PowerFlex 40 Adjustable Frequency AC Drive PowerFlex 40变频器
User Manual
用户手册
重要用户信息
固态设备具有不同于电动机械设备的操作特性。
《固态控制器的应用、安装和维护安全指南》(出版号SG I-1.1,本资料可从当地的Rockwell销售办事处或/manuals/gi获得)说明了固态设备和硬接线电动机械设备之间的重要差别。
由于这些差别的存在以及固态设备应用的多样性,因此所有技术人员有责任确保这些固态设备的每项应用是可行的。
罗克韦尔自动化公司绝不承担因使用该设备而引起的间接或灾后损失的责任或义务。
本手册所包含的例子和图表仅仅用于说明。
因为任何特定安装有着特定的变化因素和需求,所以罗克韦尔自动化公司不承担用户基于例子和图表中实际应用的任何责任或义务。
关于本手册中所说明的信息、电路、设备或软件,罗克韦尔自动化公司不承担任何专利责任。
如果没有得到罗克韦尔自动化公司书面允许,严厉禁止任何团体、公司、个人对本手册的内容进行整体或部分复制。
我们使用了注释贯穿于本手册,提醒用户作安全考虑。
本手册系根据英文原文版翻译而成。
本手册中若有与英文不符之处,请以英文为准。
25
26
27
注意事项:是指有关导致人员伤亡、财产损害或经济损失的实际应用或
环境情况。
注意事项可以帮助用户
z识别危害
z避免危害
z认识危害所带来后果
重要事项:
是指用户对有关产品正确理解和应用所需掌握的重要信息。
DriveExploer,Drive tools32和SCANport是罗克韦尔自动化公司的商标。
PLC是罗克韦尔自动化公司的登记注册商标。
ControlNet是ControlNet国际有限公司的商标。
DeviceNet是Open DeviceNet Vendor Association的商标。
目录
前言概述谁应该使用本用户手册… ……………. .P-1
参考资料…………………………………………P-1
手册定义 ……………………………………P-2
变频器外形尺寸…………………………………P-2
预防措施… …………………………………P-3
产品目录号说明…………………………………P-4 第一章安装/接线打开面板………………………………………….1-1
安装注意事项……………………………………1-2
交流电源注意事项 ………………… 1-3
接地要求…… ………………………………1-4
熔断器和断路器…………………………………1-6
电源接线…………………………………………1-8
I/O接线 ……………………………………..1-12
起动和速度给定控制………………………… 1-20
EMC电磁兼容指南……………………………..1-22 第二章起动变频器启动前的准备工作 ……………………2-1
操作面板 ……………………………………2-3
参数浏览和编辑…………………………………2-4
远程操作面板2-5 第三章编程与参数关于参数 ………………………………… 3-1
参数构成…………………………………………3-2
显示组……………………………………………3-3
基本程序(设置)组 …………………… . 3-9
高级程序(设置)组 …………………………… 3-14
参数对照-按名称(英文字母)顺序…………… 3-42 第四章故障处理变频器状态………………………………………4-1
故障情况……………………………………… 4-1
故障说明…………………………………………4-3
常见故障和处理措施……………………………4-5 附录A 变频器附加信息
变频器、熔断器和断路器的额定值…………….A-1
技术规范 ……………………………………… A-2 附录B 附件和尺寸
产品选型………………………………………….B-1
产品尺寸………………………………………… B-7 附录C RS485(DSI)协议
附录D RJ45 DSI 分裂式电缆
附录E 基本逻辑、步序逻辑和定时器/计数器功能
附录F PID 设置
索引
前言
概述
本手册的目的是为用户提供PowerFlex40交流变频器的安装、起动和故障处理所需的基本
信息。
相关信息参见页码
谁应该使用这本手册? P-1
参考资料 P-1
手册定义 P-2
变频器外形尺寸 P-2
预防措施 P-3
产品目录号说明 P-4
谁应该使用这本手册?
本手册面向专业技术人员。
用户必须能够对交流变频器进行编程并操作。
另外,用户必须
了解参数设置及其功能。
参考资料
要获取变频器的相关信息,建议参阅以下手册:
标题出版号网上在线获得
DRIVES-IN001… /manuals/gi
脉宽调制(PWM)交流变频器配线和接
地指南(Wiring and Grounding
Guidelines for Pulse Width Modulated
(PWM) AC Drives)
DRIVES-TD001 /manuals/dr
工业控制和驱动系统设备的预防性维
护(Preventive Maintenance of Industrial
Control and Drive System Equipment)
SG1-1.1 /manuals/gi 固态控制的应用、安装和维护安全指南
(Safety Guidelines for the Application,
Installation and Maintenance of Solid
State Control)
100-2.10 /manuals/gi 阅读原理图参考指南大全(A Global
Reference Guide for Reading Schematic
Diagrams)
8000-4.5.2 /manuals/dr 防止静电损害(Guarding Against
Electrostatic Damage)。
