Gazelle S1020i千兆网管型工业以太网交换机
Gazelle S1020i千兆网管型工业以太网交换机专为满足工业领
域自动化控制系统而设计,能在严苛的使用环境中长时间稳定
运行。

Gazelle S1020i拥有业内领先的环网技术,支持多种工
业级冗余环网协议,任意端口均可成环,支持链型、星型、双
星型、环型、相切环、相交环、耦合环,环网50ms内自愈。

Gazelle S1020i具有高可靠性、高安全性、高可管理性,确保
关键数据可靠传输,支持远程管理,并且可以配合瑞斯康达
NView综合网管系统进行集群管理,达到全程无盲点网管。

Gazelle S1020i工业以太网交换机具备极佳的工业现场环境适应性(包含机械稳定性、气候环境适应性、电磁环境适应性等)、防护等级达到IP40、支持双冗余供电、低功耗无风扇散热技术、MTBF平均无故障工作时间可达35年、超长5年质保,不仅可用在电力行业,也可广泛应用于交通、海运、煤炭、石油、冶金、水处理等行业。

千兆上行、线速交换
Gazelle S1020i具有11.2Gbps的总线带宽,为所有端口提供二层线速交换能力,同时可支持千兆上行,满足当前多业务大数据对高带宽的要求。

完备的安全控制策略
Gazelle S1020i支持802.1x认证,在用户接入网络时完成必要的身份认证,支持MAC地址和端口等多元组绑定、风暴抑制和端口锁定功能,保证接入用户的合法性。

Gazelle S1020i支持端口镜像功能,对监控端口的业务和流量进行监控,用于优化部署和恶意攻击监控。

快速自愈的以太环网
Gazelle S1020i任意端口均可成环,且支持多种以太环网协议,包括RRPS、生成树、G.8032(ERPS)和IEC62439-2(MRP),环网自愈时间小于50ms,保证组网节点间数据的高可靠传送。

电信级的QoS能力
Gazelle S1020i支持每个端口8个输出队列,支持队列调度算法:SP(Strict Priority)、WRR(Weighted Round Robin)、WDRR、8SP、1SP+7WDRR/RR、2SP+6WDRR/RR、3SP+5WDRR/RR、4SP+4WDRR/RR、8WDRR/RR,可以以不同的优先级将报文放入端口的输出队列。

支持端口双向限速,限速的控制粒度最小可达64Kbps。

满足用户多业务识别、分类、资源调度的需要。

Gazelle S1020i支持灵活QinQ,客户网络和运营商网络的VLAN可分层管理,使网络架构实现更为灵活。

简单易用的管理和维护
Gazelle S1020i支持SNMP,以及瑞斯康达NView综合网管系统。

Gazelle S1020i支持网络拓扑发现功能,配合综合网管系统实现了设备的集中管理和维护,可对多台设备统一管理,降低了管理成本。

Gazelle S1020i 还支持CLI命令行、SSH、Web网管、Telnet等管理方式,使设备管理更方便。
