压力开关文档

合集下载

压力开关作业指导书范本

偏差不超过名义值的±3mm水柱
6
温度循环试验
高温125±5℃，低温-15±5℃，进行2次循环，每次暴露时间12小时,转换持续时间最多5min，试验后恢复1小时
压力切换值变化不超过±3mm水柱
7
恒定湿热
试验温度保持40±2℃、相对湿度93%±3%，放置48小时后，在恒温箱中(或箱外5min内)做电气强度测试
压痕直径≤2mm
非金属件不起火或起火后30秒内熄灭(第一次送样或更换厂家时测试)
结论
备注
编制/日期：批准/日期：
无击穿和闪络
4
端子强度
端子应能承受轴向80N，其它方向20N的力，具体操作按GB5095.8试验16f规定进行
开关无断裂、变形、位移或零件松动
YF/XWJ-JG12-2001
5
切换压力
1、将压力开关安装在工装上使其动作,记录动作、复位值，取5次测试的平均值
2、压力开试条件
判定基准
参见标准
1
接触电阻
将压力开关安装在工装上使其动作,在200mA/DC条件下测试
≤50mΩ
2
绝缘电阻
施加500V DC/1分钟测量
1、所有开路端子之间
2、端子与外壳之间
≥100MΩ
≥100MΩ
YF/XWJ-JG12-2001
3
耐压
1、两开路端子之间：1250VAC
2、端子与外壳之间：3750VAC
绝缘电阻≥10MΩ
电气强度满足第4项要求
8
盐雾试验
盐雾箱中,5%的盐水，35±2℃ 48小时，测试结束后用冷水冲洗表面至表面干净
其金属表面不得出现2个以上的锈点或斑痕，且锈点或斑痕面积不大于1平方毫米

smc-数字式压力开关-使用说明书

文件No.PS※※-OMS0006CN-G数字式压力开关ZSE20(F)ISE20安全注意事项2型式表示・型号体系8产品各部位名称及功能10用语说明11安装·设置14设置方法14配管方法16配线方法18设定概要[测量模式] 20 压力设定21 3步设定模式22 简易设定模式24功能选择模式26功能选择模式说明26出厂设定26 F0 单位切换功能28 F1 OUT1的设定29 F3 数字滤波器的设定32 F4 自动预设功能的设定33 F6 显示值微调的设定35 F10 子画面的设定36 F11 显示分辨率的设定41 F80 省电模式的设定42 F81 密码输入的设定43 F82 线名输入的设定45 F90 全功能的设定46 F98 输出确认48 F99 恢复出厂设置49其他设定50维护54忘记密码的场合54故障一览表55规格62规格表62外形尺寸图64安全注意事项此处所示的注意事项是为了确保您能安全正确地使用本产品，预先防止对您和他人造成危害和伤害而制定的。

这些注意事项，按照危害和损伤的大小及紧急程度分为「注意」「警告」「危险」三个等级。

无论哪个等级都是与安全相关的重要内容，所以除了遵守国际规格(ISO/IEC)、日本工业规格(JIS)*1)以及其他安全法规*2)外，这些内容也请务必遵守｡*1) ISO 4414: Pneumatic fluid power -- General rules relating to systemsISO 4413: Hydraulic fluid power -- General rules relating to systemsIEC 60204-1: Safety of machinery -- Electrical equipment of machines (Part 1: General requirements)ISO 10218: Manipulating industrial robots-SafetyJIS B 8370: 空气压系统通则JIS B 8361: 油压系统通则JIS B 9960-1: 机械类的安全性-机械的电气装置（第1部：一般要求事项)JIS B 8433: 产业用操作机器人-安全性等*2) 劳动安全卫生法等注意误操作时，有人员受伤的风险以及物品破损的风险｡警告误操作时，有人员受到重大伤害甚至死亡的风险。

压力开关说明7页

操作手册压力继电器（压力开关）YSJ-340系列一、概述YSJ-340系列压力继电器是一种超小型压力控制仪表，用于液压、气动系统的压力显示与控制，可替代德国贺德克HYDAC(贺德克)EDS300系列压力继电器。

该仪表采用了高精度压力传感器，电路部分以高性能单片机微处理器为核心，具有3位LED数字显示及轻触开关输入的人机界面、具有开关量（报警）输出及4～20mA模拟输出，是在机械继电器无法胜任的条件（如压力剧烈波动、强环境振动、高精度高速度控制、小体积等）下可靠工作的理想选择。

二、性能指标◇测量范围：0～1.6—0～60MPa◇电源电压：16～36VDC◇输出信号：（RL≤250Ω）◇接口螺纹：G1/4◇环境条件：环境温度：-20℃～60℃介质温度：:-20℃～80℃存储温度:-40℃～125℃相对湿度：0～80%耐冲击：≤50g/ms耐振动：≤10g/（0～500HZ）◇输出信号精度：1.0◇过载压力：1.5%倍满量程压力◇最大功耗：≤3W触点容量：24VDC/1.2A（MAX）三、功能根据不同型号，装置可提供下列功能◇三位显示当前压力（正常工作）◇按压力、预设开关点输出开关量◇输出模拟量◇基本设定菜单◇提供四种不同输出模式：◇YSJ341带1路开关量输出（负载最大电流1.2A，无模拟量输出）◇YSJ342带2路开关量输出（负载最大电流1.2A，无模拟量输出）◇YSJ343带1路开关量输出（负载最大电流1.2A）和1路模拟量输出（4～20mA）◇YSJ344带2路开关量输出（负载最大电流1.2A）和1路模拟量输出（4～20mA）四、安装YSJ340可以通过压力管接头（DIN3852内螺纹G1/4），直接装在液压集成快上。

