GBF衬氟管道泵说明书

合集下载

单作用式气动衬氟蝶阀使用说明书

单作用式气动衬氟蝶阀使用说明书
产品介绍
单作用式气动衬氟蝶阀是一种常用的工业阀门，广泛应用于液体或气体的控制和调节。

该蝶阀采用衬氟材料制造，具有耐腐蚀、耐高温等特点，适用于各种恶劣工况。

使用前准备
在安装和使用单作用式气动衬氟蝶阀之前，请确保以下准备工作已完成：
1. 检查蝶阀外观是否完好无损，如有损坏请及时更换；
2. 检查蝶阀连接处是否有松动，如果有请进行紧固；
3. 确保气源压力适当，并检查气动装置是否正常工作；
4. 清洁管道系统，防止杂质对蝶阀的影响；
5. 根据需要进行阀门的定位装置安装。

使用方法
按照以下步骤正确使用单作用式气动衬氟蝶阀：
1. 打开气源，确保气源压力正常；
2. 按下气动装置上的开关，使其处于工作状态；
3. 转动手柄或操作杆，以实现蝶阀的开启或关闭；
4. 当需要调节流速时，可以适当旋转手柄或操作杆，使蝶阀处
于半开状态；
5. 当不需要使用蝶阀时，关闭气源和气动装置。

注意事项
在使用单作用式气动衬氟蝶阀时，请注意以下事项：
1. 不要超过蝶阀的额定工作压力范围，以免造成损坏或危险；
2. 定期检查蝶阀的密封性能，如有泄漏请及时处理；
3. 避免在高温或高压下开启蝶阀，以防发生意外；
4. 不要随意拆卸或更换蝶阀的零部件，以免影响正常工作；
5. 定期清洁蝶阀表面和内部，以保持良好的工作状态。

