船舶制造中英文对照外文翻译文献

合集下载

船舶设备部件中英文对照

船舶设备部件中英文对照

船舶设备部件中英文对照一、船体设备1. 锚Anchor2. 舵叶Rudder blade3. 舵柄Rudder tiller4. 舵挂臂Rudder horn5. 舵销/舵轴Rudder pintle or axle6. 舵承Rudder carrier7. 舵杆Rudder stock8. 主舵机Main steering gear9. 固定式灭火系统Fixed fire extinguishing system10. 惰气系统Inert Gas System11. 惰性气体发生器inert gas generator12. 洗涤塔 scrubber13. 甲板水封deck water seal14. 鼓风机Blower15. 压力真空阀P/V valves16. 舷梯Accommodation Ladders17. 风雨密舱口盖Weather tight hatch covers18. 救生/救助艇Lifeboat/rescue boat19. 救生/救助艇架Life boat/rescue davit20. 海上撤离系统Marine evacuation system21. 起重机(安全工作负荷≥1t)Deck cranes22. 吊杆装置(安全工作负荷≥1t)Derrick rig二、轮机设备1. 柴油机(功率≥130kw)Diesel Engine2. 应急鼓风机Emergency Blower3. 燃气轮机Turbines4. 柴油机地脚螺栓Foundation bolts & nuts5. 推力轴Thrust Shaft6. 齿轮箱Reduction Gear7. 离合器Clutch8. 中间轴Intermediate Shaft9. 连接螺栓Coupling bolts10. 联轴节Shaft coupling11. 艉轴管Stern Tube12. 艉轴Stern Shaft13. 螺旋桨轴Screw Shaft14. 备用轴Spare Shaft15. 艉轴密封装置Stern shaft seal16. 螺旋桨Propeller17. 备用螺旋桨Spare Propeller18. 导流罩Kort nozzle19. 可调桨装置CPP Installation20. “Z”型推进器装置Z-Type Propulsion System21. 喷水推进器装置Water-jet propulsion system22. 动力定位/侧推装置Dynamic positioning/lateral thruster23. 蒸汽/热油系统STEAM/THERMAL OIL SYSTEM24. 主锅炉Main Boiler25. 辅锅炉Aux. Boiler26. 废气锅炉Exhaust Gas Boiler27. 组合锅炉Composite Boiler28. 热油锅炉Thermal Oil Heater29. 蒸汽透平Steam Turbines30. 燃烧器Burning Unit31. 弦外排污阀Overboard discharge Valve32. 压缩空气系统COMPRESSED AIR SYSTEM33. 主空压机Main Air Compressor34. 辅空压机Aux. Air Compressor35. 应急空压机Emergency Air Compressor三、电气设备1. 发电机组(≥50kV A)Electric generator set2. 发电机(≥50kV A)Electric generator3. 应急发电机组Emergency generator set4. 应急配电板Emergency switchboard5. 主配电板Main switchboard6. 轮机自动化系统(控制、监测、报警)Automation of the machinery(Control, Monitoring, Alarm)7. 机舱集中控制台Engine room centralized control panel8. 驾驶集中控制台Bridge centralized control panel9. 分配电箱Electrical distribution box10. 锚机Anchor windlass11. 主机遥控系统M.E. remote control system12. 自动化机舱安全和报警系统Safety system for automation of the machinery13. 自动化机舱安全和报警系统Alarm system for automation of the machinery14. 车钟Telegraph15. 水渗漏检测报警系统和传感器Water leakage detection system and sensor16. 液位监测系统Level gauging system(and sensors)17. 电力推进电机和控制装置Electric propulsion motor and control apparatus18. 货舱进水报警系统Cargo hold flooding alarm system19. 组合声光报警灯板(箱)Audible and visual group alarm panel20. 岸电箱Connecting box for Land-use power21. 电罗经Gyro compass22. 电罗经复示器Gyro repeaters23. 雷达Radar24. 自动雷达标绘仪Automatic radar plotting aid(ARPA)25. 船令广播系统Public address system26. 自动识别系统Automatic identification system(AIS)27. 航行数据记录仪V oyage data recorder(VDR)28. 综合驾驶台系统Integrated bridge system(IBS)29. 综合航行系统Integrated navigation system(INS)30. 国际海事卫星船舶地面站Ship earth station(SES)31. 通用紧急报警系统General alarm systembrake drum 刹车卷筒brake hydraulic cylinder 制动液压缸brake hydraulic pipe 刹车液压管breadth extreme 最大宽,计算宽度breadth moulded 型宽breakbulk 件杂货breasthook 艏肘板bridge 桥楼,驾驶台bridge console stand 驾驶室集中操作台BSRA 英国船舶研究协会buckle 屈曲buffer spring 缓冲弹簧built-up plate section 组合型材bulb plate 球头扁钢bulbous bow 球状船艏,球鼻首bulk carrier 散货船bulk oil carrier 散装油轮bulkhead 舱壁bulwark 舷墙bulwark plate 舷墙板bulwark stay 舷墙支撑buoy tender 航标船buoyant 浮力的buoyant box 浮箱Bureau Veritas 法国船级社butt weld 对缝焊接butterfly screw cap 蝶形螺帽buttock 后体纵剖线by convention 按照惯例,按约定cable ship 布缆船cable winch 钢索绞车CAD(computer-aided design) 计算机辅助设计CAE(computer-aided manufacturing) 计算机辅助制造CAM(computer-aided engineering) 计算机辅助工程camber 梁拱cant beam 斜横梁cant frame 斜肋骨cantilever beam 悬臂梁capacity plan 舱容图CAPP(computer –aided process planning) 计算机辅助施工计划制定 capsize 倾覆capsizing moment 倾覆力臂captain 船长captured-air-bubble