电气连接必须由国家认定合格的电工操作（参考中国电工国家标准规范）。

压力继电器的外壳必须同时良好的接地。

如安装在液压块里，块体通过液压系统接地时有保证的。

若用微型软管安装，客体必须单独接地。

ASCO S-SERIES压力开关说明书

14Features:• Set point repeatability, +1% of operating range.• All wiring terminals, adjustments and visual scales are accessible from the front of the switch.• Choice of general purpose, watertight or explosion-proof enclosures.• Choice of fixed or full-range adjustable deadband.• Choice of single or two-stage units.• Manual reset units available.• Mounts in any position.• Rugged and vibration resistant.• Visual adjustment scales in psi and bars.• External adjusting nuts.• Separate electrical, pressure and adjusting chambers.• Wide selection of transducer wetted materials suitable for air, water, oil or corrosive fluids.• Mix and match switch and transducer components for increased stock flexibility or to change pressure ranges in field.General Description:ASCO S-Series pressure switches consist of a switch unit and a transducer unit.They can be orderedseparately for customer stocking and/or field assembly or as a complete factory-assembled unit.SwitchS-Series pressure switch units incorporate the unique ASCO TRI-POINT alternating fulcrum balance plate to control the operation of one or more electrical snap-action swtiches.The electrical snap-action switchtogether with the adjusting mechanism is a fully-tested,self-contained subassembly.TransducerT ransducer unit incorporates a diaphragm/piston type pressure sensor, and is also a fully-tested, self-contained subassembly.OperationWhen pressure is applied to the transducer it is converted into movement of the piston.This pistonmovement is then used to control the operation of the electrical snap-action switch in the switch unit.Standard Electrical RatingsSwitches for Pressure to 8000 psig, Vacuum, or Differential with General Purpose, Watertight or Explosion-Proof EnclosuresStandard Temperature RatingsOptions (See pages 34-35)EnclosuresASCO TRI-POINT S-Series switches are available in three standard enclosures.All of these enclosed units are made in accordance with NEMA and UL standards. General Purpose–Type 1.These enclosures are designed for indoor use to protect personnel from accidental contact with the equipment.S-Series general purpose switch units consist of a copper-free* aluminum die-cast body with a formed copper-free* aluminum cover;two 3/4”conduit hubs with one plug are provided.Watertight–T ype 4.Watertight and dust-tight enclo-sures are intended for use indoors and outdoors to protect the enclosed equipment against splashing or falling water, windblown dust and water, hose directed water, and severe external condensation.S-Series watertight switch units have a copper-free* aluminum die-cast body and a formed copper-free* aluminum cover with Buna “N”gaskets;two 3/4”conduit hubs with one plug are provided.Explosion-Proof–T ypes 7 and 9.T ype 7 enclosures are intended for use in locations defined by the National Electrical Code as Class I.T ype 9 enclosures are intended for Class II locations.Class I locations are those in which flammable gases are or may be present in the air in sufficient quantities to produce explosive or ignitable mixtures.Class I loca-tions are classified by group letter, which defines partic-ular atmospheres.Division 1 locations are areas where the hazardous concentration exists continuously, inter-mittently or periodically under normal operating condi-tions.Division 2 locations are those where the haz-ardous vapors are present only in case of accidental rupture or breakdown of equipment.ASCO TRI-POINT explosion-proof enclosures with letter B, C or D in the fifth position are listed for Class I, Groups B, C, and D, Division 1.They are also suitable for the less stringent Division 2 environment.Class II locations are those which are hazardous because of the presence of combustible dust.All ASCO TRI-POINT explosion-proof enclosures are listed for Groups E, F, and G locations.The switch body and cover are die-cast copper-free* aluminum with a Buna “N”gasket.T wo 3/4”conduit hubs with one plug are provided.Dimensions (inches)* Less than 0.6% copper.1518the maximum1934H-Series, P-Series and S-Series Snap-Action Switch OptionsOptional snap-action switches to meet specific electrical loads or application conditions are available on most ASCO TRI-POINT switch units. Generally, the construction of a switch unit with optional snap-action switches contains other specific parts and may be ordered only as a factory-built unit. To specify a particular optional construction, add the appropriate suffix to the switch unit action switch (suffix “P ”P-SeriesSwitch OptionsPanel Mount –Open frame P-Series compact switch units areavailable for panel mounting with the switch unit inside and the transducer outside. The panel separates the fluid sensing portion from the electromechanical portion. Five holes for bolts and operating stem must be drilled or punched through the panel.Three constructions are available: add the suffix listed below to the switch unit catalog number for the desired thickness.S-SeriesSwitch OptionsIndustrial Adjusting Nut Covers –Available in clear plastic or metal to prevent tampering with set point adjusting nuts.Clear plastic cover:To order, add suffix “1” to the switch unit catalog number, or order separately as SP01.Metal cover:To order, add suffix “2” to the switch unit catalog number, or order separately as SP02.JIC Construction –A switch unit having the electrical and adjusting nut covers attached to the switch body by a chain. Also designed to Type 13specifications. To order, add suffix “3”to the switch unit catalog number, or order separately as SP03.Terminal Block –Applicable to switch units with one single-poledouble-throw switch. The terminal strip is prewired to the snap-action switch. To order, add suffix “4” to the switch unit catalog number, or order separately as SP04.Factory Sealed –Explosion-proof units may be ordered with a factory seal separating the electrical chamber from the conduit hubs and 24” long #14 AWG 105°C. rated lead wires. To order, change the fourth digit of the “3”35Pressure Transducer OptionsP-Series and S-Series Temperature Transducer OptionsSpecial Wetted Materials –The following diaphragms maybe substituted on transducer body materials of aluminum,brass, polyester and stainless steel. To order, substitute the Oxygen Cleaning –Pressure transducers for oxygen serviceshould be specially cleaned. They are degreased and blacklight inspected, then assembled in a clean area and tested with oil-free air or nitrogen. Use metal body transducer with viton or neoprene diaphragm and add suffix “H ”Pressure Snubbers –A pressure snubber (1/4” NPTF by1/4” NPTM) installed in the transducer pressure connection will dampen the