实验一词法分析

实验一词法分析1．实验要求（1）从源程序文件中读取有效字符并将其转换成二元组内部表示形式输出。

（2）掌握词法分析的实现方法。

（3）实验时间4学时。

（4）实验完成后，要提交实验报告（包括源程序清单）。

2．实验内容2.1主程序设计考虑：主程序的说明部分为各种表格和变量安排空间（关键字和特殊符号表）。

id 和ci 数组分别存放标识符和常数；还有一些为造表填表设置的变量。

主程序的工作部分建议设计成便于调试的循环结构。

每个循环处理一个单词；调用词法分析过程；输出每个单词的内部码（种别编码，属性值）。

建议从文件中读取要分析的符号串。

2.2词法分析过程考虑该过程根据输入单词的第一个有效字符（有时还需读第二个字符），判断单词种别，产生种别编码。

对于标识符和常数，需分别与标识符表和常数表中已登记的元素相比较，如表中已有该元素，则记录其在表中的位置，如未出现过，将标识符按顺序填入数组id 中，将三：主流程图如下：四：实验思路（1）我首先把这个单词的种类分成了五类，包括：关键字、标识符、常数、算符、界符。

然后利用状态转换图进行单词的识别（2）对于关键字、算符、界符。

因为这些单词的个数有限。

所以我单独给每个单词一个种别编码。

能够做到每个单词的种别编码是不一样的。

而对于常数和标识符，我先把它们分别单独的作为一类，然后定义一个二维数组，分别存放这个单词的名称和编码。

而这个编码就是这个单词在这个二维数组中的位置；当遇到新的标识符或常数，就把这个单词放入到相应的数组中。

（3）然后构造一个状态转换图的程序。

把每次得到的单词先暂时存放在temp 二维数组中。

然后用这个临时的二维数组去确定这个单词是何种类别五：实验代码using System;using System.Collections.Generic;using ponentModel;using System.Data;using System.Drawing;using System.Linq;using System.Text;using System.Threading.Tasks;using System.Windows.Forms;namespace Word{public partial class Form1 : Form{public Form1(){InitializeComponent();}char[] receive; //从输入得到的源程序char ch; //这是从源程序读取的一个字符string cache; //暂存的单词int index; //记录取到哪个位置了key_word temp; //用来临时存放得到这个单词struct key_word{public string key_name;public int number;}struct num_word{public string num_name;public int number;}struct ID_word{public string ID_name;public int number;}public int num_index;public int ID_index;DataTable dt;private void button1_Click(object sender, EventArgs e){dt = new DataTable();dt.Columns.Add("助记符");dt.Columns.Add("外部编码");dt.Columns.Add("内部编码");dt.Columns.Add("类型");receive = textBox1.Text.ToCharArray();index = 0;num_index = 0;ID_index = 0;;while (index < receive.Length){cache = null;Get_Word();if (temp.number == 1){int i = 0;int flag = 0;if (num_index == 0){Num[num_index].num_name = temp.key_name;Num[num_index].number = num_index;num_index++;}else{for (i = 0; i < num_index; i++){if (Num[i].num_name == temp.key_name){flag = i;break;}}if (i >= num_index){Num[num_index].num_name = temp.key_name;Num[num_index].number = num_index;flag = num_index;num_index++;}}DataRow dr = dt.NewRow();dt.Rows.Add(dr);dr["助记符"] = temp.key_name;dr["内部编码"] = +Num[flag].number;dr["类型"] = "常数";}else if (temp.number == 0){int i = 0;int flag = 0;if (ID_index == 0){ID[ID_index].ID_name = temp.key_name;ID[ID_index].number = ID_index;ID_index++;}else{for (i = 0; i < ID_index; i++){if (ID[i].ID_name == temp.key_name){flag = i;break;}}if (i >= ID_index){ID[ID_index].ID_name = temp.key_name;ID[ID_index].number = ID_index;flag = ID_index;ID_index++;}}DataRow dr = dt.NewRow();dt.Rows.Add(dr);dr["助记符"] = temp.key_name;dr["外部编码"] = temp.number;dr["内部编码"] = ID[flag].number;dr["类型"] = "标识符";}else{DataRow dr = dt.NewRow();dt.Rows.Add(dr);dr["助记符"] = temp.key_name;if (temp.number >= 15 && temp.number <= 30){dr["类型"] = "运算符";}else if (temp.number >= 31 && temp.number <= 40){dr["类型"] = "界符";}else{dr["类型"] = "关键字";}}}this.dataGridView1.DataSource = dt;}key_word[] Key;num_word[] Num;ID_word[] ID;private void Form1_Load(object sender, EventArgs e){index = 0;Key = new key_word[41];Key[0].key_name = "$ID"; Key[0].number = 0; //标识符Key[1].key_name = "$INT"; Key[1].number = 1; //数Key[2].key_name = "int"; Key[2].number = 2; Key[3].key_name = "float"; K ey[3].number = 3;Key[4].key_name = "void"; Key[4].number = 4; Key[5].key_name = "const"; Key[5].number = 5; Key[6].key_name = "if"; Key[6].number = 6; Key[7].key_name = "el se"; Key[7].number = 7;Key[8].key_name = "do"; Key[8].number = 8; Key[9].key_name = "while"; Key[9].number = 9; Key[10].key_name = "scanf"; Key[10].number = 10; Key[11].key_nam e = "printf"; Key[11].number = 11;Key[12].key_name = "return"; Key[12].number = 12; Key[13].key_name = " main"; Key[13].number = 13; Key[14].key_name = "read"; Key[14].number = 14;Key[15].key_name = "+"; Key[15].number = 15;Key[16].key_name = "-"; Key[16].number = 16; Key[17].key_name = "*"; K ey[17].number = 17; Key[18].key_name = "/"; Key[18].number = 18; Key[19].key_name = "%"; Key[19].number = 19;Key[20].key_name = "="; Key[20].number = 20; Key[21].key_name = "=="; Key[21].number = 21; Key[22].key_name = ">"; Key[22].number = 22; Key[23].key_name = "<"; Key[23].number = 23;Key[24].key_name = "!