中英文对照：建筑专业词汇（2）施工 construct; execution; construction; execution of works 施工安装图 construction and erection drawing施工安装用的机械及工具 machines and tools for construction and erection 施工标桩 construction stake施工布置图 construction plan施工步骤 construction procedure; construction steps施工测量 construction survey施工程序 construction program; execution programme for works施工程序网络图 project network施工贷款 construction loan施工单位 construction organization; builder施工道路 construction road施工地点 job location施工吊车 construction hoist施工定额 construction norm施工队 construction team施工方法 job practice施工方式 form of construction work施工费用 construction cost施工缝 construction joint施工工程 construction work施工工程师 construction engineer; operating engineer施工工程学 construction engineering施工工期 construction period施工工种 construction trade施工规模 scope of construction item; size of construction施工荷载 construction loads; working load施工合同 construction contract施工机械 construction machinery施工机械费 cost of constructor's mechanical plant施工机械化 mechanization of building operation; mechanization of construction施工机械化系数 coefficient of construction mechanization施工技术财务计划 financial plan for construction technology施工计划 construction plan; construction program(me)施工监督 supervision of construction; supervision; monitoring施工检查 inspection of construction施工检查员 construction inspector施工阶段 construction stage; construction phase施工进度 construction progress施工进度表 schedule of construction; schedule of operations;work-schedule施工进度计划 detailed construction schedule; construction schedule施工经济学 construction economics施工经理 construction manager施工经验 construction experience施工卷扬机 builder's hoist; builder's winch施工临时螺栓 construction bolt施工流水作业法 construction streamline method施工面积 floor space under construction施工平面图 construction plan施工期 construction period施工起重机 construction hoist施工企业 construction enterprises施工前阶段 preconstruction stage施工区 construction area施工缺陷 constructional deficiency施工人员 constructor; builder施工设备 plant for construction; construction equipment施工设计 detail design; detai led engineering施工水平仪 builder's level施工说明 general des cription of construction施工说明书 construction specifications施工图设计 construction documents design施工图设计阶段 construction documents design phase; constructiondocuments phase施工图预算 working drawing estimate施工文件 construction documents (包括施工图及说明)施工误差 construction error施工现场 fabricating yard; job location施工详图 detail of construction; construction detail; working drawing施工项目 project under construction; construction item施工项目编号 construction item reference number施工效率 efficiency of construction施工性能 workability施工许可证 builder's licence施工验收技术规范 technical code for work and acceptance施工依据 manufacture bases施工营业执照 builder's licence施工预算 construction estimate施工执照 building permit施工准备 preliminary work for construction; preparations forconstruction施工准备计划 preparatory plan施工总平面图 overall construction site plan施工总则 general conditions of construction施工组织设计 construction management plan施工作业计划 work element construction program项目 subject of entry; item项目报告 project paper项目编制阶段 project preparation phase项目标记 project mark项目财务估价 project financial evaluation项目采购 project purchasing项目成本 project cost; item cost项目筹备融通资金 project preparation facility (PPF)项目贷款 project finance; project-financing loan; project loan 项目单 menu项目的拟订 project formulation项目的所有者 owner of the project项目的总投标价值 total tender value of project项目发展周期 project development cycle项目范围 scope of project项目方案 project alternatives项目分隔符 item separation symbol项目分类 classification of items项目分配 allocation of items项目分析 item analysis项目工程师 project engineer项目工程师负责制 project engineer system项目管理 project management项目管理人 project manager项目号 item number项目核对法 check list (市场调查技术之一)项目核准权 projects approval authority项目后评价 post project evaluation项目后评价和后继行动 post project evaluation and followup项目划分 segregation of items项目化组织 projectized organization项目环境生态评价 environmental appraisal of a project项目货款额度 project line项目技术评价 project technology evaluation项目计划 project plan项目计划设计图 project planning chart项目记录 item record项目加权 item weighting项目检验回归曲线 item-test regression curve项目建设费用 cost of project implementation项目建设进度表 project implementation scheduling项目建议书 proposals for the projects项目经济估价 project economic evaluation; economic evaluation of aproject项目经理 project manager项目矩阵组织 project matrix organization项目控制 project control项目块 entry block项目历史 history of project项目目标管理 project management by objectives项目拟订 project formulation项目匹配法 matching item项目评估 project appraisal; project evaluation项目评估法 Project Evaluation and Review Technique项目企业经济评价 enterprise's economic appraisal of a project 项目删除 deletion of items项目上端 item top项目社会评价 project's social value appraisal项目设备 project equipment项目设计 item design项目设计工程师负责制 project engineer responsibility system 项目生产 project production项目说明 item des cription项目说明书 specification of an item项目投资时期 investment phase of a project项目图与布置图 project charts and layouts项目网络法 project network technique项目网络分析 project network analysis项目文件 item file项目小组 project group; project team organiztion项目行 item line项目修理通知单 item repairing order项目选择 project selection项目训练法 project training项目研究编目 item study listing项目研究小组 project team项目一次采购法 project purchasing项目一览表 itemized schedule项目预算 program budget; project budget项目预算编制 program budgeting项目政治评价 political appraisal of a project项目支助业务 project supporting services项目执行 project implementation项目执行情况审计报告 project performance audity report (PPAR) 项目指标 project indicators项目转移 item advance项目资金筹措 project financing。