pressure spikes to a value which will not cause damage. It consists of a body with a porous metal disc of stainless steel through which the fluid passes. To order,select a snubber compatible with the fluid. Available by seperate catalog number only (see table below).Process Connection –A female process connection (1/4”NPT) is standard on all pressure transducers. A 1/2” NPT is available as an option on gauge pressure transducers. To order, add suffix “B ”Note: Armored Capillaries –Double braided copper armor isstandard for copper capillary units. Stainless steel spiral interlocked armor is available for stainless steel capillary units. Add suffix “C ” to transducer catalog number.Thermal Well –Use with direct or remote sensors forprotecting sensing bulb. This allows removal of bulb while maintaining a pressure-tight vessel. Available in 1/2” NPT or 3/4”NPT process connection in brass or 316 SS. Dimensions are in accordance with SAMA Std. RC17-9. Standard “U ” dimension (insertion length) is 2-1/2” for direct mount and 6’capillary units and is 4-1/2” for 12’capillary units.Longer Capillaries –Standard copper and stainless steelcapillary units can be furnished in 12’lengths. To order, add suffix “D ” to transducer catalog number. Consult ASCO for longer length capillaries.Union Connector –For use with remote units for mountingof bulb in fluid being controlled. Available in 1/2” NPT and 3/4” NPT process connections in brass or 316 SS.Thermal WellJam nuts provided with thermal wells.11Switch Unit – ASCO uses the term “switch unit ” to describe the electromechanical portion of a pressure or temperature switch. This is used in conjunction with a transducer unit to form a complete pressure or temperature switch.Transducer Unit – ASCO uses the term “transducer unit ” to describe that portion of a pressure or temperature switch to which a pressure or temperature is applied which converts the input signal to another form of energy to operate the switch unit.Two-Stage (Dual)– ASCO uses the term “two stage ” todescribe a pressure or temperature switch which is equivalent to two pressure or temperature switches which are independently adjustable. This switch is equivalent to two fixed deadband switches.Deadbands – The deadband is the difference between the set point and reset point readings. Deadbands are listed in the specification tables at nominal values. They are representative of the deadbands of the units at the middle of the range.The deadband values for the full range adjustable deadband switches and limited adjustable deadband switches indicate the values through which the deadband may be adjusted.Generally, as the set point is adjusted through the operating range, the deadband will vary. Normally, it will becomenarrower as the set point is towards the bottom of the range,and will become wider when the set point is towards the top of the range. The graph shown below indicates representative trends of this type of deadband variation.Temperature switch deadbands are a result of the characteris-tics of the vapor pressure curve as well as other factors.Normally, this results in a deadband which is narrower in the top third of the range than in the bottom third of the range.The values published are nominal and representative of mid-range set points.36Accuracy – The maximum deviation from the set point under specified operating condition (ambient temperature,barometric pressure, etc.).Adjustable Deadband – Refers to the capability of apressure or temperature switch to allow the deadband to be adjusted over a given range. Certain ASCO TRI-POINT switches have an adjustable deadband which can be adjusted over the total operating range of the switch.Adjustable Operating Range – The pressure or tempera-ture range of the switch within which the set point may be adjusted.Differential Pressure – The difference between twopressures. A differential pressure switch senses two pressure sources and can be adjusted to actuate on a desired difference between them.Guage Pressure – The actual reading of a typical pressure guage and is the difference between the pressure within a vessel and the atmospheric pressure surrounding it. It is normally measured in pounds per square inch (psig).Manual Reset – The switch is a semi-automatic device which operates automatically with a signal change in one direction but must be manually reset once the signal returns to its original position.Proof Pressure – A pressure which a device can besubjected to for extended periods of time without changes in its operating characteristics.Rated Overrange Temperature – A temperature which a device can be subjected to for extended periods of time without changes in its operating characteristics.Repeatability – The closeness of agreement among a number of consecutive measurements of the output for the same value of input under the same operating conditions approaching from the same direction. Repeatability isnormally specified as a percentage of the upper limit of the operating range.Example: Operating range 5-100 psig with +1%repeatability; equals +1% of 100 psig or +1 psig.Reset Point – After a pressure or temperature switch has reached its set point and operated the electrical switch, it must return to a point called the reset point before the electrical switch can return to its original position.Set Point – The pressure reading at which the electrical switch element changes contact position (it can be specified either increasing or decreasing).DefinitionsDeadbands1.5 x Catalog Value Catalog Value Half Catalog ValueBottom Mid TopPosition of Set Point in Range37These recommendations are to be used as a guide only, as service life of material is dependent on temperature, concentrations, or catalysts that may be added and other conditions which are beyond our control.Consult ASCO for specific service applications.Note:Items in black circles are standard catalog units.All others available on factory order.P - Indicates preferred construction. S - Indicates satisfactory construction.Transducer Material Code of Two Digits represents process connection material and diaphragm material, respectively; these are the sixth and seventh positions of the pressure transducer catalog number.Process Connection: 6th Position Diaphragm: 7th Position 1 Aluminum 4 316 S.S. 1 Buna “N ” 4 316 S.S.2 Brass 7 Nylon/Brass2 Viton6 Ethylene Propylene 3 303 S.S.3 Neoprene7 FluorosiliconeFluid Compatibility GuideFor high purity applications use stainless steel transducers.Notes:1Oxygen service requires special cleaning, specify suffix “H ”.2For steam service a condensate loop (pigtail) is required.3For pressure transducers for combustion service see pages 20-23.4Material availability refers to standard gauge pressure constructions only.5。

