baldor直线电机选型手册
如何进行直线电机选型资料
如何进行直线电机选型直线电机选型——最大推力和持续推力计算目录直线电机选型 (2)——最大推力和持续推力计算 (2)概述 (4)三角模式 (4)梯形模式 (5)持续推力 (5)计算公式 (5)例子 (6)概述直线电机的选型包括最大推力和持续推力需求的计算。
最大推力由移动负载质量和最大加速度大小决定。
推力 = 总质量 x 加速度 + 摩擦力 + 外界应力例子：当移动负载是2.5千克（包含动子），所需加速度为30m/s²时，那么，电机将产生75N的力（假设，摩擦力和外界应力忽略不计）。
通常，我们不知道实际加速度需求，但是，我们有电机运行实际要求。
给定的运行行程距离和所需要的行程时间，由此可以计算出所需要的加速度。
一般来说，对于短行程，推荐使用三角形速度模式，即无匀速运动，长行程的话，梯形速度模式更有效率。
在三角形速度模式中，电机的运动是没有匀速段的。
三角模式加速度为Acceleration = 4 x Distance / Travel_Time²梯形模式需要提前设置匀速的速度值，由此可以推算出加速度。
加速度 = 匀速 / （运动时间–位移 / 匀速）同理，减速度的计算与加速度的计算是类似的，特殊情况是存在一个不平衡的力（例如重力）作用在电机上。
通常情况下，为了维持匀速过程和停滞阶段，摩擦力和外界应力也要考虑进来，为了维持匀速，电机会对抗摩擦力和外界应力，电机停止时则会对抗外界应力。
持续推力计算公式持续推力的计算公式如下：RMSForce = 持续推力Fa = 加速度力Fc = 匀速段力Fd = 减速度力Fw = 停滞力Ta = 加速时间Tc = 匀速时间Td = 减速时间Tw = 停滞时间又最大推力和持续推力进行电机的选择。
一般情况下，应该将安全系数设置为20~30%，从而抵消外界应力和摩擦力。
例子电机需要在三角模式下，在0.2秒内，把4kg的负载移动0.3米。
电机在同行程中，返程之前停滞时间为0.15秒。
科尔摩根电机选型手册PLATINUM_DDL_Motor_C
科尔摩根公司 PLATINUM® DDL 直线电机已经通过评审、测 试，并确认符合以下标准：EN 60034 标准、EN 60204-1 标准、 IEC 34-1 标准。产品均已依据 EN 60950 标准、EN 60529 标准、 IEC 721-3 标准、NEMA MG7 标准、UL1004 标准、UL547 标准 以及 UL674 标准进行了审核。
标准特性：
无铁芯电机：
• 峰值推力为 60 ～ 1600 N（13.6 ～ 360 lbf）； • 持续推力为 21 ～ 450 N（4.6 ～ 101 lbf）； • 零齿槽效应； • 零吸力； • 运动平稳，可提供 1 微米 / 秒（0.00004 英寸 / 秒）的
最低速度； • 低质量的线圈总成，可提供高加速度；
科尔摩根公司 PLATINUM® 直线电机（DDL）符合关于安装到 一台机器中的《低压导则 73/23/EEC》。安全性取决于依照 制造商相关建议的电机的安装和配置。 安装有此产品的机 器必须符合《EC 导则 89/336/EEC》的相关规定。安装公司 应负责确保最终产品应符合设备安装所在国家的所有相关 法律。
有铁芯电机的技术数据（非冷却型） 电气 / 机械技术规格 线圈总成的机械概要
有铁芯电机的技术数据（水冷却型） 电气 / 机械技术规格 线圈总成的机械概要
有铁芯电机永磁体总成的技术数据 永磁体总成的机械概要 永磁体总成的典型安装
高效节能三相异步电动机 baldor,葆德 电机
为2010年制造出达到中国一级能效的Super-E电机奠定基础的上海 荣誉团队。
2
葆德电气公司与节能
葆德电气公司最宝贵的优良传统就在于能够始终不渝地探索如何 提高能源效率。1920年，葆德公司的创始人就提出他们将“建造 能源消耗最低的优质电机”来服务全球，在过去的80年里，葆德 一直率领整个行业不断研发性能更加优越、可靠性更高、能源消 耗更低的机电产品。从20世纪20年代成立公司至今，葆德已经发 起并推出了一系列节能改进措施，它们最终成为了行业标准。 随着电力成本的不断上升，如何提高电动机和驱动器等产品 的能效问题变得日益重要。 各家企业都必须在能源成本不断上升、可用电力日益不确定 的 环境中提高自己的竞争力，而同时全球各地对碳排放量的 严格管理也要求机械设备和生产过程所消耗的能源必须比过 去更 低。这些举措要求工业电机、驱动器以及发电机供应商 必须具有前瞻思想，能够预知用户的需求以生产既能节约成 本又能提高产量的机电产品。无疑葆德公司就是其中之一。 提高2.75个百分点、损耗平均下降20％左右，则每年可节约 电能160亿千瓦时。如果考虑其中的30％的电机运行在6000 小时以上的场合，将这部分电机改用超高效率电机，即效率 再提高1.5~2个百分点，损耗平均下降15％左右，则可再节 约电能46亿千瓦时，相应可再节约170万吨标煤，约合240 万吨原煤。并可再节约一座100万千瓦电站的投资建设。 许多国家针对电动机都已经制定了各自的《最低能效标准 （MEPS）》，这些标准将决定各个国家电机的最低能效。 在北美、巴西、加拿大、中国、马来西亚、澳大利亚、新西 兰以及墨西哥等国已经实施了MEPS，而世界上其他国家和 地区也正在制定各自的MEPS标准。随着人们对碳排放问题 日益关注，可以预见在不久的将来绝大多数国家都将会执行 MEPS，而欧盟已经达成了自愿协议，并正在讨论MEPS将 执行怎样的目标能效等级。
Baldor 马达安装、维护和操作手册说明书
1WARNING: Because of the possible danger to persons(s) or property from accidents which may result from the improper use of products, it is important that correct procedures be followed: Products must be used in accordance with the engineering information specified in the catalog. Proper installation, maintenance and operation procedures must be observed. The instructions in the instruction manuals must be followed. Inspections should be made as necessary to