第一篇：在海上生产平台上使用滚动压缩技术回收储存罐内闪发气体G.B.（比尔）施耐德，SPE, 布莱恩E. 博耶，SPE，马克A.古德伊尔，商科工程摘要位于墨西哥湾外大陆架的一个独立的石油天然气生产操作遭到飓风艾克的袭击并损坏了一些设施。
作为重建的一部分，其中一个海上平台被翻新了。
翻新包括浓缩产品系列控制来自附近生产平台的额外油气产品。
平台的额外产品需要一个蒸发回收系统来回收设备的闪蒸汽。
项目小组选择涡旋压缩机蒸发回收装置（VRU）来回收和重新压缩闪蒸汽。
该项目是在近海环境涡旋压缩蒸汽回收技术的首次应用。
生产者为了使设施能够回收石油储存罐中的闪发蒸汽和装置中的过剩的未使用的闪发蒸汽而安装了蒸汽回收装置。
在项目的初始阶段回收的平均量是大约每天58,000标准立方英尺天然气。
回收的天然气中甲烷含量占总额的69%。
每天甲烷的回收量估计为0.84吨，温室气体回收量估计为17.6吨二氧化碳。
挥发性有机化合物（VOC）每天回收量为1.0吨。
涡旋压缩机蒸汽回收装置满足了美国矿产管理局的放空燃烧和法规的监督要求。
该项目预计时间为15个月（基本支出）。
该项目的重要意义有：1、首次在离岸申请中使用涡旋压缩技术。
2、装置占地面积小对于近海有限操作空间的重要性。
3、涡旋技术比典型的机械压缩机所需的维修少。
4、低成本和低消耗加快经济恢复。
5、回收的闪发蒸汽含有挥发性有机化合物（VOCs）和甲烷以及温室气体。
引言在墨西哥湾外大陆架上的许多石油天然气生产平台和管道遭到2008年11月飓风艾克的破坏。
在墨西哥湾当地的一个主要的独立石油天然气生产商有一些设施被暴风雨毁坏。
作为重建的一部分，其中一个近海平台被翻新。
平台的翻新包括浓缩和改进产品系列控制来自附近生产平台的额外油气产品，由于飓风艾克的影响附近的生产平台不能输送其产品到集合管道中。
平台的额外产品需要一个蒸发回收系统来回收储存罐中的闪蒸汽。
生产商的工程小组决定利用涡旋压缩机来回收和重新压缩来自储存罐和石油设备中的闪发蒸汽。
石油储存罐中的天然气蒸汽资源包含闪发损失、工作损失和呼吸损失。
对于压力容器（如分离器、加热器）或油罐当原油或凝析油中溶解气从高压向低压移动时发生闪发。
随着油压的下降油中未溶解的轻组分被释放或“一闪而过”。
工作损失归因于储存罐压缩空间内的天然气压缩量作为一个罐已经满了。
呼吸损失归因于每天储存罐压缩空间内的天然气压缩量随着罐内温度和压力变化而改变。
对于本文，我们将油罐的排出气体统称为闪蒸汽。
通常情况下，来自近海生产平台的闪发蒸汽要么直接排放到大气中要么烧毁。
历史上蒸发回收装置被用于当投资量大并且要满足排放标准的情况下回收闪发蒸汽。
用于排出闪发蒸汽的典型蒸发回收压缩机是天然气驱动的螺杆压缩机和旋转叶压气机。
美国矿产管理局（MMS）是拥有在墨西哥湾中部和西部地区天然气放空管辖权的管理机构。
美国矿产管理局规定需要一个设施每天回收天然气量大于50,000标准立方英尺，而不是直接排放到大气中或者焚烧。
对于近海生产平台，甲板空间需求是蒸发回收装置的重要考虑因素。
为了适应这一限制条件，涡动压缩机机组的占地面积是传统蒸发回收装置的三分之一。
另外，降低总体维修成本是决定使用涡旋压缩机技术的一个重要因素。
相对于典型机械压缩机每季度换油，涡旋压缩机只需要每年更换一次。
