天然气 安装使用维护说明书中英文
汽油气设备安装与运行指南（英语）说明书
INSTALLATION & OPERATIONAL MANUALIMPORTANT FOR YOUR SAFETYTHIS MANUAL HAS BEEN PREPARED FOR PERSONNEL QUALIFIED TO INSTALL GAS EQUIPMENT, WHO SHOULD PERFORM THE INITIAL FIELD START-UP AND ADJUSTMENTS OF THE EQUIPMENT COVERED BY THIS MANUAL.POST IN A PROMINENT LOCATION THE INSTRUCTIONS TO BE FOLLOWED IN THE EVENT THE SMELL OF GAS IS DETECTED. THIS INFORMATION CAN BE OBTAINED FROM THE LOCAL GAS SUPPLIER. IMPORTANTIN THE EVENT A GAS ORDOR IS DETECTED, SHUT DOWN UNITS AT THE MAIN SHUTOFF VALVE AND CONTACT THE LOCAL GAS COMPANY OR GAS SUPPLIER FOR SERVICE.FOR YOUR SAFETYDO NOT STORE OR USE GASOLINE OR OTHER FLAMMABLE VAPORS OR LIQUIDS IN THE VICINITY OF THIS OR ANY OTHER APPLIANCE.Improper installation, adjustment, alteration, service or maintenance can cause property damage, injury or death. Read the installation, operating and maintenance instructions thoroughly before installing or servicing this equipment.Using the appliance safelyBeing an appliance designed only for professional use, it should be operated by qualified personnel exclusively.Never leave the appliance unattended while it is on.Do not move the appliance while hot.Do not replenish the tank while the oil is hot. Please pay attention to the oil level mark when filling the tank. If it is below the minimum line, the oil might catch fire. If it is over the maximum line, the oil might overspill. It must be somewhere between min and Max line.Please make sure the food is not wet. If food is wet or water drops inside the oil or fat, oil would burstand it is extremely dangerous.Do not use flammable solvents or cleaning aids to clean this fryer. Corrosion might occur. Safety instructions in case of malfunctionIf the appliance will remain idle for some time or in the event of a failure, abnormal operation, etc., turn off the shutoff valve upstream of the appliance. Call the service. Additional prohibitions (hazardous procedures)Never tamper with the seals of the adjusting screws located on the gas valves. Disposing of the applianceThis appliance has been manufactured using recyclable raw materials and does not contain any hazardous or toxic substances. To dispose of the appliance and all its packaging materials, strictly follow the local regulations in force in the place where it is installed. Packaging materials should be divided according to the type and delivered to a specific collection site. Ensure compliance with environmental protection regulations.TABLE OF CONTENTS Important for your safety IntroductionGeneralSpecifications InstallationClearancesLocationASSEMBLYFlue connectionGas connectionGas pressureTest gas supplyLeveling the fryerOperationOver temperature shutdown Before first useCleaningFilling the tank with shortening Lighting the pilotTurning on the fryerTurning off the fryer Extended shutdownBasic frying instructionsFry Basket GuidelinesExtended shortening life Daily filteringCLEANING DailyBolt out procedure MaintenanceFlue vent inspection TroubleshootingINTRODUCTIONGENERALThis type of Fryer is produced with quality workmanship and material. Proper installation, usage and maintenance will result in years of satisfactory performance.Before installing the fryer, thoroughly read this manual and carefully follow all instruction.This manual is applicable to model listed on the cover page. Procedures in this manual will apply toall models unless specified. Pictures and illustrations can be of any model unless the picture or illustration needs to be model specific.SpecificationMODEL Burner Qty Type of gas Heat Input Ignition Width Inch Shortening lbs.GF90 3 G20,G30,G3126.40.5kW (NG),0.6kW(LPG) 15.5" 35-40GF120 4 G20,G30,G31 35.2 15.5" 45-50 GF120T 4 G20,G30,G31 35.2 15.5" 25+25 GF150 5 G20,G30,G31 44 21.0" 65-70 GF85 5 G20,G30,G31 44 21.0" 85-90SpecificationMODEL Burner Qty Type of gas Heat Input Ignition Width Inch Shortening lbs.GF90 3 G25.3 25.50.5kW 15.5" 35-40GF120 4 G25.3 34 15.5" 45-50 GF120T 4 G25.3 34 15.5" 25+25 GF150 5 G25.3 42 21.0" 65-70 GF85 5 G25.3 42 21.0" 85-90INSTALLATIONBefore installing the fryer, verify that the type of gas (natural or propane) agrees with the specifications on the fryer naming plate which is located at the rear part of the unit. Make sure the fryer is configured for the proper elevation.Record your fryer model, device, and serial numbers for future reference in the space provided below. This information can be found on the fryer data plate.Model No: ___________________Device: ______________________Serial No: ____________________Clearances☆Minimum clearance from combustible construction:6” (15 cm) from the sides of the fryer 6” (15 cm) from the back of the fryer The fryer may be installed on combustible floors☆Minimum clearance from noncombustible construction:0” from the sides of the fryer 0” from the back of the fryer☆Between the fryer and any open-top flame units:16” (41 cm)Location☆ Install fryer in an area with sufficient air supply for gas combustion at fryer burners.☆ Do not obstruct the flow of combustion and ventilation air.☆ Provide adequate clearance for air openings into the combustion chamber.☆ Do not permit fans to blow directly onto fryer.☆ Avoid wall-type fans, which create cross-currents within a room. Avoid open windows next to sides or back.ASSEMBLYThe fryer must be restrained to prevent tipping and the splashing of hot liquid. The means of restraint may be the manner of installation, such as connection to a battery of appliances, installing the fryer in an alcove, or by separate means such as adequate ties.FLUE CONNECTIONMake the flue connection as follows:☆ Locate the fryer under a hood with adequate connection to an exhaust duct. The hood must extend 6” (15 cm) beyond fryer on both sides.☆ Clearance above the fryer should be adequate for combustion by-products to be removed efficiently.☆ An 18” (46 cm) minimum clearance should be maintained between the flue ventand the filters of the hood venting system.☆ Never make flue connections directly to the fryer.☆ Do not obstruct the flow of the gases from the appliance. Proper air balance should be maintained in the room.GAS CONNECTIONAll gas supply connections and any pipe joint compound must be resistant to the action of propane gases.The gas inlet is located on the lower rear of the fryer. Codes require that a gas shutoff valve be installed in the gas line ahead of the fryer.The gas supply line must be at least the equivalent of ½” (12.7 mm) iron pipe for single units and 1-1/4” (31.75 mm) for batteries. If using the optional quick-disconnect flex hose, ¾” (19 mm) iron pipe for single units and 1-1/4” (31.75 cm) iron pipe for batteries.Make sure the pipes are clean and free of obstructions, dirt, and piping compound. A battery requires one or two connections of appropriate size for the gas requirement.Prior to lighting, check all joints in the gas supply line for leaks. Use soap and water solution. Do not use an open flame.After piping has been checked for leaks, fully purge gas pipes to remove air.GAS PRESSURES (ALL MODELS):The available gas pressure should be the same as that indicated on naming plate. If incoming pressure exceeds 5 kPa, an additional pressure regulator must be installed.TESTING THE GAS SUPPLY PIPING SYSTEM:When test pressures exceed 5 kPa, the fryer and its individual shutoff valve must be disconnected from the gas supply piping system.LEVELING THE FRYERCheck the level of the fryer by placing a level on top of the fryer after gas connections have been made. Ensure that the fryer is level front-to-back and side-to-side in the final installed position. If using casters, lock the wheels after unit is level.Air adjustmentUnscrew the locking screw of the burner air shutter and adjust the air shutter to desired height. In the above picture you can find the suggested height for different types of gases. The height is the distance between burner base and air shutter.OPERATIONOVER-TEMPERATURE SHUTDOWNIf the shortening becomes overheated, a high-temperature shutoff device will turn the gas valve off and extinguish the pilot.If the fryer shuts down due to overheating, DO NOT re-light the pilot until the shortening℃℉temperature is below 149 (300 )If an overheating situation persists, contact qualified technician for help.BEFORE FIRST USECleaningNew units are wiped down at the factory to remove any visible signs of dirt, oil, grease, etc. remaining from the manufacturing process.Before any food preparation, thoroughly wipe protective oil from all surface parts and the tank interior with hot soapy water to remove any film residue and dust or debris.Do not use chlorine or sulfate/sulfide cleaners.☆ Wash any accessories shipped with unit.☆ Rinse fryer and accessories thoroughly and drain the fryer. Š Wipe tank completely dry with a soft, clean cloth.FILLING TANK WITH SHORTENINGSolid shortening should NOT be used with this type of fryer. Melting solid shortening will damage the tank.☆Close the drain valve.☆Fill the fryer tank with liquid shortening.☆Shortening level should be between the min and max lines in the fryer tank. ☆Shortening will expand when heated. Do not ill the fryer tank past the☆MAX line.☆Add fresh shortening as needed to maintain oil level.LIGHTING THE PILOT1. Open the door.2.Turn the thermostat OFF (see figure above). The thermostat is located behind the door.3.Push the gas control valve knob and turn to “O” (see figure below, view A). Wait 5 minutes forunburned gas to vent.4.5.While still holding the knob in, light the pilot with a lit flame. Continue to depress the knobuntil pilot remains lit when knob is released. If the pilot does not remain lit, repeat step 3 through 5.6.Depress and turn gas control knob to “” (See figure below, view C).7.If gas supply is interrupted, repeat steps 2 through 6.TURNING ON THE FRYER1. Set the temperature knob to desired temperature.2. After the set temperature has been reached, the thermostat shuts off the gas flow to burners.3. The pilot remains lit. The burners will cycle on and off, maintaining the set temperature. TURNING OFF THE FRYER1. Turn the thermostat OFF.3. To shut off all gas to the system, including the pilot, turn the gas valve knob to “O”. EXTENDED SHUTDOWN1. Turn the thermostat knob to OFF.2. Push in the pilot knob and turn to “O”.3. Thoroughly drain the fryer. Refer to DRAINING THE FRYER.4. Clean the fryer according to CLEANING.5. Turn off the main gas shutoff valve.BASIC FRYING INSTRUCTIONSet the desired temperature and allow shortening to heat up to that temperature.Fry items that are about the same size together to ensure equal doneness.Drain or wipe dry raw or wet foods to minimize splatter when lowering into hot shortening. Add fresh shortening as needed.Fry Basket GuidelinesDo not overfill baskets. Carefully lower basket into oil.When frying doughnuts and fritters, turn product only once during frying.When cooking French fries or onion rings, shake the basket several times in a way that does not splatter the shortening.Batter-covered foods should be dropped carefully, one by one, into shortening or basket. If you use the basket, first dip the basket into the shortening to reduce batter-build up on basket surfaces. When frying is completed, remove basket or product. Hang basket on rear hanger.EXTENDING SHORTENING LIFEShortening life can be extended by the following guidelines:☆ Do not salt foods over the fryer.☆ Use good-quality shortening.☆ Filter shortening daily (at a minimum).☆ Replace shortening if it becomes poorly flavored.☆ Keep equipment and surrounding clean.☆ Set thermostat correctly.☆ Remove excess moisture and particles from food products before placing on fryer. DRAINING THE TANK1. Turn the thermostat to OFF.3. Direct the drain spout into the container that you want to drain the shortening into.4. Open the drain valve. The oil will drain into the container. When the container is full or the fryer tank is empty, close the drain valve. Repeat this step until the fryer is empty.5. If desired, perform the weekly clean-out as described under CLEANING.6. Once tank is completely empty, add new shortening and set thermostat to desired temperature. DAILY FILTERING☆ Filter shortening at least once a day. Refer to the instructions provided with your filtering equipment.☆ A cold fryer will not drain properly. Always filter shortening between 250F and 350F. The shortening in the cold zone area will remain hard if the heat is only on for a few minutes. If necessary, use the clean-out rod to carefully stir the hard shortening to an area above the cold zone where it will melt. Use the tank brush to help clear sides and tubes of debris.CLEANINGDailyClean your fryer regularly with the tank brush along with a damp cloth, and polish with a soft dry cloth. If regular cleaning is neglected, grease will be burned on and discolorations may form. Fingerprints are sometimes a problem on highly polished surfaces of stainless steel. They can be minimized by applying a cleaner that will leave a thin oily or waxy film.☆ Clean all exterior surfaces of your fryer at least once daily.☆ Use a damp cloth with warm water and a mild soap or detergent.Do not use chlorine or sulfate/sulfide cleaners.☆ Rinse thoroughly, and then polish with a soft dry cloth.☆ Keep the fryer exterior clean and free of accumulated grease to prevent stubborn stains from forming. If regular cleaning is neglected, grease will be burned on and discolorations may form. ☆ Remove discolorations by washing with any detergent or soap and water.☆ Use a self-soaping, non-metallic scouring pad for particularly stubborn discolorations.☆ Always rub with the grain of the stainless steel. Š Do not use a metallic scoring pad or harsh cleaners.BOIL OUT PROCEDUREWeekly or as required:1.Drain the tank as described under DRAINING THE TANK.2.Once the shortening has been drained, flush out scraps and sediment with a small amount ofwarm shortening, using tank brush. Allow the tank to drain thoroughly.3.Close the drain valve and fill tank with non-corrosive, grease-dissolving commercial cleaner.Follow the manufacture’s instructions.Do not use chlorine or sulfate/sulfide cleaners.4.Add commercial boil-out solution. Solution level must be between the MIN and MAX levelson the fryer tank.5.Set thermostat to the temperature recommended for the solution being used. Allow solutionto simmer for about 15 to 20 minutes.6.Drain the cleaning solution from the tank.7.Close the drain valve and refill the tank with water. Add 1 cup (1/4 L) of vinegar to neutralizealkaline left by the cleaner. Solution level must be between the MIN and MAX level on the fryer tank.8.Bring the solution to a simmer only, turn the thermostat off. Allow to stand for a fewminutes.9.Drain the tank according to DRAINING THE TANK. Rinse thoroughly with clear, hotwater. All traces of cleaner must be removed. Dry the tank thoroughly.10.Close the drain valve and add shortening. Follow the FILLING TANK WITHSHORTENING procedure in this manual. The fryer is now ready for use. MAINTENANCEFLUE VENT INSPECTIONWhen the fryer is cool, inspect annually. Check the flue and clear any obstructions. TroubleshootingTroubleshooting Chart:Problem: Probable Cause:No Heat: Thermostat dial not turned on.Pilot not lit.Gas supply not turned on.Wire connections loose (call service)Wires connections need cleaning (call service)Thermopile (call service)Insufficient or too much heat: Thermostat dial not set to desired temperature.High limit tripped (call service)Temperature probe (call service)Tank will not drain: Shortening too cold.Drain pipe clogged with debris.Parts listKey Qty Description1 1 Screen, crumb, 3 and 4 tube fryercock2 1 Drain3 1 Tank(excluding flue)4 1 Drain, extension5 1 Flue, top, removable6 1 Flue, wrap, top, removable Wiring diagramADEXA DIRECT LIMITEDGROUND FLOOR UNIT 1 214 PURLEY WAY CROYDON CR0 4XG LONDON UNITED KINGDOM T: +44 1483 931040 ****************.uk EC Declaration of ConformityAdexa Direct Limited declares that:Equipment Type: Gas fryerModel: GF120, GF120T, GF150, GF85, GF90Imported By: ADEXA DIRECT LIMITEDGROUND FLOOR UNIT 1 214 PURLEY WAY CROYDON CR0 4XGLONDON, UNITED KINGDOMSerial Number:Year of Manufacture:Brand: ADEXAApplication of Council Directive(s): (EU) 2016/426 (9 March 2016)Standards:EN 203‐1:2014, EN 203‐2‐4:2005EN 203‐3:2009I, the undersigned, hereby declare that the equipment specified above conforms to the above Directive(s) and Standard(s).Date: 01.09.2017Signature:Full Name: Hakan BaykalPosition: Purchase Manager。
燃气售后服务维修手册