请根据实际情况和需要，详细阅读产品的技术规格和使用说明，以确保正确安装和使用单作用式气动衬氟蝶阀。

如有任何问题或疑问，请与售后服务部门联系。

PTFE管道泵操作手册说明书

OPERATING MANUALPTFE TUBING PUMPModel 77390-00®®Cole-Parmer Instrument Co.1-800-MASTERFLEX (627-8373) (U.S. and Canada only)11 (847) 549-7600 (outside U.S.)(847) 549-7600 (Local)Barnant Company1-800-637-3739 (U.S. and Canada only)11 (847) 381-7050 (outside U.S.)(847) 381-7050 (Local)A-1299-0538TABLE OF CONTENTSTitle PageSAFETY PRECAUTIONS (4)INTRODUCTION (5)APPLICATION DATA (6)GENERAL DESCRIPTION (6)INSTALLATION (7)SETUP AND OPERATION (8)Selecting Tubing Size (8)Loading Tubing (9)Recommended Occlusion Setting (11)Optimized Occlusion Settings (12)MAINTENANCE (12)Service Parts (12)Occlusion Bed (12)SPECIFICATIONS (13)WARRANTY (14)PRODUCT RETURN (14)TECHNICAL ASSISTANCE (14)Trademarks bearing the ® symbol in this publicationare registered in the U.S. and in other countries.This product is covered by one ormore of the following U.S. andcorresponding foreign patents:5,468,129 and 5,482,447SAFETY PRECAUTIONSCAUTION:Use only pre-formed MASTERFLEX® L/S® PTFE tub-ing. Use of other tubing may result in premature orunknown failure modes.WARNINGS:Turn drive off before removing or installing tubing. Fin-gers or loose clothing could be caught in the rollers.Use recommended fittings only. Use of improper fit-tings and/or improper connection to fittings may re-sult in leakage at the fittings.Do not operate the pump without the following pre-cautions:Either of the following two conditions can result insudden and/or extensive tubing failure. Tubing failuremay result in liquid leaking from pump. In the event oftubing failure, operating pump at elevated speeds andpressures will result in accelerated liquid leakage. Useappropriate measures to protect operator and equip-ment from caustic liquids.1.HIGH PUMP-generated pressures.A PRESSURE RELIEF/BYPASS VALVE must alwaysbe installed in a potentially high pressure systemto prevent the pump from exceeding the maximumrated pressure (100 psig;6.8 bar).a.where the possibility of a blocked outlet occurs.b.where occlusion setting is greater than recom-mended.c.where higher pressure filters are used that donot have a built-in pressure relief system.2.HIGH SYSTEM-generated backpressures.AN INJECTION CHECK/BACK PRESSURE VALVEshould always be installed when pumping into apressurized reservoir or line. This will preventsiphoning and/or backflow of liquid from a treatedline in the event of tubing failure.INTRODUCTIONThe Model 77390-00 PTFE Tubing Pump, Figure 1, provides quick loading of the special PTFE tubing assemblies. The pump is designed to work with the MASTERFLEX 2mm ID PTFE Tubing Model 77390-50 and 4mm ID Model 77390-60 and provides a wide flow range when used with compatible MASTERFLEX Pump Drives. Appendix A lists most of the MASTERFLEX®L/S® Pump Drives which can be used with this pump.The step-by-step instructions in this manual are task-oriented for easy reference. The manual provides information for installing, operating and customer maintenance of the Model 77390-00 PTFE Tubing Pump. CAUTION:Improper setup or operation may result in damage to the pump system components. Read instructions priorto use.Figure 1.Model 77390-00 PTFE Tubing PumpAPPLICATION DATAThe Model 77390-00 PTFE Tubing Pump is used to pump caustic and/or sterile liquids, particularly those liquids that are not compatible with other existing MASTERFLEX tubing materials. The use of PTFE tubing provides improved liquid compatibility and maintenance of liquid purity. The specially designed tubing assemblies provide for intermittent operation at pressures up to 100 psig. Various compatible accessories are available including PTFE valves, T-connectors, fittings, etc. for connection to remaining user system components. Make sure that the fittings used are properly sized and are compatible with the pressure rating of the pump. Contact your dealer.A typical application is transfer of liquids from storage containers to those used in experiments. Metering of such liquids is another application when the pump is used with an appropriate MASTERFLEX® L/S® Pump Drive. The higher pressure capability allows use in low-volume filtering, chromatogra-phy sample injection and other applications.GENERAL DESCRIPTIONThe PTFE Tubing Pump (see Figure 1) is composed of a Body Assembly and an adjustable Occlusion Bed. The Body Assembly is used to attach the pumpto a drive and to support the six-roller ball bearing Rotor Assembly and the Occlusion Bed. The Occlusion Bed holds the tubing and mounts to the Body Assembly. It is held in place