各种led灯说明书集合
led灯产品说明书
LED灯产品说明书
一、产品概述
LED灯是一种高效、环保、节能的照明产品，采用最新的LED技术，具有长寿命、低能耗、高亮度等优点。
本产品适用于家庭、办公室、商场、酒店等场所的照明需求。
二、产品特点
1.长寿命：LED灯的使用寿命长达5万小时以上，比传统白炽灯和荧光灯更耐用。
2.低能耗：LED灯的能耗仅为传统白炽灯的1/10，具有极高的节能效果。
3.高亮度：LED灯的亮度比传统白炽灯更高，能够提供更明亮的照明效果。
4.环保：LED灯不含有害物质，对环境和人体健康无害。
5.易于安装：LED灯采用标准接口，可以方便地安装到各种灯具上。
三、使用方法
1.安装：请按照说明书中的步骤正确安装LED灯，确保电源连接稳定。
2.使用：打开电源开关，LED灯即可正常工作。
可以根据需要调节亮度。
3.维护：定期清理灯具表面灰尘，保持灯具清洁。
如遇故障，请联系专业维修人员。
四、注意事项
1.请勿在潮湿环境下使用LED灯。
2.请勿在高温环境下长时间使用LED灯。
3.请勿在电源不稳定的环境下使用LED灯。
4.请勿拆卸或自行维修LED灯。
五、售后服务
本产品自购买之日起享受一年质保服务。
如有质量问题或使用不当导致的损坏，可凭购买凭证免费维修或更换。
LED灯具使用说明书使用说明书
L E D灯具使用说明书警告：
为了使灯具安装正确,开箱后请详细阅读本说明书,并妥善保管
一、灯具主要结构和适用范围
1.壳体均采用铝合金材料制成,表面抛光拉丝及静电氧化处理,恒温固化,附着力强,具有防水、防尘、结构新颖等特点.
2.主要适用于办公场所,商场共公场所作照明.
二、主要结构参数
1.：85--265V~50/60Hz
2. ：30W□60W□90W□120W□140W□160W□
3.防触电保护等级：I类
4.外壳防护等级：IP65
5.LED颗数：
6.产品尺寸
7.光通量:90LM/W□100LM/W□110LM/W
8.发光角度;60°□90°□120°□
9.使用环境:温度:≥90%;工作温度:-40℃~+55℃
三、安装要求及维护
1、首先整理灯具配套用(de)各种零部件和附件.
2、安装前必须先切断电源.
3、如使用本产品更换普通灯具,请仔细检查产品接口与旧灯座(de)符合性,切勿误用.
4、把灯体所带(de)电线连接在相配(de)电源线上.
5、确定本产品紧固在被安装物表面在进行以下操作,最后接通电源点亮.
四、注意事项
◆未按照说明书操作可能会有危险.
◆违章操作可能损坏你(de)物品,甚至会危害到您(de)人身安全.。
led射灯说明书
led射灯说明书
LED射灯说明书
一、产品概述
LED射灯是一种高效、节能、环保的照明设备，采用高品质的LED灯珠作为发光源，具有亮度高、色温可选、寿命长等优点。
适用于家庭照明、商业照明、景观照明等多种场景。
二、产品规格
1. 输入电压：AC90-240V
2. 光源：LED灯珠
3. 灯体功率：18W
4. 色温：3000K/4200K/6400K可选
5. 输出光通量：1350Lm
6. 环境温度：-20℃-40℃
7. 灯体效率：75Lm/W
8. 寿命：>30000小时
9. 发光角度：28°/38°可选
10. 外观颜色：银色/金色
三、使用方法
1. 将LED射灯安装在指定位置，确保灯体稳固，避免晃动或掉落。
2. 根据需要选择合适的色温，通过调节开关或遥控器进行控制。
3. 使用过程中请避免长时间打开或关闭，以免影响寿命。
4. 请定期清洁灯罩表面，保持干净整洁。
四、注意事项
1. 请勿在潮湿环境下使用LED射灯，以免造成短路或损坏。
2. 请勿随意拆卸或改装LED射灯，以免造成安全隐患。
3. 请勿在高温环境下使用LED射灯，以免影响寿命或造成损坏。
4. 请勿将LED射灯长时间直射人眼，以免造成视力损伤。
LED智能灯具说明书20XX
LED智能灯具说明书20XX深圳市无线创意光电科技有限公司LED智能灯具说明书一： LED红外感应+声控+光控球泡灯，吸顶灯，灯管图片LED infrared induction + voice + light bulb lamp, ceiling lamp, lamp picture红外感应球泡灯红外感应灯管红外感应吸顶灯二：适用范围：楼道，走廊，酒店，超市，家庭，会所，商场，医院，大厦等地方。
每天需长时间照明的场所使用效果最佳；三：LED红外感应声控光控球泡灯说明：LED智能球泡：无需拉线，无需开关，使用非常方便。
Intelligent LED bulb: automatic sensing switch, convenient, no manual turn on andoff.1、 LED光控球泡 (light sensing LED bulb)功能介绍 (Function)当环境亮度低于25LUX，球泡自动点亮;当环境亮度高于25LUX，球泡自动退出灭掉。
Light turns on automatically when ambient brightness is below 25 Lux and it turns off when ambient brightness is above 25 Lux.2、 LED红外感应球泡 (infrared sensing LED bulb)功能介绍 (Function)①通电时感应球泡温机30秒，然后灭掉进入感应状态。
Light turns up for 30 seconds after power on, then enters the sensing status (light off).②当环境亮度低于10LUX时，人进入感应球泡的感应范围内灯会自动亮，亮一次的时间为2分钟(可以设置时间)。
At ambient brightness below 10 Lux (twilight status), the LED light turns on automatically for 2 minutes whenever there is a person within sensing area. Different light-up time can be set. ③感应球泡感应范围为半径5M。
乐鑫LED灯光产品说明书
DIM+/DIM-10ballasts DALI/DSI maxi L/OUT230V A1380W6A230V A460W2A2.8m7mBallast de variation(10max.) dimming ballast(10max.) Ballast per variazione(10max.)Ballast de variation(10max.)dimming ballastmax.)Ballast per variazione(10max.)•Poussoir optionnel pour commande manuelle de variation et extinction •Optional momentary switch for dimming and absence detection•Pulsante opzionale per il controllo manuale di variazione e spegnimento•Commutateur avec retour en position centrale optionnel pour la variation et la détection d’absence •Optional centre biased retractive switch for up/down dimming and absence detection •Commutatore con ritorno in posizione centrale opzionale per il controllo manuale di variazione e il rilevamento di assenza •Testa di rilevamento•Tête de détection •Sensor head •Testa di rilevamento •Utiliser unsecteur pourcâblage externe•Use mainscable for externalwiring•Utilizzaredi alimentazioneper il cablaggioesterno•Utiliser unsecteur pourcâblage externe•Use mainscable for externalwiring•Utilizzaredi alimentazioneper il cablaggioesterno23•Flush The product mounted using the flush shown.If flush mounting that is greater than 6mm remove bottom of retention side cutters.A 32mm will be required to mount mount ring.•Fixation encastréeLe produit peut être montéavec l’accessoire de montage encastrécomme indiqué.En cas de montage encastrédans un matériau de plus de 6mm d’épaisseur,retirez la base des languettes de fixation avec un cutter.Un trou de 32mm de diamètre sera nécessaire pour insérer l’accessoire de montage encastré.•Montaggio a filoIl prodotto puòessere montato con l’accessorio da incasso come mostrato.In caso di montaggio a filo in materiale di spessore superiore a 6mm,rimuovere la base delle linguette di fissaggio con un cutter.Un foro di 32mm di diametro sarànecessario per inserire l’accessorio da incasso.latérale •Side mounting •Montaggio lateraleø19.5mm19mmø3.5mm=>6mm•Retirer la base des 2languettes de fixation •Remove bottom of 2small retention arms •Rimuovere la base delle liguette fissaggio•Lentille PIRrécepteur luminosité•PIR lens/IR ReceiverLight Level Status LED •Lente PIR sensore luminositàLED。
