How Does it work ? – Engaged 怎样工作? – 接合状态
Flywheel 飞轮
Transfer Torque传递扭矩
Clutch离 合器
• Disc is clamped by the clutch cover, connecting the engine crankshaft to the transmission input shaft从动盘被压盘夹 紧,将发动机曲轴和变速箱输入轴连接起来
Functions of a Clutch
离合器功能
Transfer Torque 传递扭矩
Smooth Engagement 柔和结合
Breaks Torque 切断扭矩
来自百度文库
Clean Release 清晰的分离
3
3
What are the Basic “Functions” of a Clutch?离合器 的基本功能？
Clutch Basics 离合器基础
© 2008 Eaton Corporation. All rights reserved.
What are the Basic “Functions” of a Clutch? 离合器的基本功能？
Functions of a Clutch 离合器功能
2
2
What are the Basic “Functions” of a Clutch? 离合器的基本功能？
12
12
Flywheel Ring / Bracket / Cover 支撑环/支架/盖
Flywheel Ring支撑环: Houses the Diaphragm Springs and Pressure Plate.支撑膜片弹簧 和压盘
• Provides a way to translate engine rotation into transmission rotation, • 将发动机的转动传递到变速箱的转动 • Provides a way to allow the engine to run without the truck moving, • 允许发动机运转而车辆保持不动 • Provides a way to break torque to select and change gears. • 在需要选档和换档时切断扭矩传递
4
4
What Does a Clutch Do? 离合器基本功能
The function of a clutch is to connect / disconnect the flow of power from the engine to the driveline离合器的基本功能是连接/切断发动机 到传动轴的动力传递
10
10
Pressure Plate Bolts压盘螺栓
Pressure plate bolts压盘螺栓: Shoulder-head bolts threaded directly into top of pressure plate and through the drive straps.带肩端台阶螺栓穿过传动片直接拧到压盘 上部
Functions of a Clutch
离合器功能
Transfer Torque 传递扭矩
Dampen Vibrations 使振动变弱
Smooth Engagement 柔和结合
Breaks Torque 切断扭矩
Clean Release 清晰的分离
Engage a Clutch Brake 离合器制动
8
8
Clutch - Basic Components 离合器基本部件
Cover Assembly压盘总成: An assembly which is mounted on the flywheel, and squeezes the disc against the engine flywheel.安装到飞轮上,将从动盘压紧到发动机飞轮 上的零件
11
11
Shipping Clips运输垫片
Shipping clip 运输垫片
Shipping Clips运输垫片: Fits between the flywheel bracket and the pressure plate
bolts. Used to “cage” pressure plate, in order to facilitate installation of driven discs. The clips are removed during the installations process.在压盘螺栓和架子之间,以在运输中保 持住压盘,有利于从动盘装配.在离合器安装过程中要拿走.
• Pressure plate separates from the disc压盘 与从动盘分离
• Transmission is disconnected from the engine变速箱与发动机分离
7
7
Clutch - Basic Components 离合器基本部件
Driven Disc从动盘: This is the disc which is in contact with the engine flywheel and the pressure plate of the clutch assembly这是与发动机飞轮和离合器压盘都接触的零件
9
9
Clutch - Basic Components 离合器基本部件
Release Bearing分离轴承: Serves as a stationary connection for the release linkage. Connects to the diaphragm spring.连接到膜片弹簧上,且与分离系统相连接.
• Transmission rotates with the engine变速 箱与发动机一起旋转
6
6
How Does it work ? – Disengaged 怎样工作 – 分离状态
Flywheel 飞轮
Clutch离 合器
Clean Release / Breaks Torque
清晰的切断扭矩