by increasing the occlusion to an appropriate level. Occlusion is controlled by adjustment of the Occlusion Adjustment Knob. A Locking Ring maintains the occlusion setting. The six-roller configu-ration provides low pulsation and prevents back-flow when the pump is stopped.Tubing is held in place without the use of special retainers. The curvature of the groove along the lower surface of the Occlusion Bed matches the curve of the tubing assembly and holds the tubing in place during pumping. Two different diameter specially fabricated PTFE tubing assemblies are available. The tubing is semi-flexible and chemically inert.INSTALLATIONMounting the Pump Head to a MASTERFLEX® L/S® Pump DriveThe Pump Head is attached to the drive unit with four supplied screws as shown in Figure 2.NOTE:Two Tang Boots are provided. The Pump Head is shipped with the closed end Tang Boot (A-3480) installed which matches mostMASTERFLEX® L/S® Drives. Replace with open end Tang Boot(A-3514) when necessary.1.Rotate the Occlusion Adjustment Knob fully counterclockwise to lift theOcclusion Bed as shown in Figure 3.2.Remove the Occlusion Bed by sliding out the front of the Body Assembly.3.Align the Tang on the Pump Head (including installed boot) with the slotin the motor drive shaft.4.Align the lower mounting holes on the Pump Head with the mountingholes on the drive and fasten with the two thumbscrews.5.Insert the two Phillips screws through the mounting holes in the upperpart of the Body Assembly. The upper two screw holes are accessible by removing the Occlusion Bed.This completes the mounting of the Pump Head. Proceed with the Setup Procedure.Figure 2.Attaching Pump to DriveSETUP AND OPERATIONSelecting Tubing SizeThe following chart provides approximate flow rates for the different tubing sizes when used at various speeds. Liquid medium is distilled water at 72°F (22.2°C) and zero psig backpressure.Tubing Catalog No.Drive Speed77390-5077390-60r/min Initial Flow Rate mL/min10.090.3575726100935150135330026105Drive speeds greater than 300 r/min are not recommended.Initial Flow Rate vs. Drive SpeedThe following curve provides approximate percent age of decay of initial flow vs. time at 300 r/min. Decay will be faster or slower at different speeds.Decay of initial Flow vs. time at 300 r/minLoading TubingWARNING:Turn drive off before removing or installing tubing. Fin-gers or loose clothing could be caught in the rollers.1.Rotate Locking Ring fully counterclockwise to unlock Occlusion Adjust-ment Knob.2.Rotate the Occlusion Adjustment Knob completely counterclockwise.Figure 3.Occlusion Assembly in Raised Position3.Lift the Occlusion Bed as shown in Figure 3, then remove the OcclusionBed by sliding out the front of the Body Assembly.CAUTION:Use only pre-formed MASTERFLEX® L/S® PTFE tubing.Use of other tubing may result in premature or unknownfailure modes.4.Install the pre-formed PTFE tubing assembly in the groove of theOcclusion Bed as shown in Figure 4.Figure 4.Positioning Tubing Assembly in Occlusion Bed5.Slide the occlusion assembly into the front of the body assembly. WARNING:Use recommended fittings only. Use of improper fit-tings and/or improper connection to fittings may re-sult in leakage at the fittings.6.Attach connecting fitting to the inner PTFE tubing in the Pump Head.Never attach connecting fitting over the larger of the two concentric PTFE tubing sections.WARNINGS:Do not operate the pump without the following precau-tions:Either of the following two conditions can result insudden and/or extensive tubing failure. Tubing failuremay result in liquid leaking from pump. In the event oftubing failure, operating pump at elevated speeds andpressures will result in accelerated liquid leakage. Useappropriate measures to protect operator and equip-ment from caustic liquids.1.HIGH PUMP-generated pressures.A PRESSURE RELIEF/BYPASS VALVE must alwaysbe installed in a potentially high pressure system toprevent the pump from exceeding the maximum ratedpressure (100 psig; 6.8 bar).a.where the possibility of a blocked outlet occurs.b.where occlusion setting is greater than recom-mended.c.where higher pressure filters are used that do nothave a built-in pressure relief system.2.HIGH SYSTEM-generated back pressures.AN INJECTION CHECK/BACK PRESSURE VALVEshould always be installed when pumping into apressurized reservoir or line. This will preventsiphoning and/or backflow of liquid from a treatedline in the event of tubing failure.NOTE:The following leakage modes are considered evidence of tubing failures:1.Drip from exit of the outer