报纸发行员投递管理系统

报纸发行员投递管理系统报纸的客户主要集中在社区，每个社区有若干客户。

每个发行员管理若干客户。

为该报社开发一个报纸发行员投递管理系统。

系统主要功能如下：(1) 系统用户管理：实现系统管理员添加、删除和更改密码等功能。

(2) 发行员管理：实现发行员个人信息的查询和维护。

(3) 客户信息管理：实现客户信息的查询和维护。

(4) 报纸管理：报纸订购和退订信息的维护和查询(5) 管理统计：发行员负责区域的安排，客户数量和订购信息的统计。

一、报纸发行员投递管理系统的分析和概要设计（1）系统模块菜单：1 系统用户管理实现系统管理员添加删除以及密码更改功能2 发行员管理实现发行员个人信息的维护对发行员进行查询3 客户信息管理实现客户信息的维护对客户进行查询4 报纸管理报纸订购和退订信息的维护报纸订购和退订信息的查询5 管理统计发行员负责区域的安排客户数量和订购信息的统计（2）报纸发行员投递管理系统功能描述1 系统用户管理：对系统管理员添加，删除，更新及查询；2 发行员管理：实现对每个发行员添加，删除，更新及查询3 客户信息管理：实现对每个客户信息添加，删除，更新及查询4 报纸管理：报纸订购与退订，及报纸信息的添加，删除，更新及查询5 管理统计：发行员负责的区域的更新，客户数量的统计，订购信息的统计二、系统数据结构设计用户需求具体有报刊发行员管理系统提供保存、更新、查询、维护，这就需求数据库结构能充分满足各种信息的输入与输出，实现有组织地、动态地存储大量关联数据，方便用户访问系统中的数据。

