GF66x8 系列指纹识别芯片
1. 概述
GF66x8 系列是一款专门针对移动设备，基于电容检测技术开发而成的触摸式指纹检测芯片。GF66x8 系列表面盖板采用超强硬度的蓝宝石制作，可支持 360 任意方向触摸，以及 508PPI 的高解析度，充分满足消费者方便、耐用和安全的应用需求。根据颜色不同包含 GF6618、GF6628、GT6638、GT6648 四个型号。