施工图中英文对照词汇表
中央冷冻系统Cenｔral Chiｌler Syｓtｅmｓﻫ能量回收系统EｎｅrgｙReｃｏvery Systems
施工图中英文对照词汇表
———————————————————————————————— 作者:
———————————————————————————————— 日期：
设计图ｌａｙout;desigｎ
施工图final
平面图plan ﻫ立面图eｌｅvａtioｎ
轴测图、透视图isomeｔric drawiｎg；ｄetａil drａwing
详图、大样图、接点图recｏrd dｒawiｎgﻫ修改图竣工图aｓ-complｅted draｗｉng;ａs-built draｗｉngﻫ图名title
图号drａwnＮｏ.
比例scａleﻫ温度temperatureﻫ设计温度desｉｇntempeｒatureﻫ湿度humｉdity
流量floｗﻫ流速ｆlｏｗvｅlociｔｙ
6）凹面法兰: FEMAＬＥＦLＡＮＧＥ(FM FLANＧE)
７)榫面法兰: TONGUE FLANGE (T FＬANＧE)ﻫ８)槽面法兰：GRＯOVEＦLANGE（ＧFLANGE)ﻫ 9）法兰盖：BLIND FLANGＥ
1．2螺栓、螺母
１)螺栓：BOLT
2)双头螺柱: SＴUＤﻫ 3）螺母:NUＴﻫ１.3垫片GAＳＫEＴ
目录ﻫ1． 密封元件ﻫ１.1法兰、法兰盖ﻫ1.2螺栓、螺母ﻫ１．3垫片ﻫ1.3.1常用
土建词汇(英汉)
Aa flight of stairs 一段楼梯abaciscus 嵌饰abatis 杩槎abat-vent 固定百叶窗abode 住宅abscissa 横座标absolute construction 独立结构absolute height 绝对高度abut 支柱，柱脚abutting joint 对接接头acceptance 接受，同意，验收acceptance certificate 验收证书acceptance check 验收acceptance of concrete work 混凝土工程的验收acceptance of hidden subsurface work 隐蔽工程的验收acceptance specification 验收规范access 出（入）口，通路access board 便桥access corridor (platform bridge) from power block to office building on the operating floor 运转层上从主厂房到办公楼的交通走廊（天桥）access door 便门，检修门access eye 检查孔access gully 交通沟，窨井，雨水口access hole 检查孔access ramp 入口坡道access road 入口道路accessible duct 通行地沟accessories store 备品库accommodation ladder 舷梯accommodation road 专用道路accompanying diagram 附图accordion door 折叠门accordion partition 折叠式屏风acid brick 耐酸砖acid lining 耐酸衬砌acid resisting alloy 耐酸合金acid resisting cement 耐酸水泥acid resisting concrete 耐酸混凝土acid resisting stoneware 耐酸陶器acid waste 酸性废液acid-proof brick 耐酸砖acid-proof ceramic pipe 耐酸陶瓷管acid-proof mastic 耐酸胶泥acid-proof paint 耐酸油漆acid-proof varnish 耐酸清漆acid-protection coating 耐酸涂层acoustic absorbent 吸音材料acoustic construction 隔声构造acoustic design 声学设计，音质设计acoustic disturbance 声干扰acoustic felt 吸音毡acoustic field 声场acoustic plaster 吸音灰膏acoustic tile 吸音砖acoustic treatment 防声处理acoustic vault 吸声穹窿acoustical board 吸音板acoustical tile ceiling 吸音砖平顶ACP (asbestos cement pipe) 石棉水泥管across bulkhead 横向隔墙across grain 横向木纹acting surface 作用面actinic glass 光化玻璃，闪光玻璃action of gravity 重力作用action of pile group 群桩作用action radius 作用半径activated carbon 活性碳active fault 活动断层active pressure 主动压力active storage 有效容积，有效库容active thrust of earth 主动土压力actual load 实际荷载acute arch 尖拱，锐拱adamant 硬石，金刚石adamic earth 红粘土addendum 附加物，齿顶，附录，补遗addition of clay 掺粘土addition of sand 掺砂additional disturbing force 附加扰力additional load 附加荷载additional pipe 支管，接长管additive alternate 补充比较方案A-derrick 人字起重机，动臂起重机adfreezing force 冻附力adhesion 粘着力，附着力adhesion agent 胶粘剂，粘着剂adhesive 胶合剂，粘合剂adhesive bitumen primer 冷底子沥青adhesive coating 粘附层adhesive film 粘附膜adhesive strength 粘结强度adhesive tape 胶带adhesive water 吸附水，附着水，薄膜水adhesive wax 封蜡，胶粘蜡adit collar 支洞洞口，平洞洞口adit entrance 坑道入口adit opening 坑道入口adjacent accommodation 邻近建筑物，厢房adjacent block （混凝土）相邻浇筑块adjacent country 相邻地区adjacent lifts （混凝土）相邻浇筑层adjacent map 相邻图adjacent plank 踢脚板，门头线，门框边挺adjoining building 邻近房屋adjustable louver 可调百叶窗adjustable prop 可调支柱adjustable shelf 活动架adjustable shore 可调支撑adjustable sieve 可调筛adjustable spanner 可调扳手，活动扳手adjuster for windows 撑窗杆adjusting device 调节装置adjusting key 调整健adjusting link 调节联杆adjusting nut 调整螺母，调节螺母adjusting rod 调整杆，调节杆adjusting screw 调整螺钉，校整螺钉adjusting shuttering 活动模板adjusting wedge 调整锲块administration building 行政办公楼administration office 行政办公室admixture 掺合料adobe 灰质粘土，砖坯，风干砖，砖坯房，土墙adobe construction 土坯建筑adobe wall 土坯墙adretto 阳坡adumbral 遮阳的adumbration 轮廓，草图，速描advance angle 前置角adverse wind 逆风adz 刮刀，扁斧，锛子adz plane 刮刨adz-eye hammer 小铁锤AE (air entraining) 加气，掺气AE (architect engineering) 建筑工程（公司）aeolian 风成的，风积的aeolian material 风积物aeolian soil 风积土aerated concrete 加气混凝土aerated concrete block 加气混凝土砌块aerial 架空的，空气的，架空线，天线aerial cable 架空电缆aerial cableway 架空索道aerial conductor 架空电线，明线aerial conveyer 架空输送机aerial ladder 架空消防梯aerial lighthouse 航空灯塔aerial map 航测图aerial perspective 空中透视aerial railway 高架铁道aerial ropeway 架空索道，空中缆道aerial ropeway conveyer 架空索道输送机aerial survey topographical map 航测地形图aerial tramway 架空电车道，高架电车道aerial view 鸟瞰图aerial wire 天线，架空线aeroconcrete 加气混凝土aerocrete 加气混凝土aeroview 鸟瞰图aesthetic standard 审美标准after contraction 残余收缩after flow 残余塑性变形，蠕变after quake 余震after shock 余震after shrinkage 后期收缩after tack 软化，回粘after treatment 二次处理after-working 后效age dating 年代测定，年龄测定age hardening 时效硬化age of concrete 混凝土龄期age of specimen 试件龄期aged cement 老化水泥ageing crack 自然裂纹，时效裂纹ageing resistance 抗老化性，耐久性agglomerate 聚集，结块，团块，烧结块agglomerate-foam concrete 烧结矿渣泡沫混凝土aggradation 淤积，淤高，填积aggradation plain 沉积平原，淤积平原aggraded flood plain 洪积平原aggregate 骨料aggregate bin 骨料仓aggregate chips 石屑aggregate gradation 骨料级配，骨料分级aggregate grading 选配集料，集料级配aggregate reclaiming plant 骨料场，砾石料场aggregate roofing surface 骨料屋面aggregate size 骨料粒径aggregate-cement ratio 骨料水泥比，骨灰比agitating device 搅拌装置agitating lorry 搅拌车agitating truck 搅拌车agitation 搅拌，搅动，拌和agitation dredging 搅动挖泥agitator 搅拌机agraff 搭钩，搭扣A-horizon 表土层，上土层aiguille 钻头，钻孔器aiming light 标灯aiming line 瞄准线aiming post 标杆air brick 空心砖air bubble 气泡，砂眼air casing 气隔层air cavity 气穴，空穴air cement gun 水泥喷枪air channel 通风道，排气道air chimney 通风道，排气道air chute 通风道，排气道air compressor station 空气压缩机房air flue 气道，风道，烟道air hammer 气锤air painter 喷漆设备air passage 通风道，排气道air