F-Series 压力开关说明书

INTRODUCTIONThe F-Series pressure switch is a precision built U.L.and CSA approved control device which features a single or dual SPDT, hermetically sealed mechanical snap-action switch.Several wetted material constructions for compatibil-ity with pressure media may be obtained.Series FP-S switches have a fixed deadband which will be within the limits noted on the nameplate.MOUNTINGThe F-Series snap-action pressure switch has an anodized aluminum body and conduit fitting with a 316 stainless steel pressure port.T wo holes in the body are used to surface mount the control.Location of the holes is shown on the general dimension drawings.Mount on a vibration free surface in any orientation.When tightening control to pressure line, always use the hex on the pressure connection.NEVER TIGHTEN BY TWISTING THE BODY ORTHE CONDUIT HEX.ADJUSTMENT OF SETPOINTA single setpoint adjustment nut is located centrally inside the cover of the body.Align bottom of adjustment nut slot with scale for approximate pressure setting.The adjustment nut is locked in place with a set screw located centrally in the body below the adjustment nut.A5⁄64˝Allen wrench is used to adjust the set screw.For accurate setpoint calibration use Ashcroft A TE-100 handheld calibrator with a pump, or Ashcroft 1305 dead-weight gauge tester.As received, the pressure switch will normally be set to approximately 90% of the indicated range.Pressurize the system to the required setpoint and turn the adjustment nut until switch changes mode.When the setpoint has been achieved raise and lower pressure to ensure that setpoint is correct.After installation of the control replace cover to protect internal parts from the environment.ELECTRICAL CONNECTIONThe F-Series switch is available in SPDT or (2) SPDT circuit.Wire leads (18˝) are provided for both switches.STANDARD RANGES30˝ Hg Vac.30, 60, 100, 200, 400, 600, 1000, 3000, 4000 psiSPDT(2) SPDTCommon–White Common–(JJ)White/Black;(LL) White/Green Normally Open– Blue Normally Open– BlueNormally Closed– Red Normally Closed– RedGround– GreenCommon– BlackNormally Open– Blue/BlackNormally Closed– Red/BlackGround– GreenNote:When using a vacuum range switch, the N.C.is blue and N.O.is red. ELECTRICAL RATINGOrder CodeDescription Electrical Rating (Resistive)SPDT DPDT General Purpose:11A 125/250 Vac;5A 30 Vdc J JJ Narrow Deadband:5A 125/250 Vac P N/A Gold Contacts:1A 125 Vac L LL©2007 Ashcroft Inc., 250 East Main Street, Stratford, CT 06614-5145, USA, T el:203-378-8281, Fax:203-385-0499, All sales subject to standard terms and conditions of sale.I&M009-10027-10/00 (250-3112) GBE 2/07 AMR 12/07。