售后服务维修手册（内部使用）编写：李源天然气公司使用目录服务方针： (3)服务宗旨： (3)服务目标： (3)全程服务保障安全 (3)服务思想： (3)文明售后 (3)1.小区通气流程 (4)2.户内燃气置换放散要求 (5)3.管道改造维修要求 (5)4.灶具常见故障保修范围 (5)5.灶具打不着火常见故障 (6)6.秦川燃气表打不着火处理办法 (6)6.1秦川燃气表技术参数： (6)第 1 页共15 页6.2查看燃气表电池 (6)6.3查看灶具电池是否有电 (6)6.4秦川表故障提示表 (7)7.江阴燃气表打不着火处理办法 (7)7.1江阴燃气表技术参数 (7)7.2查看燃气表上有无燃气余量 (7)7.3查看燃气表电池是否有电 (7)7.4检查灶具电池是否有电 (7)7.5江阴中威燃气表常见故障及排除办法 (7)8.宁波东海燃气表打不着火处理办法 (9)8.1宁波东海燃气表技术参数 (9)8.2查看燃气表上有无燃气余量 (9)8.3查看燃气表电池是否有电 (9)8.4检查灶具电池是否有电....................................................................... 99.宁波东海燃气表充值金额无法充入表中 .. (9)宁波东海燃气表常见故障及排除办法 (10)10.燃气热水器的安装： (12)11.前锋热水器故障判断方法： (12)11.1 JSQ16/20/24/-X8(T)型号故障代码 (12)11.2 JSQ08A6 JSQA602；16BFX故障代码H6故障代码JSQ16A420A401 20A402故障代码 (12)JSQ16/20-H4+, JSQ16/20-H5故障代码 (13)18N1故障代码 (13)11.3 JSQ16/2024-X8(T)故障代码 (13)11.4 1003TQ故障代码 (13)11.5 16-SM故障代码 (14)11.6 18N1故障代码 (14)第 2 页共15 页服务方针：诚信服务全面保障服务宗旨：用户满意才是价值服务目标：全程服务保障安全服务思想：快速反应使我们的行动准则用户满意使我们的服务目的文明售后1.公共场所不准大声喧哗2.上门服务不准迟到拖延3.预约咨询不准含糊不清4.服务规范不准执行有偏5.同事之间不准嬉戏打闹6.工具携带不准丢三落四7.在用户家不准随意乱动第 3 页共15 页8.对待问题不准推诿扯皮9.车辆工具不准乱停乱放10.信息传递不准遗勿延误1.小区通气流程1.1调压装置检漏：打开进气阀关闭出气阀，用肥皂水对进气阀、出气阀法兰、螺栓接口处进行检漏，观察燃气无泄漏为合格。
WT615、T12系列天然气发动机说明书-英文
1. For your legal rights, do not modify the structure of engine without authorization. Otherwise, theCompany's "Three Guarantees" service will be unavailable.2. Ensure the tightness of air intake system which shall be free of short circuit and leakage. Clean orreplace the air filter element according to the status to ensure the effectiveness of rubber dust exhaust nozzle of air filter, and replace it promptly if necessary.3. Strictly guarantee the tightness of natural gas (NG) supply system, and clean or replace thehigh-pressure filter as well as the elements inside the high-pressure solenoid valve and high-pressure regulator filter timely according to the daily maintenance (see 2.5.3)4. Regularly change the dedicated lubricating oil and replace the oil filter for high-quality NG as perinstruction manual, and fill oil strictly according to the scales of oil dipstick.5. Fill the high-quality antifreeze coolant rather than natural water as per instruction manual to the bottomof expansion tank filler. Do not open the radiator cap when the engine is hot to avoid the scald by heat gas.6. Use the high-quality NG and periodically check the cylinder as per instruction manual to ensure thesafety.7. Before the start of engine, check the levels of oil and coolant, and check the tightness of intake system.8. At the start of engine, the engine shall idle for 3-5 min. Warm it up, and start it when the watertemperature reaches 60 °C. Stop it after 3-5 min idle running.9. Perform the application, check, maintenance and service as per instruction manual. Invite the qualifiedpersonnel to carry out the maintenance. Perform the maintenance and service at the authorized service stations of SINOTRUK as practically as possible.10. Particularly, linkage bolt is for one-time use and shall not be used again after the disassembly.11. Particularly, tighten the linkage bolt, cylinder head bolt, main bearing bolt, etc. as per instruction manualor service manual.12. T o prevent the wiring harness short circuit, do not wash the connection of engine wiring harness withwater. Dry the connection of wiring harness with cold wind before starting the engine.13. During the welding operation, turn off the main power of engine and remove the positive and negativeterminals of battery to avoid the damage of ECM due to the welding current.14. For any questions, refer to the authorized service stations of SINOTRUK.ForewordThe 10 L and 12 L NG engines developed by SINOTRUK in line with Phase III/IV emission standards, with the electronic control gas supply system for US Econtrols Company, are one of the most ideal matching power for the large buses, passenger cars, municipal vehicles, trucks, etc.This manual gives a brief introduction to technical parameters, performance indicators, structural characteristics and maintenance precautions of 10 L and 12 L NG engines. The satisfactory results may be achieved if the users effectively implement the requirements as per the instruction manual. This manual is for reference only and subject to the modifications without prior notice.The purpose of this manual is to help the customers to understand the usage requirements of 10 L and 12 L NG engines, and describe the structure of system and parts to give the users a rough understanding.This manual describes the basic models of 10 L and 12 L NG engine. The engines for special purposes such as generator set have different requirements about structure and technical requirements, so the users concerned shall refer to the corresponding supplement.Final interpretation of this manual is reserved by SINOTRUK Jinan Fuqiang Power Co., Ltd.The comments and suggestions for further improvement from users are welcomed by the Company, and may be addressed to the T echnology Development Center of SINOTRUK (Hong Kong) Limited.June, 2011Contents1.Model of NG Engine (2)1.110 L NG Engine (2)1.212 L NG Engine (2)1.3Abbreviations and Definitions (3)2Main Technical Parameters and Characteristics Curves of NG Engine (4)2.1Main Technical Parameters of 10 L NG Engine (4)2.2Characteristics Curve of 10 L NG Engine (5)2.3Main Technical Parameters of 12 L NG Engine (7)2.4Characteristics Curve of 12 L NG Engine (8)2.5Gas Supply System of Complete NG Vehicle (9)2.6Electronic Control Ignition System (14)3Main Technical Parameters and Accessory Specifications of NG Engine (19)3.1Main Technical Parameters and Accessory Specifications of 10 L Engine (19)3.2Main Technical Parameters and Accessory Specifications of 12 L Engine (21)4.Running and Maintenance of NG Engine (23)4.1Running Precautions (23)4.2Maintenance Rules (23)4.3Maintenance of Electronic Control and Gas Supply Systems (24)4.4Common Malfunctions and Troubleshooting (26)5.List of Special Parts for NG Engine (40)User’s Feedback Card (41)1. Model of NG Engine1.1 10 L NG EnginePhase III series:WT 6 15 . 9 XModel characteristic number(expressed with “9” and an Arabic numeral)SeparatorSingle cylinder displacement (about 1.5 L)6-cylinderWater-cooled NG enginePhase IV series:T 10 . xx - 40Emission codeSeparatorModel characteristic numberSeparator10 L engineNG engine1.2 12 L NG EngineT 12 . xx - 40Emission codeSeparatorModel characteristic numberSeparator12 L engineNG engine1.3 Abbreviations and DefinitionsAbbreviation Definition Abbreviation Definition CNG Compressed NG TIP Throttle intake pressureLNG Liquefied NG ETC Electronic throttle valve controllerECT Circulating water temperature CMP Camshaft positionHD EPR High-power electronic pressureregulatorCNP crankshaft positionECM Electronic control module UEGO Universal exhaust gas oxygen sensorTMAP T emperature and intake manifold absolute pressure2 Main Technical Parameters and Characteristics Curves of NG Engine 2.1 Main Technical Parameters of 10 L NG EngineMain T echnical Parameters of 10 L NG EngineModel WT615.91 WT615.92 WT615.93 WT615.94 WT615.95 T10.23-40 T10.27-40 T10.29-40 T10.32-40 T10.34-40Type Inline, water-cooled, dry type cylinder liner, supercharging inter-cooling, electronically controlled regulator gas control, spark plug ignition, lean burnNumber ofcylinders,bore (mm)×stroke(mm)6, 126×130T otal displacement(L)9.726Compression ratio 11:1Ignition sequence 1-5-3-6-2-4Valve clearance(cold) mmIntake: 0.30; Exhaust: 0.40Rated power(kW)/speed (r/min)170/2200 196/2200 213/2200 235/2200 250/2200 Max. torque(N.m)/speed(r/min)950/1200~1500 1160/1200~1500 1230/1200~1500 1300/1200~1500 1350/1200~1500 Standard fuel Compressed natural gas (CNG)/liquefied natural gas (LNG)Min. fuelconsumption(g/kW.h)195g/kw.hOil grade 5W/40, 10W/40, 15W/40 special for NG engineMax. no-loadspeed, r/min2420±50Stable idlingspeed, r/min600±20Max. rear exhausttemperature ofturbine (℃)＜580Noise dB(A) ＜93Emission Phase III/IV (with oxidation catalyst)Net weight ofengine (kg)About 850Outline dimensions(mm)1525×773×10412.2 Characteristics Curve of 10 L NG EngineThe Characteristics Curve of WT615.91 NG EngineThe Characteristics Curve of WT615.92 NG EngineThe Characteristics Curve of WT615.93 NG EngineThe Characteristics Curve of WT615.94 NG EngineThe Characteristics Curve of WT615.95 NG Engine2.3 Main Technical Parameters of 12 L NG EngineMain T echnical Parameters of 12 L NG EngineModel T12.38-40 T12.42-40Type Inline, water-cooled, dry type cylinder liner, supercharging inter-cooling, electronically controlled regulator gas control,spark plug ignition, lean burnNumber of cylinders, bore (mm)×stroke (mm) 6 126×155T otal displacement (L) 11.596Compression ratio 11:1Ignition sequence 1-5-3-6-2-4Valve clearance (cold) mm Intake: 0.40; Exhaust: 0.50 Rated power (kW)/speed (r/min) 279/2000 309/2000Max. torque (N.m)/speed (r/min) 1650/1200~1500 1820/1200~1500Standard fuel Compressed natural gas (CNG)/liquefied natural gas(LNG)Min. fuel consumption (g/kW.h) 195g/kw.hOil grade 5W/40, 10W/40, 15W/40 special for NG engine Max. no-load speed r/min 2250±50Stable idling speed r/min 600±20Max. rear exhaust temperature of turbine (℃) ＜580Noise dB(A) ＜93Emission Phase IV (with oxidation catalyst) Net weight of engine (kg) About 1100Outline dimensions (mm) 1525×825×10902.4 Characteristics Curve of 12 L NG EngineThe Characteristics Curve of T12.38-40 NG EngineThe Characteristics Curve of T12.42-40 NG Engine92.5 G a s S u p p l y S y s t e m o f C o m p l e t e N G V e h i c l e2.5.1 S c h e m a t i c D i a g r a m o f G a s S u p p l y S y s t e m o f 10 L C o m p l e t e N G V e h i c l e2.5.2 S c h e m a t i c D i a g r a m o f G a s S u p p l y S y s t e m o f 12 L C o m p l e t e N G V e h i c l e2.5.3 E l e c t r o n i c C o n t r o l G a s S u p p l y S y s t e m2.5.3.1 S c h e m a t i c d i a g r a m o f e l e c t r o n i c c o n t r o l g a s s u p p l y s y s t e m o f 10 L C N G e n g i n eLNG cylinderVaporizerHigh-pressure solenoid valveLow-pressure solenoidvalveLow-pressure filterElectronic pressure regulator (D28) MixerIntake manifoldPressure regulatorBuffer tankHigh-pressure filter CNG cylinder Double-stage pressure regulator (DSR)High-pressure regulator LNG cylinderVaporizerHigh-pressure solenoid valveHigh-pressure regulator Low-pressure solenoid valveLow-pressure filterElectronic pressure regulator(EPR)MixerIntake manifoldPressure regulatorBuffer tankHigh-pressurefilterCNG cylinder2.5.3.2 Schematic diagram of electronic control gas supply system of 10 L ING engineCNG cylinderHigh-pressure solenoid valveHigh-pressure regulatorLow-pressure solenoid valveElectric pressure regulator (EPR)High-pressurefilterLow-pressurefilterElectronic accelerator pedalCheck the engineMalfunction indicator lampControl of ignition coilFront pressure of throttle Drive of throttleIntake pressure and humidityCamshaft positionTemperature of engine cooling waterCrankshaft phase speedStarter protection relay Exhaust valve coilExhaust valve pressureUniversal exhaust gas oxygen sensor24 V power supplyM i x e rIgnition coilExhaust valveExhaust control valveAnti-surge valveInter-coolerTurbocha rgerEnvironmental sensorIntakeExhaustUniversal exhaust gasoxygen sensorLNG cylinderLow-pressure solenoid valveElectric pressure regulator (EPR)Low-pressurefilterElectronic accelerator pedalCheck the engineMalfunction indicator lampControl of ignition coilFront pressure of throttle Drive of throttleIntake pressure and humidityCamshaft positionTemperature of engine cooling waterCrankshaft phase speedStarter protection relay Exhaust valve coilExhaust valve pressureUniversal exhaust gas oxygen sensor24 V power supplyM i x e rIgnition coilExhaust valveExhaust control valveAnti-surge valveInter-coolerTurbocha rgerEnvironmental sensorIntakeExhaustUniversal exhaust gasoxygen sensorVaporizerBuffer tank2.5.3.3 Schematic diagram of electronic control gas supply system of 12 L CNG engine2.5.3.4 Schematic diagram of electronic control system of 12 L lNG engineCNG cylinderLow-pressure solenoid valveElectric pressure regulator (EPR)Low- pressure filterElectronic accelerator pedalCheck the engineMalfunction indicator lampControl of ignition coilFront pressure of throttle Drive of throttleIntake pressure and humidityCamshaft positionTemperature of engine cooling waterCrankshaft phase speedStarter protection relayExhaust valve coilExhaust valve pressureUniversal exhaust gas oxygen sensor24 V power supplyM i x e rIgnition coilExhaust valveExhaust control valveAnti-surge valveInter-coolerTurbocha rgerEnvironmental sensorIntakeExhaustUniversal exhaust gasoxygen sensorLow-pressure solenoid valveLNG cylinderLow-pressure solenoid valveElectric pressure regulator (EPR)Low- pressure filterElectronic accelerator pedalCheck the engineMalfunction indicator lampControl of ignition coilFront pressure of throttle Drive of throttleIntake pressure and humidityCamshaft positionTemperature of engine cooling waterCrankshaft phase speedStarter protection relay Exhaust valve coilExhaust valve pressureUniversal exhaust gas oxygen sensor24 V power supplyM i x e rIgnition coilExhaust valveExhaust control valveAnti-surge valveInter-coolerTurbocha rgerEnvironmental sensorIntakeExhaustUniversal exhaust gasoxygen sensorLow-pressure solenoid valveVaporizerBuffer tankHigh-pressurefilterPrimary reducerPrimary reducerHigh-pressure solenoid valveHigh-pressure regulatorPrimary reducerPrimary reducerThe system controls gas fuel supply and ignition through the high-power electronic control module (ECM). NG fuel is supplied by the pre-mixed closed-loop control mode outside the cylinder. ECM collects the fundamental signals and correction signals to accurately determine the required volume of gas supply, and performs the closed-loop control for the air-fuel ratio through the feedback of universal exhaust gas oxygen sensor in order to improve the power, economy, emission, etc. High-pressure regulatorHigh-pressure regulator is a secondary pressure relief devicewith the adjustment range of 25 MPa-0.8 MPa. High-pressure regulator has an onboard fuel temperaturesensor. When the fuel temperature drops to less than the allowable limit, ECM will issue commands to limit the engine power in order to protect the downstream fuel system parts. High-pressure regulator requires engine coolant for heating,so the installation location shall not be higher than the top of engine radiator, otherwise it will make the heating water unable to flow through the regulator, resulting in the regulator cracking due to icing. Heat exchangerHeat exchanger is a device for gas heating.based on the actual situation of vehicle.Low-pressure solenoid valveLow-pressure solenoid valve core, with its core driven by the coil, is controlled by ECM to open/close and cut off or restore the fuel supply timely. Electromechanical fuel cutoff solenoid valve is used to block EPR (electronic pressure regulator) and all downstream parts with upstream fuel when the engine is offFig. 2-5-2 Heat ExchangerFuel inletFuel outletCirculating water outletCirculating water inletFig. 2-5-3 Low-pressure Solenoid ValveDouble-stage pressure regulator (DSR)Currently, double-stage pressure regulator is only used on 12 L NGengine, and each engine has 2 such regulators. The fuel intakepressure is not greater than 1.725 MPa.Fig. 2-5-4-1 Double-stage Pressure Regulator (DSR)Fig. 2-5-4-2Electric Pressure Regulator (EPR (10 L)Fig. 2-5-4-3D28 EPR (12 L) Fig. 2-5-7ECI engine management system adopts the electronic pressure regulator (EPR, D28 EPR as shown in Fig.4-13) to control the delivery of fuel, so as to accurately calculate the volume of fuel for optimal combustion, fuel saving and transient response.EPR fuel intake pressure range is from 689 to 1,378 kPa; D28 EPR fuel intake pressure ranges from 3.5 to 6.9 kPa. MixerMixer is a variable venturi tube and used to adjust thevolume ratio of fuel and air entering the engine. Mixer introduces the fuel into the engine by mixing the airand fuel, and 2 internal valves in reverse positions are used to control the fuel-air ratio in the flow range. Mixer model: 10 L 200DM 12 L E480Electronic throttle valveECM controls the volume of gas mixture entering the cylinder by controlling the opening of butterfly valve of electronic throttle valve, so as to manage the engine speed and load. Driver sends the power demand to the ECM through the accelerator pedal. ECM receives the signals from the accelerator pedal, and then controls the opening of electronic throttle valve according tothe operating conditions ofengine.2.6 Electronic Control Ignition SystemIn the electronic control ignition system of engine, ECM, sensor and actuator are connected as shown in Fig. 4-16.Fig. 2-5-5 MixerFig. 