1.数据流图描述：本系统从总体上分为系统系统用户管理、发行员管理、客户管理、报纸管理和统计功能。

信息流入图2.数据库中的表有关创建数据库和关系表的SQL语句如下所示：/*========================================================== ====*//* DataBase: 报纸发行员投递管理系统, 创建数据库，数据库名称为报纸发行员投递管理系统*//*========================================================== ====*/create database报纸发行员投递管理系统go/*========================================================== ====*//* Table: paper, 报纸信息表*//*========================================================== ====*/create table paper (paper nchar(10), /*报纸名*/)go/*========================================================== ====*//* Table: CustomerInfo, 客户个人信息表*//*========================================================== ====*/create table CustomerInfo (name1 nchar(10), /*客户姓名*/sex nchar(10) , /*客户性别*/telephone nchar(20), /*客户*/site nchar(10), /*客户住址*/distributor nchar(10), /*客户发行员*/)go/*========================================================== ====*//* Table: CustomerOrder，客户订购信息表*//*========================================================== ====*/create table CustomerOrder(name1 nchar(10), /*客户姓名*/sex nchar(10) , /*客户性别*/telephone nchar(20), /*客户*/site nchar(10), /*客户住址*/distributor nchar(10), /*客户发行员*/date datetime /*订购时间*/)go/*========================================================== ====*//* Table: CustomerCancle，客户退订信息表*//*========================================================== ====*/create table CustomerCancle(name1 nchar(10), /*客户姓名*/sex nchar(10) , /*客户性别*/ telephone nchar(20), /*客户*/site nchar(10), /*客户住址*/ distributor nchar(10), /*客户发行员*/ date datetime /*退订时间*/)Go3.ER图1. 系统管理员查询2. 添加系统用户3. 删除系统用户4. 更新系统用户5. 发行员查询6.发行员添加信息7.发行员信息删除8.发行员信息更新9. 客户信息查询10.客户信息添加11.客户信息删除12.客户信息更新13.报纸订购与退订的查询14.报纸订购添加15.报纸退订删除16.报纸订购与退订更新17.统计管理三、应用系统设计登录界面：登录按钮点击事件代码：private void btnLogin_Click(object sender, EventArgs e){try{if (txtUserName.Text == "") //判断用户是否输入登录名{MessageBox.Show("用户名不能为空");}elseif (txtPwd.Text == "") //判断用户是否输入密码{MessageBox.Show("密码不能为空");}elseif (cmbLogin.Text == "") //判断用户是否选择用户界面{MessageBox.Show("请选择登录界面");cmbLogin.Focus();return;}else{if (cmbLogin.Text == "客户"){SqlConnection con = PaperCon.createCon(); //创建数据库连接con.Open(); //打开连接SqlCommand cmd = new SqlCommand("select count(*)from Users where name1='" + txtUserName.Text + "' and pwd1='" + txtPwd.Text + "'andpermission='"+cmbLogin.Text+"'", con);Int32 count = (Int32)cmd.ExecuteScalar(); //获取返回值if(count==1){frmMain1 main = new frmMain1();main.Show(); //弹出客户登陆界面Login_name = txtUserName.Text;this.Hide(); //隐藏登陆界面}else{MessageBox.Show("用户名或者密码错误"); //弹出提示}con.Close();}if (cmbLogin.Text == "发行员"){SqlConnection con = PaperCon.createCon(); //创建数据库连接con.Open(); //打开连接SqlCommand cmd = new SqlCommand("select count(*)from Users where name1='" + txtUserName.Text + "' and pwd1='" + txtPwd.Text + "'and permission='" + cmbLogin.Text + "'", con);Int32 count = (Int32)cmd.ExecuteScalar(); //获取返回值if (count==1){frmMain2 main = new frmMain2();main.Show();Login_name = txtUserName.Text; //记录登陆用户名this.Hide();}else{MessageBox.Show("用户名或者密码错误"); //弹出提示}con.Close();}if (cmbLogin.Text == "系统用户"){SqlConnection con = PaperCon.createCon(); //创建数据库连接con.Open(); //打开连接SqlCommand cmd = new SqlCommand("select count(*)from Users where name1='" + txtUserName.Text + "' and pwd1='" + txtPwd.Text + "'and permission='" + cmbLogin.Text + "'", con);Int32 count = (Int32)cmd.ExecuteScalar(); //获取返回值if (count==1){frmMain3 main = new frmMain3();main.Show();Login_name = txtUserName.Text;this.Hide();}else{MessageBox.Show("用户名或者密码错误"); //弹出提示}con.Close(); //关闭连接}}}catch (Exception ex){MessageBox.Show(ex.ToString()); //获取异常}}客户界面：报纸订购事件程序：private void button1_Click(object sender, EventArgs e){try{if (textBox1.Text == ""){MessageBox.Show("请输入要订购的报纸名");}else{SqlConnection con = PaperCon.createCon(); //创建数据库连接con.Open();SqlCommand cmd1 = new SqlCommand("select count(*)from Allpaper where paper='" + textBox1.Text + "'", con);Int32 count1 = (Int32)cmd1.ExecuteScalar();SqlCommand cmd4 = new SqlCommand("select count(*)from CustomerOrder where name1='" + label8.Text + "' and paper='" + textBox1.Text + "'", con);Int32 count4 = (Int32)cmd4.ExecuteScalar();if (count4 > 0) //判断用户是否订购了该报纸{MessageBox.Show("您¨已经订购了该报纸");}if (count1 == 0) //判断是否有该报纸名{MessageBox.Show("没有该报纸名，订购失败");}else if ( count1 > 0 && count4==0){string strSql = "insert into