LED路灯说明书
LED路灯产品说明书一、产品说明LED路灯是世界上新一代低碳绿色环保节能照明灯，被广泛适用于道路照明及城市景观照明。
传统路灯均存在耗电大、有污染、工作时温度高、灯具寿命短等难以克服的缺点，导致部分城市以缩短路灯照明时间来缓解电资源贫乏带来的压力，不同程度影响了道路照明效果和城市形象。
本公司生产的LED路灯系列产品具有寿命长、节能、绿色环保、高亮度、高稳定性等特性，安装简单且不必维护更换，大大降低了路灯的安装费用和维护成本，是传统路灯的理想换代产品。
与同类的LED路灯相比，本产品工作温升低，效率高，光效高。
二、尺寸规格尺寸：******mm 三、技术参数电压：220V AC 额定功率：**W工作频率：**Hz--**Hz 色温：*****K功率因数：>0.** 显色性：>***CRI电源效率：**%--**% 环境温度：-**℃---**℃工作温升：≤**℃存储温度：***℃---***℃适应湿度：≤**% 灯具效率：≥**%使用寿命：≥50,000小时防护等级：IP65四、产品型号命名规则：□□□- □□□- □①②③●型号说明①产品名称缩写：②光源类别：LED③额定功率：（备注：可根据客户的需求，调制不同的工作电压值，可选。
）●参数说明：外观：*** 色温：K额定功率：***W 光源类别：LED五、安装说明：该路灯外观安装－先将驱动器引线接线标志与电源线相接。
确认接线无误后，松动固定螺栓，将灯杆（Φ**mm）插入灯杆孔，然后紧上固定螺栓，确认无松动，则安装完毕。
六、维护和保养：考虑户外环境影响，为保证路灯照度和美观，须定期对防护玻璃进行清洁。
七、注意事项：安装前应检查产品外观、光源和散热措施是否完好，并对其电性能进行实验，确认后再安装。
12V/24V DC LED 路灯安装过程中灯具的红、黑导线分别与控制器的“+”“－”极连接。
110V/220V AC LED 路灯安装过程中灯具的黄绿线接地线，黑、红线接交流电源。
LED节能灯说明书
济源市云州豫伟光电有限公司第一款LED路灯产品尺寸：375*306*70mm玻璃材质：钢化玻璃表面处理：阳极氧化静电喷涂防水胶圈厚度：6mm整灯寿命：＞50000H.颜色可选：银色产品净重：7.6kg★此款功率可做：42W、56W、70W、84W、98W、112W、126W、140W、154W、168W、182W、196W。
★（可随功率的大小改变外壳的长度，宽度与高度不变）第二款路灯产品尺寸：348*300*80mm玻璃材质：钢化玻璃表面处理：阳极氧化静电喷涂防水胶圈厚度：6mm整灯寿命：＞50000H.★此款功率可做：42W、56W、70W、84W、98W、112W、126W、140W。
第三款矿用隔爆型LED灯适用范围本系列灯具适用于有甲烷、煤尘等爆炸性混合物气体的煤层井下巷道及峒室内作固定式局部照明用。
当白炽灯灯具使用下瓦斯矿井下车场场周围、中心变电所、泵房和主要苍道时，这些场所应有新鲜空气流通。
第四款矿用隔爆型LED日光灯适用范围该产品适用于有甲烷、煤尘等爆炸性混合物气体的煤尘井下巷道及峒室内作固定式局部照明用。
当荧光灯具适用于瓦斯矿井下的车场周围、中心变电所，泵房和主要巷道时，这些场所应有新鲜空气流通。
第五款LED日光灯L ED日光灯采用超高亮L ED白光作为发光光源，散热效果好：采用高品质散热铝，表面温度30－40度，提高LED灯管的使用寿命.光效好：独特的异形铝管，发光效果更好，两侧无暗区。
铝合金壳配PC面罩（透明盖、磨砂条纹盖、雾状盖），材质好，不易损坏，经久耐用，使用安全。
设计新颖,节电显著.方便实用,安全可靠,寿命长.该产品是现代最环保,最节能的照明光源. L ED日光灯有着传统的日光灯的外型.尺寸.口径上都一样，长度有60c m,90c m,120c m,150c m等等，其功率分别为8W，12W，15W，18W；而20W 传统日光灯（电感镇流器）实际耗电约为53W，40W传统日光灯（电感镇流器）实际耗电约为68W ；8W L ED日光灯亮度与传统20W日光灯亮度无异, 15W L ED 日光灯与传统40W日光灯亮度一样.LED日光灯亮度尤其显得更柔和更使人们容易接授。
led防爆说明书
led防爆说明书LED防爆说明书第一章：前言1.1 概述随着科技的进步和社会的发展，LED（Light Emitting Diode）发光二极管已经成为照明行业的主流产品。
LED灯具具有能耗低、寿命长、光效高等特点，受到广大用户的青睐。
然而，在一些特殊环境下，如油气、矿山、化工等行业，存在爆炸危险。
为了满足这些特殊环境的需求，LED防爆灯应运而生。
1.2 目的本说明书主要介绍LED防爆灯的特点、优势、使用方法、注意事项、安装注意事项等内容，旨在帮助用户正确、安全地使用LED防爆灯，避免事故发生。
第二章：LED防爆灯的特点和优势2.1 特点（1）防爆性能：LED防爆灯能够在易爆气体或粉尘环境中工作，并且能够防止火花或高温引起的爆炸。
（2）能耗低：LED防爆灯采用高效LED光源，能效高，相较于传统灯具能够达到更好的节能效果。
（3）寿命长：LED防爆灯的光源寿命长，能够达到几万小时，相较于传统灯具更为耐用。
（4）光效高：LED防爆灯的光效高，照明效果好，能够提供良好的照明体验。
（5）耐用性好：LED防爆灯采用高质量材料制作，具有良好的抗震、抗压、抗腐蚀性能，能够适应恶劣的环境。
2.2 优势（1）高安全性：LED防爆灯具有优越的防爆性能，能够确保在危险环境中的安全使用。
（2）高可靠性：LED防爆灯由优质材料制作，具有较长的使用寿命和良好的可靠性，能够满足用户的需求。
（3）节能环保：LED防爆灯使用LED光源，能耗低，相较于传统灯具更为节能环保。
（4）易维护：LED防爆灯的光源寿命长，不需要经常更换，维护成本低。
（5）适用范围广：LED防爆灯适用于石油、天然气、矿山、化工等行业，满足不同环境下的照明需求。
第三章：使用方法3.1 准备工作（1）仔细阅读本说明书，并了解LED防爆灯的特点、优势。
（2）根据使用环境选择适当的型号和规格的LED防爆灯。
（3）选择合适的安装位置，并确保其可以稳固地安装在悬挂装置或支架上。
LED 投光灯 说明书
LED 投光灯说明书LED投光灯是本公司新开发的一种新型集光照明灯具，该灯采用铝合金压铸底壳，进口材料面罩，超高亮度LED光源，具有外观时尚，坚固可靠，防水防尘，亮度高，光线柔和，节能环保等特点。
灯具特点：灯具特点1、单色性好，光线柔和，发光效率高。
2、冷光源、无热幅射、无有害金属汞、绿色环保。
3、功率低、耗电小、寿命长、稳定性好、可靠性高。
4、消耗能量较同光效的白炽灯减少80%。
5、工作温度可达-30℃~40℃，低温启动正常，响应速度快。
6、灯体采用金属制成，抗冲击性好，面罩采用PC材料，光线均匀柔和，坚固耐用。
7、灯体设计新颖别致，典雅美观，具有现代照明灯具特点，安装简单，调节方便。
技术参数：技术参数光源组成：超高亮白色大功率LED输入电压：AC85~264V频率范围：47~63HZ额定亮度：>0.9发光亮度：≥53Lux(6m),≥30Lux(8m),≥18Lux(10m),≥13Lux(12m)安装高度：6~12米使用寿命：≥30.000小时工作温度：-30℃~40℃灯体与灯罩材质：铝合金和pc材料防护等级：IP65净重：2.5Kg使用说明：使用说明根据灯具的安装位置，预先埋好灯杆，将灯具安装到灯杆上，接好电源线即可。
造用场所：造用场所造合花园，小区，园林，道路等场所的照明。
大功率LED投光灯系列产品简介大功率LED投光灯系列产品主要规格有30W、50W、70W、100W、140W等，还可根据用户要求开发特殊规格的产品，该灯具还可用作高速公路隧道照明灯、广告牌射灯、厂矿照明灯、庭院灯和路灯。
该产品的主要特点有：发光强度高，，照射距离远1、发光强度高目前LED的发光效率已经达到120Lm/W，已远远超过高压钠灯（80 Lm/W）、日光灯（60 Lm/W）和其他光源，而且LED发光角度为160º~180º，所有光能量可以全部投射到被照物表面，其他光源的发光角度均为360º，所以通常只有一半光能量投射到被照物表面，因此在同样光效的情况下，LED灯的发光强度（单位角度内的光通量）比其他灯具要高一倍，因此LED灯的发光强度（即通常人们感知的灯光亮度）比其他光源高得多。
LED射灯灯系列说明书_图文(精)
输入电压In put voltage : AC90-240V 光源LED qua ntity : LED 9 pcs 灯体功率power : 18W 色温Color temperature : 3000k/4200k/6400k输出光通量Luminous flux : 1350Lm 环境温度Ambient temperature : -20°C -+40°C 灯体效率Efficiency : 75Lm/W 寿命Lifetime : >30000 hours 发光角度Beam angle : 28/38 ° 外观颜色Fixture color : 银色/金Silver/Golde n103.2mm显色指数Ra :138mm158.5mm138mm158.5mm138mm103.2mm 158.5mm158.5mm158.5mm75-90产品尺寸图Ptoduct Size :产品特点Characteristics : 材质工艺:采用导热性极高的铝合金及专利结构技术设ELU99卜A103 2mm◎使用光源:一律采用低光衰的大功率的LED作为光源,以确保其长寿命、节能、高效、环保的特点防触电等级：11级配光方式：光面(强光玻珠面(半强光雾面(柔光配光种类:28 738。
