基于单片机消毒柜控制器的设计

基于单片机消毒柜控制系统设计

学生：胥鑫指导教师：王萍

内容摘要：当前，在世界范围内，一个以微电子技术，计算机和通信技术为先导，以信息技术和信息产业为中心的信息革命方兴未艾。为使我国尽快实现经济信息化，赶上发达国家水平，必须加速发展我国的信息技术和信息产业。而计算机技术怎样与实际应用更有效的结合并有效的发挥其作用是科学界最热门的话题，也是当今计算机应用中空前活跃的领域。本文主要介绍了一个来用AT89C51 单片机制作的消毒柜控制电路。它主要包括供电电源电路、上电复位电路、晶振电路、开关控制电路、电热管电路、报警电路等部分。文中对各电路的结构及工作原理作了详尽的介绍。电路运行后，能自动定时控制消毒柜电热管的加电和断电，适时有效地完成对柜内餐具或其它物品的消毒工作。具有电路简单、制作容易、使用灵活等优点。通过改电路，可以进一步了解到单片机电路的应用扩展功能和指令应用技巧。

关键词：单片机单门消毒板

Based on SCM alexipharmic ark control design Abstract:At present, worldwide, with microelectronics technology, a computer and communication technology as the forerunner, take the information technology and the information industry as the center of information revolution is in the ascendant. In order to make our country as quickly as possible economic informatization, catch up with the developed countries, we must accelerate the development level of our country's information technology and information industry. But how computer technology and practical application is more effective combination and effective play its role is the scientific community's hottest topic, also is the current computer application in active unprecedentedly field. This paper mainly introduces a made by AT89C51 alexipharmic ark control circuit. It mainly includes the power supply circuit, the electricity reset circuit, crystal oscillator circuit, switch control circuit, electric heat pipe circuit, alarm circuit and other parts. In this paper the circuit structure and work principle of a detailed introduction. Circuit after the operation, it can automatic timing control alexipharmic ark of plus electric heating tube and power outages, timely effectively completed to rack tableware or other articles disinfection job. Has the circuit is simple, easy to make, use agile, etc. Through the change circuit, can further understanding to the application of SCM circuit function expansion and instructions application skills.

Keywords:SCM ChanMen Disinfection board

目录

前言 (1)

1.1 课题的背景和意义 (1)

1.2 国内外研究概况及发展方向 (1)

1.3 本文主要的研究内容 (2)

2 系统的组成及工作原理 (2)

2.1 系统设计要求 (2)

2.2 系统组成框图 (2)

2.3 系统工作原理 (3)

3 硬件电路设计 (3)

3.1 方案论证 (3)

3.2 方案确定 (5)

3.3 单片机最小系统设计 (5)

3.4 温度转换与放大电路 (6)

3.4.1 电桥电路 (7)

3.4.2 测量放大电路 (9)

3.5 数模转换电路 (11)

3.6 温度控制电路 (12)

3.7 显示模块 (13)

4 系统软件设计 (14)

4.1 系统软件设计原理 (14)

4.2 主程序设计 (15)

4.3 中断服务程序设计 (16)

4.4 系统子程序设计 (16)

4.4.1 温度采样及滤波子程序 (17)

4.4.2 显示处理子程序 (18)

4.4.3 消毒子程序 (18)

4.4.4 保温子程序 (19)

4.4.5 停止子程序 (20)

4.4.6 键盘处理子程序 (21)

5 调试与结果分析 (22)

5.1 硬件调试 (22)

5.2 软件调试 (23)

5.3 调试结果 (23)

6 总结 (24)

参考文献 (36)
