车床机床夹具类外文文献翻译、中英文翻译、外文翻译

合集下载

车床介绍外文资料翻译中英文对照

车床介绍外文资料翻译中英文对照

外文资料Lathe is introduced The lathe is mainly for the car round face and boring, car and so on a work and design of machine tools. Turning rarely in itsHe kinds of machine tools, and any other machine tools are not like lathe so easily turning processing. Because of the lathe can also be used to drilling and reaming, lathe versatility can make workpiece finish a few in a installationKind of processing. Therefore, in the production of various kinds of lathes use than any other kinds of machine tools.The basic parts are: lathe bed, spindle box components, the tailstock components, slip board components, screw and light poles.Bed is lathe based pieces. It can often is by after a full normalizing or aging treatment of ductile iron of grey or into. It is a strong rigid frame, all the other basic components are installed on the bed. Usually in bed body have inside.The two set of parallel guide. Some manufacturers are using to all four guide pointed toward the triangle on rails guide namelyYamagata prefecture, and some factory guide in a group or is in both groups are using a triangle guide and a rectangleGuide. Guide to machined to guarantee their straightness precision. In order to resist wear and scratches, most modernThe guide is through the surface machine hardening, but during operation should also be careful to avoid damage guide. Guide railAny error, often means the whole machine precision damaged.Spindle boxinstalled in the fixed position medial guide, usually left end of the bed. It provides power, and can make the workPieces of speed in turn. It basically consists of a installed in the hollow shaft and precision bearing a series of variable speed teethWheel similar to the truck gearbox together. Through the sliding gears, spindle can swim in the many kinds of rotating speed. mostlyCount lathe have 8 to 12 kinds of speed, general form. According to arrange series But in the modern machine just pull 2 ~ 4 handlesSo they can get all the speed. A growing trend is through the electrical or mechanical device withoutVariable.Due to the accuracy of machine tool depends largely on spindle, therefore, spindle structure size is larger, usually installedAfter the preloaded the heavy tapered roller bearings or ball bearings. Axis in a full-length through-hole throughout bar feeders, longThrough the hole by feeding. The size of the Lord when an important dimension is lathe, so when the work-piece must be when the principalThe materials, it confirms that can process the imum size of the blank bar feeders.The tailstock component mainly consists of three parts. The inside of the motherboard and lathe bed rails, can be in guide with the longitudinallyMobile. Floor has a can make whole the tailstock component clamping device at any position. The tailstock body installed in the endBoard, along some type of key slot in floor lateral movement, make the tailstock can and spindle box to the spindle is.The tailstock third part is the tailstock sleeve. It is a diameter usuallyat about 51 ~ 76mm 2 ~ 3 inchesThe steel hollow cylinder between. Through the handwheel and screw, the tailstock sleeve can in the tailstock body and move in a few longitudinal moveAn inch.The lathe with two dimensions specifications said. The first called lathe bed surface the largest machining diameter. This is in the latheCan the biggest diameter workpiece rotate. It is about two top attachment and guide rail of the distance of the nearest point two times. The second size is the imum distance between the two top. Lathe bed surface the largest machining diameter said on a latheThe biggest workpiece to turning diameter and the imum distance between the two top, said two top can be installed in betweenThe imum length of workpiece.Ordinary lathe is in the production of the most frequently used lathes type. They have all those front parts of SyracuseHeavy machine, and outside, all except for small knife tool sport has motor feed. They are usually the specifications: lathe bed face biggest process diameter for 305 ~ 610mm 12 to 24 inches; But, the bed surface the largest machining diameterAchieve 1270mm 50 inches and the distance between the two top 3658mm lathe to is not uncommon also. These carsBed most have scraps plate and a installed in internal cooling fluid circulation system. Small plain lathe bed face -- latheThe largest machining diameter usually less than 330mm 13 inches - is designed, and its bench-type lathe bed installation at workStations or on the cabinet.Although there are many USES, ordinary lathe is very useful, butthe machine tool and replacement and adjust to measure the work piece flowersFee much time, so they are not suitable for mass production application. Usually, their actual processing time less than its30% of total processing time. In addition, need skilled workers to operate ordinary lathe, the worker's salary highAnd difficult to hire. However, most of the time but operating workers spend on simply repeating adjustment and observation scraps process. Therefore, in order to reduce or totally not to hire this kind of skilled workers, hex lathe, threaded processing lathe and otherTypes of semi-automatic and automatic lathe has well developed, and has been widely applied in production.车床介绍车床主要是为了进行车外圆、车端面和镗孔等项工作而设计的机床。

机床加工外文文献翻译

机床加工外文文献翻译

机床加工外文文献翻译(含:英文原文及中文译文)文献出处:Shunmugam M. Basic Machining Operations and Cutting Technology[J]. Journal of the Institution of Engineers, 2014, 1(2):22-32. 英文原文Basic Machining Operations and Cutting TechnologyShunmugam MBasic Machining OperationsMachine was developed from the early Egyptian pedal car and John Wilkinson's trampoline. They provide rigid support for workpieces and tools and can precisely control their relative position and relative speed. Basically, metal cutting refers to a sharpened pry tool that removes a very narrow metal from the surface of a tough workpiece. Chips are discarded products. Compared with other workpieces, the chips are shorter, but there is a certain increase in the thickness of the uncut parts. The geometry of the workpiece surface depends on the shape of the tool and the path of the tool during machining operations.Most machining processes produce parts of different geometries. If a rough workpiece rotates on the central axis and the tool cuts into the workpiece surface parallel to the center of rotation, a rotating surface is created. This operation is called turning. If a hollow tube is machined onthe inner surface in the same way, this operation is called boring. When the diameter is evenly changed, a conical outer surface is produced, which is called taper turning. If the tool contact point moves in a way that changes the radius, then a workpiece with a contour like a ball is produced; or if the workpiece is short enough and the support is very rigid, then the forming tool normally feeds one outside the axis of rotation. Surfaces can be produced, and short tapered or cylindrical surfaces can also be formed.Flat surfaces are often required and they can be produced by radial turning of tool contact points with respect to the axis of rotation. It is easier to fix the tool and place the workpiece under the tool for larger workpieces while planing. The tool can feed reciprocally. The forming surface can be produced by a forming tool.Multi-blade cutters can also be used. Using a double-edged groove drilling depth is 5-10 times the hole diameter. Regardless of whether the drill rotates or the workpiece rotates, the relative motion between the cutting edge and the workpiece is an important factor. During milling, a rotating tool with many cutting edges comes into contact with the workpiece and the workpiece slowly moves relative to the tool. Flat or shaped surfaces may occur depending on the tool geometry and feed method. A horizontal or vertical axis rotation can be generated and can be fed in any of three coordinate directions.Basic machineThe machine tool produces parts with special geometry and precise dimensions by removing chips from plastic material. The latter is waste, which is a change from the long continuous strip of plastic material such as steel, which is useless from a processing point of view. It is easy to handle cracked chips produced from cast iron. The machine performs five basic metal removal processes: turning, planing, drilling, and milling. All other metal removal processes are modified from these five basic procedures. For example, boring is internal turning; reaming, tapping and counterboring are further machining of drilled holes; gear machining is based on Milling operation. Polishing and sanding are deformations that grind and remove the abrasive process. Therefore, there are only four basic types of machine tools that use specially controllable cutting tools: 1. Lathes, 2. Drilling machines, 3. Milling machines, 4. Grinding machines. The grinding process forms chips, but the geometry of the abrasive particles is uncontrollable.The amount and speed of material removal through various processing steps is enormous, just as high facets are removed in large turning operations, or in extremely small grinding and ultra-precision machining. A machine tool fulfills three major functions: 1. It supports work pieces or fixtures and tools 2. It provides relative motion to work pieces and tools 3. In each case provides a range of feeds and generallyup to 4-32 species Speed choices.Processing speed and feedSpeed, feed, and depth of cut are three major variables in economic processing. The other quantities are tapping and tool material, coolant and tool geometry. The speed of the metal removal and the power required are dependent on these variables.Depth of cut, feed, and cutting speed are the mechanical parameters that must be established in any metalworking process. They all affect the force, speed and speed of metal removal. The cutting speed can be defined as the radius of the velocity recording surface that spreads radially at any instant during one revolution, or the distance between two adjacent grooves. The depth of cut is the depth of entry and the depth of the trench.Turning in the center of the latheBasic operations completed on a motorized bed have been introduced. Those operations that use a single point tool on the outside surface are called turning. In addition to drilling, reaming, and grinding of internal surfaces, the operation is done by a single point tool. All machining operations, including turning, can be categorized as roughing, finishing or semi-finishing. Finishing removes a large amount of material as quickly and efficiently as possible, while a small part of the material left on the workpiece is used for finishing. Finishing isThe workpiece gets the final size, shape and surface accuracy. Sometimes semi-finishing leaves a predetermined amount of material for finishing, which is prior to finishing.In general, longer workpieces are simultaneously supported by one or two lathe centers. Conical holes, so-called center holes, are drilled at both ends for the center of the lathe - usually along the axis of the cylindrical workpiece. The end of the workpiece near the frame is usually supported by the center of the tailstock. At the end near the main bearing is the center of the main bearing or clamped by the jaw plate. This method can firmly tighten the workpiece and can smoothly transmit the force to the workpiece. The auxiliary support provided by the chuck to the workpiece reduces the chattering tendency during cutting. If the chuck can be carefully and accurately used to support the workpiece, then Accurate results can be obtained.Supporting the workpiece between two centers can give very accurate results. One end of the workpiece has been machined, then the workpiece can be turned. The other end is machined on a lathe, and the center hole serves as a precise positioning surface and a supporting surface for carrying the weight of the workpiece and resisting the cutting force. When the workpiece is removed from the lathe for any reason, the center hole will accurately return the workpiece to this lathe or another lathe or a cylindrical grinder. Workpieces are not allowed to be clampedon the main bearing by the chuck and lathe center. However, the first thing that comes to mind is a method of quickly adjusting the workpiece on the chuck, but this is not allowed because it is impossible to hold the center of the lathe while holding it by the chuck. The adjustment provided by the center of the lathe will not continue and the claw plate pressure will damage the center hole and lathe center, and even the lathe spindle. The floating claw plate provides an exception to the above statement. It is used almost exclusively for high production work. These chucks are real job drivers and are not used for the same purpose as ordinary three-jaw, four-jaw chucks.While large-diameter workpieces are fashioned in two centers, they are preferably held by the panel at the tail of the main bearing for smooth energy conversion; many lathe chucks do not provide sufficient energy conversion, although they can be used as special energy conversions.Mechanical processing introductionAs a method of producing a shape, machining is the most commonly used and the most important method in all manufacturing processes. The machining process is a process of producing a shape in which the drive device removes some of the material on the workpiece as chips. Although in some cases, the workpiece is supported using mobile equipment without support, most machining operations are performed by equipment that supports both the workpiece and the tool.Small batch, low cost. Machining has two applications in the manufacturing industry. Casting, forging, and pressure work produce each special shape, even one part, almost always with a higher mold cost. The shape of the weld depends largely on the raw material. By using equipment that has a high overall cost but does not have a special mold, machining is possible; starting from almost any kind of raw material, the shape is designed from any material as long as the external dimensions are large enough. Processing is therefore the preferred method. When producing one or several parts or even in mass production, the design of the parts logically leads to the casting, forging or stamping of the product. High precision, surface accuracy. The second application of mechanical machining is based on the possible high precision and surface accuracy. If mass production occurs in other processes, many low-volume components will produce low but acceptable tolerances. On the other hand, many parts produce general shapes from some large deformation processes and are only machined on selected surfaces with very high accuracy. For example, the inside process is seldom produced by any other machining method and the hole on the part may be processed immediately after the pressure operation.The main cutting parametersThere are four factors that fully describe the relationship between the basic tooling work during cutting: tool geometry, cutting speed and depthof cut. The tool must be made of a suitable material; it must have a certain strength, roughness, hardness and fatigue resistance. The tool geometry is described by face and angle and is correct for each cutting operation. Cutting speed refers to the speed at which the cutting edge passes through the work surface, which has been expressed in feet per minute. For machining efficiency, the cutting speed must be of an appropriate scale relative to the particular working combination. In general, the harder the work, the lower the speed. Feed is the rate at which the tool enters the workpiece. When the workpiece or tool rotates, the feed rate is in inches per revolution. When the tool or workpiece moves back and forth, the unit of feed is inches. In general, the feed rate is inversely proportional to the cutting speed in other similar situations. The cutting speed is expressed in inches and is represented by the distance the tool enters the workpiece. It refers to the width of the chips when turning or the thickness of the chips when cutting in a straight line. The depth of cut during roughing is greater than the depth of cut during finishing.Effect of Cutting Parameter Change on Cutting TemperatureIn metal cutting operations, heat is generated in the primary and secondary deformation zones and these results in complex temperatures throughout the tool, workpiece, and chips. A typical isothermal as shown in the figure, it can be seen that as predicted, when the workpiece materialundergoes major deformation and is reduced, there is a very large temperature gradient throughout the entire width of the chip. When the chips in the second deformed zone still have a short distance, the maximum temperature is reached.Because almost all of the work is done with metal cutting converted to heat, it can be predicted that the increased energy consumption per unit volume of metal removed will increase the cutting temperature. Therefore, when all the other parameters are unchanged, the rake angle becomes larger and the energy and cutting temperature per unit volume of metal removed will be reduced. When considering the increase in the thickness and speed of the non-formed chips, the situation is even more complicated. Increasing the thickness of the cut will often greatly affect the amount of heat transferred to the workpiece, the number of tools, and will keep the chips at a fixed amount, and at the same time the change in cutting temperature will be small. However, increasing the cutting speed will reduce the amount of heat transferred to the workpiece. This will increase the temperature rise of the main deformation of the chips. In addition, the second deformation zone is relatively small, and in this deformation zone it will increase the temperature. The other changes in cutting parameters hardly affect the removal of energy consumption per unit volume and the cutting temperature. It has thus been shown that even small changes in cutting temperature have a significant effect on toolwear rate, and it is appropriate to estimate the cutting temperature from the cutting data. The most direct and accurate method of testing high-speed steel tools, Trent gave detailed information on the temperature distribution of high-speed steel tools. This technique is based on the data detection of high-speed steel tools and is related to the microscopic changes in thermal history.Trent has described the measurement of cutting temperature and the temperature distribution of high-speed steel tools when machining a wide range of workpieces. Using scanning electron microscopy to study fine-scale microstructure changes, this technique has been further developed. This technique is also used to study the temperature distribution of high-speed steel single-point turning tools and twist drills.Tool wearBrittle fractures have been treated and there are basically three types of tool wear. Back flank wear, boundary wear and flank wear. Face wear occurs at the major and minor cutting edges. The main cutting edge is responsible for the removal of large amounts of metal, which increases the cutting force and temperature, and if left unchecked the vibration of the tool and the workpiece can be caused, and this can no longer be cut efficiently. The secondary cutting edge determines the workpiece size and surface finish. Wear of the flank causes poor surface accuracy in a large number of products. According to the actual cutting conditions, the mainreason for the unacceptable use of the tool is that the wear of the main flank before the secondary flank is very large, which results in the generation of an unacceptable portion. Due to the stress distribution of the tool, the frictional force in the sliding area is maximized between the chip and the surface at the beginning of sliding, and the final frictional force is zero. Therefore, abrasive wear occurs in this area. More wear occurs between the chip and the disengagement area adjacent to the area, which is more than adjacent to this point.This results in a localized pitting of the tool face at a certain distance from the face, which is usually partly arc-shaped. In many respects and based on actual cutting conditions, the boundary wear is a less severe wear than the flank, so that the wear of the face is a relatively common blunt standard. Then, as various authors have shown, with the increase of cutting speed, the increase of surface temperature is more than the increase of the blade surface, and because the temperature change seriously affects any type of wear rate, boundary wear usually occurs at higher cutting speeds. Situation.Where the tool is in contact with the uncut surface, the wear of the trailing portion of the main flank is more pronounced than that along the remaining wear surface. This is because the local influences such as the uncut surface are caused by the work hardening caused by the previous cutting, oxidation scale, and local high temperature. This localized wearis generally related to the wear of the boundary and is sometimes severe. Although the occurrence of a notch does not seriously affect the cutting performance of the tool, the notch is often deeper, and it is likely that the cutting tool will break if it continues.If any form of gradual wear continues to make its dramatic existence, the tool will face catastrophic failures, such as the cutting tool can not be cut, in good condition, the workpiece is scrapped, at worst, the mechanical tool may cause damage. For cemented carbide tools and various types of wear and tear, the maximum service life limit is reached before a catastrophic failure occurs. However, wear on high-speed steel cutting tools is uneven. It has been found that when wear continues and even catastrophic failure occurs, the most meaningful and reproducible results are obtained, but in practice, the cutting time is much less. At the time of failure. Several phenomena occur when a catastrophic failure occurs. The most common is a sudden increase in cutting force, a bright ring in the workpiece, and a significant increase in noise.Surface finishing mechanismThere are five basic mechanisms that affect the processed product: (1) The basic geometry of the cutting process, the single-point turning tool will advance axially a constant distance, the resulting surface will be on it, and the tool will feed in the vertical direction. A series of sharp points form the basic shape of the cutting tool. (2) The efficiency ofcutting. It has already been mentioned that an unstable tumor will produce a face that contains hardened tumor segments. This fragment reduces the surface finish. It can also be proved that under heavy cutting conditions, large feed rates, small rake angles and low cutting speeds can be used. In addition to these, the production conditions can also lead to unstable BDE products. The cutting process becomes unstable rather than continuous cutting in the shear zone. , Shattered, uneven discontinuous chips appear, and the surface is not smooth enough. This is especially true when working with ductile materials. (3) The stability of the machine tool. According to certain combinations of cutting conditions, workpiece dimensions, clamping methods and stiffness relative to the machine structure, instability is a tool-induced chatter. Under certain conditions, this kind of vibration will reach and maintain a certain amplitude, and vibrations based on other conditions will also be generated, unless the cutting prevents considerable damage or both the cutting tool and the workpiece may vibrate. This phenomenon is called chattering.Axial turning features a long spiral band on the workpiece and short pitch fluctuations on the temporary machined surface. (4) Remove the effectiveness of cuttings. In intermittent chip production processes, such as milling and turning of brittle materials, it is expected that whether due to gravity or cutting fluid, chips will leave the cutting zone and in any case will not affect the cutting surface. Consecutive chips are obvious,and if no measures are taken to control the chips, they may affect the cutting surface and leave marks. Inevitably, this marks only expectations.(5) The effective relief angle of the cutting tool. For small cutting edges and relief angles with a certain geometry, it is possible to cut at the main cutting edge and polish at the secondary cutting edge. This will result in good surface accuracy, but of course this combination of strictly metal forming cannot be recommended as an actual cutting method. However, due to occasional occurrence of these conditions, tool wear can cause changes in the surface properties.Limits and tolerancesMechanical parts are manufactured so they are interchangeable. In other words, each mechanical part or device is made to a size and shape suitable for other types of machines. In order to make the parts interchangeable, each part is dimensioned to fit the corresponding part in the right way. This is not only impossible, but it is impractical to make many parts into one size. This is because the machine is not perfect and the tool wears. A slight deviation from the correct size is usually allowed. The size of this deviation depends on the type of part being manufactured. For example, a part may be 6 inches and the upper and lower deviation is 0003 inches (one thousandth of a thousandth). So this deviation can be between 5,997 inches and 6003 inches and still maintain the correct size. This is bias. The difference between the upper and lower deviations is theThe tolerance is the maximum amount of change in part size, and the basic size is the size limit derived from the allowable variation and tolerance range. Sometimes the deviation allows only one direction to change. It allows the tolerance to change in the hole or axis without seriously affecting the fit. When the tolerance changes in both directions, it is called full deviation (positive and negative). The full deviation is separate and there will be on each side of the basic size. The limit size is only the largest size and the smallest size. Therefore, the to lerance is the difference between these two dimensions.Surface accuracy and size controlProducts have been completed in their proper shape and size, and often require some type of surface accuracy to enable them to perform their own functions. In some cases, in order to resist scratching and scratching, it is necessary to improve the physical properties of the surface material. In many manufacturing processes, dirt, chips, grease or other harmful substances are left on the surface of the product. Mixtures of different materials, the same materials processed in different ways, may require some special surface treatment to provide a uniform appearance.基本加工工序和切削技术Shunmugam M基本加工的操作机床是从早期的埃及人的脚踏动力车和约翰·威尔金森的镗床发展而来的。

