电子产品承认书样板(英文)

VER 1.0
PAGE1/3
XXX TECHNOLOGY(XXX)CO.,LTD
SPECIFICATION
1.Application This specification applies to DC type solenoid, Part NO.: The models is in line with RoHS. 2.Standard testing conditions 2-1 Environments: Ambient temperature Relative humidity Atmospheric pressure 2-2 Mechanical loading:No load. 2-3 Power:Steady power(Ripple voltage 1 mVrms Max). 2-4 Force testing: (1)Testing methods:plunger testing vertically (reference drawing above) . (2)Testing principle:fixed the load source,move product reciprocating up or down (stroke 0 mm--> 6 mm). 3.Appearance and outline dimensions 3-1 Appearance:Illumination for at(600±200)Lx,the test distance of not less than 300mm visual products can not have surface rust, abrasions cracking or pollution situation. 3-2 Outline dimension:See the attachment Drawing NO: SP-2010000050(Ver.1.0) . 3-3 Customer P/N: XXXXXXXX . 4.Rated power 4-1 Rated voltage (V) 4-2 Rated current (A) 4-3 Rated wattage (W) 4-5 Duty cycle (%) :DC 34 : XX : 210 5 % AT20°C 10 : Intermittent : A :20°C±2°C :65%±5% :1013 mbar XXXXXX .
SPECIFICATION
5.Electronical characteristics 5-1 Pull force: I= XX A apply at 20℃,initial stroke 5-2 Insulation resistance: DC- 500 V Supplied between coil and yoke,value 100 MΩ Min. 5-3 Dielectric strength: AC–1000 V (50/60Hz) supplied between coil and frame for 1 minute, or AC–1200 V (50/60Hz) for 1 sec. 5-4 Temperture rise: DC- XX V Supplied according to Duty cycle XX %(ON XX sec, OFF XX sec), 65 deg Max with resistance method. 5-5 Life: DC- XX V supplied,stroke XX mm, no load , according to Duty cycle XX %. (ON XX sec, OFF XX sec) pulse XX cycle continuously , must be still meeting the requirements in 5-1,5-2,5-3. 5-6 Lead wire strength: 1 Kgf apply following lead wire to lead wire. 5-7 Overall intensity: XXX Kg Min 6.Mark YY.WW XXXXXXXX YY.WW----Year.Week XXXXXXXX----Customer P/N Font:Arial High word: 3mm Color: Black direction for 5 sec, no abnormality happens X mm, X Kgf Min.
It could meet the features of 5-1,5-2,5-3 requirements. 8-5 Operating temperature:-20℃~+40℃. 8-6 Storage temperature：-20℃~+55℃,Humidity Range: 20% ~ 80%. The storage of the appearance is 6 months.
VER 1.0
PAGE3/3
XXX TECHNOLOGY(XXXXX)CO.,LTD
SPECIFICATION
7.Specification or engineering change 7-1 Product specifications make any changes need approve by both side. 8.Reliability test 8-1 Hot storage test: Temperature:80℃±3℃,time:16 hrs. It could meet the features of 5-1,5-2,5-3 requirements. 8-2 Cold storage test: Temperature:-25℃±3℃,time:72 hrs. It could meet the features of 5-1,5-2,5-3 requirements. 8-3 Vibration test: 10~55 Hz,1.52mm 1.5hours for each X,Y,Z axes. It could meet the features of 5-1,5-2,5-3 requirements. 8-4 Moisture test: Temperature:40℃±2℃. Humidty Time :RH 90%~95%. :48 hours.
4-4 DC Resistance (Ω) : XX ± 4-6 Insulation Class 4-8 Coil number (T)
4-7 Coil Diameter (mm) :ΦXX (copper) : XX VER 1.0Leabharlann Baidu
PAGE2/3
XXX TECHNOLOGY(XXXXX)CO.,LTD