2-5-6 electronic throttlevalveFig. 2-6-1 Connection of Controller, Sensor and ActuatorThis system implements the single-cylinder high-energy sequential ignition. The igniter integrates the ignition coil and high-energy circuit module, and a cylinder with an igniter is connected on the spark plugthrough the electrode with lengthened hose to ensure the good contact of igniter electrode lead and spark plug, which can improve the operational reliability of spark plug.Electronic control moduleThe management core of electronic control NG engine monitors the operating conditions of engine through a variety of sensors, and controls the operations of each actuator based on theoperatingCrankshaft positionsensor Camshaft positionsensor Engine coolantsensor Turbocharger/temperature sensor Environmentalsensor Pressure sensorUniversal exhaust gas oxygen sensor Knock sensorOil pressure switchFuel tanktemperature sensor Fuel tank pressuresensor Electronic accelerator pedalExhaust door controlvalveInputOutputCommunicationIgnition coilHigh-power electronic pressure regulator (for10 L engine)Electronic throttleFuel cut-off valveCheck the engineMalfunction indicator lampStarter interlockingrelayInstrument panelElectronic pressure regulator (for 10 L engine)conditions and MAP . It communicates with each subsystem via the CAN bus. Fig. 2-6-2 Electronic Control Module (ECM)Exhaust bypass control valveFig. 2-6-3 Schematic Diagram of Anti-Surge Valve and InstallationIt controls the outlet pressure of exhaust bypass control valve by controlling the duty cycle, so as to control the opening of exhaust relieve valve. Control valve is equivalent to a three-way electromechanical valve with the pulse width adjusted by ECM in order to provide the precise pressure rise control as shown in Fig. 2-6-3. The preferred gas source is the chassis brake air system. Gas source filtering requirements: a filter shall be installed in the device upstream with the filtering accuracy of 30 µm (efficiency up to 95%) or better. The supply pressure shall be controlled within 138 - 172 kPa. Anti-surge valveFig. 2-6-4 Schematic Diagram of Anti-surge Valve and InstallationThe anti-surge valve (Fig. 2-6-4) is used as a protection device of turbocharged engine. Under normal circumstances, anti-surge valve is in a closed status. In case of the sudden deceleration of engine, the low pressure behind the throttle is transferred to the pressure feedback connector of anti-surge valve through the anti-surge valve hose to open the unidirectional cut-off diaphragm of anti-surge valve, and then the high pressure in the downstream of supercharger may flow back to the upstream of supercharger. Front and rear pressures of supercharger compressor may be balanced to avoid the surge of supercharger and prevent the acceleration wear and fatigue on the supercharger parts to protect the supercharger. The installation of anti-surge valve is as shown in Fig. 2-6-4.Control valve connectorPressure sensor connector Brake /control portMounting holeIntake portVentilating ductCompensating valve bodyReference pipelineAir flowTurbochargerIntercooler ThrottleplateIntake manifoldAir flowIgnition coilIt receives the ignition commands from ECM to generate a high voltage and pass it to the spark plug to produce the sparks to ignite the gas. Ignition coil is able to control the ignition timing according to ECM commands to ensure low emissions and low gas consumption of engine.Installation requirements: tighten the mounting bolts of ignition coil to ensure that the spring inside the rubber cot of ignition coil contacts with the head of spark plug. Spark plugFunction: it receives a high voltage from the ignition coil to produce the sparks to ignite the gas.Installation requirements: wind the rubber cot of ignition coil on the spark plug until the sealing gasket is contacted. Then install it in accordance with the torque in T able 2-6-1.Note: Tighten the spark plug with a special spark plug sleeve. Spark plug screw diameter Installation torque 14mm 25~30N·m 12mm15~20N·mT able 2-6-1If the torque spanner is unavailable or inappropriate, install the spark plug according to the following figure.Engine wiring harnessFunction: it connects ECM, sensor and actuator, and sends all sensor signals to ECM which will check the engine operating conditions and control parameter status and will issue the control commands timely in accordance with the engine operating conditions to each actuator through the wiring harness to achieve the precise control of engine. SensorThe sensors mounted on the engine include:Fig. 2-6-6 Installation MethodFig. 2-6-5 Spark PlugSpark plug with the screw diameter of 18.14 mm Spark plug with the screw diameter of 12.10 mm ● For new product, turn by12~ 23(180o~240o).● For new product, turn by12(180o). ● For reused product, turn by112(30o ). ● For reused product, turn by112(30o).CNP sensor;CMP sensor;ECT sensor;TIP sensor;TMAP sensor;Envirotech sensor;UEGO sensor;Oil press sensorWGP sensor;The sensors mounted on the complete vehicle include:Accelerator pedal sensorLampExhaust brake lamp;MIL;Communication data connectionCAN1 port for diagnostic tools;DC24V power system equipped by the complete vehicleVarious types of sensors, solenoid valves on engine are connected with ECU as shown in Fig. 2-6-1.3 Main Technical Parameters and Accessory Specifications of NG Engine 3.1 Main Technical Parameters and Accessory Specifications of 10 L Engine3.1.1 Lubricating SystemModel of lubricating oil: special oil for NG engine15W/40 application range: -20~40 ℃10W/40 application range: -25~40 ℃5W/40 application range: below -25 ℃a) Added volume of lubricating oilFilling time HOWO/A7Yellow RiverPrince/ GoldPrincePassenger Car Wharf CarFirst filling for new vehicle 31 24 24 24 Oil changing and filterelement replacement28 23 23 23Oil changing 27 23 23 23 Note: 1. Each time you change the oil, you shall replace the oil filter;2. Do not check the level of lubricating oil when the engine is running;3. Do not mix different brands of oil.During the normal operation, the oil pressure range (oil temperature ≥ 80 °C): 100-600 kPa Allowed inclination of sump:- Longitudinal inclination- Highway vehicle- Long-term (front/rear): 10°/10°- Short-term (front/rear): 20°/20°- Off-highway vehicle- Long-term (front/rear): 30°/30°- Short-term (front/rear): 30°/30°- Horizontal inclination- Long-term (exhaust pipe side/intake manifold side): 30°/15°- Short-term (exhaust pipe side/intake manifold side): 30°/30°3.1.2 Cooling SystemWater pump and thermostat:Pump type Centrifugal Pump flow and head At 2800 r/min, flow: 9 L/s, head: 12.6 mThermostat type RemovableApplicable occasion T emperate zone or front-mountedengineTropical zone or rear-mountedengineOpening temperature ofthermostat, ℃80±2 71±2Wide-open temperature ofthermostat, ℃95 86Oil cooler type: plateFan: rigid ring-type fan with silicone oil clutchInstallation location: connected with water pump or crankshaftCoolant capacity of engine: 21.5 LCoolant- When ambient temperature≥-10 ℃, 33% ethanol + water- When ambient temperature≥-26 ℃, 50% ethanol + water- When ambient temperature≥-35 ℃, 56% ethanol + waterChanging Requirements of CoolantRequirement Annual Mileage, km Changing Frequency InstructionYear-round use>40,000 Once every yearExamine and adjust thefreezing point before thewinter,20,000~30,000 Once every 2 years<10,000 Once every 3 yearsNote: 1. When the temperature is below 0 °C, regularly check the antifreeze concentration.2. For the area above 0 ℃, the water have been subject to anti-rust and anti-scaling treatmentmay be used as the coolant, and it is prohibited to use the untreated water as engine coolant.3.1.3 Intake and Exhaust SystemAir filter type: two-stage paper filterRated flow of air filter: when the intake resistance is 7 kpa, the rated flow is morethan 1,700 kg/hSupercharger type: radial-flow exhaust supercharger (with bleed valve and watercooler)Intercooler type: tube-fin air-air intercoolerFront intake temperature of intercooler: ≤ 200 ℃3.1.4 Starting SystemStarterPower: 7.5 kWOperating voltage: 24 VGeneratorSpecification: 28 V/55 A, 28 V/80 A (optional)3.2 Main Technical Parameters and Accessory Specifications of 12 L Engine 3.2.1 Lubricating SystemModel of lubricating oil: special oil for NG engine15W/40 -20~40 ℃10W/40 -25~40 ℃5W/40 below -20 ℃Added volume of lubricating oilFilling time Added Amount of Oil (L) First filling of new vehicle 38Oil changing and filter element replacement 37Oil changing 36Note: 1. Each time you change the oil, you shall replace the oil filter;2. Do not check the level of lubricating oil when the engine is running;3. Do not mix different brands of oil.During the normal operation, the oil pressure range (oil temperature ≥ 80 °C): 100-600 kPa Allowed inclination of sump:- Longitudinal inclination- Highway vehicle- Long-term (front/rear): 10°/10°- Short-term (front/rear): 30°/30°- Off-highway vehicle- Long-term (front/rear): 30°/30°- Short-term (front/rear): 30°/30°- Horizontal inclination- Long-term (exhaust pipe side/intake manifold side): 35°/15°- Short-term (exhaust pipe side/intake manifold side): 40°/30°3.2.2 Intake and Exhaust SystemAir filter type: two-stage paper filterRated flow of air filter: ≥2,050 kg/hSupercharger type: radial-flow exhaust supercharger (with bleed valve) Intercooler type: tube-fin air-air intercoolerFront intake temperature of intercooler: 192℃3.2.3 Starting SystemStarterPower: 7.5 kWOperating voltage: 24 VGeneratorSpecification: 28 V/60 A4. Running and Maintenance of NG Engine4.1 Running PrecautionsCheck whether the coolant level, oil level and the gas pressure in the cylinder satisfy the relevant requirements prior to the engine start-up. If the engine fails to be started within 15 s during startup, repeatedly restart it every 2 min.After the engine is started, let it run at idle speed for 2~3 min, and the oil pressure shall be higher than 100 kPa. If the temperature of cooling water is not higher than 60 , do not run the engine at heavy load and℃high speed suddenly to avoid negatively impacting its wear resistance and reliability.Within the run-in period (3,000 km), the engine is preferred to be run at moderate load with no trailer towed by the vehicle.Check of oil level: Check the engine oil level 5 min after its shutdown. The engine oil level shall not surpass the limit (overfilling of engine oil is prohibited), or else, oil spraying, insufficient power and other malfunctions may be resulted. Reduce the load and the speed before shutting down the engine with load; the engine shall run at idle speed for not less than 5 min.4.2 Maintenance RulesT able 5-1 Three Service Conditions for VehiclesWG WG WGAdverse operation conditions (chilly or extremely hot, with high dust content, for usage inconstruction site or as public bus, municipal engineering vehicle, snow removal truck and fire truck); annual mileage less than 2×104 km or annual service time less than 600 h Annual mileage less than 6×104km, short-distance ormedium-distance transportation(for cargo delivery)Long-distancetransportation forvehicles with aannual mileage morethan 6×104 kmT able 5-2 Cycles for First Inspection and Routine Inspection & Maintenance。
燃气轮机中英文对照表
9E燃气轮机中英文对照表2007年7月目录第一部分 DCS控制画面 (3)第二部分燃机报警文本 (13)第三部分报警的原因和处理 (25)第四部分跳机和自动正常停机的保护 (32)第五部分燃机基本控制装置功能代号 (35)第六部分燃气轮机发电设备可靠性指标中、英文对照表 (37)第七部分燃气轮机发电设备几个专业用语 (40)第八部分燃气轮机生产厂商排序 (41).第一部分 DCS控制画面启动控制画面Crude 原油Stop Valve 截止阀Gen 发电机Sys 系统Gas 天然气SRV 速比阀Control Valve 控制阀Turbine Status 燃机负荷状态Trubine State 燃机负荷选择Control Mode 控制方式Mist Status 混烧状态IGV Control IGV控制Speed Control 速度控制PF Control 功率因数控制Setpoint 设定点Reference 基准PF 功率因数CPD 压气机排气压力Ctda 压气机排气温度inlet Air 进气Exhaust 排气Master Control 主控制Start 启动Stop 停机Mode Select 方式选择Off 闭锁、停止Cooldown 盘车Crank 高盘Fire 点火Auto 自动Cooldown Control 盘车控制On 启动Generator Mode 发电机方式PF 功率因数VAR 无功Governor Mode 控制器方式Droop 有差Isoch 无差Fuel Select 燃料选择Heavy 重油Liquid 轻油Load Mode 负荷选择Base Load 基本负荷Preselect Ld 预选负荷Var Control 无功控制Raise 升Lower 降Startup Trend 启动曲线Master Reset 主复归Ack 确认Silence 消音Lock 闭锁Unlock 解锁Commend 命令Setup 启动Alarm 报警Speed 速度Max Vib 最大振动FSR 燃油流量基准Control 控制Monitor 监测Aux 辅助Tests 试验Start-up 启动FSR Control 燃油流量控制IGV Control IGV控制Liquid Fuel 燃油Lube oil 滑油Motors 马达Synchro 同期Water injection 注水CTRL Location 就地控制燃油控制画面to tank 到油箱Distillate fuel stop valve 轻油截止阀Liquid Fuel Stop Valve 燃油截止阀Purge Fuel Lines 清吹管线Purge Done 进行清吹Purge Man 手动清吹Purge Time 清吹时间Start Pump 启泵Stop Pump 停泵Trans to HF 切换到重油Fuel Nozzle Purge Air 燃料喷嘴清吹空气Heavy Fuel Temp 重油温度滑油控制画面Water Out 出水Water In 进水Lube Oil Pressure 滑油压力To Atmosphere 到大气To Bearing 去轴承马达控制画面Aux Lube Oil(88QA) 辅助滑油泵T.exh frame blow(88TK) 排气框架冷却风扇Water Inj. Pump(88WN) 注水泵Aux Hydr.Supply(88HQ) 辅助液压油泵Atom Air Booster(88AB) 辅助雾化空气泵AC Flow Divder(88FM) 燃油分配器马达Lube Oil Mist Elim(88QV) 滑油油雾分离器Cranking Motor(88CR) 启动马达Emerg Lube Oil(88QE) 应急滑油泵Bear Lift Pump(88QB1) 顶轴油泵Ture Gear Motor(88TG) 盘车马达Dist Fuel Forward Pump(88FD) 轻油前置泵LD Compart Cool Air Fans(88VG) 负荷联轴间冷却风扇part.Cool Fans(88BT) 透平间冷却风扇Fuel Additive Pumps(88FA) 抑钒剂泵Gas Skid Vent Fans(88VL) 气体小间通风扇Cool Water Pumps(88WC) 内冷却水泵Crude Fuel Forw.Pumps(88FU) 重油前置泵同期控制画面BREAKER TIMERS(CYCLE) 同期计时器（循环）NORMAL CLOSE TIME 正常合闸时间LEARNED CLOSE TIME 理论合闸时间ACTIVE CLOSE TIME 实际合闸时间BREAKER TRIP 开关跳闸BREAKER CLOSE 开关合闸AUTO PERMISSIVES 自动允许GENERATOR BKR SELECTED 发电机开关被选择SYNCH LOCKOUT 同期闭锁BUS VOLTAGE 母线电压BUS FREQUENCY 母线频率GENERATOR VOLTAGE 发电机电压GENERATOR FREQUENCY 发电机频率DIFFERENCE VOLTS 电压差DIFFERENCE FREQUENCY 频率差SEQUENCING SYNC PERMIT 同期程序允许AUTO SYNC PERMIT 自动同期允许Phase Angle 相角Volts Diff 电压差Slip Freq 频率差Frequency 频率Generator Sync Mode 发电机同期方式注水控制画面Flame Intensity 火焰强度Combusion Data 燃烧室数据Allowable Spread 允许温差Exhaust Spread 排气温差Exhaust Temperature 排气温度Reference Temperature 温度基准Flow Lockout 流量闭锁Reduce Flow 降低流量Actual Flow 实际流量Water/Fuel Ratio Ref 水/油比基准Water/Fuel Ratio Actual 实际水/油比轴承温度监视画面Thrust Bearing 止推轴承Turbine Bearing 透平轴承Generator Bearing 发电机轴承Bearing Trend 轴承温度曲线Seismic Vibration 振动Wheelspace 轮间Bearing Temperature 轴承温度Lube Oil Temperature 滑油温度发电机热电偶监视画面Middle Stator Temperature 定子中间温度RTD Stator Temperature 定子热电偶温度Stator Hot Air 定子热风Stator Cool Air 定子冷风Generator Exciter Air Temp 发电机励磁机风温轮间温度监视画面Inner 内部Outer 外部Forward 前面First Stage 第一级Second Stage 第二级Third Stage 第三级Wheelspace Temprature 轮间温度启动检查辅助画面Start Check 启动检查Bus Undetvoltage 母线低电压Customer Permissive To Start 用户允许启动Comp Inlet Thermcouples Disagree 压气机进口温度热电偶不一致IGV Control Valve Fault IGV控制阀故障Master Protective Startup Lockout 主保护启动闭锁HP Speed-Minimum Firing Spd HP速度－最小点火转速Lube Oil Tank TEMP-Normal 滑油箱温度正常Flame Detector Trouble 火焰探测器故障Control Mode＝Off 控制方式＝闭锁Hydraulic Protective Trouble 液压保护故障Comp Bleed Vlv or IGV Pos Lockout 压气机防喘阀或IGV位置故障Loss of Master Protective 主保护失去Loss Of Gas Skid Ventilation Shutdown 气体小间失去通风停机Emerg.Lube Oil Pump Undervolt.Relay 应急滑油泵低电压继电器动作Vibration Start Inhibit 振动故障禁止启动Loss Of CPD Bias 失去压气机出口压力偏差Fire System Trouble 点火系统故障Liqud Fuel Temp Low 燃油温度低NOT READY TO START 未准备启机Signals in the proper state to permit 当信号处于允许启机状态时是绿色。
康诺流体 HPNGV2 系列压缩天然气车用调压器使用说明书和维护手册
