motors and geared motorsGENERAL INFORMATION1.4.6 - Standard configuration: regulation with the integrated PI loop - PI reference using the localbutton or external reference - 2 operating directions2 - COMMISSIONING THE CDC-VMACONSOLE2.1 - Installation2.1.1 - Checks on receiptWhen you receive your CDC-VMA console, make sure that it has not been damaged during transport. If necessary, report any damage to the delivery company.THE CONSOLE KIT COMPRISES:- the CDC-VMA console- 1 connection cable (length = 1.5 m) with RS 232 socket. - 1 power supply unit 230 V single phase - 50/60 Hz,- 1 parameter-setting manual.2.1.2 - Connection- Open the front cover of the VARMECA 10.- Connect the 20-pin socket on the end of the cable to the connector on the VARMECA 10 rolled cable.- The RS 232 socket on the cable is connected to theconsole socket.2.2 - Presentation of the keypade n2.3 - Read mode - Power up the VARMECA 10.- Connect the 230 V socket on the console power supply unit.- On power-up, the console display is positioned on the 1st parameter PO1 FMIN.The 1st line of the display unit indicates the parameter designation.The 2nd line indicates the parameter value and unit.Theto P29.The2.4 - Parameter-setting modekeys to select theparameter.Themodified, flash.keys.As soon as the value differs from the stored value, the MEM? message appears.When the desired setting value has been reached, it can bestored using theThe MEM? indication disappears. key is used to quit the parameter-setting mode.2.5 - The VARMECA 10 parametersList and description of the parameters which can be accessed by the CDC-VMA consoleDisplay Description Adjustment range inincrements of 1Factory setting P01 F min minimum operating frequency 6 to 30 Hz12 HzP02 REF 0 V - 4 mA calibration of the min. reference0 V or 4 mA0 to 30 Hz12 HzP03 F max maximum operating frequency(according to mini DIP K2 position)32 to 220 Hz50 or 80 HzP04 REF 10 V - 20 mA calibration of the max. reference 32 to 220 Hz50 or 80 HzP05 ACCEL.acceleration rampramp value to pass from 0 to 50 Hz0 to 20 s 3 sP06 DECEL.deceleration rampramp value to pass from 50 to 0 Hz0 to 20 s 3 sP07 STOP MODE stop mode0 = freewheel stop1 = stop according to ramp0 or 11P08 UN MOT (1)voltage applied to the motor from the base frequency(percentage of mains voltage: base 400 V)0 to 100 %100 %P09 FN MOT(1)motor base frequency50 to 150 Hz50 HzP10 U / F (1)selection of voltage/frequency ratio0 = fixed U / Fthe P08 voltage will be applied at the P08 frequency point1 = dynamic U / Fthe voltage adapts automatically to the motor load0 or 1from 0.25 to 1.1 kW1from 1.5 to 7.5 kWP11 BOOST (1)value of voltage applied in low frequencies(percentage of mains voltage)0 to 40 %adapted to themotor according tothe powerP12 OVER BOOST (1)value of voltage during starting phase(percentage of mains voltage)0 to 100 %adapted to themotor according tothe powerP13 F PWM switching frequency0 = 4 kHz1 = 6 kHz2 = 8 kHz3 = 11 kHz0 to 33from 0.25 to 2.2 kW2from 3 to 4kWP14 CONFIG terminal block configuration0 = standard1 = option 1 -2 preset speeds and 2 operatingdirections2 = option 2 - analogue reference and3 presetspeeds - 1 operating direction3 = option 