assure safe operation under prevailing conditions. Proper guards and other suitable safety devices or procedures as may be desirable or as may be specified in safety codes should be provided, and are neither provided by Baldor Electric Company nor are the responsibility of Baldor Electric Company. This unit and its associated equipment must be installed, adjusted and maintained by qualified personnel who are familiar with the construction and operation of all equipment in the system and the potential hazards involved. When risk to persons or property may be involved, a holding device must be an integral part of the driven equipment beyond the speed reducer output shaft.DODGE ® Instruction Manual for Type K and DOUBLE-INTERLOCK ®Pillow Blocks & S-1 UnitsThese instructions must be read thoroughly before installation or operation. This instruction manual was accurate at the time of printing. Please see for updated instruction manuals.WARNING: To ensure that drive is not unexpectedly started, turn off and lock out or tag power source before proceeding. Failure to observe these precautions could result in bodily injury.WARNING: All products over 25 kg (55 lbs) are noted on the shipping package. Proper lifting practices are required for those products.FITTING OR REPLACING A UNIT IN A PILLOW BLOCK1. Up to 5” bore, match marks have been stamped on themating faces of the cap and base of each outer housing. Over 5” bore match mark cap and base of each outer housing before removing cap. When reassembling pillow block make sure match marks on cap and base match.2. Lubricate bearing seat on the cap and on the base of theouter housing with an anti-seize compound.3. Fit each unit to its outer housing before carrying out step7. Place the unit in the pillow block base and install cap. Tighten cap bolts to specified torque in Table 1.Table 1 – Cap Bolt Torque (Non-Expansion & Expansion)Bore Size (In.)2 Bolt Base 4 Bolt Base Bolt SizeTorque Ft.-Lbs. Bolt Size Torque Ft.-Lbs. 1-3/16 – 1-11/16 3/8 – 16 24 – 30 — — 1-15/16 – 2-3/16 7/16 – 14 40 – 50 — — 2-7/16 – 2-1/2 1/2 – 13 60 – 75 1/2 – 13 60 – 75 2-15/16 – 3 5/8 – 11 120 – 150 5/8 –11 120 – 150 3-7/16 – 3-1/2 3/4 – 10 208 – 260 3/4 –10 208 – 260 3-15/16 – 4 — — 3/4 – 10 208 – 260 4-7/16 – 4-1/2 — — 7/8 – 9 344 – 430 4-15/16 – 5 — — 1 – 8 512 – 640 5-7/16 – 6 — — 1 – 8 512 - 6406-7/16 – 7——1 - 8512 - 6404. Add or remove shims between cap and base as requiredto obtain “snug” fit of unit in outer housing with cap bolts tightened to specified torque in Table 1.5. Check fit by prying against lubrication stud in unit throughthe lubrication hole in housing cap with a screwdriver or small pinch bar depending upon the size of the pillow blocks.6. The “snug” fit becomes a matter of judgment. A “loose orsloppy” fit may allow a unit mount to move in its outer housing