安装地点：室内Material tech ni cs:Aviati on alumi num of hingh heat con du- ctivity and pate ned configuration technics lighting source: Low light attenuation and high power LED to make sure long lifetime, energy-saving , high efficiency and pro-environment Antielectric shock rate: Class IILens surface: Tran spare nt surface(high bright bead surface (bright fog-effect surface(lambe ncy Beam an gle: 28/38 °installati on place: in door应用场所Application :适用于汽车展示、珠宝首饰、高档服装、专业橱窗等重点照明场所，是替代传统卤素灯和金卤灯的理想光源Suitable for carjewelry and cloth ing display;ca n be in show windon s,shop coun ters and other lighting locations It is the ideal lighting source for the replacement market of conven ti onal haloge n lamps and metal halide lamps技术参数Technic Parameters :ZB-D901-18Professio nalLEDLight in gE nterprise 專業LED 照明生產商en vir onmen tal en ergyU n R e gi s t e r e d输入电压In put voltage : AC90-240V 光源LED qua ntity : LED 12 pcs 灯体功率power : 12W 色温Color temperature : 3000k/4200k/6400k输出光通量Luminous flux : 970Lm 环境温度Ambient temperature : -20°C -+40°C 灯体效率Efficiency : 80Lm/W 寿命Lifetime : >30000 hours 发光角度Beam angle : 28/38 °外观颜色Fixture color : 银色Silver显色指数Ra :75-90产品尺寸图Ptoduct Size :产品特点Characteristics : 材质工艺:采用导热性极高的铝合金及专利结构技术设计生产使用光源:一律采用低光衰的大功率的LED作为光源,以确保其长寿命、节能、高效、环保的特点防触电等级：11级配光方式：光面(强光玻珠面(半强光雾面(柔光配光种类:28 738。
法国威隆 肤维安LED灯使用说明说明书
3
4
5.组装说明 灯-用户界面 1-启动/暂停按钮 开始和暂停光照时段。 灯在指示光照开始时会发出声音。
2-功率指示器 电池状态指示： 工作时： 绿色常亮：电池已充满 呈绿色闪烁：电池电量低于50％ 呈黄色闪烁：还剩不足4个照明周期 充电时： LED黄色：充电模式开启 LED黄色常亮和白色闪烁： 至少有一个周期可用。每格代表20％电池容量。 LED绿色常亮和白色常亮：电池已充满
防止有害液体进入的防护等级：IP23 ·存在空气或氧气或一氧化二氮与易燃麻醉剂混合物时的安全度：不适合在有空气、氧气或一氧 化二氮与易燃麻醉剂混合物的情况下使用。
工作环境： ·曝光区域：50cm2的圆形表面 ·光源和凝胶之间的距离（工作距离）：理想情况下为5cm，这意味着橡胶罩应尽可能靠近皮肤表面 ·工作温度：+ 5°C至+ 35°C（相当于41°F至95°F），相对湿度0-80％，无冷凝 ·大气压额定值：700 hPa至1060 hPa
运输和储存条件： ·储存和运输：-10°C至+ 50°C（相当于14°F至122°F），相对湿度0-80％，无冷凝 大气压额定值：700hPa至1060hPa
清洁和维护： ·充电座可以用70％的异丙醇、70％的乙醇或洗必泰进行消毒。
带NEMA/BS/CEE/CEI插头的12V电源线的规格
·尺寸：1.22米（4英尺） ·重量：160g ·额定电流：12V，2A
·尺寸：1.5米（5英尺） ·重量：50g ·额定电流：12V，2A
手提式灯12V汽车电源适配器规格
护目镜规格
·说明：护目镜（橙色OD2 +）57％ ·材质：聚碳酸酯
·描述：可充电锂离子电池组 ·容量：2200mAh ·标称电压：3.6V
红外LED灯产品说明书
Dimensions: [mm]35150505RS73300150505RS73300150505RS73300150505RS73300BCC(mm)min.12,80150505RS73300T e m p e r a t u r eT pT L150505RS73300Cautions and Warnings:The following conditions apply to all goods within the product series of Optoelectronic Components of Würth Elektronik eiSos GmbH & Co. KG:General:•This optoelectronic component is designed and manufactured for use in general electronic equipment.•Würth Elektronik must be asked for written approval (following the PPAP procedure) before incorporating the components into any equipment in fields such as military, aerospace, aviation, nuclear control, submarine, transportation (automotive control, train control, ship control), transportation signal, disaster prevention, medical, public information network, etc. where higher safety and reliability are especially required and/or if there is the possibility of direct damage or human injury.•Optoelectronic components that will be used in safety-critical or high-reliability applications, should be pre-evaluated by the customer •The optoelectronic component is designed and manufactured to be used within the datasheet specified values. If the usage and operation conditions specified in the datasheet are not met, the wire insulation may be damaged or dissolved.•Do not drop or impact the components, the component may be damaged•Würth Elektronik products are qualified according to international standards, which are listed in each product reliability report. Würth Elektronik does not warrant any customer qualified product characteristics beyond Würth Elektroniks’ specifications, for its validity and sustainability over time.•The responsibility for the applicability of the customer specific products and use in a particular customer design is always within the authority of the customer. All technical specifications for standard products also apply to customer specific products.•Unless Würth Elektroik has given its express consent, the customer is under no circumstances entitled to reverse engineer, disassemble or otherwise attempt to extract knowledge or design information from the optoelectronic componentProduct specific:Soldering•The solder profile must comply with the technical product specifications. All other profiles will void the warranty.•All other soldering methods are at the customers’ own risk.