3 - correction of an external referencewith the local button - 2 operating directions4 = option 4 - 2 preset speeds proportional to thereference - 1 operating direction0 to 40P15 VP1-1preset speed 1 in options 1 and 4 6 to 220 Hz50 HzP16 VP2-1 VP1-2preset speed 2 in options 1 and 4 or preset speed 1 inoption 2 6 to 220 Hz60 Hz P17 VP2-2preset speed 2 in option 2 6 to 220 Hz40 Hz P18 VP3-2preset speed 3 in option 2 6 to 220 Hz70 Hz(1) : the voltage/frequency ratio is illustrated at the end of the tableRepresentation of voltage/frequency ratioDisplayDescriptionAdjustment range in increments of 1Factory settingP19 ROTATIONchoice of directions of rotation in the con figuration option 20 = clockwise 1 = anti-clockwise0 to 1P20 SELECT 3terminal 3 assignment0 = speed image output 1 = PI feedback input 0 to 10P21 PI KPRO proportional gain of the PI loop 1 to 10010P22 PI KINT integral gain of the PI loop 1 to 10010P23 F_MOT motor operating frequency0 to 220 Hz P24 I_MOTmotor current (in tenths of an ampere) A/100 to 150% of I nP25 FAULT last fault in memory fault code0 = no fault1 = motor overheating2 = overvoltage3 = overcurrent4 = locked rotor5 = DC bus undervoltage6 = EEPROM7 = serial link8 = power module fault0 to 80P26 STOP Fmin enabling of the STOP USING REFERENCE function0 = disabled 1 = enabledwhen the reference is less than Fmin, it forces the motor to stop0 to 10P27 LOG CDC-VMAconsole software version P28 CAL MOT VARMECA 10 power rating setting code of ratings0 = 0.37 kW 1 = 0.55 kW 2 = 0.75 kW 3 = 0.9 kW 4 = 1.1 kW 5 = 1.5 kW 6 = 1.8 kW 7 = 2.2 kW 8 = 3 kW 9 = 4 kW 10 = 0.25 kW 11 = test12 = special 1.1 kW 13 = 5.5 kW 14 = 7.5 kW 0 to 14adapted to the motor according tothe powerP29access codereserved LEROY -SOMERP123 - COMMISSIONING THE PEGASEVMA 10 PC PARAMETER-SETTING SOFTWARE3.1 - Connection3.1.1 - Checks on receiptWhen you receive your parameter-setting kit, make sure that it has not been damaged during transport. If necessary, report any damage to the delivery company .THE KIT COMPRISES:- 1 connection cable (length = 3m) with RS 232 socket.- 3 disks or 1 CD-ROM,- 1 parameter-setting manual.3.1.2 - Connection- The RS 232 socket on the cable is connected to the RS232 socket on the PC.- The 20-pin socket on the cable connects to the connector on the VARMECA 10 rolled cable.3.2 - Software installation- Start up your PC.- Insert disk n˚1 (or the CD ROM).- Open the "install" file.- Follow the instructions given on the screen, in particular those relating to changing disks.- When the "Installation complete" message appears, click on OK - The PEGASE VMA software is installed.20-pinsocket P E G A S E3.3 - Use- Double-click on the icon- The first window appears.3.3.1 - Detail of the 1st window3.3.2 - Detail of the 2nd window3.3.3 - Detail of the 3rd window (access to parameters)3.4 - The VARMECA 10 parametersDescription of parameters which can be accessed from the PC.Parameter modifications must be made whilst the VARMECA 10 is powered up,but in the "stop" position (run command disabled)DisplayDescriptionAdjustment range in increments of 1Factory setting F max maximum operating frequency (according to mini DIP K2 position)32 