在近海环境使用的机器要求资金提高到典型的陆上压缩机组程度，原因是海水腐蚀环境和近海操作的额外安全控制的要求。
对于这个项目陆上蒸发回收装置的标准已经达到近海条件和管理的规格。
设备和流程的描述和应用涡旋压缩技术涡旋压缩机是一种容积式机器，使用两个交错的螺旋形涡旋盘来压缩天然气。
涡旋压缩技术中，一个涡旋盘是固定的，另一个做离心运动，从而在连续的小滚动空间“泡”间抽动压缩气体，直到在中心处达到最大压力值。
在中心处，气体被释放到固定涡旋盘上的一个排放点。
压缩在滚动轨道上是连续的，大量气泡被同时压缩。
压缩机的驱动装置是电动马达。
涡旋压缩机是一种设计使用高压制冷剂的密闭压缩机。
它有一个宽松的运行范围并且本质上是无泄漏的。
涡旋压缩机技术已被广泛用于制冷系统。
涡旋压缩机蒸发回收装置采用了卧式设计，并且滴糙度、低噪音、低振动，使用变速控制电机。
根据不同情况蒸发回收装置的进气压力范围为-10.4-101.3磅每平方英寸，排气压力范围为43.5-363磅每平方英寸。
压缩比为3-15。
自2004年涡旋压缩技术就被用于石油天然气蒸发回收应用中。
涡旋技术的应用在2009年5月，联邦和生产商开始联合共同修改一个典型陆上涡旋压缩机蒸发回收装置，这个装置用于被毁坏翻新的生产平台上。
这个涡旋压缩机蒸发回收装置包含两个堆叠的模块，每个模块是8英尺长4英尺宽4英尺高的刚撬，每个刚撬含有一个进气洗涤器。
每个模块包含两个15马力的涡旋压缩机和冷却器。
每个模块还包含一个可编程逻辑控制（PLC）和变频驱动器（VFD）的控制面板。
这个双模块机组的设计回收能力是每天200,000标准立方英尺。
一条连接油罐通用出口和石油处理机（例如加热处理器）出口的进气管线被安装在涡旋压缩机蒸发回收装置的进气洗涤器上。
连接石油处理机的进气管线用来收集处理机内的额外天然气，这些天然气是在平台上未使用的燃料天然气。
在涡旋压缩机蒸发回收装置前端的进气管线上安装了一个流量计，用来计量被回收的天然气量。
涡旋压缩机组的排放被输送到现场主压缩机的进气分离器/洗涤器中。
这个主压缩机压缩的天然气最终输送到销售管线中。
当储存罐内闪发蒸汽压力较低时，在涡旋压缩机蒸发回收装置安装一个洗气系统用来回收气体。
该洗气系统的作用是保持蒸发回收装置的运行能够维持涡旋压缩机的油温在最低值华氏235度。
当保持油温等于或高于华氏235度时，闪发蒸汽能够维持气相状态。
为安全起见，在油罐上安装填充气系统来维持罐上每平方英寸约有0.5盎司压力，从而阻止氧气进入罐内。
、图1是一个包含蒸发回收装置的简化流程。
变频驱动器的控制面板安装在马达控制中心（MCC）里，其线路系统也接到位于生产平台下层的涡旋压缩机蒸发回收装置中。
在功能上，涡旋压缩机在回收模式正常运行时能达到每分钟2400转（rpm）。
当罐内产生压力时，压力变送器会发出信号使压缩机的转速提高到4800rpms，同时闪发蒸汽也被回收并压缩。
一旦罐内的闪发蒸汽被回收并且罐内压力下降，那么变频驱动器使压缩机转速降到2400rpms。
然后蒸发回收装置重新回到回收模式。
气体洗涤器回收的任何气体都被用泵输送回储油罐。
蒸发回收装置机组的改进为了满足近海要求，涡旋压缩机组的结构部分已经经过热镀锌处理并适合近海安装，但是其他组件需要修补以抵抗海水的腐蚀环境。