•The soldering pad pattern shown above is a general recommendation for the easy assembly of optoelectronic component. If a high degree of precision is required for the selected application (i.e. high density assembly), the customer must ensure that the soldering pad pattern is optimized accordingly.Cleaning and Washing:•Washing agents used during the production to clean the customer application might damage or change the characteristics of the optoelectronic component body, marking or plating. Washing agents may have a negative effect on the long-term functionality of the product. •Using a brush during the cleaning process may break the optoelectronic component body. Therefore, we do not recommend using a brush during the PCB cleaning process.Potting:•If the product is potted in the customer application, the potting material might shrink or expand during and after hardening. Shrinking could lead to an incomplete seal, allowing contaminants into the optoelectronic component body, pins or termination. Expansion could damage the components. We recommend a manual inspection after potting to avoid these effects.Storage Conditions:• A storage of Würth Elektronik products for longer than 12 months is not recommended. Within other effects, the terminals may suffer degradation, resulting in bad solderability. Therefore, all products shall be used within the period of 12 months based on the day of shipment.•Do not expose the optoelectronic component to direct sunlight.•The storage conditions in the original packaging are defined according to DIN EN 61760-2.•For a moisture sensitive component, the storage condition in the original packaging is defined according to IPC/JEDEC-J-STD-033. It is also recommended to return the optoelectronic component to the original moisture proof bag and reseal the moisture proof bag again. •The storage conditions stated in the original packaging apply to the storage time and not to the transportation time of the components. Packaging:•The packaging specifications apply only to purchase orders comprising whole packaging units. If the ordered quantity exceeds or is lower than the specified packaging unit, packaging in accordance with the packaging specifications cannot be ensured. Handling:•Violation of the technical product specifications such as exceeding the nominal rated current, will void the warranty.•The product design may influence the automatic optical inspection.•Certain optoelectronic component surfaces consist of soft material. Pressure on the top surface has to be handled carefully to prevent negative influence to the function and reliability of the optoelectronic components.•ESD prevention methods need to be applied for manual handling and processing by machinery.•Resistors for protection are obligatory.•Luminaires in operation may harm human vision or skin on a photo-biological level. Therefore direct light impact shall be avoided. •In addition to optoelectronic components testing, products incorporating these devices have to comply with the safety precautions given in IEC 60825-1, IEC 62471 and IEC 62778•Please be aware that Products provided in bulk packaging may get bent and might lead to derivations from the mechanical manufacturing tolerances mentioned in our datasheet, which is not considered to be a material defect.Please be aware that Products provided in bulk packaging may get bent and might lead to derivations from the mechanical manufacturing tolerances mentioned in ourdatasheet, which is not considered to be a material defect.Würth Elektronik eiSos GmbH & Co. KGEMC & Inductive SolutionsMax-Eyth-Str. 174638 WaldenburgGermanyCHECKED REVISION DATE (YYYY-MM-DD)GENERAL TOLERANCE PROJECTIONMETHODLiDo002.0002022-10-25DIN ISO 2768-1mDESCRIPTIONWL-SMTW SMT Mono-color TOPLED Waterclear ORDER CODE150505RS73300SIZE/TYPE BUSINESS UNIT STATUS PAGETechnical specification:•The typical and/or calculated values and graphics of technical parameters can only reflect statistical figures. The actual parameters of each single product, may differ from the typical and/or calculated values or the typical characteristic line.•On each reel, only one bin is sorted and taped. The bin is defined on intensity, chromaticity coordinate or wavelength and forward voltage.•In order to ensure highest availability, the reel binning of standard deliveries can vary. A single bin cannot be ordered. Please contact us in advance, if you need a particular bin sorting before placing your order.•Test conditions are measured at the typical current with pulse duration < 30ms. •Optical properties are measured according the CIE 127:2007 standard. •Wavelength tolerance under measurement conditions ± 2nm. •Optical intensity tolerance under measurement conditions ±15%. •Forward voltage tolerance under measurement conditions ± 0.1V.