thus wearing the mating surfaces. Too “tight” a fit will not allow the unit to move and compensate for misalignment and for shaft deflection caused by belt pull and dead weight.7. Install bearings per installation instructions contained in thismanual.INSTALLATION INSTRUCTIONS1. Shaft must be clean, free of burrs and lubricated. File nicksfrom housing bases.2. Loosen setscrews in collar and slide bearings on shaft. Ifforce is necessary, tap inner race only with a light drift. For vertical applications, locate adjusting nut on bearing so nut faces upward.3. Position expansion (floating) pillow block on mountingsurface and tighten base hold-down bolts.4. Position non-expansion (fixed) pillow block in correct relationto shaft and mounting surface. Tighten base holddown bolts, then torque setscrews in collar per Table 2.5. The effort required to turn the shaft should be the samebefore and after bolting bearings to the support.Table 2 – Set Screw TorqueBore Size (In)Set Screw Size (In)In-Lbs 1-3/16 – 1-11/165/161651-3/4 – 2-1/23/82902-11/16 – 3-1/21/26203-15/16 – 55/813255-7/16 – 63/421506-7/16 – 77/851306. Mount a dial indicator on the shaft near the nonexpansion(fixed) bearing. Place the indicator probe so that it contacts the machined surface of the S-1 Unit Housing perpendicular to that surface. See sketch below. Only one face of the S-1 Unit is a machined face.Figure 1 - S-1 Unit7. Zero the indicator and sweep the machined face 360°,noting the total indicator turnout (TIR).8. If the TIR is less than or equal to the value shown on Table3, tighten the housing cap bolts per Table 1.9. If the TIR is greater than shown on Table 3, gently tap themachined face of the S-1 housing until the TIR is less than or equal to the value shown on Table 3. Then torque the housing cap bolts per Table 1. Sweep machined faces again to verify that the TIR is still less than or equal to the value shown on Table 3.P .O. Box 2400, Fort Smith, AR 72902-2400 U.S.A., Ph: (1) 479.646.4711, Fax (1) 479.648.5792, International Fax (1) 479.648.5895Dodge Product Support6040 Ponders Court, Greenville, SC 29615-4617 U.S.A., Ph: (1) 864.297.4800, Fax: (1) 864.281.2433All Rights Reserved. Printed in USA.06/15 Litho 20,000© Baldor Electric Company MN3037 (Replaces 499798)*3037-0615*Table 3 – Total Indicator Run-out (TIR)Shaft Size (Inches)TIR (Inches)1-3/16 – 1-7/16 0.00301-1/2 – 1-11/160.00351-3/4 – 2 0.00402-3/16 0.00402-1/4 – 2-1/2 0.00452-11/16 – 3 0.00553-3/16 – 3-1/20.00653-15/16 – 4 0.00704-7/16 – 4-1/2 0.00804-15/16 – 50.008510. The non-expansion (fixed) bearing is now installed. Move tothe expansion (floating) bearing.11. Locate expansion unit in center of its axial travel or atextreme if maximum expansion is required (do not preload stop pin) and torque collar setscrews (52) per Table 2.12. Do not install