="; Key[24].number = 24; Key[25].key_name = ">="; Key[25].number = 25; Key[26].key_name = "<="; Key[26].number = 26; Key[27].key_na me = "&&"; Key[27].number = 27;Key[28].key_name = "||"; Key[28].number = 28; Key[29].key_name = "!"; K ey[29].number = 29; Key[30].key_name = "<>";Key[30].number = 30;Key[31].key_name = "("; Key[31].number = 31;Key[32].key_name = ")"; Key[32].number = 32; Key[33].key_name = "{"; K ey[33].number = 33;Key[34].key_name = "}"; Key[34].number = 34; Key[35].key_name = ";"; K ey[35].number = 35;Key[36].key_name = ","; Key[36].number = 36; Key[37].key_name = "\""; K ey[37].number = 37; Key[38].key_name = "'"; Key[38].number = 38; Key[39].key_name = "++"; Key[39].number = 39;Key[40].key_name = "--"; Key[40].number = 40;Num = new num_word[1024];ID = new ID_word[1024];}public void GetChar() //得到一个字符{if (index < receive.Length){ch = receive[index];index++;}else{ch = '\0';}}public void GetNotKong() //得到一个不是空的字符{while (index < receive.Length){ch = receive[index];index++;if (ch != ' ' && ch != '\r' && ch != '\0' && ch != '\n'){break;}}}public void ConCat() //连接{cache += ch;}public bool IsLetter() //判断是不是字母{if (ch >= 'A' && ch <= 'Z' || ch >= 'a' && ch <= 'z') {return true;}else{return false;}}public bool IsDigit() //判断是不是数字{if (ch >= '0' && ch <= '9'){return true;}else{return false;}}public int Get_Number() //得到这个单词的编码{for (int i = 0; i < 41; i++){if (string.Equals(cache, Key[i].key_name)){return Key[i].number;}}{return 0;}}public void retrace() //退回一个单词{if (ch != '\0'){index--;}private void Get_Word(){int count;GetNotKong();if (ch >= 'A' && ch <= 'Z' || ch >= 'a' && ch <= 'z') {ConCat();GetChar();while (IsLetter() || IsDigit()){ConCat();GetChar();}retrace();count = Get_Number();temp.key_name = cache;if (count == 0){temp.number = 0;}else{temp.number = Key[count].number;}}else if (ch >= '0' && ch <= '9'){ConCat();GetChar();while (IsDigit()){ConCat();GetChar();}retrace();temp.key_name = cache;temp.number = 1;}else if (ch == '+')ConCat();GetChar();if (ch == '+'){ConCat();temp.key_name = cache;temp.number = 39;}else{retrace();temp.key_name = cache;temp.number = Get_Number();}}else if (ch == '-'){ConCat();GetChar();if (ch == '-'){ConCat();temp.key_name = cache;temp.number = 40;}else{retrace();temp.key_name = cache;temp.number = Get_Number();}}else if (ch == '<'){ConCat();GetChar();if (ch == '='){ConCat();temp.key_name = cache;temp.number = 26;}else{retrace();temp.key_name = cache;temp.number = Get_Number();}}else if (ch == '>'){ConCat();GetChar();if (ch == '='){ConCat();temp.key_name = cache;temp.number = 25;}else{retrace();temp.key_name = cache;temp.number = Get_Number();}}else if (ch == '='){ConCat();GetChar();if (ch == '='){ConCat();temp.key_name = cache;temp.number = 21;}else{retrace();temp.key_name = cache;temp.number = Get_Number();}}else if (ch == '!'){ConCat();GetChar();if (ch == '='){ConCat();temp.key_name = cache;temp.number = 24;}else{retrace();temp.key_name = cache;temp.number = Get_Number();}}else if (ch == '&'){ConCat();GetChar();if (ch == '&'){ConCat();temp.key_name = cache;temp.number = 27;}else{retrace();temp.key_name = cache;temp.number = Get_Number();}}else if (ch == '|'){ConCat();GetChar();if (ch == '|'){ConCat();temp.key_name = cache;temp.number = 28;}else{retrace();temp.key_name = cache;temp.number = Get_Number();}}else{ConCat();temp.key_name = cache;temp.number = Get_Number();}}}}六：实验截图（1）我测试的程序为void main(){ int a=20;int b=15;if(a==20)printf("A");if(b==20)printf("B");}七：实验心得通过这次实验、我对于词法分析需要做的任务有了一个更加深刻的理解。
