久保田失重秤(上料机)
称重给料机使用说明书

测速传感器将物料的运作速度转换成脉冲信号,从而控制称重仪表的采样频 率。称重给料机选用光电脉冲式测速传感器.
跑偏开关
(图四)
(图五)
(图六)
I.挡料橡胶皮带的检查及调整(见图五)
如使用平皮带结构,则挡料装置橡胶板下沿与环行带上表面有 2mm 的间隙;
J.外清扫器刮料橡胶皮带的检查及调整(见图六)
保证外清扫器刮料橡胶板与皮带接触; K.称重组件的检查及调整(见图七)
标定支架
保证标定支架与称重托辊垂直,使标棒重
5. 技术参数
给料精度:±0.5% 给料流量:0.5-500t/h(具体给料流量见设备标牌) 使用环境温度:-10℃至+40℃ 使用主电源:380VAC±10% 50 HZ±2% 使用仪表电源:24VDC±10% Max1A
6. 工作原理
6.1. 计量原理
物料通过称量段平台将负荷加载至称重辊上,称重辊又将作用力传输给称重传感 器,称重传感器输出电压通过放大传输给称重仪表微处理器,微处理器通过一系 列计算得出有关的物料实际给料量、物料的累计量等数值。
量垂直作用于称重传感器;
锁紧螺母
松开锁紧螺母,将安全限位螺钉与称重传 限位螺钉
感器底部脱开,间隙 2mm,然后将锁紧螺
母拧紧。
称重传感
(图七)