Enidine / Conoflow105 Commerce Way Westminster, SC 29693Tel: (864) 647-9521 Fax: (864) 647-9574INSTRUCTION AND MAINTENANCE MANUALHPNGV2 Series Compressed Natural GasVehicle RegulatorWARNING: These instructions must be read carefully prior to installation and system startup.INTRODUCTION: The HPNGV Series regulator is a self contained, pressure reducing regulator designed and qualified for 3000 and 3600 psig CNG vehicular fuel systems. This regulator is factory calibrated and is not field adjustable. Various configurations of this regulator are available, based on the application needs. Consult the factory for part numbers, service kits, or configuration assistance.SYSTEM REQUIREMENTS : High pressure CNGfiltration (1 micron rating) is required to keep particulates in the gas stream from damaging the regulator and downstream components. The filter must be located upstream of the pressure regulator. Clean, burr free fittings and lines must be used to prevent particulate damage to the regulator.CONNECTIONS : The HPNGV Series regulator is connected to the fuel system by inlet and outlet ports. These ports use CNG compliant SAE J1926 o-ring boss connections for 3/8” size tubing at the inlet connection (9/16-18 thread) and 1/2” size tubing at the outlet connection (3/4-16 thread). These connections are labeled “INLET” and “OUTLET”. The inlet and outlet lines must be sized for sufficient flow, and the outlet fitting must provide a 3/8” minimum bore for gas flow.A coolant circulation bowl is provided which permits engine heat to warm the regulator and prevent internal icing of the regulator valve. An optional coolantcirculation bowl is available with a thermostat. Both coolant bowls are labeled for coolant inlet and outlet, adjacent to the connections. Standard coolant lineconnections are for 3/8” reinforced rubber hose, which is secured with hose clamps.An optional SAE-3 transducer port is available to allow a high pressure transducer to be directly installed in the regulator to measure inlet pressure.Optional pressure bias controls (manifold pressure reference) are available.A pressure relief device (PRD) is provided. Standard (light duty) configurations discharge directly to atmosphere, while capture pipes are available for enclosed spaces or heavy duty applications.CAUTION: The regulator’s PRD is a control and nota system safety device. It may not protect theregulator or fuel system under all possible / potential failure modes. A downstream safety valve or other failsafe strategy must be used to fully protect the fuel system and vehicle. The PRD port must not be blocked by any obstruction.MOUNTING : Two (2) M8 X 1.25 threaded holes areprovided in the regulator to enable sturdy mounting. The regulator may be oriented in any direction; however Conoflow recommends that the gas ports arehorizontally oriented to minimize exposure of the gas lines, and prevent collection of oil and moisture in the downstream line. The regulator must be rigidly mounted on the vehicle, and protected from impact of road debris.WARNING : Do not mount the regulator by gas or coolant connections only. This regulator must be securely mounted by M8 x 1.25 bolts.Please refer to the interface drawings for mounting dimensions, connection identification and connection details.SPECIFICATIONS:Maximum Operating Inlet Pressure:3600 psig (248 bar)Outlet Pressure: Factory preset – see regulator labelWARNINGConoflow’s products are designed andmanufactured using materials and workmanship required to meet applicable standards. The use of these products should be confined to services specified and/or recommended in the Conoflow catalogs, instructions, or by Conoflow application engineers.To avoid personal injury or equipment damage resulting from misuse or misapplication of a product, it is necessary to select the proper materials of construction and pressure-temperature ratings which are consistent with performance requirements.Outlet Pressure Variation in Service: -10 to +18 psi from labeled setting throughout the range of operating inlet pressure, temperature and gas flow. See flow performance graph to see effect of changes to inlet pressure and gas flow.Temperature Range: -40° F to 250° F(-40 °C to 120 °C) Connection Torques: Inlet (SAE-6): 27 ft-lbOutlet (SAE-8): 42 ft-lbTransducer (SAE-3): 8 ft-lbMounting Bolts: 15 ft-lbFlow Capacity: To 175 lb/hr of CNG. (Flowvaries by application, consultthe factory for data.)PRD Opening: 200 +/- 40 psig (optional)270 +/- 60 psig (standard)350 +/- 60 psig (optional)PRD Type: ReseatableMATERIALS OF CONSTRUCTION:Body: 6061-T6 AluminumBonnet: 6061-T6 Aluminum Diaphragm / Seals: Nitrile Rubber classValve Trim: Stainless Steel / Polyimide /PEEKNOTE: This regulator has been tested and certified for safe and reliable service in Natural Gas Vehicles. There are significant potential hazards associated with CNG which the user and / or installer must be aware of when using this product.CAUTION: Install the regulator in accordance with NFPA 52, CAN/CGA-B149.4 and other codes and standards applicable to the jurisdiction of installation and service.WARNING: CNG can cause damage and / or injury due to very high pressure, flammability, and extreme cold during expansion. Suitable safeguards must be employed during installation, commissioning and service to prevent harm to personnel and property.PRINCIPLE OF OPERATIONThe HPNGV series is a mechanical pressure regulator. The main valve, within the regulator, is coupled to a diaphragm assembly. A spring preload against the diaphragm assembly pushes the main valve open. As gas flows through the regulator, downstream pressure will increase and push the diaphragm assembly against the spring load, closing the main valve. The diaphragm and valve are dynamic, and will seek equilibrium so the inlet pressure is reduced and regulated throughout the useful range of gas flow.When the engine is shut off, gas flow through the regulator ceases. The regulator’s main valve is pulled closed by the diaphragm assembly and downstream pressure will be trapped in the low pressure side of the fuel system.An engine coolant circulation bowl is fitted over the end of the regulator to provide engine heat to the regulator valve and the gas. This heat prevents ice buildup in the regulator, which could reduce performance and regulator life.INSTALLATION GUIDELINES1. Plan the installation for the best combination ofaccessibility, protection from engine exhaustheat, mechanical vibration or impact, andsuitable mounting orientation.SEE SYSTEM IMPERATIVES ON PAGES 3 and 42. A suitable lubricant (oil, synthetic grease, etc)should be applied to the o-ring of the fitting, priorto installation, to help the o-ring seat and seal.Do not use silicon grease – silicon may poisonthe oxygen sensor in some vehicles. Install thefitting in the applicable gas port.3. If the regulator is equipped with an optional PRDcapture pipe, connect the system fitting to thecapture pipe.NOTE: If the optional ¼” NPT PRD CapturePipe is used, it must be wrench supportedduring connection.4. Attach regulator securely to vehicle, using twoM8 x 1.25 mounting bolts (not included).5. Connect the inlet, outlet, and coolantconnections. Assure any entrapped air inregulator is fully purged from coolant bowl. Ifapplicable, connect the PRD and transducer.6. Pressurize the system and perform a leak test ofgas connections with liquid leak detectionsolution or soapy water.SYSTEM IMPERATIVESImperatives are those conditions, when violated, can cause regulator or system failure and an increased risk of gas release. The following imperatives are listed with potential risks to assist the fuel system integrator with system design failure modes and effects analysis.1. Upstream Coalescing FilterAlthough the regulator is equipped with an internal filter, a suitable coalescing filter must be installed immediately upstream of the regulator. This filter should be sized for suitable flow and condensate capacity. The purpose of this filter is to prevent excessive moisture and compressor oil or particulate contaminants from entering the regulator and flowing downstream to the fuel management system.A one (1) micron filter will sufficiently protect the regulator from particulate contamination damage.This filter must be located as close to the regulator as possible to prevent any particulate in the connection between the filter and regulator from accelerating upon system pressurization, and piercing the regulator’s internal filter.2. Upstream Lockoff (solenoid) ValveA normally closed solenoid valve must be installed upstream of the regulator. This is a safety requirement to prevent gas from freely flowing during vehicle shutdown. Although the regulator is capable of bubble tight shutoff, the upstream lockoff valve is the correct safety device for this function.3. SealantsSealants are not required for the SAE o-ring boss connections. The use of sealants as a fitting leakage preventive measure can contaminate the internal passages and valve in the regulator and cause a malfunction. Sealant use in these connections will void the factory warranty.4. Inlet / Outlet LinesTo prevent excessive pressure drop at flow, the inlet and outlet fuel lines should be of suitable size. The regulator has been designed for SAE o-ring boss fittings which correspond to 3/8 inch OD tubing (SAE-6) for the inlet, and 1/2 inch OD tubing (SAE-8) for the outlet. These are the recommended line sizes. Excessively large line or fitting diameters may induce instability of the delivery pressure. The minimum bore of the fittings must be a minimum of 0.27 inch (6.8 mm) for the SAE-6 inlet fitting and 0.37 inch (9.4 mm) for the SAE-8 outlet fitting. Fittings may be of type SAE J1926/2 or SAE J1926/3.Tubing must be clean and free of burrs, which could contaminate the regulator or system. The outlet line should not be run upward from the regulator outlet port, due to the potential for excessive oil and condensate collection. A level or downward run is preferred to prevent collection.5. Downstream Relief ValveAlthough the regulator is equipped with a pressure relief device (PRD), a high flow relief valve or other protective strategy must be installed between the regulator outlet and the remainder of the fuel system. The regulator PRD is not a high flow device and may not protect the regulator or fuel system in case of sudden failure.6. Engine CoolantThe expansion of high pressure gas to low pressure creates a significant temperature drop. To prevent moisture from freezing inside the regulator and creating a blockage, heated engine coolant must be circulated within the regulator. The regulator is equipped with a coolant bowl for this purpose.Engine coolant must be maintained for at least –40 degree antifreeze protection. If the coolant were to freeze in the regulator, for any reason, the coolant containment integrity may be compromised.Suggested minimum flow: Engine idle 1-2 lpm, Moderate power 3-6 lpm, depending on engine size.7. Excessive TemperatureThe regulator is designed for safe and reliable operation within a temperature range of –40 to 250 °F. Temperatures beyond 275 °F can cause permanent damage to internal seals and must be avoided. If the regulator is located in an area with the potential for high temperature (such as radiated energy from exhaust system components, etc), suitable heat shields must be employed.8. Fitting TorqueThe correct assembly torque for the inlet (SAE-6) fitting is 27 ft-lb.The correct assembly torque for the outlet (SAE-8) fitting is 42 ft-lb.The correct assembly torque for the optional transducer port is 8 ft-lb.Inadequate torque could allow the fitting to loosen in service and leak. Excessive torque could weaken or shear the threads in the inlet and / or outlet port of the regulator.The inlet and outlet fitting is sealed with an o-ring.9. Submergence in waterExcept for bonnet bias models, the regulator uses an atmospheric reference hole in the bonnet to sense ambient pressure. This hole is “filled” with a porous hydrophobic plastic plug to prevent water intrusion from splashing, wash down, etc. This plug may not prevent water intrusion if the regulator were to be submerged in water. For this reason, the regulator should not be mounted low in a vehicle which would have to cross flooded roads, etc.10. Chemicals in FuelAny cleaners or abnormal additives, drying agents, etc in the fuel could cause damage to the regulator’s internal seals. The regulator is tolerant to substances that occur in compressed natural gas, including compressor oils, however ITT Conoflow should be contacted regarding other materials.11. Rapid or Frequent Fuel System DecompressionCNG Fuel systems should not be rapidly or frequently decompressed of gas. Doing so will cause high pressure gas absorbed in non metallic materials to attempt to escape those materials, increasing the speed of component degradation.12. Salt and/or Dirt BuildupExcessive road salt and/or road dirt buildup will accelerate moisture attack and subsequent corrosion of the regulator at the solenoid and/or gas connections. Accelerated corrosion leads to premature external gas leakage failure.The regulator must be installed in a manner which provides reasonable protection from road salt and debris accumulation, to reduce the risks of accelerated corrosion.13. Pressure AdjustmentThis pressure regulator is factory calibrated and tested. Removing the tamper evident cover from the adjustment will void the warranty.14. Fuel System ValidationThis fuel pressure regulator will dynamically respond to the CNG fuel system. In new applications it is the responsibility of the customer to validate the performance of the fuel system with this regulator. ITT cannot be responsible for the suitability of this fuel pressure regulator in every application.15. Fuel Type / Quality This fuel pressure regulator is designed and qualified for CNG fuel. RNG (Renewable Natural Gas) is acceptable, provided it meets the quality guidelines of the American Biogas Council (ABC) for CNG fuel. This fuel pressure regulator is not for use with raw biogas.As part of your fuel system and vehicle protection review, ITT recommends the incorporation of a system warning label that clearly advises maintenance technicians to 1) NOT DISABLE any automatic upstream isolation valves and to 2) CLOSE upstream isolation valves, whenever feasible during servicing.WARNING: Bleed system pressure prior to servicing or removal of the pressure regulator from the fuel system.CAUTION: Stored spring compression within the regulator can be unexpectedly released if the regulator is disassembled incorrectlyTROUBLESHOOTING:1. The regulator “pops” when I turn on ignition keyand activate tank solenoid valve(s).This is caused by downstream leakage, orintentional fuel system decompression. If thedownstream pressure bleeds down, the inrush ofhigh pressure CNG can cause the regulatoroutlet pressure to overshoot the PRD openingpressure and discharge excessive pressure fromthe line. Correct / repair any downstreamleakage to prevent system depressurizationwhen the vehicle is not operating.2. After driving the vehicle, I see frost on theexterior of the regulator and outlet fuel line.This is quite common for driving cycles wherethere is a significant amount of gas flow.Although the regulator is heated with enginecoolant, this heat is used to protect the valve,and is not sufficient to heat the fuel completely.As the fuel flows to the engine, it will pick upheat from the fuel line. Some heavy dutyapplications may require a downstream heatexchanger.3. When leak testing the system, our gas detectorshows leakage from the white plug on theregulator.A very slight amount of gas permeates from theregulator, and this is normal. A gas detector can show leakage “false alarms”, as this instrumentis very sensitive. Conoflow recommends usingcommercially available leak detection solution,or soapy water, to leak test the system.4. Loud noises are coming from the regulator.Noisy operation can be caused by a number ofsystem related issues. If incorrectfittings or line sizes are used (small bore fittings, tubing too small), the regulator may be starvedfor pressure and overshoot the steadyequilibrium it is trying to achieve. This will cause internal oscillation which can create noisesranging from a buzzing sound to a rapid internal knocking sound.In rare instances, the regulator’s resonantfrequency (typically around 380 Hz) will matchthe fuel system’s resonant frequency. Simplychanging the length of the outlet line will usuallysolve this issue.MAINTENANCEProperly designed and maintained fuel systems will increase the reliability and life of this pressure regulator.1. Follow vehicle guidelines for fuel system filter maintenance and engine coolant maintenance.2. Keep the exterior of the regulator clean to reduce buildup. Dirt or salt buildup can attract moisture and accelerate corrosion. Protective sprays may be used in areas where dissimilar metals (gas connections, etc) meet.3. Schedule leak testing to verify regulator gas containment. Leakage is the result of wear and aging; it is the inevitable failure mode of the pressure regulator.Regulator Model Breakdown (CED Code)1 through 6 HPNGV2 Regulator Base Model7 S Standard BonnetC 3/16” Straight Hose Barb Connection on BonnetE 1/4” Tube Elbow (for Poly Tubing) Connection on Bonnet8 X No Sensor Port3 SAE-3 Sensor Port4 SAE-4 Sensor PortW Sensor (Installed) 0.25 to 4.75 Volt OutputY Sensor (Installed) 0.50 to 4.50 Volt Output9 T Integral Coolant Hose ConnectionsH Brass Coolant Hose Connections10 A 200 psi (+/- 40) PRD SettingB 270 psi (+/- 60) PRD SettingC 350 psi (+/- 60) PRD Setting11 X PRD Discharges to atmosphereP 1/4” Male NPT PRD Capture PipeT 1/2” Tube Stub PRD Capture Pipe12 through 14 XXX Output Pressure Setting (PSI)CAUTION: Regulator is factory preset. Changing the pressure setting can cause unexpected and/or potentially hazardous operation. Removal of the tamperproof cover will void the warranty.CONNECTION IDENTIFICATION AND TYPICAL GEOMETRY HPNGV2S3T_X___ CONFIGURATION SHOWN – DIMENSIONS IN MILLIMETER (INCH)Interface Views – OptionsELECTRICAL INTERFACE DATAOEM pressure sensor electrical mating connector part numbers:Housing: Delphi 12065287 (with included weather seal)Contacts: Delphi 12110236Suggested wire gauge: 18 gaugeWARNING: Circuit protection with a 1A maximum current is required for sensor power lead wiring.The components above may be substituted for functional equivalents. Other contacts and seals are available for alternative wire sizes. Consult OEM connector supplier data.When selecting alternatives, the following guidelines must be considered:• Mating terminals must be tin-plated. Gold-plated connectors may cause galvanic corrosion of the connection interface and ultimately prevent the pressure sensor from operating.• Weather seals must be used between the connector bodies, and at the cable ports.Sensor polarity / pin connection diagram:Vpwr = 5.0 +/- 0.25 VDCVout = Ratiometric output (product dependent)Ground = Common ground。
