java+ireport应用 (1)

ireport制作报表的流程：首先，我们用ireport设计报表的样式，通过编译生成.jasper文件，为java做准备。

其次，我们在java中定义report公共类，来解析.jasper文件。

最后，通过流输出到页面显示。

1.用ireport设计简单报表：在这里我们选用ireport3.0，因为3.0比较稳定。

1.1，首先，新建一个报表文件，如下图：有title、pageHeader、columnHeader......等等栏。

1.2，title栏是用来放置标题的；pageHeader栏是放副标题和日期等；columnHeader栏是放表头的；detail栏是放详细信息（向下遍历数据显示）；summary栏是放置图和交叉报表的；左下角的文件结构有“参数”、“字段”和变量，参数是用来定义一些静态文本的，可以通过后台进行传值，字段是定义VO的属性，变量是用来参与运算的；1.2.1首先我们来定义一个参数叫做title，选择参数--->"添加"----->parameter,如下图：在弹出的对话框的参数名中输入title后点击确定，然后将title参数拖拽到title栏中，如下图：在这里我们可以设置title的字体、大小和位置等。

1.2.2用同样的方法我们建立两个字段：username和password：分别拖拽到detail栏中，并调整大小、位置和边界：接下来我们可在对于的列上加上表头：点击工具栏的“T”静态文本，在columnHeader栏中画出：以上一个简单的报表就画好了，我们点击工具栏的“执行报表”按钮，编译成.jasper文件。

