OnCreate(LPCREATESTRUCT lpCreateStruct) 参数lpCreateStruct参数详解

工具栏进行设置

LPCREA TESTRUCT是一个指向结构CREA TESTRUCT的指针.以下是该结构的信息:

The CREA TESTRUCT structure defines the initialization parameters passed to the window procedure of an application.

typedef struct tagCREA TESTRUCT { // cs

LPVOID lpCreateParams;

HINSTANCE hInstance;

HMENU hMenu;

HWND hwndParent;

int cy;

int cx;

int y;

int x;

LONG style;

LPCTSTR lpszName;

LPCTSTR lpszClass;

DWORD dwExStyle;

} CREA TESTRUCT;

Members

lpCreateParams

Contains additional data which may be used to create the window. If the window is being created as a result of a call to the CreateWindow or CreateWindowEx function, this member contains the value of the lpParam parameter specified in the function call.

If the window being created is an MDI window, this member contains a pointer to an MDICREA TESTRUCT structure.

Windows NT: If the window is being created from a dialog template, this member is the address of a SHORT value that specifies the size, in bytes, of the window creation data. The value is immediately followed by the creation data. For more information, see the following Remarks section.

hInstance

Handle to the module that owns the new window.

hMenu

Handle to the menu to be used by the new window.

hwndParent

Handle to the parent window, if the window is a child window. If the window is owned, this member identifies the owner window. If the window is not a child or owned window, this member is NULL.

cy

Specifies the height of the new window, in pixels.

cx

Specifies the width of the new window, in pixels.

y

Specifies the y-coordinate of the upper left corner of the new window. If the new window is a child window, coordinates are relative to the parent window. Otherwise, the coordinates are relative to the screen origin.

x

Specifies the x-coordinate of the upper left corner of the new window. If the new window is a child window, coordinates are relative to the parent window. Otherwise, the coordinates are relative to the screen origin.

style

Specifies the style for the new window.

lpszName

Pointer to a null-terminated string that specifies the name of the new window.

lpszClass

Pointer to a null-terminated string that specifies the class name of the new window.

dwExStyle

Specifies the extended style for the new window.

Remarks

Windows NT: Y ou should access the data represented by the lpCreateParams member using a pointer that has been declared using the UNALIGNED type, because the pointer may not be DWORD aligned. This is demonstrated in the following example:

typedef struct tagMyData

{

// Define creation data here.

} MYDA TA;

typedef struct tagMyDlgData

{
