Valve box, in TS, Valve manifold, in DS Tail threading 阀箱,在引纸器TS;
8
© Metso
Valve box, in TS Rope stretcher 阀箱,在TS引纸绳 张紧器处
Water system 水系统
NDPM3R
Valve box, in TS ValSizer 阀箱,在施胶机FS
NDPM3R Paper machine dry end 纸机干部示意图
Electri IR dryers 电红外干燥器
DG9 DG11 十一组烘缸 DG10
PowerDry 强力热风干燥
TurnFloat 转向风辊
DG7-8wenku.baidu.com
ValSoft 软压光
ValCoat Jet 1 & 2 涂布机1&2
ValSizer 施胶机
OptiHard 硬压光
4
© Metso
Main dimensions and production data 主要生产技术参数及范围
NDPM3R Paper machine
• Paper grades纸种 • Basis weight range 定量范围
-
Coated white top liner, coated board, white top liner 涂布白面牛卡,涂布白板,白面牛卡
Coated white top liner涂布白面牛卡 140 g/m2 – 200 g/m2 Coated board涂布白板 175 g/m2 – 250 g/m2 Uncoated white top liner白面牛卡 126 g/m2 – 175 g/m2
Coated white top liner涂布白面牛卡 top side面层, solid contents固含量 10 % back side底层, solid contents固含量12 % Coated board涂布白板 top side coating面层涂布, solid contents 固含量62 % back side底层, solid contents固含量12 % White top liner (uncoated)白面牛卡(未涂布) top side面层, solid contents 固含量10 % back side底层, solid contents固含量12 % 挂胶量 1 g/m² 3 g/m² 8 g/m² 3 g/m² 1 g/m² 3 g/m²
涂布量
16 g/m² 14 g/m² 15 g/m² 13 g/m²
• Web width 纸幅宽度
- Wire width 网宽 - Trim at reel (min) 卷取宽度(最小) - Trim of winder 复卷机宽度 • Design speed 设计车速
6
© Metso
Hydraulics 液压系统
• Sizing 施胶
5
© Metso
Main dimensions and production data
NDPM3R Paper machine
• Coating 涂布
Coated white top liner, ValCoat Jet 1, top side, solid contents 62 % 涂布白面牛卡,涂布机1#,面层,固含量62% Coated white top liner, ValCoat Jet 2, top side, solid contents62 % 涂布白面牛卡,涂布机2#,面层,固含量62% Coated board, ValCoat Jet 1, top side, solid contents 62 % 涂布白板,涂布机1#,面层,固含量62% Coated board, ValCoat Jet 2, top side, solid contents 62 % 涂布白板,涂布机2#,面层,固含量62% 5 950 mm 5 490 – 5 560 mm 5 440 – 5 500 mm 1 150 m/min
Hydraulic unit 液压单元 - ValSizer 施胶机 - ValCoat Jet 1-2 涂布机1&2 - Coating section 涂布段
Hydraulic unit 液压单元 - OptiHard 硬压光
7
© Metso
Pneumatics气动 Valve box, in TS El.infra retraction 阀箱,在红外TS Valve box, in DS Fabric stretching 阀箱, 在DS干网张紧器处 Valve box, in TS ValCoat Jet 1 阀 箱,在1# 涂布机 TS Valve box, in DS Fabric stretching
Delivery scope 供货范围
Metso Järvenpää
• PM dry end 纸机干部
OptiHard 硬压光机 ValSizer 施胶机 ValCoat Jet 涂布机 After-dryer section 后烘干部 ValSoft thermo roll oil heating 软压光及热辊油系统 Dry end tail threading 干部引纸
Valve box, in fan room Airdryers 阀箱,在热风 干燥器风机房 Valve manifold, in TS Tail threading 阀箱, 在TS引纸器处
Valve box, in TS, Valve manifold, in DS Tail threading 阀箱,在引纸器TS;
Valve panel, in TS OptiHard 阀板,在 硬压光TS
Valve box, in TS Rope stretcher 阀箱, 在引纸绳张紧器TS Valve box, in TS, Valve manifold, in DS Tail threading 阀箱,在引纸器TS
Valve box, in TS Fabric guiding 阀箱,在TS干网导 辊处
2
© Metso
Dongguan Nine Dragons Paper Industries Co., Ltd.
NDPM3R Paper machine rebuild PM3纸机改造
• Old machine 改造前
• New machine 改造后
3
© Metso
Dongguan Nine Dragons Paper Industries Co., Ltd.
Valve box, in TS Rope stretcher 阀箱,在TS引纸绳 张紧器处 Valve box, in TS+DS Electric infra Websafe 阀箱,在TS和DS的电红外干 燥箱
Valve box, in TS Fabric guiding 阀箱,在TS干网导 辊处
Valve box, in DS ValCoat Jet 2 电磁阀箱,在2#涂 布机DS Valve panel, in TS Air dryers 阀板, 在热风干燥箱TS Valve box, in DS ValCoat Jet 1 电磁 阀箱,在1#涂布机 DS
Valve panel, in TS ValSizer 阀板,在 施胶机TS Valve panel, in TS Air dryer 阀板,在 热风干燥箱TS Valve panel, in TS OptiHard 阀板,在 硬压光机TS
Temperature control unit rolls 施胶辊温度控制单元 Temperature control unit bottom beam 底层施胶梁温度控制单元 Temperature control unit top beam 面层施胶梁温度控制单元
9
© Metso
Valve box, in TS ValSizer 阀箱,在施 胶机TS
Valve box, in DS Fabric stretching 阀箱,在干网张紧器DS
Valve box, in TS ValCoat Jet 2 阀箱,在 2#涂布机TS
Valve manifold, in TS Tail threading 阀箱,在TS引纸器处
Machine layouts and technical data 纸机布置与技术参数
OptiHard calender 硬压光 ValSizer and sizing section 施胶机 ValSoft heating system 软压光及热油系统 ValCoat Jet and coating section 喷射涂布机 NDPM3R