pick 风镐air pile hammer 气动打桩机air pit 通风井air pocket 气穴，气孔，麻点air rammer 气动夯锤air receiver 储气罐air stopping 挡风（墙）air tamper 气动夯锤air void 气孔，空隙air void ratio （土的）空隙比air well 通风井air-curing 空气养护air-free concrete 密实混凝土air-inflated structure 充气结构air-intake shaft 通风竖井，进气竖井air-placed concrete 气压浇注混凝土air-tight door 密封门airway 通气孔，风道，航空线aisle 通道，过道，走廊aisle gradient 通道坡度aisle wall 过道墙alameda 林荫散步道albanite 地沥清albertite 黑沥清albronze 铝青铜，铜铝合金alclad 镀铝的，包铝的，衬铝alfalfa gate 金属板滑动门，螺旋式闸门alignment 定线，找平，对齐alignment design 定线设计alkali earth 碱（性）土all-brick building 全砖建筑all-concrete 全混凝土的allen screw 六角固定螺钉alley-stone 矾石all-haydite concrete 全陶粒混凝土alligator-hide crack 龟裂alligatoring 龟裂，表面裂痕all-in aggregate 毛骨料allowable amplitude 容许振幅allowable bearing capacity 容许承载力allowable bearing pressure 容许承载力allowable error 容许误差allowable factor of safety 容许安全系数allowable flexural stress 容许弯曲应力allowable load 容许荷载allowable pile bearing load 单桩容许荷载allowable pressure 容许压力allowable settlement 容许沉降量allowable strength 容许强度allowable stress design (ASD) 许用应力设计allowable value 容许值alloy 合金alpine road 高山道路alpine valley 高山河谷alternate bay 隔仓alternate design 比较设计（方案）alternate joint 错缝，错列接头alternate layout 比较设计（方案），比较布置（方案）alternate load 交变荷载alternate tooth slot 交错齿缝alternating bending 反复弯曲alternating load 交变荷载alternating motion 往复运动alternating stress 交变应力altitude 高程，海拔，高度altitude difference 高度差altitude gage 高度计，测高仪altitude level 测高水准仪alum 明矾，硫酸铝aluminium frame door 铝框门alure 廊道，通道，院廊ambient temperature 环境温度，室温ambulatory 回廊，步道amended plan 修正计划，修正平面图amount of precipitation 降雨量amplitude of vibration 振幅amusement hall 娱乐厅anchor 地锚anchor bar 锚固筋anchor bolt 地脚螺栓anchorage 抛锚，锚固，锚具，锚座anchorage beam 锚梁anchorage bearing 锚座anchorage block 锚墩，锚块anchorage cable 锚索anchorage length 锚固长度anchorage pier 锚墩anchored sheet piling 锚定式板桩ancon 肋托，悬臂托梁angle 角钢angle bar 角铁，角钢angle bead 护角，角条angle bond 角砌合，墙角拉筋，角形弯条angle brace 角撑angle branch 弯管，肋管angle catch 窗插销angle cleat 连接角钢angle fillet 三角焊缝，三角形盖板angle of repose （堆料的）安息角，休止角annex room 前室，辅助小室anodized natural aluminium colour 阳极化处理天然铝色an-seismic 抗震的anta 壁端柱antechamber 前厅，接待室antefix 檐口饰antehall 前厅anteklise 台背斜，陆背斜anteport 外门，外槛anteroom 前厅antesolariun 朝日阳台ante-venna 遮阳板，遮阳棚anti-abrasive 耐磨损的antibreaker 防碎装置anti-checking iron 扒钉，防裂钩anti-corrosion 防腐蚀anticorrosive paint 防腐涂料，防锈油漆anti-dazzle lighting 防眩灯光antidetonation 防爆，抗爆antidetonator 防爆剂，抗爆剂anti-dirt 防尘antidrip 防滴，防漏antifatigue 耐疲劳anti-fluctuator 缓冲器antifrost 防冻的，防霜的antiknock 减振，消振antinoise 防噪声的，抗噪声的anti-overloading 防过载的antioxidant 抗氧化剂，防老化剂antipollution 防污染antiputrefactive 防腐的antiresonance 防共振，防共鸣anti-rolling 防滚动的antirot 防腐的antirust 防锈的antirust coat 防锈涂层antirust composition 防锈混合剂antirust grease 防锈脂antirust oil 防锈油antirust paint 防锈漆，防锈涂料antirust solution 防锈溶液antirust varnish 防锈清漆antiscale 防垢antiseep collar 防渗环antiseepage 防渗漏anti-seismic 防震的，抗震的anti-seismic joint 抗震缝anti-settling agent 抗沉淀剂anti-shrink 抗缩的，耐缩的antiskid 防滑，抗滑anti-slide pile 抗滑桩anti-sludge 抗淤沉，去垢anti-superheating 防止过热（装置）anti-symmetrical load 反对称荷载，不对称荷载antisyphonage pipe 反虹吸管anti-thrust 止推的anti-wind beam 抗风梁anvil 铁砧，砧座，基准面，平台anvil block 砧座apatite 磷灰石aperture 小孔，壁孔，开口，缝隙apex angle 顶角apex of arch 拱顶A-pole A形柱apomecometer 测距仪aposandstone 石英岩appearance of fracture 断口形状，断口外观appentice 厢房，耳房apple coal 沥清煤application of force 施力application of load 施加荷载application program 应用程序applied force 外加力applied load 外加荷载applied moment 外施力矩applied thrust 外施推力approach bank 引堤approach bridge 引桥approach channel 引水渠，引航道，进港航道approach cutting 进洞引道挖方，引桥挖方approach embankment 引道路堤approach fill 引道填方，引桥approach ramp 引道斜坡段，引桥坡道approach road 引路，引道approach segment 临近段，临近部分approach sign 引道标志approach span 引桥跨，岸跨approach trench 交通沟，窨井，雨水口approach trestle 引道栈桥approach viaduct 高架引桥apron 散水apron flashing 遮檐板，披水板apron piece 遮檐板，披水板apron space 码头前沿区apron stone 护脚石apron wall 前护墙apse 半圆室apse-buttress 半圆室支墩apsidal 半圆室的apt (apartment) 一套房间，公寓apteral 无侧柱的aqua storage tank 储水池aqueduct bridge 渠桥，渡槽araeosystyle 对柱式的，对柱式建筑物arc melting 电弧溶化arc welding 电弧焊arc welding set 电弧焊机arcade 有拱廊的走道arcaded 有拱廊的，有拱顶的arch 拱arch abutment 拱座，拱坝坝肩arch bar 拱板arch barrel 拱形筒壳arch block 拱块，拱面石arch bond 拱砌合arch brick 拱形砖arch bridge 拱桥arch buttress 拱形支墩arch camber 拱矢，起拱arch cover 拱板，拱形屋盖arch crown 拱冠，拱顶arch falsework 拱形脚手架arch hinged at ends 双铰拱arch in trellis work 格形拱arch limb 拱翼arch-braced roof 拱支屋顶arch-core 拱心arched 起拱的arched dome 圆顶穹窿arched roof 拱形屋顶arch-flat 平拱arching 架拱，形成拱状，起拱作用archit (architecture) 建筑学architect 建筑师architective 建筑的，关于建筑的architectonic 建筑术的，构造的，结构的architectonics 建筑原理，建筑学，建筑设计，结构设计architectural 建筑上的，建筑学的architectural appearance andelevational treatment 建筑外观和立面处理architectural compatibility 建筑调和性，建筑协调性architectural complex 建筑群，建筑综合体architectural composition 建筑构造architectural design 建筑设计architectural ornament 建筑装饰物architectural style 建筑风格，建筑式样architectural treatment 建筑处理architecture 建筑学，建筑艺术architrave 框缘，（柱的）下楣，嵌线archives 档案，档案馆archway 拱廊，拱道archy 拱形的arciform 拱形的，弓形的arcuated 拱式的，弓形的are 公亩（等于100平方米）area drain 露天排水斗，地面排水沟area grating 阴井格盖area load 面荷载area method 面积法area of building 建筑面积area of pile head 桩头面积area of pumping depression 抽水降水区，抽水漏斗区area of reinforcement 钢筋面积area of section 截面积area of steel 钢筋面积area of structure 构筑物面积area of supply 补给区，补给面积area-moment method 力矩面积法，面积法areaway （建筑物之间的）通道，（地下室前的）空地arenaceous 砂质的，多砂的arenaceous limestone 