to 220 Hz 50 or 80 Hz F min minimum operating frequency6 to 30 Hz 12 HzACCEL acceleration ramp value to pass from 0 to 50 Hz 0 to 20 s 3 s DECEL deceleration ramp value to pass from 50 to 0 Hz 0 to 20 s 3 s U n mot (1) voltage applied to the motor at base frequency (percentage of mains voltage: base 400 V)0 to 100 %100 %F n mot (1) base frequency of motor50 to 150 Hz 50 Hz BOOST (1)value of voltage applied in low frequencies (percentage of mains voltage)0 to 40 %adapted to the motor according tothe power OVERBOOST (1)value of voltage applied during starting phase (percentage of mains voltage)0 to 100 %adapted to the motor according tothe power(1) : the voltage/frequency ratio is illustrated at the end of the tablee nDisplay Description Adjustment range inincrements of 1Factory settingMax. reference point calibration of the max. reference10 V or 20 mA32 to 220 Hz50 or 80 HzMin. reference point calibration of the min. reference0 V or 4 mA0 to 30 Hz12 Hz Stop mode choice of stop mode ramp or freewheel rampauto U / F (1)selection of voltage/frequency ratioNO = fixed U / F ratiovoltage U n mot is applied at the frequency point F n motYES = dynamic U / F ratiothe voltage adapts automatically to the motor loadYES or NONO from 0.25 to 1.1kWYES from 1.5 to 7.5kWF switching switching frequency4, 6 , 8, 11 kHz11 kHz from 0.25 to 2.2 kW 8 kHz from 3 to 4kWTerminal block configuration choice of terminal block configurationoption 1 = 2 operating directions, 2 preset speedsoption 2 = 1 operating direction, 3 preset speeds +referenceoption 3 = correction of an external reference usingthe local buttonoption 4 = 2 preset speeds proportional to thereferencestandard, option 1,option 2, option 3,option 4standardVP1 option 1-4preset speed 1 in configuration options 1 and 40 to 220 Hz50 HzVP2 option 1-4 VP1 option 2preset speed 2 in configuration options 1 and 4or preset speed 1 in configuration option 20 to 220 Hz60VP2 option 2preset speed 2 in configuration option 20 to 220 Hz40 Hz VP3 option 2preset speed 3 in configuration option 20 to 220 Hz70 HzTerminal N˚3 assignment choice of terminal n˚3 assignmentspeed output = analogue output image of the0 - +10 V frequency0 V = stop+10 V = max. frequencyPI input = analogue input 0 to +10 V for the PIfeedbackspeed outputorPI inputspeed outputPI : K proportional PI loop proportional gain setting 1 to 10010 PI : K integral PI loop integral gain setting 1 to 10010Stop by reference enabling of stop by referenceYES = when the reference is less than the minimumfrequency, it forces the motor to stopNO = when the reference is less than the minimumfrequency, the motor operates at the minimumfrequencyYES, NO NO(1) : the voltage/frequency ratio is illustrated at the end of the tableRepresentation of voltage/frequency ratioDisplayDescriptionAdjustment range inincrements of 1Factory settingF mot motor frequency reading0 to 220 Hz readingV bus voltage of the speed controller DC busreading from 0 to 800 V Statusspeed controller statusstop or run Fault speed controller fault indicationPOSSIBLE INDICATIONS:no fault motor overheating overvoltageovercurrent locked rotor bus undervoltageEEPROM serial link module faultNO