external grease fittings until completion of finalsteps below.13. Torque setscrews of expansion unit (Table 2).14. Repeat Steps 6, 7, 8 and 9 for the expansion bearing.15. The expansion (floating) bearing is now installed.LUBRICATION GUIDELINESThis bearing is factory lubricated with a lithium or lithium complex base grease which is suitable for most applications. However, extra protection is necessary if the bearing is subjected to excessive moisture, dust, corrosive vapor or other harsh environments. In these cases, the bearing should contain as much grease as speed will permit (a full bearing with consequent slight leakage through the seal is the best protection against contaminant entry).For relubrication, select a grease that is compatible with a lithium or lithium complex grease. The following table is a general guide for normal operating conditions. However, some situations may require a change in lubricating periods as dictated by experience.Normal Operation — This bearing has been greased at the factory and is ready to run. The following table is a general guide for relubrication. However, certain conditions may require a change of lubricating periods as dictated by experience. See “High Speed Operation” and “Operation in Presence of Dust, Water or Corrosive Vapors” above.High Speed Operation — High speed operation is 70% of maximum catalog speed and above. In the higher speed ranges too much grease will cause overheating. The amount of grease that the bearing will take for a particular high speed application can only be determined by experience — see “Operating Temperature” below. If excess grease in the bearing causes overheating, it will be necessary to remove grease fitting (also drain plug when furnished) to permit excess grease to escape. The bearing has been greased at the factory and is ready to run. When establishing a relubrication schedule, note that a small amount of grease at frequent intervals is preferable to a large amount at infrequent intervals.Operation in Presence of Dust, Water or Corrosive Vapors — Under these conditions the bearing should contain as much grease as speed will permit, since a full bearing with consequent slight leakage is the best protection against entrance of foreign material. In the higher speed ranges too much grease will cause overheating — see “High Speed Operation” above. In the lower speed ranges it is advisable to add extra grease to a new bearing before putting into operation. Bearings should be greased as often as necessary (daily if required) to maintain a slight leakage at the seals.Operating Temperature — Abnormal bearing temperature may indicate faulty lubrication. Normal temperature may range from a few degrees up to 100ºF above ambient, depending on bearing size, speed, loading and environmental conditions. Unusually high