vehicle 束缚气泡减阻船cargo cubic 货舱舱容,载货容积cargo handling 货物装卸carriage 拖车,拖架cast steel stem post 铸钢艏柱catamaran 高速双体船catamaran 双体的cavitation 空泡cavitation number 空泡数cavitation tunnel 空泡水筒center keelson 中内龙骨centerline bulkhead 中纵舱壁centroid 型心,重心,质心,矩心chain cable stopper 制链器 chart 海图charterer 租船人chief engineer 轮机长chine 舭,舷,脊chock 导览钳CIM(computer integrated manufacturing) 计算机集成组合制造circulation theory 环流理论classification society 船级社cleat 系缆扣clipper bow 飞剪型船首clutch 离合器coastal cargo 沿海客货轮cofferdam 防撞舱壁combined cast and rolled stem 混合型艏柱commercial ship 营利用船commissary spaces 补给库舱室,粮食库common carrier 通用运输船commuter 交通船compartment 舱室compass 罗经concept design 概念设计connecting tank 连接水柜constant-pitch propeller 定螺距螺旋桨constraint condition 约束条件container 集装箱containerized 集装箱化contract design 合同设计contra-rotating propellers 对转桨controllable-pitch 可控螺距式corrosion 锈蚀,腐蚀couple 力矩,力偶crane 克令吊,起重机crank 曲柄crest (of wave) 波峰crew quarters 船员居住舱criterion 判据,准则Critical Path Method 关键路径法cross-channel automobile ferries 横越海峡车客渡轮cross-sectional area 横剖面面积crow’s nest 桅杆了望台cruiser stern 巡洋舰尾crussing range 航程cup and ball joint 球窝关节curvature 曲率curves of form 各船形曲线cushion of air 气垫damage stability 破损稳性damper 缓冲器damping 阻尼davit arm 吊臂deadweight 总载重量de-ballast 卸除压载deck line at side 甲板边线deck longitudinal 甲板纵骨deck stringer 甲板边板deck transverse 强横梁deckhouse 舱面室,甲板室deep v hull 深v型船体delivery 交船depth 船深derrick 起重机,吊杆design margin 设计余量design spiral 设计螺旋循环方式destroyer 驱逐舰detachable shackle 散合式连接卸扣detail design 详细设计diagonal stiffener 斜置加强筋diagram 图,原理图,设计图diesel engine 柴油机dimensionless ratio 无量纲比值displacement 排水量displacement type vessel 排水型船distributed load 分布载荷division 站,划分,分隔do work 做功dock 泊靠double hook 山字钩double iteration procedure 双重迭代法double roller chock 双滚轮式导览钳double-acting steam cylinder 双向作用的蒸汽气缸down halyard 降帆索draft 吃水drag 阻力,拖拽力drainage 排水draught 吃水,草图,设计图,牵引力dredge 挖泥船drift 漂移,偏航drilling rig 钻架drillship 钻井船drive shaft 驱动器轴driving gear box 传动齿轮箱driving shaft system 传动轴系dry dock 干船坞ducted propeller 导管螺旋桨dynamic supported craft 动力支撑型船舶dynamometer 测力计,功率计e.h.p 有效马力eccentric wheel 偏心轮echo-sounder 回声探深仪eddy 漩涡eddy-making resistance 漩涡阻力efficiency 供给能力,供给量electrohydraulic 电动液压的electroplater 电镀工elevations 高度,高程,船型线图的侧面图,立视图,纵剖线图,海拔empirical formula 经验公式enclosed fabrication shop 封闭式装配车间enclosed lifeboat 封闭式救生艇end open link 末端链环end shackle 末端卸扣endurance 续航力endurance 续航力,全功率工作时间engine room frame 机舱肋骨engine room hatch end beam 机舱口端梁ensign staff 船尾旗杆entrance 进流段erection 装配,安装exhaust valve 排气阀expanded bracket 延伸肘板expansion joint 伸缩接头extrapolate 外插fair 光顺faised floor 升高肋板fan 鼓风机fatigue 疲劳feasibility study 可行性研究feathering blade 顺流变距桨叶fender 护舷ferry 渡轮,渡运航线fillet weld connection 贴角焊连接fin angle feedback set 鳍角反馈装置fine fast ship 纤细高速船fine form 瘦长船型finite element 有限元fire tube boiler 水火管锅炉fixed-pitch 固定螺距式flange 突边,法兰盘flanking rudders 侧翼舵flap-type rudder 襟翼舵flare 外飘,外张flat of keel 平板龙骨fleets of vessels 船队flexural 挠曲的floating crane 起重船floodable length curve 可进长度曲线flow of materials 物流flow pattern 流型,流线谱flush deck vessel 平甲板型船flying bridge 游艇驾驶台flying jib 艏三角帆folding batch cover 折叠式舱口盖folding retractable fin stabilizer 折叠收放式减摇鳍following edge 随边following ship 后续船foot brake 脚踏刹车fore peak 艏尖舱forged steel stem 锻钢艏柱forging 锻件,锻造forward draft mark 船首水尺forward/afer perpendicular 艏艉柱forward/after shoulder 前/后肩foundry casting 翻砂铸造frame 船肋骨,框架,桁架freeboard 干舷freeboard deck 干舷甲板freight rate 运费率fresh water loadline 淡水载重线frictional resistance 摩擦阻力Froude number 傅汝德数fuel/water supply vessel 油水供给船full form 丰满船型full scale 全尺度fullness 丰满度funnel 烟囱furnishings 内装修。