外文翻译--车床和车削(8000多字)

外文翻译--车床和车削(8000多字)

附录翻译部分Lathe and TurningThe Lathe and Its ConstructionA lathe is a machine tool used primarily for producing surfaces of revolution flat edges. Based on their purpose,construction,number of tools that can simultaneously be mounted,and degree of automation,lathes or,more accurately,lathe-type machine tools can be classified as follows:(1)Engine lathes(2)Toolroom lathes(3)Turret lathes(4)Vertical turning and boring mills(5)Automatic lathes(6)Special-purpose lathesIn spite of that diversity of lathe-type machine tools,they all have all have common features with respect to construction and principle of operation.These features can best be illustrated by considering the commonly used representative type,the engine lathe.Following is a description of each of the main elements of an engine lathe,which is shown in Fig.11.1.Lathe bed.The lathe bed is the main frame,involving a horizontal beam on two vertical supporis.It is usually made of grey or nodular cast iron to damp vibrations and is made by casting.It has guideways to allow the carriage to slide easily lengthwise.The height of the lathe bed should be appropriate to enable the technician to do his or her jib easily and comfortably.Headstock.The headstock is fixed at the left hand side of the lathe bed and includes the spindle whose axis is parallel to the guideways(the silde surface of the bed).The spindle is driven through the gearbox,which is housed within the headstock.The function of the gearbox is to provide a number of different spindle speeds(usually6up to18speeds).Some modern lathes have headstocks with infinitely variable spindle speeds,which employ frictional, electrical,or hydraulic drives.The spindle is always hollow,I.e,it has a through hole extending lengthwise.Bar stocks can be fed througth that hole if continous production is adopted.A lso,that hole has a taperedsurface to allow mounting a plain lathe center.The outer surface of the spindle is threaded to allow mounting of a chuck,a face plate,or the like.Tailstock.The tailstock assembly consists basically of three parts,its lower base,an intermediate part,and the quill.The lower base is a casting that can slide on the lathe bed along the guidewayes,and it has a clamping device to enable locking the entire tailstock at any desired location,depending upon the length of the workpiece.The intermediate parte is a casting that can be moved transversely to enable alignment of the axis of the the tailstock with that of the headstock.The third part,the quill,is a hardened steel tube,which can be moved longitudinally in and out of the intermediate part as required.This is achieved through the use of a handwheel and a screw,around which a nut fixed to the quill is can be locked at any point along its travel path by means of a clamping device.The carriage.The main function of the carriage is mounting of the cutting tools and generating longitudinal and/or cross feeds.It is actually an H-shaped block that slides on the lathe bed between the headstock and tailstock while being guided by the V-shaped guideways of the bed.The carriage can be moved either manually or mechanically by means of the apron and either the feed rod or the lead screw.When cutting screw threads,power is provided to the gearbox of the apron by the lead screw.In all other turning operations,it is the feed rod that drives the carriage.The lead screw goes through a pair o half nuts,which are fixed to the rear of the apron.When actuating a certain lever,the half nuts are clamped together and engage with the rotating lead screw as a single nut,which is fed,together with carriage,along the bed.when the lever is disengaged, the half nuts are released and the carriage stops.On the other hand,when the feed rod is used,it supplies power to the apron through a wrom gear.The latter is keyed to feed rod and travels with the apron along the feed rod,which has a keyway extending to cover its whole length.A modern lathe usually has a quick-change gearbox located under the headstock and driven from the spindle through a train of gears.It is connected to both the feed rod and the lead screw and enables selecting a variety of feeds easily and rapidly by simply shifting the appropriate levers, the quick-change gearbox is employed in plain turning,facing and thread cutting operations. Since that gearbox is linked to spindle,the distance that the apron(and the cutting tool)travels for each revolution of the spindle can be controlled and is referred to as the feed.Lathe Cutting ToolsThe shape and geometry of the lathe tools depend upon the purpose for which they are employed.Turning tools can be classified into tow main groups,namely,external cutting tools andinternal cutting tools,Each of these groups include the following types of tools: Turning tools.Turing tools can be either finishing or rough turning tools.Rough turning tools have small nose radii and are used for obtaining the final required dimensions with good surface finish by marking slight depth of cut.Rough turning tools can be right–hand or left-hand types,depending upon the direction of feed.They can have straight,bent,or offset shanks.Facing tools.Facing tools are employed in facing operations for machining plane side or end surfaces.There are tools for machining left-hand-side surfaces and tools for right-hand-side surfaces.Those side surfaces are generated through the use of the cross feed,contrary to turning operations,where the usual longitudinal feed is used.Cutoff tools.Cutoff tools,which are sometimes called parting tools,serve to separate the workpiece into parts and/or machine external annual grooves.Thread-cutting tools.Thread-cutting tools have either triangular,square,or tranpezoidal cutting edges,depending upon the cross section of the desired thread.Also,the plane angles of these tools must always be identical to those of the thread forms.Thread-cutting tools have straight shanks for external thread cutting and are of the bent-shank type when cutting internal threads.Form tools.Form tools have edges especially manufactured to take a certain form,which is opposite to the desired shape of the machined workpiece.An HSS tools is usually made in the form of a single piece,contrary to cemented carbides or ceramic,which are made in the form of tipes.The latter are brazed or mechanically fastened to steel shanks.Fig.1indicates an arrangement of this latter type,which includes the carbide tip,the chip breaker,the pad,the clamping screw(with a washer and a nut),and the shank..As the name suggests,the function of the chip breaker is to break long chips every now and then,thus preventing the formation of very long twisted ribbons that may cause problems during the machining operations.The carbide tips(or ceramic tips)can have different shapes,depending upon the machining operations for which they are to be employed.The tips can either be solid or with a central through hole,depending on whether brazing or mechanical clamping is employed for mounting the tip on the shank.Fig.1Lathe OperationsIn the following section,we discuss the various machining operations that can be performed on a conventional engine lathe.It must be borne in mind,however,that modern computerized numerically controlled lathes have more capabiblities and do other operations,such as contouring,for example.Following are conventional lathe operations.Cylindrical turning.Cylindrical turning is the the simplest and the most common of all lathe operations.A single full turn of the workpiece generate a circle whose center falls on the lathe axis;this motion is then reproduced numerous times as a result of the axial feed motion of the tool.The resulting machining marks are,therefore,a helix having a very small pitch,which is equal to the feed.Consequently,the machined surface is always cylindrical.The axial feed is provided by the carriage or the compound rest,either manually or automatically,whereas the depths of cuts is controlled by the cross slide.In roughing cuts,it is recommended that large depths of cuts(up to0.25in.or6mm,depending upon the workpiece material)and smaller feeds would be used.On the other hand,very fine feeds,smaller depth of cut(less than0.05in.,or0.4mm),and high cutting speeds are preferred for finishing cuts.Facing.The result of a facing operation is a flat surface that is either the whole end surface of the workpiece or an annular intermediate surface like a shoulder.During a facing operation,feed is provided by the cross slide,whereas the depth of cut is controlled by the carriage or compound rest.Facing can be carried out either from the periphery in ward or from the center of the workpiece outward.It is obvious that the machining marks in both cases tack the form of a ually,it is preferred to clamp the carriage during a facing operation,since the cutting force tends to push the tool(and,of course,the whole carriage)away from the workpiece.In most facing operations,the workpiece is held in a chuck or on a face plate.Groove cutting.In cut-off and groove-cutting operations,only cross feed of the tool isemployed.The cut-off and grooving tools,which were previously discussed,are employed.Boring and internal turning.Boring and internal are performed on the internal surfaces by a boring bar or suitable internal workpiece is solid,a drilling operation must be performed first.The drilling tool is held in the tailstock,and latter is then fed against the workpiece.Taper turning.Taper turning is achieved by driving the tool in a direction that is not paralled to the lathe axis but inclined to it with an angle that is equal to the desired angle of the taper.Following are the different methods used in taper-turning practice:(1)Rotating the disc of the compound rest with an angle to half the apex angle of the cone. Feed is manually provided by cranking the handle of the compound rest.This method is recommended for taper turning of external and internal surfaces when the taper angle is relatively large.(2)Employing special form tools for external,very short,conical surfaces.The width of the workpiece must be slightly smaller than that of the tool,and the workpiece is usually held in a chuck or clamped on a face plate.I n this case,only the cross feed is used during the machining process and the carriage is clamped to the machine bed.(3)Offsetting the tailstock center.This method is employed for esternal tamper turning of long workpiece that are required to have small tamper angles(less than8).The workpiece is mounted between the two centers;then the tailstock center is shifted a distance S in the direction normal to the lathe axis.(4)Using the taper-turning attachment.This method is used for turning very long workpoece, when the length is larger than the whole stroke of the compound rest.The procedure followed in such cases involves complete disengagement of the cross slide from the carriage,which is then guided by the taper-turning attachment.During this process,the automatic axial feed can be used as usual.This method is recommend for very long workpiece with a small cone angle,i.e., 8through10.Thread cutting.When performing thread cutting,the axial feed must be kept at a constant rate,which is dependent upon the rotational speed(rpm)of the workpiece.The relationship between both is determined primarily by the desired pitch of the thread to be cut.As previously mentioned,the axial feed is automatically generated when cutting a thread by means of the lead screw,which drives the carriage.When the lead screw rotates a single revolution,the carriage travels a distance equal to the pitch of the lead screw rotates a single revolutional speed of the lead screw is equal to that of the spindle(i.e.,that of the workpiece),the pitch of the resulting cut thread is exactly to that of the lead screw .The pitch of the resulting thread being cut therefore always depends upon the ratio of the rotational speeds of the lead scew and the spindle :workpiece of pitch screwlead the of Pitch Desired =screw lead of workpiece the of rpm rpm =spindle-to-carriage gearing ratioThis equation is usefully in determining the kinematic linkage between the lathe spindle and the lead screw and enables proper selection of the gear train between them .In thread cutting operations ,the workpiece can either be held in the chuck or mounted between the two lathe centers for relatively long workpiece .The form of the tool used must exactly coincide with the profile the thread to be cut ,I .e .,triangular tools must be used for triangular threads ,and so on .Knurling .knurling is mainly a forming operation in which no chips are prodyced .Tt involves pressing two hardened rolls with rough filelike surfaces against the rotating workpiece to cause plastic deformation of the workpiece metal.Knurling is carried out to produce rough ,cylindrical (or concile )surfaces ,which are usually used as handles .Sometimes ,surfaces are knurled just for the sake of decoration ;there are different types of patterns of knurls from which to choose .Cutting Speeds and FeedsThe cutting speed ,which is usually given in surface feet per minute (SFM),is the number of feet traveled in circumferential direction by a given point on the surface (being cut )of the workpiece in one minute .The relationship between the surface speed and rpm can be given by the following equation :SMF=πDNWhereD=the diameter of the workpiece in feetN=the rpmThe surface cutting speed is dependent primarily upon the machined as well as the material of the cutting and can be obtained from handbooks ,information provided by cutting tool manufacturera ,and the like .generally ,the SFM is taken as 100when machining cold-rolled or mild steel ,as 50when machining tougher metals ,and as 200when machining sofer materials .For aluminum ,the SFMis usually taken as 400or above .There are also other variables that affect the optimal value of the surface cutting speed .These include the tool geometry,the typeof lubricant or coolant ,the feed ,and the depth of cut .As soon as the cutting sped is decided upon ,the rotational speed (rpm)of the spindle can be obtained as follows :N =DSFWπThe selection of a suitable feed depends upon many factors ,such as the required surface finish ,the depth of cut ,and the geometry of the tool used .Finer feeds produce better surface finish ,whereas higher feeds reduce the machining time during which the tool is in direct contact with the workpiece .Therefore ,it is generally recommended to use high feeds for roughing operations and finer feeds for finishing operations.Again,recommend values for feeds ,which can be taken as guidelines ,are found in handbooks and information booklets provided by cutting tool manufacturers.Here I want to introduce the drilling:Drilling involves producing through or blind holes in a workpiece by forcing a tool ,which rotates around its axis ,against the workpiece .Consequently ,the range of cutting from that axis of rotation is equal to the radius of the required hole .In practice ,two symmetrical cutting edges that rotate about the same axis are employed .Drilling operations can be carried out by using either hand drills or drilling machines .The latter differ in size and construction .nevertheless ,the tool always rotates around its axis while the workpiece is kept firmly fixed .this is contrary to drilling on a lathe .Cutting Tool for Drilling OperationsIn drilling operations ,a cylindrical rotary-end cutting ,called a drill ,is employed .The drill can have either one or more cutting edges and corresponding flutes ,which can be straight or helical .the function of the flutes is to provide outlet passages for the chips generated during the drilling operation and to allow lubricants and coolants to reach the cutting edges and the surface being machined .Following is a survey of the commonly used drills.Twist drill .The twist drill is the most common type of drill .It has two cutting edges and two helical flutes that continue over the length of the drill body ,The drill also consist of a neck and a shake that can be either straight or tapered .In the latter case ,the shank is fitted by the wedge action into the tapered socket of the spindle and has a tang ,which goes into a slot in the spindle socket ,thus acting as a solid means for transmitting rotation .On the other hand ,straight –shank drills are held in a drill chuck that is ,in turn ,fitted into the spindle socket in the same way as tapered shank drills.The two cutting edges are referred to as the lips,and are connected together by a wedge, which is a chisel-like edge.The twist drill also has two margins,which enable proper guidance and locating of the drill while it is in operation.The tool point angle(TPA)is formed by the lips and is chosen based on the properties of the material to be cut.The usual TAP for commercial drills is118,which is appropriate for drilling low-carbon steels and cast irons.For harder and tougher metals,such as hardened steel,brasss and bronze,larger TPAs(130OR140)give better performance.The helix angle of the flutes of the commonly used twist drills ranges between24and30.When drilling copper or soft plastics,higher values for the helix angle are recommended(between35and45).Twist drills are usually made of high speed steel,although carbide tipped drills are also available.The size of twist drills used in industrial range from0.01up to3.25in.(i.e.0.25up to 80mm).Core drills.A core drill consists of the chamfer,body,neck,and shank.This type of drill may be have either three or four flutes and an equal number of margins,which ensure superior guidance,thus resulting in high machining accuracy.It can also be seen in Fig12.2 that a core drill has flat end.The chamfer can have three or four cutting edges or lips,and the lip angle may vary between90and120.Core drills are employed for enlarging previously made holes and not for originating holes.This type of drill is characterized by greater productivity, high machining accuracy,and superior quality of the drilled surfaces.Gun drills.Gun drills are used for drilling deep holes.All gun drills are straight fluted, and each has a single cutting edge.A hole in the body acts as a conduit to transmit coolant under considerable pressure to the tip of the drill.There are two kinds of gun drills,namely,the center cut gun drill used for drilling blind holes and the trepanning drill.The latter has a cylindrical groove at its center,thus generating a solid core,which guides the tool as it proceeds during the drilling operation.Spade drills.Spade drills are used for drilling large holes of3.5in.(90mm)or more. Their design results in a marked saving in cost of the tool as well as a tangible reduction in its weight,which facilitates its handling.moreover,this type of drill is easy to be ground.[13]车床和车削车床及它的结构车床是一个主要用来生产旋转表面和端面的机床。

