基于ZigBee技术农业无线温湿度传感器网络与农业生产实践相结合,提出了农业无线和湿度传感器网络设计,它基于ZigBee技术。

我们使用基于CC2530 ZigBee协议作为数据的采集,传输和显示的传感器节点和协调器节点的芯片,目的是实现农业生产自动化和精确农业。

关键词:农业,生产,温度和湿度,无线网络,传感器。

1.简介目前,生产和生活的许多方面都需要提取和加工周围环境的温度和湿度信息。

在过去的技术是收集温度和湿度传感器的温湿度信息,并通过RS-485总线或现场总线再次发送数据到监控中心,所以你需要铺设大量的电缆来收集温度和湿度信息。

传统农业主要使用孤立的机械设备,没有沟通能力,主要依靠的人来监控作物生长状况。

然而,如果使用ZigBee无线传感器网络技术,农业将逐步转变为信息和生产的为主的生产模式,使用更加自动化,网络化,智能化的耕作方式,实现远程无线控制设备。

传感器可以收集信息,如土壤水分,氮浓度,pH值,降水,温度,空气湿度,空气压力等。

采集到的上述信息和所收集信息的位置被传递到中央控制设备用于通过ZigBee网络的决策和参考,所以我们可以提前和准确地识别用于帮助维持和提高作物产量的问题。

在许多面向数据的无线网络传输,低成本和复杂性的无线网络被广泛地使用。

2. ZigBee的技术特点ZigBee技术是一种短距离,低复杂度,低功耗,低数据速率,和低成本,双向无线通信技术,主要是采用在自动控制和远程控制的领域中,可以嵌入各种设备中,以实现他们的自动化[1]。

对于现有的各种无线通信技术,ZigBee技术将是最低功耗和成本的技术。

ZigBee的数据传输速率低,在10KB/ s到250KB/ s的范围内,并主要集中在低速率传输。

在低功耗待机模式下,两个普通的5号电池可以持续6至24个月。

ZigBee的数据传输速率低,并且它的协议很简单,所以它大大降低了成本。

而它的网络容量大,可容纳65000设备。

延迟时间很短,一般在15毫秒〜30毫秒。
