安卓TV开发(四) 实现主流智能TV视频播放器UI

安卓TV开发（四）实现主流智能TV视频播放器UI在FocusView中需要添加一个FocusItemModle 用于填充父布局，这个FocusItemModle 类似grideView中itemview一样,我们可以这么理解，现在我们就定义一个FocusItemModle 类，代码如下：[java] view plain copy print?在CODE上查看代码片派生到我的代码片public class FocusItemModle {private View mFocusView = null;/*** 起点行数*/private int mRow = 0;/*** view占据行数*/private int mRowSpan = 1;/*** 起点列数*/private int mCol = 0;/*** View占据列数*/private int mColSpan = 1;/*** @param v* @param row* @param col*/public FocusItemModle(View v, int row, int col) {this(v, row, 1, col, 1);}/*** @param v* @param row* @param rowspan* @param col* @param colspan*/public FocusItemModle(View v, int row, int rowspan, int col, int colspan) {mFocusView = v;setPosition(row, col);if (rowspan < 1)throw new IllegalArgumentException("rowspan < 1");mRowSpan = rowspan;if (colspan < 1)throw new IllegalArgumentException("colspan < 1");mColSpan = colspan;}public View getMetroView() {return mFocusView;}public int getRow() {return mRow;}public int getRowSpan() {return mRowSpan;}public int getCol() {return mCol;}public int getColSpan() {return mColSpan;}public void setPosition(int row, int col) {if (row < 0)throw new IllegalArgumentException("row < 0");mRow = row;if (col < 0)throw new IllegalArgumentException("col < 0");mCol = col;}此item主要控制focusView显示在第几排第几列，用于返回一个itemView显示在focusView中。

再写好这些主要view之前，便于以后项目的扩展我们就专门写一个javaBean---,TvModle，也为了迎合mvc设计模式，用来将服务器数据映射到view上。

[java] view plain copy print?在CODE上查看代码片派生到我的代码片public class TvModle {/*** 图片资源*/private int image;/*** 标题*/private String name;/*** url*/private String url;/*** 简介或信息*/private String info;/*** 日期*/private String date;/*** 包括子节目*/private List childs;public TvModle() {super();}public TvModle(int image, String name) {super();this.image = image; = name;}public int getImage() {return image;}public void setImage(int image) { this.image = image;}public String getName() {return name;}public void setName(String name) { = name;}public String getUrl() {return url;}public void setUrl(String url) {this.url = url;}public String getInfo() {return info;}public void setInfo(String info) { = info;}public String getDate() {return date;}public void setDate(String date) { this.date = date;}public List getChilds() {return childs;}public void setChilds(List childs) {this.childs = childs;}}等写好了view和中间层，接下来我们就开始写要显示该UI的activty,这里我们主要是New 一个focusView，通过不断往里面加入一个个不同的itemView。