1.3，接下来我们定义java类Reports.java：import java.io.ByteArrayOutputStream;import java.io.File;import java.io.IOException;import java.io.PrintWriter;import .URLEncoder;import java.util.ArrayList;import java.util.List;import java.util.Map;import javax.servlet.ServletOutputStream;import javax.servlet.http.HttpServletRequest;import javax.servlet.http.HttpServletResponse;import net.sf.jasperreports.engine.JRException;import net.sf.jasperreports.engine.JRExporterParameter;import net.sf.jasperreports.engine.JasperFillManager;import net.sf.jasperreports.engine.JasperPrint;import net.sf.jasperreports.engine.JasperReport;import net.sf.jasperreports.engine.data.JRBeanCollectionDataSource;import net.sf.jasperreports.engine.export.JExcelApiExporter;import net.sf.jasperreports.engine.export.JRHtmlExporter;import net.sf.jasperreports.engine.export.JRHtmlExporterParameter;import net.sf.jasperreports.engine.export.JRXlsExporterParameter;import net.sf.jasperreports.engine.util.JRLoader;public class Reports {/**//** 生成HTML报表显示*/public void selectHtmlReport(List list,HttpServletResponse response,String url,Map map){response.setContentType("text/html;charset=utf-8");File reportFile = new File(url);JasperReport jasperReport = null;try {jasperReport = (JasperReport)JRLoader.loadObject(reportFile.getPath()); } catch (JRException e) {e.printStackTrace();}JRBeanCollectionDataSource jrbean = new JRBeanCollectionDataSource(list); JasperPrint jasperPrint = null;try {jasperPrint = JasperFillManager.fillReport(jasperReport,map,jrbean);} catch (JRException e) {e.printStackTrace();}JRHtmlExporter exporter = new JRHtmlExporter();PrintWriter out = null;try {out = response.getWriter();} catch (IOException e) {e.printStackTrace();}exporter.setParameter(JRExporterParameter.JASPER_PRINT, jasperPrint);exporter.setParameter(JRExporterParameter.OUTPUT_WRITER, out);exporter.setParameter(JRHtmlExporterParameter.IS_USING_IMAGES_TO_ALIGN, Boolean.FALSE);exporter.setParameter(JRHtmlExporterParameter.IS_REMOVE_EMPTY_SPACE_BETWEEN_R OWS,Boolean.TRUE);try {exporter.exportReport();} catch (JRException e) {e.printStackTrace();}}/**//** 导出EXCEL报表*/public void selectExcelReport(List list,HttpServletResponse response,String url,Map map,String reportName){try{//加载jasper文件File reportFile = new File(url);JasperReport jasperReport =(JasperReport)JRLoader.loadObject(reportFile.getPath());//装载数据JRBeanCollectionDataSource jrbean = new JRBeanCollectionDataSource(list);//构造jasperPrint对象JasperPrint jasperPrint = JasperFillManager.fillReport(jasperReport, map, jrbean);//输出流ByteArrayOutputStream oStream = new ByteArrayOutputStream();//构造输出对象JExcelApiExporter exporter = new JExcelApiExporter();exporter.setParameter(JRHtmlExporterParameter.IMAGES_URI,"./image?image=" );exporter.setParameter(JRExporterParameter.JASPER_PRINT, jasperPrint);exporter.setParameter(JRExporterParameter.OUTPUT_STREAM, oStream);exporter.setParameter(JRXlsExporterParameter.IS_REMOVE_EMPTY_SPACE_BETWEE N_ROWS,Boolean.TRUE); // 删除记录最下面的空行exporter.setParameter(JRXlsExporterParameter.IS_ONE_PAGE_PER_SHEET,Boolea n.FALSE);// 删除多余的ColumnHeaderexporter.setParameter(JRXlsExporterParameter.IS_WHITE_PAGE_BACKGROUND,Boo lean.FALSE);// 显示边框exporter.exportReport();//excel文件名String fileName = reportName + ".xls";response.reset();response.setHeader("Content-Disposition", "attachment;filename=\"" + URLEncoder.encode(fileName,"utf-8") + "\"");//写输出流byte[] bytes = oStream.toByteArray();if(bytes != null && bytes.length > 0) {response.setContentType("application/vnd.ms-excel;charset=utf-8");response.setContentLength(bytes.length);ServletOutputStream ouputStream = response.getOutputStream();ouputStream.write(bytes,0,bytes.length);ouputStream.flush();ouputStream.close();}else{}}catch(Exception ex){ex.printStackTrace();}}/*** 功能：生成默认图形报表的处理方法* 方法名:selectHtmlReport* @param List list 数据集* @param HttpServletResponse response* @param HttpServletRequest request* @param String url 解析的报表文件* @param Map map 报表用的参数* @author 郭洪治 2010-03-15* @return void*/public void selectHtmlReport(List list,HttpServletResponseresponse,HttpServletRequest request,String url,Map map){response.setContentType("text/html;charset=utf-8");File reportFile = new File(url);JasperReport jasperReport = null;try {jasperReport = (JasperReport)JRLoader.loadObject(reportFile.getPath());} catch (JRException e) {e.printStackTrace();}JRBeanCollectionDataSource jrbean = new JRBeanCollectionDataSource(list);JasperPrint jasperPrint = null;//设置报表图形默认存放物理目录String outPutDir =request.getSession().getServletContext().getRealPath("/")+"/reportimg/";//加载图形报表的相对目录String sourceDir = request.getContextPath()+"/reportimg/";try {File file = new File(outPutDir);//判断此目录是否存在if(!file.exists()){file.mkdir();}jasperPrint = JasperFillManager.fillReport(jasperReport,map,jrbean);} catch (JRException e) {e.printStackTrace();}JRHtmlExporter exporter = new JRHtmlExporter();PrintWriter out = null;try {out = response.getWriter();} catch (IOException