SS-1 压力开关产品说明书

Phone (504) 340-0055Fax(504) 340-0056SS-1 Pressure SwitchModel 4102Model 4102ItemQty.Qty DescriptionMaterial1Spring Spring Ca p 316L or ASTM-A-351 S.S.2A 1Spring (Blue)ASTM-4012B —Spring (Red)ASTM-4012C —Spring (Silver)ASTM-4012D —Spring (Gr een) optional Inconel X-7502E —Spring (Y ellow) ello (Y optional Inconel X-7502F —Spring (Purple) optional Inconel X-750Body For SS-1CF-8M St.Stl.Parts T ube T Acetate Butyrate Lock Ring AISI 316 St.Stl.Panel Mnt.Ring (Optional)AISI 316 St.Stl.Spring Plate AISI 316 St.Stl.8*4Spool O-ring Viton Spool For SS-117-4 PH St.Stl.10*2Shuttle Seal Viton 111Shuttle AISI 316 St.Stl.12*1Spool O-ring Viton 13*2Spool Sleeve Seal Viton 141Spool Spool Sleeve AISI 316 St.Stl.151 1.25”/.50” Piston AISI 316 St.Stl.16*1 1.25” Piston O-ring Viton 171 1.25”/.50”/.25” Base AISI 316 St.Stl.18*1.50” Piston O-ring Viton 191.25” Piston (Optional)AISI 316 St.Stl.20*1.25” Piston Backup eflon eflo T 21*1.25” Piston O-ring Viton 22—Repair Kit * Items Parts T ube ube T Not Supplied With Switches Using 3.0” or .187” Sensor Base.Parts List For Pressure Switch Model SS-11314151617191Repair GENERAL DESCRIPTION: The Ruelco ‘SS-1’ pneumatic pressure switch is a three way block and bleed valve that is operated by pressure acting on a piston opposing an adjustable spring force. It functions as either a normally closed or normally open valve, depending on through which of the two ports the instrument pressure is supplied. These ports are marked as ‘HI IN’ or ‘LO IN’ on the switch body. The output port, marked ‘OUT’ on the switch body, is the same for either mode of operation. Pressure applied to the sense port will cause the valve to operate. The Ruelco ‘SS-1’ pneumatic pressure switch can also be used as a two way bleed only valve in which case one of the ‘HI IN’ or ‘LO IN’ ports is plugged depending on whether the valve is to be used as a high or a low pilot.SS-1Pneumatic Pressure SwitchFEATURES• 316 stainless steel construction (models to N.A.C.E. MR0175 available).• Standard base range 10-10,000 p.s.i. (with 1/4" piston option).• Operating pressure range from .5 to 20,000 psi.• Block-and-bleed 3-way valve.• Holds constant and accurate set points.• Designed for 1% plus or minus repeatability on set points.• Minimum deadband between trip and reset pressure.• Spring may be replaced with instrument and sensing pressure present inthe sensor.• Vent above sensing piston prevents high pressure from entering instru-ment supply should a piston seal leak develop.• Optional tamper proof lock-out device available upon request.Valv V e T ypeT 3 or 2 Way Way Wa Set Point Deviation+1%Deadband 3 Way Way Wa 3% of Range 2 Way y Way Wa 5% of Range Range Max.Instr.Instr Press. 3 Way Way Wa 60 PSI 2 Wa y WayWa 150 PSI Cv Factor Factor Factor 0.160Ambient T emp em T .-20 to 250 deg.F Range -29 to 122 deg.CSwitch SpecificationsSensor T ype T PistonMax.P Oper.Oper ress.10,000 PSI (690 BAR)Burst Pressure 20,000 PSI (1380 BAR)emperatur em T e -20 to 250 Deg.F Range-29 to 122 Deg.C.25”/.50”/.25” 1.25”/.50”/.25” Switch Sensor Specifications * For Switch and 1.25/.50/.25 Sensor Base.A 2.12 (53.8)B (Max) 6.13 (155.7)C 1.32 (33.5)D 1.43 (36.3)E 1.22 (31.0)F 1.82 (46.2)G 1.23 (31.2)H 2.0 (50.8)(50.8)I 1/2” MNPT J1/4” MNPT Panel Mount Hole 1.875 (48.0)Valv V e Ports 1/4” FNPT Weight*Weig W 4.9 lbs.(2.3Kg)Dimensions Inch (MM)ITEM .QTY DESCRIPTION TERIAL TE M A 231Upper Housing 17-4 P .H.P St.Stl.241Piston Assembly17-4 P .H.P St.Stl.251SealViton 26Lower Housing 17-4 P .H.P St.Stl.27—Rep.Kit F/ 3.0” BaseItems 8,10,12,13,253.0" Sensor Base1LWhile this information is presented in good faith and believed to be accurate, Ruelco, Inc. does not guarantee satisfactory results from reliance upon such information. Nothing contained herein is to be construedas a warranty or guarantee, expressed or implied, regarding the performance, merchantability, and fitness with respect to the products. Ruelco, Inc. reserves the right, without notice, to alter or improve the designs or specifications of the products described herein.Ordering Code:4102 X X X X X X X X X 0 X 0 0 0 0BASE MODEL NUMBER Standard Corrosive Service - (-)N.A.C.E.Option - NSPRING CODE (see range chart)PISTON STON PIST CODE (see range chart)ITEM TY .QTY DESCRIPTION TERIAL TE M A 281Retainer Sleeve AISI 316 St.Stl.291.187” Sensor Base 17-4 P .H.P St.Stl.301.187” Piston 17-4 P .H.P St.Stl.311Back -Up RingGlass Filled T efloneflo T 321SealViton3319/16” Gland Nut AISI 316 St.Stl.3419/16” Gland Collar AISI 316 St.Stl.35—Rep.Kit F/ .187” BaseItems 8,10,12,13,31,32.187" Sensor BaseK 2.0 IN.(50.8 MM)L 3.75 IN.(95.2 MM)M 1/2” FNPT Weight*Weig W 8.5 lbs.(3.7 Kg.)* For Switch and 3.0” Sensor BaseSensor T ype T PistonMax.P Oper.Oper ress.20,000 PSI (1380 BAR)Burst Pressure 40,000 PSI (2760 BAR)emperatur em T e -20 to 250 Deg.F Range-29 to 122 Deg.C Sensor T ype T PistonMax.P Oper.Oper ress.5,000 PSI (345 BAR)Burst Pressure 10,000 PSI (690 BAR)emperatur em T e -20 to 250 Deg.F Range-29 to 122 Deg.C N 2.0 IN.(50.8 MM)P 2.57 IN.(65.3 MM)Q 9/16/ M/P Autoclave Weight*Weig W 5.0 lbs.(2.3 Kg.)* For Switch and .187” Sensor BaseSpring Codes (COLOR)ST AN DARD INCONEL SPRING SPRING B (Blue)G (Green)R (Red)Y (Y ello (Y w)S (Silver)P (Purple)Piston Diameter Piston CodeAvailab Avai A le Ranges - PSI (BAR)XXXXXXXXXXXXXXX3.0" 3.0" 3.0" 1.25"1.25"1.25".50".50".50".25".25".25".187".187".187"24.5-20(.03-1.4)4-40(.3-2.75)10-80(.7-5.5)10-115(.7-7.9)20-230(1.4 - 15.8)50-450(3.4 -31)200-750(13.8-51.8)500-1500(34.5-103.5)1000-3000(69-207)1000-3000(69-207)2000-5000(138-345)5000-10000(345-689)2000-5000(138-345)3500-9000(241-620)8500-20000(586-1380)1112233344OPTIONAL BASEOPTIONAL PISTONOPTIONAL BASESS SeriesPressure Switches SS-1 High Flow SS-2 Standard SS-2 High Flow(Pneumatic or Hydraulic)SS-1 Differential SS-2 Differential SS-4 Hydraulic BleedSS-E Electric SS-E Electric DifferentialSS-1 With Optional ScaleModel 4103SS-1 With Optional Scale Model 4103。