砂质石灰岩arenaceous quartz 石英砂arenaceous rock 砂质岩arenose 粗砂arenyte 粗屑岩，砂粒岩argil 白土，陶土，矾土argilla 陶土，高龄土，铝氧土argillaceous 泥质的，含陶土的，粘土质的argillaceous rock 泥质岩argillaceous sandstone 泥质砂岩arid 干旱的arm 杆，臂，支架，扶手arm crane 悬臂式起重机arm of balance 平衡臂，秤杆arm of couple 力偶臂arm of force 力臂arm of wheel 轮辐armature 电枢，加强料，钢筋，附件arm-brace 撑脚armchair 扶手椅armor coat 护层armor course 道路护面层armor layer 护面层armor-clad 铠装的armored 包铁皮的armored concrete 钢筋混凝土armored door 装甲门，防火门armored glass 钢化玻璃，防弹玻璃armored wood 包铁木材armrest 扶手，靠手arm-tie 横臂拉条，斜撑，拉板arrangement drawing of the power plant area 电厂厂区布置图arrangement of the underground facilities for the power plant area 电厂厂区地下设施布置arrester 避雷器arris 棱（角），尖脊arris gutter V形檐槽arris of joint 接缝圆角arris of slab 板棱，板肋arris rail 三角轨arris-wise 成对角方向（砌砖）arroyo 干河道，旱谷，小河ARS (asbestos roof shingle) 石棉屋顶瓦art glass 彩色艺术玻璃arterial canal 干渠，总渠arterial drain 排水干沟arterial highway 干线公路arterial railway 干线铁路arterial road 干线道路arterial street 干线街道，主要街道artery 干线，大道，大路，动脉artesian (flowing) well 自流井artesian fountain 自喷喷泉artesian ground water 自流地下水articulated 铰接的articulated construction 装配式结构，活节式结构articulated dumper 铰接式翻斗车articulation 铰，关节，接合（方式）artificial 人工的，人造的artificial ground 人工地基artisan 技工，工匠artistry 艺术形，艺术手法，效果as per ... 按照...asb (asbestos) 石棉asbestic tile 石棉瓦asbeston 防火布asbestonite 石棉绝热材料asbestophalt 石棉沥青as-built drawing 竣工图ascent 爬高，上升，坡度，斜坡，（一段）阶梯as-dug gravel 原状砾石aseismic design 抗震设计aseismic region 无地震区aseismic structure 抗震结构aseptic 无菌的，防腐的，防腐剂ash 灰，粉尘，火山灰，煤渣，槐木ash bed 火山灰层ash bin 出灰桶，垃圾桶ash can 垃圾桶ash cellar 灰坑ash dump 灰堆ash hole 出灰口ash sluicing pump house 冲灰泵房ash water pump house 灰水泵房ashl (ashlar) 琢石，方石，条石，（装饰墙面的）石板ashlar facing 琢石镶面ashlaring 砌方石墙面，贴方石墙面ASL (above sea level) 海拔高度aspect 方向，方位，状况，形状，外观aspect of slope 坡向aspect ratio 长宽比，长径比，形态比asphalite 沥青矿，沥青岩asphalt base oil 沥青冷底子油asphalt board strip 沥青填缝条asphalt built-up roofing 沥青组合屋面asphalt felt 油毛毡asphalt jute cloth 沥青黄麻布assembling jig 装配机架，装配夹具assembling joint 装配接头assembly drawing 装配图，组装图assembly shop 装配车间assessable land 可征土地asymmetric configuration 不对称结构at one pouring 一次浇灌at one’s own cost (expense) 由某人自己出钱at one’s own risk 承担风险，（损失）自己负责ATC (acoustical tile ceiling) 吸声砖吊顶ATF (asphalt tile floor) 沥青砖地面atomizing spraying 雾化喷涂atrium 天井，前厅，门廊attached building 附联建筑物，配套建筑物attached pier 扶垛，支墩attachment link 连接杆attachment screw 连接螺钉，止动螺钉attic 顶楼，阁楼，屋顶室attic story 阁楼，屋顶层attle 废矿渣audience chamber 接见室，会见室audience room 接见室，会见室auditorium 大会堂，音乐厅auger 螺旋钻，麻花钻auger bit 螺旋钻头auger hole 钻孔auger stem 螺旋钻杆auget 雷管austral window 南窗，滑动窗，推拉窗autobahn 高速公路，快车道autocrane 汽车式起重机automatic door 自动门auxiliary stair 便梯auxiliary station 副厂房auxiliary structure 辅助建筑avalanche 崩落，崩塌，雪崩avalanche baffle 塌方防御设施avalanche control works 防崩工程avalanche defence 防塌，崩塌防护avalanche prevention works 防坍工程avenue 林荫道，道路，（南北向）街道average annual precipitation 平均年降水量average annual rainfall 平均年降雨量average annual runoff 平均年泾流量average grading 平均级配average grain diameter 平均粒径avoid any glare on the panels 避免盘上有任何眩光award of contract 签订合同awn (awning) 遮篷，凉篷，雨篷awning type window 篷式窗axed arch 斧斩拱面axial compression 轴向压缩，轴向受压axial elongation 轴向伸长axial force 轴向力axial load 轴向荷载axial strain 轴向应变axial stress 轴向应力axial symmetry 轴对称axial tension 轴向拉伸，轴向受拉axial torque 轴向转矩，轴向扭矩axial translation 轴向位移axis 轴，轴线axisymmetric 轴对称的axonometric projection 三向投影，不等角投影axonometry 轴测法，三向正投法azimuth 方位角，地平经度azimuth mark 方位标azimuth-elevation 方位-高程azimuth-range 方位-距离azure spar 天兰石azure stone 天兰石，青金石BB&S (beam and stringers) 横梁与纵梁back arch 拱背，墙内暗拱back bead 封低焊道，填角焊缝back brace 后部斜撑back coat 底层涂料back cutting 回挖，必要的超挖部分back drain 墙背排水管back elevation 后视图back filling 回填土back flap 里扉，里垂帘back guy 拉揽，牵索back heading 通风巷道back house 后屋back joint 待填槽back leg 背面支柱back lining 背衬，背衬料back nail 平钉back nut 防松螺帽，反向螺帽back of arch 拱背back of levee 堤背back shop 修理厂，修理车间back shore 背撑，顶撑back shutter 里百叶窗back stair 后楼梯back view 后视图，背视图back wall 后墙，胸墙backboard 底板，后板，背靠，背后挡板backbone 骨干，骨架，构架，主干backbone road 干道backer 支持物，衬垫物backer brick 墙心砖，背衬梁backfill 回填土back-filled 回填backfilling tamper 回填夯back-flap hinge 明铰链backform 后模，顶模backhaul cable 后拖缆绳backing 反向，后退，支架，靠背，背衬，里壁backing brick 墙心砖，背衬砖backing of veneer 饰面板里层backing of wall 墙托backing of window 窗托backing plank 衬板backing sand 填充砂backing strip 垫板back-land 腹地，后方backplan 底视图backsetting （砌墙）收进backstay 拉索backstay anchor 拉索锚定backstay cable 拉索backstop 托架，止回器，后障back-to-back angles T形组合角钢，背靠背组合角钢back-up brick 墙心砖，衬里砖back-up plate 垫片backyard 后院，后天井badigeon 油灰badland 荒原，瘠地，崎岖地badly graded sand 级配不良砂baffle board 挡板，折流板，隔音板baffle mixing chamber 隔板式混合池baffle pier 消力墩，分水墩baffle plate 挡板，隔板，遮护板，折流板，门槛baffle reaction chamber 隔板式反应池baffle sill 消力槛，门槛baffle structure 消力设施，消力建筑物baffle wall 消力墙，分水墙baffler 挡板，隔墙，消声器，导流板，消力器baffle-type 挡板式的，百叶窗式的bag dam 土袋埝坝bagged cement 袋装水泥baghouse 集尘室，沉渣室bagwork 砂包，袋装干拌混凝土bail 戽斗，桶，横木，吊环，钩，卡钉bailer 水斗，泥浆泵，抽泥桶bailey bridge 活动便桥bailey span 贝利式（桁架）桥跨bailey truss 贝利式桁架bakelite 酚醛塑料，胶木，电木baking finish 烤漆，烘漆balance cuts and fills 均衡挖填，挖填土方平衡balance of arch 拱脚balanced earthwork 平衡土方工程balanced sash 平衡式窗框，平衡式窗扇balanced step 均衡踏步，平衡阶梯balconied 有阳台的balcony 阳台baling 脚手杆balk 大梁，枕木balk board 隔板，障碍板，防护板balk roofing 重屋面ball bonding 球焊，球形接头，铰节ball flower 圆球饰ball joint 球节，球窝接头ballast 压舱物，压块，道渣，碎石，石渣ballast bed 石渣路基ballast chamber 压块室，平衡重室ballast concrete 石渣混凝土ballast road 石渣路ballasted 铺道渣的ballasted