森海塞尔E W中文使用说明书Revised final draft November 26, 2020森海塞尔EW100中文使用说明书森海塞尔EW-100系列无线话筒使用方法：发射器使用方法：发射器开关按钮：转动手持话筒底部之保护盖（ON/OFF）位置按（ON/OFF）开关只按钮，直至LED红灯亮（开）。
若要关话筒，程序也是一样。
LED灯亮表示电池量充足，如电池量不足，LED红灯会出现闪烁。
哑音控制（MUTE），使用哑音控制只是将话筒头输出讯号哑音，对接收器并无影响。
方便使用者在调校收发时不会对扩声器材造成破坏。
按（SET）设置按钮。
可选择项目，转换下一项目，按↑是增加数值和选项，按↓是衰减数值和选项.无线话筒（SEnSit）灵敏度调整：演出—30dB/—20dB；一般讲话—20dB/10dB；访问—10dB。
建议演出当中使用（—20dB)。
接收器使用方法：按（POWER）红色按钮开关制。
LCD液晶显示屏亮。
按（SET）设置按钮选择各项功能，选择所需项目后在按一下确认。
选定所需功能后可按↑↓作项目数值增减选择。
当格栏显示屏出现（MUTE）哑音字样显示时，表示发射器现状未能配合。
EM100接收器：内置四个通道/频率，频率范围共有五区：A区：518—550MHZ?B区：630—662MHZ?C区：740—772MHZD区：790—822MHZE区：838—870MHZ从A区：518—550MHZ共分成16个可同时使用通道（差数为32MHZ），每次可作25KHZ增减。
共有1280段，除去工厂预置4个通道/频率外，还有12个可同时使用频率可选择。
若5区共用，16通道乘以5区，就可供80套一起使用。
100系列常见问题:A如何从接收器寻找工厂预置频率？首先按（SET）设置按钮，找出（CHANNL）通道，在按↑（FREQU）频率字样就会闪动，就可按（SET）设置钮确认。
再按↑或↓就可看见工厂预置频率。
B如何将频率作25KHZ微调?首先按（SET）设置按钮，找出（TUNE）调整，频率数字就会出现，按↑就增加25KHZ，按↓就衰减25KHZ。