机床刀具设计机械加工工艺夹具外文文献翻译、中英文翻译、外文翻译

机床刀具设计机械加工工艺夹具外文文献翻译、中英文翻译、外文翻译

英语原文:Design Of Tool Machine PropResearch significanceThe original knife machine control procedures are designed individually, not used tool management system, features a single comparison, the knife only has to find the tool knife, knife positioning the shortest path, axis tool change, but does not support large-scale tool.Automatic knife in the knife election, in the computer memory knife-election on the basis of using the Siemens 840 D features, and the election procedures knife more concise, and complete the space Daotao View. ATC use the knife rapid completion of STEP-7 programming, and have been tested in practice. In the positioning of the knife, PLC controlled modular design method, which future production of similar machines will be very beneficial, it is easy to use its other machine. Automatic tool change systems will be faster growth, reduced tool change time, increase the positioning accuracy tool is an important means to help NC technology development.Tool and inventory components of modern production is an important link in the management, especially for large workshop management. The traditional way of account management, and low efficiency, high error rate, and not sharing information and data, tools and the use of state can not track the life cycle, are unable to meet the current information management needs. With actual production, we have to establish a workshop tool for the three-dimensional tool storage system to meet the knife workshop with auxiliary storage and management needs.The system uses optimization technology, a large number of computer storage inventory information, timely, accurate, and comprehensive tool to reflect the inventory situation. The entire system uses a graphical interface, man-machine dialogue tips from the Chinese menu, select various functions can be realized and the importation of all kinds of information. Management system using online help function. Through the workshop management, network management and sharing of information. Have automated inventory management, warehousing management tool, a tool for the management and statistical functions.1.System components and control structureThe entire system, including the structure and electrical machinery control systems.1.1.1Mechanical structure and working principleTool from the stent, drive, drive system, Turret, shielding, control system, and electrical components. Support from the column, beam, the upper and lower guide Central track, and track support component.1) Drive for the system chosen VVVF method. Cone used brake motors, with VVVF by Cycloid reducer through sprocket drive.2) Drag a variable frequency drive system and control technology. VVVF adopted, will speed drive shaft in the normal range adjustment to control the speed rotary turret to 5 ~ 30mm in, the drive shaft into two, two under through sprocket, the two profiled rollers Chain driven rotating shelves. Expansion chain adopted by the thread tight regulation swelling, swelling the regular way. - Conditioned, under the same chain-of-conditioning, so that the chain of uniform.3) Turret and shields the entire total of 14 independent Turret. 13 of them as a socket-Turret, as adrawer-Turret, each Turret back through the pin and, under the conveyor chain link chain plate, installed at the bottom roller, chain driven rotating turret rotation along the track. Outlet-Turret and BT50-BT40 Turret Turret two kinds of forms. To strengthen management, security, landscaping modeling, shelf peripherals and shields. Turret-drawer drawer placed at six other Des V oeux a knife, can be categorized with some of knife auxiliary equipment, such as bits, such as turning tools.1.1.2.Electrical Control SystemThis tool storage systems is the main electrical control their shelves for operational control and position control. Operational control equipment, including operation of the start of braking control. Position Control is the main location and address of the shelves for testing. Control system as shown in Figure 1.图 1 Tool Control System for the1) Electric Transmission horizontal rotary tool storage systems are the mechanical movements are repeated short-term work system. And the run-time system needs some speed, speed transmission needs, the system will use VVVF method can be used simple structure, reliable operation of the motor and frequency inverter.2) Control of the system is divided into two kinds of manual control and automatic control, manual control as a general reserve and debugging methods of work; ways to the system control computer (IPC) and the control unit (inverter contactor , etc.) consisting of a control system.3) location and positioning accuracy of the system automatically identify the site and location using a detection device as proximity switches, relays through the plate-point isolation and the number plate recorded close to the switching signal acquisition and operation of Hutchison with a Optimal Path addressable identify the current location and shelves of the purpose of the shelf location. In order to enable a more accurate positioning system, adopted two photoelectric switches, to detect the two shelves of the two films.1.2.The functions of the knifeknife The is the role of reserves a certain number of tools, machine tool spindle in hand to achieve the fungibility a disc cutter knife is the type of library, the chain knives, and other means, in the form of the knife and capacity according to the Machine Tool to determine the scope of the process.mon typesThe knife is a tool storage devices, the common knife mainly in the following forms:(1) the turret knifeIncluding the first level turret vertical turret and the first two, see Figure 2.6 a) and b):(2) the disc cutterDisc knife in the library with discoid knife, cutting tool along See how vertical arrangement (including radial and axial from knife from knife), along See how radial array into acute or arranged in the form of the knife. Simple, compact, more applications, but are ring-cutter, low utilization of space. Figure 2.7 a) to c). If the knife storage capacity must be increased to increase the diameter of the knife, then the moment of inertia also increased correspondingly, the election campaign long knife. Tool number not more than 32 general. Cutter was multi-loop order of the space utilization knife, but inevitably given the knife from complex institutions, applicable to the restricted space Machine Tool storage capacity and more occasions. Two-disc structure is two smaller capacity knife on both sides of the sub-spindle place, more compact layout, the number of certificates corresponding increase knife, apply to small and medium-sized processing center.(3) the chain knifeIncluding single-and multi-ring chain ring chain, chain link can take ma ny forms change, see Figure 2.8 a) to c), the basic structureFeatures: knife apply to thelarger capacity of theoccasion, the space of thesmall number of generallyapplicable to the tool in the30-120. Only increase thelength of the chain tool willincrease the number shouldnot be increasedcircumferential speed of itsmoment of inertia of theknife does not increase thedisc as large.(4) linear combination knife and the knife libraryThe linear knife simple structure in Figure 2.9, tool single order, the capacity of small knife, used for CNC lathe and drill press on. Because the location of fixed knife, ATC completed action by the spindle without manipulator. The cutter knife is generally the turret combination turret with a combination of the disc cutter knife and the chain combination. Every single knife the knife certificates of smaller, faster tool change. There are also some intensive drum wheel, and the lattice-type magazine for the knife, the knife-intensive though. Small footprint, but because of structural constraints, basically not used for single processing center, the concentration used for FMS for the knife system.1.4 Tool storage capacityTool storage capacity of the first to consider the needs of processing, from the use of point of view, generally 10 to 40 knives, knife will be the utilization of the high, and the structure is compact.1.5 Tool options(1) choose to order processing tool according to the order, followed Add to the knife every knife in the Block. Each tool change, the order of rotation of a cutter knife on location, and remove the need knives, has been used by the cutter knife can be returned to the original Block, can also order Add Block, a knife. However, as the knife in the tool in different processes can not be repeated use of the knife must increase the capacity and lower utilization rate.(2) most of the arbitrary choice of the current system of using arbitrary NC election knives, divided into Daotao coding, coding and memory-cutter, three. Daotao coding tool code or knives or Daotao need to install the code used to identify, in accordance with the general principle of binary coding coding. Tool knife election coding method uses a special knife handle structure, and each of the coding tool. Each of the tool has its own code, thereby cutting tool can be in different processes repeatedly used, not to replace the tool back at the original knife, the knife capacity can be reduced accordingly. Memory-election this paper knife, in this way can knives and knife in the position corresponding to the Daotao memory of the PLC in the NC system, no matter which tool on the Inner knife, tool information is always there in mind, PLC . On the knife with position detection devices, will be the location of each Daotao. This tool can be removed and sent back to arbitrary. On the knife is also a mechanical origin, every election, the nearest knife selection.1.6.Control of the knife(1) the knife as a system to control the positioning axis. In the ladder diagram in accordance with the instructions for computing T code comparison of the output angle and speed of instructions to the knife the knife servo drive servo motor. Tool storage capacity, rotation speed, and / deceleration time, and other system parameters can be set in such a manner free from any outside influence positioning accurate and reliable but the cost is higher.(2) knife from the hydraulic motor drives, fast / slow the points, with proximity switches count and positioning. In comparison ladder diagram of the current storage system knife (knife spindle) and goals knife (pre-knife) and computing, then output rotation instructions, judging by the shortest path rotation in place. This approach requires sufficient hydraulic power and electromagnetic valve knife the rotational speed can be adjusted through the throttle. But over time may be oily hydraulic, oil temperature and environmental factors impact the change in velocity and accuracy. Not generally used in large and medium-sized machine tool change frequently.(3) the knife from AC asynchronous motor driven cam mechanism (Markov institutions), with proximity switches count, which means stable operation, and generally accurate and reliable positioning cam used in conjunction with a mechanical hand, ATC fast-positioning.2. ATC, the main types, characteristics, and the scope of application2.1 Auto Rotary ToolRotary Tool automatically on the useof CNC machine tool is a simpleinstallation of automatic tool change, theQuartet and 47.60 Turret Tool variousforms, such as rotary turret were installedon four, six or more of the Tool , NCinstructions by ATC. Rotary Tool has twovertical and horizontal, relatively simplestructure, applicable to economic CNClathe.Rotary Tool in the structure must havegood strength and stiffness, resistance tobear rough Cutting Tool in the cuttingforce and reduce the role of deformationand improve processing accuracy.Rotating Tool to choose reliablepositioning programme structure andreasonable position, in order to ensure thateach rotary turret to a higher position afterrepeated positioning accuracy (typically0.001 to 0.005mm). Figure 2.1 shows thespiral movements of the Quartet Turret.Auto Rotary Tool in the simplest ofATC, is 180 º rotary ATC devices, asshown in Figure 2.2 ATC instructionsreceived, the machine control system put ATC spindle control to the designated location at the same time, the tool movement to the appropriate location, ATC, with the rotary axis and at the same time, the knives matching tool; drawbars from Spindle Cutting Tools rip, ATC, will be the tool from their position removed; ATC, 180 º rotary tool spindle and the tool and tool away; ATC, the Rotary At the same time, the tool refocusing its position to accept Spindle removed from the cutting tool; Next, ATC, will be replaced with the cutter knives were unloaded into the spindle and tool: Finally, back to the original ATC, "standby" position. At this point, ATC completed procedures to continue to run. This ATC, the main advantage of simple structure, the less movement, fast tool change. The main disadvantage is that knives must be kept in parallel with the axis of the plane, and after the home side compared to the tool, chip and liquid-cutting knife into the folder, it is necessary to the tool plus protection. Cone knife folder on the chip will cause ATC error, or even damage knife folders, and the possibility of spindle. Some processing centre at the transfer, and the tool side. When the ATC command is called, the transfer-cutter knives will be removed, the machine go forward, and positioning with the ATC, in line with the position. 180 º "Rotary ATC devices can be used horizontal machine, can also be used for vertical machining centers.2. 2 ATC head-turret installedWith rotating CNC machine tool often used such ATC devices, with a few turret head spindle, each with a spindle on both knives, the first tower interim process can be automatic tool change-realization. The advantage is simple structure, tool change time is short, only about 2 s. However, due to spatial constraints, the number of spindle can not be too much, usually only apply to processes less, not to high precision machine tools, such as the NC drill, such as CNC milling machine. In recent years there has been a mechanical hand and the turret head with a knife for the automatic tool change ATC devices, as shown in Figure 2.3. It is in fact a turret head ATC, and the knife-ATC device combination. The principle is as follows:5 turret on the first two tool spindle 3 and 4, when using the tool spindle 4 processing tool, the manipulator 2 will be the next step to the need for the tool does not work on the tool spindle 3 until after the completion of this process , the first rotary turret 180 º, ATC completed. ATC most of their time and processing time coincidence, the only real tool change time turret transposition of the first time, this approach mainly used for ATC and NC NC drilling file bed.2. 3.Daidao system for the automatic tool changeFigure 2.4 shows the knife and the whole machine tool CNC machine tools for the appearance of Fig. Figure 2.5 shows the knife and split-type machine to the appearance of CNC machine tool plans.At this point, knife storage capacity, a heavier tool can, and often additional transport unit to complete the knife between the spindle and cutting tool transport.Daidao the knife from the ATC, the election knives, automatic loading and unloading machine tool and tool exchange institutions (manipulator), composed of four parts, used widely.Tool Automatic Tool Change the manipulator system, the whole process more complicated ATC. We must first used in the processing of all installed in the standard tool on the knife handle in the machine outside the pre-size, according to a certain way Add to the knife. ATC, selected first in the knife knife, and then from ATC, from the knife from the knife or spindle, exchange, the new knife into the spindle, the old knife back into the knife.ATC, as the former two knives to accommodate a limited number can not be too many, can not meet the needs of complex parts machining, CNC machine tool Automatic Tool Change Daidao the use of the automatic tool change devices. The knife has more capacity, both installed in the spindle box side or above. As for the automatic tool change Daidao device CNC machine tool spindle box only a spindle, spindle components to high stiffness to meet the machining requirements. The number of establishments in larger knife, which can meet the more complex parts of the machining processes, significantly improving productivity. Daidao system for the automatic tool change applied to drilling centres and CNC machining centers. The comparison drawn Daidao automatic tool change system is the most promising.3.PLC control of the knife random mode of election 3. 1Common methods of automatic election knifeAutomatic control of the knife CNC refers to the system after the implementation of user instructions on the knife library automation process, including the process to find knives and automatic tool change [(63,71]. CNC Machining Center device (CNC) directive issued by the election knife , a knife, the tool required to take the knife position, said the election automatic knife. automatically elected knife There are two ways: random sequence election knives and knife election method.3.1.1 order election knifeTool Selection order is the process tool according to the sequence of the insert knife, the use of knives in order to take place, used knives back at the original knife, can also order Add Block, a knife. In this way, no need Tool identification devices, and drive control is a relatively simple, reliable and can be used directly from the points of the knife machinery to achieve. But the knives in each of the tool in different processes can not be reused, if the tool is installed in accordance with the order of the knife, there will be serious consequences. The need to increase the number of knives and knife the capacity of the tool and reduce the utilization of the knife.3.1.2Random election knifeRandom election under the knife is arbitrary instructions to select the required tools, then there must be tool identification devices. Tool knife in the library do not have the processing in accordance with the order of the workpiece can be arbitrary storage. Each of the tool (or knife blocks) are for a code, automatic tool change, the rotary cutter, every tool have been the "tool identification device" acceptable identification. When CNC tool code and the code in line with directives of the tool selected, the rotary cutter knives will be sent to the ATC position, waiting to grab manipulator. Random knife election is the advantage of the cutter knife in the order has nothing to do with the processing sequence, the same tool can be used repeatedly. Therefore, the relatively small number of knives, knife the corresponding smaller. Random elections knife on the tool must be coded to identify. There are three main coding.1. Tool coding. Adopt special knife handle structure coding, the drawbars on the knife handle back-end packages such as spacing of the coding part of the lock-nut fixed. Coding diameter ring diameter of a size two, respectively, said that binary "1" and "0" to the two rings are different, can be a series of code. For example, there are six small diameter of the ring can be made to distinguish between 63 (26-1 = 63) of the coding tool. All of 0 normally not allowed to use the code, to avoid the cutter knife Block did not confuse the situation.2. Knife Block coding. On the knife Block coding, coding tool, and tool into line with the number of knives in the Block. ATC knife when the rotation, so that each knife seats followed through knowledge knife, knife found blocks, knives stopped the rotation. At this time there is no knife handle encoding part of the knife handle simplified.3. Annex coding methods. This style of coding keys, coded cards, coding and coding-disc, which is the most widely used coding keys. First toknives are attached to a tool of the show wrapped coding keys, and when the cutter knife to the store at knife in, so put the number of keys to remember knife Block Road, will be inserted into key to the coding Block next to the key hole in the seat for the knife to the numbers. ConclusionFocused on in today's manufacturing environment tool storage and management of new models and methods, practical application of good results in systems integration and optimization, and other aspects of operations will be further explored, so that it has a higher theoretical and practical level.译文:机床刀具设计课题研究意义机床原来的刀库控制程序是单独设计的,没有采用刀具管理系统,功能也比较单一,只实现了刀库刀具的找刀、刀库最短路径定位、主轴换刀,而且不支持大型刀具。