燃气指南说明书
Gas GuideDealing with Gas Problems:Boiler/Heating InsuranceIf you would like the security of having your boiler and central heating maintained regularly and the peace of mind that someone will come out and carry out repairs if it breaks down then you may like to consider insurance.Your own gas supplier may offer this but you are able to take out cover from another supplier if it suits you better. Some covers can include not just your heating but a complete package which covers your plumbing and electrics too.If your system is old or you are not confident that you would be able to resolve a possible problem yourself, it may be worth considering this option. Common problems you may have with your central heating system and howyou might fix them.Radiators:Before winter sets in, you should ensure your heating system is working correctly. Ideally you should have had your heating on at regular intervals during the summer so that system continues to work efficiently.To test your radiators are working correctly, switch on the heating and make sure that the heat is spread evenly throughout each radiator. Ensure that the valves are fully turned on, on each radiator.The radiator is making a noise:If your radiators or heating system seem to be making a noise then it may mean that there is air trapped somewhere. You should check the water tank in your loft, if it is easily accessible; to make sure that there is enough water in it and that it is filling up correctly. If there is water in the tank or you do not have a tank, but a combination boiler then the problem is probably in the radiators, which can be fixed by bleeding them.The Radiator is warm at the bottom but cold at the top:If the radiators are warm at the bottom but cold at the top, then this may also mean that there is air trapped in the top section so you will need to bleed them.It is simple to bleed your radiators; you simply need to let the air out of the radiator by turning the radiator key. As you turn the key, air will be released, the water will push its way to the top, removing all the excess air and once a small amount of water comes out of the valve you should turn the key back. You should have a cloth ready in case the water is hot and to avoid any spillage.The Radiator is cold at the bottom but warm at the top:If the radiator is cold at the bottom and warm at the top and this problem persists, then there may be some sludge at the bottom of the radiator and it may need flushing out. For this, the radiator will need to be taken off the wall, flushed out with water and refitted. This can be done by yourself if you follow the correct instructions and have a basic understanding of how your heating system works but if you have not done it before or are unsure of the procedure, then you will need to call a plumber or engineer out.If several of your radiators have this problem and it is not solved by flushing the radiator out then the problem may be more serious. This could be caused by a fault with the circulating pump, blocked pipes or radiators or a badly designed system. You will need to call a professional out to look at this problem further as it may require the whole system to be flushed through or repairs to be carried out.The radiator is working correctly but not at the desired temperature.If your radiators are working correctly but are not hot enough or are too hot then you can alter the temperature by either adjusting the controls on your boiler or for more modern radiators with their own temperature controls, simply turn up or down accordingly.InsulationInsulating your house properly can save you money on your heating bills and insulating your heating system properly can save you the inconvenience and money of it breaking down.There are a few things you can do yourself to ensure your system runs well through the winter. Insulating your water tank and your pipes can prevent them from freezing up. Your water tank - usually up in your loft should havean insulating jacket on and water pipes, especially in places more exposed to the cold should have pipe insulation on them. Preventing your pipes and water tank from freezing could save you on expensive repair bills.For extra protection against the cold you can also get a frost thermostat fitted which will automatically turn your boiler on if the temperature drops below a certain level. This can give you the peace of mind if you are away for any period during the winter as a safeguard against the system freezing. It is not recommended to switch your heating off completely if you are away during the winter as if you do not have a frost thermostat you could come back to frozen pipes.Loss of pressure in your system:For a system to work properly the water pressure should remain constant. Modern combination boilers are pressurised systems and water will enter the system from the mains cold water supply through a manual filling device, known as a ‘filling loop’. Adding water via the filling loop to the system after a drop of pressure will help bring your system to the correct pressure again.There are several factors which may contribute to a loss of pressure in your heating system. It could be as a result of a water leak or air removed from the system when the radiators have been bled or removed and replaced. You check the pressure after bleeding or removing the radiators and if you notice a drop of pressure then the system will need to be topped up with water.Water leaks will also cause a drop of pressure , leaks can be very small and go unnoticed as pressure can decrease over a couple of months. Small leaks are quite hard to detect as the water evaporates quickly. If you think there is a leak, you should check the system thoroughly when it is cold especially around the radiator and boiler valves. Larger leaks will mean that you will need to regularly refill the system; these should be repaired as soon as possible.You can check the pressure of the system by using the pressure gauge which you should find on your boiler. You should check this gauge regularly to make sure it is at the correct pressure. It should be between the 1 and 1.5 bar. It should not drop below 0.5 or rise above 2.5.If the pressure is too low then you need to re-pressurise the system by topping it up via the filling loop. This is usually a small tap connected to the system via a metal hose. If the hose is not connected to the system you will need to remove the cap,the end and attach and tighten it. Once attached, you need to turn the tap, whilst watching the gauge and let enough water in to raise the gauge to the correct level (1-1.5bar).The filling loop will always be located near to the boiler but if you can't see it straight away it may be in a cupboard or perhaps behind a boarded section. If you cannot find the filling loop, consult your manufacturer's booklet or ask your service engineer.Gas emergenciesGas leak:Gas is usually a safe and easy way to heat your house but it can also be potentially dangerous if a leak occurs or an appliance is faulty.If you smell gas or think that you may have a gas leak somewhere then you should call National Grid Gas Emergencies on 0800 111 999 straight away. Open your windows and doors to let air in, make sure all gas appliances are turned off and turn the gas off at the mains if possible. Do not turn lights on or off and avoid using other electrical switches and appliances as this could trigger an explosion. Do not smoke, light a match or any other naked flame.Do not try and investigate the problem or attempt to fix a leak or a faulty appliance.Loss of gas supplyAlthough very rarely, there may be times when National Grid may have to interrupt the supply of gas to your home.They promise to give customers sufficient notice of any interruption, keep interruption to a minimum and make interruption requests on an equitable basis.Reasons for interruptions can include network capacity constraints, high system demands, testing and other emergency situations. The National Grid has to keep certain standards of performance and these state that they must notify customers of planned interruptions an in the result of an unplannedinterruption, such as an emergency, they must restore the supply as soon as is possible.Compensation may be available if they do not meet these standards and payments will be made to you either via your gas suppliers or from National Grid directly.Carbon Monoxide poisoningCarbon monoxide poisoning causes a number of accidental deaths every year when gad appliances are installed incorrectly, badly maintained or poorly ventilated. It is so deadly as you cannot see, smell it or taste it. Being exposed to carbon monoxide can cause brain damage and even death.All appliances should be safety checked and maintained and it is especially important if you live in rented accommodation that the landlord checks and maintains any gas appliances. This is a legal requirement.Although carbon monoxide is invisible and difficult to detect, there are ways that you can see whether an appliance (fires, heaters, central heating boilers, water heaters or cookers) may be dangerous. These include:•The pilot light continually blowing out•An orange and yellow flame rather than a blue one• A black, brown or scorched area on an appliance• A musty smell or signs of soot•More condensation than normal on windowsTo keep your house safe and check for the presence of carbon monoxide you can use a carbon monoxide detector. These detectors sense if there is any carbon monoxide in the air and change colour or set an alarm off to warn you. You can buy detectors in hardware or DIY stores and you should make sure that it meets the correct standard before purchasing it. The label should display BS 7860 in Britain, showing it is officially approved by the CO Alarm Standards. You should test your detector every month and replace batteries when necessary. Detectors don't last forever so you replace them as recommended by the manufacturer.Don't ever ignore the detector and if you suspect carbon monoxide is present in your home then you should evacuate everyone immediately.Symptoms of carbon monoxide poisoning can include: headaches, fatigue, dizziness, nausea, diarrhoea, stomach pains, chest pains and erratic behaviour. A faulty gas appliance can cause these symptoms and you should be wary if the symptoms worsen when a gas appliance is in use and if the symptoms lessen when away from the house but then return again when you are back in the property.Gas safety tipsGas, when not used carefully, is a potentially dangerous source of energy. Following are a number of tips about making sure the gas supply in your home is safe:•The best way to be sure about your gas appliances is to have them checked regularly by your gas supplier, or by a Corgi RegisteredInstaller. Corgi are the national watchdog for gas safety.• NEVER tamper with gas appliances yourself.•If you are in rented accommodation, it is your landlord’s responsibility to ensure that all appliances are maintained properly. If you have anyconcerns about appliances in rented accommodation, talk to yourlandlord.•Poorly maintained gas appliances ( in particular gas fires) can emit Carbon monoxide, an odourless, colourless and potentially fatal gas.Carbon Monoxide detectors can be bought relatively cheaply from most good electrical and home stores to alert you if carbon monoxide ispresent in your home.•If your carbon monoxide detector shows a presence of carbon monoxide, switch off your gas supply and call National Grid’semergency number IMMEDIATELY on 0800 111 999•If you smell gas, or think you have a gas leak in your home, turn off your gas supply, do not switch any electrical appliances on or off, orbring naked flames into your home, and call National Grid's emergency number IMMEDIATELY on 0800 111 999.Source: 。
usboiler series2系列燃气锅炉安装、操作和维护指南说明书
o y l l a cr u,r e l i obs s r i ae ho tng n i t aWe ho c.r o t c a r t nad nSr el a i r euNl eNmbmnoRn i t aunwbr es ao h sb r er eSr e l i oB s n Ibl a i r eNmuP r h2NOTE: The equipment shall be installed in accordance with those installation regulations in force in the area where theinstallation is to be made. These shall be carefully followed in all cases. Authorities having jurisdiction shall be consulted before installations are made.All wiring on boilers installed in the USA shall be made in accordance with the National Electrical Code and/or local regulations.All wiring on boilers installed in Canada shall be made in accordance with the Canadian Electrical Code and/or local regulations.The City of New York requires a Licensed Master Plumber supervise the installation of this product.The Massachusetts Board of Plumbers and Gas Fitters has approved the Series 2 boiler. See the Massachusetts Board of Plumbers and Gas Fitters website, /pubLic/pl_products/pb_pre_form.asp for the latest Approval Code or ask your local Sales Representative.The Commonwealth of Massachusetts requires this product to be installed by a Licensed Plumber or Gas Fitter.The following defined terms are used throughout this manual to bring attention to the presence of hazards of various risk levels, orto important information concerning the life of the product.34The Series 2 boilers are low pressure cast iron gas fired hot water boilers designed for use in closed hot water heating systems. These boilers are Category I draft hood equipped appliances, which must beI. PRODUCT DESCRIPTION, SPECIFICATIONS AND DImENSIONAL DATAvented by natural draft using a lined masonry or listed metal chimney system. An adequate supply of air for combustion, ventilation and dilution of flue gases must be available in the boiler room.5I. PRODUCT DESCRIPTION, SPECIFICATIONS AND DImENSIONAL DATA(CONTINUED)Figure 1: Line DrawingBoiler Model NumberDimensions [Inches]Gas Connection For Automatic Gas Valve Water Content [gallons]RecommendedVent Size[2]Approx.ShippingWeight[lb.]ABCDEFG20218-3/410-3/46-3/8445-5/88-1/210 [1]1/2 2.53" dia.212202X 20126445-5/88-1/24-3/41/2 3.24” dia.26220320126445-5/88-1/24-3/41/2 3.24” dia.26220423-1/415-1/47-5/8547-1/89-1/84-3/41/245" dia.30620526-1/218-1/29-1/4648-1/29-3/45-1/41/2 4.76" dia.35420629-3/421-3/410-7/8648-1/29-3/45-1/41/2 5.56" dia.414207332512-1/2750-1/810-3/86-5/83/4 6.27" dia.45820836-1/428-1/414-1/8750-1/810-3/86-5/83/477" dia.51420939-1/231-1/215-3/4852117-1/43/47.78" dia.55021042-3/434-3/417-3/8852117-1/43/48.58" dia.608[1] 202 only. Dimension 'G' includes allowance for 4" x 3" reducer furnished with boiler. See Figure 12.