temperature, in this range, accompanied by excessive leakage of grease indicates too much grease. In the circumstance that there is excess grease in the bearing, remove the grease fitting to allow the excess grease to purge. When purging ceases, wipe excess grease with a clean rag and screw fitting back into the bearing. High temperature with no grease showing at the seals, particularly if the bearing seems noisy, usually indicates too little grease. Normal temperature and a slight showing of grease at the seals indicate proper lubrication.Table 4 – Lubrication Guide Read Preceding Paragraphs Before Establishing Lubrication ScheduleHours Run per Day Suggested Lubrication Period In Weeks 1 to 250RPM 251 to 500RPM 501 to 750RPM 751 to 1000RPM 1001 to 1500RPM 8162412121012751053742521Lubrication recommendations are intended for standard products applied in general operating conditions. For modified products, high temperature environments and other anomalous applications, contact product engineering at 864.284.5700.Kind of Grease — Many ordinary cup greases will disintegrate at speeds far below those at which DODGE bearings will operate successfully if proper grease is used. DODGE bearings have been lubricated at the factory with an NLGI #2 lithium complex base grease. Relubricate with lithium complex-base grease or a grease which is compatible with original lubricant and suitable for roller bearing service. In unusual or doubtful cases the recommendation of a reputable grease manufacturer should be secured.Storage or Special Shutdown — If exposed to wet or dusty conditions or to corrosive vapors, extra protection is necessary. Add grease until it shows at the seals; rotate the bearing to distribute grease; cover the bearing. After storage or idle period, add a little fresh grease before running. During long idle periods, rotate shaft at least once a month.Special Operating Conditions — Refer acid, chemical, extreme or other special operating conditions to Baldor Electric Company.。
Hiwin最新直线电机力矩电机选型手册技术样本1107版
工業機器人
Single Axis Robot
• KK 半導體、電子化系列 • KS, KA 自動化系列
空氣軸承線性馬達定位 平台
Linear Motor Air Bearing Platform
2008年台灣精品金質獎 2007, 2002年台灣精品銀質獎
線性滑軌 Linear Guideway
HG/EG/RG/MG 系列 精密機械/電子半導體/生技醫療 • E2 環保潤滑模組 • Q1 靜音式 • A1 氣淨式
以下列舉了許多不同的應用案例，不單是機構部分的特殊訂製可 以提供，在某些情形下，我們也可以提供伺服控制的整體解決提 案以達到整體生產過程的最佳化。
1.1 實績案例
合理價格的取放及檢測用龍門定位系統
X Y 龍門架構使得許多應用得以更低的成本來實現，以標準元件 構築而成的龍門定位平台。 採用LMX1L系列的定位軸 重現性±2µm 可提供含底座
微米技術及晶圓處理
在微米工程等級的應用以及晶圓設備中尤其重視絕對精度及 潔淨室適用性。採用線性馬達高精度XY平台為最佳選擇。 行程200 mm x 200 mm， 亦可選購 300 mm x 300 mm 全行程平面度±4µm 各軸重現性±1µm 各軸精度±4µm 潔淨室等級100適用， 亦可選購等級10
另一AOI光學檢測應用, 客戶需求要高性能價格比 534mm × 534mm^2行程 LMS27及LMS13龍門 特殊龍門同動控制 鋼材框架 集成線路板輸送, PLC, IPC於客戶端 次微米級重現性 承諾40mm移動可於200ms內收歛至±1.5μm
4
M99TC04-1005
客製玻璃加工機台
線性馬達機台被設計用來承載工作水頭在平台上方移動, 客戶的工作 水頭用來切割雙層玻璃 同動架構線性馬達定位機台() 1300mm × 1450mm行程 平滑運動 正弦波整流, 無頓力 LMC系列馬達 各軸重現性±2μm 剛性機構底座
