一种沥青储存罐[实用新型专利]

专利名称：一种沥青储存罐专利类型：实用新型专利
发明人：王新亮
申请号：CN202020304542.9申请日：20200312
公开号：CN211811356U
公开日：
20201030
专利内容由知识产权出版社提供
摘要：本实用新型公开了一种沥青储存罐，包括罐体和电机，所述罐体上端开口中设有密封板，密封板上设有一个以上的搅拌杆，罐体内部的底面上设有一环形槽，环形槽内部活动安装有相匹配的定位环，定位环与搅拌杆之间均安装有连接杆，密封板上端设有一环形结构的齿条，齿条上的凸齿设置于外圈上，齿条的底面与密封板之间焊接固定有一块以上的连接块，齿条被所述的电机驱动。

本实用新型结构简单，电机能带动密封板旋转，密封板的旋转带动了搅拌杆，从而有效的对内部的沥青进行搅拌，避免了凝固，且在出料时，能下压密封板，通过密封板及橡胶层能有效的将罐体内壁面上的沥青及搅拌杆上的沥青刮去，避免了残留，从而不影响后续的使用。

申请人：王新亮
地址：514531 广东省梅州市兴宁市叶塘镇大路下村无尽卢屋14号
国籍：CN
代理机构：深圳市世通专利代理事务所(普通合伙)
代理人：阮文沁
更多信息请下载全文后查看。