[2] Refer to the National Fuel Gas Code for equivalent areas of circular and rectangular flue linings . Maximum Allowable Working Pressure, Water - 50 PSISafety Relief Valve Pressure, Water - 30 PSI shipped from factory (std.); 50 PSI - optional6II. PRE-INSTALLATION AND BOILER mOUNTING A. INSPECT ShIPMENT carefully for any signs ofdamage. All equipment is carefully manufactured, inspected and packed. Our responsibility ceases upon delivery of Boiler to the carrier in good condition. Any claims for damage or shortage in shipment must be filed immediately against the carrier by the consignee. No claims for variances or shortages will be allowed by Boiler Manufacturer unless presented within sixty (60) days after receipt of equipment.B . BOILER INSTALLATION must conform to therequirements of the authority having jurisdiction, or in the absence of such requirements, to:U.S.A. - National Fuel Gas Code , ANSI Z223.1. When required by the authority having juris-diction, the installation must conform to ANSI/ASME No. CSD-1.CANADA - I nstallation Codes for Natural and LP GasBurning Appliances and Equipment, CAN/ CSA-B149.1.C. These Gas Boilers are DESIGN CERTIFIED FORINSTALLATION ON COMBUSTIBLE FLOORING. DO NOT INSTALL ThESE BOILERS ONCARPETING.D. LOCATE BOILER in front of or behind installationposition before removing Crate. Locate on a level floor as close to chimney as possible. For basementinstallations, provide a solid base such as concrete, if floor is not level or if water may be encountered on floor around Boiler.The boiler shall be installed such that the gas ignition system components are protected from water (dripping, spraying, rain, etc.) during boiler operation and service(circulator replacement, control replacement, etc.).E. REMOvE CRATE -1. Remove all crate fasteners. Lift off outside container.2. Remove all screws and brackets securing boiler to skid.3. Save two of the wooden slats from the container sleeve for use in Steps 4, 5 and 6.4. Tilt the boiler to one side and slide a wooden slat under the two raised feet.5. Tilt the boiler to the other side and slide another wooden slat under the two raised feet.6. Slide the boiler forward or backward off the skid using the two wooden slats as runners.F. Move boiler to permanent position.G. PROvIDE CLEARANCE and AIR forCOMBUSTION and vENTILATION.1. CLEARANCESa. ALL INSTALLATIONS - Practical service clearances must be considered (see Figure 2). A minimum of 24" (6.0cm) from the left side and front jacket panels is recommended for servicing but may be reduced to minimum shown in Figure 2. Subject to boiler and system piping, right side clearance may be reduced to 1"(2.5cm) if left side clearance is increased to 9" (22.9cm).b. ALCOvE INSTALLATIONS - An alcove is considered a closet as shown in Figure 2 less front. height clearance may be reduced to 27" (68.6cm).c. UNCONFINED SPACE (see definition,paragraph (2) below) - height clearance may be reduced to 27" (68.6cm).2. PROvIDE COMBUSTION AND vENTILATION AIR in accordance with applicable provisions of local building codes, or: U.S.A. - National Fuel Gas Code , NFPA 54/ANSI Z223.1, Canada -Natural and Propane Gas Installation Code , CAN/CSA-B149.1.7a. CLOSET INSTALLATIONS (confined space) in a building of other than unusually tight construction (see definition below), provide combustion and ventilation air as shown in Figure 2.b. Installations other than closet in paragraph (a) :i. Determine volume of space (boiler room).Rooms communicating directly with space (through openings not furnished with doors) are considered part of space. v olume [ft³](m 3) = Length [ft](m) x Width [ft](m) x height [ft](m)ii. Determine Total Input of all appliances inspace. Round result to nearest 1,000 Btu per hour (Btuh).iii. Determine type of space. Divide v olume byTotal Input.• If result is greater than or equal to 50 ft³(1.4m3) per 1,000 Btuh, space is considered an unconfined space .• If result is less than 50 ft³ (1.4m3) per 1,000Btuh, space is considered a confined space .iv. Determine building type. A building ofunusually tight construction has the following characteristics:• Walls and ceiling exposed to outsideatmosphere have a continuous water vapor retarder with a rating of 1 perm or less with openings gasketed and sealed, andFigure 2: minimum Clearances• Weather-stripping has been added onopenable windows and doors, and• Caulking or sealants applied in joints aroundwindow and door frames, between sole plates and floors, between wall-ceiling joints, between wall panels, at plumbing and electrical penetrations, and at other openings.v. For boiler located in a building of other thanunusually tight construction , adequate combustion and ventilation air is normally provided by fresh air infiltration through cracks around windows and doors.vi. For boiler located in building of unusuallytight construction , provide outdoor air through two permanent openings which communicate directly or by duct with the outdoors or spaces (crawl or attic) freely communicating with the outdoors. Locate one opening within 12 inches (30.5cm) of top of space. Locate remaining opening within 12 inches (30.5cm) of bottom ofspace. Minimum dimension of air opening is 3 inches (7.6cm). Size each opening per following:• Direct communication with outdoors.Minimum free area of 1 square inch (6.5cm 2) per 4,000 Btu per hour input of all equipment in space.• vertical ducts. Minimum free area of 1square inch (6.5cm 2) per 4,000 Btu per hour input of all equipment in space. Duct cross-sectional area shall be same as opening free area.• Horizontal ducts. Minimum free area of 1square inch (6.5cm 2) per 2,000 Btu per hour input of all equipment in space. Duct cross-sectional area shall be same as opening free area.vii. ventilation Duct Louvers and Grilles. Equipoutside openings with louvers to prevent entrance of rain and snow, and screens to prevent entrance of insects and rodents. Louvers and grilles must be fixed in open position or interlocked with equipment to open automatically before burner operation. Screens must not be smaller than ¼ inch mesh. Consider the blocking effect of louvers,grilles and screens when calculating the opening size to provide the required free area. If free area of louver or grille is not known, assume wood louvers have 20-25 percent free area and metal louvers and grilles have 60-75 percent free area.II. PRE-INSTALLATION AND BOILER mOUNTING (continued)BOILER MODEL‘W’20210¾” (27.3cm)202X 12” (30.5cm)20312” (30.5cm)20415¼” (38.7cm)20518½” (47.0cm)20621¾” (55.2cm)20725” (63.5cm)20828¼” (71.8cm)20931½” (80.0cm)21034¾” (88.3cm)III. GAS PIPINGA.CONNECT GAS SERvICE from Meter to gas controlassembly in accordance with Local Piping Codes andrequirements of Gas Company. They may requirepiping of larger size than Control AssemblyConnection, especially if run from meter is long orincludes several elbows. See Figure 1 for size of GasConnection to gas control assembly.This piping is to be supplied by the installer and mustinclude a trap, a ground joint union and a manualshutoff valve upstream of the gas control assemblyoutside of the jacket when codes require, see Figure 3.A pipe thread compound resistant to the action ofliquefied petroleum gases should be applied to allthreaded joints in the gas piping. Pressure testing of the Gas Supply Piping Boiler and its connections isrequired before placing the boiler in operation.The boiler and shutoff valve must be disconnected from the gas supply piping system during any pressuretesting at pressures greater than ½ psig (3.5kPa).The boiler must be isolated from the gas supply piping system by closing its individual manual shutoff valve during any pressure testing of the gas supply piping system at pressures equal to or less than ½ psig (3.5kPa).RECOMMENDED SIZING OF GAS SUPPLY PIPING TO BOILER FOR NATURAL GAS - shall be such as to provide the required supply of gas without undue loss of pressure between meter and the boiler. Gas supply piping should be sized in accordance with the Tables 1, 2 and 3. The following shall be taken into account:1. Allowable loss of pressure to assure a burnermanifold pressure of 3½" (8.9cm) water for natural gas.2. Supply of gas to be provided in cubic feet.3. Length of piping and number of fittings.4. Specific gravity of gas.5. Correction factor for specific gravity.Table 1: maximum Capacity of Schedule 40 Pipe in CFH for Natural Gas Pressures of ½ psig or LessLength [Feet]0.3 Inch w.c. Pressure Drop0.5 Inch w.c. Pressure Drop½¾11¼½¾11¼101322785201,0501753606801,400 2092190350730120250465950 307315228559097200375770 406313024550082170320660 505611521544073151285580 605010519540066138260530 70469618037061125240490 80439017035057118220460 90408416032053110205430 100387915030550103195400Table 2: Equivalent Length of FittingsFittingNominal Pipe Size½¾11¼45° Ell0.71 1.2 1.690° Ell 1.6 2.1 2.6 3.5 Tee (As Elbow) 3.1 4.1 5.2 6.9 Table 3: Specific Gravity Correction Factors forNatural GasSpecific Gravity CorrectionFactorSpecificGravityCorrectionFactor0.50 1.10 1.30 1.070.55 1.04 1.40 1.040.60 1.00 1.50 1.000.650.96 1.600.970.700.93 1.700.940.750.90------0.800.87------Figure 3: Recommended Gas Piping89A.BOILER WATER PIPINGclearance from combustible construction.2. Install drain valve and safety relief valve as shown in Figures 1 and 4. Note - Safety relief valve must be in vertical position.3.Pipe safety relief valve discharge to floor.4. Install Temperature and Pressure gauge externally in boiler supply piping. All required components are included at factory supplied Miscellaneous Parts Bag (P/N 103669-01). See Figure 4 ‘Near Boiler Piping’.5. Install circulator with flanges, gaskets and bolts and circulator harness provided.6. F or recommended water piping, see Figures 5 and 6. Also, consult Residential hydronic heating Installation and Design I=B=R Guide.7. If this boiler is used in connection with refrigeration systems, the boiler must be installed so that the chilled medium is piped in parallel with the heating boiler using appropriate valves to prevent the chilled medium from entering the boiler, see Figure 7. Also consult Residential hydronic heating Installation and Design I=B=R Guide.If this Boiler is connected to heating coils located in air handling units where they may be exposed to refrigerated air, the boiler piping must be equipped with flow control valves to prevent gravitycirculation of boiler water during the operation of the cooling system.8. Use a boiler bypass if the boiler is to be operated in a system which has a large volume or excessive radiation where low boiler water temperatures may be encountered (i.e. converted gravity circulation system, etc.).Install a pipe tee at the boiler return along with a second tee in the supply piping as shown in Figures 5 and 6. The bypass should be the same size as the supply and return lines with valves located in theIV. BOILER WATER PIPINGFigure 4: Near Boiler Pipingbypass and supply outlet as illustrated in Figures 5 and 6 in order to regulate water flow to maintain higher boiler water temperatures.Set the boiler supply valve to fully open position, and the boiler bypass valve to half throttle. Operate the boiler and adjust the bypass valve to achieve 180°F to 200°F supply water temperature by closing the bypass valve to decrease supply temperature or opening the bypass valve to increase watertemperature. If the bypass valve is fully opened and the boiler water temperature is still below 180°F, slowly begin closing the boiler supply valve to achieve 180°F to 200°F supply water temperature. Caution: Never fully close the boiler supply valve.10. If it is required to perform a long term pressure testof the hydronic system, the boiler should first be isolated to avoid a pressure loss due to the escape of air trapped in the boiler. To perform a long term pressure test including theboiler, ALL trapped air must first be removed from the boiler. A loss of pressure during such a test, with no visiblewater leakage, is an indication that the boiler contained trapped air.11. OxYGEN CORROSION: Oxygen contamination of the boiler water will causecorrosion of the iron and steel boiler components, which can lead to failure. As such, any system must be designed to prevent oxygen absorption in the first place or prevent it from reaching the boiler.Problems caused by oxygen contamination of boiler water are not covered by U.S. Boiler Company's standard warranty.10I V . B O I L E R W A T E R P I P I N G (c o n t i n u e d )F i g u r e 5: R e c o m m e n d e d W a t e r P i p i n g f o r Z o n e V a l v e Z o n e d H e a t i n g S y s t e m s11I V . B O I L E R W A T E R P I P I N G (c o n t i n u e d )F i g u r e 6: R e c o m m e n d e d W a t e r P i p i n g f o r C i r c u l a t o r Z o n e d H e a t i n g S y s t e m s12IV. BOILER WATER PIPING (continued)There are many possible causes of oxygen contamination such as:a. Addition of excessive make-up water as a result of system leaks.b. Absorption through open tanks and fittings.c. Oxygen permeable materials in the distribution system.In order to insure long product life, oxygen sources should be eliminated. This can beaccomplished by taking the following measures:a. Repairing system leaks to eliminate the need for addition of make-up water.b. Eliminating open tanks from the system.c. Eliminating and/or repairing fittings which allow oxygen absorption.d. Use of non-permeable materials in the distribution system.e. Isolating the boiler from the system water by installing a heat exchanger.B.OPTIONAL PROBE LWCO INSTALLATION1. A low water cutoff is required to protect a gas-fired hot water boiler when any connected heat distributor (radiation) is installed below the top of the hot water boiler (i.e. baseboard on the same floor level as the boiler). In addition, some jurisdictions require the use of a LWCO with a hot water boiler as a redundant safety control.It is recommended that the LWCO control is installed above the boiler to provide the highest level of protection. however, where the LWCO control is approved by the LWCO controlmanufacturer for installation in a high boiler tapping of a water boiler, the use of the listed LWCO control is permitted when it is installed according to the LWCO manufacturer's instructions.2. The recommended location for a LWCO on gas hot water boilers is above the boiler, in the supply piping. The minimum safe water level of a water boiler is at the uppermost top of the boiler; that is, it must be full of water to operate safely.3. Typically, in residential applications, a probe type LWCO is used instead of a float type, due to their relative costs and the simplicity of piping for aprobe LWCO.Figure 7: Recommended Piping for CombinationHeating & Cooling (Refrigeration) Systems Figure 8: Recommended Probe LWCO Location134. Piping and fittings required to install LWCO are field supplied .5. When constructing a piping tree to install LWCO select fittings (tees, elbows etc) and nipples to have the same size (NPT) as boiler supply connection. At minimum, 1-1/4” tee with ¾” branch outlet isrequired to connect the probe LWCO to the supply piping. See Figure 8. DO NOT REDUCE THE SIZE OF NEAR BOILER SUPPLY FITTINGS AND NIPPLES .6. Installation of manual shutoff valve located above the LWCO and the boiler is recommended to allow servicing. Thus LWCO probe can be removed for inspection without draining the heating system. An annual inspection of the probe is recommended.7. The presence of water covering properly installed LWCO probe will cause the normally open contact of the LWCO to close, thus providing continuity of the 24 v AC service to the boiler gas valve. When water level drops below probe, LWCO contact opens up breaking 24v supply to gas valve and preventing the boiler to fire.8. 