CustomerOrder(name1,sex,paper,telephone,site,date) values('" + label8.Text.ToString() + "','" + label9.Text.ToString() + "','" + textBox1.Text.ToString() + "','" + label11.Text.ToString() + "','" + label12.Text.ToString() + "','" + DateTime.Now.ToString() + "')";SqlCommand cmd = new SqlCommand(strSql, con);cmd.ExecuteNonQuery();// 执行SQL语句完成SQL命令MessageBox.Show("订购成功");string strSql1 = " update CustomerOrder set distributorname=(select distributorname from CustomerInfo where name1='" + label8.Text.ToString() + "')where name1='" + label8.Text.ToString() + "'";SqlCommand cmd3 = new SqlCommand(strSql1, con);cmd3.ExecuteNonQuery();// 执行SQL语句完成SQL命令con.Close();}}}catch (Exception ex){MessageBox.Show(ex.ToString());}}private void Paperorder_Load(object sender, EventArgs e){label8.Text=frmLogin.Login_name;SqlConnection con = PaperCon.createCon(); //创建数据库连接con.Open();string str1="select sex from CustomerInfo where name1='"+frmLogin.Login_name+"'";SqlCommand cmd1 = new SqlCommand(str1, con);string sex = (string)cmd1.ExecuteScalar();label9.Text = sex.ToString();string str2 = "select telephone from CustomerInfo where name1='" +frmLogin.Login_name + "'";SqlCommand cmd2 = new SqlCommand(str2, con);string telephone = (string)cmd2.ExecuteScalar();label11.Text = telephone.ToString();string str3 = "select site from CustomerInfo where name1='" + frmLogin.Login_name + "'";SqlCommand cmd3 = new SqlCommand(str3, con);string site = (string)cmd3.ExecuteScalar();label12.Text = site.ToString();label13.Text = DateTime.Now.ToString();con.Close();}报纸退订事件程序：private void button1_Click(object sender, EventArgs e) {try{if (textBox3.Text == ""){MessageBox.Show("报纸名不能为空");}else{SqlConnection con = PaperCon.createCon(); //创建数据库连接con.Open();SqlCommand cmd1 = new SqlCommand("select count(*)from CustomerOrder where name1='" + label8.Text + "'and paper='" + textBox3.Text + "'", con);Int32 count = (Int32)cmd1.ExecuteScalar();if ( count > 0){string strSql = "DELETE FROM CustomerOrder where name1='" +label8.Text.ToString() + "'and paper='" + textBox3.Text.ToString() + "'";SqlCommand cmd = new SqlCommand(strSql, con);cmd.ExecuteNonQuery();// 执行SQL语句完成SQL命令MessageBox.Show("退订成功");string strSql1 = "insert into CustomerCancle(name1,sex,paper,telephone,site,date) values('" + label8.Text.ToString() + "','" + label9.Text.ToString() + "','" + textBox3.Text.ToString() + "','" + label10.Text.ToString() + "','" + label11.Text.ToString() + "','" + DateTime.Now.ToString() + "')";SqlCommand cmd3 = new SqlCommand(strSql1, con);cmd3.ExecuteNonQuery();// 执行SQL语句完成SQL命令con.Close();}else if (count == 0) //判断是否有该订购记录{MessageBox.Show("您没有订购该报纸，操作失败");}}}catch (Exception ex){MessageBox.Show(ex.ToString());}}private void PaperCancle_Load(object sender, EventArgs e){label8.Text = frmLogin.Login_name;SqlConnection con = PaperCon.createCon(); //创建数据库连接con.Open();string str1 = "select sex from CustomerInfo where name1='" + frmLogin.Login_name + "'";SqlCommand cmd1 = new SqlCommand(str1, con);string sex = (string)cmd1.ExecuteScalar();label9.Text = sex.ToString();string str2 = "select telephone from CustomerInfo where name1='" +frmLogin.Login_name + "'";SqlCommand cmd2 = new SqlCommand(str2, con);string telephone = (string)cmd2.ExecuteScalar();label10.Text = telephone.ToString();string str3 = "select site from CustomerInfo where name1='" + frmLogin.Login_name + "'";SqlCommand cmd3 = new SqlCommand(str3, con);string site = (string)cmd3.ExecuteScalar();label11.Text = site.ToString();label12.Text = DateTime.Now.ToString();con.Close();}发行员界面：我的客户点击事件程序：private void我的客户¡ìToolStripMenuItem_Click(object sender, EventArgs e){SqlConnection con = PaperCon.createCon(); //创建数据库连接¨con.Open();string commandString = "Select * from CustomerInfo where distributorname='" + frmLogin.Login_name + "'"; //获取该发行员的客户信息SqlDataAdapter DataAdapter = new SqlDataAdapter(commandString, con);DataSet DataSet = new DataSet();DataAdapter.Fill(DataSet, "CustomerInfo");DataTable dataTable = DataSet.Tables[0];dataGridView1.DataSource = dataTable;con.Close();}删除退订点击事件程序：private void删¦除ToolStripMenuItem_Click(object sender, EventArgs e){if (MessageBox.Show("确定删¦除所选记录吗", "提示", MessageBoxButtons.OKCancel, MessageBoxIcon.Asterisk) == DialogResult.OK){SqlConnection con = PaperCon.createCon(); //创建数据库连接con.Open();string sql = "delete from CustomerCancle where