FAULTVmains V bus 2---------------=OverboostTROUBLESHOOTING 4 - TROUBLESHOOTINGFaults are indicated on the CDC-VMA console by a code from0 to 8.With the PEGASE VMA 10 software the faults are indicatedclearly in the fault window.The table below can be used to analyse faults and specifiesany checks which should be performed.Fault code on CDC-VMA Indication of fault onPEGASE Checks to make, possible causes0NO FAULT1MOTOROVERHEATINGRed LED illuminatedoverheating fault I2t- check if the motor is overloaded(orange LED illuminated)- check the set rating and the motor power- make sure that the boost adjustment (P11) has not been modified2OVERVOLTAGERed LED flashing- check the mains supply voltage- check that the deceleration ramp is long enough for applications with high inertia3OVERCURRENTRed LED illuminated- check that there is no short circuit occurring from a motor winding or on theconnections- check the motor insulation- check that the deceleration ramp is long enough for applications with high inertia- check the set rating and the motor power- internal product fault4LOCKED ROTORRed LED illuminated- check if the motor is overloaded or has stalled (green LED flashing)5BUS UNDERVOLTAGERed LED flashing- check the mains supply voltage6EEPROMRed LED illuminated - make sure that the VARMECA 10 is not affected by interference - internal product fault7SERIAL LINKRed LED illuminated- communication fault between the EEPROM and the controller - product fault8MODULE FAULTRed LED illuminated - very sudden overcurrent (possible causes: see OVERCURRENT fault)- IGBT power module overheating. Check that the unit is not operating at an ambient temperature which is too high- IGBT power module fault. Internal product faultFAULTS CAN ONLY BE CLEARED BY SWITCHING OFF THE VARMECA 10.Fault specific to the use of the CDC-VMA consoleCONSOLE LINK FAULT - Check the connection cable.- Check that the VARMECA 10 is correctly supplied.Fault specific to the use of the software PEGASE VMA 10COMMUNICATION PROBLEM WITH THE VARMECA 10 - Check the connection cable.- Check that the VARMECA 10 is correctly supplied.- Check that the serial port is correctly configured.SUMMARY OF SETTINGS5 - SUMMARY OF SETTINGSThe table below can be used to note the settings entered inthe VARMECA 10 in order to keep a record should areplacement product be needed.Settings made using the CDC-VMA consoleSettings made using the PEGASE VMA 10 software Parameters Value setP01 F MIN P02 REF 0 V -4 mA P03 F MAX P04 REF 10 V - 20 mA P05 ACCEL P06 DECEL.P07 STOP MODE P08 Un MOT P09 Fn MOT P10 U / F P11 BOOST P12 OVERBOOST P13 F PWM P14 CONFIG Parameters Value setP15 VP1-1P16 VP2-1 VP1-2P17 VP2-2P18 VP3-2P19 ROTATION P20 SELECT 3P21 PI K PRO P22 PI K INT P23 F MOT P24 I MOT P25 FAULT P26 STOP Fmin P27 LOG CDC-VMA P28 CAL MOT。
2HP-5HP 变频电机维修手册说明书