deck 铺道渣（铁路）桥面ballasted floor 铺渣桥面balling-up of cement 水泥（受潮）起球balloon construction 轻型构造，轻型结构balloon frame 轻型骨架balsa wood 轻木，软木Baltimore truss 平行弦再分式桁架baluster 栏杆小柱baluster column 栏杆柱baluster railing 立柱栏杆balustrade 栏杆，扶手bamboo 竹材bamboo concrete 竹筋混凝土bamboo fence 竹篱笆bamboo scaffolding 竹材脚手架band and gudgeon 长铰，大门门铰band iron 扁铁条，（窄）带钢band molding 带状线脚band rope 扁钢丝绳band tape 卷尺bandage 绷带，防潮带，铁箍，纽绳banded architrave 带饰门头线banded column 带饰柱，箍柱banded penstock 加箍压力钢管banded steel pipe 加箍钢管bandlet 细带banister 栏杆小柱banister brush 软毛刷banjo fixing 对接接头bank caving 淘岸，塌岸bank cutting 河岸侵蚀bank erosion 堤岸冲刷bank grading 河岸修坡bank gravel 河卵石，河岸砾石bank measure 填方数量bank paving 护岸bank protection 护岸（工程）bank revetment 护岸bank seat 河岸（加固）桩bank yards 未扰动土石方量（以立方码计）banked 筑有堤的，筑成堤状的，倾斜的banked earth 储存土（填土用）bankette 弃土堆，填土，护坡道bankhead 丁岸，岸首，坑口banking 筑堤，填土，堆积，斜度bank-run 河岸边的banquette 弃土堆，护坡道，凸部，窗口凳，人行道bar 钢筋bar bender 钢筋弯曲工，弯筋工bar chair 钢筋支座bar chart 柱状图，条形图bar cropper 钢筋剪断机bar cutter 钢筋剪断机bar drill 杆钻bar mat 钢筋网bar screen 格栅，格网，铁栅筛bar shape （棒形）型钢bar steel 棒钢bar stock 棒材，条材bar support 钢筋座bar tracery 铁杆窗格bar with hooked end 带钩钢筋barb bolt 刺螺栓，地脚螺栓barbed nail 刺钉barbed wire 刺铁丝bar-bending schedule 钢筋表bare-cut slope 新开挖的边坡bare-faced tenon 裸面榫头bare-faced tongue 裸面榫舌barge board 挡风板，山墙封檐板barge couple 山墙上的橼barge course 山墙沿瓦，山墙沿石板barge stone 山墙凸石，封檐石barn truss 三铰构架式桁架barracks 工棚，临时工房barrage 拦河坝，拦河闸，挡水建筑物，障碍物barred door (gate) （无门板）栅门barrel vault 筒壳barren 荒芜的，贫瘠的，多孔的，不毛之地barricade 路障，栅栏，隔板，挡墙barrier 障碍物，栅栏，隔板barrier layer 阻隔层barycenter 重心，质心basal disc 基盘basalt 玄武岩base 底板，底座base block 柱脚石，门基石base brick 碱性砖base coat 底涂层base course 基层，底层，下垫层base court 里院base failure 基础破坏base flashing 基层泛水base frame 底座，支架base lacquer 底漆base level 基准面base load 基本荷载base map 底图，工作草图base molding 底座线脚base plate 底板，地脚板base rock 基岩base treatment 地基处理base-bar 基线杆baseboard 护壁板，踢脚板basement 底层，地下室basement complex 基底杂岩basementless 无地下室的basic earthquake intensity 基本地震烈度basic load 基本荷载，主要荷载basic wind speed 基本风速basin room 洗餐具室basket 花篮状柱头，篮，吊篮，铲斗basket capital 花篮状柱头basket handle arch 三心拱basswood 椴木bastard pointing 粗嵌缝bastard stucco 粗粒水泥粉刷bastard tuck pointing 粗嵌灰缝bat 板条，挂瓦条batch bin 配料仓batch box 配料量斗batch of concrete 分批（拌和的）混凝土batch of mortar 分批（拌和的）砂浆batch plant 配料装置，拌和厂，拌和楼batched water （混凝土）一次拌和用水batching plant （混凝土）拌和厂，拌和楼bate pits 脱灰，脱斑bateau bridge 浮桥batement-light 跛窗bath closet 浴池更衣室bathroom 浴室bathtub 澡盆，浴缸bathymetric line 等深线batten 板条，挂瓦条，压缝条batten board 板条心胶合板batten door 板条门batten ends 短板条（铺地板用）batten floor 木条地板batten plate 缀合板batten plate column 缀合柱（缀板式）batten sheet piling 打板条桩battened partition 板条隔墙battened strut 钉板条的支柱battened wall 板条墙battening 钉板条batter （墙壁）内倾，倾斜，斜坡batter board 龙门板，定位板batter brace （桁架）斜撑batter leg tower 斜柱塔架batter pier 斜面桥墩batter post 斜柱battered pilaster 斜面壁柱battering wall 倾斜墙battery room 蓄电池室battlement 城墙垛bauxite 铝矾土bay 开间，跨度，柱距bay delta 海湾三角洲bay harbor 港湾bay wall 池墙bay window 凸窗，八角窗bayonet 接合销钉，卡口bayonet fixing 卡口式固定，管脚固定bayou 牛轭湖，河川支流BB (baseboard) 踢脚板be compacted at optimum moisture content 以最优含水量压（夯）实be in harmony with the architectural design of ... 与...的建筑设计相协调be located at (in) ... 位于...，座落在... be responsible for ... 对...负有责任，担负，是（造成）...的（主要）原因beacon 标志(桩），指示标，灯塔，信号塔bead 焊珠，墙角圆bead joint 圆凸勾缝beading fillet 凸圆线脚，半圆饰边beak 柱尖，壳尖beam 梁beam and girder construction 主次梁结构beam and girder floor 主次梁式楼板beam bearing block 梁垫块beam of variable cross-section 变截面梁beam on elastic foundation 弹性地基梁beam pad 梁垫beam with fixed ends 固端梁beam with simply supported ends 简支梁beam-column 梁柱，偏心受力柱beams with one overhanging end 悬臂梁beard 倒钩bearer 载体，支座，托架，承木bearing course 承重层bearing pile 支承桩bearing plate 支承垫板，承重板bearing pressure 承压力bearing wall 承重墙bearing-type high strength bolt 承压型高强度螺栓beautification 美化，装饰beaver board 木纤维板becket 环索，绳环bed course 垫层bed molding 深凹饰bed of brick 砖铺垫层bed piece 垫板，底板，座板bed soil 地基bed timber 垫木，枕木bedding 基底，垫层bedding mortar 垫层砂浆bedding of brick 砖铺垫层bedding slip 层面滑动beech 山毛榉beef wood 硬红木beetling cliff 悬崖beetling wall 峭壁Belfast roof truss 弓形屋顶桁架Belfast truss 弓形桁架bell end 承插端，扩大端belled-out pile 扩底桩，扩孔桩belled-out pit 扩大竖井belled-out section 扩大断面bell-mouthed opening 漏斗口bell-shaped capital 钟形柱头bellying in 向内凸胀bellying out 向外凸胀below ground 地面以下below-norm 限额以下belt 地带，环形铁路belt conveyor floor 运输皮带层belt heading 运输巷道belt highway 环路，带状公路belt line 环形线belt of weathering 分化带belting course 带状层，垫层bench blasting 阶梯式爆破，台阶式爆破bench cut 阶梯式开挖，台阶式开挖bench excavation 阶梯式开挖bench flume 支架式渡槽bench land 台地bench mark 水准点，基准点bench method 台阶式挖土法，分层开挖法bench section 横断面bench slopes 台阶式边坡bench terrace 梯田，台地，阶地bench wall 拱座benched 阶梯式的，台阶式的benched foundation 阶梯式基础benchtop cave 半敞开小室bend in river 河湾，河曲bending 弯曲bending moment 弯矩bending moment envelope 弯矩包络线bent 弯曲，弯头，排架bent frame 排架bentonite 膨润土，斑脱土，斑脱岩bent-up bar 弯起钢筋berm 护坡道，（公路两旁的）路肩berth 停泊处，泊位berthage 泊位，停泊费besel 监视窗，监视孔betterment 改善，改进，改良，修缮和扩建bevel 斜面，斜角，倾斜，斜削beveled edge 斜削边，坡口边，倒斜板边bevelled sleeper 楔形垫木bias torque 偏转力矩bicable ropeway 双揽索道biconcave 双面凹的biconvex 双面凸的bifurcated line 分叉线bifurcation structure 分叉结构，分水结构big-end-down 上小下大的big-end-up 上大下小的bike shed 自行车棚bilection 凸出嵌线bilevel 错落式住宅bilge 弯度，矢高，拱度，鼓胀，突出，舱底bill of quantities 工程量表bimoment 双力矩bin 料仓，料斗，斜坡道bina 坚硬粘土岩bind 结合，粘合，系杆，撑条，胶泥，页岩binder 粘合剂，系梁binding agent 粘结剂binding beam 联接梁binding bolt 连接螺栓binding power 结合力，粘合力binding rivet 