e) {e.printStackTrace();}exporter.setParameter(JRHtmlExporterParameter.IMAGES_DIR_NAME,outPutDir);exporter.setParameter(JRHtmlExporterParameter.IMAGES_URI,sourceDir);exporter.setParameter(JRHtmlExporterParameter.IS_OUTPUT_IMAGES_TO_DIR, Boolean.TRUE);exporter.setParameter(JRExporterParameter.OUTPUT_WRITER, out);exporter.setParameter(JRExporterParameter.JASPER_PRINT, jasperPrint);exporter.setParameter(JRHtmlExporterParameter.IS_USING_IMAGES_TO_ALIGN, Boolean.FALSE);exporter.setParameter(JRHtmlExporterParameter.IS_REMOVE_EMPTY_SPACE_BETWEEN_ROWS,Boolean.TRUE);try {exporter.exportReport();} catch (JRException e) {e.printStackTrace();}}/*** 功能：生成指定目录图形报表查询的处理方法* @param List list 数据集* @param HttpServletResponse response* @param HttpServletRequest request* @param String url 解析的报表文件* @param Map map 报表用的参数* @param String imgDir 图形生成的目录* @author 郭洪治2010-01-20* @return void*/public void selectHtmlReport(List list,HttpServletResponseresponse,HttpServletRequest request,String url,Map map,String imgDir){response.setContentType("text/html;charset=utf-8");File reportFile = new File(url);JasperReport jasperReport = null;//生成图形目录String outPutDir =request.getSession().getServletContext().getRealPath("/")+"/"+imgDir;//图形源目录String sourceDir = request.getContextPath()+"/"+imgDir;try {jasperReport = (JasperReport)JRLoader.loadObject(reportFile.getPath()); } catch (JRException e) {e.printStackTrace();}JRBeanCollectionDataSource jrbean = new JRBeanCollectionDataSource(list); JasperPrint jasperPrint = null;try {jasperPrint = JasperFillManager.fillReport(jasperReport,map,jrbean);} catch (JRException e) {e.printStackTrace();}JRHtmlExporter exporter = new JRHtmlExporter();PrintWriter out = null;try {out = response.getWriter();} catch (IOException e) {e.printStackTrace();}//设置图片存入的物理目录exporter.setParameter(JRHtmlExporterParameter.IMAGES_DIR_NAME,outPutDir);//设置图片显示的目录exporter.setParameter(JRHtmlExporterParameter.IMAGES_URI,sourceDir);//生成图片到目录exporter.setParameter(JRHtmlExporterParameter.IS_OUTPUT_IMAGES_TO_DIR, Boolean.TRUE);exporter.setParameter(JRExporterParameter.JASPER_PRINT, jasperPrint);exporter.setParameter(JRExporterParameter.OUTPUT_WRITER, out);exporter.setParameter(JRHtmlExporterParameter.IS_USING_IMAGES_TO_ALIGN, Boolean.FALSE);exporter.setParameter(JRHtmlExporterParameter.IS_REMOVE_EMPTY_SPACE_BETWEEN_R OWS,Boolean.TRUE);try {exporter.exportReport();} catch (JRException e) {e.printStackTrace();}}/*** 功能：导出多sheet报表的处理方法* 方法名:selectAllExcelReport* @param List list 数据集* @param HttpServletResponse response* @param String url 解析的报表文件* @param String reportName 生成excel保存的名字* @author 郭洪治* 创建时间：Nov 3, 2009 2:08:31 PM*/@SuppressWarnings("unchecked")public void selectAllExcelReport(List list,HttpServletResponse response,String url,String reportName){try{//加载jasper文件File reportFile = new File(url);JasperReport jasperReport =(JasperReport)JRLoader.loadObject(reportFile.getPath());List jasperPrintList = new ArrayList();int listSize = list.size();String sheetNamesArray[] = new String[listSize];for(int i = 0; i < listSize; i++){Map eachMap = (Map)list.get(i);List eachList = (List)eachMap.get("ls");sheetNamesArray[i] = (String)eachMap.get("title");//装载数据JRBeanCollectionDataSource jrbean = new JRBeanCollectionDataSource(eachList); //构造jasperPrint对象JasperPrint jasperPrint = JasperFillManager.fillReport(jasperReport, eachMap, jrbean);jasperPrintList.add(jasperPrint);}//输出流ByteArrayOutputStream oStream = new ByteArrayOutputStream();//构造输出对象JExcelApiExporter exporter = new JExcelApiExporter();exporter.setParameter(JRHtmlExporterParameter.IMAGES_URI,"./image?image=" );exporter.setParameter(JRExporterParameter.JASPER_PRINT_LIST, jasperPrintList);exporter.setParameter(JRExporterParameter.OUTPUT_STREAM, oStream);exporter.setParameter(JRXlsExporterParameter.IS_REMOVE_EMPTY_SPACE_BETWEE N_ROWS,Boolean.TRUE); // 删除记录最下面的空行exporter.setParameter(JRXlsExporterParameter.IS_ONE_PAGE_PER_SHEET,Boolea n.FALSE);// 删除多余的ColumnHeaderexporter.setParameter(JRXlsExporterParameter.IS_WHITE_PAGE_BACKGROUND,Boo lean.FALSE);// 显示边框exporter.setParameter(JRXlsExporterParameter.SHEET_NAMES, sheetNamesArray);exporter.exportReport();//写输出流byte[] bytes = oStream.toByteArray();if(bytes != null && bytes.length > 0) {response.reset();response.setContentType("application/vnd.ms-excel;charset=utf-8");response.setContentLength(bytes.length);//excel文件名String fileName = reportName + ".xls";response.setHeader("Content-Disposition", "attachment;filename=\"" + URLEncoder.encode(fileName,"utf-8") + "\"");ServletOutputStream ouputStream = response.getOutputStream();ouputStream.write(bytes,0,bytes.length);ouputStream.flush();ouputStream.close();}}catch(Exception ex){ex.printStackTrace();}}}1.4，在action中调用：Map<String,String> parameters = new HashMap<String,String>();//定义参数mapparameters.put("title", "我的报表"); //添加参数String url = “WEB-INF/report/test.jasper";//定义报表文件路径Reports report = new Reports();//创建报表类对象report.selectHtmlReport(list, response, url, parameters);//调用生成表方法其中list是从数据库中查询的值，放的是VO对象，VO对象的属性和.jasper报表文件中定义的字段要一一对应。