tube of the concentric tubingassembly.2.Liquid between inner and outer tubes of the tubingassembly.3.After pump reaches full prime, a continuous and regularstream of bubbles exiting the tubing assembly.User must replace tubing at first sign of such leakage. Recommended Occlusion SettingCAUTION:Do not run the pump dry for an extended period of time.Pumping dry or over-occluding can cause overheatingand pump damage.Proceed as follows:1.Dip entry and exit connecting tubing approximately one inch into the fluidto be pumped.2.Be sure Pump Drive is turned on and set to desired operating speed.3.Rotate Locking Ring fully counterclockwise. Ring should be againstlower side of Occlusion Adjustment Knob.4.Slowly rotate Occlusion Adjustment Knob clockwise just until bubblesfirst appear at output of the exit connecting tube. Roughly, this will occur when 1) the top of the Occlusion Bed becomes even with the top of the Body Assembly, and 2) the pump noise level decreases.5.Rotate Occlusion Adjustment Knob an additional one-fourth turn clock-wise.6.Rotate Locking Ring fully clockwise until it is tight against the top of theBody Assembly, thus locking the Occlusion Adjustment Knob in place.Optimized Occlusion SettingsOcclusion is reduced by rotating the Adjustment Knob counterclockwise. Some applications require adjustment of the occlusion setting to maximize tube life while others require adjustment to maintain flow rate when substan-tial system pressure exists. However, the recommended setting will meet the requirements of most applications, giving both good tube life and some pressure capabilities.To Maximize Tubing LifeOcclude according to recommended setting described above and allow pump to prime with the fluid to be transferred. Then, while the pump is running, simply reduce the adjusted occlusion setting by slowly turning the Occlusion Adjustment Knob until the flow drop-off becomes unacceptable. Then turn the knob slightly clockwise and lock in position with Locking Ring. To Maintain Flow Rate at Higher PressuresTurn Occlusion Adjustment Knob clockwise just until flow rate returns to the desired level. Lock in position with Locking Ring.MAINTENANCEService Parts:Item Part NumberOcclusion Bed D-2692Thumb Screw (1)B-3304-0012Phillips Head Screw (1)B-1079-0076Tang Boot (Closed End)A-3480Tang Boot (Open End)A-3514Occlusion BedProcedures for removal and installation of the Occlusion Bed are covered in the Installation Section.SPECIFICATIONSPUMPMaximum Torque load:150 in-oz (12 kg-cm)Operating Speed:300 r/min maximumOperating Temperature:32°F to 104°F (0°C to 40°C) Storage Temperature:−50°F to 150°F (−45°C to 65°C) Humidity (Non-cond):10% to 90% RHDimensions (L x W x H):2-11/16 in x 3-5/16 in x 5-1/2 in(6.83 cm x 8.4 cm x 14.0 cm) Weight: 2 lb. (0.91 kg)Color:BlackMaterial:Pump Head:Anodized aluminum, acetal, andstainless steelKnob:PlasticTUBINGMaterial:PTFETubing Length:15 inches ±1 inch (38 cm ±2.54 cm) Tubing Diameter:77390-502mm ID, 4mm OD77390-604mm ID, 6mm OD Maximum Pressure at rated flow:100 psig*Operating Temperature (Continuous):32°F to 104°F (0°C to 40°C) Operating Temperature (Intermittent):32°F to 212°F (0°C to 100°C) Storage Temperature:−50°F to 150°F (−45°C to 65°C) Humidity (Non-cond):10% to 90% RH* Tubing life is significantly reduced at elevated pressure.WARRANTYUse only pre-formed MASTERFLEX® L/S® PTFE tubing. Use of other tubing may result in premature or unknown failure modes.The Manufacturer warrants this product to be free from significant deviations from published specifications. If repair or adjustment is necessary within the warranty period, the problem will be corrected at no charge if it is not due to misuse or abuse on your part as determined by the Manufacturer. Repair costs outside the warranty period, or those resulting from product misuse or abuse, may be invoiced to you.The warranty period for this product is noted on the Warranty Card.PRODUCT RETURNTo limit charges and delays, contact the seller or Manufacturer for authori-zation and shipping instructions before returning the product, either within or outside of the warranty period. When returning the product, please state the reason for the return. For your protection, pack the product carefully and insure it against possible damage or loss. Any damages resulting from improper packaging are your responsibility.NOTE:Items returned must be free of hazardous or toxicmaterials.TECHNICAL ASSISTANCEIf you have any questions about the use of this product, contact the Manufacturer or authorized seller.Printed in U.S.A.070102NOTES。

