DNAT负载均衡功能配置案例
DNAT负载均衡功能配置案例(设置内网服务器对互联网提供服务)
拓扑图如附件所示。
需求说明：内网有三台http服务器（192.168.2.2/3/4）要对外提供服务，使用的外网口地址是192.168.0.2，需对外提供负载均衡的功能。后续准备还要增加邮件、ftp等服务器。同时，允许这些服务器能够方便在家休息时的网管人员能管理远程的服务器。
具体配置如下：
address "cluster1"
range 192.168.2.2 192.168.2.4
host "192.168.2.2"
host "192.168.2.3"
host "192.168.2.4"
exit
service "rdp"
tcp dst-port 3389 timeout 1800
exit
interface vswitchif1
zone "trust"
ip address 192.168.2.1 255.255.255.0
manage ssh
manage ping
manage http
manage https
exit
interface ethernet0/1
zone "untrust"
ip address 192.168.0.21 255.255.255.0 manage ssh
manage ping
manage https
exit
ip vrouter trust-vr
ip route 0.0.0.0/0 192.168.0.1
exit
policy from "trust" to "untrust"
rule id 2
action permit
src-addr "Any"
dst-addr "Any"
service "Any"
exit
exit
policy from "untrust" to "trust"
rule id 3
action permit
src-addr "Any"
dst-addr "Any"
service "HTTP"
service "FTP"
service "POP3"
service "PING"
service "SMTP"
service "rdp"
service "ICMP"
exit
policy from "l2-trust" to "l2-trust"
rule id 4
action permit
src-addr "Any"
dst-addr "Any"
service "Any"
exit
nat
snatrule id 1 from "cluster1" to "Any" eif ethernet0/1 trans-to address-book "192.168.0.20" mode dynamicport sticky
exit
nat
snatrule id 2 from "Any" to "Any" eif ethernet0/1 trans-to eif-ip mode dynamicport sticky
exit
nat
dnatrule id 2 from "Any" to "192.168.0.20" service "PING" trans-to "192.168.2.3" load-balance track-ping
exit
nat
dnatrule id 1 from "Any" to "192.168.0.20" service "HTTP" trans-to "192.168.2.3" load-balance track-ping
exit
nat
dnatrule id 4 from "Any" to "192.168.0.20" service "rdp" trans-to "192.168.2.3" load-balance track-ping
exit
nat
dnatrule id 3 from "Any" to "192.168.0.20" service "PING" trans-to "192.168.2.4" load-balance track-ping
exit
nat
dnatrule id 5 from "Any" to "192.168.0.20" service "HTTP" trans-to "192.168.2.4" load-balance track-ping
exit
nat
dnatrule id 6 from "Any" to "192.168.0.20" service "rdp" trans-to "192.168.2.4" load-balance track-ping
exit
nat
dnatrule id 7 from "Any" to "192.168.0.20" service "PING" trans-to "192.168.2.2" load-balance track-ping
exit
nat
dnatrule id 8 from "Any" to "192.168.0.20" service "HTTP" trans-to "192.168.2.2" load-balance track-ping
exit
nat
dnatrule id 9 from "Any" to "192.168.0.20" service "rdp" trans-to "192.168.2.2" load-balance track-ping
exit