结合铆钉，紧固铆钉binding screw 结合螺钉，紧固螺钉biparting doors 双扇门，对开门bipod 双脚架birch 桦木bird’s-eye view 鸟瞰图bitulith （路面用）沥青混凝土bitulithic pavement 沥青混凝土路面bitumen 沥青bituminous felt 石油沥青油毡black and white work 木石构造blackout building 无窗房屋blacksmith shop 锻工车间blading compaction 刮平压实blank arcade 封闭拱廊，假拱廊blank arch 轻拱，假拱，装饰拱blank door 假门，暗门blank wall 无门窗的墙blank window 假窗，暗窗blanket area 覆盖面积blast-furnace cement 高炉矿渣水泥blast-resistant door 防爆门bleeding cement （混凝土）水泥浮浆bleeding of concrete 混凝土泌浆（现象）blind balustrade 实心栏杆blind ditch 暗沟，盲沟，填碎石的排水沟壑blind door 百叶门，暗门，装饰门blind drain （排水）暗沟blind drainage 暗沟排水blind tracery 实心窗格blind wall 无窗墙blind window 百叶窗blinding 堵塞，填塞，盖土，填砂石blinding concrete 盖面混凝土，填充混凝土blinding layer （基础）垫层blinding material 透水填料，暗沟填料blister 气泡，气孔，起皮block 块体，砌块，街区，大楼block and cross bond 丁砖与顺砖交叉砌合block bond 丁砖与顺砖隔层砌合block bridging 横撑block capital 方块式柱头block cast 整铸block caving 大块坍落block construction 大型砌块结构block joint 预留砖孔，预留混凝土块孔（作接头用）block lining 混凝土板块衬砌block mount 组合装配block out 画草图，拟计划block placement （混凝土）分区浇筑block plan 分区平面block up 堵塞，垫高blockage 堵塞，封闭，锁定，障碍物，小方石blocked course 块状砌物blocked fault 块（状）断层blocked finish （混凝土）表面磨光（用金刚砂）blocked joint 分段连结blockglide 块状滑动，地块滑坍blockhouse 木屋，工棚，砌块屋，地堡，水泥掩体block-in-course 嵌入锲块层，成层砌石块体blocking 阻塞，分段，分块，压檐墙blocking level 阻挡层blockyard （混凝土）预制构件厂blue brick 青砖blueprint 蓝图，晒图bluff 悬崖，陡壁，天然陡坡bluff work 边坡整平工作board 木板boarding 隔板，镶板，地板，板条，起纹board-rule 量木尺boasted ashlar 粗凿石板boasting （石料的）粗琢boatswain’s chair 高处工作台（绳系吊板）bob 秤锤，悬锤bobtail truss 截尾桁架body brick 优质烧透砖body case 壳体，外壳body of ballast 道渣层body plan 正面图body stress 自重应力boiler house 锅炉房Bollman truss 包尔曼桁架（多弦三角形桁架）bolster 垫枕，垫块，支撑物，承梁板，托木bolt 螺栓，插销，门闩bolt head 螺栓头bolus 团块，胶块土，陶土bond 粘合，砌合，胶结，粘合剂，粘合力bond beam 结合梁bond between concrete and steel 钢筋与混凝土的结合力bond open 焊缝裂开，焊接断开bond tile 搭接瓦bondability （钢筋与混凝土的）结合力，握裹力bonded roof 砌合屋顶bonded tendon 与混凝土结合的预应力钢筋束bonder 砌墙石，顶砖bonder wire （钢筋）绑扎钢丝bonding 支撑，加固，砖石砌体砌合bonding brick 空心墙连接砖，接合砖bone 骨架bonnet hip tile 屋脊弯瓦boom 吊杆，起重臂，钻架，横木，栏木，横江铁索boom net 栅栏网booth 小房子，小亭，公用电话亭，暗箱，窝棚border 边缘，框，壁，周界，国界，路缘，田埂border dike 围堤bordering 边界标志物，边，缘borderland 交界地区，边缘地bore pit 探井，钻探坑bored cast-in-place pile 钻孔灌注桩，钻孔桩bored pile 钻孔（灌注）桩borehole 钻孔borehole log 钻孔柱状图boring 钻探boring frame 钻探架，钻井架borrow 取土，采料，采料场borrow pit 取土坑，采料场bosom 对接连接角钢，角撑Boston caisson 管柱沉井施工法bottom chord 下弦bottom cut 底槽，下部掏槽bottom die 底模bottom door 排水底孔，清扫孔，底门bottom flange （梁的）底翼缘bottom view 底视图bottom rail （门窗的）下横档bottoming 石块铺底bottomland 盆地，洼地，滩地bottom-up 倒置，颠倒boundary wall 厂区围墙bow girder 弓形大梁bow member 弓形构件bowl 洼地box beam 箱形梁box cut 开挖槽box dam 整体围堰，箱式围堰，箱形坝box foundation 箱形基础box girder 箱形（截面）大梁box steel sheet piling 箱式钢板桩box strut 箱形（截面）支柱box-framed construction 箱形框架结构boxwood 黄杨木brace 支柱，支撑，拉板，系杆，曲柄braced 加支撑的，联接的braced core building 格架式筒体建筑bracing boom 加劲杆，支撑杆bracing in open cut 明挖支撑bracket 牛腿，托架bracket stringer 挑出式楼梯斜梁brad 土钉，角钉，曲头钉，无头钉brail 斜撑杆，斜撑梁brandreth 铁架，三脚架，井栏brash 崩解石块，破碎片，易碎的，脆的brass 黄铜brazed 铜焊的，硬焊的break ground 破土，动工breakdown point 屈服点，击穿点breaking load 破坏荷载breaking-in 插入，嵌入，breakjamb 门框边挺break-off 破坏，断开breakwind 防风墙，挡风罩breast 掌子面，侧面，梁底，窗腰breast molding 窗下墙线脚breast summer 托墙梁，过梁breeze block 水泥砖，煤渣石，（轻质）煤渣混凝土砌块brick 砖brick and reinforced concrete。
[专业词典] 施工图中英文对照词汇表精品文档14页
![[专业词典] 施工图中英文对照词汇表精品文档14页](https://img.taocdn.com/s3/m/8db647fed4d8d15abf234e37.png)
设计图layout；design施工图final平面图plan立面图elevation轴测图、透视图isometric drawing；detail drawing详图、大样图、接点图record drawing修改图竣工图as-completed drawing；as-built drawing 图名 title图号 drawn No.比例 scale温度 temperature设计温度design temperature湿度 humidity流量 flow流速 flow velocity摄氏温度centigrade scale(℃)华氏温度Fahrenheit scale(°F)公称直径nominal diameter(DN)外径 outside diameter(OD)内径 inside diameter(ID)一览表list；breviate；catalogue毛重 gross weight净重 net weight支座 saddle支架 support吊架 cradle间距 distance；clearance；spacing跨距 span焊接 welding焊缝 weld；welding seam；bead石棉水泥接口asbestos-cement joint青铅接口lead joint承口、大头 hub；bell；socket插口、小头 spigot压力试验pressure test水压试验hydraulic test渗漏 leakage关闭 close型号、类型 type；model尺寸、体积 size；volume额定功率rating power额定转速rotating speed授权经销商 authorized dealers原始设备制造商OEM (Original Equipment Manafacture)风机动力型V A V-CA V末端fan power V A V-CA V terminal units保持最新技术keep with the latest technology中国唯一的销售商 the sole Chinese distributor工程管理，设计，施工，服务，或者商务管理project management, design, construction, service, or business administration用于商业和工业空气运动与洁净室的环境控制系统Environment Control System for Commercial & Industrial Air Movement & Clean-rooms温湿度精确控制Precision Temperature & Humidity Control个性化温度控制Individual Zone Temperature Control节能 Energy Conservation能量管理系统Energy Management Systems中央冷冻系统Central Chiller Systems能量回收系统Energy Recovery Systems工作现场，工地jobsiteHV ACR系统与BAS/DDC控制系统之间的桥接装置A Bridge Role in HV AC & R System and BAS/DDC ControlHV AC总成本和投资估算Total HV AC cost and investment evaluation系统设计和应用System design and application系统和设备的选择、效率和运行成本System and equipment selection, efficiency and operating cost和其他工种的配合Coordination with other departments监督工程进度、分配时间和施工工作Monitoring project progress, delivery time and construction work设备购买，运输，质量保证 Appurtenances purchase, delivery and warranties执行设计计划并应对工程部门的检查Implementing the design plan and subject the work to the inspection of the Engineering Department目录1. 密封元件1.1 法兰、法兰盖1.2 螺栓、螺母1.3 垫片1.3.1 常用1.3.2 高压设备用2. 基础构件3. 梯子平台4. 设备常用零部件4.1 筒体封头4.2 支座4.2.1 鞍座、耳座裙座其它支座4.3 主要零部件5. 