软件安全——静态、动态程序分析技术

论道：软件安全

—静态、动态程序分析技术

What I expect you to know:

•Security Landscape

–Network, Host, Application

•Common vulnerability:

–SQL Injection, Cross-Site Scripting, Buffer Overflow •Basic concepts on programming, software development, penetration test

Agenda

•Common Misconceptions •Appsec Trends •Automatic Tools

–Static Analysis

–Dynamic Analysis •Practical Consideration

Secure the ATM at the last stage

Consider CSV format

Save as CSV

(Common Separated Format)

1.CSV: Why you want to filter out [,]?

2.SQL Injection: Why you want to filter out [‘]?

Consider CSV format

Save as CSV

(Common Separated Format)

It’s not about attack, it is a program bug.

No matter it is a internal program or a

webapp, this is a bug.

Fixing SQL Injection: Escaping

name Ægary sku_id Æ1234 or 1=1

After escaped, no change

name Ægary sku_id Æ1234 or 1=1 select * from item

where account = ‘$name' and sku_id = $sku_id

Static Analysis
• Analyze code without executing it • Able to contemplate many more possibilities than you could execute with conventional testing • Doesn’t know what your code is supposed to do • Must be told what to look for

Static Analysis Engines
• A common static analysis usually consists of many different engines • Different engines use different algorithm to detect different sets of problems • Common engines are
– Dataflow – Control flow – Semantic – Configuration - Structural - Statistical - Buffer - etc…
22

Data Flow
• Find vulnerabilities where non-trusted input can potentially control application operation.
– Vulnerabilities to injection attacks
• Analyzer uses global taint propagation to trace the flow of nontrusted data
– Source
• Non-trusted (user controlled) input
– Sink
• Potentially dangerous function call or operation
23

Understanding Data Flow – Sample
import java.sql.*; public class SQLInjection { public static void main (String args[]) { Connection conn = null; try { String userName = args [0]; String passwd = args [1]; String query = "select uname, passwd from users where uname like "+userName+"%"; conn = DriverManager.getConnection ("jdbc:odbc:logistics", "admin", "letmein"); Statement stmnt = conn.createStatement (); ResultSet rs = stmnt.executeQuery (query); while ( rs.next() ) { ... } rs.close (); stmnt.close (); conn.close (); } catch (SQLException err) { err.printStackTrace (); } } }
24

Data Flow (cont’d)
import java.sql.*; public class SQLInjection { public static void main (String args[]) { Connection conn = null; try { String userName = args [0]; String passwd = args [1]; String query = "select uname, passwd from users where uname like "+userName+"%"; conn = DriverManager.getConnection ("jdbc:odbc:logistics", "admin", "letmein"); Statement stmnt = conn.createStatement (); ResultSet rs = stmnt.executeQuery (query); while ( rs.next() ) { ... } rs.close (); stmnt.close (); conn.close (); } catch (SQLException err) { err.printStackTrace (); } } }
Source
25