activty:[java] view plain copy print?在CODE上查看代码片派生到我的代码片@Overridepublic void onCreate(Bundle savedInstanceState) {super.onCreate(savedInstanceState);setContentView(yout.mian_tv_ui);FocusView view = (FocusView) findViewById(R.id.focus_ui);view.setBackgroundColor(Color.WHITE);view.setGap(5);view.setVisibleItems(6, 5);view.setOrientation(OrientationType.Horizontal);view.setAnimation(R.anim.scale_small, R.anim.scale_big);/*view.setOnItemClickListener(new OnItemClickListener() {@Overridepublic void onItemClick(FocusView metroView, View view, int col, int row,ng id) {Toast.makeText(getApplicationContext(),col+"", 1).show();}});*/getData();// 添加自定义VIEWview.addFocusItem(getTvView(mTvLists.get(0).getName(),mTvLists.get(0).getImage(),0, 3, 0, 2));view.addFocusItem(getTvView(mTvLists.get(1).getName(),mTvLists.get(1).getImage(),3, 3, 0, 2));view.addFocusItem(getTvView(mTvLists.get(2).getName(),mTvLists.get(2).getImage(),0, 2, 2, 1));view.addFocusItem(getTvView(mTvLists.get(3).getName(),mTvLists.get(3).getImage(),0, 2, 3, 1));view.addFocusItem(getTvView(mTvLists.get(4).getName(),mTvLists.get(4).getImage(),0, 2, 4 ,1));view.addFocusItem(getTvView(mTvLists.get(5).getName(),mTvLists.get(5).getImage(),2, 2, 2, 1));view.addFocusItem(getTvView(mTvLists.get(6).getName(),mTvLists.get(6).getImage(),2, 2, 3, 1));view.addFocusItem(getTvView(mTvLists.get(7).getName(),mTvLists.get(7).getImage(),2, 2, 4 ,1));view.addFocusItem(getTvView(mTvLists.get(8).getName(),mTvLists.get(8).getImage(),4, 2, 2, 1));view.addFocusItem(getTvView(mTvLists.get(9).getName(),mTvLists.get(9).getImage(),4, 2, 3, 1));view.addFocusItem(getTvView(mTvLists.get(10).getName(),mTvLists.get(10).getImage(),4, 2, 4 ,1));//添加默认logoview.addFocusItem(getDefView(0, 2, 5, 1));view.addFocusItem(getDefView(0, 2, 6, 1));view.addFocusItem(getDefView(0, 2, 7 ,1));view.addFocusItem(getDefView(0, 2, 8 ,1));view.addFocusItem(getDefView(0, 2, 9 ,1));view.addFocusItem(getDefView(2, 2, 5, 1));view.addFocusItem(getDefView(2, 2, 6, 1));view.addFocusItem(getDefView(2, 2, 7 ,1));view.addFocusItem(getDefView(2, 2, 8 ,1));view.addFocusItem(getDefView(2, 2, 9 ,1));}这里的代码比较好理解，只是将我们所要的控件找到，加入多个子item,getdata()是用来模拟获取服务数据的，本次demo暂时写到activity中，企业开发中建议单独写个manager用来控制网络层获取数据，下面是getDate(); 本文出处：/sk719887916 [java] view plain copy print?在CODE上查看代码片派生到我的代码片// 模拟网络获取数据mTvLists.add(new TvModle(R.drawable.atm, "阿童木重磅来袭"));mTvLists.add(new TvModle(R.drawable.sdyjq, "速度与激情大片在线看"));mTvLists.add(new TvModle(R.drawable.yyt, "音悦台"));mTvLists.add(new TvModle(tv, "中国网络电视台"));mTvLists.add(new TvModle(R.drawable.shtv, "东方卫视"));mTvLists.add(new TvModle(R.drawable.hutv, "芒果卫视"));mTvLists.add(new TvModle(R.drawable.gstv, "甘肃卫视"));mTvLists.add(new TvModle(tv, "江苏卫视"));mTvLists.add(new TvModle(R.drawable.shtv, "东方卫视"));mTvLists.add(new TvModle(R.drawable.pptv, "pptv"));mTvLists.add(new TvModle(R.drawable.aqy, "爱奇艺"));mTvLists.add(new TvModle(tv, "中国网络电视台"));mTvLists.add(new TvModle(R.drawable.atm, "阿童木重磅来袭"));mTvLists.add(new TvModle(R.drawable.sdyjq, "速度与激情大片在线看"));mTvLists.add(new TvModle(R.drawable.bjaqgs, "北京爱情故事"));mTvLists.add(new TvModle(R.drawable.hutv, "芒果卫视"));mTvLists.add(new TvModle(R.drawable.gstv, "甘肃卫视"));mTvLists.add(new TvModle(tv, "江苏卫视"));mTvLists.add(new TvModle(R.drawable.shtv, "东方卫视"));在上面的初始化方法中，我们会用到添加子控件的view的方法，通过getTview()和getDefView（）,前面方法用于指定显示我们所要的itemView,后面方法是显示默认的view[java] view plain copy print?在CODE上查看代码片派生到我的代码片/*** getTvView* @param title* @param rouseid* @param row* @param rowspan* @param col* @param colspan* @return FocusItemVew*/private FocusItemModle getTvView(String title, int rouseid, int row, int rowspan,int col, int colspan) {LinearLayout layout = getLinearLayout();layout.setGravity(Gravity.CENTER);FrameLayout frameLayout = new FrameLayout(this);frameLayout.setPadding(PADDING, PADDING, PADDING, PADDING);TextView mTextView = new TextView(this);mTextView .setText(title);mTextView .setGravity(Gravity.CENTER);mTextView .setTextColor(Color.BLACK);mTextView .setTextSize(15);ImageView mLogoView = new ImageView(this);mLogoView.setLayoutParams(FILL_FILL);mLogoView.setImageResource(rouseid);frameLayout.addView(mLogoView, FILL_FILL);frameLayout.addView(mTextView , WRP_WRP);layout.addView(eLayout);return new FocusItemModle(layout, row, rowspan, col, colspan);}private FocusItemModle getDefView(int row, int rowspan, int col, int colspan) { LinearLayout layout = getLinearLayout();TextView tv2 = new TextView(this);tv2.setText("频道"+(i ++));tv2.setGravity(Gravity.CENTER);tv2.setTextColor(Color.WHITE);tv2.setTextSize(15);layout.addView(tv2, FILL_FILL);return new FocusItemModle(layout, row, rowspan, col, colspan);}再次我们还需要用到填充activty的Layout的xmL,比较简单[html] view plain copy print?在CODE上查看代码片派生到我的代码片<?xml version="1.0" ding="utf-8"?>android:layout_width="fill_parent"android:layout_height="fill_parent"android:orientation="vertical" ><_ui_View.FocusViewandroid:id="@+id/focus_ui"android:layout_width="fill_parent"android:layout_height="wrap_content" /></LinearLayout>通过上篇文章结合本次文章，我们初步实现了一个在安卓TV上显示，并且可以用遥控器控制上下左右移动的效果UI，但由于只是demo，并非实际项目，所以效果比较粗糙，但是并不影响代码质量，以上的代码在tv上没有任何bug，但是运行在手机上是存有缺陷的，如果需要兼容手机，TV和手机公用一个版本的话，代码需要优化，但我本人不建议手机和电视版本公用一个版本，这样对UI的适配和焦点控制会带来众多麻烦，手机也无需这么大的使徒，但是不仿喜欢的朋友自己去完善和扩展，况且电视的操作体验是比较简单的，并且无法触屏的（但也有触屏的电视，价格不菲）后面我会继续完善本次demo，结合第三方开源视频框架，完成一个简易的tv上的视频播放器。