衬氟管道离心泵型号参数说明

优秀水泵制造商-上海沈泉泵阀制造有限公司是一家专业生产，销售管道泵，排污泵，消防泵，化工泵等给排水设备的厂家，产品涉及工矿企业、农业、城市供水、石油化工、电站、船舶、冶金、高层建筑、消防供水、工业水处理和纯净水、食品、制药、锅炉、空调循环系统等行业领域。

上海沈泉泵阀制造有限公司是集研究、开发、生产、销售和服务为一体的泵阀生产企业。

产品涉及工矿企业、农业、城市供水、石油化工、电站、船舶、冶金、高层建筑、消防供水、工业水处理和纯净水、食品、制药、锅炉、空调循环系统等行业领域。

管道离心泵型号众多，并且在规格上还有着单级和多级两种，结构上也有着立式和卧式两种，可见其规格型号之丰富。

而能输送各种耐腐蚀介质的衬氟管道离心泵，也是其中管道离心泵众多规格型号下的其中一种。

在对于衬氟管道离心泵的选型上，若是用户能够知晓衬氟管道泵的型号参数，那么对于选型是非常有帮助的，为此，上海沈泉就为大家简单的讲解下这方面的内容。

首先，小编先拿出GBF衬氟立式管道离心泵来为大家讲解，这是由于不同的厂家所生产的衬氟管道离心泵在规格型号上都有所不同，为了方便大家理解，故以此来为大家讲解。

GBF耐腐蚀离心泵性能参数选型表：GBF衬氟立式管道离心泵：这是一款立式结构的离心泵，是沈泉在一般立式泵的基础上并结合了国内优秀水力模型及ISG型管道离心泵之性能参数所生产出来的水泵，并且采用了聚全氟乙丙烯(F46)材质，这是一种具有非常优良的耐蚀和耐热性能的材料,除熔金属锂、钾、钠、三氟化氯、高温下的三氟化氧、高流速的液氟外，它几乎可以抵搞所有化学介质(包括浓硝酸和王水)。

在采用了这种材质后使得该泵非常适用于在-85℃～+200℃温度的条件下，长期输送任意浓度的酸、碱液、氧化剂及其它腐蚀性液体。

在用途上被人广泛用于石油、化工、冶金、电力、造纸、烟气脱硫、除尘、食品制药和合成纤维等部门。

除此之外，该泵还具有着高效节能、噪音低、性能可靠等优点。

综上所述，便是小编对于衬氟管道离心泵型号参数说明的简单讲解了，希望能够对大家有所帮助。

Endurance Equipment EFP1.5H 消防泵用户手册说明书

USING YOUR FIRE PUMP
Whether you are washing down a tennis court or preparing for an approaching fire, the same basic procedures of fire pump operation apply:
2. Attach intake hose to pump. Take female cam lock on end of intake hose and clamp onto male cam lock that is now attached to the pump. 3. Attach the foot valve strainer to opposite end of intake hose. 4. Drop strainer end of intake hose into water source.
Gasoline Fire Pump 40/1.5 70/230 (100psi) 8/26 13.5/477 65 Forced Air cooled, 4-stroke OHV 6.5/3600 3.6/1 Unleaded gasoline Recoil 25/55 520x385x470 / 20.5x15x18.5 50’ Fire Hose, Fog/Stream Nozzle, 8’ Intake Hose with Strainer & Camlock Couplers
STORAGE
Proper storage of your fire pump system is essential to ensure that it is ready for the next use.

FSB氟塑料离心泵使用手册

2 40FSB-15
3 40FSB-20 770 610 460 80 80 340 310 280 250 287 162 40 85 180 4-φ14
4 40FSB-30
5 50FSB-20
6 50FSB-25 780
75 90
48 82
610 460
340 310 280 250 287 162
表二
序号
型号
外型及安装尺寸
L
S
P
f
W
T
H
h
x
m
1 40FSB-15(D)
2 40FSB-20(D)
510
90
3 40FSB-30(D)
310
4 50FSB-20(D)
40
85
220 170 265 140
180
5 50FSB-25(D) 520
93
48
82
6 50FSB-30(D) 510
90
40
85
二、管道...........................................7
使用及维护部分
一、使用前的注意事项...............................8
二、启动与运行.....................................8
三、维护与保养.....................................8
四、拆卸和组装.....................................9
五、服务承诺.......................................9