压缩机和一些其他组件已从模块中移除，特别添加了一个三层环氧树脂涂料的图层来抵抗腐蚀环境。
除了近海环境所需的特种涂料外，还有大量的安全系统需要修改以使涡旋压缩机蒸发回收装置遵从美国矿产管理局（MMS）的规定。
近海经营商需要遵守美国石油学会（API）建议措施14C（RP14C）。
美国石油学会建议措施14C包括近海平台安全系统的设计，安装和测试标准。
它确定了每个不良事件可能影响一个流程的要素，并讨论了每种要素类型的安全装置选择标准。
如果不能符合建议措施14C的要求会导致对生产商罚款，在其他情况下，需要中断生产直到遵守规定，这可能导致生产商的收入损失。
具体来说，应对建议措施14C的修改有：1、为气体洗涤器的高液位报警/关机月检安装测试线路。
2、为压缩机排气线的高排气压力报警/关机月检安装测试线路。
3、为储油罐的低压报警/关机月检安装测试线路。
4、添加冗余的油罐压力变送器。
为油罐的高压报警/关机月检安装测试线路。
此外，生产商的近海规格要求一些阀门更换到钢结构，而不是黄铜。
2009年7月涡旋压缩机蒸发回收装置被运到操作平台上。
2009年8月涡旋压缩机蒸发回收装置的互联管道已经完工。
一旦安装完成并且平台投入运行，涡旋压缩机蒸发回收装置也就投入运行了。
数据和结果的介绍投入的美元值：标准双蒸发回收装置机组费135,000海水环境修改费15,000美国矿产管理局的相应修改费5,000安装费40,000启动/调试费6,000总投入201,000这样安装之后，涡旋压缩机蒸发回收装置平均回收的罐内闪发蒸汽量高于初试运营期的每天58,000标准立方英尺。
回收的峰值流量记录为每天215,000标准立方英尺。
用于化学分析的回收气体样本的分子量是26.6，其中甲烷体积大约占69%。
挥发性有机化合物（非甲烷烃，非烷烃碳氢化合物）体积大约占29%。
较高的加热数值大约是每标准立方英尺1540英热单位（BTU）。
闪发蒸汽中的硫化氢气体量被认为是基于设备加工新天然气的最小含量。
以平均回收量和天然气价格每英热单位5美元为标准计算的涡旋压缩机蒸发回收装置基本支出为15个月。
甲烷排放量估计回收值为每天0.84美吨，温室气体二氧化碳的估计回收值为每天17.6美吨。
挥发性有机化合物（VOC）的排放量回收值为每天1.0美吨。
生产商目前正在修改涡旋压缩机蒸发回收装置的控制系统。
这些修改包括安装一个单一的可编程逻辑控制器（PLC）来控制两个模块，更换变送器的压力开关，以及在蒸发回收装置旁边安装一个触屏的控制面板。
这些修改需要符合生产商运营标准。
这些修改的费用将导致额外增加8000美元的初始成本。
结论涡旋压缩技术应用于恶劣的海上环境是一种具有成本效益、最有效的油气回收解决方案。
通过应用涡旋压缩技术回收蒸汽，近海生产商能够满足监管要求，以减少废气排放，提高他们的碳足迹，并能经济地回收闪发蒸汽。
致谢我们衷心感谢威尔士詹姆斯先生和达姆伦罗恩先生，因为有他们的专业知识和辛勤的工作才能取得这个项目的成功。
参考文献1、艾默生环境优化技术。
2008年4月。
全封闭涡旋压缩机在高温压缩气体中的应用/oil_gas/PDF/HermeticScrollCompressorWhitePaper. pdf.2、建议措施14C关于海上生产平台基础表面安全系统的分析、设计、安装和测试，第六版。
1998年3月，华盛顿：美国石油学会。