2012 compliant Series 2 gas hot water boilers have a “plug-in” provision in factory wiring that will accept optional 24v AC probe LWCO harness connector. The optional LWCO kit (P/N 104083-01) includes 24v AC probe LWCO, harness and Instructions addressing piping, wiring and testing after installation.IV. BOILER WATER PIPING (continued)Figure 9: Recommended Auxiliary Limit LocationC. OPTIONAL AUxILIARY LIMIT INSTALLATION1. Some jurisdictions may require the use of anAuxiliary Limit control with a hot water boiler as a redundant safety control.2. The recommended location for an Auxiliary Limit on gas hot water boilers is in the supply piping. See Figure 9 for recommended location.3. Piping and fittings required to install an Auxiliary Limit are field supplied .4. When constructing a piping tree to install anAuxiliary Limit select fittings (tees, elbows etc) and nipples to have the same size (NPT) as boiler supply connection. At minimum, 1-1/4” tee with 1/2”branch outlet is required to install the limit well into the supply piping. See Figure 9. DO NOT REDUCE THE SIZE OF NEAR BOILER SUPPLY FITTINGS AND NIPPLES .5. When boiler water temperature reaches or exceeds Auxiliary Limit setting, the limit normally closed contact will open, thus interrupting the 24 v AC service to the boiler gas valve. When boiler water temperature drops below limit differential, limit contact closes restoring 24v supply to gas valve and allowing the boiler to fire.6. Gas hot water boilers equipped with Intelligent hydronic Control have a “plug-in” provision in factory wiring that will accept optional 24v AC Auxiliary Limit harness connector. The optional Auxiliary Limit kit (P/N 103696-01) includes 24v AC Auxiliary Limit, Well, harness and Instructions addressing wiring and testing after installation.14Figure 10: Blocked Vent SwitchInstallation DiagramA. INSTALL DRAFT hOOD without modification onoutlet of flue collector (See Figure 1). Secure with sheetB. INSTALL BLOCkED vENT SWITChThe blocked vent switch assembly shipped taped to the top of the boiler includes a power cord and a switch attached to a mounting bracket. The mounting bracket has a three tooth staggered comb stamping at one end with a #10 sheet metal screw in the center tooth.1. Untape the blocked vent switch assembly from the top of the boiler and uncoil the power cord.2. Blocked vent switch power cord (black and black with white stripe wires) is attached to vent damper harness with wire ties. The length of the cord is sufficient to reach the blocked vent switch installed at the left side of the draft hood skirt (see Figure 10). However, if required, use flat blade screwdriver to dislodge black strain relief bushing, securing the harness to boiler left side jacket, to adjust the length as needed.3. Position the mounting bracket (with switch attached) onto the lower edge of the draft hood skirt by locating the center tooth (with the #10 sheet metal screw) on the outside and the other two teeth inside the draft hood skirt. See Figure 10.4. Slide the mounting bracket up tight against the lower edge of the draft hood skirt, so that the #10 sheet metal screw is above the skirt's stiffening rib.5. Secure the bracket in this position by tightening the #10 sheet metal screw against the outer surface of the draft hood skirt.6. If required, reinsert the excess power cord through the jacket side panel hole to take the slack out of the wires running to up to the switch and vent damper.7. Reposition the strain relief bushing around the power cord at the jacket side panel, pinch the two halves of the bushing together, and snap it back into the hole in the jacket side panel to secure the power cord to the jacket.8. Be sure the power cord, mounting bracket, andswitch are secure and located as shown in Figure 10.V. VENTINGC . INSTALL vENT DAMPEROPEN ThE vENT DAMPER CARTON and remove the Installation Instructions. READ ThE INSTALLA-TION INSTRUCTIONS ThOROUGhLY before proceeding.The automatic gas control valve supplied on each Series 2® boiler provides the redundancy referenced inthe vent damper Installation Instructions.15Figure 11: Plug-in Damper Installation1. The vent damper must be the same size as the outlet of the Draft hood supplied with the boiler (see Figure 1). Unpack the damper carefully - DO NOT FORCE IT CLOSED! Forcing the damper may damage the gear train and void the warranty.2. Mount the vent damper assembly after the draft hood, as close to the draft hood as practicable without modification to the draft hood or vent damper. (Refer to Figure 11 and to instructions packed with the vent damper for specificinstructions). This is a must for the wiring harness to fit and the damper position indicator to be visible to3. Plug the factory harness vent damper connector into damper motor polarized receptacle and secure the harness to the damper motor bracket with providedstrain relief bushing.D. INSTALL vENT CONNECTOR1. Size 202 only - Install provided 4" x 3" vent reducer into vent damper outlet, then, install vent connector from reducer outlet to chimney.2. All other sizes - Install vent connector from vent damper oulet to chimney.3. vent installation shall be in accordance with local building codes; or the local authority havingjurisdiction; or the National Fuel Gas Code, ANSI Z223.1/NFPA 54; or the Standard for Chimneys, Fireplaces, vents, and Solid Fuel Burning Appliances, ANSI/NFPA 211. Both of theaforementioned standards, ANSI Z223.1 and ANSI/NFPA 211, specify Type B and Type L double wall metal vents and fire clay tile lined masonry chimneys as suitable chimney constructions for Category I, draft hood equipped appliances, such as this Series 2® boiler. Both standards prohibit the use of unlined masonry construction as a chimney, with the exception in ANSI Z223.1/NFPA 54 that "Where permitted by the authority having jurisdiction, existing chimneys shall be permitted to have their use continued when an appliance is replaced by an appliance of similar type, input rating, andefficiency." ANSI/NFPA 211 prohibits the use of single wall metal vent as a chimney, while ANSI Z223.1 allows it under very restrictive conditions. In Canada refer to the Natural Gas and LP Installation Code, CAN/CSA-B149.1.4. Do not connect into same leg of chimney serving an open fireplace.5. Inspect chimney for obstructions or restrictions and remove. Clean chimney if necessary.V. VENTING (continued)Figure 12: Typical Vent Installation6. vent pipe to chimney must not be smaller than outleton draft hood or damper. Although single wall ventpipe may be used, Type B is recommended. Theventing system must be arranged so that only theboiler is served by the damper device. Installationper paragraph (C) complies with this provision.7. Where two or more appliances vent into a commonvent, the area of the common vent should at leastequal the area of the largest vent plus 50% of thearea in the additional vents. Do not connect the vent of this appliance into any portion of mechanicaldraft system operating under positive pressure.8. vent pipe should have the greatest possible initialrise above the draft hood consistent with the headroom available and the required clearance fromadjacent combustible building structure. vent Pipeshould be installed above the bottom of chimney toprevent blockage.9. vent pipe should slope upward from draft hood tochimney not less than one inch in four feet. Doivent présenter des tronçons horizontaux dont la pentemontante est d’au moins ¼ po par pied (21 mm/m)entre la chaudière et l’évent. No portion of ventpipe should run downward or have dips or sags.vent pipe must be securely supported. Les sections horizontales doivent être supportées pour prévenir le fléchissement.10. vent pipe must be inserted into but not beyondinside wall of chimney liner. Seal tight between vent pipe and chimney.11. Do not install non-listed (AGA, CGA, CSA, ETL orUL) vent damper or other obstruction in vent pipe.V. VENTING (continued)IF AN ExISTING BOILER IS REMOvED -When an existing boiler is removed from a commonventing system, the common venting system is likely tobe too large for proper venting of the appliancesremaining to it.At the time of removal of an existing boiler, thefollowing steps shall be followed with eachappliance remaining connected to the commonventing system placed in operation, while the otherappliances remaining connected to the commonventing system are not in operation:1. Seal any unused openings in the common ventingsystem.2. Visually inspect the venting system for proper sizeand horizontal pitch and determine there is noblockage or restriction, leakage, corrosion, and otherdeficiencies which could cause an unsafe condition.3. Insofar as is practical, close all building doors andwindows and all doors between the space in whichthe appliances remaining connected to the commonventing system are located and other spaces of thebuilding. Turn on clothes dryers and any appliancenot connected to the common venting system. Turnon any exhaust fans, such as range-hoods andbathroom exhausts, so they will operate at maxi m umspeed. Do not operate a summer exhaust fan. Closefireplace dampers.4. Place in operation the appliance being inspected.Follow the Lighting (or Operating) Instructions.Adjust thermo s tat so appliance will operatecontinuously.5. Test for spillage at the draft hood relief openingafter 5 minutes of main burner operation. Use theflame of a match or candle, or smoke from acigarette, cigar or pipe.6. After it has been determined that each applianceremain i ng connected to the common venting systemproperly vents when tested as outlined above, returndoors, win d ows, exhaust fans, fireplace dampers andany other gas burning appliance to their previousconditions of use.7. Any improper operation of the common ventingsystem should be corrected so the installationconforms with the National Fuel Gas Code, ANSIZ223.1 and/or CAN/CSA B149.1, InstallationCodes. When resizing any portion of the commonventing system, the common venting systemshould be resized to approach the minimum size asdetermined using the National Fuel Gas Code,ANSI Z223.1 and/or CAN/CSA B149.1, InstallationCodes.16。
HPNGV2 系列汽车压缩天然气调节器使用说明和维护手册说明书
Enidine / Conoflow105 Commerce WayWestminster, SC 29693电话：(864) 647-9521传真：(864) 647-9574说明和维护手册HPNGV2 系列压缩天然气车用调节器警告：安装和启动系统前必须仔细阅读这些说明。
说明：HPNGV 系列调节器是一种自给式的降压调节器，适用于 3000 和3600 磅/平方英寸 CNG 车用燃料系统。
本调节器已经过出厂校准，不可现场调解。
本调节器根据应用需求提供各种不同的配置。
请向工人询问零件编号、维修套件或寻求配置帮助。
系统要求：高压 CNG 过滤（1 微米额定值）必须防止气体流中的颗粒物损坏调节器和下游部件。
过滤器必须安装在压力调节器的上游。
必须使用清洁无毛刺的连接件和管线，防止颗粒物损坏调节器。
连接：HPNGV 系列调节器通过进气口和排气口子连接至燃料系统。
这些端口使用 SAE J1926 O 型密封圈连接，其中进气口使用 3/8” 管件连接（9/16-18 螺纹），排气口使用 1/2” 管件连接（3/4-16 螺纹）。
排这些连接处有“进气”和“排气”标记。
进气和排气管线的尺寸必须合适，以容纳充足的气体流，且排气连接件的孔径必须至少为 3/8” ，以便于气流通过。
提供冷却液循环碗，以便发动机热量给调节器加热，防止调节器阀门内部结霜。
标准冷却液循环碗配有恒温器。
两个冷却液碗在连接处附近标记了冷却液进出口。
标准冷却液管线连接件适用于 3/8” 增强橡胶软管，该橡胶软管牢牢紧固在管夹上。
可选装 SAE-3 传感器端口，以便在调节器中直接安装高压传感器，用于测量进气压力。
可选装压力偏离控制装置（以歧管压力为参考）。
提供卸压装置 (PRD)。
标准（轻型）配置将气体直接排放到大器中，同时提供用于密闭空间或重型应用的捕集管。
注意：本调节器的 PRD 是一个控制装置，而非系统安全装置。
它可能无法在所有可能潜在的故障模式下对调节器或燃料系统提供保护。
燃气设备安装和维护手册说明书
ER2-I&S-04Swimming Pool Heaters 150,000 - 399,999 Btu/hr ModelsYour conventionally vented gas unit must have a supply of fresh air circulating around it during burner operation for proper gas combustion and proper venting.Heat exchangers and headers damaged by freezing are not covered by warranty.Refer to the WINTERIZING section.The following safety rules must be observed while operating a spa or hot tub.1.Spa or hot tub water temperatures should never exceed 104ºF (40ºC). A temperature of 100ºF (38ºC) is considered safe for a healthy adult. Special caution is suggested for young children.2.Drinking of alcoholic beverages before or during spa or hot tub use can cause drowsiness which could lead to unconsciousness and subsequently result in drowning.3.Pregnant women beware! Soaking in water above 102ºF (39ºC) can cause fetal damage during the first three months of pregnancy (resulting in birth of brain-damaged or a deformed child). Pregnant women should observe the 100ºF (38ºC) maximum rule.4.Before entering the spa or hot tub, users should check the water temperature with an accurate thermometer; spa or hot tub thermostats may err in regulating water temperatures by as much as 4º Fahrenheit (2ºC).5.Persons with a medical history of heart disease, circulatory problems, diabetes or blood pressure problems should obtain their physician's advice before using spas or hot tubs.SPA AND HOT TUB SAFETYPREVENTION OF FREEZINGƽWARNING226Maximum Capacity of Pipe in Thousands of Btu/hr per hour for gas pressures of 14 Inches Water Column (0.5 PSIG) or less and a pressure drop of 0.5 Inch Water Column (Based on NAT 1025 Btu/hr per Cubic Foot of Gas and 0.60 Specific Gravity). 39 Alternate Piping ConnectionsThe corrosive level of pool water can also be measured by the Langlier Saturation Index. This index is calculated by a formula which uses operating temperatures, total alkalinity, pH, calcium hardness and total dissolved solids. The optimum Saturation Index value is zero. A negative value indicates a corrosive condition. Your pool/spa dealer can provide additional data and equipment to make this measurement if a problem exists. TubesThis pool heater is especially designed to operate without accumulation of scale in the heat exchanger, even in very hard water. Periodic inspections of the tubes should be made to be sure that no scale is accumulating. Water piping should be disconnected at the flanges. The front header can be removed to inspect the tubes. A scale deposit of paper thickness is normal. Heavier deposits should be cleaned out. If scale is found in the tubes, THE CAUSE SHOULD BE FOUND AND CORRECTED. Removal and cleaning of the heat exchanger must be performed by a qualified serviceman or installer.The probable cause is improper water chemistry. Check the following possible causes:1. High pH.2. Improper adjustment of an external bypass.3. Inadequate pump flow.Always be sure that the filter pump is in good operating condition and runs continuously when the pool heater is in operation.Heat exchangers and headers damaged by freezing are not covered by warranty. If equipment is subject to freezing temperature, the following precautions must be observed. Although this pool heater is CSA design certified for outdoor installations - such installations are not recommended in areas where pool heater will be operated in the winter months and the danger of freezing exists. Proper freeze protection must be provided for outdoor installations, pool heaters installed in unheated mechanical rooms or where temperatures may drop to the freezing point or lower. If freeze protection is not provided for the system, a low ambient temperature alarm is recommended for the mechanical room. Damage to the pool heater by freezing is non-warrantable.1.Pump Operation - MOST IMPORTANT- This pool heateris designed for continuous operation of the filter system pump when the burners are firing. If the system pump does not run continuously an additional pump must be installed to provide constant circulation through the unit. The constant flow of warm pool water can help prevent freezing.2.Location - Indoor pool heaters must be located in a roomhaving a temperature safely above freezing [32°F(0°C)]. 3.Caution - A mechanical room operating under a negativepressure may experience a downdraft in the flue of a pool heater which is not firing. The cold outside air pulled down the flue may freeze a heat exchanger. This condition must be corrected to provide adequate freeze protection.4.Outdoor Pool Heater Installation - Use extreme caution toprevent freezing. A snow screen should be installed to prevent snow and ice accumulation around the pool heater or its venting system.5.Shut-down and Draining - If for any reason the pool heater isto be shut off when temperatures may be below 35ºF (2ºC), you must winterize the unit:(a)Shut off gas supply.(b)Shut off water supply.(c)Shut off electrical supply.(d)Remove the lower side jacket panel below thewater connections (Figure59).(e)Locate the three (3) drains on the bottom of thefront header (Figure 60).(f)Open all three (3) drains and allow the heatexchanger to drain completely. Leave drains openuntil Spring. Drain the pump and related piping.FIG. 60 Front Header- Bottom View。
发电机安装使用维护说明书 英文【范本模板】
1 Operation of generator1。
1 Preparations before start-up，including：a) Clean the work-yard and the generator set from any debris.b）Check the tightening condition, lock the gasket tightly, tack weld if necessary；keep the rotatable parts clean。
c）C heck the inlet and outlet water pipelines，oil pipelines and valves，in order to know if there are leakages and problems of water flow in the pipe。
d) Check the level of lubricating oil, oil number, oil quality, water pressure, andrecord the water temperature and ambient temperature.e）Check each connecting cable, to make sure that the joints contact well and without rust, connection is right，and the marks are complete anddistinct。
f) Check if the equipments of high-pressure oil and the brake run normally，and if the brake pressure can meet the relevant requirements.g) Check the fire extinguishing system and other protecting facilities, to ensuresecurity.h）Check the gaps between rotating parts and stationary parts, especially when there are dimension requirements。
威志双燃料维修手册-中文1正文
威志车辆CNG 部件维修Ⅰ.本公司产品的功能及维护1. CNG-TURBO-Z-A (PRESSURE 减压调节器)将通过电磁阀进来的高压(200bar)天然气，在天然气钢瓶中减压3级，以减压到大气压状态的燃气。
而且，为了防止减压时因压力下降而发生的温度下降，利用冷却水来提高燃气的温度。
1) 如紧急时在1次减压室里发生异常时，为了防止因高压引起的破损，在内部安装了安全阀。
2) 内部安装了可以正确切断燃料的电磁阀。
3) 维护部件- 更换膜片3种- 重新组装时更换0-RING2. Gas Flow Adjuster (Main Adjust Screw)通过压力调节器(PRESSURE 减压调节器) 得到控制适当温度和压力的GAS供给发动机。
1) 顺时针转动旋钮，燃料减少2) 逆时针转动旋钮，燃料增加3) 维护 : 永久 (周期性清洗)3. Duty-2000将用压力调节器(PRESSURE 减压调节器)控制为适当温度和压力的GAS，通过Lambda-2000的控制来调节燃料量。
1) DUTY : 20 Hz2) 控制范围 : `10 ~ 90 %3) 维护 : 清洗4. Lambda-2000 (OBD2000)向Duty-2000传达控制信号，以便接受发动机的rpm及氧气传感器的信号后识别尾气排放状态，可以加减燃料量。
1) DUTY 信号 : `10 ~ 90 %2) 拥有TEST 功能3) 维护 : 发生问题时更换5. GAS/Air 混合器将从气流调节器(Gas Flow Adjuster)和Duty-2000所供应的燃料，与空气进行混合的作用，且根据文丘里（VENTURI）效果，按空气的吸入量，从Gas Flow Adjuster 和Duty-2000中供应的燃料量也发生变化。