paper='" +dataGridView1.CurrentRow.Cells["paper"].FormattedValue.ToString() + "' "; //删除该条退订记录SqlCommand cmd = new SqlCommand(sql, con);cmd.ExecuteNonQuery();// 执行SQL语句完成SQL命dataGridView1.Rows.Remove(dataGridView1.CurrentRow);con.Close();}}订购数量点击事件程序：private void订购数量ToolStripMenuItem_Click(object sender, EventArgs e)show2(); //调用show2()}private void show2(){SqlConnection con = PaperCon.createCon(); //创建数据库连接con.Open();string strSql = "Select * from CustomerOrder where distributorname='" + frmLogin.Login_name + "'";SqlCommand cmd = new SqlCommand(strSql, con);cmd.ExecuteNonQuery();// 执行SQL语句完成SQL命令int count = 0;SqlDataReader reader = cmd.ExecuteReader();while (reader.Read()){count++;Console.WriteLine(String.Format("{0}", reader[0]));}MessageBox.Show("我的客户订购数量为："+count.ToString());con.Close();系统用户界面：增加报纸点击事件程序：private void button1_Click(object sender, EventArgs e) {if (textBox1.Text == ""){MessageBox.Show("报纸名不能为空");}else{try{SqlConnection con = PaperCon.createCon(); //创建数据库连接con.Open();SqlCommand cmd = new SqlCommand("insert into Allpaper (paper) values('" + textBox1.Text.ToString() + "')", con); //向表中插入该报纸名cmd.ExecuteNonQuery();// 执行SQL语句完成SQL命令con.Close();MessageBox.Show("添加成功");}catch (Exception ex){MessageBox.Show("该报纸名已存在! ! !");}}}添加客户点击事件代码：private void button1_Click(object sender, EventArgs e) {if (textBox1.Text == ""){MessageBox.Show("用户名不能为空");}else if (textBox2.Text == ""){MessageBox.Show("密码不能为空");}else{SqlConnection con = PaperCon.createCon(); //创建数据库连接con.Open();SqlCommand cmd2 = new SqlCommand("select count(*)from Users where name1='" + textBox1.Text.ToString() + "'", con);Int32 count = (Int32)cmd2.ExecuteScalar();if (count == 1) //判断是否有该用户{MessageBox.Show("该用户已经存在");}else{string strSql = "insert into Users(name1,pwd1,permission) values('" + textBox1.Text.ToString() + "','" + textBox2.Text.ToString() + "','客户')"; //向用户表中插入该客户SqlCommand cmd = new SqlCommand(strSql, con);cmd.ExecuteNonQuery();// 执行SQL语句完成SQL命令string strSql1 = "insert into CustomerInfo(name1) values('" +textBox1.Text.ToString() + "')"; //向客户信息表中插入该客户SqlCommand cmd1 = new SqlCommand(strSql1, con);cmd1.ExecuteNonQuery();// 执行SQL语句完成SQL命令MessageBox.Show("添加成功");con.Close();}}}private void button1_Click(object sender, EventArgs e){try{if (textBox1.Text == ""){MessageBox.Show("客户姓名不能为空");}else if (textBox2.Text == ""){MessageBox.Show("发行员不能为空");}else{SqlConnection con = PaperCon.createCon(); //创建数据库连接con.Open();SqlCommand cmd1 = new SqlCommand("select count(*)from Users where name1='" + textBox1.Text + "'and permission='客¨ª户¡ì'", con);Int32 count1 = (Int32)cmd1.ExecuteScalar(); //判断是否有该客户SqlCommand cmd2 = new SqlCommand("select count(*)from Users where name1='" + textBox2.Text + "' and permission='发¤¡é行D员¡À'", con);Int32 count2 = (Int32)cmd2.ExecuteScalar(); //判断是否有该发行员if (count1==0){MessageBox.Show("没有该客户");}else if (count2 == 0){MessageBox.Show("没有该发行员");}else{string strSql3 = " update CustomerInfo set distributorname='" + textBox2.Text.ToString() + "'where name1='" + textBox1.Text.ToString() + "'";SqlCommand cmd3 = new SqlCommand(strSql3, con);cmd3.ExecuteNonQuery();// 执行SQL语句完成SQL命令string strSql4 = " update CustomerOrder set distributorname='" + textBox2.Text.ToString() + "'where name1='" + textBox1.Text.ToString() + "'";SqlCommand cmd4 = new SqlCommand(strSql4, con);cmd4.ExecuteNonQuery();// 执行SQL语句完成SQL命令con.Close();MessageBox.Show("分配成功");}}}catch (Exception ex){MessageBox.Show(ex.ToString());}}更改密码点击事件程序：private void button1_Click(object sender, EventArgs e){if (textBox3.Text == "") //判断用户是否输入了用户名{MessageBox.Show("用户名不能为空");}else{if (textBox1.Text == ""){MessageBox.Show("原密码不能为空"); //判断用户是否输入了密码}else if (textBox2.Text == ""){MessageBox.Show("新密码不能为空");}else{SqlConnection con = PaperCon.createCon(); //创建数据库连接con.Open();SqlCommand cmd2 = new SqlCommand("select count(*) from Users where name1='" + textBox3.Text.ToString() + "' and pwd1='" + textBox1.Text.ToString() + "'", con);Int32 count2 = (Int32)cmd2.ExecuteScalar();if (count2 > 0){string strSql1 = "update users set pwd1='" + textBox2.Text.ToString() + "' where pwd1='" + textBox1.Text.ToString() + "' ";SqlCommand cmd1 = new SqlCommand(strSql1, con);cmd1.ExecuteNonQuery();// 执行SQL语句完成SQL命令con.Close();MessageBox.Show("修改成功");}if (count2 == 0){MessageBox.Show("用户名或密码错误");}con.Close();}}}。