《压力开关说明书》word版

DG型气体压力开关使用说明书●请阅读和保持一个安全的地方解释符号●, 1, 2, 3 ... = 功能➔ = 用法说明所有工作必须在阅读操作说明后才能进行！警告！不正确的安装、调整、修改、操作或维护可能导致伤害或物质损失。

使用前先阅读说明书。

这个单位必须安装依照本条例的实施。

标准声明We, the manufacturer, hereby declare that the products DG.., marked with product ID No. CE 0085AP0467, comply with the essential requirements of the following Directives:– 90/396/EEC in conjunction with EN 1854,– 73/23/EEC in conjunction with the relevant standards.The relevant products correspond to the type tested by the notiﬁed body 0085. Comprehensive quality assurance is guaranteed by a certiﬁed Quality System pursuant to DIN EN ISO 9001 according to annex II, para-graph 3 of Directive 90/396/EEC.Elster Kromschröder GmbH, Osnabrück测试➔电源电压、环境温度和外壳——看类型的标签。

➔最大介质温度:-15 + 80°C。

在系统暴露于更高的热应力、热设备上时压力开关必须安装在上游。

DG..B型➔正压时1号位置为进气DG..U型, DG..H型, DG..N型➔正压时1号或者2号位置为进气，气体为空气、天然气或者烟气（其他位置密封），通风时气体从3号或者4号位置离开。

NI-223E 压力开关说明书

使用说明书NI-223E版本：8 04/20COMPACT DIFF. PRESSURE SWITCHES SERIES DC & DE本手册提供的所有数据、声明和建议均基于我们认为可靠的信息。

由于有效使用条件超出了我们的控制范围，我们的产品销售条件是用户在遵循我耐候且本质安全：DC 系列隔爆：DE 系列高压接头 B 低压连接 C 电缆入口重量 5.4 kg 尺寸单位：mm 高压接头B 低压连接C 电缆入口重量 5.4 kg 尺寸单位：mm对于表面安装，使用四个M6螺钉。

注意：除非在认证图纸上标注，否则尺寸和重量不是强制性的。

注意•在安装、使用或维护仪表之前，有必要阅读并理解随附说明手册中给出的说明。

•仪表必须由有资质人员安装和维护。

• 只有在检查仪表特性是否符合工艺和设备要求后，才能进行安装 • 仪器的功能特点及其防护等级显示在固定在外壳上的标识牌上。

内容：1. 一般说明2. 工作原理3. 型号代码4. 标识牌和标记5. 设定值调节6. 设定值校准7. 仪表管道8. 安全完整性等级（SIL ）安装要求9. 安装和连接 10. 投入运行 11. 目视检查 12. 功能验证 13. 停止和拆卸 14. 处置 15. 故障排除在危险环境中使用的安全说明。

压力开关安全使用建议。

使用说明书NI-223E版本：8 04/201.一般说明1.1前言系列或型号的错误选择以及不正确的安装会导致故障并缩短仪器寿命。

不遵守本手册中给出的指示可能会对仪表、环境和人员造成损害。

1.2允许的超量程压力可超过工作范围，前提是其保持在仪器特性（真空或设计压力）中规定的范围内。

超过工作范围的连续差压可应用于仪表，前提是仪表特性中明确说明了这些压力。

不得超过技术规范和额定值中规定的电流和电压值。

短暂的超量程会对开关产生破坏性影响。

1.3机械振动一般会导致仪器某些部件的磨损或引起误启动。

因此，建议将仪器安装在没有振动的地方。

压力开关规格书(一)