机械类数控车床外文翻译外文文献英文文献数控

机械类数控车床外文翻译外文文献英文文献数控

机械类数控车床外文翻译外文文献英文文献数控原文来源:Zhao Chang-ming Liu Wang-ju (CNC Machining Process and equipment, 2002,China)一、摘要Equip the engineering level, level of determining the whole national economy of the modernized degree and modernized degree of industry, numerical control technology is it develop new developing new high-tech industry and most advanced industry to equip (such as information technology and his industry, biotechnology and his industry, aviation, spaceflight, etc. national defense industry) last technology and getting more basic most equipment. Numerical control technology is the technology controlled to mechanical movement and working course with digital information, integrated products of electromechanics that the numerical control equipment is the new technology represented by numerical control technology forms to the manufacture industry of the tradition and infiltration of the new developing manufacturing industry,Keywords:Numerical ControlTechnology, E quipment,industry二、译文数控技术和装备进展趋势及计策装备工业的技术水平和现代化程度决定着整个国民经济的水平和现代化程度,数控技术及装备是进展新兴高新技术产业和尖端工业〔如信息技术及其产业、生物技术及其产业、航空、航天等国防工业产业〕的使能技术和最差不多的装备。

分析数控机床改造外文文献翻译、中英文翻译、外文翻译

分析数控机床改造外文文献翻译、中英文翻译、外文翻译

Analysis of transformation of numerical controlmachine toolIn order to survival and development of enterprises, improve the rate of CNC machine tools is necessary. Transformation of the equipment needed for NC machine tools in general, including traditional and recently introduced from abroad, due to a problem can not be put into the machine tool equipment and production lines. First, transform the contents of the NCCNC machine tools and production line transformation of the main contents are: (1) restoration of the original function, machine tools, production lines there is some fault diagnosis and recovery; (2)NC-based, in the general machine tools addend remarkable device or add numerical control system; ( 3) The renovation, to improve accuracy, efficiency and degree of automation, mechanical, electrical parts of the renovation, the mechanical part of there-assembly process, to restore the original precision; can not meet the production requirements of its CNC system be updated with the latest CNC; (4) technology updates or technical innovation, in order to improve performance or grade, or for the use of new technology, new technology, based on the original large-scale technology updates or technical innovation.Second, the development trend of CNC systeml. To open, the sixth generation of PC-based directionThe openness of the PC-based, low-cost, high reliability, rich in natural resources such as hardware and software features, and more CNC system manufacturer will be to go down this path. At least with PC, as its front-end machines, to deal with man-machine interface, programming, networking and communications issues, the original system to take over some tasks PC CNC machines has the friendly interface, will reach all of the CNC system. The remote communication, remote diagnostics and maintenance of applications will be more common.2. To the development of high-speed and high precision.3. To the intelligent direction(1) The application of adaptive control technology. Numerical control system can detect the process of important information and automatically adjust system parameters, improving the system operation status.2) the introduction of expert systems to guide processing. Will be skilled workers and expertise, processing and general laws and special laws into the system to process parameter database support, establish an artificial intelligence expert system.(3) the introduction of fault diagnosis expert system(4) intelligent digital servo drives. Can automatically identify the load and automatically adjust the parameters of the drive system to get the best state of operation.Third, the choice of numerical control system1. Open-loop systemThe system's servo-driven device is a stepper motor, power stepper motors, electro-hydraulic pulse motors. This system does not require position and velocity feedback, displacement accuracy depends mainly on the angular displacement precision stepper motor and gear drive components such as precision screw, so displacement of low accuracy. But the system is simple, debugging easy maintenance, reliable, low cost, easily converted successfully.2. Closed-loop systemThe system consists of grating, sensor position detection device synchronization, etc. The actual measured position signal fed back to the computer, compared with a given value, the difference between the two amplification and transformation, driving the implementing agencies in order to eliminate bias. The system complexity, high cost and strict temperature requirements on the environment. But thesystem of high precision, speed and big power. According to technological requirements and decide whether to adopt.3. Semi-closed-loop systemSemi-closed-loop system detects components installed in the middle of transmission parts, the indirect measurement of the location of the implementation of parts. It can only compensate for part of the components within the system loop error, and therefore its more accurate than the accuracy of closed-loop system is low, but its structure and debugging as compared with the closed-loop system is simple.Current production numerical control system are more companies and manufacturers, foreign companies such as Siemens of Germany, Japan, Fanuc, Inc.; domestic Everest companies such as China, the Beijing Aerospace CNC System Corporation, Huazhong CNC CNC high-grade corporate and Shenyang National Engineering Research Center. Select CNC systems are mainly based on numerical control after transformation to be achieved in a variety of precision machine tools, drive motor power and the user's requirements to determine. Fourth, the main steps CNC transformation1. Determination of rehabilitation programs(1) Mechanical and Electrical Repair transformation combined.Generally speaking, in need of transformation of electrical machines, are in need of mechanical repair. To determine repair requirements, scope and content; have to ascertain the electrical modification of the mechanical structure in need of transformation requirements and content; but also determine the transformation of electrical and mechanical repair, reconstruction staggered between the time requirements. Mechanical properties of intact are electrical transformation success.(2) the easier issues first, after the first partial overall. Determine the transformation step, the whole electrical part of the transformation should be divided into several sub-systems, the basic shape of various systems to be connected after the completion of the whole system work. In each subsystem, we should do first the less technical, workload the larger work, and then do a technical high, requiring fine work, can focus people's attention to key areas.(3) selection system under conditions of use. For the transformation of the object to determine its environment and conditions, which the selection of electrical system protection, anti-jamming, self-cooling and air filtering performance can provide the correct basis. Electrical system options must also be considered mature products, their performance should be reasonable and practical, there are spare parts to provide maintenance support, features a number of years to meetthe current and future development requirements.(4) The implementation and responsibilities of personnel involved in reconstruction.(5) The transformation of the determination of the scope and cycle.2. Transformation of the technical preparation(1) mechanical parts ready. In line with the transformation of mechanical electrical repairs should be completed in advance. The same time, be demolished and replaced and processing should be part of such advance planning is necessary to properly interface with the entire transformation.(2) The electrical information on the new system to digest.(3) The conversion of the old system interface design. According to the scope of each of the different equipment modification required to pre-designed interface, part of the conversion, if the entire transformation should be designed to convert mechanical and electrical interfaces, operation panel control and configuration, the Internet part of the contact, parameter measurement, the maintenance and so on. Require the operation and maintenance easy and reasonable, alignments, fluent, primary and secondary connection point less electrical interference with the strength of the smallest, with an appropriate margin and so on. Local transformation, but also need to consider the performance of the system match theold and new, the voltage polarity and size of change, the installation location, digital-analog conversion, etc., if necessary, need to create their own interfaces.(4) operation and programming staff technical training. ①training should cover the new control panel configuration, function and meaning of the instructions; ②the scope of the new system features, use, and the difference between the old system; ③maintenance requirements; ④programming standards and automated programming and more. Focused understood, grasp operating instructions and programming instructions.(5) Debugging steps and acceptance criteria for the determination. Debugging should be done by the project leader carried out with the others. Debugging step can be from simple to complex, from small to large, from outside to inside, you can also after the first local situation, the whole system after the first subsystem. The development of acceptance criteria must be realistic, too high or too low a standard will have a negative impact on the transformation.3. The implementation of reform(1) The overall maintenance of the machine. The long-term use of the original machine, you need to conduct a comprehensive maintenance. Secondly, the response to machine tools to make achange before the geometric accuracy, dimensional accuracy of measurement, and for the record. In this way pairs of reference to guide the transformation of the role, but also in the transformation of the end for comparison analysis.(2) to retain the electrical adjustment of some of the best. If the electrical system as part of the transformation, in turn, should retain the parts of the maintenance and optimization adjustments, such as high power part of the spare parts replacement, electrical maintenance, drying transformer insulation, pollution, cleaning, ventilation and cooling equipment cleaning, servo Drive optimization adjustments, update aging wires and cables, connectors and other fastening. Only the electrical part of the reservation and do excellent optimization adjustment, in order to ensure that transformed the machine tool have lower failure rates.(3) The original systems were dismantled. The removal of the original system must be controlled carefully to the original drawings in time to make mark in the drawings to prevent the omission or been demolished. In the process of demolition will find some of the new system design in the gaps, it is timely to add and correction. Removed the system should be properly safeguarded in case of unsuccessful reconstruction resume use. There is a definite value, and can be used for spare parts.(4) reasonable arrangements for the location and wiring the new system. Connection must be a clear division of labor, there is one person review the inspection to ensure that the connection process specifications, diameter suitable, correct, reliable and beautiful. (5) debugging. Debug must be pre-established procedures and requirements. Debugging the first to test the safety protection system sensitivity, personal and equipment to prevent accidents. Debugging the site must be clean; the moving coordinate extension units at the center of the whole trip; be able to load test, the first no-load after load; can simulate the experiment, the first real action after simulated; be manual, first manually and automatically.4. Acceptance and post-work(1) The mechanical properties of machine tool acceptance. Machine tool should meet the requirements of the mechanical properties, geometric accuracy should be within the limits prescribed.(2) The electrical control functions and control accuracy and acceptance. The various functions of electrical control actions must meet the normal, sensitive and reliable. Control precision application system itself functions (such as step size, etc.) and standard measuring apparatus (such as laser interferometer, coordinate measuring machine, etc.) control checks, to reach within a range. Should also be modified before the machine with the functions andaccuracy to make comparison, access to quantifiable indicators of difference.(3) The test piece cutting and acceptance. Can refer to the relevant domestic and international standards for CNC cutting specimens, in a qualified operator, the programmer with the trial under the cut. Specimen cutting machine tools can be acceptance of stiffness, cutting force, noise, motion trajectory, related actions, are generally not suitable for specimen use of a product part.(4), drawings, information and acceptance. Machine transformation finished, should be promptly drawings, data, transform the file summary, collate, transfer into the file. This is the future and stable operation of the equipment is very important.(5) Summary and improve.5, numerical examples of reconstruction1. Milling machine with the Siemens 810M transformation X53In 1998, the company invested 200,000 yuan, with Germany's Siemens 810M CNC system, 611A AC servo drive system on the company's X53 model of a milling machine to X, Y, Z three-axis numerical control transformation. Retained the original spindle system and cooling system. -Axis transformation of a ball screw used in the machinery and gear transmission mechanism. Thetransformation of work includes mechanical design, electrical design, PLC program preparation and debugging, machine tool repair, machine installation and debugging. After transformation, milling, processing and effective travel X, Y, Z axis respectively, 880mm, 270mm, 280mm; maximum speed of X, Y, Z axis respectively, 5 000mm/min, 1 500mm/min, 800mm/min; point moving speed of X, Y, Z axis respectively 3 000mm/min, 1 000mm/min, 500 mm / min; machining accuracy of ± 0.001 mm. Machine tools, coordinate linkage to be completed by a variety of complex curve or surface processing.2. GSK980T and stepper drive system with the transformation ofC6140 latheIn 1999, the company invested 8 million yuan, with Guangzhou CNC Equipment Factory production GSK980T numerical control system, DY3 hybrid stepper drive unit on the company's a longerC6140 lathe X, Z 2-axis transform. Retained the original spindle system and cooling system. Transformation of two-axis ball screw in the machinery used, and synchronous transmission. The transformation of work includes mechanical design, electrical design, machine overhaul and machine installation and debugging. Lathe After the transformation, processing and effective stroke X, Z axis respectively, 390mm, 1400mm; maximum speed X, Z axisrespectively, 1 200mm/min, 3 000mm/min; jog speed 400mm/min; point moving fast X, Z-axis respectively, 1 200mm/min, 3000mm/min; machine smallest mobile unit 0.001mm.6, numerical transformation of the issues and recommendations1. Transformation problems in NCCNC machine tools through several transformation and found work, there are also many problems, mainly reflected in: (a) The departments, developers uncertain functions, organizational chaos, a serious impact on progress in the transformation; (2) to develop the work process and plans are mostly developed rule of thumb, less reasonable; (3) the training of relevant personnel is not in place, resulting in machine tool technology officers will not be modified after programming, the operator of the machine operator unskilled and so on.2. Transformation of the proposed NC(1) is responsible for transformation of the staff responsibilities of clear penalties and rewards, fully mobilize the enthusiasm of the staff; train a batch of high-quality applications and maintenance personnel, training for selected officers to go out and learn the advanced technologies;(2) To focus on users, maintenance of CNC system of technicaltraining, the establishment of numerical control technology at home and abroad resource library. The establishment of technical data files, do the work of spare parts.分析数控机床改造为了我国民营企业的生存与发展,提高数控机床的速度是必要的。

