MOXA 无线通讯模块
无线通讯在自动仓库中的应用
无线通讯在自动仓库中的应用目前，在自动化立体仓库中，自动化设备以独立单元的方式进行工作。
自动化单元之间多数采用红外通讯器，以Profibus 总线方式进行数据传输。
计算机通过西门子CP5613 通讯卡读写PLC的数据，在速度上传输率低（187.5K）、通讯节点多，出现问题后维修复杂。
而采用无线通讯时，以太网的速度高（56M），由于通讯单元减少，出现问题能够快速判断问题所在，同时还具有费用低、安装方便、维修简单等优势。
设计规划某自动化立体库项目有5个巷道，2500个货位，项目设计1台堆垛机和1台直线转轨车用于5个巷道货位的货物存取，堆垛机通过转轨车切换到其他巷道。
堆垛机与转轨车、计算机的通讯采用无线基站互联。
堆垛机主机采用S7-200 PLC，通讯模块选取CP243-1，无线通讯基站采用MOXA AWK-1100。
基站固定在堆垛机上，随堆垛机移动。
转轨车主机采用S7-300PLC，通讯模块选取CP343-1，无线通讯基站采用MOXA AWK-1100。
基站固定在转轨车上，随转轨车移动。
RF系统采用Symbol的MC3000手持终端，RF通过Symbol AP5131访问SQL服务器。
OPC Server计算机通过基站AP5131、AWK-1100访问堆垛机和转轨车的PLC数据。
AP5131固定在库房区域中心的货架顶部，堆垛机、转轨车、手持终端的运行轨迹相对在AP5131的半径100米内，确保良好的通讯效果。
设备配置1．无线通讯基站配置堆垛机、转轨车以AWK-1100作为通讯基站，通过AP5131互相通讯，且OPC Server计算机通过AP5131、AWK-1100访问堆垛机和转轨车的PLC数据，RF也通过AP5131访问SQL服务器。
配置原则是AP5131作为无线网桥，AWK-1100做客户端。
配置完成后，用操作系统的Ping命令能够测通网络，证明配置成功完成。
OPC Server计算机要访问S7-200、S7-300的数据，必须对S7-200、S7-300进行组态配置，才能实现数据传输。