1TL0001-西门子贝德电机选型手册
产品样本Catalog1TL0001 Low-voltage Three-phase Motor1TL0001低压三相异步电动机2公司概况 Company Profile西门子电机（中国）有限公司是西门子在中国的独资企业，位于江苏省仪征市，占地面积为 200亩。
公司主要致力于研发和生产中小型低压三相异步电动机，目前生产符合 IEC 标准的西门子品牌三相异步电动机、以及按中国标准设计的贝得品牌系列三相异步电动机。
作为西门子在全球中小型低压电机产品的重要生产基地之一，公司坚持秉承西门子 100 多年的电动机设计和生产经验和先进技术，拥有先进的生产设备和生产工艺，采用西门子特色的现代化管理模式，严格按照国际标准 ISO9001:2008 实施全面质量管理，竭诚为广大客户提供优质的产品和服务！西门子电机（中国）有限公司 Siemens Standard Motors Ltd. (SSML)Siemens Standard Motors Ltd. (SSML) is a Siemens-ownedcompany in China. With an area of 200 acres, SSML is located in Yizheng City, Jiangsu Province. The company focuses on developing and producing small and medium low-voltage motors. Currently, SSML mainly produce Siemens brand low voltage AC motors according to IEC standards, and Beide brand low voltage motors designed according to China local standards.As one of Siemens main low-voltage motor production facilities worldwide, SSML uses the knowledge and experience of more than 100 years in motor design and manufacturing, owns the advanced manufacture equipment and process, adopts the SIEMENS modern management model , and implements comprehensive quality control according to ISO9001 2008. SSML will continuously serve customers with high quality products and good service.西门子电机（中国）有限公司3西门子电机（中国）有限公司公司概况Company Profile■ 让顾客满意• 顾客满意是公司发展的基础。
直线模组的选型方法
直线模组的选型方法主要包括以下几个方面：
1.确定使用环境：根据模组滑台的使用环境判定为一般环境、洁净环境、恶劣环境。
安装、垂直安装。
3.确定使用负载：了解模组滑台的使用负载，以便选择合适的模组。
4.核算运行速度和加速度：根据实际需求，核算模组滑台的运行速度和加速度。
9.考虑传动方式：传动方式有同步带传动和滚珠丝杆传动两种，根据实际需求选择合适的传动方式。
10.考虑负载能力：根据实际需求，选择负载能力合适的模组。
11.考虑速度要求：根据实际需求，选择速度合适的模组，注意导程越大，速度越快，负载越大，速度越慢。
12.考虑宽度要求：有时候用户需要固定的尺寸，有时候还要非标定制，宽度决定了模组的大小。
5.确定精度等级要求：明确需要的重复定位精度、行走平行度等精度等级要求。
6.考虑电机安装方式：常用的模组滑台安装方式有直联、左折、右折、上折、下折，根据实际需求选择合适的安装方式。
7.考虑行程极限开关方式：根据实际需求选择合适的行程极限开关方式。
8.了解电机规格和功率：了解模组滑台的电机规格和功率，以便选择合适的模组。
13.考虑折向要求：直线模组的折向指的是模组所配电机需要向左折还是右折、上折还是下折，根据实际需求选择合适的折向。
14.考虑精度要求：精度包括重复定位精度等，精度越高，模组性能越好。
以上是直线模组选型的一些主要方法，如需更多信息，建议咨询工业自动化技术专业人士。
直线电机选型知识点总结
直线电机选型知识点总结一、直线电机的工作原理直线电机是一种利用电磁感应原理实现的线性运动型电机，工作原理和直流电动机相似，但是线性运动的特点使得直线电机具有更广泛的应用领域。
直线电机由定子和活动子两部分组成，通常定子是由线圈组成，而活动子则是由磁铁组成。
当通电时，定子线圈产生磁场，吸引或排斥活动子的磁铁，从而实现线性运动。
二、直线电机的分类1. 电磁直线电机：利用磁铁和电磁感应原理实现线性运动的电机，包括直线同步电机、直线步进电机等。
2. 永磁直线电机：利用永磁体和电流之间的相互作用实现线性运动的电机，包括直线同步永磁电机、直线步进永磁电机等。
3. 超导直线电机：利用超导材料的独特性质实现超导电磁体和磁场之间的相互作用，实现线性运动的电机。
三、直线电机选型的影响因素1. 负载要求：负载要求包括负载力大小、运动速度、加速度等，这些要求将影响直线电机的功率、扭矩和速度等性能参数的选取。
2. 运动模式：直线电机可以实现直线运动、往复运动、多自由度运动等不同的运动模式，根据具体的应用需求选择不同类型的直线电机。
3. 环境条件：包括工作温度、湿度、防尘防水等环境条件，好的直线电机应具有良好的耐高温、防尘防水等性能。
4. 机械结构：机械结构包括导轨、导向装置等，需要考虑直线电机与周围设备的机械匹配性，确保能够实现稳定的运动。
5. 控制系统：控制系统包括控制方式、控制精度、控制算法等，应根据具体应用场景选择合适的控制系统，确保直线电机的准确性和稳定性。
四、直线电机选型的方法1. 根据负载要求选取合适的型号：首先根据负载的大小、运动速度、加速度等要求选取合适的直线电机型号，通常可以通过查阅相关的技术手册或者咨询厂家进行选型。
2. 根据环境条件选取合适的材料和防护措施：根据具体的环境条件选取能够满足要求的材料和防护措施，例如高温工作环境可以选用耐高温材料，防水防尘环境需要选用防护等级较高的直线电机。
3. 根据机械结构进行匹配：根据直线电机与周围设备的机械匹配性进行选型，确保直线电机能够稳定运行。
