晶粒长大fortran程序
蒙特卡洛模拟正常晶粒长大的实时-温度模型

蒙特卡洛模拟正常晶粒长大的实时-温度模型JINHUA GAO and R. G . THOMPSON摘要两种不同的模型,在金属和合金中模拟晶粒正常生长被提出来了。
这些模型的实际应用证明了时间-温度基于蒙特卡洛(MC )模拟材料加工。
一个变形晶界迁移模型加上蒙特卡洛(MC)模拟耦合的第一原则变形晶界迁移模型。
这个模拟的结果显示与在等温条件下晶粒生长的正常长大部分实验结果相关联。
基于模型的实验数据加上蒙特卡洛(MC)模拟晶粒生长的实验数据。
模拟的实验结果显示与钛合金在持续加热的条件下晶粒生长相关联。
1.介绍晶粒尺寸大小可以说是材料最重要的微观特性。
它影响着材料的强度、脆性、韧性、耐腐蚀性、耐热性以及其他性质。
由于它的重要性,晶粒生长在大多材料科学工程研究中成为一个关键科学问题。
Beck 等人[l]提出了等温条件下晶粒生长动力学关系式:nt C D 1= (1)式中:D 是晶粒尺寸半径,1C 是一个系统常数,t 表示时间,n 是动力学时间指数。
后来Burke 和Turnbull [2]推导出等温晶粒生长抛物线关系式:t RT Q C D D ⎪⎭⎫ ⎝⎛-=-exp 2202 (2)式中:0D 是t=0时刻时初始晶粒尺寸半径,2C 是一个系统常数,Q 是晶粒生长活化能,R 是气体常数,T 表示温度。
有许多关于各种金属和合金等温晶粒生长模拟的文献报道。
大多数实验结果表明时间指数n 的理论值在0.5左右[3-7]。
一些实验表明温度和时间指数n 有一定的关系[8-l1]。
Anderson 等人[12]提出了用计算机模拟技术观察晶粒生长,这种方法被叫成为蒙特卡洛(MC )模拟。
在很多关于蒙特卡洛(MC)模拟晶粒生长的出版文献中,模拟晶粒生长动力学被作为真实晶粒生长的动力学,但是在真实时间-温度和模拟时间当中,向前的相关联性的重要性已经被认可。
Ling and Anderson [13]指出蒙特卡洛模拟时间转换到真实时间需要一种隐含的活化能的因素⎥⎦⎤⎢⎣⎡⎪⎭⎫ ⎝⎛-RT W exp ,和原子的跳跃频率相对应。
