SSD1963开发板使用手册

合集下载

SSD1963开发板使用方法

SSD1963开发板使用方法板子接口图如下图所示USB接口：电源和USB接口5V电源接口。

显示7寸大屏时要用外接5V电源。

5V电源里面是正极，外面是负极点4.3寸屏时可以用USB取电，不外接5V电源。

JP2跳线帽要短接。

串口：ISP下载口SD卡：图像数据存储位置JTAG调试口：V8单步调试STM32用接口4.3寸显示屏接口：接QD430CPOTOA-40A TFT屏接口4.3寸屏接好线效果如图7寸显示屏接口：接AT070TN83V.1 TFT屏接口接好线后的效果如下图7寸屏FFC排线接线如图接线完毕，SD卡插到卡槽中，用USB线跟电脑USB口连接。

通过串口或V8下载STM32-FD-USB-SD.HEX到开发板中，这时就把SSD1963开发板映射成一个U盘，把通过IMAGE2LCD处理的图像文件拷贝到SD卡中。

重新下载图像显示代码中STM32_FD_SDCARD.HEX文件。

TFT显示屏就会把SD卡中的图像一幅一幅的显示出来。

SSD1963开发板串口ISP 步骤该方法适合SSD1963开发板及完整开发板。

1．将板上的JP1 上的短接块拔掉，用串口线(三线制)将PC 机与开发板的COM 连接起来，接上USB线，给开发板加电。

2．运行PC 机端的FLASH LOADER 软件。

该软件在随机光盘的资料文件夹里。

设置如图，点NEXT 键3. 连接正常的情况会出现如下的界面，并指示出该期间的FLASH 的存储空间大小。

4.点击NEXT 键会显示显示详细的器件信息。

5 点击NEXT 键，显示如下，选择需要下载的HEX 文件。

6. 点击NEXT 键，经过一段下载的过程，完成代码的下载7. 完成后，给开发板断电，在开发板的JP1 上插入短接块，给开发板重新供电，程序即开始运行。
