熔融指数仪操作规程

Made/DateOperating rules of G OTTFERTR熔融指数仪操作规程Doc. No ` ***-WI-W-33Verified/Date Rev. B Page 1of7 Approved/Date Effective date1.目的Purpose使操作规范化、制度化，确保测试结果准确、统一，有效控制原料及产品的质量。

Operation standardization, institutionalization, ensure the accuracy of testing results, unified, effective control of raw materials and product quality.2.适用范围Application适用于型号SS-4GL熔体流动速率仪按GB/T3682-2000的方法测测定热塑性高聚物在高温下熔体流动速率的测定。

Applicable to model SS-4GL melt flow rateinstrument according to the GB / T3682-2000method for determination ofthermoplastic polymer in high temperature melt flow rate measurement.3. 测试前准备Preparation before testing3.1.1 检查工具是否齐全；仪器电源是否接通；棉布是否够用，必须确保有足够的棉布于试验后清洁仪器。

Check whether the tools are prepared completely:instrument power supplyis connected; cotton is enough, must ensure that there is enough cotton to test after the cleaningapparatus.3.1.2 试样准备Sample preparation有关原料及素壳熔融指数的相关实验参数参照《熔融指数试验参数规范表》;On raw materials and grain shell melting index related experimental parameterswith reference to" melt index testing parameter specification table";3.1.3 将素壳剪成约5mm大小颗粒或原料(8g以上) (如图1),进行烘烤.Cut theshell into 5mm particle size or raw materials ( more than 8G ) ( Fig. 1), baking.3.2 测试步骤Testing steps3.2.1 启动仪器及程序设定Starting apparatus and program将活塞杆及口模放入料筒中，接上电源并按电源键启动仪器(如图2)，程序中设定条件和参数随塑胶种类的不同而需作相应的设定，设定方法如下：Put thepiston rod and the die into the barrel, switch on and press the power button tostart apparatus ( Figure 2), procedures set of conditions and parameters with theplastic different types require the corresponding set, setting method as follows: 按菜单试验参数设定(如图3) 依次输入要求加热温度值，Press menu testparameter setting (Figure 3) input required temperature value，for example：260℃press“260”to confirm；（温度要求参照《熔融指数试验参数规范表》和相关物性表），预热时Made/Date Operating rules of G OTTFERTR熔融指数仪操作规程Doc. No ` ***-WI-W-33 Verified/Date Rev.BPage2of7Approved/DateEffective date间一般规定为240秒，按数字键直接输入并确认 ；( the temperature requirements with reference to" melt index testing parameter specification table" and related properties table ), the preheating time general provisions for240 seconds, press the number keys directly enter and confirm; 刮料的间隔时间，一般规定为30秒，按数字键直接输入“确认”；取样次数一般为5次，按数字键直接输入“确认”；砝码重量值（砝码重量要求参照《熔融指数试验参数规范表》和相关物性表）；选择手动或自动切料；试验参数设定好并确认无误后(如图4)，按“菜单”退回主菜单，然后按“T ”开始加热升温(如图6)。

Scraper interval of time, the general regulations for30 seconds, press the number keys directly enter the" confirmation"; sampling frequency is 5times, press the number keys directly enter the" confirmation"; the weight of the weights ( weights weight requirements with reference to" melt index testing parameter specification table" and related properties table ); choice of manual or automatic cutting; test parameter setting and confirmation ( Figure 4), click "menu" back to the main menu, then press" T " to start the heating ( Figure 6).1. The piston rodinto the barrel, switch on and press the power button to start apparatus, show the initial page2. Select " set interface", enter the test parameter settingspage;图2图3图4Test parameter setting and confirmation, press "back"button to return to main menu page ( Figure 4); 3. Select the " up","down" button, test parameters.Made/Date Operating rules of G OTTFERTR熔融指数仪操作规程Doc. No ` ***-WI-W-33 Verified/Date Rev.BPage3of7Approved/DateEffective dateIn the main menu page select " interface" ( Figure 5) after direct press the "start" button start heating, heating temperature on a panel display ( Figure 6)；3.2.2 装料feed charge待实际温度稳定在设定温度值之后（恒温15分钟后），带上手套（防止烫伤）取出活塞杆，将事先准备好的试样/产品用料斗和装料杆逐次装入并压实在料筒中，全过程要在1分钟内完成，然后将活塞杆重新放入料筒中(如图7)。

The actual temperature stability at the set temperature value ( constant temperature after 15 minutes), gloves ( to prevent burns ) take out the piston rod, to prepare the sample / products with hopper and the loading rod successive load and compaction in the barrel, the entire process must be completed in 1 minutes, then the piston rod back into the barrel ( Figure 7).3.2.3 预热Preheating依预热时间240秒(4分钟)进行预热(如图9)。

In accordance with the preheating time of 240 seconds (4 minutes ) is preheated ( Figure 9). 3.2.4 切料Blanking预热时间一到，装上规定的砝码，待活塞杆下环线与料筒上平面相平时，按下“运行”键，图5图7With the hopper and thecharging bar will cut into the barrel of the successive samples, and loading rod compaction, be completed in图8Put the piston rod back into the barrel (8); and the beginning of preheating time 240 seconds ( Figure 9);图9图6Made/Date Operating rules of G OTTFERTR熔融指数仪操作规程Doc. No ` ***-WI-W-33 Verified/Date Rev.BPage4of7Approved/DateEffective date液晶屏显示的时间自动计时，到设定时间后切刀自动转动切料；When Preheating time, loading a specific weight, the piston rod of the loop line and the feed cylinder plane normally, press the"" key, LCD screen display time automatic timing, to set the time automatically rotating cutting knife;3.2.5连续切下规定间隔时间(一般为30秒)的料段3～5次，用取样盘接住切下来的料， 待其完全冷却后，用电子称称重量，算出平均值，通过数字键输入平均值按“确认” 键，此时的熔融指数作为此试样的熔融指数，按“打印”键从打印机打印出试验报告。
