武钢连铸机结晶器安装过程照
合集下载
相关主题
- 1、下载文档前请自行甄别文档内容的完整性，平台不提供额外的编辑、内容补充、找答案等附加服务。
- 2、"仅部分预览"的文档,不可在线预览部分如存在完整性等问题,可反馈申请退款(可完整预览的文档不适用该条件!)。
- 3、如文档侵犯您的权益，请联系客服反馈,我们会尽快为您处理(人工客服工作时间：9:00-18:30)。
Embedded Slab for Oscillator baseframe
Preparation works on slabs by grinding
grinding of slab surface
Surface must be checked by spirit level
Mounting plate with adjusting bolts
welding of support plates with slab
Final alignment of plates
Assembled base frame
Lifting of base frame
Temporary fixation of distance plate with fit on base frame by tack welding
Mounting base frame
Mounting base frame
after erection of base frame remove tack weld on distance plate
Alignment of base frame by using adjusting bolts
Alignment base frame
Adjusting bolts for alignment base frame
Mounting hydraulic Cylinder on oscillator(site)
or on the Oscillator Maintenance Stand (for easier handling)
Mounting Oscillator