机床——机械类外文文献翻译、中英文翻译

机床——机械类外文文献翻译、中英文翻译

毕业设计(论文)外文资料翻译系部:专业:姓名:学号:外文出处:English For Electromechanical(用外文写)Engineering附件:1.外文资料翻译译文;2.外文原文。

附件1:外文资料翻译译文机床机床是用于切削金属的机器。

工业上使用的机床要数车床、钻床和铣床最为重要。

其它类型的金属切削机床在金属切削加工方面不及这三种机床应用广泛。

车床通常被称为所有类型机床的始祖。

为了进行车削,当工件旋转经过刀具时,车床用一把单刃刀具切除金属。

用车削可以加工各种圆柱型的工件,如:轴、齿轮坯、皮带轮和丝杠轴。

镗削加工可以用来扩大和精加工定位精度很高的孔。

钻削是由旋转的钻头完成的。

大多数金属的钻削由麻花钻来完成。

用来进行钻削加工的机床称为钻床。

铰孔和攻螺纹也归类为钻削过程。

铰孔是从已经钻好的孔上再切除少量的金属。

攻螺纹是在内孔上加工出螺纹,以使螺钉或螺栓旋进孔内。

铣削由旋转的、多切削刃的铣刀来完成。

铣刀有多种类型和尺寸。

有些铣刀只有两个切削刃,而有些则有多达三十或更多的切削刃。

铣刀根据使用的刀具不同能加工平面、斜面、沟槽、齿轮轮齿和其它外形轮廓。

牛头刨床和龙门刨床用单刃刀具来加工平面。

用牛头刨床进行加工时,刀具在机床上往复运动,而工件朝向刀具自动进给。

在用龙门刨床进行加工时,工件安装在工作台上,工作台往复经过刀具而切除金属。

工作台每完成一个行程刀具自动向工件进给一个小的进给量。

磨削利用磨粒来完成切削工作。

根据加工要求,磨削可分为精密磨削和非精密磨削。

精密磨削用于公差小和非常光洁的表面,非精密磨削用于在精度要求不高的地方切除多余的金属。

车床车床是用来从圆形工件表面切除金属的机床,工件安装在车床的两个顶尖之间,并绕顶尖轴线旋转。

车削工件时,车刀沿着工件的旋转轴线平行移动或与工件的旋转轴线成一斜角移动,将工件表面的金属切除。

车刀的这种位移称为进给。

车刀装夹在刀架上,刀架则固定在溜板上。

溜板是使刀具沿所需方向进行进给的机构。

机械类车床外文翻译

机械类车床外文翻译

毕业设计(论文)——外文翻译(原文)Lathe来源:/wiki/LatheA lathe is a machine tool which spins a block of material to perform various operations such as cutting, sanding, knurling, drilling, or deformation with tools that are applied to the workpiece to create an object which has symmetry about an axis of rotation.Lathes are used in woodturning, metalworking, and glassworking. Lathes can be used to shape pottery, the best-known design being the potter's wheel. Most suitably equipped metalworking lathes can also be used to produce most solids of revolution, plane surfaces and screw threads or helices. Ornamental lathes can produce three-dimensional solids of incredible complexity. The material is held in place by either one or two centers, at least one of which can be moved horizontally to accommodate varying material lengths. Examples of objects that can be produced on a lathe include cue sticks, table legs, bowls, baseball bats, crankshafts and camshafts.HistoryThe lathe is an ancient tool, dating at least to the Egyptians ,and known and used in Greece, the Roman and Byzantine Empires.The origin of turning dates to around 1300BC when the Egyptians first developed a two-person lathe. One person would turn the wood workpiece with a rope while the other used a sharp tool to cut shapes in the wood. The Romans improved the Egyptian design with the addition of a turning bow. Early bow lathes were also developed and used in Germany, France and Britain. In the Middle Ages a pedal replaced hand-operated turning, freeing both the craftsman's hands to hold the woodturning tools. The pedal was usually connected to a pole, often a straight-grained sapling. The system today is called the "spring pole" lathe. Spring pole lathes were in common use into the early 20th Century. A two-person lathe, called a "great lathe", allowed a piece to turn continuously (like today's power lathes). A master would cut the wood while an apprentice turned the crank。

【机械类文献翻译】车床

【机械类文献翻译】车床

附录LathesLathes are machine tools designed primarily to do turning, facing and boring, Very little turning is done on other types of machine tools, and none can do it with equal facility. Because lathes also can do drilling and reaming, their versatility permits several operations to be done with a single setup of the work piece. Consequently, more lathes of various types are used in manufacturing than any other machine tool.The essential components of a lathe are the bed, headstock assembly, tailstock assembly, and the leads crew and feed rod.The bed is the backbone of a lathe. It usually is made of well normalized or aged gray or nodular cast iron and provides s heavy, rigid frame on which all the other basic components are mounted. Two sets of parallel, longitudinal ways, inner and outer, are contained on the bed, usually on the upper side. Some makers use an inverted V-shape for all four ways, whereas others utilize one inverted V and one flat way in one or both sets, They are precision-machined to assure accuracy of alignment. On most modern lathes the way are surface-hardened to resist wear and abrasion, but precaution should be taken in operating a lathe to assure that the ways are not damaged. Any inaccuracy in them usually means that the accuracy of the entire lathe is destroyed.The headstock is mounted in a foxed position on the inner ways, usually at the left end of the bed. It provides a powered means of rotating the word at various speeds . Essentially, it consists of a hollow spindle, mounted in accurate bearings, and a set of transmission gears-similar to a truck transmission—through which the spindle can be rotated at a number of speeds. Most lathes provide from 8 to 18 speeds, usually in a geometric ratio, and on modern lathes all the speeds can be obtained merely by moving from two to four levers. An increasing trend is to provide a continuously variable speed range through electrical or mechanical drives.Because the accuracy of a lathe is greatly dependent on the spindle, it is of heavy construction and mounted in heavy bearings, usually preloaded tapered roller or balltypes. The spindle has a hole extending through its length, through which long bar stock can be fed. The size of maximum size of bar stock that can be machined when the material must be fed through spindle.The tailsticd assembly consists, essentially, of three parts. A lower casting fits on the inner ways of the bed and can slide longitudinally thereon, with a means for clamping the entire assembly in any desired location, An upper casting fits on the lower one and can be moved transversely upon it, on some type of keyed ways, to permit aligning the assembly is the tailstock quill. This is a hollow steel cylinder, usually about 51 to 76mm(2to 3 inches) in diameter, that can be moved several inches longitudinally in and out of the upper casting by means of a hand wheel and screw.The size of a lathe is designated by two dimensions. The first is known as the swing. This is the maximum diameter of work that can be rotated on a lathe. It is approximately twice the distance between the line connecting the lathe centers and the nearest point on the ways, The second size dimension is the maximum distance between centers. The swing thus indicates the maximum work piece diameter that can be turned in the lathe, while the distance between centers indicates the maximum length of work piece that can be mounted between centers.Engine lathes are the type most frequently used in manufacturing. They are heavy-duty machine tools with all the components described previously and have power drive for all tool movements except on the compound rest. They commonly range in size from 305 to 610 mm(12 to 24 inches)swing and from 610 to 1219mm(24 to 48 inches) center distances, but swings up to 1270 mm(50 inches) and center distances up to 3658mm(12 feet) are not uncommon. Most have chip pans and a built-in coolant circulating system. Smaller engine lathes-with swings usually not over 330 mm (13 inches ) –also are available in bench type, designed for the bed to be mounted on a bench on a bench or cabinet.Although engine lathes are versatile and very useful, because of the time required for changing and setting tools and for making measurements on the work piece, thy are not suitable for quantity production. Often the actual chip-production tine is less than 30% of the total cycle time. In addition, a skilled machinist is required for all the operations, and such persons are costly and often in short supply. However, much of the operator’s time is consum ed by simple, repetitious adjustments and inwatching chips being made. Consequently, to reduce or eliminate the amount of skilled labor that is required, turret lathes, screw machines, and other types of semiautomatic and automatic lathes have been highly developed and are widely used in manufacturing.2 Numerical ControlOne of the most fundamental concepts in the area of advanced manufacturing technologies is numerical control (NC). Prior to the advent of NC, all machine tools ere manually operated and controlled. Among the many limitations associated with manual control machine tools, perhaps none is more prominent than the limitation of operator skills. With manual control, the quality of the product is directly related to and limited to the skills of the operator. Numerical control represents the first major step away from human control of machine tools.Numerical control means the control of machine tools and other manufacturing systems through the use of prerecorded, written symbolic instructions. Rather than operating a machine tool, an NC technician writes a program that issues operational instructions to the machine tool. For a machine tool to be numerically controlled, it must be interfaced with a device for accepting and decoding the programmed instructions, known as a reader.Numerical control was developed to overcome the limitation of human operators, and it has done so. Numerical control machines are more accurate than manually operated machines, they can produce parts more uniformly, they are faster, and the long-run tooling costs are lower. The development of NC led to the development of several other innovations in manufacturing technology:Electrical discharge machining,Laser cutting,Electron beam welding.Numerical control has also made machine tools more versatile than their manually operated predecessors. An NC machine tool can automatically produce a wide of parts, each involving an assortment of widely varied and complex machining processes. Numerical control has allowed manufacturers to undertake the production of products that would not have been feasible from an economic perspective using manually controlled machine tolls and processes.Like so many advanced technologies, NC was born in the laboratories of the Massachusetts Institute of Technology. The concept of NC was developed in the early 1950s with funding provided by the U.S. Air Force. In its earliest stages, NC machines were able to made straight cuts efficiently and effectively.However, curved paths were a problem because the machine tool had to be programmed to undertake a series of horizontal and vertical steps to produce a curve. The shorter the straight lines making up the steps, the smoother is the curve, Each line segment in the steps had to be calculated.This problem led to the development in 1959 of the Automatically Programmed Tools (APT) language. This is a special programming language for NC that uses statements similar to English language to define the part geometry, describe the cutting tool configuration, and specify the necessary motions. The development of the APT language was a major step forward in the fur ther development from those used today. The machines had hardwired logic circuits. The instructional programs were written on punched paper, which was later to be replaced by magnetic plastic tape. A tape reader was used to interpret the instructions written on the tape for the machine. Together, all of this represented a giant step forward in the control of machine tools. However, there were a number of problems with NC at this point in its development.A major problem was the fragility of the punched paper tape medium. It was common for the paper tape containing the programmed instructions to break or tear during a machining process. This problem was exacerbated by the fact that each successive time a part was produced on a machine tool, the paper tape carrying the programmed instructions had to be rerun through the reader. If it was necessary to produce 100 copies of a given part, it was also necessary to run the paper tape through the reader 100 separate tines. Fragile paper tapes simply could not withstand the rigors of a shop floor environment and this kind of repeated use.This led to the development of a special magnetic plastic tape. Whereas the paper carried the programmed instructions as a series of holes punched in the tape, the plastic tape carried the instructions as a series of magnetic dots. The plastic tape was much stronger than the paper tape, which solved the problem of frequent tearing and breakage. However, it still left two other problems.The most important of these was that it was difficult or impossible to change the instructions entered on the tape. To made even the most minor adjustments in a program of instructions, it was necessary to interrupt machining operations and make a new tape. It was also still necessary to run the tape through the reader as many times as there were parts to be produced. Fortunately, computer technology became a reality and soon solved the problems of NC associated with punched paper and plastic tape.The development of a concept known as direct numerical control (DNC) solved the paper and plastic tape problems associated with numerical control by simply eliminating tape as the medium for carrying the programmed instructions. In direct numerical control, machine tools are tied, via a data transmission link, to a host computer. Programs for operating the machine tools are stored in the host computer and fed to the machine tool an needed via the data transmission linkage. Direct numerical control represented a major step forward over punched tape and plastic tape. However, it is subject to the same limitations as all technologies that depend on a host computer. When the host computer goes down, the machine tools also experience downtime. This problem led to the development of computer numerical control.3 TurningThe engine lathe, one of the oldest metal removal machines, has a number of useful and highly desirable attributes. Today these lathes are used primarily in small shops where smaller quantities rather than large production runs are encountered.The engine lathe has been replaced in today’s production shops by a wide variety of automatic lathes such as automatic of single-point tooling for maximum metal removal, and the use of form tools for finish on a par with the fastest processing equipment on the scene today.Tolerances for the engine lathe depend primarily on the skill of the operator. The design engineer must be careful in using tolerances of an experimental part that has been produced on the engine lathe by a skilled operator. In redesigning an experimental part for production, economical tolerances should be used.Turret Lathes Production machining equipment must be evaluated now, more than ever before, this criterion for establishing the production qualification of a specific method, the turret lathe merits a high rating.In designing for low quantities such as 100 or 200 parts, it is most economical to use the turret lathe. In achieving the optimum tolerances possible on the turrets lathe, the designer should strive for a minimum of operations.Automatic Screw Machines Generally, automatic screw machines fall into several categories; single-spindle automatics, multiple-spindle automatics and automatic chucking machines. Originally designed for rapid, automatic production of screws and similar threaded parts, the automatic screw machine has long since exceeded the confines of this narrow field, and today plays a vital role in the mass production of a variety of precision parts. Quantities play an important part in the economy of the parts machined on the automatic screw machine. Quantities less than on the automatic screw machine. The cost of the parts machined can be reduced if the minimum economical lot size is calculated and the proper machine is selected for these quantities.Automatic Tracer Lathes Since surface roughness depends greatly on material turned, tooling , and feeds and speeds employed, minimum tolerances that can be held on automatic tracer lathes are not necessarily the most economical tolerances.In some cases, tolerances of 0.05mm are held in continuous production using but one cut . groove width can be held to 0.125mm on some parts. Bores and single-point finishes can be held to 0.0125mm. On high-production runs where maximum output is desirable, a minimum tolerance of 0.125mm is economical on both diameter and length of turn.1.车床车床主要是为了进行车外圆、车端面和镗孔等项工作而设计的机床。

车床机床改造外文文献翻译、中英文翻译、外文翻译

车床机床改造外文文献翻译、中英文翻译、外文翻译

本科毕业论文中英文翻译学生姓名:所在院系:机电学院所学专业:机械设计制造及其自动化车床车床主要是为了进行车外圆、车端面和镗孔等项工作而设计的机床。

车削很少在其他种类的机床上进行,而且任何一种其他机床都不想车床那样方便地进行车削加工。

由于车床还可以用来钻孔和铰孔,车床的多功能性可以使工件在一次装夹中进行几种加工。

因此,在生产中使用的各种车床比任何种类的机床都多。

普通车床:普通车床作为最早的金属切削机床中的一种,目前仍然有许多有用的和人们所需要的特性。

现在,这些机床主要用在规模较小的工厂中,进行小批量的生产,而不是进行大批量的生产。

普通车床的加工偏差主要取决于操作者的技术熟练程度。

设计工程师应该认真的确定由熟练工人在普通车床上加工的试验零件的公差。

在把试验零件重新设计为生产零件时,应该选用经济的公差。

转塔车床:对生产加工设备来说,目前比过去更着重评价是否具有精确的和快速的重复加工能力。

应用这个标准来评价具体的加工方法,转塔车床可以获得较高的质量评定。

在为小批量的零件(100—200件)设计加工方法时,采用转塔车床是经济的。

为了在转塔车床上获得极可能小的公差值,设计人员应该尽量将加工工序的数目减至最少。

自动螺丝车床:自动螺丝车床通常被分为以下几种类型:单轴自动、多轴自动和自动夹紧车床。

自动螺丝车床最初是用来对螺钉和类似的带有螺纹的零件进行自动化和快速加工的。

但是。

这种车床的用途早就超过了这个狭窄的范围。

现在,它在许多类型的精密零件的大批量生产中起着重要的作用。

车床的基本部件有:床身、主轴箱部件、尾架部件、溜板部件丝杠和光杠。

床身是车床的基础件。

它通常是由于经过充分正火或时效处理的灰铸铁或者球墨铸铁之城。

它是一个兼顾的刚性框架,所有其他基本部件都安装在车床身上。

通常在床身上有内外讲足平行的导轨。

有些制造厂对全部四条导轨都采用导轨尖顶朝上的三角形导轨(即山形导轨),而有的制造厂则在一组中或者两组中都采用一个三角形导轨和一个矩形导轨。

车床(中英文对照)