•CCT tolerance of x and y coordinate of ± 0.01 and CRI tolerance of ± 2 is allowed.In the characteristics curves, all values given in dotted lines may show a higher deviation than the parameters mentioned above.These cautions and warnings comply with the state of the scientific and technical knowledge and are believed to be accurate and reliable.However, no responsibility is assumed for inaccuracies or incompleteness.The customer has the sole responsibility to ensure that he uses the latest version of this datasheet, which is available on Würth Elektronik’s homepage. Unless otherwise agreed in writing (i.e. customer specific specification), changes to the content of this datasheet may occurwithout notice, provided that the changes do not have a significant effect on the usability of the optoelectronic componentsWürth Elektronik eiSos GmbH & Co. KG EMC & Inductive Solutions Max-Eyth-Str. 174638 Waldenburg GermanyCHECKED REVISION DATE (YYYY-MM-DD)GENERAL TOLERANCEPROJECTION METHODLiDo002.0002022-10-25DIN ISO 2768-1mDESCRIPTIONWL-SMTW SMT Mono-color TOP LED WaterclearORDER CODE150505RS73300SIZE/TYPEBUSINESS UNITSTATUSPAGEImportant NotesThe following conditions apply to all goods within the product range of Würth Elektronik eiSos GmbH & Co. KG:1. General Customer ResponsibilitySome goods within the product range of Würth Elektronik eiSos GmbH & Co. KG contain statements regarding general suitability for certain application areas. These statements about suitability are based on our knowledge and experience of typical requirements concerning the areas, serve as general guidance and cannot be estimated as binding statements about the suitability for a customer application. The responsibility for the applicability and use in a particular customer design is always solely within the authority of the customer. Due to this fact it is up to the customer to evaluate, where appropriate to investigate and decide whether the device with the specific product characteristics described in the product specification is valid and suitable for the respective customer application or not.2. Customer Responsibility related to Specific, in particular Safety-Relevant ApplicationsIt has to be clearly pointed out that the possibility of a malfunction of electronic components or failure before the end of the usual lifetime cannot be completely eliminated in the current state of the art, even if the products are operated within the range of the specifications.In certain customer applications requiring a very high level of safety and especially in customer applications in which the malfunction or failure of an electronic component could endanger human life or health it must be ensured by most advanced technological aid of suitable design of the customer application that no injury or damage is caused to third parties in the event of malfunction or failure of an electronic component. Therefore, customer is cautioned to verify that data sheets are current before placing orders. The current data sheets can be downloaded at .3. Best Care and AttentionAny product-specific notes, cautions and warnings must be strictly observed. Any disregard will result in the loss of warranty.4. Customer Support for Product SpecificationsSome products within the product range may contain substances which are subject to restrictions in certain jurisdictions in order to serve specific technical requirements. Necessary information is available on request. In this case the field sales engineer or the internal sales person in charge should be contacted who will be happy to support in this matter.5. Product R&DDue to constant product improvement product specifications may change from time to time. As a standard reporting procedure of the Product Change Notification (PCN) according to the JEDEC-Standard inform about minor and major changes. In case of further queries regarding the PCN, the field sales engineer or the internal sales person in charge should be contacted. The basic responsibility of the customer as per Section 1 and 2 remains unaffected.6. Product Life CycleDue to technical progress and economical evaluation we also reserve the right to discontinue production and delivery of products. As a standard reporting procedure of the Product Termination Notification (PTN) according to the JEDEC-Standard we will inform at an early stage about inevitable product discontinuance. According to this we cannot guarantee that all products within our product range will always be available. Therefore it needs to be verified with the field sales engineer or the internal sales person in charge about the current product availability expectancy before or when the product for application design-in disposal is considered. The approach named above does not apply in the case of individual agreements deviating from the foregoing for customer-specific products.7. Property RightsAll the rights for contractual