开欧客滑板车说明书

CONTENTS

目录

CARAOK SCOOTER features 电动滑板车特征 (2)

CARAOK SCOOTER Main Parts 电动滑板主要部件 (3)

Warnings& general information警告和总说明 (5)

Serial number序列号 (7)

Opening CARAOK SCOOTER展开滑板车 (8)

Folding CARAOK SCOOTER折叠滑板车 (10)

Operation操作 (12)

Charging battery充电与电池 (13)

Power switch电源开关 (14)

Throttle Speed control油门速度控制 (15)

Safety安全 (15)

Tires air pressure胎压 (16)

Driving technique骑行技巧 (17)

Maintenance of flat tire瘪胎的维修说明 (19)

Maintenance 保养 (20)

General Troubleshooting一般故障排除 (21)

Specification and parameter产品规格与参数 (22)

Scope of quality assurance品质保证范围 (23)

one

CARAOK SCOOTER FEATURES 开欧客电动滑板车特点

two

CARAOK SCOOTER MAIN PARTS

开欧客电动滑板主要部件

快速折叠装置自锁/解锁M形按扭

OUICK FODING MECHANISM CARAOK WHEEL MOTOR SELF LOOKING /RELEASE M BUTTOM 电动滑板车轮毂电机

ALUMINUM DECK=ANTI SKID GRIPS

铝甲板+防滑手条

后碟刹

REAR DISC BRAKE BA TTERY CHARGER CONNECTOR

电池充电器接口

t h r e e

维修塑料盖板

MAINTENANCE PLASTIC SPEED CONTROL THROTTLE

ON-OFF BUTTON/BATTERY INDICATOR

调速器/开-关按扭/电池指示灯

LED前大灯/限速开关（左慢右快）喇叭

LED HEAD LIGHT/SPEED LIMIT SWITCH (LEFT

SIDE SLOW RIGHT SIDE FAST)/HORN

快拆杆脚撑

QUICK RELEASE KICKSTAND

four

WARNINGS & GENERAL INFORMATION

警告和总说明

five

CARAOK SCOOTER needs a short period for all moving parts such as hinges and brakes to adjust themselves into their correct

six

position.

开始使用阶段需要一小段路程来使各个部件如铰链和刹车进入正确的位置。

SERIAL NUMBER

序列号

RECORD SERIAL NUMBERS:

Write down the serial number of your CARAOK SCOOTER. Keep this information separately and in a safe place.

Each CARAOK SCOOTER has a unique serial number. These numbers can provide information that may be useful later on for insurance claims and in case of loss or theft.

To find your CARAOK SCOOTER has number:

1.The number is on the bottom of the board, on the side if the front wheel.

s e v e n

2.Note the serial number and keep it in a safe place.

Serial number here

序列号在这

记录序号：

写下你车子的序列号。单独把这些信息保存在安全的地方。

每个滑板车都有一个唯一的序列号。这些数字用于以后保险索赔和丢失或被盗的情况下提供信息。

查找您滑板车的编号为：

数字是在主板的底部，前轮一侧

记下序列号，并保存在一个安全的地方。

e igh t

nine

OPENING CARAOK SCOOTER

展开开欧客滑板车

STEP 1步骤1

To release the M button(lock button),hold the Steering rod in One hand in a far point from the folding mechanism to create a Momentum, and find a point in which there is no pressure on the Opening mechanism, meanwhile creating a gentle pull on the M button in the other hand.

At the right point of no pressure the mechanism will be released and the M button will come out easily. That will enable the folding of the handlebar, CARAOK SCOOTER patent for quick and steady locking is based on exact pressures.

IMPORTANT NOTE!

重要提示！