车床(中英文对照)

LATHEThe basic machines that are designed primarily to do turning, facing and boring are called lathes. Very little turning is done on other types of machine tools, and none can do it with equal facility. Because lathe can do boring, facing, drilling, and reaming in addition to turning, their versatility permits several operations to be performed with a single setup of the work place. These accounts for the fact that lathes of various types are more widely used in manufacturing than any other machine tool.Lathes in various forms have existed for more than two thousand years. Modem lathes date from about 1797, when Henry Maudsley developed one with a lea crew. It provided controlled, mechanical feed of the tool. This ingenious Englishman also developed a change gear system that could connect the motions of the spindle and lea crew and thus enable threads to be cut.Lathe Construction. The essential components of a lathe are depicted in the block diagram. These are the bed, headstock assembly, tailstock assembly, carriage assembly, quick-change gear box, and the lea crew and feed rod.The bed is the backbone of a lathe. It usually is made of well-normalized or aged gray or nodular cast iron and provides a heavy, rigid frame on which all the other basic components are mounted. Two sets of parallel, longitudinal ways, inner and outer, are contained on the bed, usually on the upper side. Some makers use an inverted V-shape for all four ways, whereas others utilize one inverted V and one flat way in one or both sets. Because several other components are mounted and/or move on the ways they must be made with precision to assure accuracy of alignment. Similarly, proper precaution should be taken in operating a lathe to assure that the ways are not damaged. Any inaccuracy in them usually means that the accuracy of the entire lathe is destroyed. The ways on most modem lathes are surface hardened to offer greater resistance to wear and abrasion.The headstock is mounted in a fixed position on the inner ways at one end of the lathe bed. It provides a powered means of rotating the work at various speeds. It consists, essentially, of a hollow spindle, mounted in accurate bearings? And a set of transmission gears similar to a truck transmission through which the spindlecan be rotated at a number of speeds. Most lathes provide from eight to eighteen speeds, usually in a geometric ratio, and on modem lathes all the speeds can be obtained merely by moving from two to four levers. An increasing trend is to provide a continuously variable speed range through electrical or mechanical drives.Because the accuracy of a lathe is greatly dependent on the spindle, it is of heavy construction and mounted in heavy bearings, usually preloaded tapered roller or ball types, a longitudinal hole extends through the spindle so that long bar stock can be fed through it. The size of this hole is an important size dimension of a lathe because it determinus the maximum size of bar stock that can be machined when the material must be fed through the spinale.The inner end of the spindle protrudes from the gear box and contains a means for mounting various types of chucks, face plates, and dog plates on it. Whereas small lathes often employ a threaded section to which the chucks are screwed, most large lathes utilize either cam-lock or key-drive taper noses. These provide a large-diameter taper that assures the accurate alignment of the chuck, and a mechanism that permits the chuck or face plate to be locked or unlocked in position without the necessity of having to rotate these heavy attachments.Power is supplied to the spindle by means of an electric motor through a V-belt or silent-chain drive. Most modem lathes have motors of from 5 to15 horsepower to provide adequate power for carbide and ceramic tools at their high cutting speeds.The tailstock assembly consists, essentially, of three parts. A lower casting fits on the inner ways of the bed and can slide longitudinally thereon, with a means for clamping the entire assembly in any desired location. An upper casting fits on the lower one and can be moved transversely upon it on some type of keyed ways. This transverse motion pemfits aligning the tailstock and headstock spindles and provides a method of tuming tapers. The third major component of the assembly is the tailstock quill. This is a hollow steel cylinder, usually about 2 to sinches in diameter, that can be moved several inches longitudinally in and out of the upper casting by means of a handwheel and screw. The open end of the quill hole terminates in a morse. Taper in which a lathe center, or various tools such as drills, can be held. A graduated scale, several inches in length, usually is engraved on the outside of the quillto aid in controlling its motion in and out of the upper casting. A locking device permits clamping the quill in any desired position.The carriage assembly provides the means for mounting and moving cutting tools. The carriage is a reianvely fiat H-shaped casting that rests and moves on the outer set of ways on the bed. The transverse bar of the carriage contains ways on which the cross slide is mounted and can be moved by means of a feed screw that is controlled by a small handwheel and a graduated dial. Through the cross slide a means is provided for moving the lathe tool in the direction normal to the axis of rotation of the work.On most lathes the tool post actually is mounted on a compound rest. This consists of a base, which is mounted on the cross slide so that it can be pivoted about a vertical axis, and an .upper casting. The upper casting is mounted on ways on this base .so that it can be moved back and forth and controlled by means of a short lead screw operated by a handwheel and a calibrated dial.Manual and powered motion for the carriage, and powered motion for the cross slide, is provided by mechanisms within the apron,attached to the front of the carriage. Manual movement of the carriage along the bed is effected by turning a handwheel on the front of the apron, which is geared to a pinion on the back side. This pinion engages a rack that is attached beneath the upper front edge of the bed in an inverted position.To impart powered movement to the carriage and cross slide, a rotating feed rod is provided. The feed rod, which contains a keyway throughout most of its length, passes through the two reversing bevel pinions and is keyed to them. Either pinion cam be brought into mesh with a mating bevel gear by means of the reversing lever on the front of the apron and thus provide "forward" or "reverse" power to the carriage. Suitable clutches connect either the rack pinion or the cross-shde screw to provide longitudinal motion of the carriage or transverse motion of cross slide.For cutting threads, a second means of longitudinal drive is provided by a lead screw. Whereas motion of the carriage when driven by the feed-rod mechanism takes place through a friction clutch in which shppage is possible, motion through the lead screw is by a direct, mechanical connection between the apron and the lead screw, s This is achieved by a split nut. By means of a clamping lever on the front of theapron, the split nut can be closed around the lead screw. With the split nut closed, the carriage is moved along the lead screw by direct drive without possibility of slippage.Modern lathes have a quick-change gear box. The input end of this gear box is driven from the lathe spindle by means of suitable gearing. The output end of the gear box is connected to the feed rod and lead screw. Thus, through this gear train, leading from the spindle to the quick-change gear box, thence to the lead screw and feed rod, and then to the carriage, the cutting tool can be made to move a specific distance, either longitudinally or transversely, for each revolution of the spindle.A typical lathe provides, through the feed rod, forty-eight feeds ranging from 0.002 inch to 0.118 inch per revolution of the spindle, and, through tne lead screw, leads for cutting forty-eight different threads from 1.5 to 92 per inch. On some older and some cheaper lathes, one or two gears in the gear train between the spindle and the change gear box must be changed in order to obtain a full range of threads and feeds.车床用与车外圆、端面和镗孔等加工的机床叫车床。

数控机床外文文献翻译、中英文翻译

数控机床外文文献翻译、中英文翻译

数控机床外文文献翻译、中英文翻译原文一CNC machine toolsOutdate, J. and Joe, J. Configuration Synthesis of Machining Centers with Tool,JohnWiley & sons, 2001While the specific intention and application for CNC machines vary from one machine type to another, all forms of CNC have common benefits. Here are but a few of the more important benefits offered by CNC equipment.The first benefit offered by all forms of CNC machine tools is improved automation. The operator intervention related to producing work pieces can be reduced or eliminated. Many CNC machines can run unattended during their entire machining cycle, freeing the operator to do other tasks. This gives the CNC user several side benefits including reduced operator fatigue, fewer mistakes caused by human error, and consistent and predictable machining time for each work piece. Since the machine will be running under program control, the skill level required of the CNC operator (related to basic machining practice) is also reduced as compared to a machinist producing work pieces with conventional machine tools.The second major benefit of CNC technology is consistent and accurate work pieces. T oday's CNC machines boast almost unbelievable accuracy and repeatability specifications. This means that once a program is verified, two, ten, or one thousand identical work pieces can be easily produced with precision and consistency.A third benefit offered by most forms of CNC machine toolsis flexibility. Since these machines are run from programs, running a different workpiece is almost as easy as loading a different program. Once a program has been verified and executed for one production run, it can be easily recalled the next time the workpiece is to be run. This leads to yet another benefit, fast change over. Since these machines are very easy to set up and run, and since programs can be easily loaded, they allow very short setup time. This is imperative with today's just-in-time (JIT) product requirements.Motion control - the heart of CNCThe most basic function of any CNC machine is automatic, precise, and consistent motion control. Rather than applying completely mechanical devices to cause motion as is required on most conventional machine tools, CNC machines allow motion control in a revolutionary manner2. All forms of CNC equipment have two or more directions of motion, called axes. These axes can be precisely and automatically positioned along their lengths of travel. The two most common axis types are linear (driven along a straight path) and rotary (driven along a circular path).Instead of causing motion by turning cranks and handwheels as is required on conventional machine tools, CNC machines allow motions to be commanded through programmed commands. Generally speaking, the motion type (rapid, linear, and circular), the axes to move, the amount of motion and the motion rate (federate) are programmable with almost all CNC machine tools.A CNC command executed within the control tells the drive motor to rotate a precise number of times. The rotation of the drive motor in turn rotates the ball screw.And the ball screw drives the linear axis (slide). A feedbackdevice (linear scale) on the slide allows the control to confirm that the commanded number of rotations has taken place3. Refer to fig.1.fig.1 typical drive system of a CNC machine toolThough a rather crude analogy, the same basic linear motion can be found on a common table vise. As you rotate the vise crank, you rotate a lead screw that, in turn, drives the movable jaw on the vise. By comparison, a linear axis on a CNC machine tool is extremely precise. The number of revolutions of the axis drive motor precisely controls the amount of linear motion along the axis.How axis motion is commanded - understanding coordinate systemsIt would be infeasible for the CNC user to cause axis motion by trying to tell each axis drive motor how many times to rotate in order to command a given linear motion amount4. (This would be like having to figure out how many turns of the handle on a table vise will cause the movable jaw to move exactly one inch!) Instead, all CNC controls allow axis motion to be commanded in a much simpler and more logical way by utilizing some form of coordinate system. The two most popular coordinate systems used with CNC machines are the rectangular coordinate system and the polar coordinate system. By far, the more popular of these two is the rectangular coordinate system.The program zero point establishes the point of reference for motion commands in a CNC program. This allows the programmer to specify movements from a common location. If program zero is chosen wisely, usually coordinates needed forthe program can be taken directly from the print.With this technique, if the programmer wishes the tool to be sent to a position one inch to the right of the program zero point, X1.0 is commanded. If the programmer wishes the tool to move to a position one inch above the program zero point, Y1.0 is commanded. The control will automatically determine how many times to rotate each axis drive motor and ball screw to make the axis reach the commanded destination point . This lets the programmer command axis motion in a very logical manner. Refer to fig.2, 3.fig.2, 3.Understanding absolute versus incremental motionAll discussions to this point assume that the absolute mode of programming is used6. The most common CNC word used to designate the absolute mode is G90. In the absolute mode, the end points for all motions will be specified from the program zero point. For beginners, this is usually the best and easiest method of specifying end points for motion commands. However, there is another way of specifying end points for axis motion.In the incremental mode (commonly specified by G91), endpoints for motions are specified from the tool's current position, not from program zero. With this method of commanding motion, the programmer must always be asking "How far should I move the tool?" While there are times when the incremental mode can be very helpful, generally speaking, this is the more cumbersome and difficult method of specifying motion and beginners should concentrate on using the absolute mode.Be careful when making motion commands. Beginners have the tendency to think incrementally. If working in the absolute mode (as beginners should), the programmer should always be asking "To what position should the tool be moved?" This position is relative to program zero, NOT from the tools current position.Aside from making it very easy to determine the current position for any command, another benefit of working in the absolute mode has to do with mistakes made during motion commands. In the absolute mode, if a motion mistake is made in one command of the program, only one movement will be incorrect. On the other hand, if a mistake is made during incremental movements, all motions from the point of the mistake will also be incorrect.Assigning program zeroKeep in mind that the CNC control must be told the location of the program zero point by one means or another. How this is done varies dramatically from one CNC machine and control to another8. One (older) method is to assign program zero in the program. With this method, the programmer tells the control how far it is from the program zero point to the starting position of the machine. This is commonly done with a G92 (or G50) command at least at the beginning of the program and possiblyat the beginning of each tool.Another, newer and better way to assign program zero is through some form of offset. Refer to fig.4. Commonly machining center control manufacturers call offsets used to assign program zero fixture offsets. Turning center manufacturers commonly call offsets used to assign program zero for each tool geometry offsets.fig.4 assign program zero through G54Flexible manufacturing cellsA flexible manufacturing cell (FMC) can be considered as a flexible manufacturing subsystem. The following differences exist between the FMC and the FMS:1.An FMC is not under the direct control of thecentral computer. Instead, instructions from the centralcomputer are passed to the cell controller.2.The cell is limited in the number of part families itcan manufacture.The following elements are normally found in an FMC:Cell controllerProgrammable logic controller (PLC)More than one machine toolA materials handling device (robot or pallet)The FMC executes fixed machining operations with parts flowing sequentially between operations.High speed machiningThe term High Speed Machining (HSM) commonly refers to end milling at high rotational speeds and high surface feeds. For instance, the routing of pockets in aluminum airframe sections with a very high material removal rate1. Refer to fig.5 for the cutting data designations and for mulas. Over the past 60 years, HSM has been applied to a wide range of metallic and non-metallic workpiece materials, including the production of components with specific surface topography requirements and machining of materials with hardness of 50 HRC and above. With most steel components hardened to approximately 32-42 HRC, machining options currently include:Fig.5 cutting datarough machining and semi-finishing of the material in its soft (annealed) condition heat treatment to achieve the final required hardness = 63 HRC machining of electrodes and Electrical Discharge Machining (EDM) of specific parts of dies and moulds (specifically small radii and deep cavities with limited accessibility for metal cutting tools) finishing and super-finishing of cylindrical/flat/cavity surfaces with appropriate cemented carbide, cermets, solid carbide, mixed ceramic or polycrystalline cubic boron nitride (PCBN)For many components, the production process involves acombination of these options and in the case of dies and moulds it also includes time consuming hand finishing. Consequently, production costs can be high and lead times excessive.It is typical in the die and mould industry to produce one or just a few tools of the same design. The process involves constant changes to the design, and because of these changes there is also a corresponding need for measuring and reverse engineering.The main criteria are the quality level of the die or mould regarding dimensional, geometric and surface accuracy. If the quality level after machining is poor and if it cannot meet the requirements, there will be a varying need of manual finishing work. This work produces satisfactory surface accuracy, but it always has a negative impact on the dimensional and geometric accuracy.One of the main aims for the die and mould industry has been, and still is, to reduce or eliminate the need for manual polishing and thus improve the quality and shorten the production costs and lead times.Main economical and technical factors for the development of HSMSurvivalThe ever increasing competition in the marketplace is continually setting new standards. The demands on time and cost efficiency is getting higher and higher. This has forced the development of new processes and production techniques to take place. HSM provides hope and solutions...MaterialsThe development of new, more difficult to machine materials has underlined the necessity to find new machining solutions.The aerospace industry has its heat resistant and stainless steel alloys. The automotive industry has different bimetal compositions, Compact Graphite Iron and an ever increasing volume of aluminum3. The die and mould industry mainly has to face the problem of machining high hardened tool steels, from roughing to finishing.QualityThe demand for higher component or product quality is the result of ever increasing competition. HSM, if applied correctly, offers a number of solutions in thisarea. Substitution of manual finishing is one example, which is especially important on dies and moulds or components with a complex 3D geometry.ProcessesThe demands on shorter throughput times via fewer setups and simplified flows (logistics) can in most cases, be solved by HSM. A typical target within the die and mould industry is to completely machine fully hardened small sized tools in one setup. Costly and time consuming EDM processes can also be reduced or eliminated with HSM.Design & developmentOne of the main tools in today's competition is to sell products on the value of novelty. The average product life cycle on cars today is 4 years, computers and accessories 1.5 years, hand phones 3 months... One of the prerequisites of this development of fast design changes and rapid product development time is the HSM technique.Complex productsThere is an increase of multi-functional surfaces on components, such as new design of turbine blades giving newand optimized functions and features. Earlier designs allowed polishing by hand or with robots (manipulators). Turbine blades with new, more sophisticated designs have to be finished via machining and preferably by HSM . There are also more and more examples of thin walled workpiece that have to be machined (medical equipment, electronics, defense products, computer parts).Production equipmentThe strong development of cutting materials, holding tools, machine tools, controls and especially CAD/CAM features and equipment, has opened possibilities that must be met with new production methods and techniques5.Definition of HSMSalomon's theory, "Machining with high cutting speeds..." on which, in 1931, took out a German patent, assumes that "at a certain cutting speed (5-10 times higher than in conventional machining), the chip removal temperature at the cutting edge will start to decrease...".See fig.6.Fig.6 chip removal temperature as a result of the cutting speedGiven the conclusion:" ... seems to give a chance to improve productivity in machining with conventional tools at high cutting speeds..."Modern research, unfortunately, has not been able to verifythis theory totally. There is a relative decrease of the temperature at the cutting edge that starts at certain cutting speeds for different materials.The decrease is small for steel and cast iron. But larger for aluminum and other non-ferrous metals. The definition of HSM must be based on other factors.Given today's technology, "high speed" is generally accepted to mean surface speeds between 1 and 10 kilometers perminute, or roughly 3 300 to 33 000 feet per minute. Speeds above 10 km/min are in the ultra-high speed category, and are largely the realm of experimental metal cutting. Obviously, the spindle rotations required to achieve these surface cutting speeds are directly related to the diameter of the tools being used. One trend which is very evident today is the use of very large cutter diameters for these applications - and this has important implications for tool design.There are many opinions, many myths and many different ways to define HSM. Maintenance and troubleshooting Maintenance for a horizontal MCThe following is a list of required regular maintenance for a Horizontal Machining Center as shown in fig.7. Listed are the frequency of service, capacities, and type of fluids required. These required specifications must be followed in order to keep your machine in good working order and protect your warranty.Fig. 7 horizontal machining centerDailyTop off coolant level every eight hour shift (especially during heavy TSC usage).Check way lube lubrication tank level.Clean chips from way covers and bottom pan.Clean chips from tool changer.Wipe spindle taper with a clean cloth rag and apply light oil.WeeklyCheck for proper operation of auto drain on filter regulator. See fig. 8Fig. 8 way lube and pneumaticsOn machines with the TSC option, clean the chip basket on the coolant tank.Remove the tank cover and remove any sediment inside the tank. Be careful to disconnect the coolant pump from the controller and POWER OFF the control before working on the coolant tank. Do this monthly for machines without the TSC option.Check air gauge/regulator for 85 psi.For machines with the TSC option, place a dab of grease on the V-flange of tools. Do this monthly for machines without the TSC option.Clean exterior surfaces with mild cleaner. DO NOT usesolvents.Check the hydraulic counterbalance pressure according to the machine's specifications.Place a dab of grease on the outside edge of the fingers of the tool changer and run through all tools".MonthlyCheck oil level in gearbox. Add oil until oil begins dripping from over flow tube at bottom of sump tank.Clean pads on bottom of pallets.Clean the locating pads on the A-axis and the load station. This requires removing the pallet.Inspect way covers for proper operation and lubricate with light oil, if necessary.Six monthsReplace coolant and thoroughly clean the coolant tank.Check all hoses and lubrication lines for cracking.AnnuallyReplace the gearbox oil. Drain the oil from the gearbox, and slowly refill it with 2 quarts of Mobil DTE 25 oil.Check oil filter and clean out residue at bottom for the lubrication chart.Replace air filter on control box every 2 years.Mineral cutting oils will damage rubber based components throughout the machine.TroubleshootingThis section is intended for use in determining the solution to a known problem. Solutions given are intended to give the individual servicing the CNC a pattern to follow in, first, determining the problem's source and, second, solving the problem.Use common senseMany problems are easily overcome by correctly evaluating the situation. All machine operations are composed of a program, tools, and tooling. You must look at all three before blaming one as the fault area. If a bored hole is chattering because of an overextended boring bar, don't expect the machine to correct the fault.Don't suspect machine accuracy if the vise bends the part. Don't claim hole miss-positioning if you don't first center-drill the hole.Find the problem firstMany mechanics tear into things before they understand the problem, hoping that it will appear as they go. We know this from the fact that more than half of all warranty returned parts are in good working order. If the spindle doesn't turn, remember that the spindle is connected to the gear box, which is connected to the spindle motor, which is driven by the spindle drive, which is connected to the I/O BOARD, which is driven by the MOCON, which is driven by the processor. The moral here is doing replace the spindle drives if the belt is broken. Find the problem first; don't just replace the easiest part to get to.Don tinker with the machineThere are hundreds of parameters, wires, switches, etc., that you can change in this machine. Don't start randomly changing parts and parameters. Remember, there is a good chance that if you change something, you will incorrectly install it or break something else in the process6. Consider for a moment changing the processor's board. First, you have to download all parameters, remove a dozen connectors, replace the board, reconnect and reload, and if you make one mistake or bend one tiny pin itWON'T WORK. You always need to consider the risk of accidentally damaging the machine anytime you work on it. It is cheap insurance to double-check a suspect part before physically changing it. The less work you do on the machine the better.译文一数控机床虽然各种数控机床的功能和应用各不相同,但它们有着共同的优点。