products produced by Würth Elektronik eiSos GmbH & Co. KG on the basis of ideas, development contracts as well as models or templates that are subject to copyright, patent or commercial protection supplied to the customer will remain with Würth Elektronik eiSos GmbH & Co. KG. Würth Elektronik eiSos GmbH & Co. KG does not warrant or represent that any license, either expressed or implied, is granted under any patent right, copyright, mask work right, or other intellectual property right relating to any combination, application, or process in which Würth Elektronik eiSos GmbH & Co. KG components or services are used.8. General Terms and ConditionsUnless otherwise agreed in individual contracts, all orders are subject to the current version of the “General Terms and Conditions of Würth Elektronik eiSos Group”, last version available at .Würth Elektronik eiSos GmbH & Co. KGEMC & Inductive SolutionsMax-Eyth-Str. 174638 WaldenburgGermanyCHECKED REVISION DATE (YYYY-MM-DD)GENERAL TOLERANCE PROJECTIONMETHODLiDo002.0002022-10-25DIN ISO 2768-1mDESCRIPTIONWL-SMTW SMT Mono-color TOPLED Waterclear ORDER CODE150505RS73300SIZE/TYPE BUSINESS UNIT STATUS PAGE。
LED各种类型灯的说明书[整理版]
![LED各种类型灯的说明书[整理版]](https://img.taocdn.com/s3/m/c00e5635bdd126fff705cc1755270722192e59c9.png)
LED蜡烛灯该产品具有如下技术特点:1.高效节能——在相同亮度情况下,LED节能灯一千小时仅耗3度电（3W）。
2.超长寿命——使用寿命达五万小时以上，普通节能灯管使用寿命六千小时，普通白炽灯使用寿命一千小时。
3.光线健康—光线中不含紫外线和红外线，无辐射，普通节能灯管和白炽灯光线中含有紫外线和红外线。
4.绿色环保——不含汞和铅等有害元素，得利于回收和利用，而且不会产生电磁干扰，普通灯管中含有汞和铅等有害元素，节能灯中的电子镇流。
5.保护视力——直流驱动，无频闪。
(普通灯都是交流驱动，定有频闪)。
6.安全系数高——所需要的电压，电流较小，发热较小，不产生安全隐患。
产品详细参数:规格型号XD-TD1204 发光角度130-150°输入电压AC95-265V 储存温度和湿度-40℃~80℃ / 10%~90%电源频率50Hz ~60Hz 产品尺寸∮192mm*70mmLed功率12W 灯具毛重≤0.5kg显色指数Ra﹥70 使用寿命50000 H转换效率 >95% 额定光衰≤15%功率因素 >0.8 工作温度和湿度-20℃~45℃光通量正白1350-1200LM 光源色温正白 5500-6500K 暖白1250-1100LM 暖白 3000-3500K 自然白3150-2950LM 自然白 4000-4500K一.7.防蚊虫—— LED灯由于没有紫外线，不会像传统日光灯一样吸引蚊虫，从而有利于维护室内清洁二.2、产品详细参数型号规格 XD-TD1204 发光角度 130-150°输入电压 AC95-265V 储存温度和湿度 -40℃~80℃ / 10%~90% 电源频率 50Hz ~60Hz 产品尺寸∮192mm*70mm 开孔： 170mm LED功率 12W 灯具毛重≤0.5kg 显色指数 Ra﹥70 使用寿命 50000 H 转换效率 >95% 额定光衰≤15% 功率因素 >0.8 工作温度和湿度 -20℃~45℃ / 10%~90% 光通量三.正白1350-1200LM 光源色温四.正白 5500-6500K 暖白1250-1100LM 暖白 3000-3500K 自然白3150-2950LM 自然白 4000-4500K五.六.灯杯LED灯杯是用led光源、恒流驱动器、光学透镜和金属或其他具有高热导系数的散热器外壳组合而成的新型照明灯具。
Led灯简易使用说明书
Led 灯简易使用说明书
一、 后面板图解说明
菜单 减键 加键 却换/进入 操作说明：
1、 按菜单键可在’IMAGE ’、’DMX ’、’STAT ’、’RUN ’、’AUTO ’、’TEMP ’、’VOX ’、
‘MODE ’8个菜单中选择；
2、 按却换/进入键可以进入相应菜单的子项，且有多个子项时按此键进行子项
之间的却换；
3、 减键和加键进行数值的加减和功能的设置；
4、 在参数设置好后，按菜单键退出此菜单并将参数记忆；
二、 Led 显示功能对照表
三、Dmx512通道说明3通道：
6通道：
9通道：
四、技术指标
1、工作电压：AC220v 50Hz
2、最大功率：<200W
3、亮度：3m距离>3500 CD
4、颜色：R 控制等级0—255
G 控制等级0—255
B 控制等级0—255
W 控制等级0—255
5、频闪：控制等级11——255
6、灯杯角度：15度、30度、45度可选
7、温升：<40度
8、灯体可调角度：>180度
长沙新画佳光电子有限公司
2010-2-8。
LED面板灯使用说明书
47W68WLEDPNL2X4-50WLEDPNL2X4-70W ▪Available in 3000k (warm white), 3500k (warm/neutral white) 4000k (neutral white) & 5000k (cool white) color temperatures.*▪Long-life LEDs provide 63,000 hours of operation with at least 70% of initial lumen output (L 70).**▪LEDPNL2x4-50W Provides 4,652 luminaire lumens (99lumens per watt, LPW) at 3000k, 3500k & 4000k, and 5,062 luminaire lumens (108 LPW) at 5000k.*▪LEDPNL2x4-70W provides 6,567 luminaire lumens (97LPW) at 3000k, 6,645 luminaire lumens (98 LPW) at 3500k & 4000k, and 7,325 luminaire lumens (108 LPW) at 5000k.*▪Uniform illumination with no visible LED pixilation.▪Universal 120-277 AC voltage (50-60Hz) is standard.▪0-10vdc dimming capability is standard.▪Power factor > 0.90.▪Total harmonic distortion < 20%.▪Color rendering index > 80.▪Aluminum housing.▪PS (polystyrene) light guide panels for optimal light distribution, efficiency and longevity.▪Easy installation in new construction or retrofit.▪Standard earthquake clips provide secure installation in grid ceilings.▪Standard mounting options include recessed mounting in grid ceilings, or suspended mounting using attached hanging brackets. For mounting in plaster or other hard ceiling, see Mounting Kits.*Contact factory for other color temperatures and lumen packages.**L 70hours are IES TM-21-11 calculated hours.Project:Type:Catalog #:4,6524,6524,6525,0629999991083K = 3000k 35k= 3500k 4K = 4000k 5K = 5000k 6,5676,6456,6457,3259798981083K = 3000k 35k= 3500k 4K = 4000k 5K = 5000kSTANDARDFEATURESThe ultra-thin, edge-lit LED panel (LEDPNL) series isdesigned to deliver general ambient lighting in a variety of indoor settings, including schools, offices, hospitals and stores, and is the perfect choice for both new construction and retrofits. This high-efficacy luminaire provides long-life and uniform illumination, as well as standard 0-10 vdc dimming capability.ICDAMP▪ETL listed to applicable U.L. standards for damp locationsand insulated ceilings (IC-rated). Suitable for ambient temperatures from -25°C to 45°C (-13°F to 113°F).