Fig. 2At least 100MΩ when measured with a 500V DC meager between the motor coil and case at normal temperature and humidity after motor hasNormal function when a 1500V, 50/60Hz current is applied between the motor coil and case for 1 minute at normal temperature and humidityT) should be no more than 60°C (no more than 45°Cfor motors with fans) when measured by the prescribedThe warranty period for the new Products shall be 18 months after the shipment of the Products from the seller’s works or 12 months from the Products coming into operation,In the event that any problem or damage to the Product arises during the “Warranty Period” from defects in the Product whenever the Product is properly installed and com-bined with the Buyer’s equipment or machines, maintained as specified in the maintenance manual, and properly operated under the conditions described in the catalog or as otherwise agree upon in writing between the Seller and the Buyer or its customers; the Seller will provide, at its sole discretion, appropriate repair or replacement of the Prod-However, if the Product is installed or integrated into the Buyer’s equipment or machines, the Seller shall not reimburse the cost of: removal or re-installation of the Product orinstallation, connection, combination or integration of the Product in or to the other equipment or machine that is rendered by any person or entity other than the Seller ;insufficient maintenance or improper operation by the Buyer or its customers, such that the Product is not maintained in accordance with the maintenance manual pro-improper use or operation of the Product by the Buyer or its customers that is not informed to the Seller, including, without limitation, the Buyer’s or its customers’ opera-any problem or damage to any equipment or machine to which the Product is installed, connected or combined, or on any specifications particular to the Buyer or its cus-any changes, modifications, improvements or alterations to the Product or those functions that are rendered on the Product by any person or entity other than the Seller ;。
- 1、下载文档前请自行甄别文档内容的完整性，平台不提供额外的编辑、内容补充、找答案等附加服务。
- 2、"仅部分预览"的文档,不可在线预览部分如存在完整性等问题,可反馈申请退款(可完整预览的文档不适用该条件!)。
- 3、如文档侵犯您的权益，请联系客服反馈,我们会尽快为您处理(人工客服工作时间：9:00-18:30)。
YTB-S2系列交流电机变频调速器使用说明书概 述YTB-S2系列变频器是我公司在YTB-S1的基础上改进而来,它保持了原有的优点,改善了运行性能, 增加了直流制动功能,及其它附属功能. 使调速更可靠，应用更广泛.，采用先进的SMD 工艺,严格的出厂质检，能够满足用户的多种使用要求．开 箱 检 查1 确认在运输过程中是否造成损坏。
2 检查变频器的铭牌以确定在您手中的产品就是所订货品。
3 检查包装箱内含变频器本体一台，使用说明书一份，出厂合格证一张及其它选购品。
型 号 说 明输出功率容量(KW)输入电压（V）T:三相输入 S:单相输入YTB-S2-1.5/220产品系列名称二次改型技 术 参 数额定功率（KW ） 额定电流（A ）S2系列 (单相220V)0．4 30．75 41．5 7.5T2系列(三相380V)0.75 2.5 1.5 3.7 2.2 5 3.7 8.5 5.5 13 输入电源要求 1Φ 220VAC 或 3Φ 380VAC ， 50HZ/60HZ 控 制 特 性频率范围0-120HZ 环境 场所 室内无腐蚀气体，无导电尘埃，通风良好 频率设定 按键,外部电位器,0-10mA 输入温度/湿度 -10℃~+40℃ ,相对湿度90%以下,无结露 点动频率0.1-10.0HZ 标高/振动 海拔1000米以下，振动0.5G 以下 制动功能 再生制动, 能耗制动 过载能力 150%，60秒 加减速时间 0.1-120.0秒 显示 四位数码管，显示运行频率、故障代码等 保护功能 过电压,欠电压,过电流 ,过负载、过热保护,失速保护,熔断器保护 冷却方式 自冷/风冷附加功能 定时器/计数器功能安装与结构1. 安装为了提高散热效果，应垂直安装变频器， 安装底板应为铁质或为其它阻燃耐热材料，并留有足够的 通风空间(周围至少留有12CM 以上的空间). 2.接线图1:安装尺寸图铭牌“Mode”--模式键接线盖板图2:操作面板图“▼”--下降键“▲”--上升键“Run”--运行键“Stop”--停止键四位数码管外接型外接操作盒插座普通型正转灯反转灯打开接线盖板，即可看到主接线柱和控制用接线柱。
端子说明见表二。
位置排列如图3, 图4为典型接线图. 表二 主端子 说明 标志 名称 端子功能说明 R ，S ，T 交流电源输入端子 单相220V 输入接R 、S 。
三相接R 、S 、T U ，V ，W 变频器输出端子 连接三相电动机P ，PR 制动电阻端子 连接制动电阻控制回路 接线端子 说明 X1,X2,X3,X4 多功能外接端子 详见参数一览表中的说明 COM 与X1,X2,X3,X4相连的公共端 0V, 相对于+5V, +12V I+ 0-10mA 输入“+”端 参见典型接线图 VR 外接电位器输入端(电位器中点) 电位器其它两端接+5V, COM.+12V直流电压输出(正端) 可供给外接传感器用(最大20mA) r1,r2,r3 多能继电器输出触点 r3 为继电器中间转换触点K在位置1K在位置2K在位置3+5V COM I++12V VR X1X2X3X4r1r2W U 图3V PR P R 频率设定方式开关,K*频率设定方式开关K 的设置（模拟信号）外接电位器方式面板上的电位器1 2 3电流输入方式公共端COMX30--10mA输入I+r3空(T)S计数脉冲输入或定时器暂停端子+多功能端子公共端外接电位器单相或三相输入S10KX2VR +5V COMX1(T)MCRX4r1多机能继电器复位端图4外接刹车电阻变频器机壳V MP PRWr2r3U 安 全 事 项1. 此变频器仅应用于工业三相感应电机。