压力开关规格书(一)压力开关规格书是一种文档，其中包含压力开关的特性、性能和规格的详细说明。

这份规格书通常由生产商为了向用户提供规范指导而编写。

在该文档中，金属行业、塑料制品行业、压缩空气行业等生产压力开关的行业都有相关的规格书。

下面将对压力开关规格书进行详细说明。

一、压力开关的基本定义压力开关是一种控制装置，能够检测载荷、流量、液位、压力等物理量中的一个或多个，并把信号转换为开关量输出。

压力开关广泛应用于各种工业流程中，被称为“工业大脑”。

二、压力开关规格书的组成1. 压力开关名称和描述。

这通常包括该开关的品牌、型号、描述、颜色和特殊标志等信息。

2. 压力开关的性能。

这包括开关的操作范围、传感器类型和信号输出等，并对每个参数进行详细说明。

3. 压力开关的物理规格。

这包括尺寸、外形、材料、连接方式和重量等，并对每个参数进行详细说明。

4. 压力开关的环境条件。

这包括开关操作和存储的环境条件，包括温度、湿度、振动、冲击和防护等，并对每个参数进行详细说明。

5. 压力开关的安装和维护。

这包括将开关安装到应用设备上所需的步骤以及保养与维护，还要提供相应的图片和维护指导。

6. 压力开关的技术支持。

开关生产商通常会提供技术支持服务，例如培训、现场调整和应用工程师的支持等。

三、压力开关规格书的使用场景工业流程控制是压力开关主要的使用场景。

压力开关可以帮助生产制造商在各种流程控制应用中保证高效和可靠的操作。

下面是一些典型的应用场景：1. 压缩空气系统使用压力开关来控制空气压力。

2. 自动喷水灭火系统使用压力开关来感应水压并控制水流量。

3. 蒸汽锅炉使用压力开关来监测锅炉的蒸汽压力，并通过开关控制燃烧器的燃气流量。

4. 汽车发动机同样使用压力开关来监测发动机的空气流量和温度，以帮助发动机顺畅运转。

总体来看，压力开关规格书是一个非常有用的文档，可以帮助用户了解压力开关的特性、性能和规格，进而正确合理地使用它们。

因此，对于那些需要使用如此设备的人来说，他们应该了解什么是压力开关规格书，以及如何使用它们来达到自己的需求。

《压力开关说明》.(DOC)

电气连接必须由国家认定合格的电工操作（参考中国电工国家标准规范）。

压力继电器的外壳必须同时良好的接地。

如安装在液压块里，块体通过液压系统接地时有保证的。

若用微型软管安装，客体必须单独接地。

数字式压力开关ISE50资料

-3-
No.PS※※-OMF0011CN-A
■安装使用上的希望进行数字式压力开关的设计·选定·安装使用时，请遵守下述的内容。 ●关于设计·选定方面
请遵守下述与安使用相关的安装·配线·使用环境·调整·使用·维护保养等方面的内容。 ○产品规格 ·由于产品不同使用的流体也不同，因此必须确认产品规格。
· 原子能发电站的主机控制系统，原子能设施的安全保护系统，以及其他安全上的重要的系统和体系。 · 集团运输体系的操作控制系统和航空管制控制系统 · 直接与饮料·食品相接触的机器･装置
* 3：特别的考虑是指，与本公司进行充分的商议，以构筑安全的系统(误操作处理功能设计、安全保障设计、冗余设计等)。
● 为了防止本产品由于环境疲劳（时效）等原因所发生的故障·误动作而引起的危害·损害，请实施具有安全性及保全性的特别的考虑(*4)。
■标记的说明表示
意义
警告误操作时，可能会造成使用者重伤甚至死亡的危害程度。
注意 *１
*２
误操作时，有使用者被伤害的可能性，或者有物品损害的可能性。
＊1：伤害是指，受伤、烫伤及触电等，不需要住院治疗或长期检查的受伤程度。
＊2：物品损害是指，涉及到房屋、财产等的损害。
■图形记号的说明图形记号
意义
禁止（绝对不可以）。具体的禁止内容在图形记号中或者图形记号附近，用图和文字揭示。
刚接通电源后，会发生显示部的零点漂移，范围在±1％F.S.以内。显示会因静电等干扰而变化。
○维护保养 ·维护保养时，应切断电源，停止供气，排除掉配管中的残余压缩空气，确认处于大气开放状态后进行。
否则有可能造成系统构成机器无目的的误动作。
·请定期实施维护保养。
由于压力开关的误动作，有可能造成系统构成机器无目的的误动作。