▪DLC standard approved.▪Complies with RoHS (Restriction on Hazardous Substances)requirements.▪Complies with FCC Part 15.▪5-year warranty of all electronics and housing.WARRANTY & LISTINGSMOUNTING KITS See below for details47.8”23.7”0.5”2.0”DIMENSIONSWeight: 15.5 lbs.Example:LEDPNL2x4-50W-3K + LEDSMKT-24 + LEDPNL-EMBRKTModelLuminaire WattsLuminaire LumensLumens/ WattColor TemperatureLEDSMKT-24=Surface Mounting Kit (2x4)FLANGEKIT24-ET =Flange Mounting Kit (2x4)LEDPNL-CMK =Cable Mounting Kit, Quantity 6,1 meter long, 1/16” diameter, with spring clips & adjustable, locking ceiling attachmentLEDPNL-EMBRKT =Bracket for emergency batterybackup unitORDERING INFORMATION▪Optional Surface Mount Kits (LEDSMKT-24) and Flange MountingKits (FLANGEKIT24-ET) provide for installation on plaster or other hard ceilings.▪Optional Cable Mounting Kits (LEDPNL-CMK) provide additional security, as well as suspended mounting.Options (Order Separately)63,000LEDPNL2X4-50W-3K 3000k4,65247990.390.200.17120-277> 80> 90%< 20%63,00063,000ELECTRICAL DATA23911793119659830︒0︒60︒90︒20︒10︒50︒40︒70︒80︒Maximum Candela = 2,391LEDPNL2X4-70W-4K (6,645 Lumens)PHOTOMETRIC DATAModelLEDPNL2X4-50W-35K LEDPNL2X4-50W-5K Color Temperature 3500k 5000k Luminaire Lumens 4,6525,062Luminaire Watts 4747Lumens Per Watt99108Input Current (A)120V 240V 277V0.390.200.170.390.200.17120-277120-277CRI 1> 80> 80Power Factor> 90%> 90%< 20%< 20%LEDPNL2X4-70W-4K 4000k 6,64568980.570.280.25120-277> 80> 90%< 20%LEDPNL2X4-70W-5K5000k7,325681080.570.280.25120-277> 80> 90%< 20%1693127084742330︒0︒60︒90︒20︒10︒50︒40︒70︒80︒Maximum Candela = 1,693LEDPNL2X4-50W-4K (4,652 Lumens)63,00063,0000︒90︒0︒90︒CandlepowerSummary 0︒90︒0︒1,6211,62110︒1,6331,48920︒1,5161,38930︒1,3411,23940︒1,1271,04250︒87981560︒61257070︒34030580︒987690︒Zonal LumenSummaryZone Lumens % Fixture 0︒−10︒390.8%0︒−20︒3467.4%0︒−30︒91819.7%0︒−40︒1,67736.0%0︒−50︒2,51754.1%0︒−60︒3,32771.5%0︒−70︒3,99986.0%0︒−80︒4,45195.7%0︒−90︒4,652100.0%90︒−180︒00.0%0︒−180︒4,652100.0%CandlepowerSummary0︒90︒0︒2,3842,18010︒2,3042,14020︒2,1382,01930︒1,8911,82440︒1,5851,56150︒1,2271,22960︒84386970︒44748280︒10713890︒Zonal Lumen SummaryZone Lumens % Fixture 0︒−10︒560.8%0︒−20︒4917.4%0︒−30︒1,30519.6%0︒−40︒2,38835.9%0︒−50︒3,59354.1%0︒−60︒4,75471.5%0︒−70︒5,71886.1%0︒−80︒6,36295.7%0︒−90︒6,645100.0%90︒−180︒00.0%0︒−180︒6,645100.0%Cone of Light6’8’10’12’51 FC 31 FC 20 FC16 FC.0︒Nadir Cone of Light6’8’10’12’72 FC 44 FC 29 FC23 FC.0︒Nadir Input Voltage 2THD 3L 70Hours 41 Color rendering index.2 All 50-60Hz.3 Total harmonic distortion.4L 70refers to the number of hours at which lumen output declines to 70%of the initial level.L 70hours are IES TM-21-11calculated hours.63,000LEDPNL2X4-50W-4K 4000k 4,65247990.390.200.17120-277> 80> 90%< 20%LEDPNL2X4-70W-3K 3000k 6,56768970.570.280.25120-277> 80> 90%< 20%LEDPNL2X4-70W-35K 3500k 6,64568980.570.280.25120-277> 80> 90%< 20%63,00063,000OPTIONS▪Optional surface mounting kits (LEDSMKT-24) mountsbelow the ceiling.▪Optional flange mounting kits provide for recessedinstallation on plaster or other hard ceilings. Attach Flange Mount Kit (FLANGEKIT24-ET) to ceiling joists or other stationary structures, and the panel is mounted flush to the ceiling.▪Optional cable mounting kits provide additionalsecurity, as well as suspended mounting. Attach one end of the Cable Mount Kit (LEDPNL-CMK) to luminaire earthquake clips using spring clips, and attach the other end to stationary structures using the adjustable, locking ceiling attachment (see picture below right).▪Optional bracket for emergency battery backup unit(LEDPNL-EMBRKT) provides structural support to prevent panels from bending when the battery backups are installed.Cable Mount Kit:•Spring Clip•Adjustable, locking ceiling attachmentDepress plunger to unlock cableSpring Clip:Attaches to earthquake clipAdjustable, Locking Ceiling AttachmentCable Mounting Kit (LEDPNL-CMK)Flange Mounting Kit (FLANGEKIT24-ET)1.5”Surface Mounting Kit (LEDSMKT-24)2 ¾”Bracket for Emergency Battery Backup Unit (LEDPNL-EMBRKT)。
超亮红色和超亮绿色LED灯泡说明书
DATE: NOV/23/2007 DRAWN: W.J.Hua
PAGE: 5 OF 6 ERP: 1203000876
PACKING & LABEL SPECIFICATIONS
APBD3224SURKSGC-F01
SPEC NO: DSAF1338 APPROVED: WYNEC
REV NO: V.5 CHECKED: Allen Liu
Description
The Hyper Red source color devices are made with InGaAlP on GaAs substrate Light Emitting Diode. The Super Bright Green source color devices are made with Gallium Phosphide Green Light Emitting Diode.
