承认书SPECIFICATION FOR APPROVAL 客户
Customer：
客户品号
Customer P/N：
鑫光硕品号
Xgs Model：
规格Specification :XGS-PB0802UE-02
SMD 0805侧面红光普亮 20MA
制作
Prepared By：李忠
审核
Checked By：
Customer Confirmation 客户确认采购部Pur Dept By品质部QA Dept By工程部Eng Dept By
深圳市鑫光硕科技有限公司
SHEN ZHEN XIN GUANG SHUO TECHNOLOGY CO.,LTD
公司地址：广东省深圳市宝安区沙井万丰村前路31号8楼
一厂地址：广东省深圳市龙岗区嶂背创业二路18-1号
二厂地址：广东省东莞市石排镇庙边王村沙迳工业区
Tel:
Website ：
H
Data Sheet PN: XGS-
PB0802UE-02 For:
IF=20mA
Contents
3.P ackage dimensions
4.A bsolute maximum rating
optical characteristics range
label pad dimensions
conditions
10.Package tape specifications
11.T ypical electro-optical characteristics curves
test items and conditions
14.Note
Part No.XGS-PB0802UE-02
Emitted Color High Super Red Len's Color Water Clear Chip Material AlGaInP----
◆Features:
Compatible with automatic placement
equipment Compatible with reflow solder
process
Low power consumption and wide viewing angle
This product doesn’t contain restriction Substance, comply ROHS standard.
◆Applications:
Automotive and Telecommunication
Flat backlight for LCD ,switch and symbol in telephone and fax
General use for indicators
◆Package Dimensions:
Unit:mm
Electrodes: Ag Plating Tolerance±
◆Absolute Maximum Rating （Ta=25℃）
FP
◆Electrical Optical Characteristics（Ta=25℃）
Notes: of Luminous Intensity ±10%
of Dominant Wavelength ±2nm
3.Tolerance of Forward Voltage ±
4.Luminous Intensity is measured by XGSLED’s equipment on bare chips
3℃/sec.
260℃ M ax. .
210℃
Pre-heating 120~160℃ 3℃/sec.
-4℃/sec.
60~120sec.
.
◆ Soldering Pad Dimensions:
◆ Soldering Conditions (Maximum allowable soldering conditions)
Reflow soldering profile
<Pb-free solder>
Time
• Reflow soldering should not be done more than two times. • Do not stress its resin while soldering.
• After soldering,do not warp the circuit board.
T e m p e r a t u r e
225
◆ Package Tape Specifications: ( 4000 pcs/Reel)
Reel Lead No LEDs
470
225
250
60
320
5 Reels in one Box 10 Boxes in one Carton
◆ Typical Electro-Optical Characteristics Curves ：
Forward Current Vs Ambient Temperature
50
40
30
20
10
200
175 150 125
10
75
50 25 0 Forward Current Vs Relative Luminosity Ta=25℃
20
40
60
80
100
10 20 30 40 50
Ambient Temperature Ta (° C)
Forward Current (mA)
200
150
100
50 Relative Luminosity Vs
Ambient Temperature
If=15mA
-50° -60°
-70°
-80°
-90°
-40°
-30°
-20°
-10°
0°
10°
20°
30°
40°
50°
60°
70°
80°
90°
0 0
20
40
60
80
100
Radiation Angle
Ambient Temperature Ta (° C)
R e l a t i v e L u m i n o s i t y (%)
F o r w a r d C u r r e n t (m A )
R e l a t i v e L u m i n o s i t y (%)
◆Reliability
(1)Test Items and Conditions
(2)C riteria of judging the damage
* Upper standard level Lower standard leve
◆Cautions
1、Package
When moisture is absorbed into the package it may vaporize and expand during soldering. There is a
possibility that this can cause exfoliation of the contacts and damage to the optical characteristics of the LEDs. So the moisture proof package is used to keep moisture to a minimum in the package.
2、Storage
Before opening the package: The LEDs should be kept at 5~30°C and 60%RH or less. The LEDs should be used within a year.
After opening the package: The LED must be used within 24 hours, else should be kept at 5~30℃
and 30% RH or less. The LEDs should be used within 7days after opening the package. If unused LEDs remain, they should be stored in moisture proof packages, recommended to return the LEDs to the original moisture proof bag and to reseal the moisture proof bag again.
If the LEDs have exceeded the storage time, baking treatment should be performed more than 24hours at 60±5°C.
3、Soldering Iron
Each terminal is to the tip of soldering iron temperature less than 300℃ for 3 seconds within once in
less than the soldering iron capacity 25 two seconds and more internals, and do soldering of each terminal. Be careful because the damage of the product is often started at the time of the hand solder.
4、Repairing
Repairing should not be done after the LEDs have been soldered. When repairing is unavoidable, a double-head soldering iron should be used (as below figure). It should be confirmed beforehand whether the
characteristics of the LEDs will or will not be damaged by repairing.
5、The LED electrode sections are comprised of a gold plated. The gold surface may be affected by environments which contain corrosive gases and so on. Please avoid conditions which may cause the LED to corrode or discolor. This corrosion or discoloration may cause difficulty during soldering operations. It is recommended that the User use the LEDs as soon as possible.
6、Please avoid rapid transitions in ambient temperature, especially in high humidity environments
where condensation can occur.
◆Notes:
1、Above specification may be changed without notice. We will reserve authority on material change for above specification.
2 、 When using this product, please observe the absolute maximum ratings and the instructions for the specification sheets. We assume no responsibility for any damage resulting from use of the product which does not comply with the instructions included in the specification sheets.。