换热器专用名词6. 塔专用名词7. 图面节点术语及图面常用语7.1 节点术语7.2 图面常用语8. 技术要求及特性表中常用语9. 常用技术要求的英文译法10. 常用介质11. 其他1 密封元件1.1 法兰、法兰盖1）对焊法兰：WELDING NECK FLANGE2）平焊法兰：SLIP-ON FLANGE3）衬环法兰：CLADDED FLANGE4）突面法兰：RAISED FACE FLANGE (RF FLANGE)5）凸面法兰：MALE FLANGE (M FLANGE)6）凹面法兰：FEMALE FLANGE (FM FLANGE)7）榫面法兰：TONGUE FLANGE (T FLANGE)8）槽面法兰：GROOVE FLANGE (G FLANGE)9）法兰盖： BLIND FLANGE1.2 螺栓、螺母1）螺栓： BOLT2）双头螺柱：STUD3）螺母： NUT1.3 垫片 GASKET1.3.1 常用1）石棉橡胶板：ASBESTOS SHEET (OR GASKET)2）缠绕垫： SPIRAL WOUND GASKET3）橡胶垫： RUBBER GASKET4）金属包垫：METAL JACKETED GASKET5）石墨垫： GRAPHITE GASKET6）聚四氟乙烯：PTFE. GASKET(POL YTETRAFLUOROETHYLENE GASKET) 1.3.2 高压设备用1）铝平垫： ALUMINIUM PLAT GASKET2）透镜垫： LENS RING3）齿形垫： TOOTHED GASKET4）椭圆垫： OV AL RING5）八角垫： OCTAGONAL RING6）Ω垫：“Ω” GASKET7）双锥垫： CONICAL RING GASKET2 基础构件1）地脚螺栓：ANCHOR BOLT2）模板： TEMPLATE3）锚板： ANCHOR PLATE4）基础构件：FOUNDATION COMPONENT5）筋板： RIB3 梯子平台1）梯子： LADDER2）平台： PLATFORM3）钢隔板： GRATING4）槽钢梁： CHANNEL BEAM5）立柱： POST6）扶手： HANDRAIL7）扁钢： PLAT BAR8）踏步： LADDER RUNG9）连接板： CONNECTION PLATE (OR LUG)10）安全门： SAFETY CHAIN (链式) OR BAR11）角钢： ANGLE STEEL4 设备常用零部件4.1 筒体、封头1）椭圆封头：HEAD2）平盖： PLAT COVER3）半球形： HEMISPHERICAL HEAD4）碟形封头：DISHED HEAD5）锥形： CONICAL HEAD6）折边锥形：FLANGED & CONICAL HEAD7）锥段： CONICAL SECTION8）筒体： SHELL9）多层包扎筒体：LAYERED SHELL10）内筒： INNER SHELL11）层板： LAYER PLATE4.2 支座4.2.1 鞍座： SADDLE耳座： SUPPORT LUG (OR BRACKET)1）垫板： WEAR PLATE (OR PAD)2）底板： BASE PLATE3）筋板： RIB4）腹板： CELIAC PLATE4.2.2 裙座1）筒体： CYLINDER2）盖板： COVER PLATE3）底板： BASE PLATE4）垫板： PAD5）筋板： RIB6）通气孔： VENT HOLE7）进出口： ACCESS OPENING4.2.3 其他支座1）腿座： SUPPORT LEG.3 主要零部件1）接管： NOZZLE2）管台： NECK3）补强圈： REIN. RING4）加强圈： STIFF. RING5）铭牌： NAME PLATE6）接地板： EARTH LUG7）防冲板： IMPINGEMENT BAFFLE8）防涡流挡板：VORTEX BREAKER9）液位计： LEVEL GAUGE10）视镜： GLASSES11）补强管： REIN. NOZZLE12）筋板： RIB13）弯头： ELBOW14）管：PIPE15）垫板： PAD PLATE16）人孔： MANHOLE17）手孔： HANDHOLE18）组合视镜：COMBINED GLASSES19）内爬梯： INTERNAL LADDER20）内部扶手：INTERNAL HANDRAIL21）垫圈： W ASHER22）吊耳： LIFTING LUG23）管轴式吊耳：LIFTING TRUNNIONS24）板式吊耳：PLATE LIFTING LUG25）内件： INTERNALS26）支承圈： SUPPORT RING27）夹、卡子：CLIP28）保温圈： INSULATION SUPPORT RING29）弯管： BEND PIPE30）防火螺母：FIREPROOF NUT31）角钢： ANGLE STEEL32）管帽： PIPE CAP33）凸缘： PAD34）丝堵： THREADED PLUG35）一般挡板：BAFFLE36）预焊件： PREWELDED PARTS37）管架： PIPE RACK38）安全阀： SAFETY V ALVE39）除沫器： DEMISTER40）激冷环： QUENCH RING41）下降管： DOWNCOMER42）溢流管： OVERFLOW NOZZLE43）螺钉： SCREW44）铆钉： RIVET45）锚栓： ANCHOR46）销钉： PIN47）夹具： JIG48）填料箱： PACKING BOX49）填料压盖：PACKING GLAND50）填料： PACKING51）锥顶： CONE ROOF52）拱顶： COVE ROOF53）加热盘管或蛇管：COIL54）壁板： SHELL PLATE55）底板： BASE PLATE56）边缘板： SIDE PLATE57）中幅板： MIDDLE PLATE58）液封槽： LIQUID SEAL59）消防装置：FIREFIGHTING DEVICE60）排水槽： DRAIN61）夹套筒体：JACKET SHELL62）夹套封头：JACKET ELLIP HEAD63）插入管： SETIN NOZZLE64）复合板： CLAD PLATE65）衬里： LINING66）堆焊层： DEPOSITED LAYER67）高压筒体端部：SHELL END FLANGE68）高压螺栓：HIGH TENSION BOLT5 换热器专用名词1）管束： BUNDLE2）管板： TUBESHEET3）折流板： TRANSVERSE BAFFLE4）弓形折流板：SEGMENTAL BAFFLE5）支持板： SUPPORT PLATE6）换热管： TUBE7）定距管： SPACER8）挡管：DUMMY TUBE9）拉杆： TIE ROD10）防冲板： IMPINGEMENT BAFFLE11）滑道杆： GUIDE ROD (BAR)12）旁路挡板：SEAL STRIP13）分程隔板：PASS PARTITION14）壳体纵向隔板：LONGITUDINAL BAFFLE15）密封条： SEAL STRIP17）中间分流挡板：INTERMEDIATE BAFFLE18）浮动管板：FLOATING TUBESHEET19）浮头盖： FLOATING HEAD COVER20）浮头盖法兰：FLOATING HEAD COVER FLANGE21）钩圈： BACKING DEVICE22）平盖管箱：CHANNEL23）凸形封头管箱：CHANNEL24）外头盖： SHELL COVER25）防送支耳：ANTI-LOOSENING LUG26）防松螺栓：ANTI-LOOSENING BOLT27）环首螺钉：EYE BOLT28）顶丝： JACK SCREW29）膨胀节： EXPANSION JOINT30）波纹膨胀节：BELLOWS EXPANSION JOINT31）排污口： DRAIN32）放空口： VENT33）堰板： WEIR34）釜式锥段：CONICAL SECTION35）偏心锥段：ECCENTRIC CONICAL SECTION36）鞍座间调整垫板：SHIM PLATE6 塔专用名词1）塔盘： TRAY2）吊柱： DA VIT3）支持圈： SUPPORT RING4）降液管（板）：DOWNCOMER5）填料： PACKING6）填充物： FILLING7）分布器： DISTRIBUTOR8）再分布器：REDISTRIBUTOR9）泡罩： BUBBLE CAP10）浮阀： FLOA TING V ALVE11）溢流堰： OVERFLOW WEIR12）受液堰： SEAL PAN13）入口堰： INLET WEIR14）出口堰： OUTLET WEIR15）筛板： SIEVE PLATE16）内件： INTERNALS17）限位板： STOPPER18）拉杆： TIE ROD19）防溅溢流板：DECK20）碎流挡板：STREAM BREAKER21）预焊件： PREWELDED PART22）管架： BRACKET24）支承块： SUPPORT BLOCK25）就位吊耳：RETAINING LUG施工图图面节点术语及图面常用语7.1 节点术语1）壳体纵环焊缝：L&C WELD OF SHELL2）接管与筒体封头焊缝：NOZZLE “A” TO SHELL (HEAD) JOINT 3）接管与法兰焊缝：NOZZLE “A” TO FLANGE JOINT4）带补强圈接管与筒体封头焊缝：NOZZLE WITH REINF . RING TO SHELL(HEAD) JOINT5）管口方位图：NOZZLE ORIENTATION6）××剖面图：SECTION “××”7）××向视图：VIEW “××”8）法兰与筒体焊缝：FLANGE TO SHELL JOINT9）管板凸缘与筒体焊缝：TUBESHEET TO SHELL JOINT10）管支承拉筋详图：RIB DETAIL OF NOZZLE “A”11）搭接焊缝：LAP WELD12）搭接角焊缝：LAP FILLET WELD13）焊后磨平：RUBDOWN AFTER WELDING14）氩弧焊： TIG（TUNGSTEN-INERT-GAS）ARC WELD15）着色检测：PENETRANT EXAMINATION16）磁粉检测：MEGNETIC EXAMINATION17）×××详图：DETAIL OF ×××18）“U”与“U”焊缝：“U” TO “U” WELD JOINT19）“A”向折流板布置图：VIEW “A” BAFFLE ARRANGEMENT20）换热管与管板连接：TUBE TO TUBESHEET JOINT21）强度焊： STRENGTH WELDED22）密封焊： SEAL WELDED23）强度胀： STRENGTH EXPANDED24）贴胀： LIGHT EXPANDED.2 图面常用语1）装配图：ASS’Y DWG2）部件图：COM’T DWG3）零件图： PARTS DWG4）零部件图：PART & COM’T DWG5）内件图： INTERNALS DWG6）外部构件图：EXTERNALS DWG7）剖面： SECTION8）详图： DETAILS9）俯视图： VERTICAL VIEW10）侧视图： LATERAL VIEW11）固定端： FIXED SIDE12）滑动端： SLIDING SIDE13）镇静钢： KILLED STEEL14）沸腾钢： RIMMED STEEL15）不锈钢： STAINLESS STELL16）双向钢： DUPLEX STEEL17）热轧的： HOT-ROLLED18）冷轧的： COLD-ROLLED19）淬火的： QUENCH20）正火的： NORMALIZE21）退火的： ANNEAL22）回火的： TEMPER23）固溶： SOLUTION24）可拆的： REMOV ABLE25）手工电弧焊：SMAW (SHIELDED METAL ARC WELD)或MMAW (MANUAL METAL ARC WELD)26）埋弧焊： SUBMERGED ARC WELD27）定位焊： TACK WELD28）点焊： SPOT WELD29）连续焊： CONTINUOUS WELD30）间断焊： INTERMITTENT WELD31）焊后热处理：PWHT (POST WELD HEAT TREATMENT)32）红丹： RED-LEAD33）镀锌： GALV ANIZATION34）酸洗钝化：PICKLING35）泪孔： WEEP HOLE36）半圆孔： SEMICIRCLE37）长圆孔： LONG ROUND HOLE38）对开： OPPOSITE ORIENTED39）削薄过渡：TAPERED TRANSITION40）与封头内壁吻合：AS PER LOCATED INNER SUREFACE OF HEAD41）组焊后加工：MACHINED AFTER WELDING42）法兰密封面待组焊后加工：THE FLANGE SEAL SURFACE SHALL BE MECHINED AFTER WELDING 43）安装就位后点焊：SPOT-WELDED AFTER INSTALLATION44）热处理后加工：MECHINED AFTER PWHT45）（由）制造厂（决定）最终尺寸：FINAL DIMENSION BY MANUFACTURER46）衬里和填充料重量：LINING AND FILLING WEIGHT47）修改版次：REVISION48）标记： MARKED49）管口标高、尺寸和等级：ELEV ATION SIZE AND RATING OF NOZZLES8 技术要求及特性表中常用语1）FLUID (OR MEDIUM)：介质2）FLAMMABLE：易燃3）HAZARDOUS：危害性的4）TOXIC：毒性5）LETHAL：致死的6）SPEC. GRA V.