F泵使用说明书

F500/800/1000泥浆泵使用说明书2004年5月前言F－500/800/1000钻井泵使用说明书是提供给用户的一套完整资料。

编写这些资料的目的是为了给予用户准确而简明的数据及操作要领，而这是进行调试及维修所必须的。

本说明书供给为全面熟悉钻井泵的操作者、现场维修人员和技术服务人员使用。

它不打算也不可能在这有限的篇幅内将每个可能遇到的情况都提到，但可使用户往往从中获得良好而满意的机械操作方法和安全的预防措施。

所有规范都是根据工程设计编制的，应在各项修理作业时严格遵守。

有关其它制造厂家生产的设备在使用和维修时，则以制造厂家的资料为准。

公司有权在任何时候停用各种泵的型号，变更任何型号的钻井泵的设计，事后并不通知，亦不负任何责任。

本说明书如有不完善之处，恳请读者提出宝贵意见和建议。

编者目录表（F-500/800/1000钻井泵）章节内容1. F-500/800/1000钻井泵使用维护说明书2. F-500/800/1000钻井泵零件目录3. KB-45/75空气包零件目录4. JA3剪销安全阀零件目录第 1章F-500/800/1000钻井泵使用维护说明书目录总体尺寸 (5)新泵的安装 (8)对吸入系统的要求 (13)动力端的准备工作 (13)喷淋泵总成 (16)液力湍零件的装配 (20)润滑 (23)最低工作速度 (23)控制液流的飞溅润滑 (24)压力润滑系统 (26)润滑系统的维护 (27)维护 (29)动力端 (29)滚柱轴承 (30)小齿轮轴总成 (32)曲轴总成 (33)将曲轴总成安装在机架上 (37)十字头导板的安装 (39)F-500泵导筒的更换 (39)十字头的安装 (41)十字头对中的检查 (43)液力端的维护保养 (44)补焊和修理 (49)阀盖孔的修理 (50)泵的各总成的大约重量 (50)维护检查点 (52)可能发生的故障和排除方法 (55)封存注意事项 (56)5总体尺寸图1 F系列泵各部尺寸示意图6F 系列泵各部尺寸表(表1) 泵型号 F-500(英*) F-800(英*) F-1000(英*) F-1300(英*) F-1600(英*) F-1600HLH 1226.7(*) 1337.9(1304.9*) 1480.5(1464.5*) 1609.9(1665.9*) 1609.9(1665.9*) 1715.9H1 1130.3 1249(1216*) 1363(1347*) 1457.65(1513.6*) 1457.65(1464) 1669 H2 421.8(389*) 422(397*) 503(487*) 492.25(548.2*) 492.25(548.2*) 598L1 1419.2 1636.3 1870.1 2244.7 2244.7 2789.8 L2 305 330.2 330.2 419.1 419.1L3 250.8 273.1 273.1 324 324 321.6(223.4) A1 806.45 882.7 1028.7 1028.7 1028.7 1028.7B 1198.6 1330.2 1375 1424 1424 1340A 1500 1607 1800 1880 1880 L 3657.6 3963 4269 4426 4426 A2 153 150 178 155 155 H3 287(256*) 287(256*) 327(307*) 251(307*) 251(307*)输入轴长 1879.62050.13 2260.6 2413 2413 2413 d φ139.7(0,-0.05) φ177.8(0,-0.05) φ196.85（0,-0.05）φ215.9(0,-0.05) φ215.9(0,-0.05) φ215.9(0,-0.05) h 121.5（+0.17，） 152.42 167.71 187.07 187.07 187.07 轴头尺寸k 31.75±0.05 44.45±0.05 50.8±0.05 50.8±0.05 50.8±0.05 50.8±0.057F 系列泵各部尺寸表(表2) 泵型号 F-500 F-800 F-1000 F-1300 F-1600 F-1600HLdφ139.7(0,-0.05) φ177.8(0,-0.05) φ196.85（0,-0.05）φ215.9(0,-0.05) φ215.9(0,-0.05) φ215.9(0,-0.05) h 121.5（+0.17，-0.24）152.42 （0，-0.40） 167.71 （0，-0.45） 187.07 （0，-0.29） 187.07 （0，-0.29） 187.07 （0，-0.29）轴头尺寸 k 31.75±0.05 44.45±0.05 50.8±0.05 50.8±0.05 50.8±0.05 50.8±0.05 d1 φ222φ277.8 φ328 φ329 φ329 φ329 D1 φ337 φ406.5 φ457.2 φ457 φ457 φ457.2 n1-φ 12×φ28.5 12×φ25.5 12×φ28.5 12×φ28.5 12×φ28.5 12×φ28.5 D f1 φ285.75 φ365 φ400 φ400 φ400 φ400 吸入口尺寸δ1 30 30 30 30 30 30 d2 φ103.2 φ103.2 φ103.2 φ103.2 φ130 D2 φ375 φ375 φ375 φ375 385 n2-φ 8×φ42 8×φ42 8×φ42 8×φ42 12×φ32 D f2 φ292.1 φ292.1 φ292.1 φ292.1 排出口尺寸δ2 83/R44,52MPa 83/R44,52MPa 83/R44,52MPa 83/R44,52MPa BX169/78MPaF-500/800/1000钻井泵使用说明书新泵的安装公司生产的F系列泵，在发运到油田以前已完全组装好，并经过负荷运转试验，润滑油已从动力端放出。

