【转载】手把手教你用C#调用MATLAB函数
编译环境：Microsoft Visual Studio 2008
版本9.0.21022.8 RTM
Microsoft .NET Framework
版本3.5
已安装的版本: Professional
Microsoft Visual Basic 2008 91986-031-5000002-60050
Microsoft Visual Basic 2008
Microsoft Visual C# 2008 91986-031-5000002-60050
Microsoft Visual C# 2008
Microsoft Visual C++ 2008 91986-031-5000002-60050
Microsoft Visual C++ 2008
Microsoft Visual Studio 2008 Tools for Office 91986-031-5000002-60050
Microsoft Visual Studio 2008 Tools for Office
Microsoft Visual Web Developer 2008 91986-031-5000002-60050
Microsoft Visual Web Developer 2008
Crystal Reports AAJ6G-K0MSA4K-680002Z
Crystal Reports Basic for Visual Studio 2008
Matlab 2008b
首先需要做的工作是matlab编译器的设置，设置方法为：在Command window中输入mbuild -setup 显示如下
>> mbuild -setup
Please choose your compiler for building standalone MATLAB applications:
Would you like mbuild to locate installed compilers [y]/n? n %选择n
Select a compiler:
[1] Lcc-win32 C 2.4.1
[2] Microsoft Visual C++ 6.0
[3] Microsoft Visual C++ .NET 2003
[4] Microsoft Visual C++ 2005
[5] Microsoft Visual C++ 2005 Express Edition
[6] Microsoft Visual C++ 2008
[0] None
Compiler: 6 %选择6，其他编译器可以选相应的选项，我没有验证过The default location for Microsoft Visual C++ 2008 compilers is C:\Program Files\Microsoft Visual Studio 9.0,
but that directory does not exist on this machine.
Use C:\Program Files\Microsoft Visual Studio 9.0 anyway [y]/n? n%选择n
Please enter the location of your compiler: [C:\Program Files\Microsoft Visual Studio 9.0] D:\Program Files\Microsoft Visual Studio 9.0 %选择您自己的当前安装路径
Please verify your choices:
Compiler: Microsoft Visual C++ 2008
Location: D:\Program Files\Microsoft Visual Studio 9.0
Are these correct [y]/n? y %看上述信息，如果正确选择y
**************************************************************************** Warning: Applications/components generated using Microsoft Visual Studio
2008 require that the Microsoft Visual Studio 2008 run-time
libraries be available on the computer used for deployment.
To redistribute your applications/components, be sure that the
deployment machine has these run-time libraries.
****************************************************************************
Trying to update options file: C:\Documents and Settings\Administrator\Application Data\MathWorks\MATLAB\R2008b\compopts.bat
From template: D:\PROGRA~1\MA TLAB\R2008b\bin\win32\mbuildopts\msvc90compp.bat
Done . . .
%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%至次编译器设置完成%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
在matlab的Command window中输入：
>> deploytool
Matlab产生deployment tool配置窗口
单击新建按钮，新建工程------>选择MATLAB Builder NE 选项卡----->选择.NET Component 并添加工程名eaqual（测试用名，其实工程名称就是你导入C#后的命名空间名称,Matlab会在当前工作目录中新建文件夹文件夹名既为equal）---->点击ADD File按钮将你需要编译的MATLAB函数添加进当前工程，我这里导入的是D:\Program Files\MATLAB\R2008b\toolbox\aero\aero\angle2quat.m文件---->点击build.
deployment tool output 窗口输出以下信息：
Build output( 2009-03-28 15:32:55).
[url=matlab:mcc%20-F%20%27E:%5CMATLAB%5Ceaqual.prj%27]mcc -F 'E:\MATLAB\eaqual.prj'[/url]
等待...................................有点久
当输出以下信息时编译成功了
Compiler version: 4.9 (R2008b) Warning: Duplicate directory name: E:\MATLAB. mcc -W 'dotnet:eaqual,Eaqual,0.0,private' -d 'E:\MATLAB\eaqual\src' -T 'link:lib' -v
'class{Eaqual:\Program Files\MATLAB\R2008b\toolbox\aero\aero\angle2quat.m}'