维护 : 重新组装时更换O形密封圈6. M2000CNG 转换开关(Manual Switch)1) 选择BI –FUEL 燃料使用。
威索燃气燃烧器中文说明书
安装 安装燃油设备必须按相应的标准及规定进行。因此 安装者必须确保所有的规定得到贯彻执行。应当认 真对待安装、调试及保养等各项工作。燃油要符合 DIN51603 的标准。
电气接线图 每台燃烧器都附有一详细的接线图。
章节 2 5 6 8.1 8.2 7 10 9.1 9.3
安全性 要确保燃烧器的安全运行，必须由合格的专业人员 按此说明书进行正确的安装及调试。 要 特 别 注 意 相 关 的 安 全 规 定 （ 如 DIN-VDE ， DIN-DVGW）。 火焰监测装置、限制装置，调节机构以及其它安全 装置只能由制造厂或其委托单位进行安装。 不遵守规定可能导致人员伤亡及重大物质损失等 严重后果。
保养 如在保养及检验工作中密封件被打开，在重新安装 时必须清洁密封面并注意保持密闭性能。
维护与保养 根据 DIN4755 及 DIN4756 的规定，全套设备应至 少一年进行一次维护与保养。根据实际情况还应对 相应部件的气密性进行复查。燃烧后的烟气值在每 次保养及故障处理时要进行测量。
环境条件 燃烧器及燃气阀门组的原材料、制造及防护形式一
3
2. 燃烧器的安装
安装示例
燃烧器前板上的钻孔尺寸
1-10 号
11 号
燃烧头和耐火砖之间要用“可移动” 的材料填塞，不可固定死。
规格
燃烧筒型号 尺寸（单位：毫米）
热感应关闭装置 如有要求，热感应关闭装置必须安装于球阀前。
输气管道 输气管道应由相关部门做好相应的气密性检验工 作。一般情况下，输气管道的口径最少要比燃烧器 的阀门组口径大一规格。
燃气阀门组件 要注意各个组件的安装次序及方向。双．重．电．磁．阀． （．D．M．V．）．应．尽．可．能．地．安．装．于．靠．近．燃．烧．器．燃．气．蝶．阀．的． 位．置．，．以．保．证．设．备．顺．利．启．动．及．无．故．障．运．行．。
2467.0-SM2安装使用说明书(中英文对照)
目录Contents前言Foreword (4)一锅炉安装 (5)I Boiler Installation (5)安装前的准备工作： (5)Preparation Work before Installation： (5)§1 锅炉钢结构及吊挂装置的安装 (7)§1 Installation of Steel Structure and Hanger (7)§2 锅筒的安装 (13)§2 Installation of Boiler Drum (13)§3 水冷壁 (15)§3 Installation of Water Wall (15)§4 过热系统的安装 (17)§4 Installation of Superheating System (17)§5 水冷旋风分离器的安装 (19)§5 Installation of Water-cooled Cyclone Separator (19)§6 省煤器的安装 (20)§6 Installation of Economizer (20)§7 空气预热器的安装 (21)§7 Installation of Air Preheater (21)§8 燃烧设备的安装 (21)§8 Installation of Combustion Equipment (21)§9 下水管、连接管、管道及附件的安装 (23)§9 Installation of Downcomer, Connecting Pipe, Piping and Fittings (23)§10 锅炉密封 (25)§10 Tight Seal of Boiler (25)§11 锅炉水压试验 (26)§11 Boiler Hydraulic Test (26)§12 Construction of Furnace Wall (27)§13 锅炉安装顺序 (29)§13 Installation Sequence of Boiler (29)§14.锅炉辅助机械的安装 (29)§14. Installation of Boiler Auxiliaries (29)二锅炉启动、运行 (30)II. Boiler Start-up and Operation (30)§1 锅炉机组启动前应具备的条件 (31)§1 Preconditions of Boiler Start-up (31)§2 烘炉 (33)§2 Boiler Dry-up (33)§3 化学清洗： (35)§3 Chemical Cleaning (35)§4 锅炉机组启动前的检查与准备 (36)§4 Check and Preparation Work before Boiler Start-up (36)§5 锅炉机组启动方法与步骤 (39)§5 Start Method and Procedure of Boiler Unit (39)§6 过热器及主蒸汽管道的吹扫 (41)§6 Blowing of Superheater and Main Steam Pipe (41)§7 蒸汽严密性试验及安全阀的调整 (41)§7 Steam Leakage Test and Adjustment of Safety Valves (41)§8 启动要求及注意事项 (43)§8 Start-up Requirements and Matters for Attention (43)§9 锅炉运行中的监视与调整 (46)§9 Monitoring and Adjustment during Boiler Operation (46)§10 锅炉的压火与热启动 (47)§10 Boiler Banking-up and Hot Start-up (47)§11 锅炉机组的正常停止 (49)§11 Normal Shutdown of Boiler Unit (49)§12 故障处理 (51)§13 停炉后冷态再启动 (55)§13 Cold Re-start up after Shutdown (55)§14 启动中的组织与分工 (56)§14 Organization and Work Division during Boiler Start-up (56)§15 压火注意事项 (57)§15 Attentions on Banking-up (57)§16 锅炉的经济运行管理 (57)§16 Economic Operation and Management (57)三锅炉维护与检修 (59)III Maintenance and Overhauling (59)1 锅炉设备运行中的维修 (59)1 Maintenance during Boiler Operation (59)2 锅炉定期停炉检修 (60)2 Maintenance during Periodic Shutdown (60)3 锅炉机组的停（备）用保护 (61)3 Outage (Stand-by) Protection of Boiler Unit (61)前言Foreword循环流化床锅炉是我公司生产的主要电站锅炉之一。
意大利文原版说明书翻译：IST 03 C 522 - 12 DELFIS 板换式燃气壁挂炉 安装，使
I S T 03 C 522 - 12安装，使用和维护ZH本说明书由意大利文原版说明书翻译而来用户们,非常感谢您选择并购买了我们的产品，我们请您在日常使用，维护之时仔细阅读本说明书。
注意• 我们在此通知用户：• 壁挂炉应当由有资质的人员根据现行法律法规严格按照厂家说明书进行安装。
• 不遵守相关法律法规的安装可能会对人/动物和/或物品造成伤害和损失。
• 生产商拒绝承担任何以上列出的行为而带来的合同内/合同外责任。
在某些国家，本说明书提及的某些壁挂炉型号，版本或配件可能不存在。
因此我们建议关于具体可用型号，版本以及配件请向制造商或进口商垂询信息。
生产厂商保留在不进行提前通知的情况下，进行对于产品及其零部件修改的权利。
当前使用手册是用双语写成，意大利与和中文。
当翻译和意大利原文不相符合时，以意大利原文为准。
安装人员，维修人员和用户须知本说明书是产品不可分割的必要一部分，应当由安装公司交给最终用户。
最终用户应当将其小心保存，以便查询。
当壁挂炉被售卖或出让时，本说明书应当随机器一起出售。
危险该设备可以连接一套可以加热环境的水供暖系统以及一套供人使用的生活热水管道系统。
将壁挂炉作为一切其它用途都是不合适的，并且可能会对人，动物或物品造成危险。
壁挂炉的安装必须遵守当地现行法律法规以及本说明书中的指示：错误的安装可能对人，动物或物品造成损坏，生产厂商拒绝承担由此造成的责任后果。
由于不遵守厂家规范，使用不当或错误安装而造成的损坏和赔偿，厂家拒绝承担。
在安装设备前，必须检验其技术数据是否与供暖系统要求的数据相符。
除此之外，需要检查设备是否完好，是否在运输和移动过程中受到损坏。
请不要安装明显损坏/有缺陷的壁挂炉。
不要阻挡空气进气网口。
对于所有可选配件或套件（包含电子套件），应当仅使用厂家提供的原装产品。
当安装时，不应当随意丢弃包装：所有的材料均是可循环材料，应当将其分类并丢弃到对应收集点。
在去除了包装之后，请确保儿童不会接触到包装的材料（塑料袋，纸箱等），不然会成为潜在的危险源。
燃气售后服务维修手册
售后服务维修手册（内部使用）编写：李源天然气公司使用目录服务方针： (3)服务宗旨： (3)服务目标： (3)全程服务保障安全 (3)服务思想： (3)文明售后 (3)1.小区通气流程 (4)2.户内燃气置换放散要求 (5)3.管道改造维修要求 (5)4.灶具常见故障保修范围 (5)5.灶具打不着火常见故障 (6)6.秦川燃气表打不着火处理办法 (6)6.1秦川燃气表技术参数： (6)第 1 页共15 页6.2查看燃气表电池 (6)6.3查看灶具电池是否有电 (6)6.4秦川表故障提示表 (7)7.江阴燃气表打不着火处理办法 (7)7.1江阴燃气表技术参数 (7)7.2查看燃气表上有无燃气余量 (7)7.3查看燃气表电池是否有电 (7)7.4检查灶具电池是否有电 (7)7.5江阴中威燃气表常见故障及排除办法 (7)8.宁波东海燃气表打不着火处理办法 (9)8.1宁波东海燃气表技术参数 (9)8.2查看燃气表上有无燃气余量 (9)8.3查看燃气表电池是否有电 (9)8.4检查灶具电池是否有电....................................................................... 99.宁波东海燃气表充值金额无法充入表中 .. (9)宁波东海燃气表常见故障及排除办法 (10)10.燃气热水器的安装： (12)11.前锋热水器故障判断方法： (12)11.1 JSQ16/20/24/-X8(T)型号故障代码 (12)11.2 JSQ08A6 JSQA602；16BFX故障代码H6故障代码JSQ16A420A401 20A402故障代码 (12)JSQ16/20-H4+, JSQ16/20-H5故障代码 (13)18N1故障代码 (13)11.3 JSQ16/2024-X8(T)故障代码 (13)11.4 1003TQ故障代码 (13)11.5 16-SM故障代码 (14)11.6 18N1故障代码 (14)第 2 页共15 页服务方针：诚信服务全面保障服务宗旨：用户满意才是价值服务目标：全程服务保障安全服务思想：快速反应使我们的行动准则用户满意使我们的服务目的文明售后1.公共场所不准大声喧哗2.上门服务不准迟到拖延3.预约咨询不准含糊不清4.服务规范不准执行有偏5.同事之间不准嬉戏打闹6.工具携带不准丢三落四7.在用户家不准随意乱动第 3 页共15 页8.对待问题不准推诿扯皮9.车辆工具不准乱停乱放10.信息传递不准遗勿延误1.小区通气流程1.1调压装置检漏：打开进气阀关闭出气阀，用肥皂水对进气阀、出气阀法兰、螺栓接口处进行检漏，观察燃气无泄漏为合格。
福田CNG维修手册-中英对照
福田汽油∕CNG两用燃料汽车维修手册Service Manual for Foton Gasoline/CNGDual Fuel Vehicle一、Exon1.55系统工作原理 ..................................................................................................... - 2 -I. Operating principle of Exon1.55 system .................................................................................. - 2 -二、主要零部件技术参数及维修.............................................................................................. - 3 -II. Technical parameter and repair of main parts.......................................................................... - 3 -2.1 燃气ECU...................................................................................................................... - 3 -2.1 CNG ECU ...................................................................................................................... - 3 -2.2 MAP传感器.................................................................................................................. - 4 -2.2 MAP sensor.................................................................................................................... - 4 -2.3 转换开关....................................................................................................................... - 5 -2.3 Change-over switch........................................................................................................ - 5 -2.4 VTT-D1喷轨................................................................................................................. - 6 -2.4 VTT-D1 injection rail..................................................................................................... - 6 -2.5 减压器........................................................................................................................... - 7 -2.5 Decompressor................................................................................................................. - 7 -2.6 压力表........................................................................................................................... - 8 -2.6 Pressure gauge................................................................................................................ - 8 -2.7 加气阀........................................................................................................................... - 9 -2.7 CNG refilling valve........................................................................................................ - 9 -2.8 低压过滤器................................................................................................................... - 9 -2.8 Low pressure filter ......................................................................................................... - 9 -2.9 高压电磁阀................................................................................................................. - 10 -2.9 High pressure solenoid valve ....................................................................................... - 10 -2.10 水温传感器............................................................................................................... - 11 -2.10 Water temperature sensor ........................................................................................... - 11 -三、常见故障现象及原因分析................................................................................................ - 12 -III. Common fault symptoms and cause analysis....................................................................... - 12 -一、Exon1.55系统工作原理I. Operating principle of Exon1.55 systemExon1.55系统是一种燃气多点顺序喷射供气系统。
Electrolux Central Vacuum Systems 使用与维护说明书
or near children. • Use this vacuum only for its intended use as described in this manual. (Use of attachments not
recommended by manufacturer may cause fire, electric shock, injury or damage to system components.) • Never operate this vacuum if it has a damaged cord or plug, if it is not working properly, or if it has
燃气安全使用承诺书
燃气安全使用承诺书篇一：燃气安全使用承诺书(中英文)Safety Guarantee of Indoor Natural Gas Operation根据北京S政府《关于加强室内燃气设施安全管理的通告》精神，为了避免因对户内燃气设施的私接乱改而造成安全隐患及安全事故，本人保证做到：According to theauthorized by Beijing municipal government, and in order to avoid hidden factors of accidents caused by reconstruction of the indoor natural gas pipe or meters without permission, I promises to do as follow:１．严格遵守有关燃气的法规、规定，自觉维护户内燃气设施的安全。
Strictly comply with relevant rules and regulations, and maintain a safe environment for the indoor natural gas facilities.２．不随意改动、包封室内燃气管道、设施。
Do not relocate and seal indoor natural gas pipeline and facilities.３．确须拆除、改装、迁移、安装燃气管道、热水器时，应请具有相应资质的燃气安装、维修资质的企业或个人拆改、迁移、安装燃气管道和设施。
If it is necessary to dismantle, refit, relocate, or install natural gas pipeline and water heater, only licensed companies or / and technicians are authorized to carryout the above works.４．自觉抵制盗用正规企业名义进行欺诈活动的非法“小广告”，以免上当受骗，造成安全事故。
安装,使用及维护说明书
67 D4196
燃烧室压力 – mbar
4.8
4.0
3.2
2.4
1.6
0.8
0
D5212
80 70,000
100
120
140
160
180
200
220
kW
90,000
110,000 130,000 150,000 170,000 190,000 kcal/h 燃烧器出力
2977
4
3.4 电气连接 3.4.1 标准电气连接
离子探针 点火电极
点火变压器
空气压力开关
马达 兰色 白色 黑色
兰色 黑色 褐色
风门伺服马达
连接插头
控制盒 RMG 88.620A2
燃烧器接地 整流器
电容
由安装方负责
注意
在供电电源中若是相相供电 （不带零线时）, 控制盒上的 接地端子应与端子 6 短接 .
2977
1
2. 技术参数
2.1 技术参数
燃烧器出力
(1)
天然气
( 品种 2)
电源 马达 马达启动电容 点火变压器 电功耗
81 – 220 kW - 70,000 – 189,000 kcal/h
净热值 : 8 – 12 kWh/Nm3 - 7,000 – 10,340 kcal/Nm3
压力 : min. 20 mbar - max. 100 mbar
5. 维护 . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
6. 故障 / 解决方法 . . . . . . . . . . . . . . . . . . . . 11
气体安装和使用说明书
If the hob is gas, it is recommendable to place the separator at the same distance. On wood work surfaces, varnish the cutting surfaces with a special glue. This protects them from moisture which could collect under the work surface.
Safety instructions
Connection of Town Gas rubber tube -Use approved gas tubing bearing EMSD approval marking (example : 機電工程署批准EMSD APPROVAL GTXXXX) for connection to appliances, or other approval methods by EMSD.
- 1、下载文档前请自行甄别文档内容的完整性，平台不提供额外的编辑、内容补充、找答案等附加服务。
- 2、"仅部分预览"的文档,不可在线预览部分如存在完整性等问题,可反馈申请退款(可完整预览的文档不适用该条件!)。
- 3、如文档侵犯您的权益，请联系客服反馈,我们会尽快为您处理(人工客服工作时间：9:00-18:30)。
136万t/a球团工程项目供货商文件Brazil 1.36 million t / a pellet project in supplier单项工程名称：136万t/a球团工程Single Work Name Brazil 1.36 million t / a pellet project一，天然气烧嘴设备结构特点First, the structural characteristics of natural gas burner equipment1.1安装方式：水平安装。
1.1 Installation: horizontal installation.1.2天然气、空气与烧嘴采用金属软管连接。
1.2 natural gas, air and burner metal hose.1.3天然气火嘴配有空气喷枪和天然气喷枪、看火孔、高能点火烧嘴、火焰检测器以烧嘴砖部分。
1.3 Natural gas burner with the air gun and gas gun, watching the fire hole, high-energy ignition burner, the flame detector to block part of the burner1.4烧嘴喷枪采用套管结构，空气壳体和天然气喷枪可独立装卸。
天然气枪带有空气涡流导流器，燃烧空气经过气体涡流导流器后可以获得非常强劲的涡流状态。
当气体离开喷嘴时，气体的速度达到最大。
再通过带有耐火锥筒扩散器的气枪喷出。
在耐火锥筒的导流作用下，空气与天然气垂直相交，从而达到空气与天然气的完全预混合。
形成高强度预混式旋流燃烧，这种设计能够使火焰保持稳定高的设备弹性比。
1.4 burner tube structure with gun, air gun shells and natural gas can be independent of loading and unloading. Gas gun with an air swirl diffuser, combustion air through the gas swirl diffuser can be very strong after the vortex state. When the gas leaving the nozzle, the gas velocity reaches the maximum. With the fire and through the diffuser cone spray nozzles. Diversion in the fire under the cone, perpendicular to the air and gas, air and gas so as to achieve full pre-mixed. The formation of high-strength premixed swirl combustion, this design can make the flame stable than the high flexibility of equipment.1.5烧嘴设有看火孔以便现场观察火焰；自带空气吹扫入口。
1.5 burner with holes for observation to see the fire flame; own air purge inlet.1.6火焰检测器在高能点火烧嘴和主火嘴燃烧时均能正确判断火焰燃烧情况，作为火焰管理系统做点火控制和熄火保护依据。
1.6 flame detector in the high-energy ignition burner and the main burner combustion flame can correctly judge the situation, as do the ignition flame management system based on control and flame protection1.7烧嘴砖是由耐火衬里构成，衬里材料最高使用温度不大于1450℃。
衬里进行烘干处理，保证达到技术要求。
1.7 burner tiles constituted by the refractory lining, lining the maximum use temperature of not more than 1450 ℃. Lining for drying, to ensure that meet the technical requirements.1.8烧嘴能在以下条件下持续运行：烧嘴的操作弹性范围：30～130％,连续运行；在低负荷运行情况下，完全没有回火的危险。
燃烧器的允许压力降：燃料料≯400mmH2O, 空气≯300mmH2O。
天然气烧嘴燃烧能力调节比：1:10天然气进入乙方总管道调压阀前最大压力0.1 MPa（g）空气最大操作压力10kPa（g）火嘴燃气最大操作压力：10kPa（g）火嘴机械设计压力： 1.0MPa（g）火嘴机械设计温度：350 ℃1.8 burner to run continuously under the following conditions:Operating flexibility burner range: 30 to 130%, continuous operation; at low load operating conditions, there is no risk of backfire.Allowable pressure drop burner: fuel material ≯400mmH2O, air ≯300mmH2O.Ability to adjust the burner combustion gas ratio: 1:10B mains gas pressure regulator before entering the maximum pressure 0.1 MPa (g)Air Max operating pressure 10kPa (g)Maximum operating pressure of gas burners: 10kPa (g)Mechanical design pressure burner: 1.0MPa (g)Burner mechanical design temperature: 350 ℃1.9烧嘴采用空气和燃气比例调节方式。
链篦机及其热风管道通过热电阻测得温度型号传至PLC系统，预先设定系统来控制助燃空气阀组上的电动执行器，调节电动执行器的开度。
由Ø8信号管把压力信号传递给空燃比例调节阀形成压力联动，从而完成比例调节燃烧的方式。
给在天然气和空气管路均装有控制阀和安全装置。
在天然气总管上设有燃气减压阀、高低压检测保护、快速切断阀（电磁阀）等。
在空气总管上设有空气低压检测。
此外，每只烧嘴设有燃气比例阀、燃气电磁阀、空气电动调节阀及各种手动阀等组成烧嘴的燃烧系统，自动根据炉温要求调节烧嘴的燃烧能力，此外每只烧嘴还设有一个火焰监测装置实现燃烧全过程连续监视，一旦没有测到火焰，系统便会自动关闭天然气管路上的电磁阀。
1.9 ratio of air and gas burner by way of regulation. Grate and the hot air pipe temperature measured by thermal resistance model spread PLC systems,pre-combustion air valve system to control the electric actuators, electric actuators adjust the opening. By the Ø8 signal to control the pressure signal to the air-fuel ratio to form the pressure regulating valve cases of linkage to adjust the combustion ratio of the way complete. To the gas and air pipes are fitted with control valves and safety devices. Explorer is equipped with gas in the gas valve, high and low voltage detection protection, rapid shut-off valve (solenoid valve) and so on. Explorer on the air with air pressure testing. In addition, the proportion of each burner has a gas valve, gas solenoid valves, air valves and electric control valves and other components of various manual burner combustion system automatically adjust the burner combustion furnace capacity required, in addition to each burner There is also a burning flame monitoring device to achieve the whole process of continuous monitoring, once the flame is not detected, the system will automatically turn off natural gas on the way solenoid valve.1.10燃烧系统由燃气喷嘴、燃气阀系、风机、燃气流量调节阀、空气调节装置、点火装置、燃气压力检测开关、空气压力检测开关及火焰监测装置等组成。
点火时既可以手动，也可以自动。
当手动点火时，调到手动位置时，启动高能点火器，打开点火电磁阀，点着点火烧嘴，稳定后再开启天然气电磁阀，点燃主烧嘴，适当调整风阀。
1.10 combustion system by the gas nozzle, gas valves, fans, gas flow control valve, air conditioning, ignition device, gas pressure detection switch, air pressure switch and flame detection monitoring devices and other components. When the ignition either manually or automatically. When the manual ignition, transferred to the manual position, start the high-energy ignition, turn the ignition solenoid valve, lit burner ignition, stability, and then open the gas solenoid valve, ignite the main burner, adjust the air valve.1.10.1手动点火1.10.1 Manual ignition（1）、先做好通风准备工作，启动送风机，检查其是否正常运转，能否达到所需压力，启动后停止；(1), the first well ventilated preparation to start the blower, check for normal operation, can achieve the required pressure, started to stop;（2）、检查烧嘴前管路各阀门是否处于关闭状态，观察燃气压力表指示是否正确；(2), check whether the valve pipe before the burner is turned off to observe the gas pressure gauge is correct;（3）、检查烧嘴的通风阀调到需要的位置。