数控车床主轴部件机械外文文献翻译、中英文翻译、外文翻译

数控车床主轴部件机械外文文献翻译、中英文翻译、外文翻译

数控车床主轴部件机械外文文献翻译、中英文翻译、外文翻译中国地质大学长城学院本科毕业设计外文资料翻译系别:工程技术系专业:机械设计制造及其自动化姓名:王泽民学号: 052116362015年4月30日外文原文翻译数控车床主轴部件车床是主要用于生成旋转表面和平整边缘的机床。

根据它们的使用目的、结构、能同时被安装刀具的数量和自动化的程度,车床—更确切地说是车床类的机床,可以被分成以下几类:(1)普通车床(2)万能车床(3)转塔车床(4)立式车床(5)自动车床(6)特殊车床虽然车床类的机床多种多样,但它们在结构和操作原理上具有共同特性。

这些特性可以通过普通车床这一最常用的代表性类型来最好地说明。

下面是关于图11.1所示普通车床的主要部分的描述。

车床床身:车床床身是包含了在两个垂直支柱上水平横梁的主骨架。

为减振它一般由灰铸铁或球墨铸铁铸造而成。

它上面有能让大拖板轻易纵向滑动的导轨。

车床床身的高度应适当以让技师容易而舒适地工作。

主轴箱:主轴箱固定在车床床身的左侧,它包括轴线平行于导轨的主轴。

主轴通过装在主轴箱内的齿轮箱驱动。

齿轮箱的功能是给主轴提供若干不同的速度(通常是6到18速)。

有些现代车床具有采用摩擦、电力或液压驱动的无级调速主轴箱。

主轴往往是中空的,即纵向有一通孔。

如果采取连续生产,棒料能通过此孔进给。

同时,此孔为锥形表面可以安装普通车床顶尖。

主轴外表面是螺纹可以安装卡盘、花盘或类似的装置。

尾架:尾架总成基本包括三部分,底座、尾架体和套筒轴。

底座是能在车床床身上沿导轨滑动的铸件,它有一定位装置能让整个尾架根据工件长度锁定在任何需要位置。

这通过使用手轮和螺杆来达到,与螺杆啮合的是一固接在套筒轴上的螺母。

套筒轴开口端的孔是锥形的,能安装车床顶尖或诸如麻花钻和镗杆之类的工具。

套筒轴通过定位装置能沿着它的移动路径被锁定在任何点。

大拖板:大拖板的主要功能是安装刀具和产生纵向和/或横向进给。

它实际上是一由车床床身V形导轨引导的、能在车床床身主轴箱和尾架之间滑动的H形滑块。

机械毕业设计英文外文翻译71车床夹具设计分析

机械毕业设计英文外文翻译71车床夹具设计分析

机械毕业设计英文外文翻译71车床夹具设计分析附录ALathe fixture design and analysisMa Feiyue(School of Mechanical Engineering, Hefei, Anhui Hefei 230022,China)Abstract: From the start the main types of lathe fixture, fixture on the flower disc and angle iron clamp lathe was introduced, and on the basis of analysis of a lathe fixture design points.Keywords: lathe fixture; design; pointsLathe for machining parts on the rotating surface, such as the outer cylinder, inner cylinder and so on. Parts in the processing, the fixture can be installed in the lathe with rotary machine with main primary uranium movement. However, in order to expand the use of lathe, the work piece can also be installed in the lathe of the pallet, tool mounted on the spindle.THE MAIN TYPES OF LATHE FIXTUREInstalled on the lathe spindle on the lathe fixtureInstalled in the fixture on the lathe spindle in addition to three-jaw chuck, four jaw chuck, faceplate, front and rear dial with heart-shaped thimble and a combination of general-purpose lathe fixture folder outside (as these fixtures have been standardized and machine tool accessories, can be purchased when needed do not have to re-design), usually need to design special lathe fixture. Common special lathe folder with the following types.Fixture took disc latheThis process is to find the generic is installed on the faceplate is difficult to ensure the accuracy of the workpiece, so the need to design special lathe fixture. The lathe fixture design process, first select the cylindrical workpieceand the end cylinder B, the semi-circular surface finishing (finishing second circularsurface when the car has been good with circular surface) is positioned datum, limit of six degrees of freedom, in line with the principle of base overlap.The work piece fixture to ensure the accuracy of measures:The workpiece fixture to ensure the accuracy of measures:(1) tool by the workpiece machining position relative to the guarantee. (2) symmetry of size 0.02. Rely on sets of holes5.56h Φ22.5Φ0.023023+Φ0.023023+Φ180.02±and positioning theworkpiece with the precision of andlocate the position of dimensional accuracy and process specification requirements to ensure that the same parts of the four circular surface must be processed on the same pins.(3) all fixtures and clip bushing hole axis vertical concrete face A tolerance of .because the A side is the fixture with the lathe when the transition assembly base plate installed.(4) specific folder on the-hole plate with the transition to the benchmarks pin design requires processing each batch of parts to be sold in the transitional disk with a coat made of a tight match, and the local processing of the face plate to reduce the transition fixture on the set of small errors.The angle iron fixtureIf the processing technology for the and, drilling, boring, reaming process scheme. Boring is required in the face A face of finishing B ( range) and the A, B sides and the holeaxis face runout does not exceed . In addition, the processing of -hole, you should also ensure that its axis with the axis of the degree of tolerance for the uranium ; size 5.56h Φ0.0100.00220.5++Φ0.005mm 207H Φ20Φ0.0102.5+Φ0.0110.00510++Φ12Φ10Φ0.02mm2.5Φ0.0110.00510++Φ0.01mm Φ10Φand the location of ; and and of the axis of the axis of displacement tolerance not more than .Based on the above analysis on the part of process size, choose the -hole on the workpiece surface and M, N two planes to locate the benchmark.Installed on the lathe pallet fixtureLimited equipment in the factory, similar to the shape of the parts box, its small size, designed for easy installation without turning the main pumping in the fixture, you can drag the panel removal tool holder, fixture and workpiece mounted on the pallet. Processing, mounted on the lathe tool on the main primary uranium movement, feed the work piece for movement, so you can expand the scope of application of lathe.LATHE FIXTURE DESIGN POINTSThe design features of the positioning deviceLathe fixture positioning device in the design, in addition to considering the limited degrees of freedom, the most important thing is to make the surface of the workpiece axis coincides with the 15.50.1±80.1mm ± 2.5Φ10Φ17.5Φ0.02mm 17.5Φaxis of spindle rotation. This is described in the previous twosets of lathe fixture when special emphasis. In addition, the positioning device components in the specific folder location on the workpiece surface accuracy and dimensional accuracy of the location has a direct relationship, so the total figure on the fixture, be sure to mark the location positioning device dimensions and tolerances, and acceptance as a fixture conditions.Jig weight design requirementsProcessing in the lathe, the workpiece rotation together with the fixture will be a great centrifugal force and the centrifugal force increases sharply with increasing speed. This precision machining, processing, and the vibration would affect the surface quality of parts. Therefore, the lathe fixture between devices should pay attention to the layout of equipment necessary to balance the design weights.Dlamping device design requirementsLathe fixture in the course of their work should be the role of centrifugal force and cutting force, the size of its force and direction of the workpiece position relative to the base is changing. Therefore, a sufficient clamping device clamping force and a good self-locking.To ensure safe and reliable clamping. However, the clamping force can not be too large, and require a reasonable layout of the force, and will not undermine the accuracy of the location positioning device.Llathe fixture connection with the machine tool spindle design Lathe fixture connected with the spindle directly affects the accuracy of the rotary fixture accuracy, resulting in errors in the workpiece. Therefore, the required fixture rotation axis lathe spindle axis with high concentricity.Lathe fixture connected with the spindle structure,depending on the spindle when turning the front of the structure model is confirmed, by machine instructions or the manual check on. Lathe spindle nose are generally outside the car with cone and cone, or a journal and other structures with the flange end connections to the fixture base. Note, however, check the manual should be used with caution, because many manufacturers of machine tools, machine tools of similar size may differ. The most reliable method for determining, or to field measurements in order to avoid errors or losses. Determine the fixture and the spindle connecting structure, generally based on fixture size of the size of the radial: radialdimension less than , or small lathe fixture. Pairs of fixture requirements of the overall structureLathe fixture generally work in the state of the cantilever in order to ensure process stability, compact fixture structure should be simple, lightweight and safe, overhang length to as small as possible, the center of gravity close to the front spindle bearing. Fixture overhang length L and the ratio of outer diameter D profile can refer to the following values used: Less than the diameter D in fixture, ;Diameter D between the fixture in ,; Fixture diameter D is greater than , .To ensure security, installed in the specific folder on the components of the folder is not allowed out beyond the specific diameter, should also consider cutting the wound and coolant splash and other issues affecting safe operation.References140mm (23)D d <-150mm 1.25L D ≤150300mm :0.9L D ≤300mm 0.6L D ≤[1] Chen Guofu. Lathe fixture [J]. Mechanical workers. Cold,2000 (12)[2] Dong Yuming. Yang Hongyu. Fixture design in the common problems [J]. Mechanical workers. Cold, 2005 (1)[3] Liu Juncheng The machine clamps the clamping force in the design process calculations [J]. tool technology, 2007 (6) 附录B车床夹具设计分析(合肥学院机械工程系,安徽合肥230022)摘要:从车床夹具的主要类型着手,对花盘式车床夹具和角铁式夹具进行了介绍,并在此基础上分析了车床夹具设计要点。

