太阳能充电器说明书一、产品结构：内置高容量储蓄锂电池（18650），IC智能过流过载保护，单晶硅光伏电池板2W，220V，50HZ单相交流，LED镇流驱动显示，整机由交流，USP直流，单晶硅光伏充电等多功能储藏电荷。
部份产品带LED灯手电照明，收音机功能，铝合金外壳。
二、产品特点：容电量大，华贵大方，携带方便，时尚高雅，节能环保，充电1小时搞定，特别适合出差，旅游，长途乘车，找工作，野外施工，商务会议等手机充电。
只要接入手机就能使用，并适用于数码照相机，DV，PDA，MP3，MP4，GPS，平板电脑及部份笔记本电脑电源充电，产品用途广泛。
三、技术参数：输入交流AC220V，50HZ，储存电能充电时间：1~3小时，直流DC3V接USB电脑接口，储存电能充电时间：2~5小时，光伏储存电能：6V，2W，60一150MAX，转换效率25%以上，储存电能时间：6~8小时，指示灯显示100%，表示储存电能充满，输出电压：4．5V，5V，6V，9V，12V等多个供电选择，充满电后自动恒压3．7~4．2V。
不会损坏手机，电流：2600MAH一5000MAH，最大10000MA。
手机充电时间1小时搞定。
四、使用方法：1、使用本产品前要交流充电，以提高内存电池的使用效率。
2、接口IN为输入储存电能充电，接口OUT为输出给手机充电或其它产品充电。
3、手机充电前要选好与手机相符合的电压档，一般选4．5V，视手机能量而定。
4、看手机屏信号是否处于充电状态。
五、注意事项：1、光伏充电时，要光伏正面向光直射，确保效果。
2、注意防潮，防高温，防划伤光伏表面。
3、请用厂家提供的专用数据充电适配线和转接头。
4、不可用短路或损坏的电池接入充电，否则会损坏充电宝。
5．没有显示充电，可能内存电能不足或接触不良。