IHF氟塑料离心泵说明书

1 用途：汽车制造中的酸洗、喷漆工艺；有色金属冶炼中的电解液输送；离子膜烧碱项目中的氯水、废水处理和加酸等工艺流程。

适用温度：-20℃～100℃。

2 设计特点：本系列产品按国际标准设计制造（ISO2858），泵体采用金属外壳内衬氟塑料，叶轮及泵盖均采用金属嵌件外包氟塑料合金模压成型，使其具有超强的抗冲击能力又有卓越的耐腐蚀性能，轴封选用先进的外装式波纹管机械密封，对磨的密封面有：碳化硅、陶瓷、四氟、硬质合金可供选择。

具有很高的性能价格比，是目前化工行业应用最为广泛的防腐离心泵。

3氟塑料离心泵用途：IHF离心泵的耐腐和耐磨性已得到实际使用的证实和广大用户的一致认可，目前已被广泛应用于：化工生产中的腐蚀性介质输送、离子膜烧碱项目中的氯水废水处理和加酸工艺（目前国内大部分离子膜烧碱项目用泵均选用我公司产品）、有色金属冶炼中的电解液输送、汽车制造中的酸洗工艺，及制药、石油、电力、电镀、染料、农药、造纸、食品、纺织等众多行业，在-85℃～150℃温度条件下长期输送任意浓度的硫酸、盐酸、氢氟酸、硝酸、王水、强碱、强氧化剂、有机溶剂、还原剂等强腐蚀介质而毫不受损，是目前最受使用单位欢迎的泵类设备之一。

4 结构与材料：ÀIHF系列衬氟离心泵5型号意义：IHF50-32-160(D)IH 国际标准化工泵系列代号32 泵出口直径是32mmF 过流部件材质为氟塑料合金160 叶轮名义直径160mm50 泵进口直径是50mm D 短支架结构代号6型号及参数：表一（n=2900r/min）流量扬程效率汽蚀余量进口*出口转速电机功率整机质量型号m³m%m mm r/min kw kg280122.525×2029007.5225IHF25-20-250*3.680185.57826*6.33230IHF40-25-160340×252900312483231103032*6.35020IHF40-25-200340×252900 5.517085023104830*6.38020540×32290011255 IHF40-32-2508802412783472247IHF50-32-1253.250×322900 2.2110*12.52052151650733353.250×3229004135IHF50-32-160*12.5324715304775128IHF50-32-2003.250×3229007.5180*12.5504015494878021IHF50-32-250550×32290011255 *12.580341577381522463.565×5029003135IHF65-50-125*252061351667153345IHF65-50-1603.565×502900 5.5155*2532563530651552353.565×50290011210IHF65-40-200*25505135464815 823325 8048IHF65-40-2503.565×50290018.536035 7250352252480×652900 5.5195 IHF80-65-125*502065601870353360480×65290011228 IHF80-65-160*503264602753355255IHF80-50-200480×50290015250*505063604555358248IHF80-50-2504.580×50290030480*508056607250652262IHF100-80-1254.5100×80290011245*100206512017686535655100×80290015250 IHF100-80-160*10032701102665655162IHF100-65-2005100×65290030480 *10050681204356658260IHF100-65-2505100×65290055630 *100806512065701003857IHF125-80-1605125×80290030460 *1603264180265212055636125×100290055660 IHF125-100-200*2005065220456212086546125×100290075850 IHF125-100-250*20080682106561表二（n=1450r/min）流量扬程效率汽蚀余量进口*出口转速电机功率型号m³m%m mm r/min kw3.59303.250×3214500.55 IHF50-32-160*6.38407.57.5403.512.822IHF50-32-2003.250×321450 1.1*6.312.5337.512.3403.52015550×321450 1.5 IHF50-32-250*6.320307.519.3327.5 3.840IHF65-50-1253.565×5014500.55*12.555517.54617.58.8403.565×501450 1.1 IHF65-50-160*12.585117.57.5607.51330IHF65-40-2003.565×401450 1.5*12.512.54617.511.5427.520.528IHF65-40-2503.565×4014503*12.5204317.5184517.5 5.550480×651450 1.1 IHF80-65-125*2556430 4.56817.58.358IHF80-65-160480×651450 1.5*2586230 6.85017.51348480×501450 2.2 IHF80-50-200*2512.5573011.34817.520.5434.580×5014505.5 IHF80-50-250*2520513011.34532.5 5.560IHF100-80-1254.5100×801450 1.5*5056460 4.36532.58.862IHF100-80-1605100×801450 2.2*5086955 6.56232.512.862IHF100-65-2005100×651450 5.5 *5012.5686010.85632.520.560IHF100-65-2505100×651450 5.5 *5020656016.370509.555IHF125-80-1605125×801450 5.5 *8086290 6.5506013.8606125×100145011 IHF125-100-200*10012.56411011.3606021536125×100145015 IHF125-100-250*1002069120197112022605150×125145022 IHF150-125-250*200206524018641203554IHF150-125-3155150×125145045 *200326324030621205550IHF150-125-4005.5150×125145075*200506224047622402260IHF200-150-2505.5200×150145045*400206848017622403655IHF200-150-3155.5200×150145075*400326448029632405552IHF200-150-4006200×1501450110 *40050644804664表三：IHF(D)型短支架流量扬程效率汽蚀余量进口*出口转速电机功率整机质量型号m³m%m mm r/min kw kg73335IHF50-32-160(D)3.250×322900495*12.5324715304775128IHF50-32-200(D)3.250×3229007.5135*12.550401549481522463.565×502900390IHF65-50-125(D)*252061351667153345IHF65-50-160(D)3.565×502900 5.5125*253256353065352252IHF80-65-125(D)480×652900 5.5125*5020656018707性能曲线图8安装尺寸图：9使用说明：9.1安全须知在使用泵组之前请仔细阅读本“安全须知”，以避免发生意外事故和其它的财产损失或损坏。

