路的分析设计----RMxprt
磁钢数据 PERMANENT MAGNET DATA 剩磁密度 Residual Flux Density (Tesla): 1.23 矫顽力 Coercive Force (kA/m): 890 最大磁能积 Maximum Energy Density (kJ/m^3): 273.675 相对磁回复磁导率 Relative Recoil Permeability: 1.09981 退磁磁通密度 Demagnetized Flux Density (Tesla): 0.714922 回复剩磁密度 Recoil Residual Flux Density (Tesla): 1.23 回复矫顽力 Recoil Coercive Force (kA/m): 890
qq 117425040 #201Fra Baidu bibliotek005
路的分析设计----RMxprt
起动时电枢反应安匝 Armature Reactive Ampere Turns at Start Operation (A.T): 462.347 漏磁系数 Leakage-Flux Factor: 1 定子轭部磁路长修正系数 Correction Factor for Magnetic Circuit Length of Stator Yoke: 0.30529 转子轭部磁路长修正系数 Correction Factor for Magnetic Circuit Length of Rotor Yoke: 0.766768 空载转速 No-Load Speed (rpm): 3289.43 齿槽转矩 Cogging Torque (N.m): 0.464021
qq 117425040 #2013005
路的分析设计----RMxprt
满载数据 FULL-LOAD DATA 平均输入电流 Average Input Current (A): 44.4366 绕组电流有效值 Root-Mean-Square Armature Current (A):38.0006 绕组热负荷 Armature Thermal Load (A^2/mm^3): 64.0006 绕组线负荷 Specific Electric Loading (A/mm): 14.0924 绕组电流密度Armature Current Density (A/mm^2): 4.54151 风摩损耗 Frictional and Windage Loss (W): 0 铁心损耗 Iron-Core Loss (W): 148.168 绕组铜耗 Armature Copper Loss (W): 51.0173 开关损耗 Transistor Loss (W): 0 二极管损耗 Diode Loss (W):0 总损耗 Total Loss (W): 199.186
qq 117425040 #2013005
路的分析设计----RMxprt 理想反电势常数Ideal Back-EMF Constant KE (Vs/rad): 0.210737 启动转矩常数Start Torque Constant KT (Nm/A): 0.204433 额定转矩常数Rated Torque Constant KT (Nm/A): 0.220631 空载磁路数据 NO-LOAD MAGNETIC DATA 定子齿磁密Stator-Teeth Flux Density (Tesla): 0.909119 定子轭磁密Stator-Yoke Flux Density (Tesla): 2.17221 转子轭磁密Rotor-Yoke Flux Density (Tesla): 0.234834 气隙磁密Air-Gap Flux Density (Tesla): 0.720152 磁钢磁密Magnet Flux Density (Tesla): 0.758615 定子齿旁通因子Stator-Teeth By-Pass Factor: 8.66656e-005 定子轭旁通因子Stator-Yoke By-Pass Factor: 0.0171136 转子轭旁通因子Rotor-Yoke By-Pass Factor: 8.10197e-006 定子齿安匝数Stator-Teeth Ampere Turns (A.T): 1.10913 定子轭安匝数Stator-Yoke Ampere Turns (A.T): 708.303 转子轭安匝数Rotor-Yoke Ampere Turns (A.T): 0.204423 气隙安匝数Air-Gap Ampere Turns (A.T): 312.94 磁钢磁势Magnet Ampere Turns (A.T): -1023.25
qq 117425040 #2013005
路的分析设计----RMxprt
转子数据 ROTOR DATA 气隙长度Minimum Air Gap (mm): 0.5 转子内径Inner Diameter (mm): 22 转子铁心长度Length of Rotor (mm): 80 转子铁心叠压系数Stacking Factor of Iron Core: 转子铁心材料Type of Steel: DW315_50 转子极弧半径Polar Arc Radius (mm): 51 机械极弧系数Mechanical Pole Embrace: 0.7 电极弧系数Electrical Pole Embrace:0.721063 最大磁钢厚度Max. Thickness of Magnet (mm): 磁钢宽度Width of Magnet (mm): 21.7712 磁钢材料类型Type of Magnet: NdFe35 磁钢结构类型Type of Rotor: 2 是否考虑轴导磁Magnetic Shaft: No
qq 117425040 #2013005
路的分析设计----RMxprt
稳态参数 STEADY STATE PARAMETERS 定子绕组系数Stator Winding Factor: 0.933013 D-轴电枢反应电抗D-Axis Reactive Inductance Lad (H): 3.99226e-005 Q-轴电枢反应电抗Axis Reactive Inductance Laq (H): 3.99226e-005 D-轴同步电抗D-Axis Inductance L1+Lad(H): 0.000101088 Q-轴同步电抗Axis Inductance L1+Laq(H): 0.000101088 电枢绕组漏电抗Armature Leakage Inductance L1 (H): 6.1165e-005 零序电抗Zero-Sequence Inductance L0 (H):4.57943e-005 电枢绕组相电阻Armature Phase Resistance R1 (ohm): 0.0117765 电枢绕组20度时候电阻Armature Phase Resistance at 20C (ohm): 0.00968712 D-轴时间常数D-Axis Time Constant (s): 0.00339002 Q-轴时间常数Q-Axis Time Constant (s): 0.00339002
路的分析设计----RMxprt 主要性能数据 GENERAL DATA 给定输出功率 Rated Output Power (kW): 3 额定电压 Rated Voltage (V): 72 极数 Number of Poles: 10 给定转速 Given Rated Speed (rpm): 3000 摩擦损耗 Frictional Loss (W): 0 风摩损耗 Windage Loss (W): 0 转子位置 Rotor Position: Inner 负载类型 Type of Load: Constant Power 绕组连接形式 Type of Circuit: Y3 触发超前角Lead Angle of Trigger in Elec. Degrees: 0 触发脉宽 Trigger Pulse Width in Elec. Degrees: 120 晶体管压降One-Transistor Voltage Drop (V): 0 二极管压降One-Diode Voltage Drop (V): 0 工作温度Operating Temperature (C): 75 斩波控制最大相电流Maximum Current for CCC (A): 斩波控制最小相电流Minimum Current for CCC (A):