2 进线端应接有同容量以上的接触器或空气开关，以便紧急时立即切断电源。
3. 电源输入端R , S, T 端与变频器输出端U,V,W 端千万不能接错,否则将损坏变频器.4. 变频器输出端（U,V,W ）不允许接继电器，补偿电容器，否则将损坏变频器。
5. 变频器外壳应接地，以保证人身安全。
6. 变频器内有高电压,切勿以手触摸,断电后,高压需一定时间释放, 因此维修检查时, 要待接线盖板下LED 指示灯完全熄灭后方可进行.7. 当使用60Hz 以上输出频率时,请事先对电机及负载的安全性充分确认. 8. 长期不用时, 请务必切断变频器供电电源.注 意 事 项1. 产品出厂时，已将内部按键作为默认频率设定方式。
另外两种方式(0-10mA 输入方式和外部电位器方式) ,请参见典型接线图，选择其一接线， 并使频率设定方式开关K 设置在相应位置。
2. 外接型的外引控制盒,外引电位器以及外接控制线与主机的连线应远离电磁线,动力线等强电磁磁干扰性的场所. 以免影响变频器的正常工作..3.本机分为普通型与外接型两种，后者通过9针D 型插座将主机与外接操作盒相连，外接操作盒自 带频率设定电位器，主机体外形尺寸请参见图2。
外引操作盒外形尺寸请参见说明书后附图.4.用单相（220V ）变频器驱动 标称为380V,星形接法的电机时，应将电机绕组从 星形接法改接成 三角形接法 。
以使电机达到额定功率。
否则只能降额使用。
运行与操作1. 用户在上电前须仔细检查接线是否正确，牢固，上电后，数码管陆续显示 “8888”-- ->“额定电压值”-→“额定电流值”--→“预设定的运行频率值(闪烁显示)”。
按“RUN ”键运行。
按“STOP ”停止。
运行中,数码管显示用户预设定的内容 (输出频率 /转速 /计数值/ 定时值等, 具体见参数) 按上升键或下降键可增减输出频率（按键方式）。
按下 “MODE”键, 则保存当前设定的频率值（按键方式）。
在异常状态下，数码管显示错误代码。
2. 点动功能: 在停止状态下,按上升键/下降键进行正向点动/负向点动。
同时运转方向灯亮.(见参数)3. 参数的设定：3.1 在停止状态下，按MODE键(< 3秒),数码管出现“Fr”(频率预设值)与数值交替闪烁,按上升/下降键可改变频率预设值（按键方式）。
修改完成后，按一下MODE键，数码管显示下一个参数“ds ”（显示选择），同样可以按上、下键修改，完成后，再按MODE键，数码管显示“SAUE ”，提示是否存储,再按一下MODE键，保存此次修改并退回监控状态。
在设参过程中，如果按下了“STOP“键，则不保存参数退出。
3.2在停止状态下，持续按住MODE键>3秒，（此时数码管显示“node”），当数码管出现“Tac”且与数值交替闪烁时，即说明已进入内参数设定状态。
按上升键，下降键可修改参数，按MODE 键进入下一项，（不须改变时，则直接按MODE键进入下一项参数）当参数设完时，数码管显示“SAUE”，提示你是否保存此次修改，按“MODE”键保存退出。
3.3 为了加快操作速度。
改变参数数值时，持续按住上、下键将加速数值的变化。
对于设定数值最大值>1000或100.0的参数时，可将”R un”键作为移位键使用。
按一下移位键，对应的数码位将闪烁,指示此位可改。
此时再按上、下键，可以1/10/100/1000为基数进行增减。
注：参数值有最大值，最小值的限制。
参数一览表参数项显示内容参数值范围出厂设置上升时间(Tac) Tac0.1—120.0秒10秒下降时间(Tdc) Tdc0.1—120.0秒 (调整停车快慢） 0: 表示自由滑行停车10秒频率设定方式Frs0:（模拟设定：电位器/10mA输入） 1：(按键设定） 1外端子X1，X2, X3, X4功能( 详见“外端子功能”)FUN0：X1为指明运转方向， X2为运转连锁（常开）1：X1为指明运转方向。
X2为运转连锁（常闭）2：X1为起动/停止(正转)， X2为运转连锁（常闭）3：正反转控制, X1为正转，X2为反转4: 功能同Fun=2, 但面板上的STOP键为暂停。
5: 三段速控制 ( X1/速度1 , X2/速度 2, X3/速度3).最低频率限制Fb 0.0--10.0Hz (防止频率过低造成电机过热) 0.1Hz 基底电压Ub0--20% （用于调整低频出力）8% 最高频率Frn0.1--120Hz 50Hz 频率设定值 (第一段速）Fr0.1--120Hz 50Hz 第二段速度Fr20.1--120Hz 40Hz 第三段速度Fr3 0.1--120Hz 30Hz 运转方向设定(三段速模式) dir 0~15, 具体见多段速的使用。
0显示内容选择ds 0：显示频率1：显示定时器或计数器值。
如CTC无效则显示频率2：显示转速值.(跟据频率折算而得)3：测试模式转速折算系数 rpN 1—200% 100% 点动允许 JOE 0：不允许点动 1：允许用上升键作正向点动2：下降键作负向点动 3：正、负向点动均有效。
0点动频率FS0.1—10.0Hz 5Hz 点动升降速率JAC 0.1-20.0s 5.0s 计数器/定时器(CTC)控制使能( 详见“附加功能”)CtE 0：无计数器/定时器功能 , 多能继电器只作为跳闸报警输出1：计数器使能, 继电器到点输出2：变频器内控定时器使能，继电器到点输出3：外控定时器使能，继电器到点输出计数器/定时器设定值CtC 1~9999(计数器) / 1~999.9min (定时器) 9999 直流制动使能brE 0：无DC制动，１：起动时进行直流制动.2：停止时进行直流制动 3 ：起动、停止均有制动0停止时制动起始频率brb ０～25.5Hz 3.0Hz 直流制动量 (电流％) brA 0~100% 30% 直流制动时间brT 0.1~25.5s 0.5s多功能配置Con 包含停车方式，电子热继电器使能等配置.(见注解). 0运行曲线选择UF 1：恒转矩. 2: 2次方曲线. 3:3次方曲线。
1LOC厂家密码,用户应直接按“Mode”键略过。
SAUE提示存盘。
按Mode键存盘退出。
注：1. 在停止状态下，才能设定参数。
2. 正转时正转灯亮，反转时反转灯亮 ,计数器/定时器工作时，CTC灯亮 (某些机型可能无此灯).3 .增大参数可以加大低频补偿，使电机在低频时有较大的力矩。
,但Ub过大会引起电机发烫,应适可而止。
4.的测试模式可以切换轮流显示基本频率，输入电压，输出电流，瞬时功率 , 可供调试参考..切换方法为在运行中按RUN键切换; 停车中或停止后按STOP键切换..5. 选定显示转速时, 转速=输出频率 * 60 * (折算系数)/2 . 例: 如果设定=100%,=50.0Hz,则数码管显示1500 (转/分) , 如设定=200%时, 则显示3000转/分.6. 如果设定Tdc=0(自由停车)时,应当注意再次启动的时间间隔,防止因电机还没停稳,就加速而发生过电流保护。