Iv (mcd) [2] Viewing
@ 20mA
Angle [1]
Min. Typ. 2θ1/2
380 800
20°
18
60
Electrical / Optical Characteristics at TA=25°C
Symbol
Parameter
Device
λpeak
Peak Wavelength
PAGE: 2 OF 6 ERP: 1203000876
APBD3224SURKSGC-F01 Hyper Red
SPEC NO: DSAF1338 APPROVED: WYNEC
REV NO: V.5 CHECKED: Allen Liu
DATE: NOV/23/2007 DRAWN: W.J.Hua
- 1、下载文档前请自行甄别文档内容的完整性，平台不提供额外的编辑、内容补充、找答案等附加服务。
- 2、"仅部分预览"的文档,不可在线预览部分如存在完整性等问题,可反馈申请退款(可完整预览的文档不适用该条件!)。
- 3、如文档侵犯您的权益，请联系客服反馈,我们会尽快为您处理(人工客服工作时间：9:00-18:30)。
50000小时平均无故障时间（取决于使用环境）；
2.电源效率超过85%，功率因数高达0.85；
3.显色指数82以上，接近自然光；
4..采用特殊散热装置，提高了光效，延长了灯具寿命；
5.电磁辐射低；
6..独特的光学配光设计，光强接近理想分布，无光污染、无眩光、无频闪；
7采用超高亮LED作为光源，绿色安全，寿命长，显色性佳，色彩丰富，接近自然光源；
7.驱动，散热，光源整体设计更加方便用户使用与维护；
9全灯采用互换性元件达95%以上，方便用户进行产品升级换代
LED日光灯
LED日光灯主要参数
规格：T5、T8、T10、600/1200/1500mm
颜色：正白/暖白/冷白
电压：AC185-265V
功率：8W 9W 12W 15W 18W 22W
能效>80%
使用寿命：50000-80000小时
材质：铝合金，PC、洗酸玻璃、磨砂玻璃外壳
产品优势：
LED日光灯光源采用高亮度LED，包括冷白、暖白和正白三种色温。
LED日光灯与传统荧光灯相对比有
以下优点：
1、节能：比传统荧光灯节电80%;
2、绿色环保：无紫外光、红外光等辐射，不含汞等有害物质，灯体回收无污染;
3、寿命长：正常使用可达5万小时以上;
4、无频闪：LED恒流工作,有效减少LED光衰，启动快，无闪烁，保护眼睛;
5、安装简单, 安装时将原有的日光灯取下换上LED日光灯，并将镇流器和起辉器去掉，让220V交流
市电直接加到LED日光灯两端即可。
适用范围：
适用于大部分室内照明应用，例如：家庭、宾馆、商场、办公场所、学校、停车场、仓库、工厂、超
级市场、通道、走廊及广告箱体等室内照明。
交流輸入電压: □180 ~ 240V / AC 50-60HZ □90 ~ 130V / AC 50-60HZ 交流輸入電流: 30mA MAX
交流消耗功率: 3.2-4.0W/H
直流輸入電壓: 200V / DC
直流輸入電流： 17mA / DC 恒流
發光元件：高效能高亮度 LED 模組，共計1并65串
LED色温：□3500K-4000K暧色□6000K-6500k正白□红□绿□蓝
□黄□紫
燈具光通量： 325-420 流明（正白）
產品壽命：＞30,000 小時
相同亮度光源： 35W普通白炙灯 15W普通节能灯
防水等級：请在室内使用
使用環境溫度： -30℃ ~ +45℃
外型尺寸： 4.3*15.4CM
燈具總重量：≒55g
产品说明：
LED横插灯
1。
LED 光源是采用直流驱动的超低功耗器件，抗震、耐冲击、无热辐射、安全稳定、可靠、无需考虑散热，长寿命；灯体小巧，安装简便；款式新潮，工艺精良，产品系列化。
2。
节能环保，产品不产生废弃物，可全部回收
产品特点：
1、节能省电：超低功耗，比传统卤素灯、节能灯、白炽灯节能80%以上。
2、超长寿命：5万小时以上，是传统灯寿命10倍以上。
3、绿色环保：不产生辐射，不含汞和铅等有害物质，不会造成环境污染。
4、超高光效：90%的电能转化为可见光。
5、使用安全：低电流，低热量，安装方便。
◆适用范围：与传统节能灯、白炽灯、电灯泡一样，适合装饰及照射，广泛应用于水晶吊灯、台灯、筒灯、壁灯、小夜灯、家居、办公室、工厂、酒店、旅馆、超市装饰灯具、室内照明及装饰等等。
◆使用方法：与传统灯泡和节能灯使用方法一致，无须另外购买支架和灯坐，即可使用.
供电电压：220（V）功率：6（W）光通量：600（LM）
寿命：50.000（H）封装工艺：直插式色温：2500-8000。