安全压力开关说明书

221 Code Process R ange & Temp.(6) Vac 0-600 1000 2000- Material Limits in.H 2O psi psi 3000 °F psi B-Buna N 0 to 150 ● ● ● ● V-Viton 20 to 300 ● ● ● T-Teﬂon 0 to 150 ● ● ● ● S-SS (5)(10) 0 to 300 ● ● P -Monel (5)(10) 0 to 300 ● ● NOTES: 1. Standard switch. 2. D ual switches are 2 SPDT snap-action switches not independently adjustable. 3. Estimated dc rating, 2.5A, 28 Vdc (not UL listed). 4. Estimated dc rating, .4A, 120 Vdc (not UL listed). 5. Available on pressure only. 6. A mbient operating temperature limits –20 to 150°F , all styles. Setpoint shift of ±1% of range per 50°F is normal. Switch calibrated at 70°F reference. 7. Items are wetted by process ﬂuid. 8. Refer to Option Table. 9. O rder Option XUD, stainless steel process connection.10. On differential switches, stainless steel is available in 15, 30, 60 and 90 psid ranges only. Includes Teﬂon O-ring and 316 SS connection. TO ORDER THIS B-SERIES PRESSURE SWITCH:Pressure and Differential Pressure Switches, Watertight Enclosure, Type 400, B-Series • C hoice of actuators, including designs for ﬁre-safe and NACE applications (8)• Readily available • Standard pressure connection materials: Pressure psi ranges - 316L stainless steel Differential psid ranges- Nickel-plated brass (9) of water ranges - Epoxy coated carbon steel B4 - P ressure switch, type 400, watertightenclosure meets NEMA 3, 4, 4X and 13, IP66 requirementsD4 - D ifferential pressure switch, type 400,watertight enclosure meets NEMA 3, 4, 4X and 13, IP66 requirementsThis general purpose Ashcroft ® switch series is ideal for use in virtually all Industrial and OEM applications.• Watertight NEMA 4X enclosure, IP66• Choice of switch elements for all applications, including hermeti-cally sealed• Wide choice of wetted materials, including all-welded Monel or stainless steel• Fixed or limited adjustable deadband• Approved for UL, CSA and FM (8) ratings • Setpoints adjustable from 15-100% of range4 - OPTIONS (See pages 238-239)5 - STANDARD PRESSURE RANGES (See page 235) 3 - ACTUATOR SEAL (7) Order D escription/Maximum Electrical Ratings Code UL/CSA Listed SPDT 20(4) Narrow deadband 15A, 125/250 Vac 21(9) Ammonia service 5A, 125/250 VacHermetically sealed22(3) switch, narrow 5A, 125/250 Vac deadband 23 Heavy duty ac 20A,125/250 Vac15A,125/250/480 Vac 24(1)General purpose 1/2A, 125 Vdc 1/4A, 250 Vdc 25 Heavy duty dc 10A,125/ Vac or dc 1/8HP 125/ Vac or dc 26(4)Sealed environment 15A, 125/250 Vac proof 27 High temp. 300°F 15A, 125/250 Vac 28Manual reset trip 15A, 125/250 Vac on increasing 29 Manual reset trip 15A, 125/250 Vac on decreasing 31 Low level (gold) 1A,125/250 Vac contactsHermetically sealed32 switch, general 11A, 125/250 Vac purpose 5A, 30 Vdc50 Variable deadband 15A,125/250 Vac UL/CSA Listed Dual SPDT (2)We recommend hermetically sealed switch elements for improved reliability. The hermetically sealed switch provides uncompromising contact protection in harsh or corrosive environments. The Ashcroft 400 Series is also approved for installation in Division II hazardous areas when supplied with hermetically sealed contacts.L-recognized component, LOOK FOR THIS AGENCY MARK ON OUR PRODUCTS。

压力开关常识精品文档13页

1、概述压力开关是与电器开关相结合的装置，当到达预先设定的流体压力时，开关接点动作。

主要应用于电厂、石化、冶金行业等工业设备上输出报警或控制信号，在工业领域中有着重要的用途，能预防生产工程中重要装置的损坏，避免了重大生产事故地发生。

2、压力开关主要敏感原件2.1 波登管特点：普通型压力开关均采用此类敏感元件，主要材质由不锈钢、磷青铜等，测量范围广泛，长野的压力开关测量范围从10Pa（CL12）~100MPa（JM11）2.2、波纹管特点：耐久性及耐振性较波登管好，接断差可调范围大，主要材质有不锈钢、磷青铜等，价格相对较高，但可测压力范围较小，最大为15MPa（CB33）2.3膜片、特点：具有出色的耐腐蚀性，主要材质有NBR、氟橡胶等，如CS、CL系列等均采用此类敏感元件。

NBR：汽油、矿物油、苯氟橡胶：热油、蒸汽、空气、无机酸、卤素等3、压力开关的相关术语3.1 精度：表示设备精准程度的值，包括线性度、公差、迟滞、重复性等。

目前长野的压力开关最高精度可达到±0.5%F.S，型号为CB33。

3.2 最大压力（Max.P）：压力范围的最大值。

3.3 满量程（F.S）：压力范围最大值和最小值的差值。

3.4 接断差（死区）：是指开关设定动作值和复位值的差值，例如当设定、值为1MPa，实际复位值为0.9MPa时，接断差为0.1MPa。

3.5 作温度：是指仪器的内部机构、敏感元件等工作时不会发生持续变形的温度范围。

一般压力开关推荐工作温度范围为-5~400C，若介质温度过高时，可考虑加附件虹吸管（灌状），达到降温的目的。

3.6 S.P.D.T（单刀双掷）：由一个常开、一个常闭触点和一个公共端构成。

3.7 D.P.D.T（双刀双掷）：由一个对称的左、右公共端，两组常开、常闭端子构成。

3.8 上限一接点（常开）：压力上升到设定值时，接点动作，回路导通。

3.9 下限一接点（常闭）：亚力下降到设定值时，接点动作，回路导通。