：密度（填充物的）7）DEW POINT：露点8）DESIGN PRESSURE：设计压力9）DESIGN TEMPERATURE：设计温度10）OPERA TING PRESSURE (TEMPERA TURE)：操作压力（温度）11）MAX OPERA TING PRESS & TEMPERA TURE：最大操作压力（温度）12）JOINT EFFICENCY：焊接接头系数13）CORROSION ALLOWANCE：腐蚀裕度14）INSULATION THICKNESS (W ARM/COLD/SOUND)：保温层厚度（暖、冷、声）15）ULTROSONIC EXAMINATION：超声波检测16）RADIOGRAPHIC EXAMINA TION：射线检测17）HYDROSTATIC TEST：水压试验18）PHNEUMA TIC TEST：气压试验19）LEAKAGE TEST：气密性试验20）KEROSENE LEAKAGE TEST：煤油渗透试验21）AMMONIA GAS LEAKAGE TEST：氨渗透试验22）HEAT TRANSFER AREA：换热面积23）TRIANGULAR PATTERN：三角形排列24）SQUARE PA TTERN：正方形排列25）SAFETY V ALVE SET PRESSURE：安全阀启跳压力26）RUPTURE DISK BURSTING PRESSURE：爆破膜爆破压力27）NET WEIGHT：净重 N.W28）EMPTY WEIGHT：空重 E.W29）WEIGHT WITH WA TER：充水重30）TOTAL WEIGHT：总重T.W31）V ACUUM：真空32）FULL V ACUUM：全真空 F.V33）CAPACITY：容积34）MINIMUM DESIGN METAL TEMPERATURE：MDMT最低金属应力温度35）INTERGRANULAR CORROSION TEST：晶间腐蚀试验36）IMPACT TEST：冲击试验37）IMPACT SPECIMEN：冲击试样38）CHARPY IMPACT TEST：夏比冲击试验39）MINIMUM IMPACT ENERGY：最小冲击功40）V-NOTCH：V型切口9 常用技术要求的英文译法1）采用锻件按JB4726 II级为合格：FORGING MATERIAL SHOULD BE APPLIED AND INSPECTED AS II OF JB4726 REQUIREMENTS2）焊接采用电焊，焊条牌号为×××：SMAW SHALL BE APPLIED, AND THE ELECTORDE TYPE IS ××× 3）补充技术要求：SUPPLEMENT TECHNICAL REQUIREMENTS4）未注明角焊缝焊角高度按较薄板厚度：UNLESS OTHERWISE SPECIFIED, THE FILLET WELD LEG SIZE SHALL BE EQUAL TO THE THICKNESS OF THE THINNER PLA TE TO BE WELDED ON.5）板材以正火状态供货：THE STEEL PLATE (可填具体材料) SHALL BE SUPPLIED AS NORMALIZED CONDITION6）除图中注明外，焊接接头型式及尺寸按HG20583-2019中规定，法兰的焊接按相应法兰标准规定：UNLESS OTHERWISE SPECIFIED IN THIS HEREIN DWG, THE WELD TYPES AND DIMENSIONS SHALL BE AS PER STIPULATED IN HG20583-2019, AND PIPE(OR NECK) TO FLANGE JOINTS AS PER RELEV ANT FLANGE STANDARDS REGULATIONS 7）未注圆角为Rx：UNLESS OTHERWISE SPECIFIED, THE ROUND RADIUS IS Rx8）未注倒角为××：UNLESS OTHERWISE SPECIFIED, THE DIMENSION OF CHAMPER IS ××9）“A”与“B”配钻：“A” SHALL BE DRILLED WITH “B” TOGETHER10）“A”与“B”对中：SAME AXIES FOR “A” AND “B”11）含××半圆孔：×× SEMICIRCLE HOLES COUNTED10 常用介质1）HYDROGEN：氢气2）OXYGEN：氧气3）NITROGEN：氮气4）CARBON OXIDE：一氧化碳5）CARBON DIOXIDE：二氧化碳6）HYDROGEN SULFIDE (H2S)：硫化氢7）AMMONIA (NH3)：氨8）METHANOL：甲醇9）INERT GAS：惰性气10）LPG(LIQUEFIED PETROLEUM GAS)：液化石油气11）SOUR GAS：酸性12）ALKALIZATION WA TER(ALKALIZED WATER)脱盐水：13）SYNGAS (OR SYNTHESIS GAS)：合成气14）SHIFTED GAS：变换气15）RECYCLE GAS：循环气16）POL YMETER：聚合物17）DIESEL：柴油18）METHANE：甲烷19）RESIDUE OIL：渣油20）CRUDE OIL：原油设计图layout；design施工图final平面图plan立面图elevation轴测图、透视图isometric drawing；detail drawing详图、大样图、接点图record drawing修改图竣工图as-completed drawing；as-built drawing 图名 title图号 drawn No.比例 scale温度 temperature设计温度design temperature湿度 humidity流量 flow流速 flow velocity摄氏温度centigrade scale(℃)华氏温度Fahrenheit scale(°F)公称直径nominal diameter(DN)外径 outside diameter(OD)内径 inside diameter(ID)一览表list；breviate；catalogue毛重 gross weight净重 net weight支座 saddle支架 support吊架 cradle间距 distance；clearance；spacing跨距 span焊接 welding焊缝 weld；welding seam；bead石棉水泥接口asbestos-cement joint青铅接口lead joint承口、大头 hub；bell；socket插口、小头 spigot压力试验pressure test水压试验hydraulic test渗漏 leakage关闭 close型号、类型 type；model尺寸、体积 size；volume额定功率rating power额定转速rotating speed授权经销商 authorized dealers原始设备制造商OEM (Original Equipment Manafacture)风机动力型V A V-CA V末端fan power V A V-CA V terminal units保持最新技术keep with the latest technology中国唯一的销售商 the sole Chinese distributor工程管理，设计，施工，服务，或者商务管理project management, design, construction, service, or business administration用于商业和工业空气运动与洁净室的环境控制系统Environment Control System for Commercial & Industrial Air Movement & Clean-rooms温湿度精确控制Precision Temperature & Humidity Control个性化温度控制Individual Zone Temperature Control节能 Energy Conservation能量管理系统Energy Management Systems中央冷冻系统Central Chiller Systems能量回收系统Energy Recovery Systems工作现场，工地jobsiteHV ACR系统与BAS/DDC控制系统之间的桥接装置A Bridge Role in HV AC & R System and BAS/DDC ControlHV AC总成本和投资估算Total HV AC cost and investment evaluation系统设计和应用System design and application系统和设备的选择、效率和运行成本System and equipment selection, efficiency and operating cost和其他工种的配合Coordination with other departments监督工程进度、分配时间和施工工作Monitoring project progress, delivery time and construction work设备购买，运输，质量保证 Appurtenances purchase, delivery and warranties执行设计计划并应对工程部门的检查Implementing the design plan and subject the work to the inspection of the Engineering Department详图、大样图、接点图detail drawing流量 flow volume流速 flow velocity, flow speed一览表list；breviate；catalogue, detail summary支座 saddle for transform face and foundation for equipments,支架 support中国的销售商 the sole Chinese distributor能量恢复系统Energy Recovery Systems工作现场，工地jobsiteplus:系统原理图 P&ID (Piping And Instrument Diagram)大小头reducer盲板法兰 spectacle flange盲板 blind flangeand :angle bar, flat bar, round bar, bould plate, bulk plate。
