第一章绪论本章介绍了双向DC/DC变换器（Bi-directionalDC/DCConverter，BDC)的基本原理概述、研究背景和应用前景，并指出了目前双向直流变换器在应用中遇到的主要问题。
1.1双向DC/DC变换器概述所谓双向DC/DC变换器就是在保持输入、输出电压极性不变的情况下，根据具体需要改变电流的方向，实现双象限运行的双向直流/直流变换器。
相比于我们所熟悉的单向DC/DC变换器实现了能量的双向传输。
实际上，要实现能量的双向传输，也可以通过将两台单向DC/DC变换器反并联连接，由于单向变换器主功率传输通路上一般都需要二极管，因此单个变换器能量的流通方向仍是单向的，且这样的连接方式会使系统体积和重量庞大，效率低下，且成本高。
所以，最好的方式就是通过一台变换器来实现能量的双向流动，BDC就是通过将单向开关和二极管改为双向开关，再加上合理的控制来实现能量的双向流动。
1.2双向直流变换器的研究背景在20世纪80年代初期，由于人造卫星太阳能电源系统的体积和重量很大，美国学者提出了用双向Buck/Boost直流变换器来代替原有的充、放电器，从而实现汇流条电压的稳定。
之后，发表了大量文章对人造卫星应用蓄电池调节器进行了系统的研究，并应用到了实体中。
1994年，香港大学陈清泉教授将双向直流变换器应用到了电动车上，同年，F.Caricchi等教授研制成功了用20kW水冷式双向直流变换器应用到电动车驱动，由于双向直流变换器的输入输出电压极性相反，不适合于电动车，所以他提出了一种Buck-Boost级联型双向直流变换器，其输入输出的负端共用。
1998年，美国弗吉尼亚大学李泽元教授开始研究双向直流变换器在燃料电池上的配套应用。
可见，航天电源和电动车辆的技术更新对双向直流变换器的发展应用具有很大的推动力，而开关直流变换器技术为双向DC/DC变换器的发展奠定了基础。
1994年，澳大利亚FelixA.Himmelstoss发表论文，总结出了不隔离双向直流变换器的拓扑结构。
双向DCDC变换器
双向DCDC变换器1、什么是双向DCDC在储能系统、以及汽车动力系统中，存在既需要向负载供电，又存在给电池等放电的情况，我们也把这种电流反向馈入电源侧的模式称为馈电，也称这种能量可以双向流动的开关变换器为双向变换器（Bi_direactional DC/DC Converter）。
同样其也分为隔离与非隔离。
之前我们介绍的变换器均只有一个开关管，且只能实现电流的单一反向流动，所以其能量也是单相传递。
其实从理论上来说，比如buck电路正向来看是降压，反向看其实就是升压电路，所以我们只需要让该电路能够正向实现降压，反向实现升压就可以变成双向变换器。
比较简单一点的话就是用一个单向buck电路与boost电路进行并联，但是成本有点高。
下面我们就通过buck电路和boost电路合并成双向变换器:上图通过传统的buck电路和boost电路合成最终的双向buck电路，这个电路算是非常经典的双向DCDC电路了，并且在目前也是应用非常广泛的。
如果不进行同步整流情况下，buck模式打上管子储能，下管关闭，通过下管二极管实现续流，电流从左向右流动实现降压效果。
同样反向boost模式，下管导通使得电感储能，通过上管的反向二极管实现续流，所以两个开关管之间要留有足够的死区时间，避免短路直通，损坏器件。
然而其具体工作在buck模式还是boost模式需要根据占空比和两侧电压大小来确定，且对于双向buck电路电流没有断续模式，同样也是遵循电感的伏秒平衡和电容的安秒平衡。