机械制造专业外文翻译--机床夹具的分类与构成

机械制造专业外文翻译--机床夹具的分类与构成

外文原文:Machine classification and pose fixture1 fixture in the role of machiningWorkpiece clamping fixture is a kind of process equipment, it is widely used in mechanical machining of the manufacturing process, heat treatment, assembly, welding and testing processes. In the use of metal-cutting machine tools collectively referred to as the jig fixture. n a modern production machine is an indispensable fixture of the process equipment, machining of the workpiece, the processing requirements in order to ensure. First of all to the workpiece and the machine tool relative to a correct position, and this location during processing does not change the impact of external forces. To this end, during the pre-machining, workpiece clamping must be good. There are two ways to clamp workpiece: one is directly clamping the workpiece in the machine table or on the chuck; The other is the workpiece in the fixture on the fixture. The first method used when the workpiece clamping, the general design requirements have to press lines in the surface to draw the size and location, clamping, or when the needle is zoned dial indicator to find is after the clamping. This method need special equipment, but low efficiency, are generally used for one-piece and small batch production. Large quantities, mostly with the workpiece clamping fixture. With the merits of the workpiece clamping fixtures are as follows: (l) Guarantee the stability of the machining accuracy of workpiece. Workpieces with clamping fixture, the workpiece relative to the location of tool and machine tool to ensure the accuracy of the fixture from the technical level of workers, so that a number of workpiece machining accuracy of the line.(2) To improve labor productivity. Workpiece clamping fixture can facilitate the user easily、rapidly, and the workpiece does not need to find is crossed, can significantly reduce the supplementary working hours, to improve labor productivity; workpiece in the fixture after the fixture to improve the rigidity of the workpiece, thus cutting the amount of increase, to improve labor productivity; can use more pieces of multi-workpiece clamping fixture, and the use of efficient clamping bodies, to further improve labor productivity.(3) To expand the use of machine tools. Machine tools in general use a dedicated machine tool fixture can expand the scope of the process and give full play to the potential of machine tools to achieve a multi-machine use. For example, the use of adedicated fixture can be easily Lathe processing small box to the workpiece. Even in the lathe out of oil, a reduction of expensive dedicated machines, reducing the cost, which is particularly important for small and medium-sized factories.(4) To improve the operator's working conditions. As the pneumatic, hydraulic, electro-magnetic power source, such as the application in the fixture, on the one hand to reduce the labor intensity of workers; the other hand, it guarantees the reliability of the workpiece clamping, and to achieve the interlocking machine, to avoid accidents, ensure the operator safety and machine tool equipment(5) To reduce costs. In mass production after the use of fixture, from stem to increase labor productivity, lower level technical workers, as well as lower scrap and other reasons, obviously to reduce the production costs.Fixture manufacturing cost-sharing in a group of workpieces, each workpiece to increase the cost is very minimal, far less than as a result of increased labor productivity and reduce costs. The greater volume of workpiece, fixture made to use has become more significant economic benefits.2 Fixture Category2.1 General characteristics of the fixture by CategoryAccording to the production in different types of fixtures in the common characteristics of machine tool fixture fixture can be divided into general, special fixtures, adjustable clamp, and automatic line of modular fixture fixture, such as: (l) General Fixture. Universal fixture refers to the structure, size has been standardized, and has a certain universal fixture. This type of fixture adaptable, can be used to setup the scope of a certain shape and size of various parts.(2)A dedicated fixture. This type of fixture is designed for a particular part of the processing procedures and the design and manufacture. Relatively stable in the product, the production of larger quantities, used a variety of special fixtures, access to higher productivity and machining accuracy. (3) Adjustable fixture. Adjustable fixture for general fixture and special fixture and the defects developed a new kind of fixture. Of different types and sizes of the workpiece, simply adjust or replace the fixture at the original location of the individual components and will be used to clamp components. (4) Modular Fixture. Modular fixture is a modular fixture. Standard components of the module with high precision and resistance to abrasion, can be assembled into a variety of fixtures. Removable fixture used to clean the assembly after the new fixture left. (5) Automatic line fixture. Automatic line clamp generally divided into two categories:fixed-type fixture, which is similar to a dedicated fixture; other accompanying a fixture for the use of the workpiece in the fixture, together with the movement, and automatic workpiece along the line from a move to the next position position for processing.2.2 Classification by the use of machine tools ClassificationBy the use of machine tools can be divided into lathe jig fixtures, milling fixtures, drilling fixtures, hang-bed fixture, jig gear machine, CNC machine tool fixture, automatic machine tool fixtures, accompanied by automatic line, and other fixtures, such as machine tools. This is a special fixture design of the classification method used. Dedicated fixture design, the machine group, the type and the main parameters have been determined. Their difference is the cutting forming machine tool movements, so the connection fixture with the machine in different ways. Machining accuracy of their different requirements.2.3 Clamping fixture according to the power sourceClamping fixture according to the power source can be divided into manual fixture, pneumatic fixtures, hydraulic fixtures, gas fixtures by force, electromagnetic fixture, vacuum fixtures, fixture, such as centrifugal force.3 the composition of fixtureAlthough the structure of machine tool fixture range, but their components can be summarized as the following sections.(1) Positioning components. Typically, when the shape of the workpiece datum position established, the position will be the basic components of the structure identified(2) Clamping device. Positioning of the workpiece in the fixture, the need to clamp the workpiece before processing to ensure that the workpiece during processing is not due to external force and undermine its position.(3) The specific folder. Fixture and the skeleton matrix, all the components through the fixture it will constitute a whole.(4) Of the knife or the guide. Tool used to determine position relative to the correct position of components. Of the knife device common in milling fixture. Used to adjust the cutter knife block position before machining.(5) To connect components. Connected components in the machine tool fixture is todetermine the correct position on the component, therefore, can double as a specific folder to connect components. Lathe fixture on the transition plate, the positioning ofmilling machine fixture on key components are connected.(6) Other devices or components. According to the processing needs, some degree fixture device were used by mode device, the whole device, and the balance of the top block and so on. These components or devices specially designed need.中文译文:机床夹具的分类与构成1机床夹具在机械加工中的作用夹具是一种装夹工件的工艺装备,它广泛地应用于机械制造过程的切削加工、热处理、装配、焊接和检测等工艺过程中。

  1. 1、下载文档前请自行甄别文档内容的完整性,平台不提供额外的编辑、内容补充、找答案等附加服务。
  2. 2、"仅部分预览"的文档,不可在线预览部分如存在完整性等问题,可反馈申请退款(可完整预览的文档不适用该条件!)。
  3. 3、如文档侵犯您的权益,请联系客服反馈,我们会尽快为您处理(人工客服工作时间:9:00-18:30)。

中北大学信息商务学院本科毕业设计英文参考资料题目 Lathes系名专业姓名学号指导教师2016年6 月2 日译文标题车床简介原文标题Lathes作者(Serope kalpakjian)译名卡尔帕基安国籍美国原文出处/原文:LathesLathes are machine tools designed primarily to do turning, facing and boring, Very little turning is done on other types of machine tools, and none can do it with equal facility. Because lathes also can do drilling and reaming, their versatility permits several operations to be done with a single setup of the work piece. Consequently, more lathes of various types are used in manufacturing than any other machine tool.The essential components of a lathe are the bed, headstock assembly, tailstock assembly, and the leads crew and feed rod.The bed is the backbone of a lathe. It usually is made of well normalized or aged gray or nodular cast iron and provides s heavy, rigid frame on which all the other basic components are mounted. Two sets of parallel, longitudinal ways, inner and outer, are contained on the bed, usually on the upper side. Some makers use an inverted V-shape for all four ways, whereas others utilize one inverted V and one flat way in one or both sets, They are precision-machined to assure accuracy of alignment. On most modern lathes the way are surface-hardened to resist wear and abrasion, but precaution should be taken in operating a lathe to assure that the ways are not damaged. Any inaccuracy in them usually means that the accuracy of the entire lathe is destroyed.The headstock is mounted in a foxed position on the inner ways, usually at the left end of the bed. It provides a powered means of rotating the word at various speeds . Essentially, it consists of a hollow spindle, mounted in accurate bearings, and a set of transmission gears-similar to a truck transmission—through which the spindle can be rotated at a number of speeds. Most lathes provide from 8 to 18 speeds, usually in a geometric ratio, and on modern lathes all the speeds can be obtained merely by moving from two to four levers. An increasing trend is to provide a continuously variable speed range through electrical or mechanical drives.Because the accuracy of a lathe is greatly dependent on the spindle, it is of heavyconstruction and mounted in heavy bearings, usually preloaded tapered roller or ball types. The spindle has a hole extending through its length, through which long bar stock can be fed. The size of maximum size of bar stock that can be machined when the material must be fed through spindle.The tailsticd assembly consists, essentially, of three parts. A lower casting fits on the inner ways of the bed and can slide longitudinally thereon, with a means for clamping the entire assembly in any desired location, An upper casting fits on the lower one and can be moved transversely upon it, on some type of keyed ways, to permit aligning the assembly is the tailstock quill. This is a hollow steel cylinder, usually about 51 to 76mm(2to 3 inches) in diameter, that can be moved several inches longitudinally in and out of the upper casting by means of a hand wheel and screw.The size of a lathe is designated by two dimensions. The first is known as the swing. This is the maximum diameter of work that can be rotated on a lathe. It is approximately twice the distance between the line connecting the lathe centers and the nearest point on the ways, The second size dimension is the maximum distance between centers. The swing thus indicates the maximum work piece diameter that can be turned in the lathe, while the distance between centers indicates the maximum length of work piece that can be mounted between centers.Engine lathes are the type most frequently used in manufacturing. They areheavy-duty machine tools with all the components described previously and have power drive for all tool movements except on the compound rest. They commonly range in size from 305 to 610 mm(12 to 24 inches)swing and from 610 to 1219 mm(24 to 48 inches) center distances, but swings up to 1270 mm(50 inches) and center distances up to3658mm(12 feet) are not uncommon. Most have chip pans and a built-in coolant circulating system. Smaller engine lathes-with swings usually not over 330 mm (13 inches ) –also are available in bench type, designed for the bed to be mounted on a bench on a bench or cabinet.Although engine lathes are versatile and very useful, because of the time required for changing and setting tools and for making measurements on the work piece, thy are not suitable for quantity production. Often the actual chip-production tine is less than 30% of the total cycle time. In addition, a skilled machinist is required for all the operations, and such persons are costly and often in short supply. However, much of the operator’s time is consumed by simple, repetitious adjustments and in watching chips being made. Consequently, to reduce or eliminate the amount of skilled labor that is required, turret lathes, screw machines, and other types of semiautomatic and automatic lathes have been highly developed and are widely used in manufacturing.2 Numerical ControlOne of the most fundamental concepts in the area of advanced manufacturing technologies is numerical control (NC). Prior to the advent of NC, all machine tools ere manually operated and controlled. Among the many limitations associated with manual control machine tools, perhaps none is more prominent than the limitation of operator skills. With manual control, the quality of the product is directly related to and limited to the skills of the operator. Numerical control represents the first major step away from human control of machine tools.Numerical control means the control of machine tools and other manufacturing systems through the use of prerecorded, written symbolic instructions. Rather than operating a machine tool, an NC technician writes a program that issues operational instructions to the machine tool. For a machine tool to be numerically controlled, it must be interfaced with a device for accepting and decoding the programmed instructions, known as a reader.Numerical control was developed to overcome the limitation of human operators, and it has done so. Numerical control machines are more accurate than manually operated machines, they can produce parts more uniformly, they are faster, and the long-run tooling costs are lower. The development of NC led to the development of several other innovations in manufacturing technology:Electrical discharge machining,Laser cutting,Electron beam welding.Numerical control has also made machine tools more versatile than their manually operated predecessors. An NC machine tool can automatically produce a wide of parts, each involving an assortment of widely varied and complex machining processes. Numerical control has allowed manufacturers to undertake the production of products that would not have been feasible from an economic perspective using manually controlled machine tolls and processes.Like so many advanced technologies, NC was born in the laboratories of the Massachusetts Institute of Technology. The concept of NC was developed in the early 1950s with funding provided by the U.S. Air Force. In its earliest stages, NC machines were able to made straight cuts efficiently and effectively.However, curved paths were a problem because the machine tool had to be programmed to undertake a series of horizontal and vertical steps to produce a curve. The shorter the straight lines making up the steps, the smoother is the curve, Each line segment in the steps had to be calculated.This problem led to the development in 1959 of the Automatically Programmed Tools (APT) language. This is a special programming language for NC that uses statementssimilar to English language to define the part geometry, describe the cutting tool configuration, and specify the necessary motions. The development of the APT language was a major step forward in the fur ther development from those used today. The machines had hardwired logic circuits. The instructional programs were written on punched paper, which was later to be replaced by magnetic plastic tape. A tape reader was used to interpret the instructions written on the tape for the machine. Together, all of this represented a giant step forward in the control of machine tools. However, there were a number of problems with NC at this point in its development.A major problem was the fragility of the punched paper tape medium. It was common for the paper tape containing the programmed instructions to break or tear during a machining process. This problem was exacerbated by the fact that each successive time a part was produced on a machine tool, the paper tape carrying the programmed instructions had to be rerun through the reader. If it was necessary to produce 100 copies of a given part, it was also necessary to run the paper tape through the reader 100 separate tines. Fragile paper tapes simply could not withstand the rigors of a shop floor environment and this kind of repeated use.This led to the development of a special magnetic plastic tape. Whereas the paper carried the programmed instructions as a series of holes punched in the tape, the plastic tape carried the instructions as a series of magnetic dots. The plastic tape was much stronger than the paper tape, which solved the problem of frequent tearing and breakage. However, it still left two other problems.The most important of these was that it was difficult or impossible to change the instructions entered on the tape. To made even the most minor adjustments in a program of instructions, it was necessary to interrupt machining operations and make a new tape. It was also still necessary to run the tape through the reader as many times as there were parts to be produced. Fortunately, computer technology became a reality and soon solved the problems of NC associated with punched paper and plastic tape.The development of a concept known as direct numerical control (DNC) solved the paper and plastic tape problems associated with numerical control by simply eliminating tape as the medium for carrying the programmed instructions. In direct numerical control, machine tools are tied, via a data transmission link, to a host computer. Programs for operating the machine tools are stored in the host computer and fed to the machine tool an needed via the data transmission linkage. Direct numerical control represented a major step forward over punched tape and plastic tape. However, it is subject to the same limitations as all technologies that depend on a host computer. When the host computer goes down, the machine tools also experience downtime. This problem led to the development of computernumerical control.3 TurningThe engine lathe, one of the oldest metal removal machines, has a number of useful and highly desirable attributes. Today these lathes are used primarily in small shops where smaller quantities rather than large production runs are encountered.Th e engine lathe has been replaced in today’s production shops by a wide variety of automatic lathes such as automatic of single-point tooling for maximum metal removal, and the use of form tools for finish on a par with the fastest processing equipment on the scene today.Tolerances for the engine lathe depend primarily on the skill of the operator. The design engineer must be careful in using tolerances of an experimental part that has been produced on the engine lathe by a skilled operator. In redesigning an experimental part for production, economical tolerances should be used.Turret Lathes Production machining equipment must be evaluated now, more than ever before, this criterion for establishing the production qualification of a specific method, the turret lathe merits a high rating.In designing for low quantities such as 100 or 200 parts, it is most economical to use the turret lathe. In achieving the optimum tolerances possible on the turrets lathe, the designer should strive for a minimum of operations.Automatic Screw Machines Generally, automatic screw machines fall into several categories; single-spindle automatics, multiple-spindle automatics and automatic chucking machines. Originally designed for rapid, automatic production of screws and similar threaded parts, the automatic screw machine has long since exceeded the confines of this narrow field, and today plays a vital role in the mass production of a variety of precision parts. Quantities play an important part in the economy of the parts machined on the automatic screw machine. Quantities less than on the automatic screw machine. The cost of the parts machined can be reduced if the minimum economical lot size is calculated and the proper machine is selected for these quantities.Automatic Tracer Lathes Since surface roughness depends greatly on material turned, tooling , and feeds and speeds employed, minimum tolerances that can be held on automatic tracer lathes are not necessarily the most economical tolerances.In some cases, tolerances of 0.05mm are held in continuous production using but one cut . groove width can be held to 0.125mm on some parts. Bores and single-point finishes can be held to 0.0125mm. On high-production runs where maximum output is desirable, a minimum tolerance of 0.125mm is economical on both diameter and length of turn。
