振动筛外文翻译Line Vibrating Screen overviewThe use of linear vibrating screen Vibrating motor as vibration source excitation, so that materials in the sieve to be toss-line, at the same time for straight forward exercise, material from the feeder evenly into the screening machine feed through the mesh have a number of multi-storey sieve specifications on materials, sieve under物, separately from their respective export discharged. With low energy consumption, high output, simple structure, easy maintenance, full-closed structure, no dust, automatic nesting, more suitable for pipelined operation .Linear Vibrating Screen Working Principle:Linear Vibrating Screen Vibrating motor-driven double, when the two make Vibrating motor synchronization, anti-缶rotation, the eccentric block excitation forcegenerated by the electrical axis in parallel to the direction of offset each other, perpendicular to the motor shaft at the direction of stack for the one together, so the exercise machine for straight line trajectory. Its two-motor shaft relative screen surface has a dip in the excitation force and material self-gravity force role, the materials in the sieve surface by leaps and bounds toss straight forward for the sport, so as to achieve on the materials selection and classification purposes. Can be used to achieve automated assembly line in operation.With low energy consumption, high efficiency, simple structure, easy maintenance, full-closed structure without dust溢散characteristics. Maximum 325 mesh screen mesh can be screening outof seven kinds of different particle size materials.The use of linear vibrating screenOf powder, granular materials selection and classification, widely used in plastics, abrasives, chemicals, medicine, building materials, food, carbon, fertilizer and other industries.Linear Vibrating Screen (straight-line screen) is a new type of highly efficient screening equipment, widely used in mining, coal, metallurgy, building materials, refractories, light industry, chemical industry. Linear Vibrating Screen (linear sieve) stable and reliable, consume less, low noise, long life, vibration-type steady, screening and high efficiency.Linear Vibrating Screen technical parametersSZF-520-type 1S-Q235A or SUS304 2000 × 500 × 1200 1 layer (1S) 2 layer (2S)3 layers (3S)4 layers (4S)SZF-525-type 1S-Q235A or SUS304 2500 × 500 × 1200 1 layer (1S) 2 layer (2S)3 layers (3S)4 layers (4S)SZF-825-type 1S-Q235A or SUS304 2500 × 800 × 1200 1 layer (1S) 2 layer (2S)3 layers (3S)4 layers (4S)SZF-820-type 1S-Q235A or SUS304 2000 × 800 × 1200 1 layer (1S) 2 layer (2S)3 layers (3S)4 layers (4S)SZF-1025-type 1S-Q235A or SUS304 2500 × 1000 × 1500 1 layer (1S) 2 layer(2S) 3 layers (3S) 4 layers (4S)SZF-1225-type 1S-Q235A or SUS304 2500 × 1200 × 1500 1 layer (1S) 2 layer(2S) 3 layers (3S) 4 layers (4S)SZF-1235-type 1S-Q235A or SUS304 3500 × 1200 × 1600 1 layer (1S) 2 layer(2S) 3 layers (3S) 4 layers (4S)SZF-1536-type 1S-Q235A or SUS304 1500 × 3600 × 1200 1 layer (1S) 2 layer(2S) 3 layers (3S) 4 layers (4S)Information on the use of instructionsFeatures ? ?1) unique mesh design, convenient and rapid replacement of screen (only 3-5 minutes), in addition to such designPermit the use of mesh (nylon, special long, PP Net).2) screen design; compact and easy to assemble, one person can operate machine. 3) and other related brands comparison, a larger filter area and high efficiency of processing power.4) the parent fully support Net Net fine, so fine-Net can be an exclusive right of a longer life expectancy, and reduce the use of fine-Net supplies, deposition time of the production process can reduce a lot of cost.Linear vibrating screen role and the principle ofThe basic principles of the Department of Motor Borrow shaftinstalled on the bottom of a heavy hammer (Heng uneven weight), the rotation of motor sport will be transformed into horizontal, vertical, inclined three-sport, and then communicated to the sports screen surface. If the change in weights up and down the Department of the phase angleof the road can change the direction of raw materials.Electrical Usage:This series of motors to meet the following conditions when continuous output rated excitation.1, vibration acceleration: no more than 7g (g: acceleration due to gravity) 2, ambient temperature: not more than 40 ?3, above sea level: not exceed 1000m4, power supply frequency: 50Hz5, voltage: 380V6, the temperature rise: less than 80K (resistance method)Linear vibrating screen, as well as the various parts of thestructure function .This machine mainly by the screen box, screen frames, screen,vibration motor, electric pedestal, damping spring, frame and so on.1, sieve boxes: from a few different kinds of thickness of steel plate welded together with a certain degree of strength and stiffness, are the main machine components. 