B系列泵中文说明书

中文说明书Doseuro®S.R.L .ALTERNATIVE DOSING PUMP WITH DIAPHRAGM,INTERPOSED FLUID AND SPRING RETURNSeriesE 125NE 175N E 250NDoseuro 目录1 泵的使用说明2 编码说明3 泵的技术参数4 工况条件5 使用概况6 泵的运输和储存7 去除保护帽8 泵的安装9 泵的位置10 泵与系统的联系11 排液端的连接12 脉动阻尼器的安装13 齿轮油的添加14 电机接线15 噪音16 泵的启动17 泵的调节18 附加设备19 其他附件20 维修保养21 泵头的定期检查22 拆换泵头及膜片23 拆换柱塞24 添加液压油25 工厂维修26 泵的报废27 部件及有害物质的处理1. 泵的使用说明1.1 泵的应用计量泵是应用在需要调节泵的流量的场合。

泵的构成：运动:根据实际的计量情况而调整电机转速, 并通过推杆及复位弹簧将往复运动变为直线运动。

传递运动: 铸铝弹性接头调节:在工作状态下和静止状态下, 都可以通过调节复位弹簧, 在0%-100%之间调整流量。

液力件：通过吸口阀计量并吸入液体，然后通过出口阀排出。

电机：三相或单相电机。

结构： V18－F－CVE三相电源: 220／240V±80／415V 50Hz； 220／280V－380／480V－60Hz单相电源:230V－50Hz我们可以根据客户要求, 提供不同电压和频率的产品。

齿轮箱：铸铝外置零件：推杆的材质是S.S. 420, 保护件及其他附件的材质都是不同种类的塑料。

2 编码说明以下述计量泵为例，说明编码中每个字母代表的意义▲注意泵头材质的技术特点请参阅更多的技术数据表B125N - 25/F 11 DV3 泵的技术参数下面是各系列计量泵技术参数参照表，请仔细阅读，严格按照要求工况运行，确保对泵不造成损坏。

B 125N – E 125N type dataB 175N - E 175N type dataB 250N - E 250N type data4 工况条件泵的实际流量与所输送的液体的粘度，比重及水力损失有关。

管道泵技术规范书
