TC5610 C2 版
TC5610 VERSION C2
QTZ63(TC5610)塔式起重机
QTZ63(TC5610) Tower Crane
使用说明书
Operating Instructions
Changsha Zoomlion Heavy Industry Science and Technology Development Co.Ltd
Heavy Industry Science and Technology Development Co., Ltd. according to the
Chinese standard of JG/T5037-93 “Classification of Tower Crane”.
TC5610 塔机为水平起重臂、小车变幅、上回转自升多用途塔机。该机的特色有： The TC5610 tower crane is a self-climbing multi-purpose machine with a horizontal jib, a trolleying mechanism and an upper slewing mechanism. Its characteristics are: 1. 性能参数及技术指标国内领先，最大工作幅度 50m，最大起升高度 141.3m。
The performance parameters and technical indicator of the crane are at a leading level in China. The Maximum working radius is 50m and the maximum hoisting height is 141.3m. 2. 该机有地下浇基础固定式，底架固定独立式,轨道行走式，内爬式等工作方式，适 用各种不同的施工对象。独立式的起升高度为 40.5m，附着式的起升高度可达 141.3m。
Zoomlion for further consultation.
出厂编号：
Manufacturer's No.
出厂日期：
Shipped Date