2, screen box: deformation from pine or smaller made of wood, mainly used tomaintain the mesh formation, the normal screen.3, screen: there is low-carbon steel, brass, bronze, several species such as stainless steel wire mesh.4, Vibrating motor (using the repair method with the use ofVibrating motor detailed instructions).5, the electrical pedestal: Vibrating motor installation, use pre-connect screw must be tightened, especially the new machine three days before trial must be repeated fastening to prevent loosening of the accident.6, damping spring: to prevent vibration to the ground, while supporting the full weight of the sieve case, the installation, the spring must be vertical with the ground. 7, frame: from the four pillars and two channel components to support the screen box, the installation must be vertical with the ground pillars, two pillars of the following should be mutually parallel channel.Linear vibrating screen to install the pre-preparation1, check whether the motor signs in line with the requirements.2, using 500-volt megohm insulation resistance measurement table, and its value to deal with stator windings drying treatment, drying temperature should not exceed 120 ?.3, inspection of all electrical fasteners, to guard against loosening. 4, check whether the damage to the electrical surface deformation.5, check whether the rotating flexible, if abnormal, should be excluded. 6, check power supply, whether the lack of phase, and no-load operation of 5 minutes.Installation and adjustment1, the electrical be fasteners at the installation level, the installation must be smooth and flat.2, the level of motor can be installed.3, the electrical lead-core rubber cable using four YZ-500V, thenthe power cable isnot allowed when there is urgency pinout folding and reliable fixed-body vibration. 4, the electrical grounding should be reliable, there is within the electrical grounding device, lead client has signs at the end of the foot can also make use of a solid grounding bolt.5, the adjustment of excitation force.Linear vibrating screen use and repair1, the machine should be installed in the electrical protection device. 2, the machine is running early, check every day for at least one anchor bolts to prevent loosening.3, when the motor rotation direction inconsistent with the requirements, you can adjust the power phase sequence.4, the electrical should guarantee good lubrication, each running about two weeks to add lithium-based grease (ZL-3) once, come on, through the oil cups add appropriate amount of lithium-based grease. When the use of sealed bearings, the motor is not installed on the oil cup.5, the machine is running a total of 1500 hours, they should check the bearings, if serious injury should be immediately replaced.6, the local parking again after a longer period of time when used in insulation resistance should be measured for the 500-volt megohm table measurements, should be larger than 0.5 megohm.Linear Vibrating Screen routine maintenance1, start before:(1) Inspection of rough and fine Net Net availability of breakage(2) to check whether the removal of transport support. 2, start at:(1) watch for abnormal noise(2) whether the current stability(3) whether the vibration3, use: that is, each time after use clean up.Regular maintenanceNet regular inspection of rough, small networks and the availability of spring fatigueand damage, whether the various parts of the airframe vibration caused damage, needto add lubricants lubrication parts must come on.直线振动筛概述直线振动筛利用振动电机激振作为振动源，使物料在筛网上被抛起，同时向前作直线运动，物料从给料机均匀地进入筛分机的进料口，通过多层筛网产生数种规格的筛上物、筛下物、分别从各自的出口排出。
